Front View:
1. Eight sockets for PC2-5300 Fully Buffered DIMMs
(DDR2-667)
2. Hot-plug fans, full redundancy
3. Systems Insight Display
4. Quick release lever for rapid server access
5. Support for eight Small Form Factor hot plug hard drives
bays
6. Front LEDs (show server status) and Unit Identification
button/LED (for easy in rack server identification)
7. Two front USB ports (2 rear USB ports, 1 internal USB
port)
8. Intel Xeon Processor (Performance models include two
processors)
9. Hot plug power supply, redundancy option (High
performance models include redundant power supply)
10. Three full-size PCI-E expansion slots in standard
expansion cage (or optional mixed PCI-X/E expansion
cage). Two additional low-profile PCI-E slots embedded
on the system board. Four slots available for use; one
consumed by Smart Array controller (Base and
Performance models)
11. Quick removal access panel
Rear View:
1. Torx service tool
2. Optional pass through cable door
3. Two Embedded NC373i Multifunction Gigabit Server
Adapters with TCP/IP Offload Engine
4. Hot plug power supply bays, redundancy option (High
performance models include redundant power supply)
5. Integrated Lights-Out 2 (iLO 2) Remote management port
6. Video Port
7. Two USB 2.0 Ports
8. Serial Port
9. Keyboard Port
10. Mouse PS/2 Port
11. Two low-profile PCI Express x8 slots. Slot 1 is consumed
by the P400 Smart Array controller. (Base and
Performance models)
12. Three full-size PCI Express slots in standard cage (or
optional mixed PCI-X/E expansion cage)
What's New
New Intel® Xeon® Dual-core 5200 series processors
QuickSpecs
HP ProLiant DL380 Generation 5
Overview
DA - 12477 Worldwide QuickSpecs — Version 32 — 1.22.2008 Page 1

At A Glance
The HP ProLiant DL380, the world's best selling server, delivers on its history of design excellence with enterprise-class
uptime and manageability, proven 2-way Intel® Xeon® performance, and 2U density for a variety of rack deployments and
applications.
Processors:
Quad-Core and Dual-Core Intel® Xeon®processors for blazing performance; systems support up to 2
processors (2 processors standard on all Performance models)
Preconfigured Performance models save valuable deployment time at a discounted bundle price
Intel® 5000P chipset
Memory:
Up to 32 GB PC2-5300 Fully Buffered DIMMs (DDR2-667) with 4:1 and 2:1 interleaving available, online spare
and mirrored memory capabilities
Storage Controller:
Performance Models: HP Smart Array P400/512MB BBWC Controller (RAID 0/1/1+0/5/6)
Base Models: HP Smart Array P400/256MB Controller (RAID 0/1/1+0/5)
Entry Models: HP Smart Array E200/64MB Controller (RAID 0/1/1+0)
Internal Drive Support:
(8) small form factor (SFF) hot-plug drive bays to support Serial-attached SCSI (SAS) and Serial ATA (SATA)
drives
Slimline media bay supporting Optical or Floppy drive
Network Controller:
Two embedded NC373i Multifunction Gigabit Network Adapters with TCP/IP Offload Engine, including support
for Accelerated iSCSI through an optional Licensing Kit
Expansion Slots:
Four available PCI-Express slots, optional mixed PCI-X / PCI-Express configurations available (see "Standard
Features -Expansion Slots" section below for more details)
USB Ports:
USB 2.0 support
5 total ports: (2) ports up front; (2) ports in back; (1) port internal
Redundancy:
Fully redundant hot plug fans (N+1)
Hot plug power supply with optional redundancy (Included in Performance models)
Management:
HP Insight Control Environment server management software
Integrated Lights-Out 2 featuring Integrated Remote Console with KVM over IP performance over shared
network access
HP Power Meter and Power Regulator for ProLiant, delivering integrated power monitoring and server level,
policy based power management with industry leading energy efficiency and savings on system power and
cooling costs.
Automatic Server Recovery (ASR), ROM Based Setup Utility (RBSU), HP System Insight Manager, Status LEDs
including system health and UID and SmartStart
System Insight Display on the front bezel for quick and easy server diagnostics
Form Factor:
Rack (2U), (3.5-inch); Depth 26 inches (66 cm)
Deployment/Serviceability:
Quick Deploy Rail System includes sliding universal rails, an ambidextrous cable management arm and quick
release levers for fast and easy serviceability
Tool-less access to all system components for easy in rack serviceability
Warranty:
This product is covered by a global limited warranty and supported by HP Services and a worldwide network of
HP Authorized Channel Partners resellers. Hardware diagnostic support and repair is available for three years
from date of purchase. Support for software and initial setup is available for 90 days from date of purchase.
Enhancements to warranty services are available through HP Care Pack services or customized service
agreements. SATA hard drives have a one-year warranty.
NOTE: Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support with next business day
response. Additional information regarding worldwide limited warranty and technical support is available at:
http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html
QuickSpecs
HP ProLiant DL380 Generation 5
Overview
DA - 12477 Worldwide QuickSpecs — Version 32 — 1.22.2008 Page 2

