Ignition Stagepix Line 100 IP User manual

Stagepix Line 100 IP
Stagepix Line 50 IP
LED strip
User manual

Musikhaus Thomann
Thomann GmbH
Hans-Thomann-Straße 1
96138 Burgebrach
Germany
Telephone: [phone]
E-mail: [email protected]
Internet: www.thomann.de
13.11.2020, ID: 486339, 486342

Table of contents
1 General information................................................................................................................................. 5
1.1 Further information........................................................................................................................... 6
1.2 Notational conventions.................................................................................................................... 7
1.3 Symbols and signal words............................................................................................................... 7
2 Safety instructions.................................................................................................................................. 10
3 Features....................................................................................................................................................... 13
4 Installation and starting up................................................................................................................ 15
5 Connections and controls................................................................................................................... 18
6 Technical specications....................................................................................................................... 21
7 Cleaning....................................................................................................................................................... 24
8 Protecting the environment.............................................................................................................. 25
Table of contents
Stagepix Line 100 IP Stagepix Line 50 IP 3
LED strip

4Stagepix Line 100 IP Stagepix Line 50 IP
LED strip

1 General information
This user manual contains important information on the safe operation of the device. Read and
follow all safety notes and all instructions. Save this manual for future reference. Make sure
that it is available to all persons using this device. If you sell the device to another user, be sure
that they also receive this manual.
Our products and user manuals are subject to a process of continuous development. We there‐
fore reserve the right to make changes without notice. Please refer to the latest version of the
user manual which is ready for download under www.thomann.de.
General information
Stagepix Line 100 IP Stagepix Line 50 IP 5
LED strip

1.1 Further information
On our website (www.thomann.de) you will nd lots of further information and details on the
following points:
Download This manual is also available as PDF le for you to download.
Keyword search Use the search function in the electronic version to nd the topics of
interest for you quickly.
Online guides Our online guides provide detailed information on technical basics
and terms.
Personal consultation For personal consultation please contact our technical hotline.
Service If you have any problems with the device the customer service will
gladly assist you.
General information
6Stagepix Line 100 IP Stagepix Line 50 IP
LED strip

1.2 Notational conventions
This manual uses the following notational conventions:
The letterings for connectors and controls are marked by square brackets and italics.
Examples: [VOLUME] control, [Mono] button.
1.3 Symbols and signal words
In this section you will nd an overview of the meaning of symbols and signal words that are
used in this manual.
Letterings
General information
Stagepix Line 100 IP Stagepix Line 50 IP 7
LED strip

Signal word Meaning
DANGER! This combination of symbol and signal word indicates an
immediate dangerous situation that will result in death or
serious injury if it is not avoided.
WARNING! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in death or serious
injury if it is not avoided.
NOTICE! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in material and
environmental damage if it is not avoided.
Warning signs Type of danger
Warning – high-voltage.
Warning – suspended load.
General information
8Stagepix Line 100 IP Stagepix Line 50 IP
LED strip

Warning signs Type of danger
Warning – danger zone.
General information
Stagepix Line 100 IP Stagepix Line 50 IP 9
LED strip

2 Safety instructions
This device is intended for use as a lighting eect in connection with a Stagepix Brain IP (item
no. 486345). Use the device only as described in this user manual. Any other use or use under
other operating conditions is considered to be improper and may result in personal injury or
property damage. No liability will be assumed for damages resulting from improper use.
This device may be used only by persons with sucient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
Extend the operating life of the device by regular breaks and by avoiding frequent switching
on and o. The device is not suitable for continuous operation.
Intended use
Safety instructions
10 Stagepix Line 100 IP Stagepix Line 50 IP
LED strip

DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not
within reach of babies and young children. Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the like) from
the unit. They could swallow the pieces and choke!
Never let children unattended use electrical devices.
DANGER!
Electric shock caused by high voltages inside
Within the device there are areas where high voltages may be present. Never
remove any covers.
There are no user-serviceable parts inside.
Do not use the device if covers, protectors or optical components are missing or
damaged.
Safety
Safety instructions
Stagepix Line 100 IP Stagepix Line 50 IP 11
LED strip

