Humanetics Q10 2020 User manual

HUMANETICS
23300 HAGGERTY ROAD
FARMINGTON HILLS, MICHIGAN 48335 USA
012-9900 Q10 2020
USER MANUAL [Rev. 1]
Q10 2020
10.5 YEAR
OLD CHILD
012-0000

012-9900 Q10 2020 USER MANUAL [REV. 1]
©2020 HUMANETICS
| II
Our Vision
Global leadership in occupant safety test & measurement
for the development of safer vehicles, ulmately saving lives.
Our Mission
To achieve our vision and increase enterprise value,
our customer focused organizaon will:
»Aract and develop exceponal people
»Reduce performance variability of our products,
systems, and services
» Connuously improve and innovate our products
and services
» Invent the next generaon of test & measurement
products by facilitang the cooperaon of industry,
regulators, government, and academic instuons
» Exceed our customer’s expectaons of reliability,
support, dependability and innovaon
» Achieve supply chain and manufacturing excellence

012-9900 Q10 2020 USER MANUAL [REV. 1]
©2020 HUMANETICS
| III
Company & Support
Humanecs is the world’s leading supplier in the design and manufacture of sophiscated crash
test dummies, associated technical support and laboratory services, development and supply of
nite element soware dummy models for computerized crash test simulaons and speciales
in stac and dynamic strain measurements.
Humanecs is the only full service provider worldwide oering on and o-site customer
laboratory management service, training and consultancy. In addion, Humanecs’ local oces
and agents are capable of providing full technical support on both the physical and virtual product
lines. Humanecs also has an Engineer to Order capability, catering to specic customer needs.
Humanecs also designs and manufactures all applicable load cells in the crash safety area,
ranging from single axis low-weight seat belt to mul-axis heavy duty crash wall load cells.
Calibraon Laboratories
Crash Wall Load Cells
Dummy Load Cells
Engineer to Order Products
Localized Technical Support
Users Training
Spare Parts Management

012-9900 Q10 2020 USER MANUAL [REV. 1]
©2020 HUMANETICS
| IV
General Safety Instrucons
Non compliance with these general safety instrucons can endanger the safety of humans
(including death or serious injury), the environment and the equipment. This can lead to loss of
any claims to compensaon for damages.
The safety instrucons in this manual are structured and dened as follows:
WARNING
TYPE AND SOURCE OF DANGER
Refers to an immediately dangerous
situation, which may lead to death or serious
injury.
DANGER
TYPE AND SOURCE OF DANGER
Refers to an immediately dangerous
situation, which may lead to death or serious
injury.
DANGER
FATAL INJURY BY ELECTRIC SHOCK
There is a risk of electric shock when
connecng the device to the power supply.
Finding and removing faults on electrical
components, cables, and connecons may lead
to accidents, including electrocuon. All work
on electrical connecons must only be carried
out by a qualied electrician in accordance
with technical electrical regulaons.
DANGER
RISK OF FATAL INJURY
The operator must ensure that the test device
is completely visible from the operator’s desk.
DANGER
RISK OF INJURIES CAUSED BY NOISE, FIRE,
AND FLYING DEBRIS
The operator must ensure that personnel
are protected against risks caused by the
test set-up/procedure, for example, noise
and re risks or risks of injury as a result of
ying debris.
DANGER
SUBSTANCE RISKS
The operator must ensure that personnel are
protected from material/substance hazards
caused by the test set-up and procedure.
DANGER
RISK OF INJURY
There is a risk of injury due to the toppling
and slipping of the device. Install the device
on a industrial concrete oor with a minimum
thickness of 15 cm. Posion the device in the
locaon specied and secure with suitable
fastening bolts.
CAUTION
TYPE AND SOURCE OF DANGER
Refers to an immediately dangerous
situation, which may lead to minor injuries or
material damage if not prevented.
NOTICE
Indicates useful tips, recommendations
and information for an improved or more
efficient and trouble-free operation.
Safety Symbols & Description

012-9900 Q10 2020 USER MANUAL [REV. 1]
©2020 HUMANETICS
| V
Addional safety symbols and descripons:
WARNING
EXPLOSION
Refers to the risks and dangers
of explosion.
WARNING
HAND INJURIES
Refers to the risks and dangers
of hand injuries.
WARNING
HOT SURFACES
Refers to the risks and dangers of injury
from hot surfaces.
WARNING
HIGH VOLTAGE
Refers to the risks and dangers of electric
shock, possibly with fatal consequences.
WARNING
CORROSIVE
Refers to the risks and dangers
of corrosion.
WARNING
ENTRAPMENT
Refers to the risks and dangers
of entrapment.
WARNING
OVERHEAD CRANE
Refers to the risks and dangers of lied
loads that can fall down or injure people.
WARNING
WEAR EYE PROTECTION
Refers to a potenally dangerous situaon,
which may lead to death or serious injury if
not prevented.
WARNING
WEAR HAND PROTECTION
Refers to a potenally dangerous situaon,
which may lead to death or serious injury if
not prevented.
WARNING
READ INSTRUCTION MANUAL
Refers to a potenally dangerous situaon,
which may lead to death or serious injury if
not prevented.
WARNING
WEAR FOOT PROTECTION
Refers to a potenally dangerous situaon,
which may lead to death or serious injury if
not prevented.
Safety Symbols & Description

