1. WLAN antennas (2) * 12. AC adapter/Battery light
2. WWAN antennas (2) * 13. Power light
3. Internal microphone array (2) ** 14. Wireless light
4. Webcam light (select models only) 15. Smart Card Reader
5. Webcam (select models only) 16. Optical Drive (select models only)
6. Internal display switch 17. USB 2.0 port (1)
7. Wireless button 18. Secure Digital slot
8. Volume mute button 19. USB 2.0 charging port (1)
9. Touchpad buttons 20. RJ-45 (network) jack/lights
10. Touchpad zone 21. Power connector
11. Hard drive light 22. Power button
* The antennas are not visible from the outside of the computer. For optimal transmission, keep the areas immediately around the
antennas free from obstructions.
**Models without optional webcam have single integrated microphone on left side of display panel.
QuickSpecs
HP mt41 Mobile Thin Client
Overview
DA - 14782 Worldwide — Version 5 — November 19, 2013 Page 1

1. Audio-out (headphone) jack/Audio-in (microphone) jack 4. External VGA monitor port
2. USB 2.0 ports (2) 5. Vents (2)
3. DisplayPort 1.2 6. Security cable slot
1. Service cover 5 Service cover release lock
2. Battery release latch 6. Service door release latch
3. SIM card slot 7. Battery bay
4. Docking connector 8. Vents
QuickSpecs
HP mt41 Mobile Thin Client
Overview
DA - 14782 Worldwide — Version 5 — November 19, 2013 Page 2

At A Glance
Windows Embedded Standard 7e (WES7E 32-bit)
14.0-inch diagonal LED-backlit HD anti-glare display (1366 x 768)
Administrator control over read/write access to Solid State Drive and USB attached memory devices
Weight starting at 4.59 lb (2.08 kg)
16GB Solid State Drive for reliability, durability, and increased battery life
Full-sized spill-resistant keyboard with bottom-case drain, touchpad with scroll zone and gestures support, discrete buttons,
WLAN on/off, and mute)
Choice of primary battery to optimize run-time or weight: 9-cell (100 WHr) or 6-cell (55 WHr)
Easily hot dock with the optional HP docking station
HP Device Manager to track, configure, upgrade, clone and manage hundreds or thousands of thin clients
Improved Quality of Experience for End User using HP Velocity
HP Velocity intelligently reduces network packet loss and retransmissions providing a better experience for the end user
HP Velocity enables IT managers to monitor network activity and optimize end-user experience
Available only on HP thin clients
VGA and DisplayPort v1.2 for dual external-monitor support, including high-definition displays
Can support up to three monitors simultaneously when docked and if docking station has VGA and DisplayPort v.1.2
Flexible wireless connectivity options:
HP Connection Manager allows full control over wireless connections, including 3G and 4G mobile broadband,
Integrated 3G/4G HP Mobile Broadband Modules
Integrated 802.11 a/b/g/n wireless LAN module
Integrated Secure Digital slot (supports SD, SDHC, SDXC)
Optional integrated DVD-ROM drive
Optional webcam
QuickSpecs
HP mt41 Mobile Thin Client
Overview
DA - 14782 Worldwide — Version 5 — November 19, 2013 Page 3

OPERATING SYSTEM
Preinstalled Windows Embedded Standard 7e (WES7E 32-bit)
ACCELERATED PROCESSING UNIT
AMD Elite A4-5150M APU (2.7 GHz, 1 MB cache, 2 cores) with AMD Radeon™ HD 8350G Graphics *
AMD Elite A4-4300M APU (2.5 GHz, 1 MB cache, 2 cores) with AMD Radeon™ HD 7420G Graphics *
NOTE: AMD Radeon™ Dual Graphics requires an AMD "A" series APU plus an AMD Radeon™ discrete graphics configuration.
NOTE: With AMD Dynamic Switchable Graphics technology, full enablement of all discrete graphics video and display features may
not be supported on all systems (e.g. OpenGL applications will run on the integrated GPU or the APU as the case may be).
NOTE: Processor speed denotes maximum performance mode; processors will run at lower speeds in battery optimization mode.
*This system requires a separately purchased 64-bit operating system and 64-bit software products to take advantage of the 64-
bit processing capabilities of AMD technology. (language in red only used if the OS is not x64) Multi-core processing available with
AMD technology is designed to improve performance of this system. Given the wide range of software applications available,
performance of a system including a 64-bit operating system and a dual-core processor will vary. AMD's numbering is not a
measurement of clock speed.
FUSION CONTROLLER HUB (FCH)
AMD A76M FCH
GRAPHICS
Integrated graphics :
AMD A4-5150M Accelerated Processor with AMD Radeon™ HD 8350G Graphics
AMD A4-4300M Accelerated Processor with AMD Radeon™ HD 7420G Graphics
DISPLAY
Internal
14.0" diagonal LED-backlit HD 16:9 anti-glare (1366 x 768)
HP Privacy Filter support
External
Up to 32-bit per pixel color depth
DisplayPort v1.2
Supports resolutions up to 2560 x 1600, 30-bit color depth at 60 Hz, and full HD (1920 x 1080) monitors, 24-bit color depth at 120
Hz
VGA
Port supports resolutions up to 1920 x 1080 at 60Hz, and lower resolutions at up to 75 Hz
NOTE: Can support up to three monitors simultaneously when docked and if docking station has VGA and DisplayPort v.1.2
NOTE: Resolutions are dependent upon monitor capability, and resolution and color depth settings.
QuickSpecs
HP mt41 Mobile Thin Client
Features
DA - 14782 Worldwide — Version 5 — November 19, 2013 Page 4

