HP StorageWorks 2/8-EL - SAN Switch Instruction Manual

release notes
hp StorageWorks
SAN Switch 2/8
Product Version: 3.0.2k
Second Edition (February 2003)
Part Number: AV-RSB7B-TE
This document summarizes late-breaking and supplemental information for the SAN Switch
2/8 EL and SAN Switch 2/8 Power Pak. In the event of conflicting information between these
Release Notes and other documents contained in this product release, the Release Note content
takes precedence.
For the latest version of these Release Notes and related switch documentation, access the HP
storage website at:
http://www.hp.com/country/us/eng/prodserv/storage.html .

2 SAN Switch 2/8 Version 3.0.2k Release Notes
© 2003 Hewlett-Packard Company
Hewlett-Packard Company makes no warranty of any kind with regard to this material, including, but not limited to,
the implied warranties of merchantability and fitness for a particular purpose. Hewlett-Packard shall not be liable for
errors contained herein or for incidental or consequential damages in connection with the furnishing, performance,
or use of this material.
Compaq Computer Corporation is a wholly-owned subsidiary of Hewlett-Packard Company.
This document contains proprietary information, which is protected by copyright. No part of this document may be
photocopied, reproduced, or translated into another language without the prior written consent of Hewlett-Packard.
The information contained in this document is subject to change without notice.
Microsoft, Windows, and Windows NT are U.S. registered trademarks of Microsoft Corporation.
UNIX is a registered trademark of The Open Group.
BROCADE, the Brocade B weave logo, Brocade: the Intelligent Platform for Networking Storage, SilkWorm, and
SilkWorm Express, are trademarks or registered trademarks of Brocade Communications Systems, Inc. or its
subsidiaries in the United States and/or in other countries.
All other product names mentioned herein may be trademarks of their respective companies.
Hewlett-Packard Company shall not be liable for technical or editorial errors or omissions contained herein. The
information is provided “as is” without warranty of any kind and is subject to change without notice. The warranties
for Hewlett-Packard Company products are set forth in the express limited warranty statements for such products.
Nothing herein should be construed as constituting an additional warranty.
Printed in the U.S.A.
SAN Switch 2/8 Version 3.0.2k Release Notes
Second Edition (February 2003)
Part Number: AV-RSB7B-TE

About this Document
3SAN Switch 2/8 Version 3.0.2k Release Notes
About this Document
This section lists the content contained in these Release Notes, including:
Note: The SAN Switch 2/8 is offered in two configurations, the 2/8 EL and 2/8
Power Pak. These Release Notes refer to both models as the SAN Switch 2/8, unless
otherwise noted.
■Intended Audience, page 4
■Related SAN Switch 2/8 Product Documentation, page 4
■Features Summary, page 6
—If You Purchased the SAN Switch 2/8 EL, page 6
—If You Purchased the SAN Switch 2/8 Power Pak, page 7
■Optional Upgrades, page 8
■Obtaining Optional Software License Keys from HP, page 8
■Orderable Hardware, page 9
■hp StorageWorks SAN Switch Software v3.0.2k CD, page 10
■v3.0.2k Firmware Overview, page 10
—Firmware v3.0.2k Updates, page 10
—Excessive Error Counts, page 11
■Hardware Updates, page 11
—Verify Licenses Before Replacing Hardware, page 11
—Cables, page 11
■Compatibility, page 12

Intended Audience
4 SAN Switch 2/8 Version 3.0.2k Release Notes
■Important Information about the IV_Domain_Fabric License, page 12
—Four Switch Limitation, page 12
—Four Switch Limitation Workarounds, page 13
■Management Station Requirements for Running Web Tools, page 13
—Operating Systems, page 13
—Memory Requirement (Windows operating systems), page 14
—Disk Space, page 14
—Web Browsers, page 14
—Java Plug-in, page 15
■SNMP-based Management, page 15
Intended Audience
This document is intended for HP technicians and customers who purchased the
SAN Switch 2/8 EL and SAN Switch 2/8 Power Pak models.

