HP rp7400 User manual

rp7400 Hardware Manual

2
Notice
© Copyright 2002-2010 Hewlett-Packard Development Company
Hewlett-Packard makes no warranty of any kind with regard to this material,
including but not limited to, the implied warranties of merchantability and fitness
for a particular purpose. Hewlett-Packard shall not be liable for errors contained herein or
for incidental or consequential damages in connection with the furnishing, performance, or
use of this material.
Hewlett-Packard assumes no responsibility for the use or reliability of its software on
equipment that is not furnished by Hewlett-Packard.
All rights are reserved. No part of this document may be photographed, reproduced, or
translated to another language without prior written consent of Hewlett-Packard Company.
The information contained in this document is subject to change without notice.
HP welcomes your feedback. To make comments and suggestions about product documentation,
send a message to [email protected].
Include the document title and manufacturing part number. All submissions become the property of HP.

What’s New?
3
What’s New?
Visit this page to find out what new information has been released since the last web site publish (August,
2001) and CD-ROM on August, 2001. The additions and modifications to the web site listed here are effective
as of March, 2010.
New Sections On the Web Site:
• System upgrade instructions for the PA8700 upgrade.
Modified Sections On the Web Site:
• Identified changes to all sections as applicable to HP e3000.
The current version of the Customer CD-ROM was released August, 2002.
The web site will be identical to the CD-ROM on September, 2002.
NOTE All references to rp74xx are equally applicable to the HP e3000.

What’s New?
4

5
System Overview
The following sections provide or point to an overview of the rp7400 server hardware and software.
Hardware overview
For an overview of the Enterprise Server Family hardware go to http://www.hp.com/go/hp9000_servers-docs
For an overview of the HP-9000 or HP e3000 rp7400 Server hardware go to http://www.hp.com/go/hp9000_servers-docs
Software Overview
The HP-9000 rp7400 server is designed to operate using HP-UX version 11.0 or newer.
The HP e3000 rp7400 is designed to operate using MPE/iX release 7.0 (uni-processor support) and MPE/iX
release 7.0 express (multi-processor support).
NOTE All references to rp7400 are equally applicable to the HP e3000 and n4000.
KEY:
X - Supported with MPE/iX 7.0
X* - Supported with MPE/iX 7.0 Express 1 Release
X1 - Supported with MPE/iX 7.5 or later
NOTE 1 and 2 way 550 MHz and 750MHz servers are not supported.
Table 1
Processor
Speed Number of Processors Supported
220MHz1234567
330MHz X
380MHz X
440MHz X1 X1
500MHz X* X* X* X*
550MHz X* X*
750MHz X1 X1

System Overview
6

rp7400 Enterprise Server System Safety and Regulatory Information
7
rp7400 Enterprise Server System Safety and Regulatory Information
Overview
Regulatory Compliance statements are required by some countries for international importation of rp7400
Enterprise Servers. The following information is provided:
Regulatory Information
Electrical Safety
— Electrostatic Discharge (ESD) Precautions
— Battery Notice
Cabinet Safety Precautions
Declaration of Conformity
FCC Statement (USA Only)
Canada RFI Statement
European Union RFI Statement
Korean RFI Statement
Taiwan RFI Statement
Japan Safety and Regulatory Statements
Acoustics (Germany)
Australian C-Tick Label
Laser Safety
Product Information
For detailed information on the rp7400 Enterprise Server product, see the following web site:
http://www.hp.com/go/hp9000_servers-docs (in the Systems Hardware selection).

