Huawei ETS-2 User manual

HUAWEI ETS-2 FC612E
3G GSM Cordless Phone
USER GUIDE

1
The product described in this manual may include copyrighted software of
Huawei Technologies Co., Ltd. and possible licensors. Customers shall not
in any manner reproduce, distribute, modify, decompile, disassemble,
decrypt, extract, reverse engineer, lease, assign, or sublicense the said
software, unless such restrictions are prohibited by applicable laws or such
actions are approved by respective copyright holders under licenses.
Trademarks and Permissions
, , and are trademarks or registered trademarks of
Huawei Technologies Co., Ltd.
Other trademarks, product, service and company names mentioned are
the property of their respective owners.
Notice
Some features of the product and its accessories described herein rely on
the software installed, capacities and settings of local network, and may
not be activated or may be limited by local network operators or network
service providers, thus the descriptions herein may not exactly match the
product or its accessories you purchase.
Huawei Technologies Co., Ltd. reserves the right to change or modify any
information or specifications contained in this manual without prior notice
or obligation.
NO WARRANTY
THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT
AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY
KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED
TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION
TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO
CASE SHALL HUAWEI TECHNOLOGIES CO., LTD. BE LIABLE FOR
ANY SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL
DAMAGES, OR LOST PROFITS, BUSINESS, REVENUE, DATA,
GOODWILL OR ANTICIPATED SAVINGS.
Copyright © Huawei Technologies Co., Ltd. 2016. All rights reserved.
No part of this document may be reproduced or transmitted in any form
or by any means without prior written consent of Huawei Technologies
Co., Ltd.

2
Import and Export Regulations
Customers shall comply with all applicable export or import laws and
regulations and will obtain all necessary governmental permits and
licenses in order to export, re-export or import the product mentioned in
this manual including the software and technical data therein.
Getting Started
Front View
Note：
The following figure shows the front view of your phone and
is provided for your reference only.
1
2
3
4
5
6
7
8
9
10
11
12
13
14

3
No.
Description
No.
Description
1 Earpiece 2 Screen
3 Right soft key 4 Clear key
5 End key 6 #key
7 Microphone 8 Charger jack
9 *key 10 Number keys
11 Call key 12 Profile key
13 Left soft key 14 Navigation keys
Keys
Press ... To …
Right soft key
Select the option displayed in the lower right
corner of the screen.
Clear key
Delete the character to the left of the cursor.
End key
End or reject a call.
Power on or off the phone (by pressing and
holding the key).
Return to the standby screen.

4
Press ... To …
Number keys
Enter digits or characters (by pressing the
0–9keys).
Speed-dial phone numbers in standby
mode (by pressing and holding the 2–9
keys).
Call the voicemail in standby mode (by
pressing and holding the 1key).
Call key
Dial a number or answer a call.
View the call log in standby mode.
Profile key
Access Profiles in standby mode.
Left soft key
Select the option displayed in the lower left
corner of the screen.
Navigation
keys
Access the functions for which shortcuts
are predefined in standby mode.
Adjust the volume during a call.
Access the main menu in standby mode
(by pressing the OK key).
Switch between the hands-free mode and
the hand-held mode during a call (by
pressing the OK key).

5
Installing the SIM Card and the Battery
When installing the subscriber identity module (SIM) card,
ensure that the golden contact area on the SIM card is facing
downward and that the beveled edge of the SIM card is
properly aligned with that of the SIM card slot. Contact your
service provider to check whether the SIM card is required on
the phone.
Charging the Battery
You can use either of the following methods as required to
charge the battery:
Method 1: Method 2:
Note：
If the phone is not going to be used for a long time,
remove the battery from the phone.
If the battery has not been used for a long time, or if the
battery power has been used up, the phone will not
display anything on the screen. The phone can be
powered on and used only after the battery is charged
for some time.

6
Screen Icons
Icon Indicates … Icon Indicates …
Signal strength. Battery power level.
A call is being set
up or there is an
ongoing call. An alarm is enabled.
Unread text
messages.
Unread multimedia
messages.
Unread voice
messages.
The Normal profile is
enabled.
/2G network. 3G network.
Line 2. /
All calls will be
forwarded.
Line 1/2.
Accessing a Function Menu
To access a function menu, do as follows:
1. In standby mode, press to access the main
menu.
2. Press the navigation keys to select a function menu.
3. Press to access the selected menu.
4. Press the up or down navigation key to select a submenu,
and then press to access the selected submenu.
5. Press to return to the upper-level menu or exit
the function menu.
6. Press to return to the standby screen.

