HPM LWK0110WBL User manual

LED Worklights
Instruction Manual
Cat. LWK0110WBL, LWK0120WBL,
LWK0130WBL, LWK0220WBL,
LWK0240WBL
1 Specifications
Cat No LWK0110WBL LWK0120WBL LWK0130WBL LWK0220WBL LWK0240WBL
Supply Voltage 230-240V a.c 50Hz
Input Power 11W 23W 32W 22W 46W
Power Output 10W 20W 30W 2 x 10W 2 x 20W
Lumens Output 730lm 1615lm 2250lm 2 x 730lm 2 x 1615lm
Colour Temperature Cool White 4000K Nominal
Protection Class Class 1
Lens/Glass 4mm thick tempered glass
IP Rating IP44
Length of power cord 1.8m
Weight (excl packaging) 1.1kg 1.7kg 2.5kg 4.1kg 5.5kg
Height adjustment N/A Tripod: min 0.65m, max 1.25m
2 Assembly
For LWK0110WBL, LWK0120WBL and LWK0130WBL, mount the head lamp
on the stand and fix in place with mounting bolt. Tighten to secure.
Tripod stand
Cord storage hooks
Leg adjustment bolt (x3)
Height adjustment knobs
Mounting bolt
Cross bar
Head lamps
For LWK0220WBL and LWK0240WBL:
1. Release the 3 leg adjustment bolts, set the 3 legs and allow to lock in
position as shown in diagram.
2. Mount the cross bar on to the tripod stand and fix in place with mounting
bolt. Tighten to secure.
3. Mount the head lamps on the cross bar and fix in place with mounting
bolt. Tighten to secure.
4. Set the height of the worklight to desired position and tighten the height
adjustment knobs.
5. Tilt and swivel the head lamps to desired position. Tighten moulded
knob. When adjusting the head lamps ensure no strain is placed on the
supply cord.
LWK0240WBL LWK0220WBL LWK0130WBL LWK0120WBL LWK0110WBL

1. The worklight requires very little care and maintenance. Simply
clean the lens/glass regularly with a non-abrasive cleaner.
2. Wrap power cord around storage hooks when not in use.
3 Maintenance and Storage
Warranty
HPM Legrand warrants this product for a period of 3 years from the date of purchase.
These goods come with guarantees that cannot be excluded under the Australian
and New Zealand Consumer Laws. You are entitled to a replacement or a refund for
a major failure and for compensation for any other reasonably foreseeable loss or
damage. You are also entitled to have the goods repaired if the goods fail to be of
acceptable quality and the failure does not amount to a major failure.
See the Warranty card enclosed with this product for further details.
Customer Service
For all Customer Service and Technical Support
please call Monday to Friday during business hours.
LE08177AAA HPML0471
Warnings
1. When the worklight is used outdoors it should not be exposed
directly to the elements.
2. Do not operate in close proximity to combustible materials or
substances affected by heating or drying. Keep a minimum
distance of 0.5m from adjacent objects.
3. This product contains no serviceable parts and no attempt
should be made to repair this product. If the product is faulty it
should be discarded.
4. This product has been designed to operate in ambient
temperatures: -10°C to +40°C.
5. Recommended for use only on circuits with Earth Leakage
Protection (with RCD).
6. This product is not suitable for use in hazardous environments
and/or corrosive areas.
7. The material in this product may vary in colour from batch to
batch. Colour matching from one batch to another cannot be
guaranteed.
8. This product utilises intellectual property in the form of
registered designs, trademarks, and/or patents. Such
intellectual property remains the property of HPM Legrand in
all cases.
9. HPM Legrand reserves the right to modify the specification of
this product at any time.
HPM Legrand Australia
1300 369 777
www.hpm.com.au
HPM Legrand New Zealand
0800 476 009
www.hpm.co.nz
ABN: 31 000 102 661
0.5m