Related SAN Switch 2/8 Product Documentation
5SAN Switch 2/8 Version 3.0.2k Release Notes
Related SAN Switch 2/8 Product Documentation
The SAN Switch 2/8 kit also includes the following documents:
Note: The SAN Switch 2/16 Installation Guide and Release Notes ship in hard copy
format with the switch.With the exception of the Release Notes, all listed documents are
provided on the hp StorageWorks SAN Switch Software v3.0.2k CD, part number
AG-RR86C-BE.
■hp StorageWorks SAN Switch 2/8 Version 3.0.x Installation Guide, part
number AA-RSB6B-TE
■hp StorageWorks SAN Switch 2/8 Version 3.0.2k Release Notes, part number
AV-RSB7B-TE (this document)
■ hp StorageWorks Common Software and Switch Options Version 3.0.x/4.0.x
Release Notes, part number AV-RTQUB-TE
■hp StorageWorks Fabric OS Version 3.0.x/4.0.x Reference Guide, part number
AA-RS24B-TE
■hp StorageWorks Fabric OS Procedures Version 3.0.x/4.0.x User Guide, part
number AA-RS23B-TE
■hp StorageWorks Diagnostics and System Error Messages Version 3.0.x/4.0.x
Reference Guide, part number AA-RS22B-TE
■hp StorageWorks Web Tools Version 3.0.x/4.0.x User Guide, part number
AA-RS25B-TE
■hp StorageWorks Advanced Performance Monitoring Version 3.0.x/4.0.x User
Guide, part number AA-RTS4B-TE
■hp StorageWorks ISL Trunking Version 3.0.x/4.0.x User Guide, part number
AA-RTSAB-TE
■hp StorageWorks Extended Fabric Version 3.0.x/4.0.x User Guide, part
number AA-RTSDB-TE
■hp StorageWorks Fabric Watch Version 3.0.x/4.0.x User Guide, part number
AA-RTSGB-TE
■hp StorageWorks Zoning Version 3.0.x/4.0.x User Guide, part number
AA-RS26B-TE

Features Summary
6 SAN Switch 2/8 Version 3.0.2k Release Notes
■hp StorageWorks Remote Switch Version 3.0.x/4.0.x User Guide, part number
AA-RTS7B-TE
■hp StorageWorks QuickLoop Version 3.0.x User Guide, part number
AA-RTS1A-TE
Soft copy of the hp StorageWorks SAN Switch 2/16 Version 3.0.x Installation
Guide, part number AA-RR84B-TE, is also provided on the CD, which is shared
with 2/8 SAN Switch products.
For the latest supported configurations, please refer to the hp StorageWorks SAN
Design Reference Guide, part number AA-RMPNF-TE, available at:
http://h18006.www1.hp.com/storage/saninfrastructure.html
Additional documentation, including white papers and best practices documents,
are available via the HP website at:
http://welcome.hp.com/country/us/eng/prodserv/storage.html
Features Summary
The following sections summarize the management features enabled on your
specific switch model (SAN Switch 2/8 EL or SAN Switch 2/8 Power Pak).
If You Purchased the SAN Switch 2/8 EL
The SAN Switch 2/8 EL ships with the following features enabled:
■Web Tools—Provides a graphical user interface (GUI) to monitor and manage
the entire fabric.
■Zoning—Allows partitioning of the SAN into logical groupings of devices
that access each other.
■IV_Domain_Fabric OS—Restricts the number of HP switches within a fabric
to four. To upgrade to full fabric support, you must purchase the Full Fabric
OS license, as listed in the Optional Upgrades section of these Release Notes.
■QuickLoop (present on the switch, but not enabled)—Allows arbitrated loops
to attach to a fabric. To enable, use the Web Tools QuickLoop Tab, or use the
telnet qlPortEnable command.

Features Summary
7SAN Switch 2/8 Version 3.0.2k Release Notes
If You Purchased the SAN Switch 2/8 Power Pak
The SAN Switch 2/8 Power Pak ships with the following features enabled, and
ready to use:
■Web Tools—Provides a graphical user interface (GUI) to monitor and manage
the entire fabric.
■Zoning—Allows partitioning of the SAN into logical groupings of devices
that access each other.
■Fabric Watch—Monitors the performance and status of HP StorageWorks
SAN switches, and alerts network managers as problems arise.
■Full Fabric—Updates a switch from IV_Domain_Fabric OS to Full Fabric
OS.
■ISL Trunking—Using ISL trunking, high speed links ensure that
server-to-storage performance is efficient.
■Advanced Performance Monitoring—Provides a comprehensive tool for
monitoring the performance of storage devices within the network.
The following features are built into the switch firmware, but not enabled.
■QuickLoop—Allows arbitrated loops to attach to a fabric. To enable, use the
Web Tools QuickLoop Tab, or use the telnet qlPortEnable command.
■Extended Fabric —Creates a fabric interconnected at distances greater than 5
km for 2 Gb interswitch links. To enable, use the Web Tools Extended Fabrics
Tab, or use the telnet portCfgLongDistance command.
■Remote Switch—Provides a network bridge to interconnect fabrics. To
enable, use the Web Tools Extended Fabrics Tab. See the hp StorageWorks
Common Software and Switch Options Version 3.0.x/v4.0.x Release Notes for
Remote Switch limitations.