7
Voice Services
Making a Call
Making a Call Directly
To make a call, do as follows:
1. In standby mode, press the number keys to enter a phone
number.
2. Press to dial the number.
3. Press to end the call or cancel the dialing.
Making a Call from Contacts
To make a call from Contacts, do as follows:
1. In standby mode, select Menu > Contacts.
2. Find the desired contact, and then press to dial
the number.
Note：
In Contacts, you can also create, search for, or delete a
contact.
Making a Call from the Call Log
To make a call from the call log, do as follows:
1. In standby mode, select Menu > Calls or press
to display the missed calls, received calls, and dialed
numbers.
2. Find the desired number, and then press to dial
the number.
Answering or Rejecting a Call
When there is an incoming call, you can press to

8
answer the call; press to mute the ringtone; press
to reject the call.
Messaging
Creating a Message
To create a message, do as follows:
1. Select Menu > Messaging > Create message.
2. When writing a message, do as follows:
Press the down navigation key to insert pictures, video
clips, recorded audio clips, or other audio clips into the
message.
Select Options to perform operations available in the
menu.
3. Press the OK key to enter the numbers of recipients.
4. Press the OK key to send the message.
Reading a Message
Inbox stores the received messages. To read a message, do
as follows:
1. Select Menu > Messaging > Inbox.
2. Press the up or down navigation key to view the message
list.
3. Press the OK key to read the selected message.
4. Select Options to reply to, forward, or delete the message
or call the message sender.

9
Entering Text
Note：
Press the *key to switch between the text entry modes.
In ABC, Abc, or abc mode, you can press and hold the
*key to enable or disable the T9 mode.
Press the #key to display the symbol list, and then you
can select and enter different symbols. Press and hold
the #key to change the input language.
In the editing state, you can press to delete the
character to the left of the cursor.
In Abc, ABC, or abc mode, you can press the 0key to
enter a space.
In Abc, ABC, or abc mode, you can press the 1key
consecutively to enter a commonly used symbol.
Entering Text in T9 Mode
In T9 mode, you can enter an English word as follows:
1. Press each number key only once according to the
spelling sequence of the desired word.
Then the phone displays the candidate words that contain
the entered letters.
2. Press the up or down navigation key to select the desired
word.
3. Press the left or right navigation key to confirm the
selection and enter the word.
You can also press the 0key to confirm the selection and
enter the word followed by a space.
Entering Text in ABC, Abc or abc Mode
In Abc, ABC or abc mode, you can press the number key
labeled with the desired letter or digit consecutively until the

10
desired letter or digit appears on the display. If the letter you
want to enter is on the same key as the previous letter, enter
the letter after the cursor appears again.
Entering a Digit
In 123 mode, directly press the number key labeled with the
desired digit.
Network Mode
Switching Between Network Modes
To switch between network modes, do as follows:
1. Select Menu > Settings > Network > Mode.
2. Press the up or down navigation key to set the network
mode as required.
3. Press to save the settings.
Music
To play music, do as follows:
Select Menu > Music to access the music list, and then select
the music you want to play.
During music playing, do as follows:
Press the navigation keys to perform relevant operations
according to the icons on the screen.
Select Options to perform operations as required.

11
Calendar
To view the calendar, do as follows:
1. Select Menu > Calendar, and then scroll to the desired
date.
2. Do as follows:
Press the OK key to view the corresponding schedule of
the date.
Select Options to add a reminder, jump to a specified
date, view undue reminders, search for a schedule, or set
the display mode.
Alarms
To enable an alarm, do as follows:
1. Select Menu > Tools > Alarms.
2. Select the desired alarm in the existing list, and then press
the OK key to set the alarm.
3. Press to save the settings.
Browser
Select Menu > Browser to perform operations as required. The
browser on your phone allows you to access various Internet
services conveniently.
Security Settings
Phone Lock
The phone lock can protect your phone against unauthorized

12
use. By default, the phone lock is disabled. You can change the
default phone lock code (0000) to a number of one to eight
digits.
If the phone lock is enabled, the phone prompts you to enter
the phone lock code each time you power on the phone. In this
case, you need to enter the correct phone lock code to use the
phone.
PIN and PUK
The personal identification number (PIN) can protect your SIM
card against unauthorized use. The PIN unblocking Key (PUK)
is used to unlock the blocked PIN. If you enter wrong PINs
consecutively for specified times, the SIM card is blocked. In
this case, you need to enter the PUK to unblock the SIM card.
The PIN and the PUK are provided with your SIM card. For
details, contact your service provider.
Keypad Lock
In standby mode, press and hold the *key to lock the keypad. If
the keypad is locked, unlock the keypad first. Otherwise, you
can only dial emergency numbers and answer incoming calls.
In standby mode, press the OK key and then the *key to
unlock the keypad.
Warnings and Precautions
This section contains important information pertaining to the
operating instructions of your device. It also contains
information about how to use the device safely. Read this
information carefully before using your device.
Electronic Device
Power off your device if using the device is prohibited. Do not
use the device when using the device causes danger or