rp7400 Enterprise Server System Safety and Regulatory Information
8
Regulatory Information
For your protection, this product has been tested for conformance to various national and international
regulations and standards. The scope of this regulatory testing includes electrical and mechanical safety,
electromagnetic emissions, immunity, acoustics and hazardous materials.
When required, approvals are obtained from third party test agencies. Approval marks appear on the product
label. In addition, various regulatory bodies require some information under the headings listed in this
section.
Electrical Safety
This product has not been evaluated for connection to an “IT” power system (AC distribution system having
no direct connection to earth according to IEC 950).
Locate the AC outlet near the computer! The AC power cords are this product's main AC disconnect devices
and must be easily accessible at all times.
Electrostatic Discharge (ESD) Precautions
When handling any electronic component or assembly (such as, a PCI card or Memory SIMM), you must
observe the following antistatic precautions to prevent damage. An ESD kit (HP P/N A3024-80004) is
available (or supplied with Memory additions). This kit contains one wrist strap, one conductive sheet, and
one anti-static foam pad.
• Always wear a grounded wrist strap when working around the system, and when handling printed circuit
boards.
• Treat all assemblies, components and interface connections as static-sensitive.
• Avoid working in carpeted areas, and keep body movement to a minimum while removing or installing
boards, to minimize buildup of static charge.
Battery Notice
This product contains a Lithium battery.
This battery is not to be removed or replaced by the user. If the battery needs to be replaced, contact your
Hewlett-Packard authorized service personnel.
CAUTION Lithium batteries may explode if mistreated.
Do not recharge, disassemble, or dispose of in a fire.
Please properly recycle all used batteries.

rp7400 Enterprise Server System Safety and Regulatory Information
9
Cabinet Safety Precautions
WARNING Cabinets are heavy even when empty. Exercise caution when moving cabinets
whether equipment is installed in the cabinet or not. Avoid rolling cabinets on rough
or uneven surfaces or inclines greater than 10 degrees. Unloading cabinets from the
pallet and movement of cabinets should be performed by at least two people.
WARNING Slideable products are not to be extended from the cabinet while the equipment is
on the shipping pallet. The cabinet must be unloaded from the pallet and both front
and rear anti-tip feet properly installed prior to extending any slideable product.
WARNING Once installed, both the front and rear anti-tip feet must remain in place to maintain
stability. Only one slideable product must be extended at a time.
Sicherheitsvorkehrungen für Einbaugehäuse
WARNING Einbaugehäuse haben auch ohne Inhalt ein hohes Gewicht. Seien Sie also vorsichtig,
wenn Sie ein Gehäuse hin und her bewegen, sei es mit oder ohne installierten
Innenteilen. Rollen Sie das Gehäuse nach Möglichkeit nicht über rauhe oder
unebene Oberflächen bzw. Oberflächen mit mehr als 10 Grad Neigung. Das Abladen
von der Palette und Positionieren muß von mindestens zwei Personen durchgeführt
werden.
WARNING Ziehen Sie keine beweglichen Teile heraus, solange sich das Einbaugehäuse auf der
Palette befindet. Laden Sie es zunächst von der Palette ab, und stellen Sie es mit den
kippsicheren Vorder-und Hinterfüßen ordnungsgemäß auf, um bewegliche Teile
sicher herausziehen zu können.
WARNING Nach deren Installation dürfen die kippsicheren Füße nicht wieder entfernt werden,
um sicheren Stand zu gewährleisten. Ziehen Sie jeweils nur ein bewegliches Teil
heraus.

rp7400 Enterprise Server System Safety and Regulatory Information
10
Consignes de sécurité relatives aux armoires
WARNING Une armoire est lourde même lorsqu’elle est vide. Faites preuve de prudence lorsque
vous en déplacer une, peu importe si des éléments y sont installés ou non. Évitez de
faire rouler l’armoire sur un sol irrégulier ou incliné à plus de 10 degrés. Il faut au
moins deux personnes pour décharger une armoire de la palette d’expédition et la
déplacer.
WARNING Ne faites pas glisser les éléments coulissants hors de l’armoire alors qu’elle se trouve
sur la palette d’expédition. Vous devez d’abord décharger l’armoire de la palette et
installer correctement les pieds antibasculement, en avant et en arrière, avant de
faire glisser les éléments coulissants.
WARNING Lorsqu’ils sont installés, les pieds antibasculement situés à l’avant et à l’arrière
doivent tous deux rester en place pour assurer la stabilité de l'armoire. Vous ne
devez faire glisser hors de l’armoire qu’un seul élément coulissant à la fois.
Medidas de seguridad para armarios
WARNING Los armarios son pesados aun cuando estén vacíos. Tenga cuidado cuando mueva los
armarios independientemente de que haya equipo instalado en el armario o no.
Evite desplazar los armarios sobre superficies rugosas o disparejas o pendientes de
más de 10 grados. Dos personas, como mínimo, tienen que realizar la descarga de los
armarios de la plataforma de carga y mover los armarios.
WARNING Los productos deslizables no deben extenderse del armario cuando el equipo se
encuentre en la plataforma de carga. Se debe descargar el armario de la plataforma
e instalar bien las punteras delanteras y traseras de protección antes de extender
cualquier producto deslizable.
WARNING Una vez instalado, se deberán dejar puestas las punteras de protección, delanteras y
traseras, para mantener la estabilidad. Se deberá extender un solo producto
deslizable cada vez.

