The HP ProLiant DL380p Gen8 sets the next generation standards of 2U 2-socket rack servers for the industry. With enhanced
configuration flexibility, unmatched performance, and leading energy efficient design the DL380p Gen8 offers the perfect solution for
the dynamic compute requirements of today's demanding datacenters.
Front View: Rear View:
1. Quick removal access panel 1. PCIe 3.0 Slots 1, 2, 3-PCIe 2.0 top to bottom
2. Second Intel Processor 2. PCIe 3.0 Slots 4-6 top to bottom
3. First Intel Processor 3. Power supply 1
4. 24 DIMM slots: DDR3 Registered (RDIMM), Load Reduced
(LRDIMM), or Unbuffered (UDIMM) memory
4. Power supply 1 Power LED
5. Air Baffle 5. Power supply 1 Power connection (with Intelligent PDU
communication)
6. Hot-plug fans, full N+1 redundancy 6. Power supply 2 Power connection (with Intelligent PDU
communication)
7. Health LED 7. Power supply 2 Power LED
8. Power On /Standby button and system power LED button 8. Power supply 2
9. USB connector 9. Unit ID LED/Button
10. Unit ID LED 10. USB connectors (4)
11. Systems Insight Display 11. Video connector
12. Asset Tag 12. iLO connector
13. USB connector 13. Serial connector
14. Drive Bays 14. FlexibleLOM ports (Shown: 4 ports 1Gb each /Optional: 2
ports 10Gb each)
15. Optional Slim Optical Bay (SATA DVD-RW /ROM Optical Drive)
16. Video connector
What's New
E5-2690, E5-2680, and E5-2667 processors now available on the DL380p Gen8 25 SFF Configure-to-order Server
QuickSpecs
HP ProLiant DL380p Generation8 (Gen8)
Overview
DA - 14212 North America — Version 38 — July 22, 2013 Page 1

NOTE: For the Standard Features shipped in the "Factory Integrated Models", please see the "Configuration Information - Factory
Integrated Models" section.
Processor
One of the following
depending on Model
Entry Processors
NOTE: All support up to 1066MHz memory speeds.
Intel® Xeon® E5-2609 (2.4GHz/4-core/10MB/6.4GT-s QPI/80W)
Intel® Xeon® E5-2603 (1.8GHz/4-core/10MB/6.4GT-s QPI/80W)
Base Processors
NOTE: All support up to1333MHz DDR3 memory speeds.
Intel® Xeon® E5-2640 (2.5GHz/6-core/15MB/7.2GT-s QPI/95W, DDR3-1333, HT, Turbo2- 3/3/4/4/5/5)
Intel® Xeon® E5-2630 (2.3GHz/6-core/15MB/7.2GT-s QPI/95W, DDR3-1333, HT, Turbo2- 3/3/4/4/5/5)
Intel® Xeon® E5-2620 (2.0GHz/6-core/15MB/7.2GT-s QPI/95W, DDR3-1333, HT, Turbo2- 3/3/4/4/5/5)
Intel® Xeon® E5-2630L (2.0GHz/6-core/15MB/8.0GT-s QPI/60W, DDR3-1333, HT, Turbo2- 3/3/4/4/5/5)
Performance Processors
NOTE: All support up to 1600MHz DDR3 memory speeds.
Intel® Xeon® E5-2690 (2.9GHz/8-core/20MB/8GT-s QPI/135W, DDR3-1600, HT, Turbo2- 4/4/4/5/5/7/7/9)
Intel® Xeon® E5-2680 (2.7GHz/8-core/20MB/8GT-s QPI/130W, DDR3-1600, HT, Turbo2- 4/4/5/5/5/7/8/8)
Intel® Xeon® E5-2670 (2.6GHz/8-core/20MB/8GT-s QPI/115W, DDR3-1600, HT, Turbo2- 4/4/5/5/6/6/7/7)
Intel® Xeon® E5-2667 (2.9GHz/6-core/15MB/8GT-s QPI/130W, DDR3-1600, HT, Turbo2- 3/3/3/4/5/6)
Intel® Xeon® E5-2665 (2.4GHz/8-core/20MB/8GT-s QPI/115W, DDR3-1600, HT, Turbo2- 4/4/5/5/6/6/7/7)
Intel® Xeon® E5-2660 (2.2GHz/8-core/20MB/8GT-s QPI/95W, DDR3-1600, HT, Turbo2- 5/5/6/6/7/7/8/8)
Intel® Xeon® E5-2650 (2.0GHz/8-core/20MB/8GT-s QPI/95W, DDR3-1600, HT, Turbo2- 4/4/5/5/5/7/8/8)
Intel® Xeon® E5-2650L (1.8GHz/8-core/20MB/8.0 GT-s QPI/70W, DDR3-1600, HT, Turbo2-
2/2/3/3/4/4/5/5)
Intel® Xeon® E5-2643 (3.3GHz/4-core/10MB/8GT-s QPI/130W, DDR3-1600, HT, Turbo2- 1/1/2/2)
Intel® Xeon® E5-2637 (3.0GHz/2-core/5MB/8.0GT-s QPI/80W, DDR3-1600, HT, Turbo2- 5/5)
NOTE: HT indicates that the processor model supports Intel® Hyper-Threading Technology.
NOTE: Turbo indicates the maximum potential frequency increment when using Intel® Turbo Boost
Technology, with 8, 7, 6, 5, 4, 3, 2 and 1 cores active.
NOTE: DDR3 speed is the maximum memory speed of the processor. Actual memory speed may depend on
the quantity and type of DIMMs installed.
NOTE: Up to 2 processors supported. Mixing different processor models is not supported.
NOTE: For the Intel® C600 Chipset E5-2600 Series, the letter preceding the model number indicates the
Product Line (E3, E5, E7); 2600x v#, 2 = number of CPUs in a Node, 6 is socket/segment designation, 00 =
Processor SKU, x = L for low power SKUs and v# (not yet designated) = version number.
QuickSpecs
HP ProLiant DL380p Generation8 (Gen8)
Standard Features
DA - 14212 North America — Version 38 — July 22, 2013 Page 2