13
interference with electronic devices.
Medical Device
Follow rules and regulations set forth by hospitals and health
care facilities. Do not use your device when using the device
is prohibited.
Pacemaker manufacturers recommend that a minimum
distance of 15 cm be maintained between a device and a
pacemaker to prevent potential interference with the
pacemaker. If you are using a pacemaker, use the device on
the opposite side of the pacemaker and do not carry the
device in your front pocket.
Potentially Explosive Atmosphere
Power off your device in any area with a potentially explosive
atmosphere, and comply with all signs and instructions. Areas
that may have potentially explosive atmospheres include the
areas where you would normally be advised to turn off your
vehicle engine. Triggering of sparks in such areas could cause
an explosion or a fire, resulting in bodily injuries or even deaths.
Do not power on your device at refueling points such as service
stations. Comply with restrictions on the use of radio equipment
in fuel depots, storage, and distribution areas, and chemical
plants. In addition, adhere to restrictions in areas where
blasting operations are in progress. Before using the device,
watch out for areas that have potentially explosive
atmospheres that are often, but not always, clearly marked.
Such locations include areas below the deck on boats,
chemical transfer or storage facilities, and areas where the air
contains chemicals or particles such as grain, dust, or metal
powders. Ask the manufacturers of vehicles using liquefied
petroleum gas (such as propane or butane) whether this device
can be safely used in their vicinity.
Traffic Security
Observe local laws and regulations while using the device. In

14
addition, if using the device while driving a vehicle, comply with
the following guidelines:
Concentrate on driving. Your first responsibility is to drive
safely.
Do not talk on the device while driving. Use hands-free
accessories.
When you have to make or answer a call, park the vehicle at
the road side before using your device.
RF signals may affect electronic systems of motor vehicles.
For more information, consult the vehicle manufacturer.
In a motor vehicle, do not place the device over the air bag
or in the air bag deployment area. Otherwise, the device
may hurt you owing to the strong force when the air bag
inflates.
Do not use your device while flying in an aircraft. Power off
your device before boarding an aircraft. Using wireless
devices in an aircraft may cause danger to the operation of
the aircraft and disrupt the wireless telephone network. It
may also be considered illegal.
Operating Environment
Do not use or charge the device in dusty, damp, and dirty
places or places with magnetic fields. Otherwise, it may
result in a malfunction of the circuit.
The device complies with the RF specifications when the
device is used near your ear or at a distance of 1.5 cm from
your body. Ensure that the device accessories such as a
device case and a device holster are not composed of metal
components. Keep your device 1.5 cm away from your body
to meet the requirement earlier mentioned.
On a stormy day with thunder, do not use your device when
it is being charged, to prevent any danger caused by
lightning.

15
When you are on a call, do not touch the antenna. Touching
the antenna affects the call quality and results in increase in
power consumption. As a result, the talk time and the
standby time are reduced.
While using the device, observe the local laws and
regulations, and respect others' privacy and legal rights.
Keep the ambient temperature between 0°C and 45°C while
the device is being charged. Keep the ambient temperature
between -10°C to 55°C for using the device powered by a
battery.
Prevention of Hearing Damage
Using a headset at high volume can damage your hearing. To
reduce the risk of damage to hearing, lower the headset
volume to a safe and comfortable level.
Safety of Children
Comply with all precautions with regard to children's safety.
Letting the child play with your device or its accessories, which
may include parts that can be detached from the device, may
be dangerous, as it may present a choking hazard. Ensure that
small children are kept away from the device and accessories.
Accessories
Use the accessories delivered only by the manufacturer. Using
accessories of other manufacturers or vendors with this device
model may invalidate any approval or warranty applicable to
the device, result in the non-operation of the device, and cause
danger.
Battery and Charger
Unplug the charger from the electrical plug and the device
when not in use.
The battery can be charged and discharged hundreds of
times before it eventually wears out. When the standby time

16
and the talk time are shorter than the normal time, replace
the battery.
Use the AC power supply defined in the specifications of the
charger. An improper power voltage may cause a fire or a
malfunction of the charger.
Do not connect two poles of the battery with conductors,
such as metal materials, keys, or jewelries. Otherwise, the
battery may be short-circuited and may cause injuries and
burns on your body.
Do not disassemble the battery or solder the battery poles.
Otherwise, it may lead to electrolyte leakage, overheating,
fire, or explosion.
If battery electrolyte leaks out, ensure that the electrolyte
does not touch your skin and eyes. When the electrolyte
touches your skin or splashes into your eyes, wash your
eyes with clean water immediately and consult a doctor.
If there is a case of battery deformation, color change, or
abnormal heating while you charge or store the battery,
remove the battery immediately and stop using it. Otherwise,
it may lead to battery leakage, overheating, explosion, or
fire.
If the power cable is damaged (for example, the cord is
exposed or broken), or the plug loosens, stop using the
cable at once. Otherwise, it may lead to an electric shock, a
short circuit of the charger, or a fire.
Do not dispose of batteries in fire as they may explode.
Batteries may also explode if damaged.
Danger of explosion if battery is incorrectly replaced.
Recycle or dispose of used batteries according to the local
regulations or reference instruction supplied with your
device.

