HUDSON
Foot - Control Radio
OWNERS MANUAL
D B 4 7
INSTALLATION AND OPERATING
INSTRUCTIONS
HUDSON MOTOR CAR CO.
DETROIT, MICH., U.S.A

OPERATING INSTRUCTIONS
This radio incorporates the new Hudson Automatic Touch Tuning. The purpose and position of each control is shown in (Fig. 1).
To Turn Radio On
Press push button on right side below ON-OFF indicator window and allow receiver to reach operating temperature.
(Approximately 20 seconds.)
Manual Tuning
1. Press the automatic tuning push button on the left side beneath automatic indicator window several times or until the letter "M"
appears in the automatic indicator window.
2. Pull manual tuning (right hand) control knob outward and turn to tune in desired stations. Tune to exact frequency for the best
tone quality.
Volume
Adjust left hand control knob for desired volume.
Tone Control
The tone control is located directly behind the volume control knob (Fig. 1). Rotating this control to the right or left will change
the tone of the receiver. The treble position is useful in overcoming wind, noise, etc. when driving, while the bass position brings
out the full mellow tones of musical programs. With the tone control set midway, the full tonal range is obtained. Turning to the
right will emphasize the high notes, while turning to left will emphasize the bass notes.

Automatic Tuning
There are five automatic tuning positions which may be adjusted to five desired stations. If
these positions have not been previously adjusted proceed as follows:
1. Press the automatic tuning push button (on the left side) until Number 1 appears in the
automatic indicator window.
2. Pull the manual tuning knob OUTWARD to engage the automatic mechanism.
3. Select the station desired and tune to its frequency by turning the tuning knob. Tune very
carefully for clearest reception.
CAUTION: DO NOT ATTEMPT TO FORCE THE KNOB IN. The knob will automati-
cally return to the "IN" position when the automatic tuning push button or the foot switch is
operated.
4. Press the automatic tuning push button, pull manual tuning knob outward, and tune in
station desired for No. 2 position. Use the same procedure for positions No. 3, 4 and 5.
Whenthefiveautomaticpositionshavebeenadjustedtothefivedesiredstationsasinstruct-
ed, it is only necessary to press the AUTOMATIC button to return to MANUAL tuning, or
to any one of the stations selected on the Automatic.
Foot Control
The Foot Control provides a convenient means of selecting stations, and muting the set
without taking the hands off the steering wheel or the eyes from the road. Its function is
identical to that of the automatic tuning push button. The foot control requires no set up or
other adjustment. Press the foot control button all the way down to change stations. Press
lightly to silence the radio during conversation.
NOTE:Thereceiver cannot be turned on or offwiththe foot control. The on-off switch (Fig.
1) must be used for this purpose.
Warranty and Service
Your Hudson Receiver is covered by warranty against defect in material and workmanship
for a period of 90 days after retail delivery.
This warranty covers a receiver installed at the factory, also a receiver installed in the field
asan accessory.
IMPORTANT
A warranty registration tag is furnished with your receiver. This tag must be filled in and
attached to the unit at the time of retail delivery in order that auto radio service stations may
have the proper information when you require service during the warranty.
How To Obtain Service
Return to your Hudson dealer, or if you are traveling go to your nearest Hudson dealer. Do
not contact any other source for warranty service.
In case you are traveling, the dealer, to whom you apply for service, will render a small
charge for the removal and re-installation of the radio equipment.