STORAGE AND DRIVES
Solid State Drive
16 GB *
*For storage drives, GB = 1 billion bytes. Actual formatted capacity is less.
OPTICAL DRIVES (OPTIONAL)
Fixed 9.5 mm SATA optical drive
DVD-ROM Drive
MEMORY
Standard *
DDR3L PC3L-12800 (1600 MHz)
Two SODIMM slots supporting dual-channel memory
4 GB SODIMM
Maximum **
Upgradeable to 8192 MB with 4096 MB SODIMMs in slots 1 and 2
Dual-channel
Maximized dual-channel performance requires SODIMMs of the same size and speed in both memory slots.
*Graphics chipset uses part of the total system memory (RAM) for graphics performance. System memory dedicated to graphics
performance is not available for other use by other programs.
** Maximum memory capacities assume Windows 64-bit operating systems or Linux. With Windows 32-bit operating systems,
memory above 3 GB may not all be available due to system resource requirements.
NOTE: Due to the non-industry standard nature of some third-party memory modules, we recommend HP branded memory to
ensure compatibility. If you mix memory speeds, the system will perform at the lower memory speed.
NETWORKING/COMMUNICATIONS
Wireless
Support for a broad range of secure, integrated wireless LAN and wireless WAN options featuring support for the latest industry
standards. Broadband Wireless (WWAN) requires a Windows operating system and is available in select countries as a standard,
factory configurable feature only.
Broadband Wireless (WWAN) *
HP lt4111 LTE/EV-DO/HSPA+ Mobile Broadband Module (US, APJ) * , **
HP lt4112 LTE/HSPA+ Mobile Broadband Module (EMEA) * , **
Wireless LAN (WLAN)
Broadcom 802.11 a/b/g/n WiFi Adapter (2x2) ***
Atheros 802.11 b/g/n 1x1 (for Indonesia only)
Communications
Integrated Realtek RTL8151GH-CG 10/100/1000 Ethernet ****
* Mobile broadband is an optional or add-on feature and is not available in all regions. Mobile broadband use requires separately
QuickSpecs
HP mt41 Mobile Thin Client
Features
DA - 14782 Worldwide — Version 5 — November 19, 2013 Page 5

purchased service contract. Check with service provider for coverage and availability in your area. Connection speeds will vary due
to location, environment, network conditions, and other factors.
** 4G LTE not available on all products, or in all regions.
***802.11 a/b/g/n/ requires separately purchased wireless access point and internet service. Availability of public wireless access
points limited.
****The term "10/100/1000" or "Gigabit" Ethernet indicates compatibility with IEEE standard 802.3ab for Gigabit Ethernet, and
does not denote actual operating speed of 1 Gb/s. For high-speed transmission, connection to a Gigabit Ethernet server and
network infrastructure is required.
AUDIO/MULTIMEDIA
Audio
Integrated stereo speakers
Integrated microphone (dual-microphone array when equipped with optional webcam)
Button for volume mute; function keys for volume up and down
Stereo headphone/line out
Stereo microphone/line in
Webcam
Optional 720p HD webcam *
*Optional webcam sold separately or as an add on feature. Internet access required.
HD format (widescreen)
Supports videoconferencing and still image capture
High quality fixed focus lens
Video capture at various resolutions up to 1280x720 resolution (720p) and up to 30fps
M-JPEG compression supports higher frame rates for video capture and videoconferencing
Improved low light sensitivity
Improved dynamic range
KEYBOARDS/POINTING DEVICES/BUTTONS & FUNCTION KEYS
Keyboard
The HP spill-resistant keyboard is designed using a thin layer of Mylar film under the keyboard and a drain system that funnels
fluid through a hole in the bottom of the notebook. This minimizes the risk of damage to sensitive components underneath. The
101/102-key compatible keyboard features an industry standard, full-pitch key layout with desktop keyboard features, such as
linear cursor control keys, editing keys, both left and right control and alt keys, and 12 function keys. U.S. and International key
layouts are available. Other features include an integrated numeric keypad, brightness, and other features, 19 mm x 19 mm key
pitch (center-to-center spacing), 2.0 mm stroke, and comfort-dished keycaps.
Pointing Devices
Touchpad with on/off button, two-way scroll, gestures, two pick buttons
Buttons and Function Keys
Discrete buttons provide easy access to the following features: wireless on/off, and volume mute. Function keys provide control
of the following features: standby mode, external display, volume down, volume up, mic mute, and display brightness.
QuickSpecs
HP mt41 Mobile Thin Client
Features
DA - 14782 Worldwide — Version 5 — November 19, 2013 Page 6

