Humminbird Helix Series User manual

BOW UNIT
CONSOLE UNIT
Networking
Graph
Networking
Graph
Cranking
Battery
1
1
2
3
4
5
Transducer supplied with
MEGA Side Imaging unit at
console
Compatible Accessories
HELIX Series SOLIX Series
1Ethernet Adapter Cable (need 2) Ethernet Adapter Cable
720074-1 AS EC QDE NA
2Ethernet Cable (need 1) Ethernet Cable (need 1)
720073-6
720073-2
720073-5
720073-3
720073-4
AS EC 5E (5’)
AS EC 10E (10’)
AS EC 15E (15’)
AS EC 20E (20’)
AS EC 30E (30’)
720073-6
720073-2
720073-5
720073-3
720073-4
AS EC 5E (5’)
AS EC 10E (10’)
AS EC 15E (15’)
AS EC 20E (20’)
AS EC 30E (30’)
3GPS + Heading Sensor GPS + Heading Sensor
408400-1 AS GPS HS 408400-1 AS GPS HS
720080-1 AS GPS NMEA
4Transducer Splitter Cable Transducer Splitter Cable
720101-1 9 M SIDB Y 720103-1 14 M SIDB Y
5High Speed Transducer (fiberglass hull) High Speed Transducer (fiberglass hull)
710276-1 XP 9 HW T 710287-1 XP 14 HW T
High Speed Transducer (aluminum hull) High Speed Transducer (aluminum hull)
710274-1 XNT 9 HW T 710285-1 XNT 14 HW T
The accessories and part numbers listed are valid as of April 2020. Installations shown are for
HELIX G3N and SOLIX G2 networking models and Minn Kota trolling motors with i-Pilot Link.
NMEA 0183 Ethernet 12V DC Power Transducer Cable
INSTALLATION DIAGRAMS
(1) Humminbird bow unit and (1) console unit
networked together, with heading sensor GPS
puck and high-speed transducer with y-cable

BOW UNIT
CONSOLE UNIT
Networking
Graph
Networking
Graph
Cranking
Battery
Trolling Motor
Batteries
1
1
2
2
4
3
8
Transducer supplied with
MEGA Side Imaging unit at
console
6
7
5
Compatible Accessories
HELIX Series SOLIX Series
1Ethernet Adapter Cable (need 2) Ethernet Adapter Cable
720074-1 AS EC QDE NA
2Ethernet Cable (need 2) Ethernet Cable (need 2)
720073-6
720073-2
720073-5
720073-3
720073-4
AS EC 5E (5’)
AS EC 10E (10’)
AS EC 15E (15’)
AS EC 20E (20’)
AS EC 30E (30’)
720073-6
720073-2
720073-5
720073-3
720073-4
AS EC 5E (5’)
AS EC 10E (10’)
AS EC 15E (15’)
AS EC 20E (20’)
AS EC 30E (30’)
3GPS + Heading Sensor GPS + Heading Sensor
408400-1 AS GPS HS 408400-1 AS GPS HS
720080-1 AS GPS NMEA
4Minn Kota Trolling Motor with i-Pilot
Link and Built-In MEGA Imaging
Minn Kota Trolling Motor with i-Pilot
Link and Built-In MEGA Imaging
55-Port Ethernet Switch 5-Port Ethernet Switch
408450-1 AS ETH 5PXG 408450-1 AS ETH 5PXG
6Transducer Splitter Cable Transducer Splitter Cable
720101-1 9 M SIDB Y 720103-1 14 M SIDB Y
7High Speed Transducer (fiberglass hull) High Speed Transducer (fiberglass hull)
710276-1 XP 9 HW T 710287-1 XP 14 HW T
High Speed Transducer (aluminum hull) High Speed Transducer (aluminum hull)
710274-1 XNT 9 HW T 710285-1 XNT 14 HW T
8Adapter Cable for Built-In MEGA Imaging Adapter Cable for Built-In MEGA Imaging
1852088
MKR-MI-1
(HELIX 8-12 G2N
and newer)
NA
1852086
MKR-MDI-2 HB
HELIX 7 G2N
/ G3N
NA
* One (1) AS ECX 30E Ethernet Extension cable included with i-Pilot Link trolling motor
The accessories and part numbers listed are valid as of April 2020. Installations shown are for
HELIX G3N and SOLIX G2 networking models and Minn Kota trolling motors with i-Pilot Link.