Cache Memory
One of the following
depending on Model
20MB (1x20MB) Level 3
NOTE: For Eight-core processors.
15MB (1x15MB) Level 3
NOTE: For Six-core processors.
10MB (1x10MB) Level 3
NOTE: For Quad-core processors.
5MB (1x5MB) Level 3
NOTE: For Dual-core processors.
NOTE: All processor models above list the L3 Cache associated with that particular processor.
Chipset Intel® C600 Series Chipset
Intel® E5-2600 Processor Family
NOTE: For more information regarding Intel chipsets, please see the following URL:
http://www.intel.com/products/server/chipsets/ .
Upgradeability Upgradeable to 2 processors (16 Cores)
Up to 24 DIMM slots available for higher Memory capacity
FlexibleLOM connector for 1 Gigabit or 10 Gigabit networking options
8SFF Hard drive bays (total of 16 with optional upgrade)
Optional 3 slot riser (x16, x8, x8), or 2 slot (x16, x16)
NOTE: To take advantage of the additional 3 PCI slot upgrade, the second processor must be installed.
Redundant Power Supply
Optical Drive (8SFF/8LFF only)
On System Management
Chipset
HP iLO (Firmware: HP iLO 4)
NOTE: For more information, visit: http://www.hp.com/go/ilo
Memory Protection Advanced ECC
NOTE: Advanced ECC uses single device data correction (SDDC) to detect and correct single and all multi-
bit error that occurs within a single DRAM chip. Both x4 and x8 SDDC are supported (x8 requires lockstep
mode).
Online Spare
NOTE: Memory online spare mode (also known as rank spare mode) detects a rank that is degrading and
switches operation to the spare rank.
Lock-step mode
NOTE: Memory Lockstep mode is used to correct a single x8 DRAM device failure on a DIMM. The DIMMs in
each paired memory channel must have identical HP part numbers.
QuickSpecs
HP ProLiant DL380p Generation8 (Gen8)
Standard Features
DA - 14212 North America — Version 38 — July 22, 2013 Page 3

Memory
One of the following
depending on Model
Type HP SmartMemory
DDR3 Load Reduced (LRDIMM), Registered (RDIMM) or Unbuffered (UDIMM)
DIMM Slots Available 24 (12 DIMM slots per processor /4 channels per processor/3 DIMMs per
channel)
Standard (Entry Model) 4GB (1x4GB) PC3L-10600R (DDR3-1333) Registered DIMMS
Standard (Base Models) 16GB (4x4GB) PC3L-10600R (DDR3-1333) Registered DIMMS
Standard (High
Performance Models)
32GB (4x8GB) PC3-12800R (DDR3-1600) Registered DIMMS
Maximum Capacity
(LRDIMM)
768GB (24 x 32GB LRDIMM @1066MHz)
Maximum Capacity
(RDIMM)
384GB (24x 16GB RDIMM @1333MHz)
Maximum Capacity
(UDIMM)
128GB (16 x 8GB UDIMM @1600MHz)
Maximum Capacity
(HDIMM)
384GB (24 x 16GB UDIMM @1333MHz)
NOTE: HP memory from previous generation servers are not qualified or warranted with this HP ProLiant
Server. HP SmartMemory is required to realize the memory performance improvements and enhanced
functionality listed in this document for Gen8. For additional information, please see the HP SmartMemory
QuickSpecs at: http://h18000.www1.hp.com/products/quickspecs/14225_na/14225_na.html
NOTE: LRDIMM, RDIMM and UDIMMs are all distinct memory technologies and cannot be mixed within a
server. The majority of ProLiant Gen8 servers support RDIMM, UDIMM and LRDIMM.
NOTE: If only one processor is installed, only half the DIMM slots are available
NOTE: UDIMM max DIMM population is 16
NOTE: Depending on the memory configuration and processor model, the memory speed may run at
1600MHz, 1333MHz, or 1066MHz. Please see Memory Population Table or the Online Memory
Configuration Tool at: www.hp.com/go/ddr3memory-configurator .
Network Controller
One of the following
depending on Model
HP ProLiant Gen8 servers offer a new networking technology - Flexible Network Technology. The HP
ProLiant DL380p Gen8 server offers the customer the choice of 1 Gigabit and/or 10 Gigabit networking
solutions. For additional details see the Networking Section of this document.
Entry Models HP Ethernet 1Gb 4-port 331FLR Adapter
Base Models HP Ethernet 1Gb 4-port 331FLR Adapter
High Performance Models HP Ethernet 10Gb 2-port 530FLR-SFP+ Adapter
HP Ethernet 1Gb 4-port 331FLR Adapter
Energy Star - Base Models HP Ethernet 1Gb 4-port 331FLR Adapter
QuickSpecs
HP ProLiant DL380p Generation8 (Gen8)
Standard Features
DA - 14212 North America — Version 38 — July 22, 2013 Page 4

Expansion Slots
Primary Riser
(Standard)
Expansion
Slots #
Technology Bus
Width **
Connector
Width
Bus Number * Form Factor Notes
1 PCIe 3.0 X16 X16 7 Full Length,
Full Height
Slot
Proc 1
2 PCIe 3.0 X8 X8 10 Half Length,
Full Height
Slot
Proc 1
3 PCIe 2.0 X4 X8 13 Half Length,
Full Height
Slot
Chipset
* Default bus assignment (in decimal). Inserting cards with PCI bridges may alter the actual bus assignment
number
** Indicates the number of physical electrical lanes running to the connector.
NOTE: When populating the second optional riser slot, the second processor must be installed.
NOTE: All slots support up to 150w PCIe cards, but an additional Power Cord Option is required (PN
669777-B21). See Option Section below for offering.
PCIe Riser
(Optional 3-slot)
Expansion
Slots #
Technology Bus
Width **
Connector
Width
Bus Number * Form Factor Notes
4 PCIe 3.0 X16 X16 16 Full length,
full height slot
Proc 2
5 PCIe 3.0 X8 X8 20 Half length,
full height slot
Proc 2
6 PCIe 3.0 X8 X8 23 Half length,
full height slot
Proc 2
* Default bus assignment (in decimal). Inserting cards with PCI bridges may alter the actual bus assignment
number
** Indicates the number of physical electrical lanes running to the connector.
NOTE: When populating the second optional riser slot, the second processor must be installed.
NOTE: All slots support up to 150w PCIe cards, but an additional Power Cord Option is required (669777-
B21). See Option Section below for offering
PCIe Riser
(Optional 2-slot)
Expansion
Slots #
Technology Bus
Width **
Connector
Width
Bus Number * Form Factor Notes
4 PCIe 3.0 X16 X16 16 Full length,
Full height
slot
Proc 2
5 PCIe 3.0 X16 X16 16 Half Length,
Full Height
Proc 2
* Default bus assignment (in decimal). Inserting cards with PCI bridges may alter the actual bus assignment
number
** Indicates the number of physical electrical lanes running to the connector.
QuickSpecs
HP ProLiant DL380p Generation8 (Gen8)
Standard Features
DA - 14212 North America — Version 38 — July 22, 2013 Page 5

