Huawei ETS8221 User manual

ETS8221
Cordless Phone

Copyright © Huawei Technologies Co., Ltd. 2009. All rights reserved.
No part of this document may be reproduced or transmitted in any form or
by any means without prior written consent of Huawei Technologies Co.,
Ltd.
The product described in this manual may include copyrighted software of
Huawei Technologies Co., Ltd and possible licensors. Customers shall not
in any manner reproduce, distribute, modify, decompile, disassemble,
decrypt, extract, reverse engineer, lease, assign, or sublicense the said
software, unless such restrictions are prohibited by applicable laws or such
actions are approved by respective copyright holders under licenses.
Trademarks and Permissions
, HUAWEI, and are trademarks or registered trademarks
of Huawei Technologies Co., Ltd.
Other trademarks, product, service and company names mentioned are
the property of their respective owners.
Notice
Some features of the product and its accessories described herein rely on
the software installed, capacities and settings of local network, and may
not be activated or may be limited by local network operators or network
service providers, thus the descriptions herein may not exactly match the
product or its accessories you purchase.
Huawei Technologies Co., Ltd reserves the right to change or modify any
information or specifications contained in this manual without prior notice
or obligation.
NO WARRANTY
THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT AS REQUIRED
BY APPLICABLE LAWS, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR
IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN
RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO CASE SHALL
HUAWEI TECHNOLOGIES CO., LTD BE LIABLE FOR ANY SPECIAL, INCIDENTAL,
INDIRECT, OR CONSEQUENTIAL DAMAGES, OR LOST PROFITS, BUSINESS,
REVENUE, DATA, GOODWILL OR ANTICIPATED SAVINGS.
Import and Export Regulations
Customers shall comply with all applicable export or import laws and
regulations and will obtain all necessary governmental permits and
licenses in order to export, re-export or import the product mentioned in
this manual including the software and technical data therein.

1
Your Cordless Phone
Earpiece
#Key
Key
End/Power Key
Microphone
Number Keys
Left Soft Key
Call Key
Screen
RightSoftKey
Navigation Key
Charger Interface
Note:
This is a sketch. Your cordless phone may be
different. It is subject to your actual one.

2
Keys and Functions
Press… To…
zView the dialed calls in the standby mode.
zMake or answer a call.
zPower on or off the cordless phone by pressing
and holding it in the standby mode.
zEnd a call or reject an incoming call.
zReturn to the home screen.
Select the option displayed on the lower left corner
of the screen.
Select the option displayed on the lower right
corner of the screen.
zIn the standby mode, press Navigation key to
access the shortcut screen.
zDuring a call, press Left or Right key to adjust
the volume of the earpiece,.
zIn the standby mode, press OK key to access
the main menu.
Number
Keys
zEnter numbers and characters.
zSpeed-dial cordless phone numbers in the
standby mode (by pressing and holding the 1-9
keys).
zSelect a submenu item labeled with the
corresponding number.
*key
Perform different operations for different functions
of the cordless phone.
#key Perform different operations for different functions
of the cordless phone.

3
Screen Icons
Icon Description Icon Description
Network signal strength Battery power level
Calling Alarm clock is on
zMessage received
zMemory for messages
is full, when the icon is
blinking
Keypad is locked
Remind by sound
Menu Tree
Phone Book Messages Call History
1. Search
2. Add New
3. Groups
4. Speed Dial
5. Delete All
6. My Phone Num
7. Memory Status
1. Write
Message
2. Inbox
3. Outbox
4. Draft
5. Voice Mail
6. Message
Settings
7. Delete All
1. Missed Calls
2. Received
Calls
3. Dialed Calls
4. Call Duration
5. Delete All
Fun&Utility Profiles Settings
1. Alarm
2. Schedule
3. Calculator
4. Stopwatch
5. World Clock
6. Line Game
7. Smash Game
1. General
2. Outdoor
3. Quiet
1. Display
2. Call Settings
3. Phone
Settings
4. Security

4
Installing the UIM Card（Optional）and Battery
Consult the network operator if a UIM card is needed.
Make sure that the golden area on the UIM card is facing
downwards and the cut-off edge is correctly fit to that of the
card holder.
Charging the Battery
1. Connect the cordless phone to the charger stand.
2. Connect one power adapter connector to the charger stand.
3. Connect the charger to an AC power socket. During the
charging, the animation of charging icon is displayed.
4. When the charging icon becomes static, the cordless phone
is fully charged.
5. When the cordless phone is fully charged, disconnect the
charger from the AC power socket first. Then disconnect the
charger stand from the charger.
Note:
zRemove the battery if the cordless phone is left
unused for a long period.
zIf the battery has not been used for a long time or
the battery is exhausted, the screen of the
cordless phone may not function when you charge
the battery again. This is normal. After the battery
is being charged for a while, you can power on the
cordless phone for use.