rp7400 Enterprise Server System Safety and Regulatory Information
11
Procedimentos de Segurança - Armários
WARNING Os armários são pesados, mesmo quando vazios. Tenha cuidado ao movimentar os
armários, quer haja equipamentos instalados quer não. Evite deslizar os armários
sobre superficies acidentadas, irregulares ou com inclinação superior a 10 graus. A
retirada dos armários do palete e sua movimentação deverão ser feitas por, no
mínimo, duas pessoas.
WARNING Partes deslizantes não deverão ser abertas enquanto o armário encontrar-se no
palete de embarque. O armário deve ser descarregado do palete e os anteparos nos
pés dianteiros e traseiros devem ser instalados adequadamente antes de se abrir
qualquer parte deslizante.
WARNING Uma vez instalados, tanto os anteparos nos pés dianteiros quanto nos traseiros
devem permanecer em seus lugares adequados para garantir a estabilidade da peça.
Deve-se abrir apenas uma parte deslizante por vez.
Precauzioni di siccurezza sugli armadi
WARNING Gli armadi sono molto pesanti anche quando sono vuoti. Esercitare la massima
cautela durante lo spostamento degli armadi indipendentemente dal fatto che
l'apparecchiatura sia installata o meno. Evitare di far scorrere gli armadi su
superfici irregolari, disagevoli o con un’inclinazione superiore ai 10 gradi. Servirsi
di almeno due persone sia per scaricare che per spostare gli armadi dal pallet.
WARNING Non aprire o estendere gli elementi scorrevoli dagli armadi mentre
l'apparecchiatura è sul pallet di trasporto. Prima di estendere o aprire un qualsiasi
elemento scorrevole è necessario aver scaricato gli armadi dai pallet ed aver
debitamente installato gli appositi piedini antiribaltamento anteriori e posteriori.
WARNING Non smontare i piedini antiribaltamento dopo l’installazione perché stabilizzano gli
armadi. Estendere o aprire soltanto un prodotto scorrevole per volta.

rp7400 Enterprise Server System Safety and Regulatory Information
12
Säkerhetsföreskrifter för kabinett
WARNING Kabinetten är tunga även när de är tomma. Var försiktig när du flyttar ett kabinett,
oavsett om det är tomt eller innehåller utrustning. Undvik att rulla kabinett på ett
underlag som är ojämnt eller lutar mer än 10 grader. Det krävs minst två personer
för att lasta av ett kabinett från transportpallen eller för att flytta det.
WARNING Inskjutningsbara produkter får inte vara utdragna när utrustningen befinner sig på
transportpallen. Kabinettet måste lastas av från pallen och tippskyddsfötter ska
monteras både fram- och baktill innan en inskjutningsbar produkt dras ut.
WARNING Efter montering ska tippskyddsfötterna sitta kvar både fram- och baktill så att
stabiliteten upprätthålls. De inskjutningsbara produkterna får bara dras ut en i
sänder.
Voorzorgsmaatregelen voor de veiligheid voor kasten
WARNING Kasten zijn zwaar, ook als deze leeg zijn. Ga voorzichtig te werk als u een kast
verplaatst, of er nu wel of niet apparatuur in de kast is geïnstalleerd. Rol kasten niet
over ruwe of ongelijke oppervlakken of hellingen van meer dan 10 graden. Als u een
kast van een pallet moet afhalen of moet verplaatsen, doet u dat dan altijd met twee
personen.
WARNING Zorg ervoor dat er geen uitschuifbare onderdelen uit de kast uitsteken als de
apparatuur ter verzending op een pallet is geplaatst. Voordat u een uitschuifbaar
onderdeel uitschuift, moet u de kast eerst van het pallet halen en de
stabilisatiesteunen aan de voor- en achterkant op de juiste manier installeren.
WARNING Zodra de kast is geïnstalleerd, mogen de stabilisatiesteunen niet meer worden
verplaatst. U mag niet meer dan één uitschuifbaar onderdeel tegelijk uitschuiven.