NOTE: For a brief, printer friendly data sheet that describes this product and informs you of the essential capabilities and
specifications, please visit: http://h71028.www7.hp.com/ERC/downloads/5983-0605EN.pdf .
NOTE: For the Standard Features shipped in the "Factory Integrated Models", please see the "Configuration Information -
Factory Integrated Models" section.
Processor
One of the following
depending on Model
Quad-Core Intel® Xeon® Processor X5460 (3.16 GHz, 120 Watts, 1333 Front Side Bus (FSB))
Quad-Core Intel® Xeon® Processor X5450 (3.0 GHz, 120 Watts, 1333 FSB)
Quad-Core Intel® Xeon® Processor E5450 (3.00 GHz, 80 Watts, 1333 FSB)
Quad-Core Intel® Xeon® Processor E5440 (2.83 GHz, 80 Watts, 1333 FSB)
Quad-Core Intel® Xeon® Processor E5430 (2.66 GHz, 80 Watts, 1333 FSB)
Quad-Core Intel® Xeon® Processor E5420 (2.50 GHz, 80 Watts, 1333 FSB)
Quad-Core Intel® Xeon® Processor E5410 (2.33 GHz, 80 Watts, 1333 FSB)
Quad-Core Intel® Xeon® Processor E5405 (2.00 GHz, 80 Watts, 1333 FSB)
Quad-Core Intel® Xeon® Processor X5365 (3.00 GHz, 120 Watts, 1333 FSB)
Quad-Core Intel® Xeon® Processor X5355 (2.66 GHz, 120 Watts, 1333 FSB)
Quad-Core Intel® Xeon® Processor E5345 (2.33 GHz, 80 Watts, 1333 FSB)
Quad-Core Intel® Xeon® Processor L5335 (2.00 GHz, 50 Watts, 1333 FSB, Low Voltage)
Quad-Core Intel® Xeon® Processor E5335 (2.00 GHz, 80 Watts, 1333 FSB)
Quad-Core Intel® Xeon® Processor E5320 (1.86 GHz, 80 Watts, 1066 FSB)
Quad-Core Intel® Xeon® Processor L5320 (1.86 GHz, 50 Watts, 1066 FSB)
Quad-Core Intel® Xeon® Processor E5310 (1.60 GHz, 80 Watts, 1066 FSB)
Dual-Core Intel® Xeon® Processor X5260 (3.33 GHz, 80 Watts, 1333 FSB)
Dual-Core Intel® Xeon® Processor E5205 (1.86 GHz, 65 Watts, 1066 FSB)
Dual-Core Intel® Xeon® Processor 5160 (3.0 GHz, 80 Watts, 1333 FSB)
Dual-Core Intel® Xeon® Processor 5150 (2.66 GHz, 65 Watts, 1333 FSB)
Dual-Core Intel® Xeon® Processor 5148 (2.33 GHz, 40 Watts, 1333 FSB, Low Voltage)
Dual-Core Intel® Xeon® Processor 5140 (2.33 GHz, 65 Watts, 1333 FSB)
Dual-Core Intel® Xeon® Processor 5130 (2.0 GHz, 65 Watts, 1333 FSB)
Dual-Core Intel® Xeon® Processor 5120 (1.86 GHz, 65 Watts, 1066 FSB)
Dual-Core Intel® Xeon® Processor 5110 (1.6 GHz, 65 Watts, 1066 FSB)
Dual-Core Intel® Xeon® Processor 5080 (3.73GHz, 130 Watts, 1066 FSB)
Dual-Core Intel® Xeon® Processor 5060 (3.2GHz, 130 Watts, 1066 FSB)
Dual-Core Intel® Xeon® Processor 5050 (3.0 GHz, 95 Watts, 667 FSB)
NOTE: Up to 2 processors supported. Performance configurations include two processors. Mixing
different processor models is not supported.
Cache Memory
One of the following
depending on Model
12MB (2 x 6MB) Level 2 cache (5400 series)
8MB (2 x 4MB) Level 2 cache (5300 series)
6MB (2 x 3MB) Level 2 cache (5200 series)
4MB (1 x 4MB) Level 2 cache (5100 series)
4MB (2 x 2MB) Level 2 cache (5000 series)
Chipset Intel® 5000P Chipset
NOTE: For more information regarding Intel chipsets, please see the following URL:
http://www.intel.com/products/server/chipsets/ .
QuickSpecs
HP ProLiant DL380 Generation 5
Standard Features
DA - 12477 Worldwide QuickSpecs — Version 32 — 1.22.2008 Page 3

Upgradeability Upgradeable to 2 processors (8 cores)
Future upgradeable to Xeon® Series 5400/5300 Quad-Core processors (Please contact your
regional sales support to determine quad core upgradeability. Some of the earlier shipping models
may not support this upgrade). 5100 Dual-Core models are not upgradeable to the 5200 Dual-
Core processors.
Memory Protection Advanced ECC (multi-bit error protection), Online Spare, Mirroring
4-way Interleaving
Memory Type PC2-5300 Fully Buffered DIMMs (DDR2-667) with 4:1 and 2:1
interleaving available (interleaving requires identical DIMMs)
Standard
(Entry Models)
1 GB (2 x 512 MB)
Standard
(Base Models)
2 GB (2 x 1 GB)
Standard
(Performance Models)
4 GB (4 x 1 GB)
Maximum 32 GB (8 x 4 GB)
NOTE: Memory DIMMs in systems with the Front Side Bus (FSB) running at 1333 MHz will run at
667 MHz and in systems with a FSB running at 1066 MHz or 667 MHz the memory DIMMs will run
at 533 MHz.
Network Controller Two embedded NC373i Multifunction Gigabit Network Adapters with TCP/IP Offload Engine,
including support for Accelerated iSCSI through an optional Licensing Kit
Expansion Slots
Embedded Slots Slot
Number
Bus Speed * Bus Number ** Device
Number ***
Hot Plug PCI Voltage
1 x4 PCIe (x8
connector)
6 0 no N/A
2 x4 PCIe
(x8 connector)
11 0 no N/A
NOTE: Embedded slots support half-height low profile cards. For Base and Performance models,
the integrated Smart Array P400 (SAS Controller) is installed in Slot 1.
PCIe Riser (Standard) Slot
Number
Bus Speed * Bus Number ** Device
Number ***
Hot Plug PCI Voltage
3 x4 PCIe
(x8 connector)
14 0 no N/A
4 x8 PCIe
(x16 connector)
23 0 no N/A
5 x8 PCIe
(x16 connector)
19 0 no N/A
NOTE: Riser slots support full-size PCIe/PCI-X cards. For Entry model, the standard Smart Array
E200 Controller with 64MB Cache (SAS Controller) is installed in Slot 3.
QuickSpecs
HP ProLiant DL380 Generation 5
Standard Features
DA - 12477 Worldwide QuickSpecs — Version 32 — 1.22.2008 Page 4

PCIe/PCI-X Riser
(Optional)
Slot
Number
Bus Speed * Bus Number ** Device
Number ***
Hot Plug PCI Voltage
3 x8 PCIe
(x16 connector)
23 0 no N/A
4 64-bit/133MHz
PCI-X
18 1 no 3.3 Volt
5 64-bit/133MHz
PCI-X
18 2 no 3.3 Volt
NOTE: Server has 5 total slots with 4 slots are available for use; one slot populated by the internal
storage controller.
* x4 slots support x8 cards, but will run at x4 speeds. x8 slots support x16 cards, but will run at x8
speeds.
** Default bus assignment. Inserting cards with PCI bridges may alter the actual bus assignment
number.
*** Slots are enumerated differently based on OS. MS OS's enumerate from lowest to highest
Device ID by bus (starting with the lowest bus).
Storage Controller
One of the following
depending on Model
Performance Models: HP Smart Array P400/512MB BBWC Controller (RAID 0/1/1+0/5/6)
Base Models: HP Smart Array P400/256MB Controller (RAID 0/1/1+0/5)
Available upgrades : 512MB battery-backed write cache (BBWC) or
standalone battery for RAID 0/1/1+0/5/6
Entry Models: HP Smart Array E200/64MB Controller (RAID 0/1/1+0)
Available upgrades : 128MB battery-backed write cache (BBWC) for
RAID 0/1/1+0/5
Storage Diskette Drive None Standard
Optical Drive
One of the following
depending on Model
None Standard
IDE DVD-ROM/CDRW Combo included on Performance models
Hard Drives None Standard
Maximum Internal
Storage
Hot Plug SAS 1.168TB 8 x 146GB with standard internal hot plug SFF
SAS drive cage
Remote Management Integrated Lights Out 2 (iLO2) Standard Management:
Virtual Text Remote Console (pre-OS only)
Remote Serial Console
Virtual Power Button Control
Virtual Unit ID control
Integrated Remote Console
Dedicated & full function shared network connectivity
Embedded system health
Browser, command line and scripted access
Automatic IP Configuration via DHCP/DNS/WINS
Industry Standard 128-bit Secure Sockets Layer (SSL) and Secure Shell security (SSH)
OS independent hardware health status
IML and iLO Event Logging
Support for 12 user accounts with customizable access privilege
QuickSpecs
HP ProLiant DL380 Generation 5
Standard Features
DA - 12477 Worldwide QuickSpecs — Version 32 — 1.22.2008 Page 5

