HP Performance Optimized Datacenter 40c North
America
Maintenance and Service Guide
Abstract
This guide provides maintenance and service guidance for the HP Performance Optimized Datacenter 40c NA (HP POD 40c NA).
Part Number: 756850-001
December 2013
Edition: 1

© Copyright 2013 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express
warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall
not be liable for technical or editorial errors or omissions contained herein.

Contents 3
Contents
Illustrated parts catalog ................................................................................................................. 6
Structural component identification................................................................................................................. 6
Parts and part number identification..................................................................................................... 6
Life safety component identification................................................................................................................7
Electrical power component identification .......................................................................................................8
Control cabinet component identification......................................................................................................11
Cooling system component identification ......................................................................................................12
HP POD 40c NA racks ...............................................................................................................................12
Aisle clearances.........................................................................................................................................13
Cold aisle clearance.........................................................................................................................13
Hot aisle clearance ..........................................................................................................................14
Replaceable components ............................................................................................................................14
Removal and replacement procedures........................................................................................... 15
Safety considerations..................................................................................................................................15
Operator safety................................................................................................................................15
Fire detection and suppression ....................................................................................................................16
Air filter.....................................................................................................................................................16
Removing the air filter.......................................................................................................................16
Replacing the air filter.......................................................................................................................17
Busway drop box.......................................................................................................................................18
Removing the busway drop box.........................................................................................................18
Replacing the busway drop box ........................................................................................................19
Differential pressure sensor..........................................................................................................................20
Removing the differential pressure sensor............................................................................................21
Replacing the differential pressure sensor............................................................................................21
Door position contact..................................................................................................................................22
Removing the door position contact....................................................................................................22
Replacing the door position contact ...................................................................................................22
Drain pan sensor........................................................................................................................................23
Removing the drain pan sensor..........................................................................................................23
Replacing the drain pan sensor .........................................................................................................24
ECS touchscreen ........................................................................................................................................26
Removing the ECS touchscreen ..........................................................................................................26
Replacing the ECS touchscreen..........................................................................................................27
EPO button ................................................................................................................................................27
Removing the EPO button..................................................................................................................28
Replacing the EPO button..................................................................................................................29
EPO LED indicators.....................................................................................................................................30
Removing the EPO LED indicator........................................................................................................30
Replacing the EPO LED indicator .......................................................................................................31
EPO thermister ...........................................................................................................................................32
Removing the EPO thermister.............................................................................................................32
Replacing the EPO thermister.............................................................................................................32
External chilled water flow actuator..............................................................................................................33
Removing the external chilled water flow actuator ...............................................................................33
Replacing the external chilled water flow actuator ...............................................................................35

Contents 4
External chilled water flow valve..................................................................................................................35
Removing the external chilled water flow valve....................................................................................36
Replacing the external chilled water flow valve ...................................................................................36
External pressure gauge isolation valve ........................................................................................................36
Removing the external pressure gauge isolation valve ..........................................................................37
Replacing the external pressure gauge isolation valve..........................................................................37
Fan...........................................................................................................................................................37
Removing the fan .............................................................................................................................38
Replacing the fan .............................................................................................................................39
Fan bank...................................................................................................................................................40
Removing the fan bank .....................................................................................................................40
Replacing the fan bank.....................................................................................................................41
Fire strobe light ..........................................................................................................................................42
Removing the fire strobe light ............................................................................................................42
Replacing the fire strobe light ............................................................................................................43
Humidifier .................................................................................................................................................43
Removing the humidifier....................................................................................................................44
Replacing the humidifier ...................................................................................................................46
Humidistat.................................................................................................................................................47
Removing the humidistat ...................................................................................................................47
Replacing the humidistat ...................................................................................................................48
Humidity sensor .........................................................................................................................................50
Removing the humidity sensor............................................................................................................50
Replacing the humidity sensor ...........................................................................................................52
LED light....................................................................................................................................................53
Removing the LED light .....................................................................................................................53
Replacing the LED light .....................................................................................................................54
Temperature sensor (cold aisle)....................................................................................................................54
Removing the cold aisle temperature sensor ........................................................................................55
Replacing the cold aisle temperature sensor........................................................................................56
Temperature sensor (hot aisle) .....................................................................................................................57
Removing the hot aisle temperature sensor..........................................................................................57
Replacing the hot aisle temperature sensor..........................................................................................59
VESDA filter...............................................................................................................................................60
Removing the VESDA filter ................................................................................................................60
Replacing the VESDA filter ................................................................................................................61
Periodic maintenance.................................................................................................................. 62
Periodic maintenance overview ...................................................................................................................62
Qualified personnel..........................................................................................................................62
Cooling system maintenance schedule................................................................................................62
Humidifier (if installed)......................................................................................................................64
ECS ................................................................................................................................................64
Electrical .........................................................................................................................................65
Fire alarm and suppression system.....................................................................................................66
HP POD 40c NA structure.................................................................................................................67
Life safety........................................................................................................................................67
Access control..................................................................................................................................68
Third-party components.....................................................................................................................68
Specifications............................................................................................................................. 70
General specifications ................................................................................................................................70
Electrical specifications ...............................................................................................................................70
Water specifications...................................................................................................................................71

