HSS Hire 56144 Troubleshooting guide

Never push the equipment beyond its design limits.
If it will not do what you want with reasonable ease and
speed, assume you have the wrong heater for the job.
Contact your local HSS Hire Shop for advice.
Keep the equipment clean - you will find this less of a
chore if you clean it regularly, rather than wait until the end
of the hire period.
When not in use, store the equipment somewhere
clean, dry and safe from thieves.
Set the switch to ‘fan only and wait for the unit to
cool down.
Once cool switch the supply OFF and unplug it from
the power supply.
All that remains is to give the unit a final clean up
ready for return, to your local HSS Hire Shop.
Code 56144 / 56145
Three Phase
9KW and
18KW Heaters
Three phase fan type heaters offering two
heat settings and one ‘fan only’ setting.
Operating & Safety Guide 892
892/02
©HSS Hire Service Group Ltd 2004 No. 892/02
Group Office: 25 Willow Lane, Mitcham, Surrey CR4 4TS
Web Site: http://www.hss.com
...any comments?
If you have any suggestions to enable us to improve
the information within this guide please fax your
comments or write to the Product Manager at the
address below
Fax: [phone]
EQUIPMENT CARE
FINISHING OFF
The heater has a three position switch, ‘0’ for fan
only, ‘1’ for 9Kw heat output, and ‘2’ for 18Kw heat
output.
Note that when the unit is connected to a power
supply and the supply is switched ON, the fan will
run in all three switch positions. Only when set to No
1 or 2 will heat be emitted
Having double-checked that the heater switch is set to the
‘0’ (fan only position), plug the heater into its power
supply and switch the supply ON.
Model 1…
Start by setting the switch to position ‘1’, this will
activate the fan without heat. Check that the fan is
running BEFORE you move the switch to position ‘2’
(the 6.5Kw heat setting).
If the fan fails to run, DISCONNECT THE UNIT AND
SWITCH THE SUPPLY OFF then contact your local HSS
Hire Shop for advice.
Once you have confirmed that the fan is running move
the switch to position ‘2’, this will give an output of
6.5Kw and may prove to be sufficient for your needs.
If setting ‘2’ proves insufficient, move the switch to
position ‘3’.
Always avoid using more heat than is required and
keep an eye on the room temperature as the heat builds
up.
When you want to switch the unit OFF, turn the
switch to position ‘1’ and leave the unit for at least 5
minutes. In this position, only the fan will run and will
help cool down the heating element before you handle
the unit.
The ‘fan only’ setting can be used if you wish to
circulate air without heating it.
Model 2…
Check that the fan is running BEFORE you move the
switch to position ‘1’ (the 9Kw heat setting).
If the fan fails to run, DISCONNECT THE UNIT AND
SWITCH THE SUPPLY OFF then contact your local HSS
Hire Shop for advice.
Once you have confirmed that the fan is running move
the switch to position ‘1’, this will give an output of 9Kw
and may prove to be sufficient for your needs.
If setting ‘1’ proves insufficient, move the switch to
position ‘2’.
Always avoid using more heat than is required and
keep an eye on the room temperature as the heat builds
up.
When you want to switch the unit OFF, turn the
switch to position ‘0’ and leave the unit for at least 5
minutes. In this position, only the fan will run and will
help cool down the heating element before you handle
the unit.
The ‘fan only’ setting can be used if you wish to
circulate air without heating it.
BASIC TECHNIQUES

415V 3-Phase power supply. Use either a mains or
generated supply.
You will need a 415V 3-Phase 32A (5 pin) armoured
power lead, available for hire from your local HSS
Hire Shop.
Extension leads should be fully unwound and loosely
coiled away from the equipment. Never run it through
water, over sharp edges, or where it could trip
someone.
Keep the equipment dry, using electrical equipment
in very damp or wet conditions can be dangerous.
To reduce the risk of electric shock, connect the unit
to a supply, which is protected by an RCD (Residual
Current-Operated Device) contact your local HSS Hire
Shop for advice.
If the equipment fails, or if its power supply cable or
plug gets damaged, return it. Never try to repair it
yourself.
Ensure the heater and the power socket are
switched OFF before plugging into the power
supply.
Set the heater up on a firm level surface. Do not place
the unit close to a wall or other surfaces where the airflow
will be restricted.
For safety reasons you must not direct the heat outlet
close to any vertical surfaces, as the heat generated can
cause certain materials to catch fire.
The heater should not be used in areas where there
is airborne dust, as this too can ignite.
For advice on the safety and suitability of this equipment
contact your local HSS Hire Shop.
There is a serious risk of personal injury if you do not
follow all instructions laid down in this guide.
The hirer has a responsibility to ensure that all necessary
risk assessments have been completed prior to the use
of this equipment.
This equipment should only be used by an operator
who has been deemed competent to do so by
his/her employer.
This equipment should be used by an able bodied,
competent adult who has read and understood these
instructions. Anyone with either a temporary or permanent
disability, should seek expert advice before using it.
Keep children, animals and bystanders away from
the work area. Cordon off a NO GO area using either
cones, barriers or tape, available for hire from your local
HSS Hire Shop.
Never use this equipment if you are ill,
feeling tired, or under the influence of
alcohol or drugs.
Wear practical, protective clothing, gloves and
footwear. Avoid loose garments and jewellery that could
catch in moving parts, tie back long hair.
Never place anything on top of a heater and never
obstruct its air vents.
Never lift or move this equipment by its power
supply cable.
Always switch OFF and unplug the equipment when
not in use.
Ensure the work area is well lit and ventilated, if in
doubt, ask about lighting and ventilation equipment at
your local HSS Hire Shop.
Do not operate the heater near flammable gases or
liquids, petrol or paint thinner fumes for example. Keep
combustible materials at a safe distance - at least 5m.
Make sure you know how to switch this machine
OFF before you switch it ON in case you get into
difficulty.
Always disconnect the machine from its power
supply before making adjustments to it. Never leave it
switched ON and unattended.
Having switched OFF, always wait for the unit to cool
down before handling it (see Getting Started).
Make sure that everyone is warned of what you are
doing.
Check the condition of the equipment before use. If
it shows signs of damage or excessive wear, return it to
your local HSS Hire Shop.
Ensure the machine and power socket are switched
OFF before plugging into the power supply.
This model of heater is designed to be run from a
GENERAL SAFETY
GETTING STARTED
ELECTRICAL SAFETY
Ensure that there is adequate fresh air ventilating
into the room, by opening one or two small windows.
Model 1…
This heater has a four position switch, ‘0’ for OFF, ‘1’
for fan only, ‘2’ for 6kW heat output and ‘3’ for 9 kW
heat output.
Having double-checked that the heater switch is set to the
‘0’ (OFF position), plug the heater into its power
supply and switch the supply ON.
Model 2…
Power
Supply
Cable
Air
Intake
Air
Outlet
Model 1
Position 0
Position 1 Position 2
Position 3
Model 2
Lifting Handle
Air Intake
Air
Outlet
Castors
1
0
2
Fan Only
