HP 1410 series User manual

Models
HP 1410-8G Switch J9559A
HP 1410-16G Switch J9560A
HP 1410-24G-R Switch JG708A
HP 1410-24G Switch J9561A
HP 1410-8 Switch J9661A
HP 1410-16 Switch J9662A
HP 1410-24 Switch J9663A
HP 1410-24-R Switch JD986B
HP 1410-24-2G Switch J9664A
Key features
Unmanaged Gigabit Ethernet and Fast Ethernet switches
Green features for low power consumption
Fanless design for silent operation
Quality of service (QoS) support
Lifetime warranty
Product overview
HP 1410 Switch Series comprises unmanaged Gigabit Ethernet and Fast Ethernet switches designed for small businesses looking for
entry-level, low-cost networking solutions that come with a lifetime warranty. The series consists of nine models with flexible
mounting options to meet different network switching needs. All models have quality of service(QoS) support and IEEE 802.3x flow
control features that provide outstanding data efficiency. Simplified plug-and-play convenience is enabled by features such as Auto-
MDIX and auto-speed negotiation. HP has innovated and combined the latest advances in silicon technology to bring you some of the
most power-efficient switches: 1410-24G-R,1410-16 and 1410-24 models are advanced IEEE 802.3az-compliant unmanaged Gigabit
and Fast Ethernet switches. The switches come with built-in green features and a lifetime warranty, making the series the right choice
for organizations seeking a networking solution that's both economical and reliable.
Features and benefits
Quality of Service (QoS)
IEEE 802.1p prioritisation
delivers data to devices based on the priority and type of traffic
DiffServ Code Point (DSCP) support
allows real-time traffic prioritisation based on Layer 3 TOS/DSCP parameters
Connectivity
Auto-MDIX
provides automatic adjustments for straight-through or crossover cables on all 10/100 and 10/100/1000 ports
Performance
QuickSpecs
HP 1410 Switch series
Overview
DA - 13674 Worldwide — Version 12 — December 16, 2013 Page 1

NEW Energy-efficient Ethernet support
supports new IEEE 802.3az standard; allows lower power consumption when operated with IEEE-compliant client devices in
100 Mb/s mode only (JG708A, J9662A and J9663A switches)
Half-/full-duplex auto-negotiating capability on every port
doubles the throughput of every port
NEW Jumbo frame support
allows frames up to 9216 bytes to be switched through the network (Gigabit Ethernet models)
Mini jumbo frame support
allows frames up to 2048 bytes to be switched through the network, which supports large data transfers (J9662A and J9663A
switches)
Ease of use
Unmanaged
provides plug-and-play simplicity
Comprehensive LED display with per-port indicators
provides an at-a-glance view of status, activity, speed and full-duplex operation
Flow control
helps ensure reliable communications during full-duplex operation
Auto-speed negotiation
selects individual port speed automatically depending on client capabilities without the need for manual intervention, allowing
for simple plug-and-play operation
Flexibility
Fanless design
enables quiet operation for deployment in open spaces
NEW Internal power supply
provides operation convenience and a neat operation environment (JG708A, J9561A and JD986B switches)
Warranty and support
NEW Lifetime Warranty 2.0
advance hardware replacement for as long as you own the product with next-business-day delivery (available in most countries)†
NEW Electronic and telephone support (for Lifetime Warranty 2.0)
limited 24x7 telephone support is available from HP for the first 3 years; limited electronic and business hours telephone
support is available from HP for the complete warranty period; to reach our support centres, refer to
www.hp.com/networking/contact-support ; for details on the duration of support provided with your product purchase, refer
to www.hp.com/networking/warrantysummary
* HP warranty includes repair or replacement of hardware for as long as you own the product, with next business day advance
replacement (available in most countries). The disk drive included with HP AllianceOne Advanced Services and Services zl Modules, HP
Threat Management Services zl Module, HP AllianceOne Extended zl Module with Riverbed Steelhead, HP MSM765 zl Mobility Controller
and HP Survivable Branch Communication zl Module powered by Microsoft® Lync has a five-year hardware warranty. For details, refer
to the Software license and hardware warranty statements at www.hp.com/networking/warranty
QuickSpecs
HP 1410 Switch series
Overview
DA - 13674 Worldwide — Version 12 — December 16, 2013 Page 2

Build To Order
: BTO is a standalone unit with no integration. BTO products ship standalone are not part of a CTO or Rack-
Shippable solution.
HP 1410-8G Switch J9559A
8 autosensing 10/100/1000 ports
See Configuration
Note:2
HP 1410-16G Switch J9560A
16 autosensing 10/100/1000 ports
1U - Height
See Configuration
Note:2
HP 1410-24G-R Switch JG708A
24 autosensing 10/100/1000 ports
1U - Height
See Configuration
Note:2
HP 1410-24G Switch J9561A
22 autosensing 10/100/1000 ports
2 dual-personality ports; either an RJ-45 10/100/1000 port or an open mini-GBIC slot
1U - Height
See Configuration
Note:1, 3
PDU Cable NA/MX/TW/JP J9561A #B2B
C15 PDU Jumper Cord (NA/MX/TW/JP)
PDU Cable ROW J9561A #B2C
C15 PDU Jumper Cord (ROW)
HP 1410-8 Switch J9661A
8 autosensing 10/100 ports
See Configuration
Note:2
HP 1410-16 Switch J9662A
16 autosensing 10/100 ports
1U - Height
See Configuration
Note:2
HP 1410-24 Switch J9663A
24 autosensing 10/100 ports
1U - Height
See Configuration
Note:2
HP 1410-24-R Switch JD986B
24 autosensing 10/100 ports
1U - Height
See Configuration
Note:2
QuickSpecs
HP 1410 Switch series
Configuration
DA - 13674 Worldwide — Version 12 — December 16, 2013 Page 3