SOFTWARE AND SECURITY
Preinstalled Software with Windows Embedded Standard 7 (WES7E 32-bit)
HP Device Manager
HP Velocity
Standard Security
Security lock slot
TPM 1.2
Integrated Smart Card reader
Preboot Authentication
Optional Security
HP Combo Lock *
* Optional feature sold separately or as an add-on feature.For more information on HP security solutions refer to:
http://www.hp.com/go/security
POWER
Power Supply
External 65W HP Smart AC Adapter
Power cord included is 6-foot (1.8 meter)
Total length including external AC adapter is 12 feet (3.66 meter)
Primary Battery
HP 6-cell Lithium-Ion Battery (55 WHr)
HP 9-cell Lithium-Ion Battery (100 WHr) (optional)
Battery Life *
9-cell (100 WHr) Up to 14 hours 39 minutes
6-cell (55 WHr) Up to 8 hours 39 minutes
System Standby Time
Up to TBD weeks
*Battery life will vary depending on the product model, configuration, loaded applications, features, use, wireless functionality
and power management settings. The maximum capacity of the battery will naturally decrease with time and usage. See
MobileMark07 battery benchmark http://www.bapco.com/products/mobilemark2007 for additional details.
Power Conservation
Standby
QuickSpecs
HP mt41 Mobile Thin Client
Features
DA - 14782 Worldwide — Version 5 — November 19, 2013 Page 7

ENVIRONMENTAL
ENERGY STAR *
IT ECO Declaration
EPEAT<Gold registered in the United States. See http://www.epeat.net for registration status in your country.
Low Halogen **
*Configurations that are ENERGY STAR qualified are identified on HP websites and on www.energystar.gov.
** External power supplies, power cords, cables and peripherals are not Low Halogen. Service parts obtained after purchase may
not be Low Halogen.
NOTE: This product has received or is in the process of being certified to the following approvals and may be labeled with one or
more of these marks.
WEIGHTS & DIMENSIONS
Weight
Starting at 4.59 lbs. (2.08 kg)
Dimensions (w x d x h)
13.39 x 9.33 1.14 in (at front) / 34 x 23.7 x 2.9 cm (at front)
NOTE: Height varies depending upon where on the notebook the measurement is made. Weight varies by configuration and
components.
PORTS/SLOTS
Ports
VGA - One
DisplayPort - One (v1.2)
Headphone/Microphone (combo jack) - One
Power Connector - One
Docking Connector - One
RJ-45 (Ethernet) - One
USB 2.0- Three
USB 2.0 charging - One
Digital Media Slots
1 Secure Digital slot (SD/SDHC/SDXC)
QuickSpecs
HP mt41 Mobile Thin Client
Features
DA - 14782 Worldwide — Version 5 — November 19, 2013 Page 8

SERVICE AND SUPPORT
HP Services offers limited 3-year warranty. 1-year limited warranty on primary battery.
1-year limited warranty on primary battery. On-site service and warranty upgrades are also available. Optional * HP Care Pack
Services ** are extended service contracts which go beyond your standard warranties. For more details visit:
http://www.hp.com/go/lookuptool .
*Sold separately or as an optional feature.
** Service levels and response times for HP Care Packs may vary depending on your geographic location. Service starts on date of
hardware purchase. Restrictions and limitations apply. Consult the HP Customer Support Center for details.
http://h20000.www2.hp.com/bizsupport/TechSupport/ProductRoot.jsp
For details, visit: www.hp.com/go/cpc
QuickSpecs
HP mt41 Mobile Thin Client
Features
DA - 14782 Worldwide — Version 5 — November 19, 2013 Page 9