Optional Upgrades
8 SAN Switch 2/8 Version 3.0.2k Release Notes
Optional Upgrades
The following upgrades are available for the SAN Switch 2/8:
■Full Fabric Upgrade—allows the user to upgrade their switch from
IV_Domain_Fabric OS to Full Fabric OS.
■Power Pak Upgrade Bundle—includes licenses for ISL Trunking, Advanced
Performance Monitoring, Extended Fabric, Remote Switch and Fabric Watch
options.
Note: Options purchased separately require you to obtain a license. See the next
section, ”Obtaining Optional Software License Keys from HP.”
Obtaining Optional Software License Keys from HP
If you’ve purchased optional software, or need to reinstall software features due to
a motherboard replacement in your switch, you will need to retrieve the software
license keys from the HP Authorization Center.
Obtain software license keys as follows:
■If you have your HP Registration Number, (located on your software
entitlement certificate) go to
http://webkey.external.hp.com/welcome.asp .
■If your HP Registration Number is unavailable, contact the Authorization
Center directly:
— Canada and United States, (Monday through Friday 6:00 am to 6:00 pm
MST), [phone] or [phone].
— Asia, (Monday through Friday 9:00 am to 5:00 pm), [phone]
or [phone].
— Europe, Middle East, Africa and Netherlands (Monday through Friday
9:00 am to 6:00 pm), [phone].

Orderable Hardware
9SAN Switch 2/8 Version 3.0.2k Release Notes
Orderable Hardware
Table 1 lists optional hardware kits for the SAN Switch 2/8.
* premerger HP part number
** premerger Compaq part number
Note: The hp StorageWorks SAN switch Universal Rack Mount Kit is a separate,
orderable item. See the
hp StorageWorks SAN switch Universal Rack Mount Kit
Installation Addendum
, part number AV-RU6YA-TE, supplied with the rack mount kit for
installation instructions.
Table 1: SAN Switch 2/8 Orderable Hardware
Accessory Part Number
Short wavelength SFP A6515A*or 300834-B21**
Long wavelength SFP, 10 km A6516A*or 300835-B21**
2m LC-to-LC Fibre Channel (fc) cable C7524A*
2m LC-to-LC multi-mode fc cable 221692-B21**
16m LC-to-LC fc cable C7525A*
5m LC-to-LC multi-mode fc cable 221692-B22**
50m LC-to-LC fc cable C7526A*
15m LC-to-LC multi-mode fc cable 221692-B23**
200m LC-to-LC fc cable C7527A*
30m LC-to-LC multi-mode fc cable 221692-B26**
50m LC-to-LC multi-mode fc cable 221692-B27**
2m LC-to-SC fc cable C7529A*
2m LC-to-SC multi-mode fc cable 221691-B21**
16m LC-to-SC fc cable C7530A*
5m LC-to-SC multi-mode fc cable 221691-B21**
15m LC-to-SC multi-mode fc cable 221691-B23**
30m LC-to-SC multi-mode fc cable 221691-B26**
50m LC-to-SC multi-mode fc cable 221691-B27**
SC female to SC female adapter C7534A*
2m LC male to SC male adapter kit C7534A*