012-9900 Q10 2020 USER MANUAL [REV. 1]
©2020 HUMANETICS
| VI

012-9900 Q10 2020 USER MANUAL [REV. 1]
©2020 HUMANETICS
| VII
Table of Contents
Table of Contents�������������������������������������������������������������������������������������������������������������� vii
List of Figures�������������������������������������������������������������������������������������������������������������������� xiv
List of Tables��������������������������������������������������������������������������������������������������������������������� xvii
SECTION 1
Introduction ������������������������������������������������������������������������������������������������������������������������� 1
1.1 Q10 2020 Introduction .............................................................................................................................. 1
1.1.1 Development History ............................................................................................................................2
1.1.2 Application ............................................................................................................................................2
1.1.3 Standard Dummy Delivery ....................................................................................................................2
1.2 Getting Familiar with the User Manual ............................................................................................... 2
1.2.1 Section Organization .............................................................................................................................3
1.2.2 Conventions Used throughout this Manual .........................................................................................3
SECTION 2
Dummy Preparation and Use ������������������������������������������������������������������������������������������ 5
2.1 General ................................................................................................................................................ 5
2.1.1 Hardware and Fasteners .......................................................................................................................5
2.1.2 Recommended Tools .............................................................................................................................5
2.1.3 Torque Values ........................................................................................................................................6
SECTION 3
Top Level Dummy Assembly �������������������������������������������������������������������������������������������� 7
3.1 Description of Features ....................................................................................................................... 7
3.2 Assembly of Top Level ......................................................................................................................... 7
3.2.1 Top Level Parts List ................................................................................................................................7
3.3 Disassembly of Body Segments ........................................................................................................... 9
3.3.1 Suit Disassembly ....................................................................................................................................9
3.3.2 Head/Neck Disassembly ......................................................................................................................10
3.3.3 Neck/Torso Disassembly .....................................................................................................................12
3.3.4 Torso Disassembly ...............................................................................................................................13
3.3.5 Arm Disassembly .................................................................................................................................13
3.3.6 Lumbar Disassembly ...........................................................................................................................14
3.3.7 Pelvis Disassembly ...............................................................................................................................15
3.3.8 Leg Disassembly ..................................................................................................................................15
Table of Contents

012-9900 Q10 2020 USER MANUAL [REV. 1]
©2020 HUMANETICS
| VIII
Table of Contents
SECTION 4
Head Assembly ������������������������������������������������������������������������������������������������������������������ 16
4.1 Description of Features ..................................................................................................................... 16
4.2 Assembly of Head .............................................................................................................................. 16
4.2.1 Head Assembly Parts List ....................................................................................................................16
4.2.2 Assembly of Head Components .........................................................................................................17
SECTION 5
Neck Assembly������������������������������������������������������������������������������������������������������������������� 20
5.1 Description of Neck Assembly and Features .................................................................................... 20
5.2 Assembly of the Neck ........................................................................................................................ 20
5.2.1 Neck Assembly Parts List ....................................................................................................................20
5.2.2 Assembly of Neck Components ..........................................................................................................21
SECTION 6
Thorax Assembly��������������������������������������������������������������������������������������������������������������� 22
6.1 Description of Thorax Assembly and Features ................................................................................. 22
6.2 Assembly of the Thorax ..................................................................................................................... 22
6.2.1 Thorax Assembly Parts List .................................................................................................................22
6.2.2 Assembly of Thorax Components .......................................................................................................23
SECTION 7
Arm Assembly�������������������������������������������������������������������������������������������������������������������� 26
7.1 Description of Lower Arm and Hand Assembly and Features ......................................................... 26
7.2 Assembly of the Arm ......................................................................................................................... 26
7.2.1 Arm Assembly Parts List .....................................................................................................................26
7.2.2 Assembly of the Arm Components .....................................................................................................29
SECTION 8
Lumbar Assembly�������������������������������������������������������������������������������������������������������������� 31
8.1 Description of Lumbar Assembly ...................................................................................................... 31
8.2 Assembly of the Lumbar .................................................................................................................... 31
8.2.1 Lumbar Assembly Parts List ................................................................................................................31
8.2.2 Assembly of the Lumbar assembly Components ...............................................................................32