Intelligent
Manageability
HP Systems Insight Manager
SmartStart
Management Agent
Redundant ROM
Remote Flash ROM
ROM-Based Setup Utility (RBSU)
Integrated Management Log
Automatic Server Recovery (ASR)
Dynamic Sector Repairing (with Smart Array controller)
Drive Parameter Tracking (with Smart Array controller)
Hot Spare Boot
NOTE: Upon the event of a failed processor in a multi-processing environment, the system will
automatically reboot and attempt to use the remaining good processor.
Pre-Failure Warranty (covers processors, SAS hard drives and memory)
Interfaces Serial 1
Pointing Device (Mouse) 1
Graphics 1
Keyboard 1
VGA 2 (1 front, 1 back)
Network RJ-45 2
iLO 2 remote
management port
1
USB 2.0 Ports 5 total: 2 front, 2 back, 1 internal
NOTE: Please see the following URL for additional information
regarding USB support:
http://h18004.www1.hp.com/products/servers/platforms/usb-
support.html .
Graphics Integrated ATI ES1000, 32MB video standard
16 bit color: maximum resolution of 1600 x 1200
32 bit color: maximum resolution of 1280 x 1024
NOTE: Maximum resolution available via iLO 2 remote console is 1280x1024.
Form Factor Rack (2U); Height 3.38-inch (8.59 cm); Depth: 26 inches (66 cm)
QuickSpecs
HP ProLiant DL380 Generation 5
Standard Features
DA - 12477 Worldwide QuickSpecs — Version 32 — 1.22.2008 Page 6

HP Insight Control
Management Suites
HP Insight Control Environment delivers foundation management, including remote monitoring,
hardware resource deployment, health monitoring, software version control, performance
monitoring, vulnerability scanning and patch management, and power management.
HP Insight Control Environment installs and licenses the following components by default using a
wizard-based integrated installer:
HP Systems Insight Manager
HP iLO Advanced Pack
HP Rapid Deployment Pack
HP Insight Power Manager
HP Performance Management Pack
HP Vulnerability and Patch Management Pack
Additional ProLiant Essentials software and management tools included on the Insight Control
Management kit can be installed manually:
HP Server Migration Pack - Universal Edition
HP Open Service Event Manager
HP Instant Support Enterprise Edition
NOTE: Server Migration Pack - Universal Edition can be installed from the SMP Universal CD
included in the Insight Control Management media kit.
NOTE: For additional product and licensing information about HP Insight Control Environment,
visit: http://www.hp.com/go/ice .
HP Insight Control management suites and most HP ProLiant Essentials include a one year of 24
x 7 HP Software Technical Support and Update Service ensuring rapid access to HP support staff
and proactive delivery of software updates. For more information about this service, please visit:
http://www.hp.com/services/insight .
Server Management
Stand Alone Software
Product - ProLiant
Essentials
HP Systems Insight
Manager
HP Systems Insight Manager (HP SIM) provides a unified, secure and
extensible standards-based environment to centrally manage servers,
storage and other infrastructure devices, (both HP and non-HP) across
multiple operating system platforms.
ProLiant Essentials
Rapid Deployment Pack
Rapid Deployment Pack (RDP) extends HP Systems Insight Manager
with a complete deployment solution for HP ProLiant servers. RDP
provides a central location to configure server hardware, deploy
Windows, Linux and VMware ESX operating environments and install
HP ProLiant Support Pack drivers using images and scripted profiles.
For more information, visit: http://www.hp.com/servers/rdp .
ProLiant Essentials
Server Migration Pack -
Universal Edition
Upgrading, replacing, or virtualizing your existing server? Effortlessly
transition to new virtual or physical HP ProLiant servers or BladeSystem
with automated, accurate and affordable migration of OS, application
and data. SMP Universal automates the manual processes required for
migrating servers between physical or virtual platforms, whether
migrating to VMware or Microsoft virtual machines. SMP Universal
allows all of the following migrations:
physical to ProLiant
physical to virtual
virtual to virtual
virtual to ProLiant
NOTE: For more information, visit: http://www.hp.com/go/migrate .
QuickSpecs
HP ProLiant DL380 Generation 5
Standard Features
DA - 12477 Worldwide QuickSpecs — Version 32 — 1.22.2008 Page 7

ProLiant Essentials
Performance
Management Pack
Performance Management Pack (offered exclusively through the Insight
Control suites) - a performance management solution that identifies and
explains hardware performance bottlenecks on ProLiant servers and
attached options enabling users to better utilize their valuable
resources.
Integrated Lights-Out
Advanced Pack
Upgrades the iLO 2 processor with comprehensive remote control
including Virtual KVM remote graphical console, enhanced console
sharing and replay, virtual media (floppy, CD/DVD, USB key), virtual
folders, and enterprise security (directory services and two-factor
authentication).
Integrated Lights-Out
Select Pack
Upgrades the iLO 2 processor with enhanced console sharing and
replay, virtual media (floppy, CD/DVD, USB key), virtual folders,
historical power reporting, power capping and enterprise security
(directory services and two-factor authentication) for servers managed
using remote consoles available in iLO 2 Standard and iLO 2 Standard
Blade Edition.
iLO Power Management
Pack
Energy-efficient management software that delivers centralized control,
reliable security, and energy savings for your BladeSystem
infrastructure. iPMP combines the total control of iLO 2 Advanced in the
area of remote management with the energy monitoring and control of
the Insight Power Manager to deliver a robust solution capable of full
remote control and power management of ProLiant servers through a
unified interface within HP Systems Insight Manager.
ProLiant Essentials
Accelerated iSCSI Pack
Enables the embedded Multifunction network controller to serve as both
a NIC and an iSCSI HBA providing access to SAN storage over the
same connection used for networking. Processing of the protocol stack
is offloaded to the NIC reducing CPU utilization and greatly improving
the speed with which the requests are processed and sent to the
network.
HP Insight Power
Manager (IPM)
Upgrades the single-server remote management capabilities of iLO
Select/Advanced to include centralized reporting and policy-based
management of power consumption and thermal output provided by the
Insight Power Manager. IPM unifies all of this functionality within a
single user interface - HP Systems Insight Manager.
NOTE: Flexible and volume quantity license kits are available for ProLiant Essentials Value Packs.
Refer to: http://www.hp.com/servers/proliantessentials or the various ProLiant Essentials Value
Pack product QuickSpecs for more information.
QuickSpecs
HP ProLiant DL380 Generation 5
Standard Features
DA - 12477 Worldwide QuickSpecs — Version 32 — 1.22.2008 Page 8

