Wonderful Communication, Mobile Life.
Welcome to HUAWEI ETS2528 Fixed Wireless Terminal.
HUAWEI ETS2528 Fixed Wireless Terminal
User Manual

Copyright © 2006 Huawei Technologies Co., Ltd.
All Rights Reserved
No part of this manual may be reproduced or transmitted in any form or by any
means without prior written consent of Huawei Technologies Co., Ltd.
Trademarks
And HUAWEI are trademarks of Huawei Technologies Co., Ltd. All other
trademarks and trade names mentioned in this manual are the property of their
respective holders.
Notice
The information in this manual is subject to change without notice. Every effort
has been made in the preparation of this manual to ensure accuracy of the contents,
but all statements, information, and recommendations in this manual do not
constitute the warranty of any kind, expressed or implied.
Output Power of the FWT: 250mW (24dBm)
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.

i
Table of Contents
1 Warnings and Precautions...................................................................................3
2 Introduction ........................................................................................................7
DOC document ............................................................................................7
Packing List..................................................................................................7
Appearance of the FWT ...............................................................................8
Icons...........................................................................................................11
3 Installation........................................................................................................12
Installing the UIM Card (Optional)............................................................12
Installing the Power Adapter or the Spare Battery .....................................13
Installing the Antenna ................................................................................14
Validating ...................................................................................................15
4 Basic Operations...............................................................................................16
Powering the FWT On or Off.....................................................................16
Making a Call.............................................................................................16
Answering a Call........................................................................................17
Locking the Keypad ...................................................................................17
5 Text Entry .........................................................................................................19
Text Input Mode.........................................................................................19
Entering English.........................................................................................19
6 Messages ..........................................................................................................21
Writing and Sending a Message .................................................................21
Viewing a Message ....................................................................................21
Deleting a Message ....................................................................................22
Voice Mail..................................................................................................22
Message Settings........................................................................................23
7 Phone Book ......................................................................................................25
Adding a Contact........................................................................................25

ii
Searching for a Contact..............................................................................25
Editing a Contact........................................................................................25
Deleting a Contact......................................................................................26
Copying a Contact......................................................................................26
Groups........................................................................................................27
Memory Status ...........................................................................................27
Saving My FWT Number...........................................................................27
8 Settings.............................................................................................................28
Call Settings ...............................................................................................28
Profile Settings...........................................................................................29
Operations During a Call............................................................................30
Security Settings ........................................................................................30
9 Fun & Utility ....................................................................................................32
10 Menu Commands ...........................................................................................33
11 Maintenance and Troubleshooting..................................................................35
Maintenance...............................................................................................35
Troubleshooting .........................................................................................35
12 Specifications .................................................................................................37

3
1 Warnings and Precautions
Before using HUAWEI Fixed Wireless Terminal (hereinafter referred to FWT),
please read the following cautions and let your children know these, so that you
can use your FWT correctly and safely.
Basic Cautions
According to the packing list, check items in the package box to make sure they
are complete and undamaged.
Before installing and using FWT, read the user manual carefully.
Electronic Device
Switch your FWT off near high-precision electronic devices. The FWT may
affect the performance of these devices.
Such devices include hearing aids, pacemakers, fire alarm systems, automatic
gates, and other automatic-control devices. If you are using an electronic medical
device, consult the device manufacturer and confirm whether the radio wave
affects the operation of this electronic device.
Hospital
Pay attention to the following points in hospitals or health care facilities:
yDo not take your FWT into the operating room (OR), intensive care unit (ICU), or
coronary care unit (CCU).
ySwitch your FWT off near medial devices.
yObserve any instructions wherever the use of wireless device is prohibited.
Traffic Safety
yDo not use your FWT while driving. Secure the FWT on its holder. Do not place the
FWT on the seat or other places where it can get loose in a sudden stop or collision.
yObserve the rules and regulations of airline companies. Switch your FWT off before
boarding an aircraft.

