HP P4522A - Traffic Management Server Sa8220 User manual

hp traffic director
server appliances
user guide for the hp e-commerce
traffic director server appliance
sa8200/sa8220 and the hp traffic
director server appliance sa7200/
sa7220

© Copyright 2001 Hewlett-Packard Company. All rights
reserved.
Hewlett-Packard Company
3000 Hanover Street
Palo Alto, CA 94304-1185
Publication Number
5971-0900
February 2001
Disclaimer
The information contained in this document is subject to change
without notice.
HEWLETT-PACKARD COMPANY MAKES NO WARRANTY
OF ANY KIND WITH REGARD TO THIS MATERIAL,
INCLUDING, BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE. Hewlett-Packard shall not be liable for
errors contained herein or for incidental or consequential damages in
connection with the furnishing, performance, or use of this material.
Hewlett-Packard assumes no responsibility for the use or reliability
of its software on equipment that is not furnished by Hewlett-
Packard.
Warranty
A copy of the specific warranty terms applicable to your Hewlett-
Packard products and replacement parts can be obtained from
http://www.hp.com/serverappliances/support.
*Other brands and names are the property of their respective owners.

Contents
Chapter 1: Introduction 1
Introduction to the Traffic Director Server Appliances . . . . . . . . . . . . . . . . . . . . . . . . 2
Assumptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Benefits. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Typographic Conventions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Chapter 2: Theory of Operations 11
General Operating Principles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Layer 4 (HOT) Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Layer 7 (RICH) Services (all models except the SA7200). . . . . . . . . . . . . . . . 13
Out-of-Path Return (OPR) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
FTP Limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

C O N T E N T S HP Traffic Director Server Appliances User Guide
ii
Sticky Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Sticky Persistence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Sticky-timeout. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Server-timeout (SA8200/SA8220 only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
SSL and Sticky (SA8200/SA8220 only). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Grouping Services. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
SSL Acceleration (SA8200/SA8220 only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
SSL Fundamentals (SA8200/SA8220 only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Application Message Traffic Management. . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
HTTPS Redirect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Client Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
HTTP Header Option Fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Load Balancing Across Multiple Servers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Balancing Algorithms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Response-Time Metrics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Primary and Backup Servers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Server Configuration Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Source Address Preservation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Multi-hop Source Address Preservation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
RICH Expressions (not available on the SA7200) . . . . . . . . . . . . . . . . . . . . . . 25
Order of Expressions (not available on the SA7200) . . . . . . . . . . . . . . . . . . . . 26
Routing with Dual Interfaces. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Prioritization and Policy Groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Routing Method for VIP Addresses. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Error Detection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Server Status Detection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
HTTP Error Detection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Serial Cable Failover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Serial Cable Failover Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Replicating the Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Status Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Contents
iii
Chapter 3: Boot Monitor 41
Using the Boot Monitor CLI. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
System Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Accessing the Boot Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Interrupting the Bootup Sequence. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Using the Run Time CLI. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Boot Monitor Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Chapter 4: Graphical User Interface 59
Before You Begin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Logon Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Logging on to the GUI. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Topology Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Using the Topology Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Purposes of the Topology Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Topology Screen Toolbar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Online Help. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Topology Screen Elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Window Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Policy Manager Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Policy Manager Controls and Displays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Policy Manager Toolbar. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Policy Manager’s Pop-up Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Policy Groups. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Creating Policy Groups. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Throttling. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Deleting Policy Groups. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Creating Services. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Additional Service Tab Controls and Displays. . . . . . . . . . . . . . . . . . . . . . . . . 73
Balance Strategy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Deleting Services. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Servers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
RICH Controls (all models except the SA7200). . . . . . . . . . . . . . . . . . . . . . . . 79
Order of Expressions (all models except the SA7200) . . . . . . . . . . . . . . . . . . . 81
Deleting Servers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

C O N T E N T S HP Traffic Director Server Appliances User Guide
iv
Administration Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Settings Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Software Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
System Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Agent Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Users Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Routing Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
System Role. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Active Routing Protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
RIP Protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
OSPF Protocol. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Security Tab. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Source IP Filtering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Access Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
GUI Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
CLI Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
SNMP Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
SNMP Agent. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Multi-Site Tab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Logging Tab. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
Specifying System Log Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
Viewing the Log File. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Configuration Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Saving Configuration Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
Restoring Configuration Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
Deleting Configuration Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Copying Configuration Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Viewing Configuration Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
Resetting the Factory Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
Sending and Retrieving Configuration Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
Tools Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
ARP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
Ether. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
Ping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
Netstat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119