Core Infrastructure
Management
SmartStart SmartStart is a tool that simplifies server setup, providing a rapid way to
deploy reliable and consistent server configurations. For more
information, please visit the SmartStart Web site at:
http://www.hp.com/servers/smartstart .
SmartStart version supported (minimum): SmartStart 7.51
Insight Management
Agents
The Insight Management Agents should be installed on all HP servers to
present system instrumentation, health and configuration information
into HP Systems Insight Manager and the HP System Management
Homepage. The HP System Management Homepage aggregates
systems data from Insight Management Agents and other HP
management tools, providing a consolidated browser-based interface for
managing individual servers.
Insight Management Agents and The HP System Management
Homepage are included on ProLiant Support Packs, and can also be
installed using the server profiles provided with the ProLiant Essentials
Rapid Deployment Pack
For additional information about the Management Agents and the HP
System Management Homepage please visit the management Web site
at: http://www.hp.com/servers/manage .
Subscriber's Choice Subscriber's Choice Driver and Support Alerts/Notifications is a web-
based email subscription service that provides software and driver
change notifications for ProLiant products. Sign up at:
http://www.hp.com/go/subscriberschoice
and customize your profile to receive various new alerts as they become
available, on a weekly or monthly basis.
ProLiant Support Packs
and ROMPaq, software
The latest software, drivers, and firmware fully optimized and tested for
your ProLiant server and options, available through ProLiant Support
Packs the ProLiant Essentials Rapid Deployment Pack, SmartStart or
downloaded from software and drivers download pages website at:
http://www.hp.com/go/support .
Industry Standard
Compliance
ACPI 2.0 Compliant
PCI 2.2 Compliant
WOL Support
Microsoft® Logo certifications
USB 2.0 Support
Security Power-on password
Keyboard password
Diskette drive control
Diskette boot control
QuickLock, Network Server Mode
Parallel and serial interface control
Administrator's password
Server Power Cords An IEC13 to IEC14 jumper cord ships standard with all part numbers if connecting to a UPS or
PDU. If a localized cable is desired or required for each geographic specific model, it needs to be
purchased, including the US.
UPS and PDU Power
Cord Matrix
Please see the UPS and PDU cable matrix that lists cable descriptions, requirements, and
specifications for UPS and PDU units:
http://h18004.www1.hp.com/products/servers/proliantstorage/power-protection/index.html
QuickSpecs
HP ProLiant DL380 Generation 5
Standard Features
DA - 12477 Worldwide QuickSpecs — Version 32 — 1.22.2008 Page 9

Power Supply 800Watt, CE Mark Compliant
Optional Hot Plug AC Redundant Power Supply
System Fans Fully redundant hot plug fans ship standard (N+1).
OS Support Microsoft Windows Server 2000
Microsoft Windows Server 2003
Microsoft Windows Small Business Server 2003, R2
Novell NetWare
Red Hat Enterprise Linux
SUSE Linux Enterprise Server
SCO UnixWare, OpenServer
VMware Virtualization Software
Solaris 10 32/64-bit
NOTE: For more complete and up-to-date information on how to buy server operating systems
from HP please visit the OS product site at:
http://h18004.www1.hp.com/products/servers/software/OEM.html .
NOTE: For a more complete and up-to-date listing of supported OSs and versions, please visit our
OS Support Matrix at: http://www.hp.com/go/supportos .
NOTE: For an up-to-date listing of the latest drivers available for the HP ProLiant DL380 G5,
please see: http://h18023.www1.hp.com/support/files/server/us/index.html .
NOTE: For more Linux OS support & certification information, please visit our the ProLiant &
BladeSystem Server Linux matrix:
http://h18004.www1.hp.com/products/servers/linux/hpLinuxcert.html
NOTE: For more information on HP's Certified and Supported ProLiant Servers, please visit the
VMware Server Support Matrix at:
http://h18004.www1.hp.com/products/servers/software/vmware/hpvmwarecert.html .
Rack Airflow
Requirements
Rack 10000 series Cabinets
The increasing power of new high-performance processor technology requires increased cooling
efficiency for rack-mounted servers. The 10000 Series Racks provide enhanced airflow for
maximum cooling, allowing these racks to be fully loaded with servers using the latest processors.
CAUTION: If a third-party rack is used, observe the following additional requirements to ensure
adequate airflow and to prevent damage to the equipment:
Front and rear doors: If your 42U server rack includes closing front and rear doors, you
must allow 830 square inches (5,350 sq cm) of hole evenly distributed from top to bottom to
permit adequate airflow (equivalent to the required 64 percent open area for ventilation).
Side: The clearance between the installed rack component and the side panels of the rack
must be a minimum of 2.75 inches (7 cm).
CAUTION: Always use blanking panels to fill all remaining empty front panel U-spaces in the rack.
This arrangement ensures proper airflow. Using a rack without blanking panels results in improper
cooling that can lead to thermal damage.
NOTE: For additional information, refer to the Setup and Installation Guide or the Documentation
CD provided with the server, or to the server documentation located in the Support section at the
following URL: www.hp.com/servers/dl380 .
QuickSpecs
HP ProLiant DL380 Generation 5
Standard Features
DA - 12477 Worldwide QuickSpecs — Version 32 — 1.22.2008 Page 10

