HSF EcoAdvance Compact Instruction Manual

EcoAdvance Compact
EcoAdvance Compact
Save this manual with the interface unit
Art.nr. 54324 - Rev. A - 13.02.2020 Changes and misprints reserved
INSTALLATION & USER MANUAL

1
EcoAdvance Compact
230 V
Torx
Symbols
WARNING, general warning
WARNING, electricity, chance of shock or injury
WARNING, hot surface, chance of burns
Important
230 V Alternating current
Dispose of part
Recycle if possible
Open-ended spanner
Torx-screwdriver
Electric drill
Manual processing
Abbreviations
DHW Domestic hot water °C Temperature in degrees Celsius
CH Central heating system Hz Unit for frequency (1 / second)
pH Acidity g (kg) Unit for weight in grams
Pa (kPa) Unit for pressure in Pascal mm Unit for distance in millimeter
Wh (kWh) Unit for energy in watt hours “ Unit for length in inch
W (kW) Unit for power in watt VAC Unit for alternating voltage in Volts
A Unit for current in Ampere LED Light Emitting Diode

2
EcoAdvance Compact
Inhoud
Overview of components 3
Hydraulic scheme 4
User manual 5
Installation conditions 6
Maintenance and inspection 7
Technische specificaties 8
Heat exchanger 40 plates 9
Delivery range 11
Additional items required 11
Dimensions 11
Installation 12
Room thermostat (optional) 16
Commisioning 17
Cover sealing 18
Errors (end user) 19
Errors (installer) 20
Guarantee 21
EC Declaration of conformity 23

3
EcoAdvance Compact
Overview of components
1 Rear cover
2 Domestic water control valve
3 230V power adaptor
4 Heat exchanger
5 Differential pressure regulator impulse line
6 Temperature sensor domestic water
7 Strainer district heating network
8 Electronics
9 LED indication
10 Temperature sensor district heating network
11 CH control valve
12 Temperature sensor district heating network
supply
13 Nipple for temperature sensor
for heat meter
14 Flow sensor domestic water
15 Spool piece for heat meter
16 Differential pressure regulator
8
9
10
11
16
1
2
3
4
13
12
15
14
5
6
7
AB
CD
EF
A Primary supply
B Primary return
C Domestic Hot Water
D Domestic Cold Water
E Central Heating Supply
F Central Heating return

4
EcoAdvance Compact
Hydraulic scheme
CHsupply
Domestic cold water
District heating network supply
CH return
Spool piece
L=110mm
Electronic control unit
2
13
76
5
10
12
15
14
16 11
9
Connection thermostat (ON/OFF)
Service cable
District heating network return
Optional
Domestic hot water

5
EcoAdvance Compact
User manual
INTRODUCTION
This manual covers the installation of the heat interface unit and the relative applicable instructions. These
must be followed to ensure the proper and trouble-free operation of the heat interface unit. You will also
find general technical details and information about maintenance, any errors occurring and their possible
causes. This document forms part of the heat interface unit and must be kept with the interface unit.
APPLICATION
The interface unit is used in collective heat distribtuion systems. This interface unit is suitable for both
heating and preparing domestic hot water. The water that runs through the different systems connected to
the interface unit needs to meet the water quality standards mentioned in document 53261 “Requirements
on water quality for Heat Interface Units for District Heating systems”. The interface unit needs to suffi ce
with the IWUN guidelines 06283 and 06285 and the NEN2768 standard.
STATUS INDICATION LED LIGHT OF THE INTERFACE UNIT
General
Flashing blue : Interface unit is in hot domestic water position
Flashing red : Interface unit failure
Continuously white (only for heat supplier) : Interface unit is in service mode
No LED : Interface unit off
Interface unit with room thermostat connection cable and with priority
Flashing green slowly (approx. once per second) : Interface unit in rest position; there is no heat demand
and the CH control valve is closed.
Flashing green quickly (approx. twice per second) : Interface unit in CH position; there is heat demand and
the CH control valve is open.
Interface unit without room thermostat connection cable or priority switching
Flashing green slowly (approx. once per second) : Interface unit in rest or CH position.
OPERATION
Central heating system
The interface unit is fitted with a differential pressure regulator that keeps the differential pressure
constant throughout the CH installation. The differential pressure ensures continuous flow of heat from the
district heating network through the CH installation.
Room thermostat connection
A (smart) room thermostat can optionally be connected to the heat interface unit. The interface unit will
then respond to heat demand from the room thermostat. The connection of a room thermostat is not
necessary for the proper operation of the interface unit. A conductor is connected to the thermostat
connection cable ex-works (default). This conductor ensures a closed contact and therefore ensures heat
demand at the interface unit.
Note!
Only (smart) on/off room thermostats can be connected which have a potential-free contact or the
Honeywell round on/off (T87G2014) type thermostat with power-stealing technology. Thermostats without
a potential-free contact and/or not of the on/off type are explicitly not allowed.
Note!
High temperatures of parts in the interface unit, pipework and radiators
The interface unit is designed for district heating networks with water temperatures to 95 ºC. The pipework
and parts in the interface unit as well as pipework and radiators in the CH installation can reach this
temperature. Contact can result in burns.