HP Server ROM HP ROM (Read Only Memory) is now digitally signed using HP's Corporate Signing Service. This signature is
verified before the flash process starts, reducing accidental programming and preventing malicious
efforts to corrupt system ROM.
HP ROM provides for essential initialization and validation of hardware components before control is
passed to the customer-installed operating system. The ROM also provides the capability of booting from
various fixed media (HDD, CD-ROM) and removable media (USB), to continue operation to the operating
system.
HP ROM performs very early configuration of the video controller, to allow monitoring of initialization
progress via an attached monitor. If configuration or hardware errors are discovered during this early
phase of hardware initialization, suitable messages are now displayed on the connected monitor.
Additionally, these configuration or hardware errors are logged to the Integrated Management Log (IML)
to assist in diagnosis.
HP's ProLiant ROM is used to configure the following:
Processor and chipset status registers
System memory, memory map, and memory initialization
System hardware configuration (Integrated PCI devices and optional PCIe cards).
Customer-specific BIOS configuration (using the HP ROM-Based Setup Utility (RBSU).
NOTE: For further information, please refer to HP's RBSU (ROM based setup utility) user guide:
www.hp.com/support/rbsu .
Storage Controller
One of the following
depending on Model
Entry Models HP Smart Array P420i/ZM (RAID 0/1/1+0)
Base Models HP Smart Array P420i/1GB with FBWC (RAID 0/1/1+0/5/5+0)
High Performance Models HP Smart Array P420i/2GB with FBWC (RAID 0/1/1+0/5/5+0)
Energy Star - Base Models HP Smart Array P420i/1GB with FBWC (RAID 0/1/1+0/5/5+0)
Internal Storage Devices Diskette Drive None
Optical Drive Ships standard in Performance Models
* Optional: DVD-ROM, DVD-RW
Hard Drives None ship standard
Drive Bays Standard: 8SFF drive bays total with Optical Bay or 8 LFF drive bays total with
Optical Bay
Optional: +8SFF drive bay (total of 16SFF drive bays)
NOTE: HP ProLiant DL380p series servers offer both LFF and SFF versions. The
Optical Drive bay is not available with the optional +8SFF drive bay upgrade.
NOTE: The Optical drive bay is not available with the +8SFF drive bay optional
upgrade nor 12LFF and 25SFF server models
NOTE: The 8LFF, 12LFF, and 25SFF drive cage versions are not field
upgradeable options from the 8SFF model.
NOTE: The optional +8SFF drive bay requires an additional internal storage
controller be selected. HP recommends the HP Smart Array P420/1GB FBWC
6Gb 2-ports Int SAS Controller (P/N 631670-B21).
NOTE: All Pre-configured Models come populated with some hard drive blanks
QuickSpecs
HP ProLiant DL380p Generation8 (Gen8)
Standard Features
DA - 14212 North America — Version 38 — July 22, 2013 Page 6

installed. Should the customer need additional hard drive blanks, they can
order more using either P/N 666987-B21: HP SFF Gen8 Hard Drive Blank Kit or
P/N 666986-B21: HP LFF Gen8 Hard Drive Blank Kit. The part numbers for
single HDD blanks below are also provided should the customer require
replacement HDD blanks for their server.
Maximum Internal
Storage
Hot Plug SFF SAS 30.0TB 25 x 1.2TB (with optional SFF drive cage)
Hot Plug SFF SATA 25.0TB 25 x 1TB (with optional SFF drive cage)
Hot Plug LFF SAS 36.0TB 12 x 3TB (with optional LFF drive cage)
Hot Plug LFF SATA 48.0TB 12 x 4TB (with optional LFF drive cage)
Hot Plug SFF SAS SSD 20.0TB 25 x 800GB (with optional SFF drive cage)
Hot Plug LFF SATA SSD 4.8TB 12 x 400GB (with optional LFF drive cage)
Interfaces Serial 1
Video 2 (1 front, 1 back) not active simultaneously
FlexibleLOM Network Ports Some models come standard with 4 x 1GB ports while others come with 2 x
10GB ports (See HP Networking section below for more details and options).
HP iLO Remote
Management Network Port
1 Gb Dedicated
SD slot 1 Internal Secure
NOTE: The SD slot is not a hot-pluggable device. Customers should not
attempt to plug an SD card into the SD slot while the server is powered.
USB 2.0 Ports Up to 7 total: up to 2 front, 4 back, 1 internal
Industry Standard
Compliance
ACPI 2.0b Compliant
PCIe 3.0 Compliant
PXE Support
WOL Support
Microsoft® Logo certifications
USB 2.0 Compliant
Server Power Cords All Pre-configured servers ship with a high voltage server-to-PDU power cord.
NOTE: HP ProLiant DL servers no longer ship standard with a 12-foot NEMA 5-15P to C13 power cord that
connects to 110V US wall outlets in a home or office. ProLiant DL servers are primarily connected to power
distribution units (PDUs) in data center racks and now ship standard with a PDU 6-foot C-14 to C13 power
cord (A0K02A). If a user wishes to power a ProLiant DL server using a 110V receptacle (NEMA-15), the 6-
foot NEMA 5-15 to C13 power cord must be ordered separately (AF556A). See Power Cords section for
Power Cord options.
QuickSpecs
HP ProLiant DL380p Generation8 (Gen8)
Standard Features
DA - 14212 North America — Version 38 — July 22, 2013 Page 7