Contents 5
Rack specifications .....................................................................................................................................71
Thermal and air flow performance ...............................................................................................................71
Environmental specifications........................................................................................................................71
Optional features specifications ...................................................................................................................72
Contacting HP ............................................................................................................................ 73
Before you contact HP ................................................................................................................................73
HP contact information......................................................................................................................73
Regulatory information ................................................................................................................ 74
Safety and regulatory compliance................................................................................................................74
Turkey RoHS material content declaration .....................................................................................................74
Ukraine RoHS material content declaration ...................................................................................................74
Warranty information .................................................................................................................................74
Glossary.................................................................................................................................... 75
Documentation feedback ............................................................................................................. 77
Index......................................................................................................................................... 78

Illustrated parts catalog 6
Illustrated parts catalog
Structural component identification
The HP POD 40c NA documentation frequently refers to the specific components of the HP POD 40c NA as
shown in the following figure and described in the following table.
Item Component Description
1 Heat exchanger access hatches Provides access to the overhead heat exchangers
2 Personnel access doors Provides access to the POD
3 Facility chilled water return Facilitates the return of chilled water to the POD
4 Facility chilled water supply Facilitates the supply of chilled water to the POD
Parts and part number identification
Review the contents of the HP POD 40c NA to identify the following for each component:
•Model number—The model number is located on the door to the control panel inside the cold aisle of
the HP POD 40c NA, as shown in the following figure.

Illustrated parts catalog 7
•Regulatory compliance identification number—This product has been assigned a unique regulatory
model number and is located on the door to the control panel inside the cold aisle of the HP POD 40c
NA, as shown in the following figure.
Life safety component identification
Internal life safety components
Top view shown
Item Component Description
1 Exit sign locations Indicates the location of an exit
2 Fire strobe light Indicates a fire alarm condition within the HP POD 40c NA
3
EPO button Disconnects the HP POD 40c NA from main power feeds

Illustrated parts catalog 8
Item Component Description
4 Fire alarm manual pull* Enables manual initiation of the fire system, which includes
activating the interior and exterior fire strobe lights and the
optional fire suppression system
5 Fire suppression abort button* Aborts the fire suppression system. A fire suppression abort
button is located next to each personnel door.
*This is an optional component that might not be included.
Exit sign locations
Top view shown
External emergency status indicators
The HP POD 40c NA has one external fire strobe light that indicates a fire alarm condition.
Top view shown
Electrical power component identification
WARNING: To avoid the risk of personal injury or loss of life, all personnel must comply with PPE
requirements when opening or working inside areas of the HP POD 40c NA that are marked as
hazardous voltage, per NFPA 70E in accordance with NEC (NA) and IEC (EMEA and APJ).

Illustrated parts catalog 9
WARNING: To avoid the risk of personal injury or loss of life, all personnel must comply with
electrical warning labels when operating and maintaining the electrical panels and systems of the
HP POD 40c NA.
Front view shown
Item Component Description
1 Fire box* Connection location for fire emergency and VESDAnet signals
2 Demarcation box* Customer communication connection point:
•
ECS
•
Security
•
Phone
3 415/240V 3-phase, wye,
4-wire, 800 A electrical
panel
A feed power for critical IT loads (electrical busways) and house power
4 415/240V 3-phase, wye,
4-wire, 800 A electrical
panel
B feed power for critical IT loads (electrical busways) and house power
*The demarcation box and the fire box are communication data points that are provided on the POD by HP. Connecting
these data points is the responsibility of the customer, unless an approved Statement of Work is initiated.
External panel labels

Illustrated parts catalog 10
Front view shown
Callout Electrical safety label Description
1 Danger sign Provides a reminder to users that the electrical panels must be
accessed only by authorized personnel
2 Disconnect label Provides the order for disconnecting all of the electrical panels
3 Caution Cautions users about isolating power from the HP POD 40c
NA
4 Arc flash warning Provides a reminder to users of the danger of arc flash and
required PPE
Internal panel labels
Front view shown
Item Electrical safety label Description
1 Input power Lists the input power information