012-9900 Q10 2020 USER MANUAL [REV. 1]
©2020 HUMANETICS
| IX
Table of Contents
SECTION 9
Pelvis Assembly����������������������������������������������������������������������������������������������������������������� 33
9.1 Description of Pelvis Assembly.......................................................................................................... 33
9.2 Assembly of the Pelvis ....................................................................................................................... 33
9.2.1 Pelvis Assembly Parts List ...................................................................................................................33
9.2.2 Assembly of the Pelvis assembly Components ..................................................................................35
SECTION 10
Leg Assembly���������������������������������������������������������������������������������������������������������������������� 40
10.1 Description of Leg Assembly ............................................................................................................. 40
10.2 Assembly of the Leg .......................................................................................................................... 40
10.2.1 Leg Assembly Parts List .......................................................................................................................40
10.2.2 Assembly of the Leg Components ......................................................................................................44
10.2.3 Assembly of the Upper leg to the Pelvis .............................................................................................45
SECTION 11
Dummy Suit and Hip Shield ������������������������������������������������������������������������������������������� 46
11.1 Description of the Suit and Hip Shield Features ............................................................................... 46
11.2 Assembly of the Suit .......................................................................................................................... 46
11.2.1 Suit Parts List .......................................................................................................................................46
11.2.2 Assembly of Suit ..................................................................................................................................46
11.3 Assembly of the Hip Shields .............................................................................................................. 47
SECTION 12
Instrumentation ���������������������������������������������������������������������������������������������������������������� 48
12.1 General .............................................................................................................................................. 48
12.2 Transducers ....................................................................................................................................... 48
12.3 Accelerometers Mounts ................................................................................................................... 50
12.4 Cable Routing .................................................................................................................................... 54
12.5 Abdomen Pressure Twin Sensor (APTS) ............................................................................................ 55
12.5.1 Purpose ................................................................................................................................................55
12.5.2 Description ..........................................................................................................................................55
SECTION 13
Pretest Checks ������������������������������������������������������������������������������������������������������������������� 57
13.1 Recommended Spare Parts ............................................................................................................... 59

012-9900 Q10 2020 USER MANUAL [REV. 1]
©2020 HUMANETICS
| X
Table of Contents
SECTION 14
Certification Equipment�������������������������������������������������������������������������������������������������� 60
14.1 Requirements .................................................................................................................................... 60
14.2 Equipment ......................................................................................................................................... 60
14.2.1 Head Drop ..........................................................................................................................................60
14.2.2 Neck and Lumbar Spine ......................................................................................................................61
14.2.3 Full Body Pendulum ............................................................................................................................63
14.2.4 Abdomen Test Rig ...............................................................................................................................64
14.3 Equipment List ................................................................................................................................... 65
SECTION 15
Certification Procedures������������������������������������������������������������������������������������������������� 68
15.1 Head Certification ............................................................................................................................. 68
15.1.1 General ................................................................................................................................................68
15.1.2 Instrumentation ..................................................................................................................................68
15.2 Frontal Impact Head Certification..................................................................................................... 68
15.2.1 Test Procedure ....................................................................................................................................68
15.2.2 Data Processing ...................................................................................................................................69
15.2.3 Requirement ........................................................................................................................................69
15.3 Lateral Impact Head Certification ..................................................................................................... 70
15.3.1 Test Procedure ....................................................................................................................................70
15.3.2 Data Processing ...................................................................................................................................71
15.3.3 Requirement ........................................................................................................................................71
15.4 Neck Certification .............................................................................................................................. 71
15.4.1 General ................................................................................................................................................71
15.5 Flexion Neck Test ............................................................................................................................. 72
15.5.1 Set-up ..................................................................................................................................................72
15.5.2 Performing the Test ............................................................................................................................73
15.5.3 Data Processing ...................................................................................................................................73
15.5.4 Requirements ......................................................................................................................................73
15.6 Extension Neck Test ..........................................................................................................................74
15.6.1 Set-up ..................................................................................................................................................74
15.6.2 Performing the Test ............................................................................................................................75
15.6.3 Data Processing ...................................................................................................................................75
15.6.4 Requirements ......................................................................................................................................75