SYSTEM UNIT
Stand-Alone Power
Requirements (AC Power)
Nominal Operating
Voltage
19.52V
Average Operating Power 14.05W
Max Operating Power < 65 W
Temperature Operating 32° to 95° F (0° to 35° C) (not writing optical)
41° to 95° F (5° to 35° C) (writing optical)
Non-operating -4° to 140° F (-20° to 60° C)
Relative Humidity Operating 10% to 90%, non-condensing
Non-operating 5% to 95%, 101.6° F (38.7° C) maximum wet bulb temperature
Shock Operating 40 G, 2 ms, half-sine
Non-operating 200 G, 2 ms, half-sine
Random Vibration Operating 0.75 grms
Non-operating 1.50 grms
Altitude (unpressurized) Operating -50 to 10,000 ft (-15.24 to 3,048 m)
Non-operating -50 to 40,000 ft (-15.24 to 12,192 m)
Planned Industry
Standard
Certifications
UL Yes
CSA Yes
508 Compliance (test and
document)
Yes
ENERGY STAR® Select models *
EPEAT Registered Gold in the United States **
Low halogen(does not
cover adapters and power
cords)
Yes
Acoustics Performance
Summary (requires ISO
7779)
Yes
Environmental Data
Sheet (EDS)
Yes
ISO 9241/9995
(keyboard ergonomics)
Yes
IT ECO declaration Yes
CA AB 1125 Rechargeable
Battery Recycling Act of
2006
Yes
TAA (FAR 52.255-5) Yes
GS Mark (EMEA) Yes
China CECP & SEPA (China) Yes
QuickSpecs
HP mt41 Mobile Thin Client
Technical Specifications
DA - 14782 Worldwide — Version 5 — November 19, 2013 Page 10

China Minimum Efficiency
and Labeling
Requirements
Yes
E-Standby (Korea) Yes
Made in Japan Yes (Only applies to Japan RCTO units)
Taiwan Green Mark
(Taiwan)
Yes
* Configurations of the HP mt41 Mobile Thin Client that are ENERGY STAR qualified are identified as HP mt41 Mobile Thin Client
ENERGY STAR on HP websites and on www.energystar.gov .
** EPEAT registration varies by country. See www.epeat.net for registration status by country.
EPEAT status listed above applies to U.S.
For accessibility information on HP products, please visit: http://www.hp.com/accessibility .
DISPLAY
14.0-inch LED HD
(1366 x 768)
anti-glare
Dimensions (W x H) 12.74 x 7.56 in (32.4 x 19.2 cm)
Diagonal Size 14.0 in (35.6cm)
Surface Treatment Anti-glare
Contrast Ratio 400:1 (typical)
Refresh Rate 60 Hz
Brightness 200 nit (typical)
Pixel Resolution Pitch 0.227 mm
Format 1366 x 768
Configuration RGB Stripe
Backlight LED
PPI 112 ppi
Viewing Angle ±30° Horizontal, ±10° Vertical (minimum)
30/30/20/10 (Left/Right/Down/Up) (minimum) or
45/45/35/25 (Left/Right/Down/Up) (typical)
STORAGE AND DRIVES
Internal Storage
QuickSpecs
HP mt41 Mobile Thin Client
Technical Specifications
DA - 14782 Worldwide — Version 5 — November 19, 2013 Page 11

16-GB Solid State Drive
(SSD)
Drive Weight 3.4 grams
Capacity 16 GB (unformatted)
Height 100.5 mm
Width 70 mm
Interface SATA 6 GB/s
Performance Maximum Sequential
Read
Maximum Sequential Write
Up to 450 MB/s Up to 350 MB/s
Logical Blocks 31,277,232
Operating Temperature 32° to 158°F (0° to 70°C) [case temp]
Features ATA Command Set ACS-2
NCQ support up to queue depth = 32
Advanced Flash Management:
nCache™ - Non Volatile Write Cache
Support for TRIM
Dynamic & Static Wear-leveling
Bad Block Management
Background Garbage Collection
Support for Performance throttling and Power Classes
Optical Drives
DVD-ROM Drive (optional) Access Times Random < 140 ms CD (typical)
< 160 ms DVD (typical)
Max Data Transfer Rate 24X CD-ROM
8X-DVD
Transfer Mode UDMA Mode 5
Interface Gen 1 SATA
Supported Media (read) CD-DA, CD-TEXT, CD-ROM, CD-ROM XA, MIXED MODE CD, CD-I, CD-I Bridge
(Photo-CD, Video CD), Multisession CD (Photo-CD, CD-EXTRA, Portfolio, CD-R,
CD-RW), CD-R, CD-RW, DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-R,
DVD-RW, DVD+R, DVD+RW, DVD-RAM
Supported Media (write) None
Max Media Capacity (read) 8.5GB
Transport Tray Loading
NETWORKING/COMMUNICATIONS
QuickSpecs
HP mt41 Mobile Thin Client
Technical Specifications
DA - 14782 Worldwide — Version 5 — November 19, 2013 Page 12