HP 1410-24-2G Switch J9664A
24 autosensing 10/100ports
2 autosensing 10/100/1000 ports
1U - Height
See Configuration
Note:2
Configuration Rules:
Note 1 The following Transceivers install into this switch:
HP X121 1G SFP LC SX Transceiver J4858C
HP X121 1G SFP LC LX Transceiver J4859C
HP X111 100M SFP LC FX Transceiver J9054C
Note 2 Localization required. (See Localization Menu for list.)
Note 3 Localization (Wall Power Cord) required on orders without #B2B or #B2C (PDU Power Cord). (See
Localization Menu)
Internal or External Power Supplies(Model Dependant)
Power supplies included
Enter the following menu selections as integrated to the CTO Model X server above if order is factory built.
Transceivers
SFP Transceivers
HP X121 1G SFP LC SX Transceiver J4858C
HP X121 1G SFP LC LX Transceiver J4859C
HP X111 100M SFP LC FX Transceiver J9054C
Cables
Multi-Mode Cables
HP .5m Multi-mode OM3 LC/LC FC Cable AJ833A
HP 1m Multi-mode OM3 LC/LC FC Cable AJ834A
HP 2 m Multimode OM3 LC/LC FC Cable AJ835A
HP 5 m Multimode OM3 LC/LC FC Cable AJ836A
HP 15 m Multimode OM3 LC/LC FC Cable AJ837A
HP 30 m Multimode OM3 LC/LC FC Cable AJ838A
HP 50 m Multimode OM3 LC/LC FC Cable AJ839A
HP Premier Flex LC/LC OM4 2f 1m Cbl QK732A
QuickSpecs
HP 1410 Switch series
Configuration
DA - 13674 Worldwide — Version 12 — December 16, 2013 Page 4

HP Premier Flex LC/LC OM4 2f 2m Cbl QK733A
HP Premier Flex LC/LC OM4 2f 5m Cbl QK734A
HP Premier Flex LC/LC OM4 2f 15m Cbl QK735A
HP Premier Flex LC/LC OM4 2f 30m Cbl QK736A
HP Premier Flex LC/LC OM4 2f 50m Cbl QK737A
QuickSpecs
HP 1410 Switch series
Configuration
DA - 13674 Worldwide — Version 12 — December 16, 2013 Page 5

HP 1410-8G Switch (J9559A)
I/O ports and slots 8 RJ-45 autosensing 10/100/1000 ports; Media Type: Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or
full; 1000BASE-T: full only (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type
1000BASE-T)
Supports a maximum of 8 autosensing 10/100/1000 ports
Physical characteristics Dimensions 6.14(w) x 3.8(d) x 0.96(h) in (15.6 x 9.65 x 2.45 cm)
Weight 0.74 lb (0.34 kg)
Memory and processor 4 Kb EEPROM capacity; packet buffer size: 192 KB
Mounting Wall, desktop, and under-table mounting
Performance 100 Mb Latency < 3.6 µs (LIFO 64-byte packets)
1000 Mb Latency < 1.2 µs (LIFO 64-byte packets)
Throughput 11.9 Mpps (64-byte packets)
Switching capacity 16 Gbps
MAC address table size 4096 entries
Environment Operating temperature 32°F to 104°F (0°C to 40°C)
Operating relative
humidity
15% to 95% @ 104°F (40°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 90% @ 149°F (65°C), noncondensing
Altitude up to 10,000 ft. (3 km)
Acoustic Power: 0 dB No fan
Electrical characteristics Frequency 50/60 Hz
Maximum heat
dissipation
41 BTU/hr (43.26 kJ/hr)
Voltage 100 - 240 VAC
Current 1.0 A
Maximum power rating 12 W
Notes Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided for planning the infrastructure with
fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all
modules populated.
The exact input voltage and frequency rating are determined by the specific
power adaptor part number ordered. Please select the correct power adaptor
country option.
Safety CSA 22.2 No. 60950; EN 60950/IEC 60950; UL 60950-1
Emissions FCC Rules Part 15, Subpart B Class A
Immunity Generic EN 55022 CISPR 22
EN EN 55024, CISPR 24
QuickSpecs
HP 1410 Switch series
Technical Specifications
DA - 13674 Worldwide — Version 12 — December 16, 2013 Page 6