NOTICE!
Risk of re
Do not block areas of ventilation. Do not install the device near any direct heat
source. Keep the device away from naked ames.
NOTICE!
Compatible devices
The device may only be used with Ignition Stagepix Brain IP (item no. 486345).
Safety instructions
12 Stagepix Line 100 IP Stagepix Line 50 IP
LED strip

3 Features
nStagepix Line 100 IP (item no. 486339): LED line light with 80 SMD LEDs (RGB) in
40 segments
nStagepix Line 50 IP (item no. 486342): LED line light with 40 SMD LEDs (RGB) in
20 segments
nControl via Stagepix Brain IP (item no. 486345), not included.
nFlexibility due to interchangeable light diusers
nConnection of several LED strips with a clamping mechanism
nRobust aluminium housing
nIncluding black frosted cover
nAlso ideal for outdoor events due to IP65
For technological reasons, the light output of LEDs decreases over their lifetime. This eect
increases with higher operating temperature. You can extend the service life of the illuminants
by providing adequate ventilation and operating the LEDs with the lowest possible brightness.
Features
Stagepix Line 100 IP Stagepix Line 50 IP 13
LED strip

Equipment with protection class IP65 are dust-tight and completely protected against contact
(rst code number). They are also protected against splash water from any angle (second code
digit). That is why this equipment can also be used outdoors. Event technology equipment is
generally only designed for temporary use however (event lighting) and not for permanent
use outdoors.
The specied protection class does not make a statement about the weather resistance of the
equipment (resistance to changing ambient conditions as well as against the eects of sun‐
light and UV rays).
The seals and screw connections of the equipment must be checked regularly to ensure a
fault-free operation. In cases of doubt, consult a specialist workshop in due time.
Information about protection
class IP65
Features
14 Stagepix Line 100 IP Stagepix Line 50 IP
LED strip

4 Installation and starting up
Unpack and check carefully there is no transportation damage before using the unit. Keep the
equipment packaging. To fully protect the product against vibration, dust and moisture during
transportation or storage use the original packaging or your own packaging material suitable
for transport or storage, respectively.
WARNING!
Risk of injury caused by falling objects
Make sure that the installation complies with the standards and rules that apply
in your country. Always secure the device with a secondary safety attachment,
such as a safety cable or a safety chain.
Installation and starting up
Stagepix Line 100 IP Stagepix Line 50 IP 15
LED strip

NOTICE!
Risk of overheating
The distance between light output and the illuminated surface must be more
than 1.5 m (19.7in).
Provide sucient ventilation.
The ambient temperature must always be below 40 °C (104 °F).
You can install the unit in hanging position. When in use, the device must always be attached
to a solid surface or an approved truss. Use the designated mounts for omega brackets on the
retaining bracket for fastening.
Always work from a stable platform whenever installing, moving or servicing the unit. In doing
so, the area underneath the unit must be cordoned o.
Create all connections while the device is o. Use the shortest possible high-quality cables for
all connections. Take care when running the cables to prevent tripping hazards.
Mounting options
Cable connections
Installation and starting up
16 Stagepix Line 100 IP Stagepix Line 50 IP
LED strip

Connect the device via a suitable RJ45 data cable (Cat) to the Stagepix Brain IP (item no.
486345). A maximum of four Ignition Stagepix Line 100 IP LED strips (item no. 486339) or a
maximum of eight Ignition Stagepix Line 50 IP LED strips (item no. 486342) may be connected
in series to each serial interface of the controller.
Please note that this device must not be connected to a dimmer.
Installation and starting up
Stagepix Line 100 IP Stagepix Line 50 IP 17
LED strip

5 Connections and controls
Stagepix Line 100 IP
(Item no. 486339)
Connections and controls
18 Stagepix Line 100 IP Stagepix Line 50 IP
LED strip

Stagepix Line 50 IP
(Item no. 486342)
Connections and controls
Stagepix Line 100 IP Stagepix Line 50 IP 19
LED strip

1 Fastening element for the mechanical connection of two pixel rails using a clamping mechanism
2[INPUT]
RJ45 input for power supply and control of the device by means of Stagepix Brain IP (item no. 486345)
3 Retaining bracket for attaching the device to a suitable truss bar
4[OUTPUT]
RJ45 output for power supply and control of the following pixel strip
5 Safety eyelets and connector for seamless connection of multiple bars