012-9900 Q10 2020 USER MANUAL [REV. 1]
©2020 HUMANETICS
| XI
Table of Contents
15.7 Lateral Neck Test ............................................................................................................................... 76
15.7.1 Set-up ..................................................................................................................................................76
15.7.2 Performing the Test ............................................................................................................................77
15.7.3 Data Processing ...................................................................................................................................77
15.7.4 Requirements ......................................................................................................................................77
15.8 Lumbar Spine Certification ................................................................................................................ 78
15.8.1 General ................................................................................................................................................78
15.9 Frontal Spine Test .............................................................................................................................. 78
15.9.1 Set-up ..................................................................................................................................................78
15.9.2 Performing the Test ............................................................................................................................79
15.9.3 Data Processing ...................................................................................................................................80
15.9.4 Requirements ......................................................................................................................................80
15.10 Lateral Spine Test .............................................................................................................................. 80
15.10.1 Set-up ..................................................................................................................................................80
15.10.2 Performing the Test ............................................................................................................................81
15.10.3 Data Processing ...................................................................................................................................82
15.10.4 Requirements ......................................................................................................................................82
15.11 Thorax Certification........................................................................................................................... 82
15.11.1 General ................................................................................................................................................82
15.12 Frontal Impact Thorax Test ............................................................................................................... 83
15.12.1 Instrumentation ..................................................................................................................................83
15.12.2 Test procedure ....................................................................................................................................83
15.12.3 Data Processing ...................................................................................................................................83
15.12.4 Requirement ........................................................................................................................................84
15.13 Side Impact Thorax Test .................................................................................................................... 84
15.13.1 Instrumentation ..................................................................................................................................84
15.13.2 Test procedure ....................................................................................................................................84
15.13.3 Data Processing ...................................................................................................................................85
15.13.4 Requirement ........................................................................................................................................85
15.14 Shoulder Lateral Impact Test/Application for Frontal Dummy with Full Arms ................................. 85
15.14.1 Instrumentation ..................................................................................................................................85
15.14.2 Test procedure ....................................................................................................................................86
15.14.3 Data Processing ...................................................................................................................................86
15.14.4 Requirement ........................................................................................................................................86

012-9900 Q10 2020 USER MANUAL [REV. 1]
©2020 HUMANETICS
| XII
Table of Contents
15.15 Side Impact Pelvis Test ...................................................................................................................... 87
15.15.1 Instrumentation ..................................................................................................................................87
15.15.2 Test procedure ....................................................................................................................................87
15.15.3 Data Processing ...................................................................................................................................89
15.15.4 Requirement ........................................................................................................................................89
15.16 Abdomen Certification ...................................................................................................................... 89
15.16.1 General ................................................................................................................................................89
15.16.2 Instrumentation ..................................................................................................................................89
15.16.3 Test Procedure ....................................................................................................................................90
15.16.4 Data Processing ...................................................................................................................................90
15.16.5 Requirement ........................................................................................................................................90
15.17 Shoulder Lateral Impact Test/Application for Side Impact Shoulder Kit .......................................... 91
15.17.1 Instrumentation ..................................................................................................................................91
15.17.2 Test procedure ....................................................................................................................................91
15.17.3 Data Processing ...................................................................................................................................91
15.17.4 Requirement ........................................................................................................................................92
SECTION 16
Mass Measurement���������������������������������������������������������������������������������������������������������� 93
SECTION 17
External Measurement���������������������������������������������������������������������������������������������������� 94
SECTION 18
Dummy Setup and Positioning Procedure���������������������������������������������������������������� 96
18.1 Guidelines for set-up and positioning ............................................................................................... 96
18.2 Marker and Instrumentation locations ............................................................................................. 96
18.2.1 General ...............................................................................................................................................97
18.2.2 Markers Location Coordinates and Relevant Dimensions .................................................................97
18.2.3 Instrumentation Location Coordinates and Relevant Dimensions ..................................................100
SECTION 19
IR-TRACC Processing������������������������������������������������������������������������������������������������������� 102
19.1 2D IR-TRACC ‘Absolute Length’ Verification .................................................................................... 102
19.2 Theory of the Procedure ................................................................................................................. 102
19.3 Data Post Processing ....................................................................................................................... 107
19.4 Checking Polarity ............................................................................................................................. 109

012-9900 Q10 2020 USER MANUAL [REV. 1]
©2020 HUMANETICS
| XIII
Table of Contents
SECTION 20
Q10 Side Impact Shoulder Kit�������������������������������������������������������������������������������������� 111
20.1 Side Impact Kit Description ............................................................................................................. 111
20.2 Assembly and Disassembly ............................................................................................................. 112
20.2.1. Starting Condition with Old SBL A Shoulder Interface Part and Lower Neck Interface Plate .........112
20.2.2 Starting Condition with New Shoulder Interface Part and Lower Neck Interface Plate .................113
20.3 Instrumentation ............................................................................................................................... 114
SECTION 21
Q10 2020 Kit��������������������������������������������������������������������������������������������������������������������� 115
21.1 Introduction ..................................................................................................................................... 115
SECTION 22
Reference �������������������������������������������������������������������������������������������������������������������������� 117
SECTION 23
Disclaimer ������������������������������������������������������������������������������������������������������������������������� 118
SECTION 24
Update Log������������������������������������������������������������������������������������������������������������������������ 119