Contents
v
Nslookup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Reboot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
Trace. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
Traceroute . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
Statistics Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Statistics Screen Controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Statistics Box. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
Graph Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
Selection List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
Window Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
Graphing Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
Chapter 5: Command Line Interface 133
CLI Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134
Secure Shell Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134
Online Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134
Pipes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
Syntax. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
Categorical List of CLI Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
Global System Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
Admin Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
File Management Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
CLI Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
IRV Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
GUI Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
Routing Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139
Policy Group Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139
Service Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139
Server Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
System Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
Security Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141
SNMP Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142
SSL Commands (SA8200/SA8220 only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142
Logging Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143
Show Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143

C O N T E N T S HP Traffic Director Server Appliances User Guide
vi
Run-Time CLI Command Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145
Global System Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145
Admin Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152
File Management Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152
CLI Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155
IRV Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 158
GUI Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 158
Routing Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160
Policy Group Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163
System Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175
Security Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179
SNMP Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 182
SSL Commands (SA8200/SA8220 only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 185
Logging Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 199
Show Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201
Chapter 6: Scenarios 207
e-Commerce Appliance Scenarios . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 208
Scenario 1: Load Balancing a Web Site with Two Servers and the SA8220 in Inline
Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 208
Prerequisites for Scenario 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 209
Procedure for Scenario 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 209
Scenario 2: Load Balancing Servers with Source Address Preservation . . . . . . 214
Prerequisites for Scenario 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 215
Procedure for Scenario 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 215
Scenario 3: Routing Outbound Data Away from the SA8220 for OPR . . . . . . . 217
Prerequisites for Scenario 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 218
Procedure for Scenario 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 218
Scenario 4: Content Routing (SA7220 and SA8200/SA8220 only). . . . . . . . . . 220
Prerequisites for Scenario 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 221
Procedure for Scenario 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 221
Scenario 5: Using SSL Acceleration (SA8200/SA8220 only) . . . . . . . . . . . . . . 226
Procedure for Scenario 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 227
Scenario 6: Using CRLs (SA8200/SA8220 only). . . . . . . . . . . . . . . . . . . . . . . . 228

Contents
vii
Chapter 7: SNMP Support 233
Using SNMP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 234
Standards Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 234
HP MIB Tree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 235
Supported MIBs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 236
Where to find MIB Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 236
Trap Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 242
Standard SNMP Traps. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 242
Displaying SNMP Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 243
Configuring Community Authentication and Security Parameters . . . . . . . . . . . 243
Configuring Trap Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 245
Other Configurable SNMP Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 245
Chapter 8: Software Updates 247
Updating Your System Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 248
Multiple Software Images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 248
Software Image Media. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 248
Saving Your Current Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 248
Downloading and Installing the Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 249
Rebooting with the New Image and Verifying Installation. . . . . . . . . . . . . . . . . 250
Upgrading Under Serial Cable Failover Configuration. . . . . . . . . . . . . . . . . . . . 251
Appendix A: Security Configuration 253
Recommended Security Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 253
Appendix B: SSL Configuration 255
Obtaining Keys and Certificates. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 255
Copying and Pasting Keys and Certificates. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 256
Obtaining a Certificate from Verisign or another CA . . . . . . . . . . . . . . . . . . . . . 257
Procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 257
Importing Keys into the SA8220. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 258
Importing Certificates into the SA8220. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 259
Creating a new Key/Certificate on the SA8220. . . . . . . . . . . . . . . . . . . . . . . . . . 260
Procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 260

C O N T E N T S HP Traffic Director Server Appliances User Guide
viii
Using Global Site Certificates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 261
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 261
Using the CLI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 261
Generating a Client CA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 263
Generating a CRL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 264
Revoking a Certificate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 265
Using Ciphers with the SA8220 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 265
HTTP Header Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 267
Appendix C: Failover Method Dependencies 269
Failover Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 269
Appendix D: Configuring Out-of-Path Return 273
Configure OPR for Windows* 2000* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 273
Set the Loopback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 273
Configure OPR for Windows* NT*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 288
Set the Loopback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 288
Run a Web Service on the Loopback Interface Using IIS 3.0 . . . . . . . . . . . . 295
Run a Web Service on the Loopback Interface Using IIS 4.0 . . . . . . . . . . . . 296
Configuring OPR for Apache Web Server on a UNIX* machine . . . . . . . . . . . . . . 297
Appendix E: Diagnostics and Troubleshooting 299
Running Diagnostics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 299
Diagnostic LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 300
Power Indication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 300
Boot-time LED Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 301
Run time LED Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 301
Run time Errors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 302
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 303
Appendix F: Cleaning the Dust Filter 307
Background. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 307
Dust Filter Cleaning Procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 308