4
Operating Environment
yDo not place magnetic storage media such as magnetic cards and floppy disks near the
FWT. Radiation from the FWT may erase the information stored on them.
yDo not put your FWT, battery, or other accessories in containers with strong magnetic
field, such as the induction cooker and microwave oven. Otherwise, circuit failure, fire,
or explosion may result.
yDo not leave your FWT, battery, or power adapter in a high-temperature place or use
them in a place with flammable gas. Otherwise, malfunction of the products, fire, or
explosion may result.
yBecause FWT needs to eliminate heat during working, put the FWT and the power
supply in a ventilated and shadowy place. Never airproof the FWT or put something on it
or place it near water, fire as well as inflammable and explosive materials.
yBecause FWT contains precision devices, you should put it in a dry place and away from
moist materials.
yBefore cleaning FWT, please turn off the FWT, and then disconnect the power supply
and take out the battery. Before moving FWT, please disconnect the external power
supply
yDo not subject your FWT, battery, and power adapter to serious collision or shock.
Otherwise, battery leakage, FWT malfunction, overheats, fire, or explosion may result.
yDo not place sharp metal objects such as pins near the earpiece. The earpiece may attract
these objects and hurt you when you are using the FWT.
yDo not place the FWT in the area over the air bag or in the air bag deployment area.
Otherwise, the FWT may hurt you owing to the strong force when the air bag inflates.
yPut your FWT, battery, and power adapter in places beyond the reach of children. Do not
allow children to use the FWT, battery, or power adapter without guidance.
yDo not touch the antenna when a call is going on. Touching the antenna may affect call
quality and cause the FWT to operate at a power level higher than needed.
yThe network signal condition will directly affect the quality and stability of the call.
Consequently, you should place FWT in a place where it can receive network signal well.
Do not put FWT in a building with an iron or metal roof. The distance between FWT and
other metal materials (such as metal brackets or metal doors and windows) should be
greater than 25cm and the distance between FWTs should be greater than 30cm.
yDo not open the chassis in any case and the device should be maintained by a qualified
maintenance department.
yWithout permission, you are not allowed to modify the architecture and security design
of FWT. You must bear any consequence resulted from the operation without permission
yYour FWT is designed to conform to the authoritative international radio frequency (RF)
specifications. Use FWT accessories approved by Huawei only.
yThe antenna(s) used for this transmitter must be installed to provide a separation distance
of at least 20cm from all persons.
Emergency Call
You can use your FWT for emergency calls. However, connections in all
conditions cannot be guaranteed. You should never rely solely on the FWT for

Table 1-5 5
essential communications.
Battery
yIf the battery fluid gets into eyes, do not rub them. Wash with clean water and seek
medical assistance immediately.
yIf the battery fluid contacts skin or cloth, wash with clean water immediately to avoid
irritation to the skin.
yDo not dispose of the battery in fire. Otherwise, the battery may ignite or explode.
yWhen installing the battery on your FWT, do not push the battery by force lest battery
fluid leak out or the battery crack.
yDo not connect two poles of the battery with metallic materials such as cables.
yDo not disassemble the battery or solder the battery poles. Otherwise fluid leakage,
overheat, fire, or explosion may result.
yIf there is battery leakage, smoke, or strange smell, stop using the battery and keep it
away from open flame to avoid fire or explosion.
yDisconnect the power adapter and take out the spare battery when FWT is not used for a
long time.
yDo select its self-contained complete battery and power adapter, otherwise, FWT may be
spoiled. Dispose of used batteries according to the instructions
yDispose of the battery according to local laws or regulations.
Power Adapter
yUse AC power as specified for the power adapter. Any violation of this rule may result in
fire or malfunction of the power adapter.
yDo not short-circuit the power adapter. Short-circuiting the power adapter may cause fire
or malfunction of the power adapter.
yRemove the dust on the power plug regularly.
yDo not use worn-out power cords. Otherwise, electric shock, short-circuiting of the
power adapter, or fire may result.
yDo not put the power adapter near the container filled with liquid such as water. If the
liquid comes into the power adapter, electrical leakage or other faults may result.
yIf the liquid such as water comes into the power adapter accidentally, remove the plug of
the power adapter from the socket immediately.
yDisconnect the power adapter from the socket before cleaning or maintaining it.
Otherwise, electric shock or short-circuiting of the battery or power adapter may result.
yEnsure the plug of the power adapter is properly inserted into the power socket when
charging the battery. Improper insertion may result in electric shock, fire, or explosion.
yDo not place any heavy object on the power cord of the power adapter. Do not damage,
change, or pluck the power cord.
Environmental Protection
Please abide by the local laws in proposing of the package materials of your
handset, consumed batteries and used handsets, and try to recycle them.