Power Specifications To review typical system power ratings use the HP Power Advisor which is available via the online tool
located at URL: www.hp.com/go/proliant-energy-efficient or www.hp.com/go/hppoweradvisor .
NOTE: Power Specification and Technical Content for supported power supplies can be found at:
http://h18000.www1.hp.com/products/quickspecs/14209_div/14209_div.html
Common Slot Power
Supply
NOTE: Mixing of power supplies in the same server is not supported. All power supplies inside a server
must be exactly the same model. Mixing Gold, Platinum, and Platinum Plus certified power supplies is not
supported.
HP's Common Slot (CS) power supplies allow for commonality of power supplies across a wide range of
ProLiant and Integrity servers, as well as HP Storage solutions, and are designed to provide the highest
power supply efficiency without degrading system performance. HP CS power supplies are tested by the
Electric Power Research Institute (EPRI) and certified through the ECOS 80 Plus power supply program. HP
CS power supply options provide efficiency ratings of up to 94% (80 Plus Platinum) and are available in
three power output options - 460W, 750W, and 1200W - allowing the customer to "right-size" a power
supply for their specific server configuration. All HP Common Slot power sources are UL, CE Mark
Compliant, hot-plug and support redundant configurations.
NOTE: Mixing of power supplies in the same server is not supported. All power supplies must be of the
same output and efficiency rating. If non-matched power supplies are inserted you will get errors and
operation will fail.
HP CS Platinum Plus power supplies are required when enabling HP's Intelligent Power Discovery (IPD)
solution. IPD is the first technology to create an automated, energy-aware network between IT systems
and facilities. This allows your company to reclaim millions of dollars in wasted power capacity and
downtime costs across data centers. For more information on HP's IPD solution, go to
www.hp.com/go/ipd .
It is highly recommended that you use the HP Power Advisor in defining the "Right-Size" power supply for
your needs. HP Power Advisor can be accessed at: www.hp.com/go/hppoweradvisor .
NOTE: The 80 PLUS program is a unique forum that unites electric utilities, the computer industry, and
consumers in an effort to bring energy efficient technology solutions to the marketplace. 80 Plus
independently tests power supply efficiency and publicly posts the results on 80Plus.org.
Redundant Power: Optional (1+ 1 or n+n redundant) power supplies can be purchased through power
supply option kits (see Power Supplies for part numbers).
NOTE: Power Specification and Technical Content for supported power supplies can be found at:
http://h18000.www1.hp.com/products/quickspecs/14209_na/14209_na.html
System Fans
One of the following
depending on Model
2P Models have (6) (N+1 redundancy standard)
1P Models have (4) (N+1 redundancy standard)
Required Cabling For required cabling information, refer to the HP Web site at: www.hp.com/servers/dl380p-gen8 .
QuickSpecs
HP ProLiant DL380p Generation8 (Gen8)
Standard Features
DA - 14212 North America — Version 38 — July 22, 2013 Page 8

Operating Systems and
Virtualization Software
Support for ProLiant
Servers
Microsoft Windows Server
Red Hat Enterprise Linux (RHEL)
SUSE Linux Enterprise Server (SLES)
Oracle Solaris
VMware
Citrix XenServer
NOTE: For more information on HP's Certified and Supported ProLiant Servers for OS and Virtualization
Software and latest listing of software drivers available for your server, please visit our Support Matrix at:
http://www.hp.com/go/ossupport and our driver download page:
http://www.hp.com/support/DL380pGen8
Graphics Integrated Matrox G200 video standard
1280 x 1024 (32 bpp)
1920 x 1200 (16 bpp)
HP iLO 4 On System Management Memory
16 MB Flash
256 MB DDR 3 with ECC (112 MB after ECC and video)
Form Factor
One of the following
depending on Model
2U Rack form factor, ships with ball bearing rails and cable management system
8 SFF Drive Bay Version:
3.44 (8.74 cm) Height x 17.54" (44.55 cm) Width x 27.5" (69.85 cm) Length
8 LFF Drive Bay Version:
3.44 (8.74 cm) Height x 17.54" (44.55 cm) Width x 29.5" (74.94cm) Length
On System Management HP iLO Management
Engine
HP iLO Management Engine is a comprehensive set of embedded
management features supporting the complete lifecycle of the server,
from initial deployment, through ongoing management, to service
alerting and remote support. HP iLO Management Engine comes
standard on all HP ProLiant Gen8 servers. The HP iLO Management
Engine portfolio includes:
HP iLO: The HP iLO (Integrated Lights-Out) management
processor is the core foundation for the HP iLO Management
Engine
HP Agentless Management: Provides built in server health
monitoring and alerting capability without OS agents, that starts
working the moment a power cord and an Ethernet cable are
connected.
HP Active Health System: Always on, continuous monitoring for
increased stability and shorter downtimes; 100% configuration
history; Health and service alerts and easy export and upload to
Service and Support.
HP Intelligent Provisioning: Lets customers provision and
QuickSpecs
HP ProLiant DL380p Generation8 (Gen8)
Standard Features
DA - 14212 North America — Version 38 — July 22, 2013 Page 9

configure a single server without any separate media. No more
SmartStart CDs or Smart Update Firmware DVD are needed.
To start Intelligent Provisioning:
Press the F10 key during the ProLiant Gen8 server
boot process (also known as power on self test or
POST).
Please go to the Intelligent Provisioning website at
www.hp.com/go/intelligentprovisioning for
additional information and to view usage videos.
Use the Service Pack for ProLiant (SPP) at
www.hp.com/go/spp to get firmware and software
updates.
HP iLO Mobile App: Enables the ability to access, deploy, and
manage your server anytime from anywhere from select
smartphones and mobile devices. For additional information
please visit: www.hp.com/go/ilo/mobileapp
NOTE: For more information, visit: http://www.hp.com/go/ilo or HP iLO
Management Engine technologies whitepaper
HP Insight management HP Service Pack for
ProLiant (SPP)
HP Service Pack for ProLiant (SPP) and HP Smart Update Manager (HP SUM)
version 5 provide a new, comprehensive approach to firmware and system
software maintenance. Together they provide better operating stability and
ensure maximum uptime. The SPP will be updated at a predictable cadence,
typically coinciding with new HP server hardware launches. By enabling all
firmware to be updated online and integrating firmware and system software
updates in one operation HP SUM and the SPP offer faster updates of
individual servers and dramatically faster updates of entire BladeSystem
enclosures. Further improving system uptime and stability is the fact that HP
provides 12 months of support on each Service Pack for ProLiant.
The user experience around HP SUM and the SPP has been improved in several
ways, starting with the web download. A single web page provides access to a
single download containing both the latest version of HP SUM version 5 and
the latest SPP. Optional smaller subsets with only specific types of servers or
specific operating systems are offered to save on download time. The HP SUM
application has been re-written to provide a more straightforward, intuitive
user interface that guides the user through the steps of discovery, analyses
and update, providing comprehensive information on available updates,
criticality and interdependencies. This information is also available in reports.
By providing the option of multiple local or shared repositories which can be
easily updated from hp.com, HP SUM provides the tools to optimize stability
and consistency throughout the company. While HP SUM and the SPP will
recommend the combinations of firmware and system software that HP has
found to be the best practice, the application gives customers the flexibility to
set their own specific baseline.
The Service Pack for ProLiant has been rigorously tested with specific
attention for interaction between firmware, drivers and agents both within the
server as well as in interaction with the BladeSystem enclosure components
QuickSpecs
HP ProLiant DL380p Generation8 (Gen8)
Standard Features
DA - 14212 North America — Version 38 — July 22, 2013 Page 10