ESD IEC 61000-4-2
Radiated IEC 61000-4-3
EFT/Burst IEC 61000-4-4
Surge IEC 61000-4-5
Conducted IEC 61000-4-6
Power frequency
magnetic field
IEC 61000-4-8
Voltage dips and
interruptions
IEC 61000-4-11
Harmonics IEC 61000-3-2
Flicker IEC 61000-3-3
Services 3-year, 4-hour onsite, 13x5 coverage for hardware (UF795E)
3-year, 4-hour onsite, 24x7 coverage for hardware (UF796E)
1-year, post-warranty, 4-hour onsite, 13x5 coverage for hardware (HR843E)
1-year, post-warranty, 4-hour onsite, 24x7 coverage for hardware (HR844E)
Installation with minimum configuration, system-based pricing (U4826E)
Installation with HP-provided configuration, system-based pricing (U4830E)
4-year, 4-hour onsite, 13x5 coverage for hardware (UR816E)
4-year, 4-hour onsite, 24x7 coverage for hardware (UR817E)
5-year, 4-hour onsite, 13x5 coverage for hardware (UR818E)
5-year, 4-hour onsite, 24x7 coverage for hardware (UR819E)
3 Yr 6 hr Call-to-Repair Onsite (UW386E)
4 Yr 6 hr Call-to-Repair Onsite (UW387E)
5 Yr 6 hr Call-to-Repair Onsite (UW388E)
1-year, 6 hour Call-To-Repair Onsite for hardware (HR845E)
Refer to the HP website at: www.hp.com/networking/services for details on the service-level
descriptions and product numbers. For details about services and response times in your area, please
contact your local HP sales office.
HP 1410-16G Switch (J9560A)
I/O ports and slots 16 RJ-45 autosensing 10/100/1000 ports; Media Type: Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or
full; 1000BASE-T: full only (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type
1000BASE-T)
Supports a maximum of 16 autosensing 10/100/1000 ports
Physical characteristics Dimensions 8.21(w) x 4.41(d) x 1.73(h) in (20.85 x 11.2 x 4.4 cm) (1U height)
Weight 1.43 lb (0.65 kg)
Memory and processor 512 Kb flash; packet buffer size: 512 KB
Mounting Mounts in an EIA-standard 19 in. telco rack (hardware included); wall, desktop, and under-table mounting
Performance 100 Mb Latency < 8.0 µs (LIFO 64-byte packets)
1000 Mb Latency < 3.6 µs (LIFO 64-byte packets)
Throughput 23.8 Mpps (64-byte packets)
Switching capacity 32 Gb/s
QuickSpecs
HP 1410 Switch series
Technical Specifications
DA - 13674 Worldwide — Version 12 — December 16, 2013 Page 7

MAC address table size 8192 entries
Environment Operating temperature 32°F to 104°F (0°C to 40°C)
Operating relative
humidity
15% to 95% @ 104°F (40°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 90% @ 149°F (65°C), noncondensing
Altitude up to 10,000 ft. (3 km)
Acoustic Power: 0 dB No fan
Electrical characteristics Frequency 50/60 Hz
Maximum heat
dissipation
44 BTU/hr (46.42 kJ/hr)
Voltage 100 - 240 VAC
Current 1.1 A
Maximum power rating 13 W
Notes Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided for planning the infrastructure with
fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all
modules populated.
The exact input voltage and frequency rating are determined by the specific
power adaptor part number ordered. Please select the correct power adaptor
country option.
Safety CSA 22.2 No. 60950; UL 60950-1; IEC 60950-1; EN 60950-1
Emissions FCC Rules Part 15, Subpart B Class A
Immunity Generic EN 55022 CISPR 22
EN EN 55024, CISPR 24
ESD IEC 61000-4-2
Radiated IEC 61000-4-3
EFT/Burst IEC 61000-4-4
Surge IEC 61000-4-5
Conducted IEC 61000-4-6
Power frequency
magnetic field
IEC 61000-4-8
Voltage dips and
interruptions
IEC 61000-4-11
Harmonics IEC 61000-3-2
Flicker IEC 61000-3-3
Services 3-year, 4-hour onsite, 13x5 coverage for hardware (UF797E)
3-year, 4-hour onsite, 24x7 coverage for hardware (UF798E)
1-year, post-warranty, 4-hour onsite, 13x5 coverage for hardware (HR846E)
1-year, post-warranty, 4-hour onsite, 24x7 coverage for hardware (HR847E)
QuickSpecs
HP 1410 Switch series
Technical Specifications
DA - 13674 Worldwide — Version 12 — December 16, 2013 Page 8