012-9900 Q10 2020 USER MANUAL [REV. 1]
©2020 HUMANETICS
List of Figures
| XIV
List of Figures
Figure 1.1 Dummy Coordinate System (SAE J1733 Issued DEC94) .................................................................. 4
Figure 3.1 Top Level Assembly ......................................................................................................................... 7
Figure 3.2 Top Level Assembly Exploded View ................................................................................................ 8
Figure 3.3 Remove the Skull Cap ................................................................................................................... 10
Figure 3.4 Remove the Accelerometer Mounting Bracket ............................................................................ 10
Figure 3.5 Disassemble the Neck Assemble from the Head Assembly ......................................................... 11
Figure 3.6 Remove the Neck Assembly from the Torso Assembly ............................................................... 12
Figure 3.7 Remove the M6 X 1 X 55 LG. SHCS ZINC ....................................................................................... 13
Figure 3.8 Remove Arms from the Shoulder ................................................................................................. 13
Figure 3.9 Remove M5 X 0.8 X 16 LG. SHCS ZINC to Free the Load Cell Structural Replacement ................ 14
Figure 3.10 Remove the M5 X 0.8 X 10 LG. SHCS to Remove the Lumbar Assembly ................................... 14
Figure 3.11 Remove the Pelvis Flesh.............................................................................................................. 15
Figure 3.12 Remove the Legs from the Pelvis ............................................................................................... 15
Figure 4.1 Head Assembly Exploded View .................................................................................................... 16
Figure 4.2 Attach the Load Cell to the Skull Molded Assembly .................................................................... 17
Figure 4.3 Attach the Head to the Neck ........................................................................................................ 18
Figure 4.4 Attach the Mounting Bracket to the Head ................................................................................... 18
Figure 4.5 Attach the Skull Cap ...................................................................................................................... 19
Figure 5.1 Neck Exploded View ..................................................................................................................... 20
Figure 5.2 Assemble the Neck Cable, Bushing, Washers, and Nut to the Molded Neck .............................. 21
Figure 6.1 Thorax Exploded View .................................................................................................................. 22
Figure 6.2 Attach the Side Impact IR-TRACC Mount ..................................................................................... 24
Figure 6.3 Attach the IR-TRACCs to the Side Impact Mount ......................................................................... 24
Figure 6.4 Frontal IR-TRACC Configuration .................................................................................................... 25
Figure 7.1 Arm Assembly View ...................................................................................................................... 26
Figure 7.2 Upper Arm Exploded View ............................................................................................................ 27
Figure 7.3 Lower Arm Exploded View ............................................................................................................ 28
Figure 7.4 Assemble Lower Arm to Upper Arm ............................................................................................. 29
Figure 7.5 Attach the Upper Arms to the Shoulder ....................................................................................... 30
List of Figures

012-9900 Q10 2020 USER MANUAL [REV. 1]
©2020 HUMANETICS
List of Figures
| XV
Figure 8.1 Lumbar Exploded View (Optional Instrumentation shown) ......................................................... 31
Figure 8.2 Assemble the Cable, Washer, and Lock Nut to the Lumbar Spine, Molded ................................ 32
Figure 9.1 Pelvis Exploded View .................................................................................................................... 33
Figure 9.2 Assemble the Sacrum Top Plate, Central Support Assembly, and Bottom Plate Together ......... 35
Figure 9.3 Attach the Sacro Iliac Load Cell Structural Replacement ............................................................. 36
Figure 9.4 Attach the Interface Sacro Iliac Load Cell ..................................................................................... 36
Figure 9.5 Attach the DAS Ballast, Pelvis to the Sacrum Front Plate ............................................................ 37
Figure 9.6 Attach the Iliac Wings, the Pubic Buffer and the Pubic Structural Replacement Load Cell ........ 37
Figure 9.7 Attach the Retaining Plate and the Load Cell ............................................................................... 38
Figure 9.8 Assemble the Pelvic Flesh, Femur Ball Assembly, and Hip Ball Retaining Plate........................... 38
Figure 9.9 Hip Adjuster Location.................................................................................................................... 39
Figure 10.1 Leg Assembly View ..................................................................................................................... 40
Figure 10.2 Left Upper Leg Exploded View ....................................................................................................41
Figure 10.3 Right Upper Leg Exploded View ................................................................................................. 42
Figure 10.4 Lower Leg exploded view ........................................................................................................... 43
Figure 10.5 Attach the Lower Leg to the Upper Leg ..................................................................................... 44
Figure 10.6 Attach Legs to Pelvis ................................................................................................................... 45
Figure 11.1 Suit .............................................................................................................................................. 46
Figure 11.2 Fitting of the Hip Shields ............................................................................................................. 47
Figure 11.3 Fitted Hip Shields with Recommended Min. Distance between Shields ................................... 47
Figure 12.1 Q10 2020 Instrumentation Overview ......................................................................................... 48
Figure 12.2 Head Accel Mounts for Type 7264C (034-1201 with ARS & 020-1017 w/o) ...............................51
Figure 12.3 Head Accel Mounts for Type 7264B (036-1101 with ARS & I.AD w/o) for T1 Accelerometer ....51
Figure 12.4 Thorax Accel mounts at T4 for Type 7264C (034-1201 with ARS & 020-1017 w/o) ................... 52
Figure 12.5 Thorax Accel Mounts at T4 for Type 7264B (036-1101 with ARS & I.AD w/o) ........................... 52
Figure 12.6 Pelvis Accel Mounts for Type 7264C (034-1201 with ARS & 020-1017 w/o) ............................. 53
Figure 12.7 Pelvis Accel Mounts for Type 7264B (036-1101 with ARS and I.AD w/o) ................................... 53
Figure 12.8 Recommended Wire Routing to Pubic Load Cell ....................................................................... 54
Figure 12.9 50 mm Bladder Details ............................................................................................................... 55
Figure 12.10 Q10 Abdomen APTS Sleeves Assembled w/o Sensors & Foam Plugs for Certification ........... 56