(Onboard Administrator and Virtual Connect). This testing ensures the highest
quality as well as providing the input for HP SUM to deploy updates taking into
account all interdepencies, when determining the correct updates and order of
update deployment.
NOTE: The Service Pack for ProLiant (which includes HP SUM 5) can be
downloaded from www.hp.com/go/spp/download . More information can be
found: www.hp.com/go/spp and http://www.hp.com/go/hpsum
Security Power-on password
Serial interface control
Administrator's password
Warranty This product is covered by a global limited warranty and supported by HP Services and a worldwide
network of HP Authorized Channel Partners resellers. Hardware diagnostic support and repair is available
for three years from date of purchase. Support for software and initial setup is available for 90 days from
date of purchase. Enhancements to warranty services are available through HP Care Pack services or
customized service agreements. Hard drives have either a one year or three year warranty; refer to the
specific hard drive QuickSpecs for details.
NOTE: Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support with next business day
response. Warranty repairs may be accomplished through the use of Customer Self Repair (CSR) parts.
These parts fall into two categories: 1) Mandatory CSR parts are designed for easy replacement. A travel
and labor charge will result when customers decline to replace a Mandatory CSR part; 2) Optional CSR
parts are also designed for easy replacement but may involve added complexity. Customers may choose
to have HP replace Optional CSR parts at no charge. Additional information regarding worldwide limited
warranty and technical support is available at:
http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html
QuickSpecs
HP ProLiant DL380p Generation8 (Gen8)
Standard Features
DA - 14212 North America — Version 38 — July 22, 2013 Page 11

HP Insight management HP Insight Control HP Insight Control, a product option, delivers essential infrastructure
management that can help save time and money by making it easy to deploy,
migrate, monitor, remote control, and optimize your IT infrastructure through
a single, simple management console. HP Insight Control also supports
Location and Power Discovery Services to automate many configuration, asset
tracking, and power management tasks to speed implementation and prevent
downtime. For more information, see http://www.hp.com/go/insightcontrol .
HP Insight Control includes one year of 24 x 7 HP Software Technical Support
and Update Service ensuring rapid access to HP support staff and proactive
delivery of software updates. For more information about this service, see:
http://www.hp.com/services/insight .
HP iLO Advanced HP Integrated Lights-Out Advanced License a product option, providing smart
remote server management without compromise. iLO Advanced unlocks the
full set of remote administration functionality for all HP ProLiant servers by
activating the full Virtual Keyboard Video and Mouse remote console, multi-
user collaboration, console record and replay, GUI-based and scripted virtual
media and virtual folders, and enhanced security and power management
functionality. For more information, see: http://www.hp.com/go/iloadvance
HP Matrix Operating
Environment
The HP Matrix Operating Environment (Matrix OE) for ProLiant and Integrity
servers is an integrated command center that helps you instantly adjust to
dynamic business demands. This advanced infrastructure management
software lets you reduce the cost of common data center tasks by up to 40
percent while keeping pace with your changing business.
The HP Matrix OE includes the automated provisioning, optimization, and
recovery management capabilities for HP CloudSystem Matrix, the ideal
platform for private cloud and Infrastructure as a Service (IaaS).
NOTE: For more information, visit: http://www.hp.com/go/matrixoe
High Performance
Clusters
HP Cluster Platforms HP Cluster Platforms are specifically engineered, factory-integrated large-
scale ProLiant clusters optimized for High Performance Computing, with a
choice of servers, networks and software. Operating system options include
specially priced offerings for Red Hat Enterprise Linux and SUSE Linux
Enterprise Server, as well as Microsoft Windows HPC Server. A Cluster
Platform Configurator simplifies ordering. http://www.hp.com/go/clusters
HP HPC Interconnects High Performance Computing (HPC) interconnect technologies are available
for this server as part of the HP Cluster Platform portfolio. These high-speed
InfiniBand and Gigabit interconnects are fully supported by HP when
integrated within an HP cluster. Flexible, validated solutions can be defined
with the help of configuration tools.
http://www.hp.com/techservers/clusters/ucp/index.html
QuickSpecs
HP ProLiant DL380p Generation8 (Gen8)
Optional Features
DA - 14212 North America — Version 38 — July 22, 2013 Page 12

HP Insight Cluster
Management Utility
HP Insight Cluster Management Utility (CMU) is an HP-licensed and HP-
supported suite of tools that are used for lifecycle management of hyperscale
clusters of Linux ProLiant systems. CMU includes software for the centralized
provisioning, management and monitoring of nodes. CMU makes the
administration of clusters user friendly, efficient, and effective.
http://www.hp.com/go/cmu
HP HPC Linux Value Pack HP HPC Linux Value Pack (Value Pack) is an HP-licensed and HP-supported
option to HP Insight CMU, for the development and deployment of
applications on HPC Cluster Platforms. Value Pack includes the Platform LSF
workload scheduler and Platform Application Center, as well as the HP-MPI
parallelization library. HP HPC Linux Value Pack
Storage Software Whether you need to solve a specific data protection, archiving, or storage command and control
challenge, or deliver on strategic consolidation, compliance, or continuity initiatives, look no further than
HP storage software. Our storage software helps you reduce costs, simplify storage infrastructure,
protect vital assets and respond faster to business opportunities.
Storage software that gets the job done:
Data Protection and Recovery Software
Whether you're a large enterprise or a smaller business, HP data protection and recovery software
will cost-effectively protect you against disaster and ensure business continuity.
Data Archive and Migration Software
HP's storage software enables you to comply with data retention and retrieval requirements,
improve application performance, and reduce costs by efficiently migrating infrequently accessed
or less valuable data to lower cost storage.
Storage Resource Management Software (SRM)
HP's storage resource management software reduces operational costs and provides the command
and control foundation you need to efficiently manage and visualize your physical and virtual
environments.
Data Replication Software
HP offers array-based and host-based replication software for use in disaster recovery, testing,
application development and reporting.
Storage Device Management Software
Maximize your investment in HP storage and networking with software that enables hardware-
specific configuration, performance tuning and connectivity management.
HP StoreVirtual VSA
With HP StoreVirtual VSA you can use the power of virtualization to turn a set of heterogeneous and
disconnected physical disk drives in your servers and storage devices into a single pool of logical
storage capacity.
NOTE: For more information available Storage Software including QuickSpecs, please see:
www.hp.com/go/storage/software
QuickSpecs
HP ProLiant DL380p Generation8 (Gen8)
Optional Features
DA - 14212 North America — Version 38 — July 22, 2013 Page 13