Contents
ix
Regulatory Information 309
Taiwan Class A EMI Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 309
VCCI Class A (Japan). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 309
VCCI Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 310
Australia . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 310
FCC Part 15 Compliance Statement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 311
Canada Compliance Statement (Industry Canada). . . . . . . . . . . . . . . . . . . . . . . . . . 312
CE Compliance Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 312
CISPR 22 Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 312
WARNING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 313
AVERTISSEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 314
WARNUNG . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 315
AVVERTENZA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 316
ADVERTENCIAS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 317
Wichtige Sicherheitshinweise. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 318
Software License Agreements 321
Support Services 325
Support for your SA8220 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 325
U.S. and Canada. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 325
Europe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 326
Asia . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 327
Latin America . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 328
Other Countries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 328
Glossary 329

C O N T E N T S HP Traffic Director Server Appliances User Guide
x
Notes

Introduction
This chapter covers the following topics:
NOTE: For ease of
reading, all models are
referred to as the SA8220
throughout this
document. Unless noted
otherwise, all SA8220
references refer to all
models.
•Introduction to the Traffic Director Server Appliances
•Assumptions
•Benefits
•Specifications
•Typographic Conventions

C H A P T E R 1 HP Traffic Director Server Appliances User Guide
2
Introduction to the Traffic Director Server
Appliances
The HP e-Commerce Traffic Director Server Appliance SA8200/
SA8220s and the HP Traffic Director Server Appliance SA7200/
SA7220s provide reliable load balancing, failover, and policy-based
management to Web sites, Intranets, and e-Commerce sites. These
models also include intelligent content routing, and are the best load
balancing solution available for the reasons shown below.
Feature Description
Reliability The SA8220 provides 7 x 24 uptime through failover systems and
the inherent robustness of leading network protocols.
Fault Resistance The SA8220-managed configurations offer many features and
capabilities that improve the availability and reliability of server-
based services.
Policy-based
Management The SA8220 allows system administrators to implement classes of
service, assign priority levels, and set target response times.
Intelligent Content
Routing (SA8200/
SA8220 only)
The SA8220 takes application-aware routing to a new level with
the ability to segment Internet content according to the requested
URL.
Error Recovery Application intelligence allows the SA8220 to understand and
correct application errors transparently to the end user.
Secure Sockets Layer
Acceleration (SA8200/
SA8220 only)
The SA8220 can offload encrypted web traffic (HTTPS) providing
a significant performance improvement over web server based
Secure Sockets Layer (SSL) processing.

C H A P T E R 1 Assumptions
3
Assumptions
This User Guide assumes that you are a network administrator and
that you have at least a basic understanding of the following:
•Networking concepts and terminology
•Network topologies
•Networks and IP routing
Benefits
SA8220 benefits are listed below.
Benefit Description
Substantial performance
boost and reliability for
e-Commerce
(SA8200/SA8220 only)
The SA8220 can increase the speed, scalability, and reliability of
multi-server e-Commerce sites. It regains the speed lost by servers
processing secure transactions by delivering faster SSL
processing. It integrates SSL processing with third generation
traffic management technology, eliminating errors and improving
Quality of Service (QoS). This unique capability ensures that
customers working with sensitive information or buying online
receive timely responses, do not see error messages, and are
confident that delivery of their information is kept private.
Up to 150 times SSL
acceleration
(SA8200/SA8220 only)
E-Commerce sites suffer dramatic performance degradation as
secure transactions increase. Using patent-pending technology to
perform cryptographic processing offloaded from the server, the
SA8220 (only) can support up to 1200 SSL connections per
second.
The SA8220 enables e-Commerce sites to transact secure business
and deliver sensitive information quickly, and confidentially. It
performs all key management and encryption. The result is a
tremendous performance boost for heavily trafficked e-Commerce
sites.

C H A P T E R 1 HP Traffic Director Server Appliances User Guide
4
Substantial economic
benefits
(SA8200/SA8220 only)
The SA8220 improves customer satisfaction by improving the
response time for secure transactions. E-Commerce sites can now
enjoy the benefits provided by having secure transactions
participate in layer 7 intelligent traffic management. This creates
substantial economic savings for e-Commerce sites through
improved customer satisfaction, lower cost of ownership, and
reduced server provisioning requirements.
SSL acceleration and
intelligent traffic
management benefits
(SA8200/SA8220 only)
Performance degrades dramatically as more customers access a
site in secure SSL mode, frustrating to the very customers who are
trying to make a purchase. The SA8220 is essential to providing
high performance and superior levels of service when building
reliable, scalable, and secure e-Commerce sites.
Off-loading SSL handling from e-Commerce servers improves
overall site performance and customer response time
Accelerated SSL processing eliminates over-provisioning capacity
Lower processing demands on the server creates greater capacity
for your e-Commerce site
Drop-in installation avoids impacting your mission critical e-
Commerce servers
Response-time based prioritized service for secure transactions
Improved responsiveness, reliability, and QoS for secure
transactions means delivering the highest levels of support for
paying customers
Ensures that e-Commerce merchants are always open for business
by preventing “Server Too Busy”and “File Not Found”errors,
even for secure transactions
Benefit Description