012-9900 Q10 2020 USER MANUAL [REV. 1]
©2020 HUMANETICS
List of Figures
| XVI
Figure 14.1 Neck (left) and Lumbar Spine (right) Headform Test Set-Up for Frontal Test ............................ 61
Figure 14.2 Neck (left) and Lumbar Spine (right) Headform Test Set-Up for Lateral Test ............................ 61
Figure 14.3 Q10 Full Body Impactor .............................................................................................................. 63
Figure 14.4 Full Body Pendulum Impactor Suspension Wire Diagram .......................................................... 64
Figure 14.5 TE-2651 Head Drop Fixture ......................................................................................................... 65
Figure 14.6 TE-2650-Q10KIT Neck and Lumbar Headform ........................................................................... 66
Figure 14.7 From Left, Neck Adaptor Plate, Head Drop Ballast, and Lumbar Central Block ......................... 67
Figure 15.1 Frontal Impact Test Procedure ................................................................................................... 69
Figure 15.2 Lateral Impact Test Procedure ................................................................................................... 70
Figure 15.3 Neck Certification Setup for Frontal Flexion Test, View from Rear in Drop Position ................ 72
Figure 15.4 Neck Certification Setup for Frontal Extension Test, Front in Drop Position View ....................74
Figure 15.5 Neck Certification Setup for Lateral Test, View from Rear in Drop Position ............................. 76
Figure 15.6 Lumbar Spine Frontal Set-Up, View from Rear in Drop Position................................................ 79
Figure 15.7 Q10 Lumbar Spine lateral set-up, view from rear in drop position ........................................... 81
Figure 15.8 Front View of Pelvis Certification Setup ..................................................................................... 87
Figure 15.9 Side View of Pelvis Certification Setup ....................................................................................... 88
Figure 15.10 Abdomen Certification Test set-up .......................................................................................... 89
Figure 15.11 Abdomen Certification Test set-up .......................................................................................... 90
Figure 17.1 External Dimension ..................................................................................................................... 94
Figure 18.1 Marker Positions on Dummy ...................................................................................................... 98
Figure 19.1 Example 2D-IR-TRACC Assembly Absolute Length Verification Sheet ..................................... 102
Figure 19.2 Relation Between Absolute Intercept in mm and Volts & Values in Verification Sheet .......... 103
Figure 19.3 2D IR-TRACC Assembly ............................................................................................................. 104
Figure 19.4 Orientation Angle, Offset Angle, and Reference Angle Definitions ......................................... 105
Figure 19.5 Verification Sheet Example ....................................................................................................... 106
Figure 19.6 2D IR-TRACCs in Lateral LH Side Impact Configuration ............................................................ 109
Figure 20.1 Q10 Side Impact Kit Shoulder Parts.......................................................................................... 111
Figure 20.2 Q10 Side Impact Kit with Shoulder Joint Accelerometer Ay .................................................... 114
Figure 20.3 Q10 Side Impact Kit with T1 Ay Accelerometers Installed ....................................................... 114
Figure 21.1 Q10 2020 Kit.............................................................................................................................. 115