5
Using the Function Menu
1. In the standby mode, press to display the Menu
interface.
2. Press Up or Down key to scroll in the menu.
3. Press to display the menu.
4. Display the submenu in either of the ways:
zPress Up or Down key to scroll to a submenu item and
press to select the submenu.
zPress the Number key corresponding to the number of a
submenu to select it.
5. Press to return to the previous menu or return to the
home screen.
6. Press to return to the home screen.
Making a Call
1. In the standby mode, enter a phone number.
2. Press to dial the number.
3. Press to end the call.
Note:
zWhen the cordless phone is locked, enter the lock
code to unlock the cordless phone first; otherwise,
you can only make emergency calls or answer
calls.
zIn the standby mode, press to view the
dialed calls. Select a record and press to
dial this number.

6
zSelect a contact from the cordless phonebook and
press to call this contact.
Answering a Call
When there is an incoming call, you can press or
to answer it, or press to reject it.
If the any-key answer function is enabled, you can press any
key except and to answer an incoming call.
Cordless phone Lock
The cordless phone lock protects your cordless phone from
unauthorized use. The default cordless phone lock code is
000000. You can change it into any numeric string of 4 to 8
digits.
If the cordless phone lock is enabled, you need to enter the
correct cordless phone lock code when you power on the
cordless phone.
PIN and PUK
The personal identity number (PIN) protects your UIM card
from unauthorized use. The PIN unblocking key (PUK) can
unblock the blocked PIN. Both the PIN and PUK are delivered
with the UIM card. For details, consult your service provider.
If you enter wrong PINs three times consecutively, the cordless
phone asks you to enter the PUK code.
If you enter wrong PUKs ten times, the UIM card is invalidated
permanently. Contact your service provider for a new card.
Locking the Keypad
In the standby mode, press and hold #key to lock the keypad.

7
In the standby mode, press and *key to unlock the
keypad.
When the keyguard function is enabled, if there is no operation
on the cordless phone for a preset period, the keypad is locked
automatically.
Changing the Text Input Modes
The indicator of the current text input mode is displayed on the
screen. In the editing mode, press #key to change the input
mode.
Note:
zIn the editing mode, press once to delete the
letter on the left of the cursor. Press and hold
to delete all the entered letters.
zIn the "eZiEn" input mode, press to enter a
space. In the "ABC" or "abc" input mode, press
once to enter a space, twice to enter "0", and
three times to move the cursor to the next line.
zIn the "ABC" or "abc" input mode, press
repeatedly to select and enter the commonly used
punctuations. In the "eZiEn" input mode, press
repeatedly to enter a full stop.
Entering English (eZiEn)
In the "eZiEn" input mode, do the follows to enter the English
letters:
1. Press each desired key once corresponding to the
sequence of the word. Then the cordless phone displays the
commonly used words according to the numeric sequence
of key presses.
2. Press Up or Down key to scroll to the desired word.

8
3. Press Left or Right key to select the word.
Press to enter the word and a space.
Entering English (ABC or abc)
In the "ABC" or "abc" input mode, you can press a key labeled
with the desired letters once to enter the first letter on the key,
twice to enter the second letter on the key, and so on.
Note:
If the letter you want to enter is on the same key as
the previous one, you can enter the latter one only
after the cursor appears again or after you press the
Right key to move the cursor to the next space.
Entering Numbers
zIn the "123" input mode, press a key labeled with the desired
number.
zIn the "ABC" or "abc" input mode, press a key continuously
or press and hold it until the desired number appears on the
screen.
zIn the "eZiEn" input mode, press a key and then press the
Down key to select desired number.
Entering Symbols
1. In any input mode, press *key to display a symbol list.
2. Press Up or Down Key to select the desired symbol.
3. Press the corresponding number key to enter the symbol.
Warnings and Precautions
This section contains important information pertaining to the
operating instructions of your device. It also contains
information about how to use the device safely. Read this
information carefully before using your device.