Illustrated parts catalog 11
Item Electrical safety label Description
2 Panel schedule/circuit breaker
table
Lists the layout and designation for all circuit breakers on the
panel
3 Fuse type table Lists all fuse type and sizes
4 Wire color code 415Y/240V color codes
•
Purple/Brown—Phase A/L1
•
Purple/Orange—Phase B/L2
•
Purple/Yellow—Phase 3/L3
•
Purple/White—Neutral
•
Green and yellow—Equipment ground
Control cabinet component identification
Item Component Description
1 VESDA air sampling smoke
detection unit
An early warning laser scan smoke detection unit
2 VESDA power supply with
battery backup
Provides power to the VESDA and backup power to the VESDA
during a utility power loss
3 Fire alarm and suppression
release control panel
•
Controls all fire systems in the HP POD 40c NA, including the
smoke detection system, fire suppression system, and fire pulls.
•
Includes a battery backup system that provides backup power
to the fire system during a utility power loss
4 Customer connection box Controls information monitored by the HP POD 40c NA access
control components
5 ECS relays and ECS modules Relays for the ECS control, ECS communications, I/O connections,
and terminal block connections
6 EPO controller board and house
panel fuses
Connections for the EPO system and fuses for other house panel
components

Illustrated parts catalog 12
Item Component Description
7 Dual power supplies with
battery backup
Provides 24 V DC power to the PLC, LED lighting, and ECS systems
8 Batteries Provides 24 V DC power to the PLC and ECS system
9 Control transformers Provides to the power flow control valve
10 240/120 V transformer Provides house power to the convenience outlets
— PLC The computer that controls the ECS system (located on the inside
door of the control cabinet)
Cooling system component identification
The heat exchanger access hatches are located on top of the POD. The hatches are coated with a durable
finish to prevent corrosion.
Side view shown
Item Component Description
1 Heat exchangers Use facility chilled water to cool the air in the HP POD 40c NA
2 Heat exchanger fan
banks
Operate at variable speeds to maintain the preprogrammed differential
pressure setpoint and the hot aisle temperature setpoint
3 Chilled water supply Supplies facility chilled water to cool the HP POD 40c NA
4 Chilled water return Returns heated chilled water to the facility
HP POD 40c NA racks
The HP POD 40c NA contains a total of 20 IT racks.
CAUTION: If any racks contain empty RU space, use the HP POD 40c NA filler panels to
maintain the efficien
cy of the HP POD 40c NA thermal system. Filler panels are available from HP
in 10-pack quantities (part number AQ682A) and 100-pack quantities (part number AS993A).
For more information about racks and network cabling, see the HP Performance Optimized Datacenter
Networking Guide.

Illustrated parts catalog 13
Aisle clearances
Cold aisle clearance
The maximum protrusion of any installed IT component directly impacts the available cold aisle clearance for
removal and replacement of other IT components. Maximum component depth must follow the clear aisle
distance calculations. The following figure shows how to calculate this distance.
The maximum rack face-to-cold aisle wall distance is 39.5 inches. In the figure, Xrepresents any protrusion
into the cold aisle starting from the rack face of the installed IT component (for example, the bezel). Y
represents cold aisle clearance. The cold aisle clearance dictates the maximum depth (D) of any installed IT
component. To find the maximum cold aisle clearance, calculate 100.33 cm (39.5 in) - X = Y.
IMPORTANT: As the value for X increases, the value for Y decreases, which also decreases the
maximum depth allowed for an installed component.

Illustrated parts catalog 14
Hot aisle clearance
Hot aisle clearance is defined as the distance from the rear of the rack to the hot aisle wall. The reference
distance of 2.54 cm (16 in) must be considered when selecting IT infrastructure that will populate into the hot
aisle.
Replaceable components
Each HP POD 40c NA is unique and the specific replaceable components vary for each POD. For specific
replaceable component information, see the Operations and Maintenance Manual for the HP Performance
Optimized Datacenter 40c North America.

Removal and replacement procedures 15
Removal and replacement procedures
Safety considerations
The HP POD 40c NA is listed to the UL 69050 standard as an Information Technology Product and Classified
according to the NEC, NFPA-70, 2008.
The HP POD 40c NA is not suitable for long term personnel occupancy.
The safety information is specific to the people operating and maintaining the components of the HP POD
40c NA.
IMPORTANT: All plumbing to and from the HP POD 40c NA must be completed by a licensed
plumber.
IMPORTANT: All wiring in and around the HP POD 40c NA must be completed by a licensed
electrician.
Operator safety
The HP POD 40c NA is not habitable or suitable for human occupancy. The HP POD 40c NA is Listed as a
Product that provides service access areas for periodic maintenance and service. These areas must be
controlled and available for use only by owner-authorized personnel and qualified personnel who are
trained in the maintenance and service of the HP POD 40c NA components.
WARNING: To avoid the risk of personal injury or loss of life, all personnel must comply with PPE
requirements when opening or working inside areas of the HP POD 40c NA that are marked as
hazardous voltage, per NFPA 70E in accordance with NEC (NA) and IEC (EMEA and APJ).
WARNING: To avoid the risk of personal injury, hearing protection must be worn at all times
when working inside the HP POD 40c NA.
WARNING: To avoid the risk of personal injury or damage to the equipment, do not insert
anything inside the electrical busways, except for the approved HP busway drop boxes.
Before completing the installation of the HP POD 40c NA, the customer, or a designated agent, is
responsible for completing any Environmental Health and Safety evaluation of the HP POD 40c NA or any
attached structural component purchased through HP. The customer, or their designated agent, must also
complete an arc flash assessment and breaker coordination study of the HP POD 40c NA and the associated
electrical supply system for operation and maintenance. The individual or organization that completes the
arc flash assessment must also create and provide all required labeling for all electrical panels on the HP
POD 40c NA.