012-9900 Q10 2020 USER MANUAL [REV. 1]
©2020 HUMANETICS
List of Tables
| XVII
List of Tables
Table 2-1 Hardware and Fastener Abbreviations ............................................................................................ 5
Table 2-2 List of Recommended Tools ............................................................................................................. 5
Table 2-3 Recommended Fastener Torque Specifications (SHCS) .................................................................. 6
Table 2-4 Recommended Fastener Torque Specifications (BHCS & FHCS) ..................................................... 6
Table 3-1 Top Level Assembly Parts List .......................................................................................................... 9
Table 4-1 Head Assembly Parts List ............................................................................................................... 17
Table 5-1 Neck Assembly Parts List ............................................................................................................... 20
Table 6-1 Thorax Assembly Parts Lists .......................................................................................................... 23
Table 7-1 Arm Assembly Parts List ................................................................................................................. 26
Table 7-2 Upper Arm Assembly Parts List ..................................................................................................... 27
Table 7-3 Lower Arm Assembly Parts List ...................................................................................................... 28
Table 8-1 Lumbar Assembly Parts List ........................................................................................................... 31
Table 9-1 Pelvis Assembly Parts List .............................................................................................................. 34
Table 10-1 Leg Assembly Parts List ................................................................................................................ 40
Table 10-2 Left Upper Leg Parts List ...............................................................................................................41
Table 10-3 Right Upper Leg Parts List ............................................................................................................ 42
Table 10-4 Lower Leg Parts List ...................................................................................................................... 43
Table 12-1 Q10 2020 Instrumentation ........................................................................................................... 49
Table 12-2 Uni-Axial Accelerometers ............................................................................................................. 50
Table 12-3 APTS Component Part Numbers .................................................................................................. 56
Table 13-1 Recommended Spare Parts List ................................................................................................... 59
Table 14-1 Probe Specs .................................................................................................................................. 63
Table 14-2 Equipment Parts List .................................................................................................................... 65
Table 15-1 Neck Test Components ................................................................................................................ 71
Table 15-2 Pendulum Velocity ....................................................................................................................... 73
Table 15-3 Pendulum Velocity ....................................................................................................................... 75
Table 15-4 Pendulum Velocity ....................................................................................................................... 77
Table 15-5 Lumbar Parts List ......................................................................................................................... 78
Table 15-6 Pendulum Velocity ....................................................................................................................... 80
Table 15-7 Pendulum Velocity ....................................................................................................................... 82
List of Tables

012-9900 Q10 2020 USER MANUAL [REV. 1]
©2020 HUMANETICS
List of Tables
| XVIII
Table 15-8 Abdomen Certification Weights .................................................................................................. 90
Table 16-1 Q10 Assembly Masses.................................................................................................................. 93
Table 17-2 External Dimensions ..................................................................................................................... 94
Table 18-1 Markers Head and Neck, Origin: Occipital Condoyle .................................................................. 98
Table 18-2 Markers Torso, Origin: Erect Seating, Intersection of Seat Back, Seating & Mid-sagittal-plane 99
Table 18-3 Markers Arms, Origin: Elbow Joint Center, Upper Arm Bone Vertical & Horizontal ................... 99
Table 18-4 Markers Legs, Origin: Knee Joint Center, Upper Leg Bone Horizontal & Vertical ..................... 100
Table 18-5 Markers Head and Neck, Origin: Occipital Condoyle ................................................................ 100
Table 18-6 Markers Torso, Origin: Erect Seating, Intersection of Seat Back, Seating & Mid-sagittal-plane
.......................................................................................................................................................................100
Table 19-1 Calculation Parameters, Symbols, and Description ................................................................... 107
Table 19-2 Example ISO codes for Upper and Lower 2D IR-TRACCs in SI Units .......................................... 108
Table 19-3 Dummy Manipulations & Parameter Responses (after post processing) ................................. 110
Table 20-1 Side Impact Kit Shoulder Parts List ............................................................................................ 112
Table 21-1 Parts Removed and Added for Kit .............................................................................................. 116
Table 24-1 Update Log ................................................................................................................................. 119

