hpmont HDRU Series User manual

HDRU Series
Power Regenerative Unit
User Manual
V1.5 2019.05

FOREWORD
Thank you for purchasing HDRU series power regenerative unit manufactured by
Shenzhen Hpmont Technology Co., Ltd.
Based on the DSP digital control, HDRU series power regenerative unit (hereinafter
referred to as HDRU) use the advanced PWM rectification control technology,
replace the normal dynamic braking unit and feedback the regenerative power to
power network to reduce the power consumption and achieve energy saving and
environmental protection. HDRU have built-in fuses and three-phase feedback
inductances and have over-temperature, overvoltage and overcurrent protection
function, which make they have low harmonic pollution and high power factor, etc.
This User Manual describes how to use the HDRU and its installation wiring,
troubleshooting and daily maintenance etc.
Before using the product, please read through this user manual carefully.
In addition, please do not use this product until you have fully understood safety
precautions.
Note:
Preserve this Manual for future use.
If you need the User Manual due to damage, loss or other reasons, please contact
the regional distributor of our company or directly contact our company Technical
Service Center.
If you still have some problems during use, please contact our company Technical
Service Center.
Due to product upgrade or specification change, and for the purpose of
improving convenience and accuracy of this manual, this manual’s contents may
be modified.
Email address: oversea[email protected]

Version and Revision Records
Time: 2019/05
Version: V1.5
Revised chapter Revised contents
Chapter 6 •Function parameter modification
Chapter 7 •Fault change

CONTENTS
Chapter 1 Safety Information and Precautions.................................................................................................... 1
1.1 Safety Definition ............................................................................................................................... 1
1.2 Precautions ........................................................................................................................................ 1
Chapter 2 Product Information............................................................................................................................... 3
2.1 Model.................................................................................................................................................. 3
2.2 Product Selection.............................................................................................................................. 3
2.3 Nameplate.......................................................................................................................................... 4
2.4 Part Name........................................................................................................................................... 4
Chapter 3 Mechanical Installation.......................................................................................................................... 5
3.1 Requirement for the Installation Site ............................................................................................ 5
3.2 Installation Direction and Space .................................................................................................... 6
3.3 Dimensions and Weight................................................................................................................... 7
Chapter 4 Wiring and Application.......................................................................................................................... 9
4.1 Wiring Requirements........................................................................................................................ 9
4.2 Power Terminal Description .......................................................................................................... 10
4.3 Control Terminal Description........................................................................................................ 11
4.4 Fuse Explanation............................................................................................................................. 13
4.5 Indicator Description ..................................................................................................................... 13
4.6 Typical Connection ......................................................................................................................... 14
4.7 Typical Application ......................................................................................................................... 15
Chapter 5 Accessory ............................................................................................................................................... 17
Chapter 6 Function Introduction.......................................................................................................................... 19
6.1 Group D: Display Parameters........................................................................................................ 19
6.1.1 D00: State Display Parameter 1............................................................................................................. 19
6.1.2 D01: State Display Parameter 2............................................................................................................. 19
6.2 Group F: General Function Parameters....................................................................................... 20
6.2.1 F00: Basic Parameters ............................................................................................................................... 20
6.2.2 F01: Parameter Protection Function....................................................................................................22
6.2.3 F02: Input Terminal Functions ............................................................................................................... 22
6.2.4 F03: SCI Communication ......................................................................................................................... 23
6.2.5 F04: Display Parameters........................................................................................................................... 24
6.2.6 F05: Diagnostics Parameters .................................................................................................................. 25
6.3 Group y: Manufacturer Function Parameters ............................................................................ 25

Chapter 7 Troubleshooting and Maintenance ................................................................................................... 27
7.1 Troubleshooting.............................................................................................................................. 27
7.2 Maintenance .................................................................................................................................... 28
Appendix A Parameters ......................................................................................................................................... 31