Installation with minimum configuration, system-based pricing (U4826E)
Installation with HP-provided configuration, system-based pricing (U4830E)
4-year, 4-hour onsite, 13x5 coverage for hardware (UR820E)
4-year, 4-hour onsite, 24x7 coverage for hardware (UR821E)
5-year, 4-hour onsite, 13x5 coverage for hardware (UR822E)
5-year, 4-hour onsite, 24x7 coverage for hardware (UR823E)
3 Yr 6 hr Call-to-Repair Onsite (UW389E)
4 Yr 6 hr Call-to-Repair Onsite (UW390E)
5 Yr 6 hr Call-to-Repair Onsite (UW391E)
1-year, 6 hour Call-To-Repair Onsite for hardware (HR848E)
Refer to the HP website at: www.hp.com/networking/services for details on the service-level descriptions
and product numbers. For details about services and response times in your area, please contact your local
HP sales office.
HP 1410-24G-R Switch (JG708A)
I/O ports and slots 24 RJ-45 autosensing 10/100/1000 ports; Media Type: Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or
full; 1000BASE-T: full only (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type
1000BASE-T)
Supports a maximum of 24 autosensing 10/100/1000 ports
Physical characteristics Dimensions 17.32(w) x 6.81(d) x 1.73(h) in (44 x 17.3 x 4.4 cm) (1U height)
Weight 6.61 lb (3 kg)
Memory and processor 1 MB flash; packet buffer size: 512 KB
Mounting Mounts in an EIA standard 19-inch telco rack (hardware included); desktop mounting
Performance 100 Mb Latency < 8.0 µs (LIFO 64-byte packets)
1000 Mb Latency < 3.6 µs (LIFO 64-byte packets)
Throughput 35.7 Mpps (64-byte packets)
Switching capacity 48 Gb/s
MAC address table size 8192 entries
Environment Operating temperature 32°F to 104°F (0°C to 40°C)
Operating relative
humidity
5% to 95% @ 104°F (40°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
5% to 90% @ 149°F (65°C), noncondensing
Altitude up to 16,404 ft (5 km)
Acoustic Power: 0 dB No fan
Electrical characteristics Frequency 50/60 Hz
Maximum heat
dissipation
55 BTU/hr (58 kJ/hr)
Voltage 100 - 240 VAC
Current 0.3 A
QuickSpecs
HP 1410 Switch series
Technical Specifications
DA - 13674 Worldwide — Version 12 — December 16, 2013 Page 9

Maximum power rating 16 W
Notes Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided for planning the infrastructure with
fully loaded PoE (if equipped), 100% traffic, all ports plugged
in, and all modules populated.
This model provides internal power supply. Please select the correct power
cord country option.
Safety CSA 22.2 No. 60950; UL 60950-1; IEC 60950-1; EN 60950-1
Emissions FCC Rules Part 15, Subpart B Class A
Immunity Generic EN 55022 CISPR 22
EN EN 55024, CISPR 24
ESD IEC 61000-4-2
Radiated IEC 61000-4-3
EFT/Burst IEC 61000-4-4
Surge IEC 61000-4-5
Conducted IEC 61000-4-6
Power frequency
magnetic field
IEC 61000-4-8
Voltage dips and
interruptions
IEC 61000-4-11
Harmonics IEC 61000-3-2
Flicker IEC 61000-3-3
Notes IEEE 802.3az Energy Efficient Ethernet protocol is supported by the HP 1410-24G-R (JG708A), HP 1410-16
(J9662A) and HP 1410-24 (J9663A) Switches.
Services 3-year, 4-hour onsite, 13x5 coverage for hardware (UF797E)
3-year, 4-hour onsite, 24x7 coverage for hardware (UF798E)
1-year, post-warranty, 4-hour onsite, 13x5 coverage for hardware (HR846E)
1-year, post-warranty, 4-hour onsite, 24x7 coverage for hardware (HR847E)
Installation with minimum configuration, system-based pricing (U4826E)
Installation with HP-provided configuration, system-based pricing (U4830E)
4-year, 4-hour onsite, 13x5 coverage for hardware (UR820E)
4-year, 4-hour onsite, 24x7 coverage for hardware (UR821E)
5-year, 4-hour onsite, 13x5 coverage for hardware (UR822E)
5-year, 4-hour onsite, 24x7 coverage for hardware (UR823E)
3 Yr 6 hr Call-to-Repair Onsite (UW389E)
4 Yr 6 hr Call-to-Repair Onsite (UW390E)
5 Yr 6 hr Call-to-Repair Onsite (UW391E)
1-year, 6 hour Call-To-Repair Onsite for hardware (HR848E)
Refer to the HP website at: www.hp.com/networking/services for details on the service-level
descriptions and product numbers. For details about services and response times in your area, please
contact your local HP sales office.
HP 1410-24G Switch (J9561A)
QuickSpecs
HP 1410 Switch series
Technical Specifications
DA - 13674 Worldwide — Version 12 — December 16, 2013 Page 10

I/O ports and slots 22 RJ-45 autosensing 10/100/1000 ports; Media Type: Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or
full; 1000BASE-T: full only (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type
1000BASE-T)
2 dual-personality ports; each port can be used as either an RJ-45 10/100/1000 port (IEEE 802.3 Type
10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab 1000BASE-T Gigabit Ethernet) or an open mini-
GBIC slot (for use with mini-GBIC transceivers)
Supports a maximum of 24 Gigabit Ethernet ports
Physical characteristics Dimensions 13.23(w) x 6.65(d) x 1.73(h) in (33.6 x 16.9 x 4.4 cm) (1U height)
Weight 2.98 lb (1.35 kg)
Memory and processor 512 Kb flash; packet buffer size: 512 KB
Mounting Mounts in an EIA-standard 19 in. telco rack (hardware included); wall, desktop, and under-table mounting
Performance 100 Mb Latency < 8.0 µs (LIFO 64-byte packets)
1000 Mb Latency < 3.6 µs (LIFO 64-byte packets)
Throughput 35.7 Kpps (64-byte packets)
Switching capacity 48 Gb/s
MAC address table size 8192 entries
Environment Operating temperature 32°F to 104°F (0°C to 40°C)
Operating relative
humidity
15% to 95% @ 104°F (40°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 90% @ 149°F (65°C), noncondensing
Altitude up to 10,000 ft (3 km)
Acoustic Power: 0 dB No fan
Electrical characteristics Frequency 50/60 Hz
Maximum heat
dissipation
75 BTU/hr (79.13 kJ/hr)
Voltage 100 - 127 / 200 - 240 VAC
Current 0.3/0.2 A
Maximum power rating 22 W
Notes Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided for planning the infrastructure with
fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all
modules populated.
This model provides internal power supply. Please select the correct power
cord country option.
Safety CSA 22.2 No. 60950; UL 60950-1; IEC 60950-1; EN 60950-1
Emissions FCC Rules Part 15, Subpart B Class A
Immunity Generic EN 55022 CISPR 22
EN EN 55024, CISPR 24
ESD IEC 61000-4-2
QuickSpecs
HP 1410 Switch series
Technical Specifications
DA - 13674 Worldwide — Version 12 — December 16, 2013 Page 11