012-9900 Q10 2020 USER MANUAL [REV. 1]
©2020 HUMANETICS
SECTION 1
Introduction
| 1
SECTION 1
Introduction
1�1 Q10 2020 Introduction
In the late 1970’s and early 1980’s, TNO and others developed the P-dummies, a series of child dummies that cover
almost the complete child population up to 10 years. The P-series dummies up to 2013 are still test tools for the
European regulation ECE-R44 and are also adopted by many other standards.
In 1993 the international Child Dummy Working Group started the development of a new series of child dummies as
a successor to the P-series. This new series was called the Q-series.
The Q series dummies are available in the following age groups: Newborn, 1 year, 1 ½ year, 3 year, 6 year and 10
year old child. The Q3s is a side impact only adaptation of the Q3 dummy designed to complement the Part 572
Subpart P Hybrid III 3 year old child dummy. A Q6s dummy is also available.
Humanetics controls the configuration of the Q-dummies in close contact with dummy user groups and regulatory
bodies like EuroNCAP and UNECE-GRSP. Since spring 2004 the design of the Q-dummies was frozen and no changes,
that affect the dummy performance or interchangeability of parts, were implemented.
In 2009-2011 the last member of the Q-dummy family was developed and evaluated in a European FP7 Project
called EPOCh. In 2011-2012 third parties evaluated the Q10 prototype dummy (SBL-A). These evaluations resulted in
recommendation for design updates that were implemented in SBL-B.
In the European Enhanced Vehicle-Safety Committee Q10 dummy report – Advanced Child Dummies and Injury
Criteria for frontal dummies 2015 it is recommended “Based on the extensive evaluation and validation results
described in this report, EEVC recommends that the Q10 dummy is used in child restraint homologation tests (UN
R129).” For the other recommendations and further details please refer to the full report. [vii]
In 2015 Euro NCAP requested a design update to address issues that came to light in full scale car testing. The
main issue to address was to improve shoulder belt stability. Humanetics designed solutions and build a prototype
that was evaluated in 2017. After the internal and third party evaluation of the 2017 prototype, a limited set of
design updates were selected by Euro NCAP. In September 2018 the hardware update proposed was adopted for
the Euro NCAP 2020 protocol called the Q10 2020 configuration. To comply with Euro NCAP approval process, the
Humanetics 2020 kit was subjected to a large suit of (comparative) tests that were conducted with the help of Euro
NCAP labs ADAC, BASt and TASS and various vehicle manufacturers and Tier-1 suppliers. Comparative data was
submitted to Euro NCAP at component level on geometry, mass and dynamic response and further at full dummy
level in certification, sled and full scale vehicle type testing. Generally the reported differences with the competitor
hardware were minor and within tolerance; dynamic and kinematic performance were found very similar and within
expected dummy variation. For injury prediction both kits gave very similar results. For details of the evaluation
results refer to conference presentations [i] and [ii].
In April 2020 the Humanetics Q10 2020 hardware was accredited by Euro NCAP. This manual describes the Q10
2020 dummy (drawing 012-0000).
The so called standard Q10 production version dummy is still in use in UN-ECE Regulation 129. The standard dummy
is described in the 010-9900 User Manual Q10. In that manual the history of Q10 hardware updates are listed.
In chapter 14.21 of this manual it is described how to modify the standard Q10 into the Q10 2020 by replacing 23
parts in the Q10 2020 Update kit (010-4450)

012-9900 Q10 2020 USER MANUAL [REV. 1]
©2020 HUMANETICS
SECTION 1
Introduction
| 2
1�1�1 DEVELOPMENT HISTORY
Q10 design started in 2009 and was developed with co-funding from the EU commission within the Seventh
Framework program under the project name EPOCh (Enable Protection for Older Children). The Q10 has the
anthropometry of a 10.5 year old 50th percentile child as defined in CANDAT (Child ANthropometry DATabase).
After EPOCH improvements were made taking comments from users into consideration, this raised the standard
build level to SBL-B. In 2013 a lateral shoulder kit was developed which raised the service build level (SBL) to C.
In 2018 the Q10 2020 (012-0000) configuration for Euro NCAP 2020 protocol testing was defined alongside the
standard Q10 dummy used for CRS testing according to UNECE Regulation 129.
1�1�2 APPLICATION
The Q10 dummy is suitable for frontal as well as side impact CRS evaluations, to be used for both homologation,
consumer rating and research purposes. Possible applications include:
• Child Restraint Systems (CRS) testing� This includes the European UNECE R129 and the US FMVSS
213 regulations� The Q-dummies have been designed to succeed the P-dummies in CRS evaluation
regulations�
• EuroNCAP tests� The dummy has been designed to withstand impacts up to 64 km/h partial overlap and
56 km/h full width frontal tests under the EuroNCAP protocol on the rear seat in modern cars�
1�1�3 STANDARD DUMMY DELIVERY
The standard Q-dummy is delivered with the following items (if not ordered otherwise):
• Clothing (a yellow suit);
• Hip shields (red colored)
• Structural replacements in the location of the load cells;
• Mounting blocks for use with uni-axial accelerometers and angular velocity sensors to customer
requirements�
• Two 2D-IRTRACCs mounted in the chest
• H-shaped bracket for mounting the 2D-IRTRACCs in side impact configuration
• Provisions for IES tilt sensors in head, thorax and pelvis
• Dummy tool, hip adjuster
• Manual
1�2 Getting Familiar with the User Manual
This manual is designed to serve as a reference book for technical people working with the Q10 2020 Crash Test
Dummy. Each assembly of the Q10 2020 dummy has been described in great detail to assist the technical personnel
in the proper set-up and adjustment of the dummy for testing. The user manual has been divided into sections as
outlined below:
• Introduction
• Dummy Preparation and Use
• Top Level Dummy Assembly
• Head Assembly
• Neck Assembly