Shenzhen Hpmont Technology Co., Ltd. Chapter 1 Safety Information and Precautions
HDRU Series User Manual V1.5 -1-
Chapter 1 Safety Information and Precautions
1.1 Safety Definition
Danger: A Danger contains information which is critical for avoiding safety hazard.
Warning: A Warning contains information which is essential for avoiding a risk of damage to product or other
equipments.
Note: A Note contains information which helps to ensure correct operation of the product.
1.2 Precautions
Before delivering, this product has been strictly checked and reliably packaged. Due to handling,
loading and unloading in transit, it may cause damage. Therefore, after open the package please check
product integrality carefully:
Check items Check methods
Whether the produtct is in agreement with your ordering
information Check the nameplate on the right side of product
Whether there is damage to parts or damaged Check the overall appearance, check if there is
damage in transit
If there is loose screws or other fasten parts If necessary, use the screwdriver to check
Whether the manual intact Check the manual
If has lacked, please contact manufacturer.
Danger
Warning
Note

Shenzhen Hpmont Technology Co., Ltd. Chapter 2 Product Information
HDRU Series User Manual V1.5 -3-
Chapter 2 Product Information
2.1 Model
2.2 Product Selection
Size Model Rated feedback current Power of adaptive inverter
FR1B HDRU-4T025-B 25A 380V / 7.5 - 22kW
FR2B HDRU-4T050-B 50A 380V / 30 - 37kW
FR2B HDRU-4T075-B 75A 380V / 45 - 75kW
HDRU-4T025-X
4T: 380 - 460V
Rated feedback current
Voltage class of adapting inverter
Product series
Power regenerative unit
Specialfeature

Chapter 2 Product Information Shenzhen Hpmont Technology Co., Ltd.
-4- HDRU Series User Manual V1.5
2.3 Nameplate
2.4 Part Name
MODEL: HDRU-4T025-B
400-800VDC
INPUT:
0-25A
OUTPUT:
1.00
Version:
Product model
Input voltage
Feedback current
Software version
Serial number
Nameplate
Connection hole
Certification
Bottom enclosure
Upper cover
Indicator

Shenzhen Hpmont Technology Co., Ltd. Chapter 3 Mechanical Installation
HDRU Series User Manual V1.5 -5-
Chapter 3 Mechanical Installation
•Do not install if the HDRU is imcomplete or impaired.
•Make sure that the HDRU is far from the explosive and combustible things.
•Only when the power supply is completely cut-off 10 minutes later can you do the wiring job.
•It is required not only carry the display panel and the cover but also the bottom enclosure of the HDRU.
•Do not play metal into the HDRU when installing.
3.1 Requirement for the Installation Site
Ensure the installation site meeting the following requirements:
•Do not install at the direct sunlight, moisture, water droplet location;
•Do not install at the combustible, explosive, corrosive gas and liquid location;
•Do not install at the oily dust, fiber and metal powder location;
•Be vertical installation on fire-retardant material with a strong support;
•Make sure adequate cooling space for the HDRU so as to keep the ambient temperature among
-10 - +40°C;
•Install at where the vibration is 3.5m/s2in 2 - 9Hz, 10m/s2in 9 - 200Hz (IEC60721-3-3);
•Install at where the humidity is less than 95%RH and non-condensing location;
•Protection level of HDRU is IP20 and pollution level is 2 (Dry, non-conducting dust pollution).
Note:
1. It needs derating use if the HDRU operation temperature exceeds 40°C. The derating value of HDRU shall
be 2% for each degree centigrade. Max. allowed temperature is 50°C.
2. Keep ambient temperature among -10 - +40°C. It can improve the HDRU operation performance if install
at the location with good ventilation or cooling devices.
Danger
Warning

Chapter 3 Mechanical Installation Shenzhen Hpmont Technology Co., Ltd.
-6- HDRU Series User Manual V1.5
3.2 Installation Direction and Space
When install HDRU, it should consider the heat dissipation of
air flow. To achieve good cooling efficiency, install the HDRU
perpendicularly according to Table 3-1.
Table 3-1 Installation space size table
A (left and right) ≥50mm
B (up and down) ≥100mm
C (up vent) ≥50mm
D (down vent) ≥50mm
123
C C
B
DD
B
A A