6
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
yReorient or relocate the receiving antenna.
yIncrease the separation between the equipment and receiver.
yConnect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
yConsult the dealer or an experienced radio/ TV technician for help.

Table 1-5 7
2 Introduction
DOC document
Packing List
The FWT package box contains the following items. If any of the items is lost or
damaged, contact your local dealer.
Item Quantity Item Quanti
ty
Handle set, handset, and coiled handset
cord
1 Spare
battery
1
Power adapter 1 Antenna
(optional)
1
HUAWEI ETS2528 Fixed Wireless
Terminal User manual, Certificate of
Quality, and Warranty Card
1

8
Appearance of the FWT
Front View of the FWT
1
2
3
4
5
6
7
8
9
1011
12
13
No Item Description
1 Indoor antenna To receive signals.
2 Display To display information.
3
Left function key
yIn the standby mode, press it to access the home
screen.
yIn the non-standby mode, press it to perform the
operation displayed on the lower left corner of the
display.

Table 1-5 9
No Item Description
4
Scroll key
yUp key: In the standby mode, press it to view the
schedule.; during a call, press it to increase the
volume.
yDown key: In the standby mode, press it to set FM or
alarm clocks,; during a call, press it to decrease the
volume.
yLeft key: In the standby mode, press it to enter the
List of call..
yRight key: In the standby mode, press it to access the
Messages screen..
5
Right function key
yIn the standby mode, press it to access the Phone
Book screen.
yIn the non-standby mode, press it to perform the
operation displayed on the lower right corner of the
display.
6
OK key yIn the standby mode, press it to access the home
screen.
yIn the non-standby mode, press it to perform the
operation displayed on the lower left corner of the
display.
7
End key
yPress it to end a call or cancel the dialing.
yPress and hold it for two seconds to power your FTW
on or off.
yIn the non-standby mode, press it to return to the
standby mode.
8
Handfree key
In the standby mode, press it to make or answer a call
without lifting the handset.
9
Call/Redial key
yPress it to make or answer a call.
yIn the standby mode, press it to view the call history.

10
No Item Description
10
#key yIn the standby mode, press and hold it to lock the
FWT.
yPress it to perform corresponding operations of
functions.
11
*key yIn the standby mode, press and hold it to activate the
quiet profile.
yPress it to perform corresponding operations of
functions.
12 Number keys Press 0–9 keys to enter numbers/characters or speed
dial a phone number.
13 Handset Lift it to answer a call.
Back View of the FWT
1
2
3
4
56
7
9
8
10 11 12
No. Item Description
1 Indoor antenna To receive signals.
2 Hook To fix the FWT when installed vertically.
3 Battery case To house the spare battery.
4 Spare battery To supply the FWT with power.

Table 1-5 11
No. Item Description
5 Battery cord jack To connect to the battery cord.
6 Handset coiled cord jack
on the handle set To connect to the handset coiled cord.
7 Handset coiled cord To connect to the handset to the handle set.
8 Handset coiled cord jack
on the handset To connect to the handset coiled cord.
9 Handset To make a call or answer a call by lifting it.
10 DB9 serial port To maintain the FWT through it.
12 Power supply jack To connect to the power adapter for power supply.
Icons
Icon Description
Indicates the signal strength. The more the bars are, the
stronger the signal strength is.
Indicates there is a new message.
Indicates there is an outgoing call or a call is ongoing.
Indicates the alarm clock is activated.
Indicates the battery power level. The more the bars are, the
higher the power level is.
Indicates the FWT is powered by the power adapter.

12
3 Installation
Installing the UIM Card (Optional)
Caution:
yWhether a user identity module (UIM) card is needed depends on your service
provider. Consult your service provider for details.
yThe UIM card and its golden contact can be easily damaged by scratch or
bending. Be careful when installing or removing the UIM card.
Press and hold to power your FWT off and then disconnect it from the power
socket. Install the UIM card according to the following figure. Make sure that the
golden contact of the UIM card is facing downwards.

