Humandata LNX-203 User manual

HuMANDATA LTD.
2 Channel
RS-232C LAN Converter
LNX-203
User’s Manual
Ver. 1.0

1
LNX-203 (Ver.1.0)
Table of Contents
Precautions ..................................................................................................... 2
Revision History.............................................................................................. 1
Introduction .................................................................................................... 1
1. Product Configuration........................................................................................ 1
2. Product Summary .............................................................................................. 2
3. Overview ............................................................................................................ 2
3.1. Block Diagram......................................................................................................2
3.2. Front Side .............................................................................................................3
3.3. Rear Side...............................................................................................................4
4. Specifications ..................................................................................................... 5
4.1. AC adapter (Japan's specifications)....................................................................6
4.2. Optional Accessories ............................................................................................7
4.3. Power Supply........................................................................................................7
5. RS232C Pin Assignment..................................................................................... 8
6. Connection examples.......................................................................................... 9
7. Setting Tool ...................................................................................................... 11
7.1. Access Flow of microSD card............................................................................ 12
7.2. Function............................................................................................................. 13
7.3. Write Setting Data ............................................................................................ 19
7.4. Read Setting Data............................................................................................. 22
7.5. Write or Read setting data over the network.................................................. 24
7.6. Setting Example................................................................................................ 25
8. Virtual COM Port............................................................................................. 30
9. Additional Documentation and User Support ................................................... 30
10. Warranty and Compensation.......................................................................... 30

2
LNX-203 (Ver.1.0)
Precautions
1
This product uses ordinary off-the-shelf electronic components, and
is therefore inappropriate for use in applications that require special
quality or reliability and are expected to protect human lives or
prevent accidents, such as safety mechanisms in fields including
space, aeronautics, medicine, and nuclear power.
2
Do not be used underwater or in high-humidity environments.
3
Do not be used in the presence of corrosive gases, combustible gases,
or other flammable gases.
4
Do not turn on power when circuit board surface is in contact with
other metal.
5
Do not apply voltage higher than rated voltage.
6
This manual may be revised in the future without notice owing to
improvements.
7
All efforts have been made to produce the best manual possible, but
if users notice an error or other problem, we ask that they notify us.
8
Item 7 notwithstanding, HuMANDATA cannot be held liable for the
consequences arising from use of this product.
9
HuMANDATA cannot be held liable for consequences arising from
using this product in a way different from the uses described herein,
or from uses not shown herein.
10
This manual, circuit diagrams, sample circuits, and other content
may not be copied, reproduced, or distributed without permission.
11
If the product emits smoke, catches fire, or becomes unusually hot,
cut the power immediately.
12
Do not install the control cables or communication cables together
with the main circuit lines or power cables. In such an environment,
it may result in malfunction due to noise.
13
Be careful of static electricity.
Do Not
Attention

1
LNX-203 (Ver.1.0)
Revision History
Date
Revision
Description
December 6, 2018
v1.0
Initial release
Introduction
Thank you very much for purchasing our product LNX-203.
LNX-203 is a 2 channel RS-232C LAN converter which makes it possible to use 2
channels of RS-232C devices via Ethernet local area network.
1. Product Configuration
The following lists the product configuration of the LNX-203.
2 Channel RS-232C LAN Converter (LNX-203) 1
microSD card with USB adapter 1
D-Sub 9pin M2.6 screw (#4-40 UNC is mounted) 4
AC adapter (DC5V) 1
Driver & Application CD 1

2
LNX-203 (Ver.1.0)
2. Product Summary
LNX-203 is a 2 channel RS-232C LAN converter which makes it possible to use 2
channels of RS-232C port from single LAN port via Ethernet local area network.
Tunneling mode (transparent mode: connected on one-to-one connection without
PC) is available with LNX-203 using LAN. By using TCP/UDP or Telnet, direct
control from PC is also available.
LNX-203 supports PoE. That makes it possible to be powered via a LAN cable (PoE
compatible HUB or other is required). It can also be powered by the AC adapter.
Network setting can be saved to and restored from a microSD card. Restoring the
setting information from a microSD card is very convenient when replacing
LNX-203.
3. Overview
3.1. Block Diagram

3
LNX-203 (Ver.1.0)
3.2. Front Side
LEDs
Name (color)
Function
POWER Power LED (red) Turn on during the power is supplied.
RX Reception LED (red) Turn on when data is received from RS-232C side.
TX Transmitter LED (red) Turn on when data is transmitted to RS-232C side.
SYS System LED (red) Blink few seconds during reading process.
Turn on when system is ready.
BUSY micro SD card access
LED (red)
Turn on during accessing micro SD card.
When it turned off, you can extract the card.
Power LED
Tx/Rx LED x2
System LED
micro SD card
Slot
micro SD card access LED