Rack Kit The HP ProLiant DL380 quick deploy rail system provides tool-free support for racks with square
or round mounting holes (including Compaq/HP 7000*, 9000, 10000 and HP series), with an
adjustment range of 24" - 36". The ambidextrous cable management arm can be mounted on
either the left or right side for improved cable management.
NOTE: Cable management arm must be removed to access hot-plug power supplies when the
cable management arm is mounted on the right.
* NOTE: High Airflow Inserts (High Air Flow Rack Door Insert for the 7142 Rack (single) - PN:
327281-B21; or High Air Flow Rack Door Insert for the 7142 Rack (6-pack) - PN: 327281-B22) are
required to support the HP ProLiant DL380 G5 in 7000 series racks. The DL380 G5 Cable
Management Arm is not supported on 7000 series racks.
Telco Rack Support DL380 G5 Telco Rack Kit:
Support for all 2-post Telco racks requires the use of the standard rack kit and an additional option
kit from Rack Solutions: http://www.racksolutions.com/hp/ .
Factory Express
Portfolio for Servers
and Storage
HP Factory Express offers configuration, customization, integration and deployment services for
HP servers and storage products. Customers can choose how their factory solutions are built,
tested, integrated, shipped and deployed.
Factory Express offers service packages for simple configuration, racking, installation, complex
configuration and design services as well as individual factory services, such as image loading,
asset tagging, and custom packaging. HP products supported through Factory Express include a
wide array of servers and storage: HP Integrity, HP ProLiant, HP ProLiant Server Blades, HP
BladeSystem, HP 9000 servers as well as the MSA1000, VA7xxx, EVA, XP, rackable tape
libraries and configurable network switches.
For more information on Factory Express services for your specific server model please contact
your sales representative or go to: http://www.hp.com/go/factory-express .
HP Enterprise
Configurator
The HP eCo-Enterprise Configurator now provides factory default racking for our HP hardware
portfolio. This approach is aligned with our strategic direction to meet the needs and expectations
of our valued customers. If you require "custom" rack configuration, please contact HP's Customer
Business Center or an Authorized Partner for assistance.
http://www.hp.com/products/configurator .
Service and Support HP Care Pack services include coverage for the HP branded hardware options qualified for the
server and purchased at the same time or afterward that are internal to the enclosure. This also
includes the 22" and smaller external monitors and tower UPS options up to 3kVA. These items
will be covered at the same service level and for the same coverage period as the server.
Coverage of UPS Battery is not included, and standard warranty terms & conditions apply. For
servers or storage systems installed within a rack, service also covers all HP qualified rack
options installed within the same rack.
To fully capitalizing on your HP ProLiant servers' capabilities requires a service partner who
thoroughly understands your server technology and systems environment. HP Services, an
industry leader in provision of multi vender support solutions, provides a range of support services
designed to meet the varying needs of your business. Whether an SMB, or large global
corporation, HP has a ProLiant server support offer to help you speedily deploy and maximize
system uptime.
Recommended Service - simplify ProLiant solution implementation, maintenance, and
management.
Support : 3-Year 4-Hour response 24x7 Same Business Day Coverage only
Deployment Service : Installation and Start up only
Enhanced Service - optimize service level to increase IT performance and availability.
QuickSpecs
HP ProLiant DL380 Generation 5
Standard Features
DA - 12477 Worldwide QuickSpecs — Version 32 — 1.22.2008 Page 11

Support : 3-Year Support Plus 24 only
Refer to the information on "Installation & Start-Up" for service on ProLiant server and Microsoft or
Linux O/S per the Customer Description and/or Data Sheet; to be delivered on a scheduled basis
8am-5pm, M-F, excluding HP holidays.
NOTE: For a complete listing of service offerings and information visit:
http://www.hp.com/services/proliantservices
http://www.hp.com/go/proliant/carepack
QuickSpecs
HP ProLiant DL380 Generation 5
Standard Features
DA - 12477 Worldwide QuickSpecs — Version 32 — 1.22.2008 Page 12

NOTE: High Performance Computing (HPC) interconnect technologies are available for the DL380 under the Cluster
Platform product portfolio. These high-speed interconnects are fully supported by HP when they are part of these configure
to order clusters. Solutions can be defined with a lot of flexibility with the help of configuration tools. Please visit the following
URL to configure HPC Clusters with InfiniBand, Gigabit Ethernet or Myrinet Interconnects:
http://www.hp.com/techservers/clusters/ucp/index.html
HPC Interconnect InfiniBand PCI-X and PCI-Express adapters
Gigabit Ethernet Use embedded ports
Myrinet XP PCI-X Rev D and Rev E adapters
QuickSpecs
HP ProLiant DL380 Generation 5
HPC Interconnects
DA - 12477 Worldwide QuickSpecs — Version 32 — 1.22.2008 Page 13