rp7400 Enterprise Server System Safety and Regulatory Information
13
Sikkerhedsforanstaltninger for skabe
WARNING Skabene er tunge, selv når de er tomme. Vær forsigtig når De flytter skabe, hvad
enten der er installeret udstyr i skabet eller ej. Undgå at rulle skabe på ru eller
ujævne overflader eller skråninger der hælder mere end 10 grader. Der skal mindst
to personer til at aflæsse skabe fra pallen og til at flytte skabe.
WARNING Udtræksdele må ikke være trukket ud, når skabet står på forsendelsespallen. Skabet
skal først læsses af pallen og anti-tip fødderne skal være installeret både forpå og
bagpå, før udtræksdelene må trækkes ud.
WARNING Efter installation skal både de forreste og bageste anti-tip fødder blive siddende for
at opretholde stabiliteten. Der må kun trækkes en udtræksdel ud ad gangen.
Sikkerhetsforanstaltninger for skapene
WARNING Skapene er tunge, selv når de er tomme. Vær forsiktig når du flytter skap, uansett
om de er tomme eller inneholder utstyr. Ikke rull skap på ru eller ujevne overflater
eller i skråninger som heller mer enn 10 grader. Det trengs minst to personer til
lessing av skap fra pallen og til flytting av skap.
WARNING Produkter som kan gli inn og ut av skapet bør ikke være trukket ut når skapet er på
transportpallen. Skabet må lesses av pallen og anti-tippe-føtter må være påmontert
både foran og bak før et produkt som kan gli inn og ut av skapet, trekkes ut.
WARNING Etter montering skal anti-tippe-føttene både foran og bak fortsatt være på for å
opprettholde stabilitet. Produkter som kan gli inn og ut av skapet, må kun trekkes
ut ett og ett om gangen.

rp7400 Enterprise Server System Safety and Regulatory Information
14
Laitekaappia koskeva turvavaroitus
WARNING Kaapit ovat tyhjinäkin painavia. Ole varovainen siirtäessäsi kaappia siitä
riippumatta, onko siihen asennettu laitteistoa. Älä rullaa kaappeja karkeilla tai
epätasaisilla pinnoilla tai jos pinnan kaltevuus ylittää 10 astetta. Kaappien
ottamiseen alas lastausalustalta ja niiden siirtämiseen tarvitaan ainakin kaksi
henkilöä.
WARNING Liukuvia osia ei pidä vetää ulos kaapista laitteen ollessa lastausalustalla. Kaappi
täytyy ottaa alas alustalta, ja sekä etummaisen että takimmaisen kallistustuen
täytyy olla asennettu ennen liukuvien osien vetämistä ulos.
WARNING Kun kallistustuet on asennettu, ne täytyy jättää paikoilleen sekä edessä että takana,
jotta kaappi pysyisi vakaasti paikoillaan. Vain yksi liukuosa saa olla ulkona
kerrallaan.

rp7400 Enterprise Server System Safety and Regulatory Information
15

rp7400 Enterprise Server System Safety and Regulatory Information
16

rp7400 Enterprise Server System Safety and Regulatory Information
17

rp7400 Enterprise Server System Safety and Regulatory Information
18
Declaration of Conformity

rp7400 Enterprise Server System Safety and Regulatory Information
19
FCC Statement (USA Only)
The United States Federal Communications Commission has specified that the following notice be brought to
the attention of users of this product:
NOTE This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
Hewlett-Packard's system verification tests were conducted with HP-supported peripheral devices and HP
shielded cables, such as those you receive with your computer. Changes or modifications not expressly
approved by Hewlett-Packard could void the user's authority to operate the equipment. Cables used with this
device must be properly shielded to comply with the requirements of the FCC.
Canada RFI Statement
This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment
Regulations.
Notice relative aux interférences radioélectriques (Canada)
Cet appareil numérique de la classe A respecte toutes les exigences du Règlement sur le matériel brouilleur
du Canada.
European Union RFI Statement
This is a Class A product. In a domestic environment, this product may cause radio interference in which case
the user may be required to take adequate measures.

rp7400 Enterprise Server System Safety and Regulatory Information
20
Korean RFI Statement
Taiwan RFI Statement
Japan Safety and Regulatory Statements