Radiated IEC 61000-4-3
EFT/Burst IEC 61000-4-4
Surge IEC 61000-4-5
Conducted IEC 61000-4-6
Power frequency
magnetic field
IEC 61000-4-8
Voltage dips and
interruptions
IEC 61000-4-11
Harmonics IEC 61000-3-2
Flicker IEC 61000-3-3
Notes Use only supported genuine HP mini-GBICs with your switch.
Services 3-year, 4-hour onsite, 13x5 coverage for hardware (UF797E)
3-year, 4-hour onsite, 24x7 coverage for hardware (UF798E)
1-year, post-warranty, 4-hour onsite, 13x5 coverage for hardware (HR846E)
1-year, post-warranty, 4-hour onsite, 24x7 coverage for hardware (HR847E)
Installation with minimum configuration, system-based pricing (U4826E)
Installation with HP-provided configuration, system-based pricing (U4830E)
4-year, 4-hour onsite, 13x5 coverage for hardware (UR820E)
4-year, 4-hour onsite, 24x7 coverage for hardware (UR821E)
5-year, 4-hour onsite, 13x5 coverage for hardware (UR822E)
5-year, 4-hour onsite, 24x7 coverage for hardware (UR823E)
3 Yr 6 hr Call-to-Repair Onsite (UW389E)
4 Yr 6 hr Call-to-Repair Onsite (UW390E)
5 Yr 6 hr Call-to-Repair Onsite (UW391E)
1-year, 6 hour Call-To-Repair Onsite for hardware (HR848E)
Refer to the HP website at: www.hp.com/networking/services for details on the service-level
descriptions and product numbers. For details about services and response times in your area, please
contact your local HP sales office.
HP 1410-8 Switch (J9661A)
I/O ports and slots 8 RJ-45 autosensing 10/100 ports; Duplex: half or full (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type
100BASE-TX)
Supports a maximum of 8 autosensing 10/100 ports
Physical characteristics Dimensions 6.14(w) x 3.74(d) x 0.97(h) in (15.6 x 9.5 x 2.46 cm)
Weight 0.74 lb (0.34 kg)
Memory and processor 16 Kb EEPROM; packet buffer size: 96 KB
Mounting Wall, desktop, and under-table mounting
Performance 100 Mb Latency < 3.7µs (LIFO 64-byte packets)
Throughput 1.1 Mpps (64-byte packets)
Switching capacity 1.6 Gb/s
MAC address table size 1024 entries
Environment Operating temperature 32°F to 104°F (0°C to 40°C)
QuickSpecs
HP 1410 Switch series
Technical Specifications
DA - 13674 Worldwide — Version 12 — December 16, 2013 Page 12

Operating relative
humidity
15% to 95% @ 104°F (40°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 90% @ 149°F (65°C), noncondensing
Altitude up to 10,000 ft. (3 km)
Acoustic Power: 0 dB No fan
Electrical characteristics Frequency 50/60 Hz
Maximum heat
dissipation
13 BTU/hr (13.72 kJ/hr)
Voltage 100 - 240 VAC
DC voltage 12 V
Current 0.3 A
Maximum power rating 3.6 W
Notes Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided for planning the infrastructure with
fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all
modules populated.
The exact input voltage and frequency rating are determined by the specific
power adaptor part number ordered. Please select the correct power adaptor
country option.
Safety UL 60950-1; CSA 22.2 60950-1; IEC 60950-1:2005; EN 60950-1:2006 + A11:2009
Emissions FCC Rules Part 15, Subpart B Class A
Immunity Generic EN 55022 CISPR 22
EN EN 55024, CISPR 24
ESD IEC 61000-4-2
Radiated IEC 61000-4-3
EFT/Burst IEC 61000-4-4
Surge IEC 61000-4-5
Conducted IEC 61000-4-6
Power frequency
magnetic field
IEC 61000-4-8
Voltage dips and
interruptions
IEC 61000-4-11
Harmonics IEC 61000-3-2
Flicker IEC 61000-3-3
Services 3-year, 4-hour onsite, 13x5 coverage for hardware (UF795E)
3-year, 4-hour onsite, 24x7 coverage for hardware (UF796E)
1-year, post-warranty, 4-hour onsite, 13x5 coverage for hardware (HR843E)
1-year, post-warranty, 4-hour onsite, 24x7 coverage for hardware (HR844E)
4-year, 4-hour onsite, 24x7 coverage for hardware (UR817E)
QuickSpecs
HP 1410 Switch series
Technical Specifications
DA - 13674 Worldwide — Version 12 — December 16, 2013 Page 13