NOTE: For the Standard Features shipped in the "Factory Integrated Models", please see the "Configuration Information -
Factory Integrated Models" section.
HP DL380 G5
Performance Models
Quad-Core Models
HP DL380G5 X5460 4G
458561-xx1
HP DL380G5 X5450 4G
458562-xx1
HP DL380G5 E5345 4G
433524-xx1
Dual-Core Models
HP DL380G5 5160 4G
HPM
418315-xx1
HP DL380G5 5150 4G
HPM
418314-xx1
Processor(s)
Two of the following
depending on Model
(2) Quad-Core Intel® Xeon® X5460 Processors (3.16 GHz, 120 Watt,
1333 FSB)
(2) Quad-Core Intel® Xeon® X5450 Processors (3.00 GHz, 120 Watt,
1333 FSB)
(2) Quad-Core Intel® Xeon® E5345 Processors (2.33 GHz, 80 Watt,
1333 FSB)
(2) Dual-Core Intel® Xeon® 5160 Processors (3.00 GHz, 80 Watt, 1333
FSB)
(2) Dual-Core Intel® Xeon® 5150 Processors (2.66 GHz, 65 Watt, 1333
FSB)
Cache Memory
Two of the following
depending on Model
12MB (2 x 6MB) Level 2 cache - Intel® Xeon® processor 5400
sequence
8MB (2 x 4MB) Level 2 cache - Intel® Xeon® processor 5300 sequence
6MB (2 x 3MB) Level 2 cache - Intel® Xeon® processor 5200 sequence
4MB (1 x 4MB) Level 2 cache - Intel® Xeon® processor 5100 sequence
Memory 4 GB (4 x 1 GB of PC2-5300 Fully Buffered DIMMs (DDR2-667) with
Advanced ECC, mirrored and online spare memory capabilities
Network Controller Two Embedded NC373i Multifunction Gigabit Server Adapters
Storage Controller HP Smart Array P400/512MB BBWC Controller (RAID 0/1/1+0/5/6)
Hard Drive None ship standard
Internal Storage 1.168TB (with optional hard drives)
Optical Drive IDE DVD-ROM/CDRW combo
Form Factor Rack (2U), Height 3.38-inch/8.59 cm; Depth: 26 inches (66 cm)
Availability Hot Plug Fully Redundant Fans and Power Supplies
HP DL380 G5 Base
Models
Quad-Core Models
HP DL380G5 E5440 2G
458563-xx1
HP DL380G5 E5430 2G
458565-xx1
HP DL380G5 E5420 2G
458567-xx1
HP DL380G5 E5335 2G
433525-xx1
HP DL380G5 E5320 2G
433526-xx1
Dual-Core Models
HP DL380RG5 X5260
2G
461453-xx1
HP DL380G5 5160 2G
417458-xx1
HP DL380G5 5150 2G
417457-xx1
HP DL380G5 5140 2G
417456-xx1
HP DL380G5 5130 2G
417455-xx1
Processor(s)
One of the following
depending on Model
(1) Quad-Core Intel® Xeon® Processor E5440 (2.83 GHz, 80 Watts,
1333 FSB)
(1) Quad-Core Intel® Xeon® Processor E5430 (2.66 GHz, 80 Watts,
1333 FSB)
(1) Quad-Core Intel® Xeon® Processor E5420 (2.50 GHz, 80 Watts,
1333 FSB)
(1) Quad-Core Intel® Xeon® Processor E5335 (2.00 GHz, 80 Watts,
1333 FSB)
(1) Quad-Core Intel® Xeon® E5320 Processors (1.86 GHz, 80 Watt,
1066 FSB)
(1) Dual-Core Intel® Xeon® Processor X5260 (3.33 GHz, 80 Watts,
1333 FSB)
(1) Dual-Core Intel® Xeon® 5160 Processors (3.00 GHz, 80 Watt, 1333
FSB)
(1) Dual-Core Intel® Xeon® 5150 Processors (2.66 GHz, 65 Watt, 1333
FSB)
(1) Dual-Core Intel® Xeon® 5140 Processor (2.33 GHz, 65 Watt, 1333
FSB)
(1) Dual-Core Intel® Xeon® 5130 Processor (2.0 GHz, 65 Watt, 1333
FSB)
Cache Memory
One of the following
depending on Model
12MB (2 x 6MB) Level 2 cache - Intel® Xeon® processor 5400
sequence
8MB (2 x 4MB) Level 2 cache - Intel® Xeon® processor 5300 sequence
6MB (2 x 3MB) Level 2 cache - Intel® Xeon® processor 5200 sequence
4MB (1 x 4MB) Level 2 cache - Intel® Xeon® processor 5100 sequence
4MB (2 x 2MB) Level 2 cache - Intel® Xeon® processor 5000 sequence
Memory 2 GB (2 x 1 GB) PC2-5300 Fully Buffered DIMMs (DDR2-667) with
Advanced ECC, mirrored and online spare memory capabilities
QuickSpecs
HP ProLiant DL380 Generation 5
Models
DA - 12477 Worldwide QuickSpecs — Version 32 — 1.22.2008 Page 14

Network Controller Two Embedded NC373i Multifunction Gigabit Server Adapters
Storage Controller HP Smart Array P400/256MB Controller (RAID 0/1/1+0/5)
Hard Drive None ship standard
Internal Storage 1.168TB (with optional hard drives)
Optical Drive Optional DVD, DVD/CD-RW combo, DVD+R/RW or floppy drive
Form Factor Rack (2U), Height 3.38-inch/8.59cm; Depth: 26 inches (66 cm)
Availability Hot Plug Fully Redundant Fans Standard
HP DL380 G5 Entry
Models
Quad-Core Models
DL380G5 E5405 1G
458568-xx1
HP DL380G5 E5310 1G
433527-xx1
Dual-Core Models
HP DL380G5 5120 1G
417454-xx1
HP DL380G5 5110 1G
417453-xx1
Processor(s)
One of the following
depending on Model
(1) Quad-Core Intel® Xeon® E5405 Processor (2.0 GHz, 80 Watt, 1333
FSB)
(1) Quad-Core Intel® Xeon® E5310 Processor (1.60 GHz, 80 Watt,
1066 FSB)
(1) Dual-Core Intel® Xeon® 5120 Processor (1.87 GHz, 65 Watt, 1066
FSB)
(1) Dual-Core Intel® Xeon® 5110 Processor (1.60 GHz, 65 Watt, 1066
FSB)
Cache Memory
Two of the following
depending on Model
12MB (2 x 6MB) Level 2 cache - Intel® Xeon® processor 5400
sequence
8MB (2 x 4MB) Level 2 cache - Intel® Xeon® processor 5300 sequence
6MB (2 x 3MB) Level 2 cache - Intel® Xeon® processor 5200 sequence
4MB (1 x 4MB) Level 2 cache - Intel® Xeon® processor 5100 sequence
Memory 1 GB (2 x 512 MB) PC2-5300 Fully Buffered DIMMs (DDR2-667) with
Advanced ECC, mirrored and online spare memory capabilities
Network Controller Two Embedded NC373i Multifunction Gigabit Server Adapters
Storage Controller HP Smart Array E200/64MB Controller (RAID 0/1/1+0)
Hard Drive None ship standard
Internal Storage 1.168TB (with optional hard drives)
Optical Drive Optional DVD, DVD/CD-RW combo, DVD+R/RW or floppy drive
Form Factor Rack (2U), Height 3.38-inch/8.59cm; Depth: 26 inches (66 cm)
Availability Hot Plug Fully Redundant Fans Standard
Country Code Key XX=00 U.S.
XX=20 Brazil
XX=29 Japan
XX=37 APD
XX=42 Euro
XX=AA PRC
QuickSpecs
HP ProLiant DL380 Generation 5
Models
DA - 12477 Worldwide QuickSpecs — Version 32 — 1.22.2008 Page 15