HP Insight Online HP Insight Online is a new addition to the HP Support Center for one stop, secure access to product and HP
support information personalized to your IT environment. Insight Online can automatically display devices
remotely monitored by HP Insight Remote Support. With Insight Online's easy navigation you can
efficiently track your IT support contracts and device status from anywhere and at anytime.
www.hp.com/go/insightonline
HP Proactive Insight
experience
Prevent problems with innovative, automated monitoring tools and proactive services. The HP Proactive
Insight experience consist of using Insight Online, Insight Remote Support, and Proactive Care Support
Service as one integrated solution. The Proactive Insight experience provides you with expert advice and
personalized, cloud-based automated IT support, helping to prevent unplanned down time and solve
problems quickly. For more information, visit: www.hp.com/go/proactiveinsightexperience
Factory Express Portfolio
for Servers and Storage
HP Factory Express offers configuration, customization, integration and deployment services for HP
servers and storage products. Customers can choose how their factory solutions are built, tested,
integrated, shipped and deployed.
Factory Express offers service packages for simple configuration, racking, installation, complex
configuration and design services as well as individual factory services, such as image loading, asset
tagging, and custom packaging. HP products supported through Factory Express include a wide array of
servers and storage: HP Integrity, HP ProLiant, HP ProLiant Server Blades, HP BladeSystem, HP 9000
servers as well as the MSAxxxx, EVA7xxx, EVA, XP, rackable tape libraries and configurable network
switches.
For more information on Factory Express services for your specific server model please contact your sales
representative or go to: http://www.hp.com/go/factory-express .
HP Simple Configurator SCE is a guided self service tool to help sales and non technical people provide customers with initial
configurations in 3 to 5 minutes. You may then send the configuration on for configuration help, or use in
your existing ordering processes. If you require "custom" rack configuration or configuration for products
not available in SCE, please contact HP's Customer Business Center or an Authorized Partner for
assistance. http://www.hp.com/products/configurator
QuickSpecs
HP ProLiant DL380p Generation8 (Gen8)
Optional Features
DA - 14212 North America — Version 38 — July 22, 2013 Page 14

Service and Support HP Technology Services for Industry Standard Servers and BladeSystem
Capitalizing on HP ProLiant server and HP BladeSystem capabilities requires a service partner who
understands your increasingly complex business technology environment. That's why it makes sense to
team up with the people who know HP infrastructure hardware and software best - the experienced
professionals at HP Services.
What HP ProLiant and BladeSystem Services can do for you
HP ProLiant and BladeSystem Services can help you design, deploy, test, integrate, support, and manage
IT and infrastructure solutions. This way, HP proposes services solutions that include more than just uplift
of base warranty. Foundation Care services deliver scalable support-packages for HP industry-standard
servers and software. You can choose the type and level of service that is most suitable for their business
needs. New to this portfolio is HP Collaborative Support. If you are running business critical environments,
HP offers Proactive Care or Critical Advantage. These services help deliver high levels of application
availability through proactive service management and advanced technical response
You can get the support you need by choosing from one of a number of service packaged solutions we
have designed to address wider set of customer support needs.
HP Technology Services meets business challenges with services offered in three support
recommendations - Optimized Care, Standard Care, and Basic Care - available for each product group.
Such support solutions enable customers to optimize technology operations, minimize risk and drive
better business outcomes with easy-to-buy, easy-to-use scalable support recommendations for servers,
storage, networking and software designed to meet your specific needs.
All three service recommendations include support services from the broader portfolio of Foundation Care
and Proactive Care services.
Optimized Care Optimized Care : Supports maintaining servers at optimum performance availability
HP ProLiant Server Hardware Installation
Provides for the basic hardware installation of HP branded servers, storage devices and networking
options to assist you in bringing your new hardware into operation in a timely and professional manner
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-9356EN.pdf
HP Installation and Startup for Insight Control Software / HP SIM
Provides for the deployment and basic configuration of HP Insight Control or HP SIM (Systems Insight
Manager) on HP ProLiant ML and DL series servers or HP BladeSystem servers
http://h20195.www2.hp.com/v2/GetPDF.aspx/4AA0-9972ENW.pdf
3-Year HP 24x7 4 hour Response, Proactive Care
Helps optimize your systems and delivers high levels of application availability through proactive service
management and advanced technical response. A skilled Technical Manager will own your call and end to
end until resolved, delivering a single point of contact for you. Helping you to resolve your hardware and
software issues and minimizing downtime in your business critical environment.
Additional Services: Factory Express, Education Services, Proactive Select - 30 Credit Package
QuickSpecs
HP ProLiant DL380p Generation8 (Gen8)
Service and Support
DA - 14212 North America — Version 38 — July 22, 2013 Page 15