NMEA 0183 Ethernet 12V DC Power Transducer Cable Bluetooth® Signal
MK
Heading
Sensor
INSTALLATION DIAGRAMS
Minn Kota Trolling Motor with i-Pilot Link
and Built-in MEGA Imaging, (1) bow-mounted
Humminbird unit and (1) console mounted
Humminbird unit

CONSOLE UNIT
Graph
Cranking
Battery
Trolling
Motor
Batteries
1
3
2
4
5
Transducer supplied with
MEGA Side Imaging unit at
console
Compatible Accessories
HELIX Series SOLIX Series
1Ethernet Adapter Cable Ethernet Adapter Cable
720074-1 AS EC QDE NA
2GPS + Heading Sensor GPS + Heading Sensor
408400-1 AS GPS HS 408400-1 AS GPS HS
720080-1 AS GPS NMEA
3Minn Kota Trolling Motor with
i-Pilot Link *
Minn Kota Trolling Motor with
i-Pilot Link *
4Transducer Splitter Cable Transducer Splitter Cable
720101-1 9 M SIDB Y 720103-1 14 M SIDB Y
5High Speed Transducer (fiberglass hull) High Speed Transducer (fiberglass hull)
710276-1 XP 9 HW T 710287-1 XP 14 HW T
High Speed Transducer (aluminum hull) High Speed Transducer (aluminum hull)
710274-1 XNT 9 HW T 710285-1 XNT 14 HW T
* One (1) AS ECX 30E Ethernet Extension cable included with i-Pilot Link trolling motor
The accessories and part numbers listed are valid as of April 2020. Installations shown are for
HELIX G3N and SOLIX G2 networking models and Minn Kota trolling motors with i-Pilot Link.
NMEA 0183 Ethernet 12V DC Power Transducer Cable Bluetooth® Signal
MK
Heading
Sensor
INSTALLATION DIAGRAMS
Minn Kota Trolling Motor with i-Pilot Link
and (1) console-mounted Humminbird unit

CONSOLE UNITS
BOW UNIT
Networking
Graph
Networking
Graph
Networking
Graph
Cranking
Battery
Trolling
Motor
Batteries
1
1 1
2
2
2
6
7
4
5
3
Transducer supplied with
MEGA Side Imaging unit at
console
8
9
Compatible Accessories
HELIX G3N Series SOLIX Series
1Ethernet Adapter Cable (need 3) Ethernet Adapter Cable
720074-1 AS EC QDE NA
2Ethernet Cable (need 3) Ethernet Cable (need 3)
720073-6
720073-2
720073-5
720073-3
720073-4
AS EC 5E (5’)
AS EC 10E (10’)
AS EC 15E (15’)
AS EC 20E (20’)
AS EC 30E (30’)
720073-6
720073-2
720073-5
720073-3
720073-4
AS EC 5E (5’)
AS EC 10E (10’)
AS EC 15E (15’)
AS EC 20E (20’)
AS EC 30E
(30’)
3GPS + Heading Sensor GPS + Heading Sensor
408400-1 AS GPS HS 408400-1 AS GPS HS
720080-1 AS GPS NMEA
4Minn Kota Trolling Motor with i-Pilot
Link and Built-In MEGA Imaging
Minn Kota Trolling Motor with i-Pilot
Link and Built-In MEGA Imaging
55-Port Ethernet Switch 5-Port Ethernet Switch
408450-1 AS ETH 5PXG 408450-1 AS ETH 5PXG
6Transducer Splitter Cable Transducer Splitter Cable
720101-1 9 M SIDB Y 720103-1 14 M SIDB Y
7High Speed Transducer (fiberglass hull) High Speed Transducer (fiberglass hull)
710276-1 XP 9 HW T 710287-1 XP 14 HW T
High Speed Transducer (aluminum hull) High Speed Transducer (aluminum hull)
710274-1 XNT 9 HW T 710285-1 XNT 14 HW T
8Minn Kota Talon with Bluetooth Minn Kota Talon with Bluetooth
Talon SWA Talon SWA
9Adapter Cable for Built-In MEGA Imaging Adapter Cable for Built-In MEGA Imaging
1852088
MKR-MI-1
(HELIX 8-12 G2N
and newer)
NA
1852086
MKR-MDI-2 HB
HELIX 7 G2N /
G3N
NA
* One (1) AS ECX 30E Ethernet Extension cable included with i-Pilot Link trolling motor
The accessories and part numbers listed are valid as of April 2020. Installations shown are for
HELIX G3N and SOLIX G2 networking models and Minn Kota trolling motors with i-Pilot Link.