Table 1-5 13
Installing the Power Adapter or the Spare Battery
Note:
yThe FWT can be powered by the power adapter or the spare battery.
yIf the FWT installed with the spare battery is powered by the power adapter, the
spare battery is automatically charged. After the spare battery is fully charged,
the charging stops.
yBefore using the spare battery for the first time, charge the spare battery for at
least eight hours. If a fully-charged spare battery is left unused for a long time,
charge it for at least five minutes before using it again.
yIf the FWT is powered solely by the spare battery, the talk time is 3 hours to 5
hours or the standby time is 40 hours to 120 hours (the talk time and the standby
time are network dependent).
Installing the Power Adapter
Press and hold to power your FWT off. Then connect the corresponding end
of the power adapter plug to the power supply jack and connect the other end of
the power adapter to a power socket.
Installing the Spare Battery
Press and hold to power your FWT off and then disconnect the FWT from
the power socket. Then install the spare battery as shown in the following figure.
When installing the spare battery, make sure that the battery cord plug matches
the battery jack. Do not insert reversely.

14
Removing the Spare Battery
Press and hold to power your FWT off and then disconnect the FWT from
the power socket. Then remove the battery house cover. Disconnect the battery
cord and take out the spare battery.
Installing the Antenna
Installing the Indoor Antenna
Power your FWT off and disconnect the FWT from the power socket. Then
connect the indoor antenna to the antenna jack on the handle set. Make sure that
the antenna is stably connected to the antenna jack.
Horizontally
Place the FWT on a flat surface. Select a cool and ventilated site for the FWT to
dissipate the heat.

Table 1-5 15
Vertically
1. Pull out the hook from the slot and turn it around. Then push it back so that the handset
will not fall down when FWT is placed vertically.
2. According to the distance between the two hooks (7.7 cm), hammer two nails into the
wall with a 3 mm end left outside.
7.7cm
3. Snap the hooks to the nails.
Validating
After installing the FWT, you can make a call to check whether it is correctly
installed.
1. Press and hold to power your FWT on. After connecting the FWT to the power
socket, the icon appears, indicating that the FWT is powered normally.
2. Lift the handset. In the standby mode, the signal strength icon appears normally.
3. If you can make a call, it indicates that the FWT is installed correctly.

16
4 Basic Operations
Powering the FWT On or Off
When the FWT is powered off, press and hold to power it on.
In the standby mode, press and hold to power it off.
Making a Call
Making a Call Through the Keypad
1. In the standby mode, press number keys to enter a phone number. If the entered phone
number is wrong, press .
2. Press to dial the phone number.
3. Press to end the call or cancel the dialing.
Making a Call from the Dialed Calls List
1. In the standby mode, press to access the Dialed Calls screen.
2. Press the up/down key to scroll up or down the dialed calls.
3. Press to dial.
Making a Call from the Phone Book
1. In the phone book, search for the contact to dial.
2. Press to dial.
Speed Dialing a Call
The speed dial function allows you to call a phone number by pressing one
number key. You can only set the speed dial function for contacts saved in the
FWT.
1. Select Menu > Phone Book > Speed Dial.
2. Press the up/down key to scroll up or down the items.

Table 1-5 17
3. If a number key is not assigned to a contact, press to select a contact from the
phone book.
4. If a number key is assigned to a contact, press for the following options:
yChange: Change a contact.
yDelete: Delete the contact.
Answering a Call
In the standby mode, you can lift the handset, press ,press or press
to answer a call.
Activating the Any Key Answer Function
In the standby mode, select Menu > Settings > Call Settings > Any-key Answer
to set the any-key answer function.
If the any-key answer function is activated, you can press any key to answer an
incoming call (except and ).
Rejecting a Call
If there is an incoming call, you can press to reject the call.
Adjusting the Volume
During a call, you can press the up/right key to increase volume or press the
down/left key to decrease volume.
Locking the Keypad
When the keypad is locked, you can press to answer a call.
Locking the Keypad Manually
Press and hold the #key for two seconds to lock the keypad.
Locking the Keypad Automatically
With the keyguard function activated, if there is no operation within the preset
time period when the FWT is in the standby mode, the keypad is automatically
locked.

18
Select Menu > Settings > Phone Settings > Keyguard.
Press the up/down key to select:
yOff: Deactivate the keyguard function.
y30 Seconds, 2Minutes or 5 Minutes:Set the FWT to lock automatically if there is no
operation in 30 seconds, 2 minutes or 5 minutes.
Unlocking the Keypad
Press . Then press the *key to unlock the keypad.