hp StorageWorks SAN Switch Software v3.0.2k CD
10 SAN Switch 2/8 Version 3.0.2k Release Notes
hp StorageWorks SAN Switch Software v3.0.2k CD
The hp SAN Switch 2/8 ships with the latest version of the firmware installed. A
copy of the latest version of the firmware as of this date, v3.0.2k, is also contained
on the hp StorageWorks SAN Switch Software v3.0.2k CD, part number
AG-RR86C-BE. The v3.0.2k firmware is also available on the HP website at:
http://www.compaq.com/products/storageworks/hubs-and-bridges/firmwareupdate.html
v3.0.2k Firmware Overview
Firmware v3.0.2k works with HP StorageWorks 2 Gb switch models only. The
firmware will not work if loaded onto HP StorageWorks 1 Gb switch models.
Additionally, firmware release v3.0.2k provides fixes for problems associated
with v3.0.2j.
Firmware v3.0.2k Updates
Enhancements to firmware V3.0.2k include:
■3.0.2k provides support for the hp StorageWorks MSA SAN switch 2/8.
■Fan errors no longer display after a specific interval (414 days) of run time.
■Extends name service query time to 1 second from 0.12 second.
■No longer sends PDISK to a single Arbitrated Loop Physical Address (ALPA)
on a single port on the switch.
■Supports both Microsoft Internet Explorer and Netscape Navigator Browsers.
■Commands are insensitive to letter case. For example, the command line
accepts fabricshow as well as fabricShow.
■Active Zone Configuration Warning: Web Tools now issues a warning before
disabling an active zone configuration. This lowers the risk that a Zoned
Fabric may become un-zoned. A "Confirm Zone Delete" window appears
confirming deletion of a zone. The window also notifies the user that the
specified zone member will be removed from corresponding configurations.
The user should click Yes to continue, and No to cancel the zone delete.

Hardware Updates
11SAN Switch 2/8 Version 3.0.2k Release Notes
Excessive Error Counts
Encoding Out Error counts vary under the following conditions:
■When the switch port is set to auto-negotiation, and an N-port device is
connected, the port synchronization takes longer to complete, and a larger
error count displays.
■If a 1Gbps signal is received and the speed negotiation is transmitting at
2 Gbps, a larger error count displays.If the portSpeed and N-port device are
configured to 2 Gbps, encoding out errors are minimal. Similarly, if the
portSpeed and N-port device are configured to 1 Gbps, encoding out errors are
minimal.
■If auto-negotiation is set, the potential error count can be excessive.
Hardware Updates
The following sections list SAN Switch 2/8 hardware updates.
Verify Licenses Before Replacing Hardware
Prior to replacing a switch or motherboard, display and record the current feature
licenses active in the unit. Additional licenses could have been added to the switch
after the installation. Licenses that are active can be viewed from a Telnet session
using the licenseshow command, or they can be viewed from the Web Tools
GUI.
Cables
Optical cables for the Fibre Channel SAN Switches must be ordered separately.
Cables that are 500 meters or less for 1 Gbps and 300 meters or less for 2 Gbps,
should be multi-mode Fibre Channel cables. Cables that are longer than 500
meters should be single-mode.
Multi-mode optical cables are connected to short-wave Small Form Factor
Pluggable (SFP) modules in Fibre Channel SAN Switches. Single-mode optical
cables are connected to longwave SFP modules in the Fibre Channel SAN
Switches. Multi-mode cables should use 50/125 optical fibers, SC Duplex
connectors with a PC finish.
Use of 62.5/125 should be restricted to situations where 62.5/125 optical fiber was
previously installed and the link lengths are to be kept shorter than 200 meters at 1
Gbps and shorter than 150 meters for 2 Gbps.

Compatibility
12 SAN Switch 2/8 Version 3.0.2k Release Notes
Compatibility
SAN Switch firmware v3.0.2k is compatible with the StorageWorks SAN Switch
software version 2.6.0h, allowing both 1 and 2 Gb switches to operate in the same
fabric.
For the latest supported configurations, please refer to the hp StorageWorks SAN
Design Reference Guide, part number AA-RMPNF-TE, available at:
http://www.compaq.com/products/storageworks/san/documentation.html
Note: hp StorageWorks 1 Gb switch models running software version 1.6d are not
supported with the SAN Switch 2/8.
The minimum supported firmware level for the StorageWorks Enterprise Virtual
Array is VCS v1.02. The upgrade of the Enterprise storage subsystem firmware
must be performed before the upgrade of the switch firmware. Please consult the
Enterprise Virtual Array technical documentation for specific information for
upgrading VCS firmware.
Important Information about the IV_Domain_Fabric License
Read the following sections for important information regarding the
IV_Domain_Fabric license installed on your SAN Switch 2/8 EL model only.
Four Switch Limitation
The SAN Switch 2/8 EL shipping configuration integrates the IV_Domain_Fabric
license. The IV_Domain_Fabric license limits the number of switches that can be
connected to a single fabric to four. If more than four switches (of any type) are
added to the fabric where EL switches are installed, Web Tools generates multiple
error messages.
Note: You can upgrade the 2/8 EL switch to full fabric support by installing an
optional upgrade license. See the “Four Switch Limitation Workarounds” described in
these Release Notes for instructions on how to purchase the Full Fabric license.