Shenzhen Hpmont Technology Co., Ltd. Chapter 3 Mechanical Installation
HDRU Series User Manual V1.5 -7-
3.3 Dimensions and Weight
The dimensions and weight of HDRU are as shown in Table 3-2.
For the corresponding model of the mounting size, please refer to 2.2 Product Selection, on page 3.
FR1B
FR2B
Table 3-2 HDRU dimensions and weight
Model
Dimension (mm) Mounting dimension (mm) GW
(kg)
W H D W1 H1 H2 d
FR1B 320 380 160 280 365 340 7 17.5
FR2B 320 555 200 280 535 510 10 43.5
W
W1
H
H1
D
H2
4-Ød
W
W1
H
H1
D
H2
4-Ød

Shenzhen Hpmont Technology Co., Ltd. Chapter 4 Wiring and Application
HDRU Series User Manual V1.5 -9-
Chapter 4 Wiring and Application
•Only qualified electrical engineer can perform wiring job.
•The cable on power terminal should have no metal parts exposed in air.
•Do not dismantle HDRU or do wiring operation until the power is cut-off for more than 10 minutes, the internal
charge indicator of HDRU is off and the voltage between (+) and (-) of the main circuit terminals is below 36V.
•The power regenerative unit will produce large leakage current.The GND terminal of unit must be grounded
firmly. Two independent ground wires can guarantee reliable grounding.
•Do not touch the wire terminals of HDRU when it is live. The power terminals are neither allowed connecting to
the enclosure nor short-circuiting.
•The chassis shell should be installed before powering-up. Nobody is allowed to open the shell when HDRU is
living.
•Make sure the HDRU’s power supply voltage is the same as the inverter’s rated voltage.
•HDRU has been passed the withstand voltage test, do not do withstand test on HDRU.
•Do wiring connection according to the wiring figure. Do not connect the HDRU’s DC bus terminals (+) and (-) to
the inverter’s DC terminals (+) and (-).
•Make sure the terminals are fixed tightly.
•Do not play screws, washers and metal bars etc. metal into the HDRU when installing.
•Do not mount the HDRU at the water pipe where may have a water droplet splash.
•Do not supply the damage or parts of insufficiency of the HDRU with power.
•Do not check or detect the signal during the HDRU operation.
4.1 Wiring Requirements
Wiring Requirements
1 For the two power terminals’wiring between the inverter and the HDRU, it is suggested to use the red and
the black of 600V voltage level cable, to prevent the DC bus terminal wiring error.
2 The two lines should be closed and used twisted pair when connect the inverter with the HDRU so as to
reduce the current loop. It suggests that the length of wiring should be less than 2m and not exceed 5m.
3 The interval distance between the control terminal wiring and the power terminal wiring should be greater
than 0.3m so as to reduce the interference to control terminal signal.
4 Caused by filter inductance, HDRU will creates induced voltage in running. The earth terminal of HDRU and
related inverter’s earth terminal should be reliable grounding.
Danger
Warning

Chapter 4 Wiring and Application Shenzhen Hpmont Technology Co., Ltd.
-10- HDRU Series User Manual V1.5
4.2 Power Terminal Description
Power terminals layout as shown in Figure 4-1 and Figure 4-2.
Power terminals description as shown in Table 4-1.
Figure 4-1 FR1 power terminal
Figure 4-2 FR2B power terminal
Table 4-1 Power terminal function description of HDRU
Terminal Description
L1/L2/L3 Three-phase AC power supply output
terminal
The three-phase AC power supply output terminal of
HDRU
(+), (-) DC bus input terminal Respectively connect to the inverter’s (+) and (-) DC bus
PE Protection ground terminal Connect with the protective ground
L1
L2
L3
(+)
(-)
PE
L1 L3
L2 (+) (-) PE

Shenzhen Hpmont Technology Co., Ltd. Chapter 4 Wiring and Application
HDRU Series User Manual V1.5 -11-
4.3 Control Terminal Description
The positions of control terminal, fuses and indicators of HDRU are shown as Figure 4-3 and Figure 4-4.
Control terminals description as shown in Table 4-2.
Refer to section 4.4 for fuses, section 4.5 for indicator.
Figure 4-3 Positions of control terminal, fuses and indicators of FR1B
Fuses
POWER ALARM
REGEN
Terminal
Indicator
REGEN
POWER
ALARM
R1A R1B R1C P24 COM DO1
DI1 DI2 DI3
Optional panel