Integrated Realtek
RTL8151GH-CG
10/100/1000 NIC
Ethernet Features 10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-14)
100 Mbit/s operation (100BASE-TX; IEEE 802.3u; IEEE 802.3 clauses 21-30)
1000 Mbit/s operation (1000BASE-T; IEEE 802.3ab; IEEE 8023 clauses 40)
Auto-Negotiation (Automatic Speed Selection)
Full Duplex Operation at all Speeds, Half Duplex operation at 10 and 100
Mbit/s
IEEE 802.1p QoS (Quality of Service) Support
IEEE 802.1q VLAN support
IEEE 802.3x Flow Control (IEEE 802.3 clauses 31-32; configurable)
IEEE 802.3az EEE (Energy Efficient Ethernet)
Jumbo Frame 9K
Auto MDI/MDIX Crossover cable detection
Power Management
Support
ACPI compliant - multiple power modes
Situation-sensitive features reduce power consumption
Advanced link down power saving for reducing link down power consumption
Performance
Features
TCP/IP/UDP Checksum Offload (configurable)
Protocol Offload (ARP & NS)
Large send offload and Giant send offload
Receiving Side Scaling
Manageability Wake-on-LAN from standby (Magic Packet and Microsoft Wake-Up Frame);
Wake-on-LAN from off (Magic Packet only)
PXE 2.1 Remote Boot
Statistics Gathering (SNMP MIB II, Ethernet-like MIB, Ethernet MIB (802.3x,
clause 30))
Comprehensive diagnostic and configuration software suite
Virtual Cable Doctor for Ethernet cable status
Interface PCI Express 1.1 x1 to fully support ASPM L0s/L1 and CLKREQ
NIC Device Driver Name Realtek PCIe GBE Ethernet Family Controller
HP lt4111 LTE/EV-
DO/HSPA+ 4G WWAN *
Technology/Operating
bands
LTE FDD all bands with diversity: 1900 MHz (Band II)
1
, 1700/2100MHz (Band IV
(AWS), 850 MHz (Band V), 700MHz (Band XIII), 700MHZ (Band XVII), 1900MHz G
Block (Band XXV)
WCDMA/HSDPA/HSUPA/HSPA+: all bands with diversity: 2100 MHz (Band I),
1900 MHz (Band II) , AWS 1700/2100MHz (Band IV), 850 MHz (Band V), 800
MHz (Band VIII)
GSM/GPRS/EDGE: 1900 MHz, 1800 MHz , 850 MHz , 900 MHz
CDMA: Cellular 800MHz (BC0), PCS 1900MHz (BC1)
Wireless protocol
standards
3GPP Release 8 LTE Specification
WCDMA R99, 3GPP Release 5, 6 and 7 UMTS Specification
EVDO Release 0 and Release A
Wireless parametric
standards
Complies with 3GPP specifications Release 8 for LTE
Maximum data rates LTE (Category 3): 100 Mbps (Download), 50Mbps (Upload)
DC-HSPA+: 42 Mbps (Download), 5.76 Mbps (Upload)
HSPA+: 21.6 Mbps (Download), 5.76 Mbps (Upload)
EDGE: 236.8 kbps (Download), 236.8 kbps (Upload)
GPRS: 85.6 kbps(Download), 85.6 kbps (Upload)
GPS Standalone GPS, A-GPS, GPS XTRA
QuickSpecs
HP mt41 Mobile Thin Client
Technical Specifications
DA - 14782 Worldwide — Version 5 — November 19, 2013 Page 13

GPS bands 1575.42 MHz (± 1.023 MHz), GLONASS 1596-1607MHz
Maximum output power LTE: +23 dBm (+/- 1 dBm)
WCDMA: +23 dBm (+/- 1 dBm)
GSM850/900, GMSK: +32dBm (+/- 1dBm)
GSM850/900, 8PSK: +27dBm (+/- 1dBm)
DCS1800 / PCS 1900, GMSK: +29dBm (+/- 1dBm)
DCS1800 / PCS 1900, 8PSK: +26dBm (+/- 1dBm)
CDMA: +24dBm (+/- 1dBm)
Maximum power
consumption
LTE: 1,200 mA (peak); <900 mA (average)
WCDMA: 1,100 mA (peak); <800 mA (average)
EGPRS: 2,500 mA (peak); <700 mA (average)
Power consumption,
sleep mode
2 mA
Power management USB selective suspend, Integrated notebook wireless button
Antenna type Dual high efficiency multi-band antennae with spatial diversity
Form Factor M.2, 3042-S3 Key B
Weight 6 g
Dimensions
(Length x Width x
Thickness)
42 mm × 30 mm × 2.3 mm
Voltage, Operating 3.135 V to 4.4 V (3.3 V +1.1V/-0.165V)
Temperature, operating
(from TIA/EIA/IS-98-D)
-13° to 140° F (-25° to 60° C)
Temperature, non-
operating, 96 hours (from
MIL-STD 202 Method 108)
-40° to 185° F (-40° to 85° C)
Humidity, non-operating 95% relative humidity for 48 hours @ 185° F (85° C) (non-condensing)
LED activity LED Off - Radio Off; Solid LED On - Radio On
1
1900 MHz (Band II) and 850 MHz (Band V) not supported at launch but support planned in a future
firmware update.
* 4G LTE not available on all products, in all regions. WWAN use requires separately purchased service
contract. Check with service provider for coverage and availability in your area. Connection speeds will
vary due to location, environment, network conditions, and other factors.
HP lt4112 LTE/HSPA+
Gobi 4G Module *
Technology/Operating
bands
LTE FDD all bands with diversity: 2100 MHz (Band I), 1900 MHz (Band II), 1800
MHz (Band III), 850 MHz (Band V), 2600 MHz (Band VII), 900 MHz (Band VIII),
700 MHz (Band XX, DD800)
WCDMA/HSDPA/HSUPA/HSPA+ all bands with diversity: 2100 MHz (Band I),
1900 MHz (Band II), 800 MHz (Band V), 900 MHz (Band VIII)
GSM/GPRS/EDGE: 1900 MHz (Band II), 1800 MHz (Band III), 850 MHz (Band V),
900 MHz (Band VIII)
Wireless protocol
standards
3GPP Release 8 LTE Specification
WCDMA R99, 3GPP Release 5, 6 and 7 UMTS Specification
Wireless parametric
standards
Complies with 3GPP specifications Release 8 for LTE
QuickSpecs
HP mt41 Mobile Thin Client
Technical Specifications
DA - 14782 Worldwide — Version 5 — November 19, 2013 Page 14