Standard Care Standard Care : Service recommendation that maintains high level of server availability
HP ProLiant Server Hardware Installation
Provides for the basic hardware installation of HP branded servers, storage devices and networking
options to assist you in bringing your new hardware into operation in a timely and professional manner
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-9356EN.pdf
HP Installation and Startup for Insight Control Software / HP SIM
Provides for the deployment and basic configuration of HP Insight Control or HP SIM (Systems Insight
Manager) on HP ProLiant ML and DL series servers or HP BladeSystem servers
http://h20195.www2.hp.com/v2/GetPDF.aspx/4AA0-9972ENW.pdf
3-Year HP 24x7 4 hour Response, Collaborative Support
Provides problem resolution support across the stack of HW, firmware, and HP and 3rd party SW. In case
the issue is with 3rd party SW, HP does known issue resolution. If HP cannot solve the issue, it will contact
the third-party vendor and create a problem incident on your behalf.
http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA3-8232ENW.pdf
Additional Services: Software support service with 24X7 availability with a 2 hour response, Training
courses on Microsoft, Linux (Red Hat and SUSE), VMware, and HP Insight Software, 10 Proactive Select
Credit package, Factory Express
http://www8.hp.com/us/en/business-services/it-services.html?compURI=1078865
Basic Care Basic Care: delivers minimum recommended support service level
HP ProLiant Server Hardware Installation
Provides for the basic hardware installation of HP branded servers, storage devices and networking
options to assist you in bringing your new hardware into operation in a timely and professional manner
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-9356EN.pdf
3-Year HP 24x7 4 hour Response, Hardware Support Onsite Service
Provides you with rapid remote support and if required an HP authorized technical engineer will be on site
24X7 begin hardware maintenance service within 4 hours of the service request being logged
http://h20195.www2.hp.com/V2/GetPDF.aspx/5982-6547EEE.pdf
3-Year , HP 24x7 Software Support for Insight Control
Provides remote 3-year software support service that delivers comprehensive software services, including
access to HP technical resources and software updates
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-6645EEE.pdf
Additional Services: Factory Express, Education Services, Proactive Select - 10 Credits
Insight Remote Support Provides 24 X 7 remote monitoring, proactive notifications, and problem resolution. Learn more
http://www.hp.com/go/insightremotesupport
QuickSpecs
HP ProLiant DL380p Generation8 (Gen8)
Service and Support
DA - 14212 North America — Version 38 — July 22, 2013 Page 16

HP Support Center Personalized online support portal with access to information, tools and experts to support HP business
products. Submit support cases online, chat with HP experts, access support resources or collaborate with
peers. Learn more http://www.hp.com/go/hpsc
HP's Support Center Mobile App * allows you to resolve issues yourself or quickly connect to an agent for
live support. Now, you can get access to personalized IT support anywhere, anytime.
HP Insight Remote Support and HP Support Center are available at no additional cost with a HP warranty,
HP Care Pack or HP contractual support agreement.
*HP' Support Center Mobile App is subject to local availability
Warranty / Service
Coverage
For ProLiant servers and storage systems, the services cover HP-branded hardware options qualified for
the server, purchased at the same time or afterward, internal to the enclosure, as well as external
monitors up to 22" and tower UPS products; these items will be covered at the same service level and for
the same coverage period as the server unless the maximum supported lifetime and/or the maximum
usage limitation has been exceeded. Coverage of the UPS battery is not included; standard warranty terms
and conditions apply.
The defective media retention service feature option applies only to Disk or eligible SSD/Flash Drives
replaced by HP due to malfunction. It does not apply to any exchange of Disk or SSD/Flash Drives that
have not failed. SSD/Flash Drives that are specified by HP as consumable parts and/or that have exceeded
maximum supported lifetime and/or the maximum usage limit as set forth in the manufacturer's operating
manual or the technical data sheet are not eligible for the defective media retention service feature option.
For more information To learn more on HP ProLiant servers and HP BladeSystem servers, please contact your HP sales
representative or HP Authorized Channel Partner. Or visit: http://www.hp.com/services/proliant
QuickSpecs
HP ProLiant DL380p Generation8 (Gen8)
Service and Support
DA - 14212 North America — Version 38 — July 22, 2013 Page 17

NOTE: For the Standard Features shipped in the "Factory Integrated Models", please see the "Configuration Information - Factory
Integrated Models" section.
NOTE: Pre-configured models ship with the configurations below. Options can be selected from the Core or Additional options section
of this QuickSpecs.
NOTE: HP does not allow factory integration of options into pre-configured models. Any additional options purchased will be shipped
separately.
NOTE: If you desire a custom configuration please see "Configuration Information - Factory Integrated Models" section of this
QuickSpecs.
NOTE: All Pre-configured Models come populated with some hard drive blanks installed. Should the customer need additional hard
drive blanks, they can order more using either P/N 666987-B21: HP SFF Gen8 Hard Drive Blank Kit or P/N 666986-B21: HP LFF Gen8
Hard Drive Blank Kit.
Entry Models
HP ProLiant DL380p Gen8
E5-2609 1P 4GB-R P420i
SFF 460W PS Entry Server
642121-001
Processor(s) (1) Intel® Xeon® E5-2609 (2.4GHz/4-core/10MB/6.4GT-s QPI/80W) Processor
Cache Memory 10MB (1x10MB) Level 3
Memory 4GB (1x4GB) PC3L-10600R (DDR3-1333) Registered DIMMS
NOTE: Total 24 DIMM slots available with processor upgrade (2P
configuration)
Network Controller HP Ethernet 1Gb 4-port 331FLR Adapter
Storage Controller HP Smart Array P420i/ZM (RAID 0/1/1+0)
Hard Drive None ship standard
Internal Storage Standard: 8 SFF SAS/SATA HDD Bays; includes 6 SFF hard drive blanks
Optional: +8 SFF (total of 16) SFF SAS/SATA HDD Bays
Optical Drive Bay Optional Slim Optical Bay (SATA DVD-RW/ROM Optical Drive)
PCI-Express Slots 3 PCIe slots (+3 PCI slots available with upgrade option)
Power Supply (1) HP 460W Common Slot Gold Hot Plug Power Supply (92% Efficient)
Fans (4) (N+1 redundancy standard)
Management HP iLO Management Engine (standard)
Optional: HP Insight Control
Energy Star Meets Energy Star requirements
Form Factor Rack (2U), HP Friction Rail Kit
NOTE: The Friction Rail Kit is not compatible with the Cable Management Arm
option.
NOTE: The HP 2U Gen8 Cable Management Arm is not available when using
Friction Rails.
NOTE: To assist in the installation of the server into the rack an optional
installation tool is available by contacting your local services representative
(p/n 695539-001).
Caution: HP recommends that a minimum of two people are required for all
Rack Server installations. Please refer to your installation instructions for
proper tools and number of people to use for any installation.
Warranty Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support
with next business day response.
QuickSpecs
HP ProLiant DL380p Generation8 (Gen8)
Pre-configured Models
DA - 14212 North America — Version 38 — July 22, 2013 Page 18