Chapter 4 Wiring and Application Shenzhen Hpmont Technology Co., Ltd.
-12- HDRU Series User Manual V1.5
Figure 4-4 Positions of control terminal and panel terminal of FR2B
Table 4-2 Control terminal function description
Terminal Description
DI1 - DI3 Digital input
Programmable optical-coupled isolation, it is enabled when short
connected with COM
Input voltage range: 0 - 30VDC. Input impedance: 4.7kΩ
DO1, COM Digital output Programmable optical-coupled isolation, open collector output
Output voltage range: 0 - 30VDC, maximum output current is 50mA
P24, COM +24V power supply Digital input/output power supply, max output current is 200mA
R1A/R1B/R1C Relay output terminal
Programmable relay contact output
Contact rating: 250VAC / 3A or 30VDC /1A
•R1C-R1A: Normally open contact, R1C-R1B: Normally closed contact
POWER ALARM
REGEN
REGEN
POWER
ALARM
+10 DI1 DI2 DI3 R1A
P24 DO1 R1C
COM R1B
Fuses
Terminal
Indicator
Optional panel

Shenzhen Hpmont Technology Co., Ltd. Chapter 4 Wiring and Application
HDRU Series User Manual V1.5 -13-
4.4 Fuse Explanation
The DC bus input side of HDRU is built-in fuses whose location is shown as Figure 4-3 or Figure 4-4.
If the HDRU is damaged by accident, these fuses can break off the electrical connection between HDRU
and inverter’s DC bus so as to avoid inverter damage.
When the fuse is damaged, please use another fuse which is the same as the damaged one, such as the
same brand and model. If have any question, please contact us or our suppliers.
4.5 Indicator Description
The position of indicator light as shown in Figure 4-3, Figure 4-4.
Table 4-3 Indicator description
Indicator Description
POWER HDRU power-on indicator On: The HDRU is at power-on state
Off: The HDRU is not at power-on state
REGEN HDRU’s operating state indicator On: The HDRU is at regenerative state
Off: The HDRU is not at regenerative state
ALARM HDRU’s fault alarm state indicator On: The HDRU is faulty
Off: The HDRU is not faulty

Chapter 4 Wiring and Application Shenzhen Hpmont Technology Co., Ltd.
-14- HDRU Series User Manual V1.5
4.6 Typical Connection
The typical connection of HDRU and HD series inverter is shown as Figure 4-5.
Figure 4-5 Connection of HDRU
Note:
1. Please connect positive and negative terminal correctly, connect (+) terminal of HDRU DC bus to (+)
terminal of inverter DC bus, connect (-) terminal of HDRU DC bus to inverter DC bus.
2. When power on HDRU and inverter at the same time, and the voltage difference must less than F00.27,
the HDRU works as it should.
Since the filter inductance reasons, the adaptive inverter and the HDRU metal enclosure will induce voltage at HDRU
runtime. Please make sure that ground terminals of the HDRU and the adaptive inverter are reliable grounded,
otherwise there is the risk of electric shock.
Inverter
HDRU
MCCB
M
COM
DI3
R1A
R1B
R1C
DO1
P24
PE
PE
(+)
(+)
(-)
(-)
L1
L2
L3
L1
L2
L3
U
V
W
DI2
DI1
+24V
F1
F2
+24V
HDRU is ready
HDRU fault
Terminal auto-run
Fault reset
External fault
Danger

Shenzhen Hpmont Technology Co., Ltd. Chapter 4 Wiring and Application
HDRU Series User Manual V1.5 -15-
4.7 Typical Application
The HDRU has automatic mode and manual mode. The automatic mode has fully automatic mode and
terminal automatic mode, while the manual mode has panel manual mode and terminal manual
mode.
The user can set the different working modes of the feedback unit by setting the function parameters
F00.00 and F00.01.
Automatic mode as an example
The feedback unit factory default parameter is set to automatic mode.
Set F00.01 as 0 or 3.
The feedback unit automatically runs according to the bus voltage value, and stops automatically
when there is no feedback current. shown as Figure 4-6.
Figure 4-6 Automatic mode
Bus voltage
HDRU operating state
Feedback current
Run
Stop
F00.00
F00.03
