HP T5135 - Compaq Thin Client Quick guide

Connection Broker Client Configuration Document
for HP Compaq t5135, t5530, t5720, and t5725 Thin Clients
Purpose .............................................................................................................................................. 2
Support .............................................................................................................................................. 2
Disclaimer........................................................................................................................................... 2
1HP ThinConnect (t5135)................................................................................................................ 2
1.1 How to Configure Citrix Dynamic Desktop Initiative for ThinConnect - t5135................................ 2
1.2 How to Configure LeoStream for ThinConnect - t5135 ............................................................... 7
1.3 How to Configure Provision Network for ThinConnect - t5135 .................................................... 7
1.4 How to Configure HP Session Allocation Manager (SAM) for ThinConnect - t5135 ....................... 8
2Windows CE 5.0 (t5530).............................................................................................................. 8
2.1 How to Configure Citrix Dynamic Desktop Initiative for Windows CE 5.0 - t5530......................... 8
2.2 How to Configure LeoStream for Windows CE 5.0 - t5530...................................................... 11
2.3 How to Configure Provision Network Client for Windows CE 5.0 - t5530.................................. 11
2.4 How to Configure HP Session Allocation Manager (HP SAM) for Windows CE 5.0 - t5530......... 15
3Linux (t5725) ............................................................................................................................. 15
3.1 How to Configure Citrix Dynamic Desktop Initiative for Linux - t5725 ........................................ 15
3.2 How to Configure LeoStream for Linux - t5725........................................................................ 17
3.3 How to Configure Provision Network for Linux - t5725 ............................................................ 17
3.4 How to Configure PC Session Allocation Manager (HP SAM) for Linux - t5725 .......................... 17
4Microsoft Windows XPe (t5720) .................................................................................................. 17
4.1 How to Configure Citrix Dynamic Desktop Initiative for Windows XPe – t5720........................... 17
4.2 How to Configure Leostream for Windows XPe - t5720 ........................................................... 20
4.3 How to Configure Provision Network for Windows XPe - t5720............................................... 20
4.4 How to Configure PC Session Allocation Manager (HP SAM) for Windows XPe - t5720.............. 20

2
Purpose
This document explains how to configure the listed HP Compaq Thin Clients to be used with Citrix, HP
Session Allocation Manager (HP SAM), Provision Network, and LeoStream brokers.
Support
Citrix Dynamic Desktop Initiative and HP Session Allocation Manager (HP SAM) come preinstalled on
the listed HP Compaq Thin Clients and are supported by HP. For support, contact HP Customer
Service.
Provision Network and LeoStream connection broker software are third-party software applications
that are only preinstalled on the t5135 and not on the remaining listed HP Thin Clients. For any
support related to Provision Network or LeoStream, contact these companies directly:
•Provision Network: www.provisionnetworks.com
•LeoStream: www.LeoStream.com/support
Disclaimer
THE INFORMATION CONTAINED HEREIN IS SUBJECT TO CHANGE WITHOUT NOTICE AND IS
PROVIDED "AS IS" WITHOUT WARRANTY OF ANY KIND. THE WARRANTIES FOR HP PRODUCTS
AND SERVICES ARE SET FORTH IN THE EXPRESS LIMITED WARRANTY STATEMENTS
ACCOMPANYING SUCH PRODUCTS AND SERVICES. NOTHING HEREIN SHOULD BE
CONSTRUED AS CONSTITUTING AN ADDITIONAL WARRANTY. HP SHALL NOT BE LIABLE FOR
TECHNICAL OR EDITORIAL ERRORS OR OMISSIONS CONTAINED HEREIN.
1HP ThinConnect (t5135)
1.1 How to Configure Citrix Dynamic Desktop Initiative for ThinConnect
- t5135
This section describes how to connect the HP Compaq t5135 (ThinConnect) Citrix Client to a Citrix
DDI (Dynamic Desktop Initiative) environment.
Topics Include:
•Creating Connection Entries
•Opening a Connection
Creating Connection Entries
There are two types of connections to a “Citrix Desktop Server.”
•A connection to a server desktop lets a user access the desktop of a server. The user can run any
applications available on the desktop, in any order.
•A connection to published applications lets a user access predefined Windows XP Pro Published
Desktop(s).
To create an ICA connection to a Published Application Server:
1. Boot the t5135 Thin Client – the HP ThinConnect screen will automatically open.

3
2. Click Settings. The following screen is displayed.
3. Click the Global Citrix tab.

4
4. Click the App Servers button.
5. Click Add App Server and type the Published App Server address of the Desktop Server and XML
Port Number (example: 10.100.8.101:80)
6. Click OK.

5
7. Click OK then Save on the App Servers screen.
8. Click Restart Session at the Save Warning screen.
9. After the thin client restarts, click Settings then the Connections tab.
10. Click Add ICA. The following screen will open.
11. Type a Connection Name, select Published Applications as the Server Type, then select a
Published Application using the drop-down menu.
In the example below, the ICA connection is named “XP Pro Station 1,” the Server Type is
changed to Published Application, and “XP Pro” is selected from the Published Application drop-
down list (from the 10.1000.8.101:80 server address).