Base Models
Six-Core Models
HP ProLiant DL380p Gen8
E5-2640 1P 16GB-R P420i
SFF 460W PS Base Server
642107-001
HP ProLiant DL380p Gen8
E5-2630 1P 16GB-R P420i
SFF 460W PS Base Server
642119-001
HP ProLiant DL380p Gen8
E5-2620 1P 16GB-R P420i
SFF 460W PS Base Server
642120-001
Processor(s)
One of the following
depending on Model
(1) Intel® Xeon® E5-2640 (2.5GHz/6-core/15MB/7.2GT-s QPI/95W, DDR3-
1333, HT, Turbo2- 3/3/4/4/5/5) Processor
(1) Intel® Xeon® E5-2630 (2.3GHz/6-core/15MB/7.2GT-s QPI/95W, DDR3-
1333, HT, Turbo2- 3/3/4/4/5/5) Processor
(1) Intel® Xeon® E5-2620 (2.0GHz/6-core/15MB/7.2GT-s QPI/95W, DDR3-
1333, HT, Turbo2- 3/3/4/4/5/5) Processor
Cache Memory 15MB (1x15MB) Level 3
Memory 16GB (4x4GB) PC3L-10600R (DDR3-1333) Registered DIMMS
NOTE: Total 24 DIMM slots available with processor upgrade (2P
configuration)
Network Controller HP Ethernet 1Gb 4-port 331FLR Adapter
Storage Controller HP Smart Array P420i/1GB FBWC (RAID 0/1/1+0/5/5+0)
Hard Drive None ship standard
Internal Storage Standard: 8 SFF SAS/SATA HDD Bays; includes 6 SFF hard drive blanks
Optional: +8 SFF (total of 16) SFF SAS/SATA HDD Bays
Optical Drive Bay Optional Slim Optical Bay (SATA DVD-RW/ROM Optical Drive)
PCI-Express Slots 3 PCIe slots (+3 PCI slots available with upgrade option)
Power Supply (1) HP 460W CS Platinum Plus Hot Plug Power Supply (94% Efficient)
Fans (4) (N+1 redundancy standard)
Management HP iLO Management Engine (standard)
Optional: HP Insight Control
Energy Star Meets Energy Star requirements
Form Factor Rack (2U), HP Ball Bearing Rail Kit /Cable Management Arm standard
NOTE: The HP 2U Gen8 Cable Management Arm is not available when using
Friction Rails.
NOTE: To assist in the installation of the server into the rack an optional
installation tool is available by contacting your local services representative
(p/n 695539-001).
Caution: HP recommends that a minimum of two people are required for all
Rack Server installations. Please refer to your installation instructions for
proper tools and number of people to use for any installation.
Warranty Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support
with next business day response.
QuickSpecs
HP ProLiant DL380p Generation8 (Gen8)
Pre-configured Models
DA - 14212 North America — Version 38 — July 22, 2013 Page 19

High Performance Models
NOTE: These Models are Energy Star Certified.
Eight-Core Models
HP ProLiant DL380p Gen8
E5-2690 2P 32GB-R P420i
SATA SFF 750W PS High
Perf Server
662257-001
HP ProLiant DL380p Gen8
E5-2665 2P 32GB-R P420i
SFF 750W PS High Perf
Server
642105-001
HP ProLiant DL380p Gen8
E5-2650 2P 32GB-R P420i
SFF 750W PS High Perf
Server
642106-001
Processor(s)
One of the following
depending on Model
(2) Intel® Xeon® E5-2690 (2.9GHz/8-core/20MB/8GT-s QPI/135W, DDR3-1600,
HT, Turbo2- 4/4/4/5/5/7/7/9) Processor
(2) Intel® Xeon® E5-2665 (2.4GHz/8-core/20MB/8GT-s QPI/115W, DDR3-1600,
HT, Turbo2- 4/4/5/5/6/6/7/7) Processor
(2) Intel® Xeon® E5-2650 (2.0GHz/8-core/20MB/8GT-s QPI/95W, DDR3-1600,
HT, Turbo2- 4/4/5/5/5/7/8/8) Processor
Cache Memory 20MB (1x20MB) Level 3
Memory 32GB (4x8GB) PC3-12800R (DDR3-1600) Registered DIMMS
NOTE: Total 24 DIMM slots available.
Network Controller
One of the following
depending on Model
HP Ethernet 10Gb 2-port 530FLR-SFP+ Adapter (on E5-2690/E5-2665 Models)
NOTE: SFP Transceivers for the 530FLR-SFP+ are not included with the server
and must be purchased separately.
HP Ethernet 1Gb 4-port 331FLR Adapter (on E5-2650 Model)
Storage Controller HP Smart Array P420i/2GB FBWC (RAID 0/1/1+0/5/5+0)
Hard Drive None ship standard
Internal Storage Standard: 8 SFF SAS/SATA HDD Bays; includes 6 SFF hard drive blanks
Optional: +8 SFF (total of 16) SFF SAS/SATA HDD Bays
Optical Drive Bay DVD-RW standard
PCI-Express Slots 6 PCIe slots (includes second riser slot upgrade option)
Power Supply (2) HP 750W CS Platinum Plus Hot Plug Power Supplies (94% Efficient)
Fans (6) (N+1 redundancy standard)
Management HP iLO Management Engine (standard)
HP Insight Control Standard
Energy Star Meets Energy Star requirements
Form Factor Rack (2U), HP Ball Bearing Rail Kit /Cable Management Arm standard
NOTE: The HP 2U Gen8 Cable Management Arm is not available when using
Friction Rails
NOTE: To assist in the installation of the server into the rack an optional
installation tool is available by contacting your local services representative
(p/n 695539-001).
CAUTION: HP recommends that a minimum of two people are required for all
Rack Server installations. Please refer to your installation instructions for
proper tools and number of people to use for any installation.
Warranty Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support
with next business day response.
QuickSpecs
HP ProLiant DL380p Generation8 (Gen8)
Pre-configured Models
DA - 14212 North America — Version 38 — July 22, 2013 Page 20