NMEA 0183 Ethernet 12V DC Power Transducer Cable Bluetooth® Signal
MK
Heading
Sensor
INSTALLATION DIAGRAMS
Minn Kota Trolling Motor with i-Pilot Link and
Built-In MEGA Down Imaging, (1) bow-mounted
Humminbird unit, (2) console-mounted Humminbird
units and Talon Shallow Water Anchor

CONSOLE UNIT
Networking
MFD
3
1
2
Cranking
Battery
Transducer
supplied with
MEGA Side
Imaging unit at
console
Trolling
Motor
Battery
Compatible Accessories
HELIX Series SOLIX Series
1Ethernet Adapter Cable Ethernet Adapter Cable
720074-1 AS EC QDE NA
2GPS + Heading Sensor GPS + Heading Sensor
408400-1 AS GPS HS 408400-1 AS GPS HS
720080-1 AS GPS NMEA
3Minn Kota Trolling Motor with
i-Pilot Link *
Minn Kota Trolling Motor with
i-Pilot Link *
4Transducer Splitter Cable Transducer Splitter Cable
720101-1 9 M SIDB Y 720103-1 14 M SIDB Y
5High Speed Transducer (fiberglass hull) High Speed Transducer (fiberglass hull)
710276-1 XP 9 HW T 710287-1 XP 14 HW T
6High Speed Transducer (aluminum hull) High Speed Transducer (aluminum hull)
710274-1 XNT 9 HW T 710285-1 XNT 14 HW T
* One (1) AS ECX 30E Ethernet Extension cable included with i-Pilot Link trolling motor
The accessories and part numbers listed are valid as of April 2020. Installations shown are for
HELIX G3N and SOLIX G2 networking models and Minn Kota trolling motors with i-Pilot Link.