6
EcoAdvance Compact
Hot domestic water
The interface unit features a double wall heat exchanger which transfers the heat supplied by the district
heating network to the domestic water supply. Electronic control together with an electronic control valve
and a flow sensor in the interface unit ensure a domestic water temperature of approx. 55 ºC. The interface
unit has a low tapping threshold of 1 l/min.
Ex-works (default) the heat exchanger is continuously kept warm to supply domestic water as quickly
as possible in case of domestic water demand. Keeping warm takes place at a lowered temperature to
minimise energy consumption. By default the interface unit is provided with an anti-Legionella’s disease
function. To prevent Legionella’s disease the heat exchanger is heated once every 24 hours to at least 60 °C
for at least 90 minutes, whereby any Legionella bacteria are made harmless.
Note!
Hot domestic water
The domestic water temperature is controlled at approx. 55 ºC. With a power outage during hot water
tapping the interface unit stops controlling the domestic water temperature. This can result in domestic
water temperatures lower or higher than 55 ºC. Hot domestic water can cause burns.
Priority switching (optional)
The interface unit is available with optional priority switching. With hot water tapping a CH control valve
ensures that the full differential pressure from the district heating network is available for the heating of
domestic water. During hot water tapping the heat supply to the CH circuit is interrupted. After tapping the
heat supply to the CH circuit resumes again. With a power outage during hot water tapping or in a situation
where there is no heat demand from the (connected) room thermostat, the CH control valve remains in the
closed position. This can result in the cooling of the CH installation.
Installation conditions
With the installation of the interface units account must be taken of the current and applicable Buildings
Regulations, safety requirements for CH installations and general instructions for potable water
installations. The interface unit may only be installed by persons accredited in this discipline. Accreditations
are issued by the energy companies and electricity and water companies. The interface unit is only for
use in closed heating systems to a maximum temperature of 95 ºC. The plug must remain accessible after
installation and must be able to be simply removed from the plug socket.
The following conditions must be observed when installing the interface unit:
1. An associated pre-fix bracket of the same make must be used to ensure the proper operation of the
interface unit.
2. A water heater inlet combination (BIC) of 6 bar must be fitted on the cold domestic water inlet side of
the pre-fix bracket.
3. When using a room thermostat, it must be connected to the thermostat cable on the interface unit
if possible (electronic with priority). NOTE: refer to the technical table for permitted types of room
thermostats.
4. If the room thermostat cannot be connected to the heat interface unit but is connected to the district
heating valve, then the district heating valve must be fitted to the CH return pipe as close to the heat
interface unit as possible.
5. The interface unit must be installed in a frost-free space.
6. The interface unit must not be exposed to direct sunlight.
7. Ambient temperature range: +5 ºC to +40 ºC
8. Humidity range: 20% t/m 80%

7
EcoAdvance Compact
Maintenance and inspection
For proper operation of the interface unit it is advised to have the following points inspected and
maintained at least once every 24 months on the interface unit. Ask your heat supplier or your installer
about the options for service and inspection. Maintenance and repairs on the interface unit must be carried
out by approved professionals.
• For maintenance and inspection of the interface unit fi rst remove the plug from the plug socket.
• Close the supply and return valve in the district heating network.
• Close the supply and return valve in the central heating system.
• Check the couplings and connections inside and outside the interface unit for leaks. If necessary,
replace the seals and/or tighten the couplings.
• Check the strainer for dirt and clean it if required.
• Check the valves for dirt and clean them if required.
• Check the heat supply for domestic water and CH.
• The jacket can be cleaned with a damp cloth. Under no circumstances use solvents (for example:
cleaning spirit, methylated spirits, etc.)
Note!
The interface unit contains electrical components (24 V direct current). These components are not
splashproof
and must be kept dry at all times.
DURING ABSENCE OR HOLIDAYS
Do not pull the plug out of the plug socket! During (long-lasting) absence or holidays do not switch the
interface unit off and under no circumstances close the radiator valves or the valves of the interface unit
and/or the district heating network. This is to prevent frost damage to the pipework in the district heating
network or home installation. If desired it is possible to lower the radiator position to the frost protection
position (slightly open position) and/or set the room thermostat no lower than 15 °C.
After a period of absence it is recommended to fl ush all water tapping points for at least 2 minutes.
WEEE Directive 2012/19/EU: Product must be disposed of at the end of its working
life in accordance with this directive.