C H A P T E R 1Benefits
5
Intelligent content
routing for SSL
transactions
(SA8200/SA8220 only)
The SA8220 incorporates intelligent traffic management for secure
transactions, dramatically improving an e-Commerce site’s
responsiveness, reliability, and QoS. While typical traffic
management devices make decisions based only on information at
Layer 4 in the network stack, the SA8220 combines Layer 4
through 7 (application/content) awareness to speed up response
times and eliminate error messages for secure transactions. It
keeps e-Commerce sites open for business, even during back-end
transaction problems or content glitches.
Intelligent session
recovery for
transactions
(all models except the
SA7200)
The SA8220 provides Intelligent Session Recovery technology for
transactions. By monitoring content within the response sent back
by the server, Intelligent Session Recovery detects HTTP 400,
500, or 600 series errors, transparently rolls back the session, and
redirects the transaction to another server until the request is
fulfilled.
Response-time base
prioritized service for
secure transactions
The SA8220 enables system administrators to implement varying
classes of service, assign priority levels, and set target response
times for secure transactions. The SA8220 continually measures
the response times of each class of service group and assigns
incoming requests to the server that can fulfill those requests
within the predefined response time. If the response time exceeds
the predefined threshold, requests designated as high priority
receive preference over those of lower priority. The SA8220
allows you to offer predictable performance for high-priority
secure requests.
Benefit Description

C H A P T E R 1 HP Traffic Director Server Appliances User Guide
6
Specifications
SA8220 specifications are listed below.
Specification Description SA7200 SA7220 SA8200/
SA8220
Servers
supported Any Web server (Apache, Microsoft,
Netscape, etc.) XXX
Any operating system (UNIX*, Solaris*,
Windows NT*, BSD*/BSDI*, AIX*,
etc.)
XXX
Any server hardware (SUN, HP, IBM,
Compaq, SGI, Intel-based platforms,
etc.)
XXX
No practical limit on number of servers XXX
System
Administration Command line interface XXX
Web-based GUI XXX
SNMP monitoring (MIB II and Private
MIB) XXX
Dynamic configuration through
password-protected serial console,
telnet, SSH v1, and SSH v2
XXX

C H A P T E R 1 Specifications
7
Performance SA8220 is rated up to 1200 HTTPS
connections/sec, 2500 RICH HTTP
connections/sec, 3500 HOT connections/
sec, 95 Mb/sec.
SA8200 is rated up to 600 HTTPS
connections/sec, 1300 RICH HTTP
connections/sec, 2800 HOT connections/
sec. Both the SA8200 and the SA8220
are rated up to 6600 Max HTTP/
HTTPS/sec.
XXX
Layer 7 traffic management XX
Patent-pending technology offloads all
cryptographic processing from server XXX
Dimensions Mounting: Standard 19-inch rack mount XXX
Height: 3.5 inches (8.9 cm) XXX
Width: 17 inches (43.2 cm) XXX
Depth: 20.16 inches (51.21 cm) for the
SA7200, SA7220, and SA8220
Depth: 23.75 inches (60.3 cm) for the
SA8200
XXX
Weight 24 pounds (10.89 kg) XXX
Interface
Connections Dual 10/100 Ethernet XXX
TTY Serial - console XXX
Failover port XXX
Transparent
Operation Supports single or multiple Virtual IP
(VIP) addresses per domain XXX
Priority Classes Application/protocol types supported:
Any TCP Port, e.g., HTTP, HTTPS, FTP XXX
Specification Description SA7200 SA7220 SA8200/
SA8220

C H A P T E R 1 HP Traffic Director Server Appliances User Guide
8
Intelligent
Content Routing Content: URL, file types such as *.GIF,
file paths such as \ads\, file names such
as Index.html
XX
Transactions: Transaction types such as
*.CGI XX
Intelligent
Session
Recovery
(HTTPS is
available on the
SA8200/SA8220
only)
Automatically resubmits requests XX
Traps 400, 500, and 600 series errors for
HTTP and HTTPS XX
Response-time
based Priority
for secure and
non-secure
transactions)
Sets and enacts target response times XX
Real-time performance monitoring XX
Automatic server weighting and tuning XX
Server-state aware (“sticky”) based on:
- Source IP XXX
- SSL session ID X
- HTTP cookie XX
System Fault
Tolerance Single site, single or multiple
connections XXX
Automatic detection of status change
and health of servers XXX
Intelligent Resource Verification (IRV) XXX
Specification Description SA7200 SA7220 SA8200/
SA8220