NMEA 0183 Ethernet 12V DC Power Transducer Cable Bluetooth® Signal
MK
Heading
Sensor
4
5
INSTALLATION DIAGRAMS
Saltwater - Minn Kota Riptide Trolling Motor with
i-Pilot Link and (1) Console Mount Humminbird Unit

CONSOLE UNITS
Networking
MFD
Networking
MFD 3
4
2
5
11
Cranking
Battery
Trolling
Motor
Battery
7
6
Transducer supplied with
MEGA Side Imaging unit at
console
Compatible Accessories
HELIX Series SOLIX Series
1Ethernet Adapter Cable (need 2) Ethernet Adapter Cable
720074-1 AS EC QDE NA
2Ethernet Cable (need 2) Ethernet Cable (need 2)
720073-6
720073-2
720073-5
720073-3
720073-4
760025-1
AS EC 5E - 5’
AS EC 10E - 10’
AS EC 15E - 15’
AS EC 20E - 20’
AS EC 30E - 30’
AS ECX 30E -30’
720073-6
720073-2
720073-5
720073-3
720073-4
760025-1
AS EC 5E - 5’
AS EC 10E - 10’
AS EC 15E - 15’
AS EC 20E - 20’
AS EC 30E - 30’
AS ECX 30E -30’
3GPS + Heading Sensor GPS + Heading Sensor
408400-1 AS GPS HS 408400-1 AS GPS HS
720080-1 AS GPS NMEA
4Minn Kota Trolling Motor with
i-Pilot Link *
Minn Kota Trolling Motor with
i-Pilot Link *
55-Port Ethernet Switch 5-Port Ethernet Switch
408450-1 AS ETH 5PXG 408450-1 AS ETH 5PXG
6High Speed Transducer (fiberglass hull) High Speed Transducer (fiberglass hull)
710276-1 XP 9 HW T 710287-1 XP 14 HW T
High Speed Transducer (aluminum hull) High Speed Transducer (aluminum hull)
710274-1 XNT 9 HW T 710285-1 XNT 14 HW T
7Transducer Splitter Cable Transducer Splitter Cable
720101-1 9 M SIDB Y 720103-1 14 M SIDB Y
* One (1) AS ECX 30E Ethernet Extension cable included with i-Pilot Link trolling motor
The accessories and part numbers listed are valid as of April 2020. Installations shown are for
HELIX G3N and SOLIX G2 networking models and Minn Kota trolling motors with i-Pilot Link.
NMEA 0183 Ethernet 12V DC Power Transducer Cable Bluetooth® Signal
MK
Heading
Sensor
INSTALLATION DIAGRAMS
Saltwater - Minn Kota Riptide Trolling Motor
with i-Pilot Link and (2) console-mounted
Humminbird Units

CONSOLE UNITS
BOW UNIT
Networking
Graph
Networking
Graph
INSTALLATION DIAGRAMS
Minn Kota Trolling Motor with i-Pilot Link
and Built-In MEGA Imaging, (1) Bow-Mounted
Humminbird unit, MEGA 360 Imaging – Ultrex,
(2) Console-Mounted Humminbird units,
and Talon Shallow Water Anchor
Cranking
Battery
Trolling
Motor
Batteries
1
1 1
2
6
7
4
5
3
Transducer supplied
with MEGA Side
Imaging unit at
console
8
9
10 11
Compatible Accessories
HELIX G3N Series SOLIX Series
1Ethernet Adapter Cable (need 3) Ethernet Adapter Cable
720074-1 AS EC QDE NA
2Ethernet Cable (need 3) Ethernet Cable (need 3)
720073-6
720073-2
720073-5
720073-3
720073-4
AS EC 5E (5’)
AS EC 10E (10’)
AS EC 15E (15’)
AS EC 20E (20’)
AS EC 30E (30’)
720073-6
720073-2
720073-5
720073-3
720073-4
AS EC 5E (5’)
AS EC 10E (10’)
AS EC 15E (15’)
AS EC 20E (20’)
AS EC 30E (30’)
3GPS + Heading Sensor GPS + Heading Sensor
408400-1 AS GPS HS 408400-1 AS GPS HS
720080-1 AS GPS NMEA
4Minn Kota Ultrex Trolling Motor with
i-Pilot Link and Built-In Mega Imaging *
Minn Kota Ultrex Trolling Motor with
i-Pilot Link and Built-In Mega Imaging *
55-Port Ethernet Switch 5-Port Ethernet Switch
408450-1 AS ETH 5PXG 408450-1 AS ETH 5PXG
6Transducer Splitter Cable Transducer Splitter Cable
720101-1 9 M SIDB Y 720103-1 14 M SIDB Y
7High Speed Transducer (fiberglass hull) High Speed Transducer (fiberglass hull)
710276-1 XP 9 HW T 710287-1 XP 14 HW T
High Speed Transducer (aluminum hull) High Speed Transducer (aluminum hull)
710274-1 XNT 9 HW T 710285-1 XNT 14 HW T
8Minn Kota Talon with Bluetooth Minn Kota Talon with Bluetooth
Talon SWA Talon SWA
9MEGA 360 and MDI/2D Y-Cable MEGA 360 and MDI/2D Y-Cable
720108-1 14 M360 2DDI Y 720108-1 14 M360 2DDI Y
10 Adapter Cable for MEGA 360 Y-cable Adapter Cable for MEGA 360 Y-cable
AD HELIX M360 (Included with MEGA
360) NA
11 MEGA 360 Imaging MEGA 360 Imaging
411250-1 MEGA 360
Imaging – Ultrex 411250-1 MEGA 360 Imaging – Ultrex
* One (1) AS ECX 30E Ethernet Extension cable included with i-Pilot Link trolling motor
The accessories and part numbers listed are valid as of April 2020. Installations shown are for
HELIX G3N and SOLIX G2 networking models and Minn Kota trolling motors with i-Pilot Link.