6
12. Click OK. The Settings > Connection screen will open.
13. Click Save and Restart Session at the Save Warning screen.

7
Opening a Connection
At the HP ThinConnect screen, highlight the name of the connection and click the Connect button. Both
are highlighted in the example below.
NOTE:
If Password Manager is not installed, you will be prompted for a username
and password multiple times.
1.2 How to Configure LeoStream for ThinConnect - t5135
This section describes how to connect the HP Compaq t5135 (ThinConnect) to a LeoStream broker
environment.
1. Image device with S1ST0032 or newer
2. Boot device
3. Press the "Settings" button
4. Select the "Security" tab
5. Choose desired mode from the "Thin Client State" combo box
6. Press the "Save" button
7. Press the "Restart Session" button
8. At the prompt file in username, password, domain, and server name
Note:
Not all connection attributes are currently being propagated
Supports LeoStream broker server 4.4 and newer
1.3 How to Configure Provision Network for ThinConnect - t5135
This section describes how to connect the HP Compaq t5135 (ThinConnect) to a Provision Network
broker environment.
1. Image device with S1ST0032 or newer
2. Boot device
3. Press the "Settings" button
4. Select the "Security" tab
5. Choose desired mode from the "Thin Client State" combo box
6. Press the "Save" button
7. Press the "Restart Session" button

8
8. At the prompt file in username, password, domain, and server name
Note:
Not all connection attributes are currently being propagated.
Need to quit session if failed login (i.e.: no connections).
Provision Networks need to include port on server entry - default is 8080.
1.4 How to Configure HP Session Allocation Manager (SAM) for
ThinConnect - t5135
Not available at this time
2Windows CE 5.0 (t5530)
2.1 How to Configure Citrix Dynamic Desktop Initiative for Windows
CE 5.0 - t5530
This section describes how to connect the HP Compaq t5530 (Genuine Windows CE 5.0) 9.x Citrix
Client to a Citrix DDI (Dynamic Desktop Initiative) environment.
Topics Include:
•Creating Connection Entries
•Opening a Connection
Creating Connection Entries
There are two types of connections to a “Citrix Desktop Server.”
•A connection to a server desktop lets a user access the desktop of a server. The user can run any
applications available on the desktop, in any order
•A connection to published applications lets a user access predefined Windows XP Pro Published
Desktop(s).
To create a connection
1. Launch the Citrix Client
StartÆProgramsÆCitrix Program Neighborhood

9
2. Double-click New Citrix ICA Client - ICA.
3. Select Published Application, select Server Location, choose TCP browser then add the name or IP
address of the Desktop Broker Server, click OK, then OK again to accept the server location.

10
4. Click on Refresh and you should get a list of the published Desktop Server(s) available or the
Published XP Pro instances available.
5. Click Done.
Opening a Connection
Double-click the name of the connection you want to make and click on the connect button, enter
username, password and domain, click OK.

11
Note:
If you do not have Password Manager installed you will be prompted for
your username and password multiple times.
2.2 How to Configure LeoStream for Windows CE 5.0 - t5530
Not available at this time
2.3 How to Configure Provision Network Client for Windows CE 5.0 -
t5530
Contact Provision Networks directly for sale and support.
Installation
1. Visit www.provisionnetworks.com to obtain the ZIP file from Provision that contains the agent
binaries:
•PNTSC.EXE
•PNLLMCLI.DLL
•PNTSCVC.DLL
You will need to sign up for an account to have access to download client.
2. Copy the 3 binaries to the t5530 flash directory ‘\hard disk\program files’.
3. Run PNTSC.EXE. (See Figure 1: PNTSC Window)
4. This will add the necessary registry data into the CE OS.
5. Close PNTSC window
6. (Optional) Verify registry data was entered properly.
7. From a command shell run:
\> regdump –m Software\Microsoft\WBT\Clients\Registration\pntsc
RegDump
Copyright 2004 Hewlett-Packard Development Company, L.P.. All rights
reserved.

12
[HKEY_LOCAL_MACHINE\software\microsoft\wbt\clients\registration\pntsc]
“Description”=”Provision Networks”
“NewCmdLineArgs”=””
“NewExe”=”\\Hard Disk\\Program Files\\pntsc.exe”
“Type”=”PNTSC”
Add Connection
In order to make use of the Provision client one first adds a connection to HP ThinConnect. However,
clicking the Add button from ThinConnect does not work with the Provision client. Instead, follow these
steps:
1. Run PNTSC.EXE (See Figure 1: PNTSC Window).
2. From the General tab, select Application.
3. Click Connectivity.
4. Enter TCP Port 80 (See Figure 2: Connectivity Screen)
5. Click Add to enter Server Address
6. Click OK.
7. Click OK.
8. From Credentials tab, enter user credentials (See Figure 3: Credentials Screen).
9. From the General tab, select from the drop down box (See Figure 4: Published Apps List).
10. Click button Save As…
11. Type MyConnection
12. Click OK.
13. Close PNTSC Window.
14. Run HP ThinConnect.
15. Click Advanced.
16. Verify that MyConnection appears under Available Connections.
17. Assign MyConnection to Administrator by clicking on the right arrow button.
18. Click OK.
Connect
1. Run HP ThinConnect.
2. Highlight “MyConnection” added from steps above.
3. Click Connect.
Issues
Although the Provision Network client requires the HP ThinConnect to work, the following ThinConnect
buttons fail with Provision Network:
Add
Edit – bring up the PNTSC Window that has no idea which connection you clicked Edit on. You must
click Save As and select the proper connection name.