3 Yr 6 hr Call-to-Repair Onsite (UW386E)
1-year, 6 hour Call-To-Repair Onsite for hardware (HR845E)
Refer to the HP website at: www.hp.com/networking/services for details on the service-level
descriptions and product numbers. For details about services and response times in your area, please
contact your local HP sales office.
HP 1410-16 Switch (J9662A)
Ports 16 RJ-45 autosensing 10/100 ports; Duplex: half or full (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type
100BASE-TX)
Supports a maximum of 16 autosensing 10/100 ports
Physical characteristics Dimensions 8.21(w) x 4.21(d) x 1.73(h) in (20.85 x 10.69 x 4.39 cm) (1U height)
Weight 1.43 lb (0.65 kg)
Memory and processor 16 Kb EEPROM; packet buffer size: 2 Mb
Mounting Mounts in an EIA standard 19-inch telco rack (hardware included); wall, desktop and under-table mounting
Performance 100 Mb Latency < 10.6 µs (LIFO 64-byte packets)
Throughput 2.3 Mpps (64-byte packets)
Switching capacity 3.2 Gb/s
MAC address table size 8192 entries
Environment Operating temperature 32°F to 104°F (0°C to 40°C)
Operating relative
humidity
15% to 95% @ 104°F (40°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 90% @ 149°F (65°C), noncondensing
Altitude up to 10,000 ft. (3 km)
Acoustic Power: 0 dB No fan
Electrical characteristics Frequency 50/60 Hz
Maximum heat
dissipation
13 BTU/hr (13.72 kJ/hr)
Voltage 100 - 240 VAC
DC voltage 12 V
Current 0.3 A
Maximum power rating 3.6 W
Notes Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided for planning the infrastructure with
fully loaded PoE (if equipped), 100% traffic, all ports plugged
in, and all modules populated.
The exact input voltage and frequency rating are determined by the specific
power adaptor part number ordered. Please select the correct power adaptor
QuickSpecs
HP 1410 Switch series
Technical Specifications
DA - 13674 Worldwide — Version 12 — December 16, 2013 Page 14

country option.
Safety UL 60950-1; CSA C22.2 60950-1; IEC 60950-1:2005; EN 60950-1:2006 + A11:2009
Emissions FCC Rules Part 15, Subpart B Class A
Immunity Generic EN 55022 CISPR 22
EN EN 55024, CISPR 24
ESD IEC 61000-4-2
Radiated IEC 61000-4-3
EFT/Burst IEC 61000-4-4
Surge IEC 61000-4-5
Conducted IEC 61000-4-6
Power frequency
magnetic field
IEC 61000-4-8
Voltage dips and
interruptions
IEC 61000-4-11
Harmonics IEC 61000-3-2
Flicker IEC 61000-3-3
Notes IEEE 802.3az Energy Efficient Ethernet protocol is supported by the HP 1410-16 (J9662A) and HP 1410-24
(J9663A) Switches only
Services 3-year, 4-hour onsite, 13x5 coverage for hardware (UF797E)
3-year, 4-hour onsite, 24x7 coverage for hardware (UF798E)
1-year, post-warranty, 4-hour onsite, 13x5 coverage for hardware (HR846E)
1-year, post-warranty, 4-hour onsite, 24x7 coverage for hardware (HR847E)
4-year, 4-hour onsite, 13x5 coverage for hardware (UR820E)
4-year, 4-hour onsite, 24x7 coverage for hardware (UR821E)
5-year, 4-hour onsite, 13x5 coverage for hardware (UR822E)
5-year, 4-hour onsite, 24x7 coverage for hardware (UR823E)
3 Yr 6 hr Call-to-Repair Onsite (UW389E)
4 Yr 6 hr Call-to-Repair Onsite (UW390E)
5 Yr 6 hr Call-to-Repair Onsite (UW391E)
Refer to the HP website at: www.hp.com/networking/services for details on the service-level
descriptions and product numbers. For details about services and response times in your area, please
contact your local HP sales office.
HP 1410-24 Switch (J9663A)
I/O ports and slots 24 RJ-45 autosensing 10/100 ports; Duplex: half or full (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type
100BASE-TX)
Supports a maximum of 24 autosensing 10/100 ports
Physical characteristics Dimensions 13.23(w) x 6.65(d) x 1.73(h) in (33.6 x 16.89 x 4.39 cm) (1U height)
Weight 2.98 lb (1.35 kg)
Memory and processor 16 Kb EEPROM; packet buffer size: 2 Mb
Mounting Mounts in an EIA-standard 19 in. telco rack (hardware included); wall, desktop, and under-table mounting
QuickSpecs
HP 1410 Switch series
Technical Specifications
DA - 13674 Worldwide — Version 12 — December 16, 2013 Page 15