NMEA 0183 Ethernet 12V DC Power Transducer Cable Bluetooth® Signal
Networking
Graph
MK
Heading
Sensor

CONSOLE UNITS
BOW UNIT
Networking
Graph
Networking
Graph
Cranking
Battery
Trolling
Motor
Batteries
11
1 1
2
2
2
2
6
7
5
3
Transducer supplied
with MEGA Side
Imaging unit at
console
8
10 9 Compatible Accessories
HELIX G3N Series SOLIX Series
1Ethernet Adapter Cable (need 4) Ethernet Adapter Cable
720074-1 AS EC QDE NA
2Ethernet Cable (need 4) Ethernet Cable (need 4)
720073-6
720073-2
720073-5
720073-3
720073-4
AS EC 5E (5’)
AS EC 10E (10’)
AS EC 15E (15’)
AS EC 20E (20’)
AS EC 30E (30’)
720073-6
720073-2
720073-5
720073-3
720073-4
AS EC 5E (5’)
AS EC 10E (10’)
AS EC 15E (15’)
AS EC 20E (20’)
AS EC 30E (30’)
3GPS + Heading Sensor GPS + Heading Sensor
408400-1 AS GPS HS 408400-1 AS GPS HS
720080-1 AS GPS NMEA
4Minn Kota Ultrex Trolling Motor with
i-Pilot Link and Built-In Mega Imaging *
Minn Kota Ultrex Trolling Motor with
i-Pilot Link and Built-In Mega Imaging *
55-Port Ethernet Switch 5-Port Ethernet Switch
408450-1 AS ETH 5PXG 408450-1 AS ETH 5PXG
6Transducer Splitter Cable Transducer Splitter Cable
720101-1 9 M SIDB Y 720103-1 14 M SIDB Y
7High Speed Transducer (fiberglass hull) High Speed Transducer (fiberglass hull)
710276-1 XP 9 HW T 710287-1 XP 14 HW T
High Speed Transducer (aluminum hull) High Speed Transducer (aluminum hull)
710274-1 XNT 9 HW T 710285-1 XNT 14 HW T
8Minn Kota Talon with Bluetooth (need 2) Minn Kota Talon with Bluetooth (need 2)
Talon SWA Talon SWA
9MEGA 360 Adapter Cable Adapter MEGA 360 Adapter Cable Adapter
AD HELIX M360 (Included with MEGA 360) NA
10 Adapter Cable for Built-In MEGA Imaging Adapter Cable for Built-In MEGA Imaging
#1852088
MKR-MI-1 (HELIX
8-12 G2N and newer)
NA
#1852086 MKR-MDI-2 (HELIX
7 G3/G3N) NA
11 MEGA 360 Imaging MEGA 360 Imaging
411250-1 MEGA 360
Imaging – Ultrex 411250-1 MEGA 360 Imaging – Ultrex
* One (1) AS ECX 30E Ethernet Extension cable included with i-Pilot Link trolling motor
The accessories and part numbers listed are valid as of April 2020. Installations shown are for
HELIX G3N and SOLIX G2 networking models and Minn Kota trolling motors with i-Pilot Link.