Maximum data rates LTE (Category 3): 100 Mbps (Download), 50Mbps (Upload)
DC-HSPA+: 42 Mbps (Download), 5.76 Mbps (Upload)
HSPA+: 21.6 Mbps (Download), 5.76 Mbps (Upload)
EDGE: 236.8 kbps (Download), 236.8 kbps (Upload)
GPRS: 85.6 kbps(Download), 85.6 kbps (Upload)
GPS Standalone
GPS bands 1575.42 MHz (± 1.023 MHz), GLONASS 1596-1607MHz
Maximum output power LTE: +23 dBm (+/- 2 dBm)
WCDMA: +23.5 dBm (+/- 1 dBm)
GPRS Band II, III: +29.5 dBm (+/- 1 dBm)
GPRS Band V, VIII: +32.5 dBm (+/- 1 dBm)
EGPRS Band II, III: +26.5 dBM (+/-1.5 dBm)
EGPRS Band V, VIII: +27.5 dBM (+/-1.5 dBm)
Maximum power
consumption
LTE: 1,200 mA (peak); <900 mA (average)
WCDMA: 1,100 mA (peak); <800 mA (average)
EGPRS: 2,800 mA (peak); <700 mA (average)
Power consumption,
sleep mode
3 mA
Power management USB selective suspend, Integrated notebook wireless button
Antenna type Dual high efficiency multi-band antennae with spatial diversity
Form Factor M.2, USB 2.0 interface
Weight 6 g
Dimensions
(Length x Width x
Thickness)
42 mm × 30 mm × 2.3 mm
Voltage, Operating 3.135 V to 4.4 V (3.3 V +1.1V/-0.165V)
Temperature, operating
(from TIA/EIA/IS-98-D)
14° to 131° F (-10° to 55° C)
Temperature, non-
operating, 96 hours (from
MIL-STD 202 Method 108)
-40° to 185° F (-40° to 85° C)
Humidity, non-operating 95% relative humidity for 48 hours @ 185° F (85° C) (non-condensing)
LED activity LED Off - Radio Off; Solid LED On - Radio On
* 4G LTE not available on all products, in all regions. WWAN use requires separately purchased service
contract. Check with service provider for coverage and availability in your area. Connection speeds will
vary due to location, environment, network conditions, and other factors.
Broadcom 802.11 a/b/g/n
WiFi Adapter (2x2)
Wireless LAN Standards IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
Interoperability Wi-Fi certified
Cisco Compatible Extensions Program compliant with Microsoft Windows 7,
Windows Vista and XP (details at: http://www.hp.com/go/notebooks/WLAN )
Frequency Band 2.4 GHz and 5 GHz
QuickSpecs
HP mt41 Mobile Thin Client
Technical Specifications
DA - 14782 Worldwide — Version 5 — November 19, 2013 Page 15

