Huawei E589 Assembly instructions

1
Thank you for choosing Huwei E589 4G Mobile WiFi
This guide briefly describes the functions of your Huawei E589 4G Mobile WiFi. For more
details, see help on the web management page. See” Accessing the Web Management
Page” on page 13.
Copyright © Huawei Technologies Co., Ltd. 2012. All rights reserved.
THIS DOCUMENT IS FOR INFORMATION PURPOSE ONLY, AND DOES NOT CONSTITUTE
ANY KIND OF WARRANTIES.

2
Getting to Know Huawei E589 4G Mobile WiFi
Connection Scenario
Any WiFi device can be connected to the Internet through your Huawei E589 4G Mobile
WiFi. You can connect up to 10 different devices. The actual connection procedure
depends on the operating system of the WiFi device. The connection scenario illustrated
here is for your reference.

3
Getting to know your Huawei E589 4G Mobile WiFi
No.
Item
1
Screen
2
WPS button
Press it twice consecutively to display
the SSID and wireless network key.
Press and hold it until a WPS
activation animation is displayed to
enable the WPS function.
3
Power/Wi-Fi button
4
SIM card slot
5
Strap hole
6
USB port
7
Reset button
8
microSD card slot
1
2
3
4
5
6
7
8

4
Screen
No.
Item
1
Signal strength
2
Network
3
Wi-Fi enabled
Number of devices connected
4
Internet connection status
5
New messages
Number of new messages
6
Battery level
7
International roaming state
8
Traffic data
Connection duration
9
A: Auto mode
M: Manual mode
1
2
3
4
5
6
R
8
7
0 00:00
B
A
9
4G

5
Note:
WiFi: Wireless Fidelity
WPS: WiFi Protected Setup
Traffic statistics are for your reference only. To obtain the actual traffic data, contact
your service provider.
SSID and Wireless Network Key
To connect a WiFi device to your Mobile WiFi, an SSID and a wireless network key are
required. The default SSID and wireless network key can be found in the gift box.
Alternatively press twice consecutively to display the current SSID and wireless
network key on the screen.

6
Before You Start
Inserting the SIM Card
Caution: Do not use any SIM card that is not standard or
is incompatible with the Mobile WiFi. Otherwise, the
Mobile WiFi may be damaged.
Insert the SIM card in the card slot. Be sure that the SIM card is facing in the right direction,
as shown in the following picture , and then slide the SIM card into the slot.

7
Inserting the micro SD Card
Insert the micro SD card into the Mobile WiFi, as shown in the picture below.
Note:
The microSD card is an optional accessory. You may purchase one yourself to enhance
data memory.
To remove the microSD or SIM card, press in the card gently. The microSD or SIM card
will pop out for removal.
Do not remove the microSD or SIM card when the card is in use. Otherwise, the card
as well as your Mobile WiFi may get damaged and the data stored on the card may be
corrupted.

8
Charging the Battery
Charge your Mobile WiFi the first time you use it or if it has not been used for a long time.
Method 1: Using the charger
Caution:
Only use the charger provided with your
Mobile WiFi device. Use of an
incompatible charger or one from an
unknown manufacturer may cause the
Mobile WiFi to malfunction, fail, or could
even cause a fire. Such use voids all
warranties, whether expressed or implied, on the product.

9
Method 2: Connecting to a PC for charging
Connect the Mobile WiFi to a PC using a compatible data cable.

10
Accessing the Internet via Wi-Fi Connection
By default, management parameters are preset on the Mobile WiFi according to the
requirements of the service provider. Follow the steps below to quickly access the Internet.
For details on how to set management parameters, see help on the web management
page.
Step1: Power on the Mobile WiFi
Press and hold until the screen lights up.
The Mobile WiFi is powered on.
Note: Press and hold to power off the
Mobile WiFi.

11
Step2: Establish a WiFi Connection
Make sure that the WiFi is enabled
1. Select Start >Control Panel >Network Connections >Wireless Network Connection.
Note: To set up a WiFi connection, the PC must have a wireless network adapter
installed. If Wireless Network Connection is displayed, a wireless network adapter is
available. Otherwise, check to make sure a wireless network adapter is installed.
2. Click “View available wireless networks“ to display a list of WiFi’s available.
3. Select a network indicated by the SSID of the Mobile WiFi, and then click “Connect”.
Note:
If the encryption parameter is already set for the Mobile WiFi, the Wireless Network
Connection dialog box is displayed. Enter the wireless network key in the dialog box.
Press twice consecutively to display the current SSID and wireless network key on
the screen.
4. Wait until the wireless connection icon is displayed in the status area in the lower
right corner of the PC screen.