Performance 100 Mb Latency < 11 µs (LIFO 64-byte packets)
Throughput 3.5 Mpps (64-byte packets)
Switching capacity 4.8 Gb/s
MAC address table size 8192 entries
Environment Operating temperature 32°F to 104°F (0°C to 40°C)
Operating relative
humidity
15% to 95% @ 104°F (40°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 90% @ 149°F (65°C), noncondensing
Altitude up to 10,000 ft. (3 km)
Acoustic Power: 0 dB No fan
Electrical characteristics Frequency 50/60 Hz
Maximum heat
dissipation
17 BTU/hr (17.93 kJ/hr)
Voltage 100-240 VAC
DC voltage 12 V
Current 0.4 A
Maximum power rating 4.8 W
Notes Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided for planning the infrastructure with
fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all
modules populated.
The exact input voltage and frequency rating are determined by the specific
power adaptor part number ordered. Please select the correct power adaptor
country option.
Safety UL 60950-1; CSA 22.2 60950-1; IEC 60950-1:2005; EN 60950-1:2006 + A11:2009
Emissions FCC Rules Part 15, Subpart B Class A
Immunity Generic EN 55022 CISPR 22
EN EN 55024, CISPR 24
ESD IEC 61000-4-2
Radiated IEC 61000-4-3
EFT/Burst IEC 61000-4-4
Surge IEC 61000-4-5
Conducted IEC 61000-4-6
Power frequency
magnetic field
IEC 61000-4-8
Voltage dips and
interruptions
IEC 61000-4-11
Harmonics IEC 61000-3-2
QuickSpecs
HP 1410 Switch series
Technical Specifications
DA - 13674 Worldwide — Version 12 — December 16, 2013 Page 16

Flicker IEC 61000-3-3
Notes IEEE 802.3az Energy Efficient Ethernet protocol is supported by the HP 1410-24G-R (JG708A), HP 1410-16
(J9662A) and HP 1410-24 (J9663A) Switches.
Services 3-year, 4-hour onsite, 13x5 coverage for hardware (UF797E)
3-year, 4-hour onsite, 24x7 coverage for hardware (UF798E)
1-year, post-warranty, 4-hour onsite, 13x5 coverage for hardware (HR846E)
1-year, post-warranty, 4-hour onsite, 24x7 coverage for hardware (HR847E)
4-year, 4-hour onsite, 13x5 coverage for hardware (UR820E)
4-year, 4-hour onsite, 24x7 coverage for hardware (UR821E)
5-year, 4-hour onsite, 13x5 coverage for hardware (UR822E)
5-year, 4-hour onsite, 24x7 coverage for hardware (UR823E)
3 Yr 6 hr Call-to-Repair Onsite (UW389E)
4 Yr 6 hr Call-to-Repair Onsite (UW390E)
5 Yr 6 hr Call-to-Repair Onsite (UW391E)
Refer to the HP website at: www.hp.com/networking/services for details on the service-level
descriptions and product numbers. For details about services and response times in your area, please
contact your local HP sales office.
HP 1410-24-R Switch (JD986B)
I/O ports and slots 24 RJ-45 autosensing 10/100 ports; Duplex: half or full (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type
100BASE-TX)
Supports a maximum of 24 autosensing 10/100 ports
Physical characteristics Dimensions 17.32(w) x 6.81(d) x 1.73(h) in (44 x 17.3 x 4.4 cm)
Weight 4.41 lb (2.0 kg)
Memory and processor 8kb EEPROM; packet buffer size: 2 Mb
Mounting Mounts in an EIA standard 19-inch telco rack (hardware included); desktop mounting
Performance 100 Mb Latency < 11 µs (LIFO 64-byte packets)
Throughput 3.5 Mpps (64-byte packets)
Switching capacity 4.8 Gb/s
MAC address table size 8192 entries
Environment Operating temperature 32°F to 104°F (0°C to 40°C)
Operating relative
humidity
15% to 95% @ 104°F (40°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
5% to 90% @ 149°F (65°C), noncondensing
Altitude up to 16,404 ft (5 km)
Acoustic Power: 0 dB No fan
Electrical characteristics Frequency 50/60 Hz
Maximum heat
dissipation
21 BTU/hr (22 kJ/hr)
QuickSpecs
HP 1410 Switch series
Technical Specifications
DA - 13674 Worldwide — Version 12 — December 16, 2013 Page 17

Voltage 100 - 240 VAC
DC voltage 3.3 V
Current 1.1 A
Maximum power rating 3.6 W
Notes Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided for planning the infrastructure with
fully loaded PoE (if equipped), 100% traffic, all ports plugged
in, and all modules populated.
This model provides an internal power supply. Please select the correct power
cord country option.
Safety UL 60950-1; CSA 22.2 60950-1; IEC 60950-1:2005; EN 60950-1:2006 + A11:2009
Emissions FCC Rules Part 15, Subpart B Class A
Immunity Generic EN 55022 CISPR 22
EN EN 55024, CISPR 24
ESD IEC 61000-4-2
Radiated IEC 61000-4-3
EFT/Burst IEC 61000-4-4
Surge IEC 61000-4-5
Conducted IEC 61000-4-6
Power frequency
magnetic field
IEC 61000-4-8
Voltage dips and
interruptions
IEC 61000-4-11
Harmonics IEC 61000-3-2
Flicker IEC 61000-3-3
Services 3-year, 4-hour onsite, 13x5 coverage for hardware (UF797E)
3-year, 4-hour onsite, 24x7 coverage for hardware (UF798E)
1-year, post-warranty, 4-hour onsite, 13x5 coverage for hardware (HR846E)
1-year, post-warranty, 4-hour onsite, 24x7 coverage for hardware (HR847E)
4-year, 4-hour onsite, 13x5 coverage for hardware (UR820E)
4-year, 4-hour onsite, 24x7 coverage for hardware (UR821E)
5-year, 4-hour onsite, 13x5 coverage for hardware (UR822E)
5-year, 4-hour onsite, 24x7 coverage for hardware (UR823E)
3 Yr 6 hr Call-to-Repair Onsite (UW389E)
4 Yr 6 hr Call-to-Repair Onsite (UW390E)
5 Yr 6 hr Call-to-Repair Onsite (UW391E)
1-year, 6 hour Call-To-Repair Onsite for hardware (HR848E)
Refer to the HP website at: www.hp.com/networking/services for details on the service-level
descriptions and product numbers. For details about services and response times in your area, please
contact your local HP sales office.
HP 1410-24-2G Switch (J9664A)
QuickSpecs
HP 1410 Switch series
Technical Specifications
DA - 13674 Worldwide — Version 12 — December 16, 2013 Page 18