RadioReceiverKit
Model DB-47 Part No. H.A. 206990
Radio receiver Temperature gauge condenser
Screws,lockwashers,knobs Ignition coil condenser
Foot selector switch assembly Motor hood bonding spring Speaker and
bracket assembly Support bracket and attaching
Distributor suppressor parts
Voltage regulator condenser Ground strap and attaching parts
RadioAntennaKits
Part No. 209558-60" Telescopic Antenna including all
installationparts.
Part No. 209762-90" Telescopic Antenna including all
installationparts.
Part No. 205451—Vacuum Operated Antenna including all
installationparts.
NOTE: The above kits are not available from the radio manufacturer. See
your Hudson dealer.
Radio Installation Instructions
1. Install the antenna. Complete instructions for installation are packed
witheachkit.
2. Remove the decorative plate in the center of the grille covering the
radioopening.
3. Remove the floor mat around the clutch and brake pedals. Place the
foot control over the holes provided in the floor board. Fasten it with
the three No. 8 R.H. self-tapping screws furnished in the installation
kit (Fig. 3)
4.Dress the footcontrol leadto the leftof theclutchpedal andup behind
thefirewallpad.
5. Replace the floor mat and cut a hole for the foot control button.
6. Remove accessory switch bracket.
7. Plug the foot control cable into the socket provided on the left end of
the receiver. With thisend of thereceiver down and thecontrol shafts
to the right, push the receiver up between the instrument panel and the
air hopper as far as it will go. Turn the radio clockwise until the knob
shafts point downward. Lift the front of the receiver up until the shafts
slide through the slots provided below the shaft openings in the instru-
ment panel. Bring the receiver forward so that the knob shafts protrude
through the shaft openings.
8. Fit the knob shaft bushing nuts on the shafts and tighten as much as
possiblewith the fingers.Place thetips of longnose pliersinthe holesin
thenutsandtightensecurely.
9. Attach set mounting bracket by fastening one end to the side of the
receivercase with the wingnut. Fasten theother end of theradio mount-
ing bracket to the cowl ventilator handle bracket with 1/4" x 3/4" M.S.,
flat washer, lock washer and nut. (Fig. 2.)
10. Remove cardboard protector from speaker unit and fasten speaker and
bracket assembly in place with two 1/4" x 3/4" M.S. flat washers, two
lock washers, and two nuts provided. (Fig. 2.) Connect the speaker-
cable socket to the plug provided on the speaker frame.
11.Fastenthecontrols inplaceasshown infigure1.
NOTE: Tuning knob must be placed 3/16" away from the instrument
panelinorderto rotatefreelyintheautomaticposition.
12. Fasten the accessory switch bracket back in place.
13. Remove the ash tray assembly and plug the antenna lead into the socket
provided on the top of the receiver.
14. Fasten the "A" lead to the unfused terminal of the fuse block as indicated
in Figure 2.
15. IMPORTANT: Turn the receiver on and allow it to operate for approxi-
matelyfifteenminutesinorder forit toreachnormaloperatingtempera-
ture. Tune in a weak station near 1200 Kc. Reach through the ash tray
opening with a small screw driver and adjust the antenna trimmer,
locatedonthetopofthereceiverformaximumvolume.(Fig.2.)Replace
ash tray.

IMPORTANT: Use the utmost care in the following operations to insure
freedom from motor noise. Be sure that good ground contacts are made
between the interference condensers and the car body. If necessary, clean
away paint or dirt with emery paper. Tighten all nuts and bolts securely.
1. Remove the top mounting screw of the horn relay near the voltage regula-
tor and under this screw mount the condenser No. 22-1537. Connect the
lead to the voltage regulator battery terminal. (Fig. 4.)
2. Install suppressor No. 63-1252 in center hole of distributor cap. Place high
tension lead in the top of suppressor. Be sure the suppressor and the lead
are fastened securely. (Fig 5.)
3. On the six cylinder car, remove the bolt above the ignition coil, from the
firewall. Mount the condenser No. 22-1537 under this bolt. Connect the
leadtothe coil terminal asshown in Figure 6.
On the eight cylinder car, remove the bottom screw from r_ the ignition coil
mounting bracket. Install the condenser No. 22-1537 under the screw.
Connect the lead to the coil terminal as shown in Figure 6A.
4. Loosen the upper rear cap screw of the engine water jacket plate. CAU-
TION: Do not REMOVE cap screw. Slide the slotted bracket of the
condenser No. 22-1260 under the head of this screw. Tighten the screw.
Attach the condenser lead to the water temperature element in the head. (Fig
7.)
5. Remove the tape from the hole, located near the left rear cylinder head nut
in the dash. Fasten the flat ground strap 83-986 to this hole with a sheet
metalscrew andlockwasher. Placethe otherend ofthestrapontop ofthe
stud nut, and fasten it in place with the special nut furnished in the installa-
tion kit. (Fig. 7.)
6. Install the motor hood bond spring as shown in Figure 8. Fasten with No.
8 sheet metal screw.
Interference Elimination