Data Rates 802.11b: 1, 2, 5.5, 11 Mbps
802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n: 6, 6.5, 9, 12, 13, 13.5, 18, 19.5, 24, 26, 27, 36, 39, 40.5, 48, 52, 54,
58.5, 65, 78, 81, 104, 108, 117, 121.5, 130, 135, 162, 216, 243, 270, 300 Mbps
Frequency Support 20 MHz: 2.4 GHz and 5 GHz bands
40 MHz: 2.4 GHz and 5 GHz bands
Modulation Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM, BPSK, QPSK, 16-QAM, 64-QAM
Security
1
Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated AES,
802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP-MSCHAPv2,
LEAP, EAP-FAST.
Support for Cisco Security Features (proven compatibility with Cisco Aironet
infrastructure products through the Cisco Compatible Extensions Program
Version 4) with Microsoft Windows Vista and XP only.
Sub-channels Multinational support with frequency bands and channels compliant to local
regulations.
Media Access Protocol CSMA/CA (Collision Avoidance) with ACK
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming IEEE 802.11 compliant roaming between access points
Output Power (for CCK)
2
17 dBm , nominal
Output Power (for OFDM;
power varies by data
rate)
2
15 dBm , nominal
Power Consumption Idle associated: 250 mW
Idle unassociated: 150 mW
Transmit/Receive 20 MHz channel: 2.0 W (max)
Transmit/Receive 40 MHz channel: 2.0 W (max)
Power Management ACPI compliant power management
802.11 compliant power saving mode
Receiver Sensitivity
3
270 Mbps: -61dBm, 54 Mbps: -72 dBm, 11 Mbps: -85 dBm , 1 Mbps: -92 dBm
Antenna Connections High efficiency dual band antenna with spatial diversity, mounted in the
display enclosure
Form Factor PCI-Express Half-MiniCard
Weight 0.013 lb (6 g)
Dimensions 0.19 x 1.06 x 1.18 in (4.75 x 26.8 x 30 mm)
Operating Voltage 3.3v +/- 10%
Temperature Operating
Non-operating
14° to 149° F (-10° to 65° C)
-40° to 176° F (-40° to 80° C)
Humidity Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
LED Activity LED Off - Radio OFF; Solid LED On - Radio ON
QuickSpecs
HP mt41 Mobile Thin Client
Technical Specifications
DA - 14782 Worldwide — Version 5 — November 19, 2013 Page 16

1. Check latest software/driver release for updates on supported security features.
2. Maximum output power may vary by country according to local regulations.
3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CCK modulation) and a packet
error rate of 10% for 802.11a/g (OFDM modulation).
4. WLAN supplier's client utility is required for Cisco Compatible Extensions support with Microsoft
Windows XP. WLAN may also be compatible with certain third-party software supplicants. WLAN supplier
IHV extensions required for Cisco Compatible Extensions support for Microsoft Windows Vista.
AUDIO/MULTIMEDIA
Audio HD Audio with DTS Sound+
Hardware Implementation IDT 92HD87 High Definition CODEC
Function Key Volume
Controls
Volume up, volume down
Mute Key Yes
Full Duplex Yes
Microphone In Stereo
Headphone/Line Out Stereo
Integrated Microphone Yes, dual digital microphone array when equipped with optional webcam
Audio Output Quality Frequency Response 20 Hz - 20 kHz
Signal to Noise Ratio >85 dB
Total Harmonic Distortion 0.01%
Noise Floor -110 dB
Play/Record Sampling
Rate (s)
8 kHz - 48kHz
DAC 16, 20 or 24-bit
ADC 16 or 20-bit
Integrated Stereo
Speakers
Power Rating 2 Watts
Impedance 4 ohms
POWER
QuickSpecs
HP mt41 Mobile Thin Client
Technical Specifications
DA - 14782 Worldwide — Version 5 — November 19, 2013 Page 17

HP 65W Smart AC Adapter Dimensions 4.17 x 1.85 x 1.1 in (10.6 x 4.7 x 2.8 cm)
Weight 0.62 lb (280 g)
Input 100 to 240 VAC
Input Efficiency 87% min at 115 VAC
Input frequency range 47 to 63 Hz
Input AC current 1.7 A at 90 VAC, 0.85 A at 180 VAC
Output Output power 65W
DC output 18.5V
Hold-up time 5 msec at 115 VAC input
Output current limit <11A, Over voltage protection- 29V max
automatic shutdown
Connector 3 pin/grounded, mates with interchangeable cords
Environmental Design Operating
temperature
32° to 104° F (0° to 40° C)
Non-operating (storage)
temperature
-4° to 149° F (-20° to 65° C)
Altitude 0 to 10,000 ft (0 to 3,048 m)
Humidity 20% to 80%
Storage Humidity 10% to 90%
EMI and Safety
Certifications
CE Mark - full compliance with LVD and EMC directives; Worldwide safety
standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals -
C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B,
CCC, NOM-1 NYCE; MTBF - over 200,000 hours at 25°C ambient condition.
HP 9-cell (100 WHr)
Lithium-Ion Primary
battery (optional)
Dimensions (H x W x L) 0.8 x 2.4 x 8.1in (2 x 6.6 x 20.5cm)
Weight 1.1lb, (.488kg)
Cells/Type Lithium-Ion
Energy Voltage 11.25V
Amp-hour capacity 8.85Ah
Watt-hour capacity 100Wh
Temperature Operating (Charging) 32° to 113° F (0° to 45° C)
Operating (Discharging) 14° to 122° F(-10° to 50° C)
Non-operating -4° to 122° F (-20° to 50° C)
Battery
Re-Charge Time
System in OFF or
Standby Mode
3.5 to 5 hours
System ON 4 to 7 hours
Fuel Gauge LED No
Warranty 1 year
Optional Travel Battery
Available
Yes
QuickSpecs
HP mt41 Mobile Thin Client
Technical Specifications
DA - 14782 Worldwide — Version 5 — November 19, 2013 Page 18