17
Cleaning and Maintenance
The device, battery, and charger are not water-resistant.
Keep them dry. Protect the device, battery, and charger from
water or vapor. Do not touch the device or the charger with a
wet hand. Otherwise, it may lead to a short circuit, a
malfunction of the device, and an electric shock to the user.
Do not place your device, battery, and charger in places
where they can get damaged because of collision.
Otherwise, it may lead to battery leakage, device
malfunction, overheating, fire, or explosion.
Do not place magnetic storage media such as magnetic
cards and floppy disks near the device. Radiation from the
device may erase the information stored on them.
Do not leave your device, battery, and charger in a place
with an extreme high or low temperature. Otherwise, they
may not function properly and may lead to a fire or an
explosion. When the temperature is lower than 0°C,
performance of the battery is affected.
Do not place sharp metal objects such as pins near the
earpiece. The earpiece may attract these objects and hurt
you when you are using the device.
Before you clean or maintain the device, power off the
device and disconnect it from the charger.
Do not use any chemical detergent, powder, or other
chemical agents (such as alcohol and benzene) to clean the
device and the charger. Otherwise, parts of the device may
be damaged or a fire can be caused. You can clean the
device and the charger with a piece of damp and soft
antistatic cloth.
Do not dismantle the device or accessories. Otherwise, the
warranty on the device and accessories is invalid and the
manufacturer is not liable to pay for the damage.

18
Emergency Call
You can use your device for emergency calls in the service
area. The connection, however, cannot be guaranteed in all
conditions. You should not rely solely on the device for
essential communications.
Certification Information (SAR)
This device meets guidelines for exposure to radio waves.
Your device is a low-power radio transmitter and receiver. As
recommended by international guidelines, the device is
designed not to exceed the limits for exposure to radio waves.
These guidelines were developed by the independent scientific
organization International Commission on Non-Ionizing
Radiation Protection (ICNIRP) and include safety measures
designed to ensure safety for all users, regardless of age and
health.
The Specific Absorption Rate (SAR) is the unit of measurement
for the amount of radio frequency energy absorbed by the body
when using a device. The SAR value is determined at the
highest certified power level in laboratory conditions, but the
actual SAR level of the device when being operated can be well
below the value. This is because the device is designed to use
the minimum power required to reach the network.
The SAR limit adopted by USA and Canada is 1.6
watts/kilogram (W/kg) averaged over one gram of tissue. The
highest SAR value reported to the FCC and IC for this device
type when tested for use at the ear is 1.12 W/kg, and when
properly worn on the body is 0.651 W/kg.
The SAR limit also adopted by Europe is 2.0 W/kg averaged
over 10 grams of tissue. The highest SAR value for this device
type when tested at the ear is 0.792 W/kg, and when properly
worn on the body is 0.452 W/kg.

19
Disposal and Recycling Information
This symbol (or without a solid bar) on the device,
and/or on its packaging, and on its batteries where
included, indicates that the device including its
electrical accessories (e.g. headset, adapter,
cable) and the batteries should not be disposed of
as normal household garbage. These items should
not be disposed as unsorted municipal waste and
should be handed over to a certified collection point for
recycling or proper disposal at the end of their life.
For more detailed information about the recycling of the device
or batteries, please contact your local city office, the household
waste disposal service, or the retail store where you purchased
it/them.
Disposal of the device and batteries if included is subject to
WEEE Directive Recast (Directive 2012/19/EU) and Battery
Directive (Directive 2006/66/EC). The purpose for separating
WEEE and batteries from other waste is to minimize the
potential environmental impacts on human health of any
hazardous substances that may be present.
Reduction of Hazardous Substances
This device is compliant with the REACH Regulation
[Regulation (EC) No 1907/2006] and RoHS Directive Recast
(Directive 2011/65/EU). Batteries where included are compliant
with Battery Directive (Directive 2006/66/EC). For more
information about the REACH and RoHS compliance of the
device, please visit the Web site
www.huaweidevice.com/certification. You are
recommended to visit the Web site regularly for up-to-date
information.
EU Regulatory Conformance
Hereby, Huawei Technologies Co., Ltd. declares that this
device is in compliance with the essential requirements and