4
LNX-203 (Ver.1.0)
3.3. Rear Side
LAN side and RS-232C side is isolated.
LEDs
Name (color)
Function
ACT Active LED (green) Turn on during network port communication.
LINK Link LED (yellow) Turn on when the power is supplied and LAN cable is
connected normally.
Power Input
LAN Connector
D-sub 9pin
male Connector x2
Link LED
Active LED
Power Switch

5
LNX-203 (Ver.1.0)
4. Specifications
Item
Description
Remarks
Model
LNX-203
Power
5VDC, Supplied by AC adapter or LAN
connector (PoE function)
PoE function supports
both mode A and B
Current Consumption
Less than 350mA
Network Interface
IEEE802.3 (10Base-T)
IEEE802.3u (100Base-TX)
half-duplex / full-duplex (auto detected)
LAN Connector
RJ45
ESD protection ±11KV
isolation over
1500Vrms
Protocol
TCP / UDP / Telnet
Input/Output Interface
RS232C x 2 channel ESD protection ±15KV
RS-232C Connector
D-Sub 9pin Male
(#4-40 UNC screws are mounted)
M2.6 screws are also
attached for accessary
Setting Memory Card
microSD card
For save and restore
the product setting
SPI mode
Baud Rate
300, 600, 1200, 2400, 4800, 9600, 19200,
38400,
57600, 115200, 230400, 460800,
921600 bps
Data Bits
7 or 8 bits
Stop Bits
1 or 2 bits
Parity
Even, Odd, No parity
LED
POWER: Power LED
RX: Receiver LED x 2
TX: Transmitter LED x 2
SYS: System LED
BUSY: micro SD card access LED
LINK (RJ45 Connector): LINK Status
ACT (RJ45 Connector): ACT Status

6
LNX-203 (Ver.1.0)
Operating Ambient Temp.
-10 to 55 [°C] (14 to 131 [°F])
No condensation
permitted
Operating Ambient Humi.
30 to 85 %RH
Storage Ambient Tem.
-20 to 60 [°C] (-4 to 140 [°F])
Storage Ambient Humi.
30 to 85 % RH
Weight
Approx. 300 [g] Only main body
Dimensions
165 x 80.5 x 39 [mm]
(6.496" x 3.169" x 1.535") Without projections
* There may be cases that these parts and specifications are changed.
* Power saving function (suspend, standby, sleep and others) is not supported
* Please use the microSD card that is included in the package.
4.1. AC adapter (Japan's specifications)
Item
Description
Remarks
Output
5VDC 2.0A
Plug
2.1mm inner diameter Positive Tip
Compatible DC Jack
2.1mm inner diameter
Operating Ambient Temp.
0 to 40 [°C] (32 to 104 [°F])
No condensation
permitted
Operating Ambient Humi.
30 to 85 % RH
Storage Ambient Temp.
-20 to 80 [°C] (-4 to 176 [°F])
Storage Ambient Humi.
10 to 95 % RH
Wire Length
1.6m
Weight
approx. 70 [g]
Dimensions
46 x 34 x 25 [mm]
1.811" x 1.339" x 0.984" Without projections
* This AC adapter is attached for use mainly in Japan. If you use in the other countries, please
check the specifications above and plug shape.
* There may be cases that this part and specifications are changed.

7
LNX-203 (Ver.1.0)
4.2. Optional Accessories
Model Name
Description
ACC-027
Metal bracket type A
for vertical mounting USB/LNX series
JAN : 4937920801096
ACC-028
Metal bracket type A
for horizontal mounting USB/LNX series
JAN : 4937920801102
ACC-031
Din rail attachment type B for USB/LNX series
JAN : 4937920801256
ACC-036
Neodymium magnet set for USB/LNX series
JAN : 4937920801539
4.3. Power Supply
LNX-203 supports PoE function both A and B type as standard which make it
possible to be powered via a LAN cable (PoE compatible HUB is required). It also
can be powered by the AC adapter.

8
LNX-203 (Ver.1.0)
5. RS232C Pin Assignment
* DCD and RING signals are not supported.
* #4-40 UNC screws are mounted by factory setting. You can change them to attached
M2.6 screws.
Pin No
Name
Direction
Remarks
1
(DCD) In
Data carrier
detect
2
RXD
In Receive data
3
TXD
Out Transmit data
4
DTR
Out Data terminal
ready
5
GND
- Signal ground
6
DSR
In Data set ready
7
RTS
Out Request to send
8
CTS
In Clear to send
9
(RING) In Ring indicator
CASE
FG
- Connect to GND
D-Sub 9pin Male

9
LNX-203 (Ver.1.0)
6. Connection examples
[Tunneling mode between two LNX-203]
Direct communication between two LNX-203s without any PCs offers you a way to
connect separated RS-232C devices.
[Tunneling mode between LNX-203 and two LNX-002 with RS-232C]
Direct communication between LNX-203 and LNX-002 without any PCs offers you a
way to connect separated RS-232C devices.
[LNX-203 single operation]
Communication with RS-232C devices via a local area network is available.