I/O ports and slots 24 RJ-45 autosensing 10/100 ports; Duplex: half or full (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type
100BASE-TX)
2 RJ-45 autosensing 10/100/1000 ports; Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full
only (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T)
Supports a maximum of 24 autosensing 10/100 ports plus 2 autosensing 10/100/1000 ports
Physical characteristics Dimensions 13.23(w) x 6.65(d) x 1.73(h) in (33.6 x 16.89 x 4.39 cm) (1U height)
Weight 2.98 lb (1.35 kg)
Memory and processor 2 Kb EEPROM; packet buffer size: 2.5 Mb
Mounting Mounts in an EIA-standard 19 in. telco rack (hardware included); wall, desktop, and under-table mounting
Performance 100 Mb Latency < 5.6 µs (LIFO 64-byte packets)
1000 Mb Latency < 2.2 µs (LIFO 64-byte packets)
Throughput 6.5 Mpps (64-byte packets)
Switching capacity 8.8 Gb/s
MAC address table size 8192 entries
Environment Operating temperature 32°F to 104°F (0°C to 40°C)
Operating relative
humidity
15% to 95% @ 104°F (40°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 90% @ 149°F (65°C), noncondensing
Altitude up to 10,000 ft. (3 km)
Acoustic Power: 0 dB
Electrical characteristics Frequency 50/60 Hz
Maximum heat
dissipation
37 BTU/hr (39.03 kJ/hr)
Voltage 100 - 240 VAC
DC voltage 12 V
Current 0.9 A
Maximum power rating 10.8 W
Notes Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided for planning the infrastructure with
fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all
modules populated.
The exact input voltage and frequency rating are determined by the specific
power adaptor part number ordered. Please select the correct power adaptor
country option.
Safety UL 60950-1; CSA 22.2 60950-1; IEC 60950-1:2005; EN 60950-1:2006 + A11:2009
Emissions FCC Rules Part 15, Subpart B Class A
Immunity Generic EN 55022 CISPR 22
EN EN 55024, CISPR 24
QuickSpecs
HP 1410 Switch series
Technical Specifications
DA - 13674 Worldwide — Version 12 — December 16, 2013 Page 19

ESD IEC 61000-4-2
Radiated IEC 61000-4-3
EFT/Burst IEC 61000-4-4
Surge IEC 61000-4-5
Conducted IEC 61000-4-6
Power frequency
magnetic field
IEC 61000-4-8
Voltage dips and
interruptions
IEC 61000-4-11
Harmonics IEC 61000-3-2
Flicker IEC 61000-3-3
Services 3-year, 4-hour onsite, 13x5 coverage for hardware (UF797E)
3-year, 4-hour onsite, 24x7 coverage for hardware (UF798E)
1-year, post-warranty, 4-hour onsite, 13x5 coverage for hardware (HR846E)
1-year, post-warranty, 4-hour onsite, 24x7 coverage for hardware (HR847E)
4-year, 4-hour onsite, 13x5 coverage for hardware (UR820E)
4-year, 4-hour onsite, 24x7 coverage for hardware (UR821E)
5-year, 4-hour onsite, 13x5 coverage for hardware (UR822E)
5-year, 4-hour onsite, 24x7 coverage for hardware (UR823E)
3 Yr 6 hr Call-to-Repair Onsite (UW389E)
4 Yr 6 hr Call-to-Repair Onsite (UW390E)
5 Yr 6 hr Call-to-Repair Onsite (UW391E)
1-year, 6 hour Call-To-Repair Onsite for hardware (HR848E)
Refer to the HP website at: www.hp.com/networking/services for details on the service-level
descriptions and product numbers. For details about services and response times in your area, please
contact your local HP sales office.
Standards and protocols
(applies to all products in
series)
General protocols
IEEE 802.1p Priority
IEEE 802.3ab 1000BASE-T Gigabit Ethernet over twisted pair (10/100/1000 models only)
IEEE 802.3i 10BASE-T Ethernet over twisted pair
IEEE 802.3u 100BASE-TX Fast Ethernet, 100BASE-FX with autonegotiation
IEEE 802.3x Flow Control
QuickSpecs
HP 1410 Switch series
Technical Specifications
DA - 13674 Worldwide — Version 12 — December 16, 2013 Page 20