NOTE: This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid
configurations are ordered, HP recommends the use of an HP approved configurator. Contact your local sales
representative for information on CTO product offerings and requirements.
NOTE: HP does not allow factory integration of options into standard models listed above. Configure-to-order servers must
start with a CTO Chassis.
NOTE: This product offering does not support HP Factory Express Server Configuration Level 1.
NOTE: FIO indicates that this option only available as a Factory Installable Option.
Step 1: Base Configuration (choose one of the following configurable models)
Models HP ProLiant DL380G5 Rack CTO Chassis 391835-B21
Factory Integrated Model ships with:
(8) SFF Serial Attached SCSI (SAS) Drive Bays
Two Embedded NC373i Multifunction Gigabit Server Adapters
PCI-Express Riser Cage
800Watt hot plug power supply, CE Mark Compliant
One IEC Power cord
Rack (2U), (3.5-inch)
Step 1A: Choose SAS Controller (must choose only one of the following)
SAS Controllers HP Smart Array P400/256 for DL380 G5/ DL385 G2 FIO Controller
NOTE: PCI Express
405160-B21
HP Smart Array P400/512 BBWC for DL380 G5/ DL385 G2 FIO Controller
NOTE: PCI Express
405162-B21
HP Smart Array E200/128 BBWC Controller
NOTE: PCI Express
411508-B21
HP Smart Array P800/512 BBWC Controller
NOTE: PCI Express SA-P800 Controller supports both internal and external
drives.
381513-B21
HP Smart Array P600/256 BBWC Controller
NOTE: PCI-X. SA-P600 Controller supports both internal and external drives.
337972-B21
HP Smart Array E200/64 FIO Controller 405528-B21
HP Smart Array 6402/512 FIO Controller 441508-B21
HP Smart Array 6404/512 FIO CNTRLR 452240-B21
Step 2: Choose Required Options (only one of the following from each list unless
otherwise noted)
Processors Quad-Core Intel® Xeon® Processor X5460 (3.16 GHz, 120 Watts, 1333 FSB)
DL380 FIO Kit
458581-L21
Quad-Core Intel® Xeon® Processor X5450 (3.0 GHz, 120 Watts, 1333 FSB)
DL380 FIO Kit
462593-L21
Quad-Core Intel® Xeon® Processor E5450 (3.0 GHz, 80 Watts, 1333 FSB)
DL380 FIO Kit
458583-L21
Quad-Core Intel® Xeon® Processor E5440 (2.83 GHz, 80 Watts, 1333 FSB)
DL380 FIO Kit
458585-L21
Quad-Core Intel® Xeon® Processor E5430 (2.66 GHz, 80 Watts, 1333 FSB)
DL380 FIO Kit
458575-L21
Quad-Core Intel® Xeon® Processor E5420 (2.50 GHz, 80 Watts, 1333 FSB)
DL380 FIO Kit
458577-L21
Quad-Core Intel® Xeon® Processor E5410 (2.33 GHz, 80 Watts, 1333 FSB)
DL380 FIO Kit
459142-L21
Quad-Core Intel® Xeon® Processor E5405 (2.00 GHz, 80 Watts, 1333 FSB)
DL380 FIO Kit
458579-L21
QuickSpecs
HP ProLiant DL380 Generation 5
Configuration Information - Factory Integrated Models
DA - 12477 Worldwide QuickSpecs — Version 32 — 1.22.2008 Page 16

Quad-Core Intel® Xeon® Processor X5365 (3.0 GHz, 120 Watts, 1333 FSB)
DL380 FIO Kit
445560-L21
Quad-Core Intel® Xeon® Processor L5335 (2.0 GHz, 50 Watts, 1333 FSB)
DL380 FIO Kit
452640-L21
Quad-Core Intel® Xeon® Processor X5355 (2.66 GHz , 120 Watts, 1333 FSB)
DL380 G5 FIO Kit
437939-L21
Quad-Core Intel® Xeon® Processor E5345 (2.33 GHz, 80 Watts, 1333 FSB)
DL380 G5 FIO Kit
437940-L21
Quad-Core Intel® Xeon® Processor E5335 (2.00 GHz, 80 Watts, 1333 FSB)
DL380 G5 FIO Kit
437941-L21
Quad-Core Intel® Xeon® Processor E5320 (1.86 GHz, 80 Watts, 1066 FSB)
DL380 G5 FIO Kit
433522-L21
Quad-Core Intel® Xeon® Processor L5320 (1.86 GHz, 50 Watts, 1066 FSB)
DL380 G5 FIO Kit
435934-L21
Quad-Core Intel® Xeon® Processor E5310 (1.60 GHz, 80 Watts, 1066 FSB)
DL380 G5 FIO Kit
437943-L21
Dual-Core Intel® Xeon® Processor X5260 (3.33 GHz, 80 Watts, 1333 FSB)
DL380 FIO Kit
461461-L21
Dual-Core Intel® Xeon® Processor E5205 (1.86 GHz, 65 Watts, 1066 FSB)
DL380 FIO Kit
461465-L21
Dual-Core Intel® Xeon® Processor 5160 (3.0 GHz, 80 Watts, 1333 FSB) DL380
G5 FIO Kit
418324-L21
Dual-Core Intel® Xeon® Processor 5150 (2.66 GHz, 65 Watts, 1333 FSB)
DL380 G5 FIO Kit
418323-L21
Dual-Core Intel® Xeon® Processor 5148 (2.33 GHz, 40 Watts, 1333 FSB, Low
Voltage) DL380 G5 FIO Kit
432333-L21
Dual-Core Intel® Xeon® Processor 5140 (2.33 GHz, 65 Watts, 1333 FSB)
DL380 G5 FIO Kit
418322-L21
Dual-Core Intel® Xeon® Processor 5130 (2.0 GHz, 65 Watts, 1333 FSB) DL380
G5 FIO Kit
418321-L21
Dual-Core Intel® Xeon® Processor 5120 (1.86 GHz, 65 Watts, 1066 FSB)
DL380 G5 FIO Kit
418320-L21
Dual-Core Intel® Xeon® Processor 5110 (1.6 GHz, 65 Watts, 1066 FSB) DL380
G5 FIO Kit
418319-L21
Base Memory 1 GB FBD PC2-5300 2 x 512 MB Kit 397409-B21
2 GB FBD PC2-5300 2 x 1 GB Kit 397411-B21
2 GB FBD PC2-5300 2 x 1 GB LP Kit 461826-B21
4 GB FBD PC2-5300 2 x 2 GB Kit 397413-B21
4 GB FBD PC2-5300 2 x 2 GB LP Kit 461828-B21
8 GB FBD PC2-5300 2 x 4 GB Kit 397415-B21
8 GB FBD PC2-5300 2 x 4 GB LP Kit 466440-B21
NOTE: Memory Option Kits described as LP include Low Power DIMMs. For
more information on ProLiant Energy Efficient Features, please visit:
http://h18004.www1.hp.com/products/servers/platforms/energyefficient/
QuickSpecs
HP ProLiant DL380 Generation 5
Configuration Information - Factory Integrated Models
DA - 12477 Worldwide QuickSpecs — Version 32 — 1.22.2008 Page 17

Step 3: Choose Additional Factory Integratable Options
Performance Packs The HP ProLiant DL380 G5 performance packs are necessary to configure a HP ProLiant DL380
G5 Performance Model. HP ProLiant DL380 G5 Performance model includes the latest
performance technologies and enterprise class availability features pre-installed for convenience
and value. The performance pack includes a 2nd processor and a redundant power supply.
NOTE: Must also select Slimline CD-RW/DVD-ROM Combo Option Kit (331903-B21) to achieve
parity to DL380 G5 High Performance Models.
HP DL380G5 X5460 HPM FIO Perf Pack 458588-B21
HP DL380G5 X5450 HPM FIO Perf Pack 458589-B21
HP DL380G5 E5345 HPM FIO Perf Pack 433559-B21
HP DL380G5 X5160 HPM FIO Perf Pack 419812-B21
HP DL380G5 X5150 HPM FIO Perf Pack 419811-B21
Step 4: Choose Additional Options for Factory Integration
NOTE: For additional options, please refer to the "Options" section below.
QuickSpecs
HP ProLiant DL380 Generation 5
Configuration Information - Factory Integrated Models
DA - 12477 Worldwide QuickSpecs — Version 32 — 1.22.2008 Page 18