NMEA 0183 Ethernet 12V DC Power Transducer Cable Bluetooth® Signal
MK
Heading
Sensor
8
Networking
Graph
Networking
Graph
INSTALLATION DIAGRAMS
Minn Kota Ultrex Trolling Motor with i-Pilot Link
and Built-In MEGA Imaging, (2) Bow-Mounted
Humminbird units, MEGA 360 Imaging – Ultrex,
(2) Console-Mounted Humminbird units,
and Talon Shallow Water Anchor
4
11

BOW UNIT
Trolling Motor
Batteries
2
1
3
4
5
Compatible Accessories
HELIX G3N Series SOLIX Series
1GPS + Heading Sensor GPS + Heading Sensor
408400-1 AS GPS HS 408400-1 AS GPS HS
720080-1 AS GPS NMEA
2Minn Kota Ultrex Trolling Motor with
i-Pilot Link and Built-In Mega Imaging *
Minn Kota Ultrex Trolling Motor with
i-Pilot Link and Built-In Mega Imaging *
3MEGA 360 and MDI/2D Y-Cable MEGA 360 and MDI/2D Y-Cable
720108-1 14 M360 2DDI Y 720108-1 14 M360 2DDI Y
4MEGA 360 Adapter Cable MEGA 360 Adapter Cable
AD HELIX M360
(Included with
MEGA 360)
NA
5MEGA 360 Imaging MEGA 360 Imaging
411250-1 MEGA 360
Imaging – Ultrex 411250-1 MEGA 360 Imaging – Ultrex
The accessories and part numbers listed are valid as of April 2020. Installations shown are for
HELIX G3N and SOLIX G2 networking models and Minn Kota trolling motors with i-Pilot Link.
NMEA 0183 Ethernet 12V DC Power Transducer Cable Bluetooth® Signal
Networking
Graph
MK
Heading
Sensor
Cranking
Battery
INSTALLATION DIAGRAMS
Adding a MEGA 360 Imaging – Ultrex model
to a boat with (1) Bow-Mounted Humminbird unit
and Minn Kota motor with Built-In MEGA Imaging

BOW UNIT
Cranking
Battery
1
43
Networking
Graph
Networking
Graph
MK
Heading
Sensor
Trolling Motor
Batteries
Compatible Accessories
HELIX G3N Series SOLIX Series
1GPS + Heading Sensor GPS + Heading Sensor
408400-1 AS GPS HS 408400-1 AS GPS HS
720080-1 AS GPS NMEA
2Minn Kota Ultrex Trolling Motor with
i-Pilot Link and Built-In Mega Imaging *
Minn Kota Ultrex Trolling Motor with
i-Pilot Link and Built-In Mega Imaging *
3Adapter Cable for Built-In MEGA Imaging Adapter Cable for Built-In MEGA Imaging
#1852088
MKR-MI-1 (HELIX
8-12 G2N and
newer)
NA
#1852086 MKR-MDI-2
(HELIX 7 G3/G3N) NA
4MEGA 360 Adapter Cable MEGA 360 Adapter Cable
AD HELIX M360
(Included with
MEGA 360)
NA
5MEGA 360 Imaging MEGA 360 Imaging
411250-1 MEGA 360
Imaging - Ultrex 411250-1 MEGA 360 Imaging - Ultrex
The accessories and part numbers listed are valid as of April 2020. Installations shown are for
HELIX G3N and SOLIX G2 networking models and Minn Kota trolling motors with i-Pilot Link.
NMEA 0183 Ethernet 12V DC Power Transducer Cable Bluetooth® Signal
INSTALLATION DIAGRAMS
Adding a MEGA 360 Imaging – Ultrex model
to a boat with (2) Bow-Mounted Humminbird units
and Minn Kota motor with Built-In MEGA Imaging
2
5