9
Electronic Device
Power off your device if using the device is prohibited. Do not
use the device when using the device causes danger or
interference with electronic devices.
Medical Device
zFollow rules and regulations set forth by hospitals and health
care facilities. Do not use your device when using the device
is prohibited.
zPacemaker manufacturers recommend that a minimum
distance of 15 cm be maintained between a device and a
pacemaker to prevent potential interference with the
pacemaker. If you are using a pacemaker, use the device on
the opposite side of the pacemaker and do not carry the
device in your front pocket.
zSome wireless devices may affect the performance of
hearing aids. For any such problems, consult your service
provider.
Potentially Explosive Atmosphere
Power off your device in any area with a potentially explosive
atmosphere, and comply with all signs and instructions. Areas
that may have potentially explosive atmospheres include the
areas where you would normally be advised to turn off your
vehicle engine. Triggering of sparks in such areas could cause
an explosion or a fire, resulting in bodily injuries or even deaths.
Do not power on your device at refueling points such as service
stations. Comply with restrictions on the use of radio equipment
in fuel depots, storage, and distribution areas, and chemical
plants. In addition, adhere to restrictions in areas where
blasting operations are in progress. Before using the device,
watch out for areas that have potentially explosive
atmospheres that are often, but not always, clearly marked.
Such locations include areas below the deck on boats,
chemical transfer or storage facilities, and areas where the air

10
contains chemicals or particles such as grain, dust, or metal
powders. Ask the manufacturers of vehicles using liquefied
petroleum gas (such as propane or butane) whether this device
can be safely used in their vicinity.
Traffic Security
Observe local laws and regulations while using the device. In
addition, if using the device while driving a vehicle, comply with
the following guidelines:
zConcentrate on driving. Your first responsibility is to drive
safely.
zDo not talk on the device while driving. Use hands-free
accessories.
zWhen you have to make or answer a call, park the vehicle at
the road side before using your device.
zRF signals may affect electronic systems of motor vehicles.
For more information, consult the vehicle manufacturer.
zIn a motor vehicle, do not place the device over the air bag
or in the air bag deployment area. Otherwise, the device
may hurt you owing to the strong force when the air bag
inflates.
zDo not use your device while flying in an aircraft. Power off
your device before boarding an aircraft. Using wireless
devices in an aircraft may cause danger to the operation of
the aircraft and disrupt the wireless telephone network. It
may also be considered illegal.
Operating Environment
zDo not use or charge the device in dusty, damp, and dirty
places or places with magnetic fields. Otherwise, it may
result in a malfunction of the circuit.
zThe device complies with the RF specifications when the
device is used near your ear or at a distance of 1.5 cm from
your body. Ensure that the device accessories such as a
device case and a device holster are not composed of metal

11
components. Keep your device 1.5 cm away from your body
to meet the requirement earlier mentioned.
zOn a stormy day with thunder, do not use your device when
it is being charged, to prevent any danger caused by
lightning.
zWhen you are on a call, do not touch the antenna. Touching
the antenna affects the call quality and results in increase in
power consumption. As a result, the talk time and the
standby time are reduced.
zWhile using the device, observe the local laws and
regulations, and respect others' privacy and legal rights.
zKeep the ambient temperature between 0°C and 45°C while
the device is being charged. Keep the ambient temperature
between -10°C to 55°C for using the device powered by a
battery.
Safety of Children
Comply with all precautions with regard to children's safety.
Letting the child play with your device or its accessories, which
may include parts that can be detached from the device, may
be dangerous, as it may present a choking hazard. Ensure that
small children are kept away from the device and accessories.
Accessories
Use the accessories delivered only by the manufacturer. Using
accessories of other manufacturers or vendors with this device
model may invalidate any approval or warranty applicable to
the device, result in the non-operation of the device, and cause
danger.
Battery and Charger
zUnplug the charger from the electrical plug and the device
when not in use.
zThe battery can be charged and discharged hundreds of
times before it eventually wears out. When the standby time

12
and the talk time are shorter than the normal time, replace
the battery.
zUse the AC power supply defined in the specifications of the
charger. An improper power voltage may cause a fire or a
malfunction of the charger.
zDo not connect two poles of the battery with conductors,
such as metal materials, keys, or jewelries. Otherwise, the
battery may be short-circuited and may cause injuries and
burns on your body.
zDo not disassemble the battery or solder the battery poles.
Otherwise, it may lead to electrolyte leakage, overheating,
fire, or explosion.
zIf battery electrolyte leaks out, ensure that the electrolyte
does not touch your skin and eyes. When the electrolyte
touches your skin or splashes into your eyes, wash your
eyes with clean water immediately and consult a doctor.
zIf there is a case of battery deformation, color change, or
abnormal heating while you charge or store the battery,
remove the battery immediately and stop using it. Otherwise,
it may lead to battery leakage, overheating, explosion, or
fire.
zIf the power cable is damaged (for example, the cord is
exposed or broken), or the plug loosens, stop using the
cable at once. Otherwise, it may lead to an electric shock, a
short circuit of the charger, or a fire.
zDo not dispose of batteries in fire as they may explode.
Batteries may also explode if damaged.
Cleaning and Maintenance
zThe device, battery, and charger are not water-resistant.
Keep them dry. Protect the device, battery, and charger from
water or vapor. Do not touch the device or the charger with a
wet hand. Otherwise, it may lead to a short circuit, a
malfunction of the device, and an electric shock to the user.