12
Step3: Access the Internet
After you establish a WiFi connection successfully, you can access the Internet using the
following modes.
Caution: Please select a proper Internet connection mode based on your service expense.
For example, if you are subscribed to the time-based network service, you are
recommended to select Manual mode. For details about the service expense, consult your
service provider.
Mode
Operations
Auto
After the Mobile WiFi is powered on, it will connect to the Internet
automatically. If there is no data transmission over a period of time, the
Mobile WiFi automatically terminates the Internet connection.
Manual
Launch the web management page and follow the prompts to connect
to or disconnect from the network.

13
Note:
Launch the web management page to select the mode for accessing the Internet.
You can choose whether to enable the Mobile WiFi to connect to the Internet
automatically even while you are roaming. If this function is disabled, the Mobile WiFi
automatically disconnects from the Internet while you are roaming. To access the
Internet, set up a connection manually.
Accessing the Web Management Page
1. Make sure that the connection between the Mobile WiFi and the client is proper.
2. Start the Internet browser and enter http://192.168.1.1 in the address bar.
3. Enter the password and log in to the web management page.
Note: The default password is admin.

14
Daily Use
Power Saving Mode
If no operation is performed on the Mobile WiFi within a preset period, the screen turns off.
Press any key to light up the screen.
If the Mobile WiFi is powered by the battery only, choose whether to enable the Mobile
WiFi to turn off WiFi automatically. If this function is enabled and no WiFi devices access
the Mobile WiFi for a preset period, the Mobile WiFi turns off WiFi automatically. You can
press any key to turn WiFi on again.
Validating the PIN Code
If PIN code protection is enabled, log in to the web management page and follow the
prompts to enter the correct PIN code. Both PIN and PUK are delivered with the SIM card.
For details, consult your service provider.

15
Establishing a WPS Connection
If a WiFi client connected to the Mobile WiFi supports the WPS function, a wireless
network key will be automatically generated without manual input. To establish a WPS
connection, perform the following steps:
1. Power on the Mobile WiFi.
2. Start the client.
3. Enable the WPS function of the Mobile WiFi.
Note: After WiFi is enabled, press and hold
until a WPS activation animation is displayed on
the screen to enable the WPS function of the
Mobile WiFi.
4. Enable the WPS function of the client.
Note: For WPS operations on the client, see the user guide of the client.

16
Restoring Factory Defaults
If you forget the changes you have made to some
parameters, you may restore factory defaults and
reconfigure the Mobile WiFi. To restore the
factory defaults, press and hold the RESET button
until the screen turns off. All factory default
settings are successfully restored.
Note: Restoring factory defaults deletes all personal configuration settings and restores all
web-based management settings and parameters to their default values.

17
Example 1: Wi-Fi Connection to Game Machine (Sony
PSP)
1. Turn on the PSP WLAN switch.
2. Select “Settings > Network Settings”.
3. Select “Infrastructure Mode” to connect
to your local Wi-Fi access point.
4. Select “New Connection” to specify an
easy to remember connection name.
5. Select “Scan” to detect all networks
within range. The access point list is
displayed.
6. Select a network indicated by the SSID of
the Mobile WiFi. First press the
“►“ button of your game machine to
confirm the SSID and then press it again
to input the wireless network key.

18
Note: Press twice consecutively to
display the current SSID and wireless network
key on the screen.
7. Press the “►“ button of your game
machine to continue, and then press the
“X” button to save the settings.
8. Select “Test Connection“ to check the
connection.
9. Go to “Internet Browser”.

19
Example 2: WiFi Connection to a Smart Phone (iPhone)
1. Select “Settings > WiFi”, and then turn on
WiFi.
2. Automatically detect the networks in range
and display the access point list.
3. Select a network indicated by the SSID of the
Mobile WiFi.
4. If necessary, enter a password and tap “Join”.
(Networks requiring a password appear with
a lock icon.)
Note: Some WiFi clients such as iTouch, PS3 and
NDSi can also access the Internet via the Mobile
WiFi. For details, see the user guides of the WiFi
clients.

20
Tips
If the Mobile WiFi is placed in an environment with poor ventilation, it may overheat after
extended use. When the Mobile WiFi overheats, it will switch off and disconnect from the
network automatically to protect itself. If this happens, place the Mobile WiFi in a
well-ventilated location, then restart the Mobile WiFi.
If you are experiencing difficulties using the Mobile WiFi, try the following:
See help on the web management page.
Restart the Mobile WiFi.
Restore the factory defaults.
Contact your service provider.
Version: V100R001_01Part Number: 31010***