NOTE: Some options may not be integrated at the factory. Contact your local sales representative for additional information.
HP ProLiant DL380 G5
Unique Options
Mixed Riser Cage Option Kit (PCI-E/PCI-X) 410570-B21
HP Insight Control
Management Suites
NOTE: Electronic licensing options are available for Insight Control suites
software products. Please see the appropriate Insight Control QuickSpecs for
additional information.
HP Insight Control Environment
HP Insight Control Environment, No Media 1-Server License including 1 year of
24x7 Technical Support and Updates
452148-B21
HP Insight Control Management Software Media Kit
NOTE: Insight Control Management DVD media without licenses. Contains
Insight Manager and Essentials software products and components licensed by
Insight Control Management suites. Uses an integrated installer to perform quick
and accurate software installation and updates.
436222-B21
NOTE: For additional License Kits, please see the QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/12631_div/12631_div.html
Integrated Lights-Out Power Management Pack
HP iLO Power Management Pack, No Media, 1-Server License, including 1 year
of 24x7 Technical Support and Updates
NOTE: This option kit includes 1 license for iLO Advanced and Insight Power
Manager.
452145-B21
NOTE: For additional License Kits, please see the QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/12632_div/12632_div.html
Server Management
Stand Alone Software
NOTE: Electronic licensing options are available for select ProLiant Essentials
software products. Please see the appropriate ProLiant Essentials QuickSpecs
for additional information.
Deploy
ProLiant Essentials Rapid Deployment Pack
ProLiant Essentials Rapid Deployment Pack No Media 1-Server License
including 1 year of 24x7 Technical Support and Updates
NOTE: This license allows 1 server to be deployed and managed via RDP.
Customer will receive a printed license entitlement certificate via physical
shipment. The license entitlement certificate must be redeemed online or via fax
in order to obtain the license activation key(s). Includes one year of 24 x 7 HP
Software Technical Support Service
NOTE: For additional License Kits, please see the QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/11053_div/11053_div.html
452151-B21
HP Server Migration Pack - Universal Edition
HP Server Migration Pack - Universal Edition, No Media, Physical / Virtual to
ProLiant Single Migration License, including 1 year of 24x7 Technical Support
and Updates
NOTE: This license allows 1 physical to ProLiant or virtual to ProLiant migration.
Customer will receive a printed license entitlement certificate and documentation
via physical shipment. The license entitlement certificate must be redeemed
online or via fax in order to obtain the license activation key(s). Includes one
year of 24 x 7 HP Software Technical Support and Update Service.
460750-B21
HP Server Migration Pack - Universal Edition, No Media, Physical / Virtual to
Virtual Single Migration License, including 1 year of 24x7 Technical Support and
Updates
NOTE: This license allows 1 physical to virtual or virtual to virtual migration.
Customer will receive a printed license entitlement certificate and documentation
via physical shipment. The license entitlement certificate must be redeemed
460753-B21
QuickSpecs
HP ProLiant DL380 Generation 5
Options
DA - 12477 Worldwide QuickSpecs — Version 32 — 1.22.2008 Page 19

online or via fax in order to obtain the license activation key(s). Includes one
year of 24 x 7 HP Software Technical Support and Update Service.
HP Server Migration Pack - Universal Edition, No Media, 1-Year Unlimited
Migration License, including 1 year of 24x7 Technical Support
NOTE: This license allows unlimited migrations (physical to ProLiant, physical to
virtual, virtual to virtual, and virtual to ProLiant) for one year. Customer will
receive a printed license entitlement certificate and documentation via physical
shipment. The license entitlement certificate must be redeemed online or via fax
in order to obtain the license activation key(s). Includes one year of 24 x 7 HP
Software Technical Support Service.
460756-B21
NOTE: For additional License Kits, please see the QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/12855_div/12855_div.html
Control
Integrated Lights-Out Select Pack
ProLiant Essentials Integrated Lights-Out Select Pack, No Media, 1-Server
License
NOTE: For additional License Kits, please see the QuickSpecs at :
http://h18000.www1.hp.com/products/quickspecs/12362_div/12362_div.html
452158-B21
Integrated Lights-Out Advanced Pack
Integrated Lights-Out Advanced Pack, No Media ,1 Server License
NOTE: For additional License Kits, please see the QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/10861_div/10861_div.html
452141-B21
Optimize
Accelerated iSCSI Pack
ProLiant Essentials Accelerated iSCSI Pack, No Media, Single License
NOTE: For use with a single NIC port. Contains one license with a unique
license activation key and documentation.
452679-B21
NOTE: For additional License Kits, please see the QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/12466_div/12466_div.html
HP Insight Power Manager (IPM)
HP Insight Power Manager, No Media, 1-Server License, including 1 year of
24x7 Technical Support and Updates
NOTE: Customers purchasing this upgrade must already have an iLO Advanced
or Select license on each managed server. Customer will receive a printed
license entitlement certificate via physical shipment. The license entitlement
certificate must be redeemed online or via fax in order to obtain the license
activation key(s). Includes one year of 24 x 7 HP Software Technical Support
and Update Service.
NOTE: For additional License Kits, please see the QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/12623_div/12623_div.html
452677-B21
ProLiant Essentials Virtual Machine Management Pack
ProLiant Essentials Virtual Machine Management Pack, No Media, 1-Server
License, including 1 year of 24x7 Technical Support and Updates
NOTE: Customer will receive a printed license entitlement certificate via physical
shipment. The license entitlement certificate must be redeemed online or via fax
in order to obtain the license activation key(s). Includes one year of 24 x 7 HP
Software Technical Support and Update Service.
NOTE: For additional License Kits, please see the QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/12328_div/12328_div.html
452153-B21
RDMA Pack
RDMA Pack for Embedded Multifunction Gigabit Server Adapters, No Media, 1-
Server License
NOTE: For additional License Kits, please see the QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/12573_div/12573_div.html
452681-B21
QuickSpecs
HP ProLiant DL380 Generation 5
Options
DA - 12477 Worldwide QuickSpecs — Version 32 — 1.22.2008 Page 20