8
EcoAdvance Compact
Technische specificaties
Domestic hot water temperature
°
C
Nominal flowrate litre/min
Nominal power (at 10
°
C - 55°C
)
(1)
kW
Pressure loss at nominal flowrate kPa
Pressure class design -
Maximal working pressure bar
Minimal hot water draw off litre/min
Keep warm temperature
(2)
°
C
Keep warm time after draw off
(2)
-
Legionella prevention program -
Thermal standby loss W
Maximal power (at
ΔT=3
0
°
C
)
kW
Maximal flow litre/hour
Differential pressure regulator setpoint kPa
Kvs value m
3
/hour
Pressure class design -
Connection on/off thermostat potential free
(3)
-
Priority switching domestic hot water -
Supply temperature maximal
°
C
Supply temperature minimal
(1)
°
C
Differential pressure minimal
(1)
kPa
Differential pressure maximal kPa
Pressure class design -
District Heating supply -
District Heating return -
Sanitary water cold -
Domestic hot water -
Central Heating supply -
Central Heating return -
Heatmeter (in supply) -
Temperature sensor heatmeter -
Electrical power supply -
Electrical power consumption per year kWh
Height mm
Width mm
Depth mm
Weight kg
(3) Type on/off thermostats with potential free contacts or Honeywell round on/off (T87G2014) thermostat with powerstealing.
16
50
25
Dimensions
475
300
246
(1) Performance HIU is dependent on supply temperatures and differential pressures of the District Heating network. See also the performance graphs.
(2) Adjustable with special Service software and -cable for installers.
Swivel nut 3/4"
Swivel nut 3/4"
Swivel nut 3/4" (2x) L=110 mm
M10x1 or G1/2" (remove adapter)
230VAC - 50Hz - 0,31A max.
approx. 18
PN16
Connections
Swivel nut 3/4"
Swivel nut 3/4"
Swivel nut 3/4"
Swivel nut 3/4"
yes
District Heating network
95 (short term 100)
60
40
21
600
20
1.6
yes
Types and specifications
Art.nr. 54343 - Rev. A - 07-02-2020
Domestic Hot Water
55
1
35 ( adjustable 25-60 )
allways ( adjustable 0 - allways )
yes
approx. 20
9
PN10
6
PN16
250
Central Heating

9
EcoAdvance Compact
0
10
20
30
40
50
60
70
0 2 4 6 8 10 12 14 16 18 20
80
0
10
20
30
40
50
60
70
80
0
10
20
30
40
50
60
70
80
10.0
12.5
15.0
17.5
20.0
22.5
25.0
27.5
30.0
0 2 4 6 8 10 12 14 16 18 20
Heat exchanger 40 plates
Hot domestic water temperature =55 °C old domestic water temperature = 10 °C
Domestic water flow [litres/minute]
Pressure drop tapping side [kPa]
Pressure drop
tapping side
Power [kW]
Power [kW]
Pressure drop tapping side over interface unit
Power [kW]
Domestic water flow [litres/minute]
District heating
network = 65°C
District heating
network = 70°C
District heating
network = 80°C
Power [kW]
District heating network return temperature
District heating network return temperature [°C]

10
EcoAdvance Compact
0
10
20
30
40
50
60
70
80
0
10
20
30
40
50
60
70
80
0 2 4 6 8 10 12 14 16 18 20
Pressure drop
tapping side
Power [kW]
Pressure drop district heating network over interface unit
District heating network flow
Domestic water flow [litres/minute]
Pressure drop district heating network [kPa]
Power [kW]
Domestic water flow [litres/minute]
District heating network flow [litres/minute]
Power [kW]
0
10
20
30
40
50
60
70
80
0.0
2.5
5.0
7.5
10.0
12.5
15.0
17.5
20.0
0 2 4 6 8 10 12 14 16 18 20
District heating
network = 65°C
District heating
network = 70°C
District heating
network = 80°C
Power [kW]
District heating
network = 65°C
District heating
network = 70°C
District heating
network = 80°C
Power [kW]

11
EcoAdvance Compact
Delivery range
Dimensions
HSF EcoAdvance Compact
15
Leveromvang
Maatvoering
1x
230 V
14, 22,
24, 30 mm Torx 25
220
195
140
80 175
75
2540
300 250
485
495
Benodigdheden
17065 65
6080 8040 40
300
250
75 100 75
HSF EcoAdvance Compact
15
Leveromvang
Maatvoering
1x
230 V
14, 22,
24, 30 mm Torx 25
220
195
140
80 175
75
2540
300 250
485
495
Benodigdheden
17065 65
6080 8040 40
300
250
75 100 75
HSF EcoAdvance Compact
15
Leveromvang
Maatvoering
1x
230 V
14, 22,
24, 30 mm Torx 25
220
195
140
80 175
75
2540
300 250
485
495
17065 65
6080 8040 40
300
250
75 100 75
Additional items required

