Quidway® AR 46 Router 1000 M Ethernet Line Module
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved. 1
http://datacomm.huawei.com
Quidway® AR 46 Router 1000 M Ethernet Line Module
Overview
The 10/100/1000 M Ethernet electrical interface module and 1000 M Ethernet optical interface
module of the AR46 router provide Gigabit Ethernet (GE) electrical and optical interfaces
respectively, mainly for communicating with the router and LAN.
At present, the AR46 router has two 10/100/1000 M Ethernet electrical interface modules: 1-port
interface module and 2-port interface module. It also has two optical interface modules: 1-port
SFP 1000 M optical interface module and 2-port SFP 1000 M optical interface module.
Specifications
The specifications of 1000 M Ethernet line module of the AR46 router are shown in the following
table.
Product Number Connector
Type Description
RT-FIC-1GBE RJ45
AR46 1-port 1000 Mbps Base-T (RJ45) module
RT-FIC-2GBE RJ45
AR46 2-port 1000 Mbps Base-T (RJ45) module
RT-FIC-1GEF LC
AR46 1-port 1000 Mbps Ethernet optical interface 〔SFP〕
module
RT-FIC-2GEF LC
AR46 2-port 1000 Mbps Ethernet optical interface〔SFP〕
module
Where, the specifications of 1000 M SFP module are as follows:
Product Number Connector
Type Description
SFP-GE-SX-MM850-A LC Optical module-SFP 1000 Mbps multi-mode (850nm,
0.55km, LC)
SFP-GE-LX-SM1310-A LC Optical module –SFP 1000 Mbps single-mode (1310nm,
10km, LC)
SFP-GE-LH40-SM1310 LC Function module-SFP 1000 Mbps single-mode
middle-haul (1310nm, 40km, LC)
Quidway® AR 46 Router 1000 M Ethernet Line Module
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved. 2
http://datacomm.huawei.com
Connector
Product Number Description
Type
SFP-GE-LH40-SM1550 LC Function module - SFP 1000 Mbps single-mode
middle-haul (1550nm, 40km, LC)
SFP-GE-LH70-SM1550 LC Function module –SFP 1000 Mbps single-mode
long-haul (1550nm, 70km, LC)
Interface property
The properties of FIC-1GBE/FIC-2GBE interface are shown in the table:
Attribute FIC-1GBE Description FIC-2GBE Description
Connector type RJ45
Connector quantity 1 2
Interface type MDI/MDIX
Interface standard 802.3, 802.3u and 802.3ab
Cable type Ethernet cable
Working mode 10/100/1000 Mbps auto-sensing
Half-/full-duplex Auto-negotiation
The properties of FIC-1GEF/FIC-2GEF interface are shown in the table:
Attribute FIC-1GEF Description FIC-2GEF Description
Interface quantity 1 2
Connector type SFP/LC
Interface standard 802.3, 802.3u and 802.3ab
type
Short-haul
Multi-mode
(850nm)
Optical
interface
module
Middle-haul
Single-mode
(1310nm)
Optical
interface
module
Long-haul
(1310nm)
Optical
interface
module
Long-haul
(1550nm)
Optical
interface
module
Ultra long haul
(1550nm)
Optical
interface
module
Min. -9.5dBm -9dBm -2dBm -4dBm -4dBm
Transmitting
Optical
Power
Max. 0dBm -3dBm 5dBm 1dBm 2dBm
Receiver Sensitivity -17dBm -20dBm -23dBm - -21dBm -22dBm
Central wavelength 850nm 1310nm 1310nm 1550nm 1550nm
Fiber type 62.5/125μm
Multi-mode
9/125μ
Single-mode
9/125μm
Single-mode
9/125μm
Single-mode
9/125μm
Single-mode
Quidway® AR 46 Router 1000 M Ethernet Line Module
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved. 3
http://datacomm.huawei.com
Attribute FIC-1GEF Description FIC-2GEF Description
Maximum
transmission distance 0.55km 10km 40km 40km 70km
Working mode 1000Mbps
Full-duplex
Note:
zLC fiber connector is a small fiber connector developed by Lucent. It uses the push-pull button
for installation.
LC fiber connector
zThe fiber is selected. The user must specify the selected SFP interface module when
purchasing the interface card; otherwise, the fiber is not provided.