Removal and replacement procedures 16
Fire detection and suppression
The fire detection and suppression system is a "Manufacturer Designed" system specifically for this HP
product, in compliance with national standards.
The HP standard suppression system, supplied as an optional component for the HP POD 40c NA, includes
a Novec 1230 clean agent system. However, if the customer or local AHJ requires specific modifications or
a replacement, HP can assist in these actions at the expense of the customer.
HP does not certify that the fire detection and suppression system that is installed in the HP POD 40c NA
meets all local and jurisdictional requirements. The customer is responsible for the following actions as
related to the fire suppression system:
•Verifying that the POD detection and suppression system meets local codes, including specific local
requirements for initial and periodic inspections
•Arranging for and receiving all required local permits, including initial commissioning as well as
standard and repair maintenance
•Arranging for the connection of the agent tanks, refilling of tanks, and all system testing, including
pressure tests
All general maintenance of the suppression system must be completed by an authorized technician.
•General maintenance of the fire detection and suppression system must be completed by an authorized
technician
For more information, see the HP Performance Optimized Datacenter 40c NA Maintenance and
Service guide.
Additional local requirements are not covered as part of the option price or basic installation and
deployment services, unless specifically included in an executed Statement of Work.
Air filter
There are 2 air filters per cooling zone, for a total of 12 filters.
Tools are not required for installation.
Removing the air filter
1. Pull the locking tabs away from the air filter to release the filter.

Removal and replacement procedures 17
2. Pull the filter down through the frame channels to remove the filter.
Replacing the air filter
1. Angle the filter to position the top corners in the frame channels, and then push the filter up to the top of
the frame.
2. Press in the bottom corners of the filter until the locking tabs engage and the filter clicks into place.

Removal and replacement procedures 18
Busway drop box
The internal electrical busways provide a location to connect each of the drop boxes, which then power the
PDUs. Stagger the drop boxes on the electrical busways by connecting one drop box to busway #1 and
connecting the next drop box to busway #2. A staggered configuration enables load balancing with the rack
equipment and is necessary to ensure redundancy.
You need a socket wrench for installation.
IMPORTANT: HP recommends that you shut down the associated IT equipment and de-energize
the appropriate section of the power busway before attempting to remove or replace a busway
drop box. The corresponding branch circuit breaker is labeled on the busway.
Removing the busway drop box
1. Turn the power off by opening both breakers on the busway drop box (1).
2. Disconnect the PDUs that are connected to the busway drop box (2).
3. Use a socket wrench to loosen and remove the bolt securing the busway drop box to the retaining
hardware bracket (1).

Removal and replacement procedures 19
4. Slide the hardware bracket to the right along the busway, completely disconnecting it from the busway
drop box (2).
WARNING: Use caution when removing and replacing the busway drop box. The drop box
weighs approximately 9 kg (20 lb).
5. Rotate the busway drop box 90° so that it is perpendicular to the electrical busway, and then remove
the drop box from the electrical busway (3).
Replacing the busway drop box
WARNING: Use caution when removing and replacing the busway drop box. The drop box
weighs approximately 9 kg (20 lb).
1. Place the silver drop box bracket on the electrical busway where you want to replace the busway drop
box (1).
2. Note the required rotation indicated on the drop box, insert the drop box into the drop box bracket on
the electrical busway, and then rotate the drop box 90° until it locks into place (2).
CAUTION: To prevent damage to the drop box and make sure that the drop box engages
properly, be sure that the drop box is completely flush to the busway. If a drop box is damaged
during installation, do not attempt to re-engage or repair the drop box.
3. Slide the hardware bracket to the left along the busway until it connects to the drop box (3).

Removal and replacement procedures 20
4. Secure the busway drop box to the retaining hardware bracket by using a socket wrench to insert and
tighten a bolt (4).
5. Connect the PDUs to the busway drop box (1).
6. Turn the power on by closing both breakers on the busway drop box (2).
Differential pressure sensor
The differential pressure sensors are located in the cold aisle.
You need a screwdriver for installation.