12
EcoAdvance Compact
Installation
1
2
1
2
1. District heating return
2. District heating supply
3. Domestic cold water
4. Domestic hot water
5. CH supply
6. CH return
HSF EcoAdvance Compact
16
Installatie
1
2
1
2
1. Warmtedistributienet aanvoer.
2. Warmtedistributienet retour.
3. Warm tapwater
4. Koud tapwater
5. CV aanvoer
6. CV retour
6x
1
2
3
2
1
35
4
6
3
1
2

13
EcoAdvance Compact
3
4
1
2
30 mm
6x
2
1
6x

14
EcoAdvance Compact
5
?? mm
30 mm
3
24 mm
22 mm
1
14 mm
Option 1
22 mm
2Option 2
Note! Spool piece must be removed and replaced by heat
meter or steel spool piece (Art Nº 44452). Contact your
supplier.
3
3
12
option 1 option 2

15
EcoAdvance Compact
1
2
2
option 1
Connection:
M10 x 1 BN
option 2
Connection: ½" BN
30 mm
2
1
6

16
EcoAdvance Compact
Room thermostat (optional)
Connecting the room thermostat:
1. Remove the conductor. (only when a thermostat is used)
2. Connect the room thermostat cable, with an isolated conductor*, to the room thermostat.
* sold separately
CAUTION!
The unit can (optionally) be connected to a room thermostat. For eligable types of thermostats see chapter
“Technical data”.
1
1
2

17
EcoAdvance Compact
Commisioning
Follow the steps below to start up the unit. If there are leaks or other defects we refer you to the
ERRORS section.
NOTE!
Exercise caution when handling the unit. Components can be hot or electrically charged. Contact can
result in injury.
1. Close all in-house tapping valves.
2. Check tightness of all connection nuts. (Nuts can come loose during transport).
3. Make sure that the electronics housing (A) is in place and that no cables obstruct the cover when it
is closed.
4. Gradually apply domestic water pressure to the unit and check it for leaks.
5. Insert the plug (B) of the unit into the plug socket. The LED lamp (C) should now be flashing green.
6. Gradually open the district heating network supply (D) and check the unit for leaks.
7. Gradually open the district heating network return (E) and check for leaks.
8. Gradually open the CH supply (F).
9. Deaerate the system. Start at the lowest and end at the highest radiator or bleed point.
10. Gradually open the CH return (G).
11. Check there is heat in the system.
12. Gradually open the DCW return (H).
13. Gradually open the DHW return (I).
14. Gradually open a domestic hot water tap. During this step continuously check that the LED light (C)
of the electronics is flashing blue. Fully open the faucet as soon as all air has been removed fromthe
piping and leave it open for 5 minutes. Check the domestic water is 52-58 oC after 3 to 5 min.
15. Close the domestic water tap. The LED light (C) is flashing green.
A
B
230 V
C
D
E
FG
IH

18
EcoAdvance Compact
Cover sealing
2
torx 25
1
2
1

19
EcoAdvance Compact
Errors (end user)
STATUS INDICATION LED LIGHT
Flashing green : Interface unit is in normal position (rest or CH position)
Flashing blue : Interface unit is in hot domestic water position
Flashing red : Interface unit failure
Continuously white : Interface unit is in service mode (only for the heat supplier)
No LED : Interface unit off
WHAT TO DO IF AN ERROR OCCURS?
Note! The cover is sealed and may only be opened by your heat supplier.
In the event of leak
1. Close all taps on the pre-fix bracket under the appliance (levers in horizontal position) and the potable
water main valve.
2. Contact your heat supplier.
CH does not heat up
1. Check whether the valves of the pre-fix bracket are open (levers in vertical position). If not, open the
valves.
2. Check whether the plug of the appliance is inserted in the plug socket (230 V). If not, insert the plug in
the plug socket.
3. Check whether the radiator valves are open. If not, open the radiator valves.
4. Set your thermostat higher than the ambient temperature.
5. Problem solved? If not, contact your heat supplier.
Domestic water does not heat up
1. Check whether the valves of the pre-fix bracket open are (levers in vertical position) and that the main
valve is open. If not, open all valves on the pre-fix bracket under the appliance and the main valve.
2. Check whether the plug of the appliance is inserted in the plug socket (230 V). If not, insert the plug in
the plug socket.
3. Problem solved? If not, contact your heat supplier.
No domestic water
1. Check whether the main valve (usually at the water meter) is open. If not, open the main valve.
2. Problem solved? If not, contact your heat supplier.