Management Station Requirements for Running Web Tools
13SAN Switch 2/8 Version 3.0.2k Release Notes
Four Switch Limitation Workarounds
Use one of the following workarounds to prevent four switch limitation errors.
■Upgrade the current HP StorageWorks SAN Switch 2/8 EL
IV_Domain_Fabric license to the optional Full Fabric license. The Full Fabric
license provides full fabric functionality, with no limits on the number of
switches in the fabric.
For purchasing information, contact your authorized HP Sales representative,
or go to the HP storage website at:
http://www.hp.com/country/us/eng/prodserv/storage.html
Note: Complete installation instructions are provided with each license. After the Full
Fabric license is installed, the fabric identifies the switch as a 2/8-EL with a Full Fabric
license, providing full fabric functionality.
■In fabrics which contain five or more switches, with at least one switch with
the IV_FABRIC license installed, reduce the number of switches to four or
less.
Management Station Requirements for Running Web Tools
The workstation used to manage a fabric and configure a switch must meet the
following requirements in order to install and run Web Tools. Web Tools is
installed and runs on the switch, but is displayed in a web browser running on the
workstation.
Operating Systems
One of the following operating systems must be installed:
■Solaris 2.61 or later
■Windows 95, 98, or 2000
■Windows NT 4.0

Management Station Requirements for Running Web Tools
14 SAN Switch 2/8 Version 3.0.2k Release Notes
Memory Requirement (Windows operating systems)
The minimum installed RAM memory requirements are listed next. Generally,
managing more switches means a larger memory requirement.
Number of Switches Minimum Memory Requirement
1-4 64 MB
5-9 96 MB
10-20 128 MB
21 or more 256 MB
Disk Space
Free disk space of 5 MB or more is required to store the program. Free disk space
of 256 MB is recommended to run the program efficiently.
Web Browsers
One of the following web browsers must be installed:
■Netscape Communicator 4.5x, 4.7x
■Internet Explorer 4.x, 5.x
Note: The browser must be configured to work with Web Tools. For configuration
information, refer to the
hp StorageWorks Web Tools User Guide contained on the hp
StorageWorks SAN Switch Software v3.0.2k CD that shipped with the switch.

SNMP-based Management
15SAN Switch 2/8 Version 3.0.2k Release Notes
Java Plug-in
The correct Java Plug-in must be installed for the operating system installed on the
workstation.
■Windows 95, 98, 2000, or NT:
Java Plug-in version 1.3.1_01 is required for the SAN Appliance.
■Solaris:
Java Plug-in version 1.2.2-02 for Solaris, including the Java Plug-in patch
created by Sun Microsystems for Solaris, is required.
The Java Plug-In is contained on the hp StorageWorks SAN Switch Software
v3.0.2k CD included with the switch. The plug-in is located in the FIRMWARE
subdirectory. Double-click on the JAVAPLUGIN.EXE file to begin the installation
procedure.
SNMP-based Management
Many SNMP Fibre Channel Management programs have the capability to log
SNMP trap information (error and status events) occurring on the switch into the
Windows NT application Event log. To enable this capability, parameters must be
set on the switch.
Note: These parameters can be set either through Web Tools by selecting the admin.
button and clicking on the SNMP Admin tab, or by using the Telnet interface along with
the agtcfgSet Telnet command.

SNMP-based Management
16 SAN Switch 2/8 Version 3.0.2k Release Notes
The switch will send one copy of a trap message to each IP address that is listed in
the communities. If you enter the same IP address into more than one of the
communities, you will get multiple copies of the same trap message.
■swEventTrapLevel: (0..5)—must be set for a severity level from 0 to 5
— 0 – none
— 1 – critical
— 2 – error
—3–warning
— 4 – informational
—5–debug
■authTrapsEnabled: (true, t, false, f)—must be set to true or tto enable
sending of traps
Note: This parameter is set to true or t by default.