13
zDo not place your device, battery, and charger in places
where they can get damaged because of collision.
Otherwise, it may lead to battery leakage, device
malfunction, overheating, fire, or explosion.
zDo not place magnetic storage media such as magnetic
cards and floppy disks near the device. Radiation from the
device may erase the information stored on them.
zDo not leave your device, battery, and charger in a place
with an extreme high or low temperature. Otherwise, they
may not function properly and may lead to a fire or an
explosion. When the temperature is lower than 0°C,
performance of the battery is affected.
zDo not place sharp metal objects such as pins near the
earpiece. The earpiece may attract these objects and hurt
you when you are using the device.
zBefore you clean or maintain the device, power off the
device and disconnect it from the charger.
zDo not use any chemical detergent, powder, or other
chemical agents (such as alcohol and benzene) to clean the
device and the charger. Otherwise, parts of the device may
be damaged or a fire can be caused. You can clean the
device and the charger with a piece of damp and soft
antistatic cloth.
zDo not dismantle the device or accessories. Otherwise, the
warranty on the device and accessories is invalid and the
manufacturer is not liable to pay for the damage.
Emergency Call
You can use your device for emergency calls in the service
area. The connection, however, can not be guaranteed in all
conditions. You should not rely solely on the device for
essential communications.

14
FCC Statement
This device has been tested and found to comply with Part 15
of the Federal Communications Commission (FCC) rules.
This device complies with Part 15 of the FCC rules. Operation
is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received,
including interference that may cause undesired operation.
Warning: Changes or modifications made to this device not
expressly approved by Huawei Technologies Co., Ltd. may void
the FCC authorization to operate this device.
Certification Information (SAR)
This mobile device meets guidelines for exposure to radio
waves.
Your device is a low-power radio transmitter and receiver. As
recommended by international guidelines, the mobile device is
designed not to exceed the limits for exposure to radio waves.
These guidelines were developed by the independent scientific
organization International Commission on Non-Ionizing
Radiation Protection (ICNIRP) and include safety measures
designed to ensure safety for all users, regardless of age and
health.
The Specific Absorption Rate (SAR) is the unit of measurement
for the amount of radio frequency energy absorbed by the body
when using a device. The SAR value is determined at the
highest certified power level in laboratory conditions, but the
actual SAR level of the device when being operated can be well
below the value. This is because the device is designed to use
the minimum power required to reach the network.
The SAR limit adopted by USA and Canada is 1.6
watts/kilogram (W/kg) averaged over one gram of tissue. The
highest SAR value reported to the FCC and IC for this device

15
type when tested for use at the ear is 0.832 W/kg, and when
properly worn on the body is 0.91 W/kg.
The SAR limit also adopted by Europe is 2.0 W/kg averaged
over 10 grams of tissue. The highest SAR value for this device
type when tested at the ear is 0.496 W/kg, and when properly
worn on the body is 0.659 W/kg.
Disposal and Recycling Information
This symbol on the device (and any included batteries)
indicates that they should not be disposed of as
normal household garbage. Do not dispose of
your device or batteries as unsorted municipal
waste. The device (and any batteries) should be
handed over to a certified collection point for
recycling or proper disposal at the end of their life.
For more detailed information about the recycling of the device
or batteries, contact your local city office, the household waste
disposal service, or the retail store where you purchased this
device.
The disposal of this device is subject to the Waste from
Electrical and Electronic Equipment (WEEE) directive of the
European Union. The reason for separating WEEE and
batteries from other waste is to minimize the potential
environmental impacts on human health of any hazardous
substances that may be present.
Reduction of Hazardous Substances
This device is compliant with the EU Registration, Evaluation,
Authorisation and Restriction of Chemicals (REACH)
Regulation (Regulation No 1907/2006/EC of the European
Parliament and of the Council) and the EU Restriction of
Hazardous Substances (RoHS) Directive (Directive
2002/95/EC of the European Parliament and of the Council).
For more information about the REACH compliance of the
device, visit the Web site www.huaweidevice.com/certification.

16
You are recommended to visit the Web site regularly for
up-to-date information.
EU Regulatory Conformance
Hereby, Huawei Technologies Co., Ltd. declares that this
device is in compliance with the essential requirements and
other relevant provisions of Directive 1999/5/EC.
For the declaration of conformity, visit the Web site
www.huaweidevice.com/certification.
0168
Notice: Observe the national local regulations in the location
where the device is to be used. This device may be restricted
Version: V100R001_01 Part Number: 31010ADQ