10
LNX-203 (Ver.1.0)
[Connect LNX-203 and LAN printer and output from microcomputer and PLC devices]
Send print data to remote network printer using RS-232C interface of microcomputer
and PLC devices.
* Please use a cross cable to connect LNX-203 without using a hub.
(LNX-203 does not have a function for AutoMDI/MDI-X.)

11
LNX-203 (Ver.1.0)
7. Setting Tool
Setting tool supports to save and read network setting by a microSD card. This tool
does not require installation.
This is a screenshot from version 2.0

12
LNX-203 (Ver.1.0)
Power ON
Detect
Ready
microSD
card
None
Setting data
WR_DATA.TXT
Find
None
Product type
Verify
OK
NG
BUSY LED flicker
Different product types in the setting
data and actual product.
It is necessary to correct the product
type by LNX setting tool.
Possible to remove of the
microSD card
POW LED、
BUSY LED turn on
Write setting data
BUSY LED turn off
SYS LED turn on
Saving backup data of
RD_DATA.TXT in the micro SD card.
SYS LED flicker
（System start up）
7.1. Access Flow of microSD card
Access to the microSD card is done
immediately after power input. When
BUSY LEDs are lighting, do not detach the
microSD card. You can detach it after
confirming BUSY LEDs are turned off.

13
LNX-203 (Ver.1.0)
7.2. Function
Item
Contents
Reading data
Read setting data (RD_DATA.txt) from microSD card.
Saving data
Save setting data (WR_DATA.txt) to microSD card.
Network
Read or write setting data over the network. LNX product and PC
must be connected to the same network segment.
Product select
Display product select window.
Copy to clipboard
Copy a display image to clipboard.
Exit
Terminate the application.

14
LNX-203 (Ver.1.0)
[Basic Setting]
Item
Contents
IP address
If DHCP is not used to assign an IP address, enter it manually.
Unique IP address must be used in the network. The default
setting is 0.0.0.0 (DHCP is enabled)
Subnet mask
A subnet mask defines the number of bits taken from the IP
address that are assigned for the host part.
Default gateway
A gateway address of a router which is allowed to communicate to
other LAN segments. This address should be an IP address of the
router which is in the same LAN segment.
Port number
Enter the local port number. The default setting is 10001.
If you change the value, please avoid the following numbers. They
are allocated to other function.
1-1024
Reserved for well-known ports
9999 Reserved for telnet setup
14000-14009
Reserved for old redirector
30704 Reserved for remote control of user I/Os
30718
Reserved for configuration

15
LNX-203 (Ver.1.0)
Protocol
From the drop-down menu, select TCP or UDP.
Normally TCP is used, but when one-to-multiple communication
like broadcast or sensitive-responsiveness is needed, please select
UDP. The default setting is TCP.
Baudrate
LNX-203 and an attached serial device must agree on the baud
rate to use for the serial connection. Valid baud rates are 300, 600,
1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200, 230400,
460800 or 921600. The default setting is 9600.
Flow control
Flow control manages data flow between devices in a network to
ensure it is processed efficiently. Too much data arriving before a
device is prepared to receive it causes lost or retransmitted data.
Select from None, Xon/Xoff, Xon/Xoff Pass Chars to Host or
RTS/CTS (hardware). The default setting is none.
Stop bits
Select from 1 or 2 bit. The default setting is 1.
Parity
Select from Even, Odd or None. The default setting is none.
Data bits
Select from 7 or 8 bit. The default setting is 8.

16
LNX-203 (Ver.1.0)
[Remote Setting (Tunneling Mode)]
Item
Contents
Remote Setting
(Tunneling mode)
Enable/Disable
Select to enable remote connection (tunneling).
The default setting is disable.
Remote IP address
Enter the remote IP address of tunneling target.
Remote Port
number
Enter the remote port number of tunneling target.
Connection method
Select connection method to the target.

17
LNX-203 (Ver.1.0)
[Extension Setting (1/2)]
Item
Contents
TCP keepalive
TCP keepalive time defines how many seconds LNX-203 waits
during an inactive connection before checking its status. If the unit
does not receive a response, it drops that connection. Enter a value
between 0 and 65 seconds. 0 disables keepalive.
The default setting is 5.
Pack control
Enable/Disable
Select to enable pack control.
Two packing algorithms define how and when packets are sent to the
network. The standard algorithm is optimized for applications in
which the unit is used in a local environment, allowing for very small
delays for single characters, while keeping the packet count low. The
alternate packing algorithm minimizes the packet count on the
network and is especially useful in applications in a routed Wide
Area Network (WAN). Adjusting parameters in this mode can
economize the network data stream.
The default setting is disable.