13
Figure 1: PNTSC Window
Figure 2: Connectivity Screen

14
Figure 3: Credentials Screen

15
Figure 4: Published Apps List
2.4 How to Configure HP Session Allocation Manager (HP SAM) for
Windows CE 5.0 - t5530
Please see HP PC Session Allocation Manager (SAM) Administrator User Guide (Document Part
Number: 453252–002)
http://bizsupport.austin.hp.com/bc/docs/support/SupportManual/c01301691/c01301691.pdf
3Linux (t5725)
3.1 How to Configure Citrix Dynamic Desktop Initiative for Linux -
t5725
This section describes how to connect the HP Compaq t5725 (Debian Linux OS) Linux Citrix Client
10.X to a Citrix DDI (Dynamic Desktop Initiative) environment.
Topics Include:
•Creating Connection Entries
•Opening a Connection
Creating Connection Entries
There are two types of connections to a Citrix Desktop Server.
1. A connection to a server desktop lets a user access the desktop of a server. The user can run any
applications available on the desktop, in any order
2. A connection to published applications lets a user access predefined Windows XP Pro Published
Desktop(s).
To create a connection
3. Launch the Citrix Client:
StartÆProgramsÆAppsÆNetÆCitrix ICA Connection Manager

16
1. On the Connections menu (highlighted in the picture above), click New.
2. On the Connections menu (highlighted in the picture above), click New.
The Properties dialog box appears with the Network page displayed. The Network option is
default and is correct.
3. Deselect Use Default and select TCP/IP for the Network Protocol.
4. For Server Location, enter the name or IP of the server.
5. Click Server or Published Applications.
Note:
XP Pro can only be published as an application in Citrix’s current release of
DDI.
6. For a server desktop, type the name or IP address of the server or click Browse to select from a list
of servers.
7. For a published application (i.e. XP Pro Desktop Connection), type the name of the published
application or click Browse to select from a list of published applications.
8. Once you have added the connections, your connection center should look similar to the picture
below.
Opening a Connection
Highlight the name of the connection you want to make and click on the connect button, both have
been highlighted in the picture below.

17
Note:
If you do not have Password Manager installed you will be prompted for
your username and password multiple times.
3.2 How to Configure LeoStream for Linux - t5725
Not available at this time
3.3 How to Configure Provision Network for Linux - t5725
Not available at this time
3.4 How to Configure PC Session Allocation Manager (HP SAM) for
Linux - t5725
Not available at this time
4Microsoft Windows XPe (t5720)
4.1 How to Configure Citrix Dynamic Desktop Initiative
for Windows XPe – t5720
This section describes how to connect the HP Compaq t5720 (XPE Embedded OS) via the Citrix
Presentation Server Client 9.X to a Citrix DDI (Dynamic Desktop Initiative) environment.
Topics Include:
•Configuring an Application Set
•Opening a Connection
To configure an application set.
1. Launch the Citrix Client
2. StartÆAll ProgramsÆCitrixÆCitrix Access Clients ÆProgram Neighborhood

18
3. Double-click Application Set Manager.
4. Double-click Find New Application Set.
5. Select Local Area Network from the drop down box and click Next.
6. Click Server Location and change network protocol to TCP/IP; add the name of your Desktop
Servers; then, click OK
7. This will take you back to the previous screen, click on the drop down button to locate the
application set to add. Once you have click on Next.

19
8. Click Next and accept the defaults until you are prompted to click Finish.
9. At this point you should get a login prompt for the application set:
10. Type in credentials with permission to get to the appropriate XP PRO published application
instances. Once you have been authenticated you will see which Server Desktop(s) or XP Pro
instances you are allowed to utilize by what is listed in your application set.
Opening a Connection
11. Double-click on whichever connection (Desktop Server or XPPro) that you need to work on.

20
NOTE:
Please keep in mind if you do not have Password Manager installed you
will be prompted for your username and password multiple times.
4.2 How to Configure Leostream for Windows XPe - t5720
Not currently available.
4.3 How to Configure Provision Network for Windows XPe - t5720
Not currently available.
4.4 How to Configure PC Session Allocation Manager (HP SAM) for
Windows XPe - t5720
Please see HP PC Session Allocation Manager (SAM) Administrator User Guide (Document Part
Number: 453252–002)
http://bizsupport.austin.hp.com/bc/docs/support/SupportManual/c01301691/c01301691.pdf