HP 6-cell (55 WHr)
Lithium-Ion Primary
battery
Dimensions (H x W x L) 0.8 x 1.8 x 8.0in (2.0 x 4.7 x 20.5cm)
Weight .70lb, (.313kg)
Cells/Type Lithium-Ion
Energy Voltage 10.8V
Amp-hour capacity 5.1Ah
Watt-hour capacity 55Wh
Temperature Operating (Charging) 32° to 113° F (0° to 45° C)
Operating (Discharging) 14° to 122° F(-10° to 50° C)
Non-operating -4° to 122° F (-20° to 50° C)
Battery
Re-Charge Time
System in OFF or
Standby Mode
2.5 hours
System ON 3 to 5 hours
Fuel Gauge LED No
Warranty 1 year
Optional Travel Battery
Available
Yes
Environmental Data Eco-Label Certifications &
declarations
This product has received or is in the process of being certified to the following
approvals and may be labeled with one or more of these marks:
IT ECO declaration
US ENERGY STAR®
EPEAT<Gold registered in the United States. See http://www.epeat.net
for registration status in your country.
System Configuration The configuration used for the Energy Consumption and Declared Noise
Emissions data for the Notebook model is based on a "Typically Configured
Notebook".
Energy Consumption
(in accordance with US
ENERGY STAR® test
method) 115VAC, 60Hz 230VAC, 50Hz 100VAC, 60Hz
Normal Operation 8.38 W 8.61 W 8.45 W
Sleep 1.28 W 1.33 W 1.28 W
Off 0.46 W 0.49 W 0.46 W
NOTE:
Energy efficiency data listed is for an ENERGY STAR® compliant product if
offered within the model family. HP computers marked with the ENERGY
STAR® Logo are compliant with the applicable U.S. Environmental Protection
Agency (EPA) ENERGY STAR® specifications for computers. If a model family
does not offer ENERGY STAR® compliant configurations, then energy
efficiency data listed is for a typically configured PC featuring a hard disk
drive, a high efficiency power supply, and a Microsoft Windows® operating
system.
Heat Dissipation * 115VAC, 60Hz 230VAC, 50Hz 100VAC, 60Hz
QuickSpecs
HP mt41 Mobile Thin Client
Technical Specifications
DA - 14782 Worldwide — Version 5 — November 19, 2013 Page 19

Normal Operation 29 BTU/hr 29 BTU/hr 29 BTU/hr
Sleep 4 BTU/hr 5 BTU/hr 4 BTU/hr
Off 2 BTU/hr 2 BTU/hr 2 BTU/hr
* Heat dissipation is calculated based on the measured watts, assuming the
service level is attained for one hour.
Declared Noise Emissions
(in accordance with
ISO 7779 and ISO 9296)
Sound Power
(LWAd, bels)
Sound Pressure
(LpAm, decibels)
Typically Configured - Idle 3.4 27
Fixed Disk - Random writes 3.4 27
Batteries This battery(s) in this product comply with EU Directive 2006/66/EC
Batteries used in the product do not contain:
Mercury greater the1ppm by weight
Cadmium greater than 20ppm by weight
Battery size: CR2032 (coin cell)
Battery type: Lithium
Battery size: 6-cell high capacity Lithium-Ion battery (optional 8 cell available)
Battery type:
Additional Information This product is in compliance with the Restrictions of Hazardous Substances
(RoHS) directive - 2011/65/EC.
This HP product is designed to comply with the Waste Electrical and
Electronic Equipment (WEEE) Directive - 2002/96/EC.
This product is in compliance with California Proposition 65 (State of
California; Safe Drinking Water and Toxic Enforcement Act of 1986).
This product is in compliance with the IEEE 1680 (EPEAT) standard at the
<gold> level, see www.epeat.net
Plastics parts weighing over 25 grams used in the product are marked per
ISO11469 and ISO1043.
This product contains 0% post-consumer recycled plastic (by wt.)
This product is 95.8% recycle-able when properly disposed of at end of life.
Packaging Materials External: PAPER/Corrugated 482.6 g
Internal: PLASTIC/EPE (Expanded
Polyethylene)
28 g
PLASTIC/Polyethylene low
density
30.4 g
The PAPER/Corrugated packaging material contains at least 70% recycled
content.
The PLASTIC/EPE (Expanded Polyethylene) packaging materials contains at least
50% recycled content.
The PLASTIC/Polyethylene low density packaging materials contains at least 50%
recycled content.
Material Usage This product does not contain any of the following substances in excess of
regulatory limits (refer to the HP General Specification for the Environment at:
http://www.hp.com/hpinfo/globalcitizenship/environment
/pdf/gse.pdf ):
QuickSpecs
HP mt41 Mobile Thin Client
Technical Specifications
DA - 14782 Worldwide — Version 5 — November 19, 2013 Page 20
