PowerView® Curtain

Track Transceiver

User Manual

Installing the Curtain track with Powerview® Transceiver

Installing the track

1. Assemble the track

2. Install the brackets to the wall ot ceiling and x the track onto

the brackets

3. Do not aach drapery aer end posions have been set or

complete installaon is nished.

•posion the master carrier(s) into half open posion

4. Aach motor to the track.

•Posion motor drive head into the track gear. (motor is in

posion when locking pin can be secured).

Connecng power and communicaon

5. Mount Transceiver dongle to track motor like below

P.S. actual look of dongle might dier from drawing below

6. Connect data cable between PowerView Transceiver and motor

(Input: Port2)

6. Connect Forest DC or AC plug to the power socket of the Shule® motor.

7. Connect AC plug of Forest power supply to wall socket.

Seng and adjusng end limits Shule© motor

Aer power up open and close posions are to be referenced by the shule

motor.

1. Push/press track carrier towards CLOSE posion, carrier will travel to

wards CLOSE posion automacally.

2. Push/press track carrier towards OPEN posion, carrier will travel towards

OPEN posion automacally.

To adjust to a customized curtain stack back (OPEN) posion please follow

the following instrucons.

3. Aer the track carrier reaches open posion LED 4 will light-up yellow,

within 10 seconds the curtain stack back posion can be manually

adjusted.

4. Aer the Yellow LED goes o, the end posions are stored into the

memory.

5. For Re-adjusng the end limits rst follow the following reset sequence

followed by steps 1 through 4 of this manual.

Stack back posion can

also be adjusted using a

paired PV remote.

Pairing PowerView© Transceiver with PowerView© remote

Adding the Curtain Transceiver to a remote can be done using the normal

procedure for adding a shade to a remote.

See Quickstart guide “ adding a shade to remote”

1. Press and hold STOP on the remote

unl lights start blinking

2. Select desired group (1-6) on re-

mote

3. Press and hold the PV transceiver

buon (transceiver LED will ash

1x red and 1x green)

4. Push OPEN on the remote, forest

track will move to indicate it has

joined the group on the remote

5. Press and hold STOP buon on the

remote unl lights stop ashing.

PowerView Transceiver LED Feedback

PV Transceiver LED ashing 5 x red: (repeon of

signalling sequence in a loop)

No correct communicaon to FOREST shule.

Please check if PV Transceiver is connected correctly

to “PORT 2 AUX” of shule motor

PV Transceiver LED ashing 2 x orange 1x red (long) and

2 x green:

PV Transceiver is connected correctly and is ready for

operaon

PV Transceiver LED ashing 4 x red and 1 x green:

(repeon of signalling sequence in a loop)

PV Transceiver is connected correctly but FOREST

shule is not referenced.

Please set shule end limits as described at chapter

seng end limits

PowerView Transceiver Curtain Track - Technical data

PowerView® Transceiver Curtain track

Arcle name: PV Transceiver CT

Arcle code: 17.0345.0000

Nominal voltage (dc) 5.0

Maximum current (mA) 15

92 x 40 x 31.5Dimensions (mm)

Operaon temperature (°C) 0 – 60

Duty rang 100% on

Weight (g) 34

IP protecon class 40

Radio frequency (GHz) 2,407

Type of connecon RJ45

Cable length (mm) 150

Cable colour White

Approvals CE

PowerView Transceiver - Addional technical notes

Please note:

PV Transceiver behaviour aer a power failure:

A recalibraon run for the forest shule is required aer a power failure.

Shule recalibraon run starts automacally and always in close direcon

aer rst user operaon command (manually or by radio and regardless of

selected operang direcon). Recalibraon run cannot be interrupted even

with STOP command.

Please note:

PV Transceiver registraon in APP:

In the PV APP the PV curtain track Transceiver is shown as

“Provenance® Vercal” product.

Legal noce

This device complies with Industry Canada licence-exempt RSS standard(s) and part 15 of the FCC Rules. Operaon is subject to the following two

condions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause unde-

sired operaon of the device.

Changes or modicaons not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

"Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitaon est autorisée aux

deux condions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'appareil doit accepter tout brouillage radioélectrique subi, même

si le brouillage est suscepble d'en compromere le fonconnement."

Safety instrucons

The motor may only be installed by qualied personnel who:

• Have read and understood the mounng instrucons of both curtain track, motor and communicaon transceiver

• Are familiar with the electronic safety aspects

• Recognize and avoid danger which can be produced from the mechanical or electrical components

• Always observe and are familiar with the local safety, labour regulaons and laws

Important noce

Hunter Douglas Europe B.V. and its aliates (Hunter Douglas) reserve the right to make correcons, enhancements, improvements and other changes to

its products and services, and to disconnue any product or service. Buyers should obtain the latest relevant informaon before placing orders and should

verify that such informaon is current and complete. All products (also referred to herein as "components") are sold subject to Hunter Douglas’ terms and

condions of sale supplied at the me of order acknowledgment.

Hunter Douglas warrants performance of its components to the specicaons applicable at the me of sale, in accordance with its standard warranty

terms. Tesng and other quality control techniques are used to the extent Hunter Douglas deems necessary to support this war ranty. Except where man-

dated by applicable law, tesng of all parameters of each component is not necessarily performed.

Hunter Douglas assumes no liability for applicaons assistance or the design of Buyers' products. Buyers are responsible for their products, applicaons

and interfaces using Hunter Douglas components. To minimize the risks associated with Buyers' products and applicaons, Buye rs should provide ade-

quate design and operang safeguards.

Hunter Douglas does not warrant or represent that any license, either express or implied, is granted under any patent right, copyright, mask work right, or

other intellectual property right relang to any combinaon, machine, or process in which Hunter Douglas components or serv ices are used. Informaon

published by Hunter Douglas regarding third-party products or services does not constute a license to use such products or services or a warranty or

endorsement thereof. Use of such informaon may require a license from a third party under the patents or other intellectual property of the third party,

or a license from Hunter Douglas under the patents or other intellectual property of Hunter Douglas.

Reproducon of Hunter Douglas informaon in Hunter Douglas data sheets is permissible only if reproducon is without alter aon and is accompanied by

all associated warranes, condions, limitaons, and noces. Hunter Douglas is not responsible or liable for any altered documentaon. Informaon of

third pares may be subject to addional restricons.

Resale of Hunter Douglas components or services with statements dierent from or beyond the parameters stated by Hunter Doug las for that component

or service voids all express and any implied warranes for the associated Hunter Douglas component or service and is an unfa ir and decepve business

pracce. Hunter Douglas is not responsible or liable for any such statements.

Buyers acknowledge and agree that they are solely responsible for compliance with all legal, regulatory and safety-related requirements concerning its

products, and any use of Hunter Douglas components in its applicaons, notwithstanding any applicaons-related informaon or support that may be

provided by Hunter Douglas. Buyers represent and agree that they have all the necessary experse to create and implement saf eguards which ancipate

dangerous consequences of failures, monitor failures and their consequences, lessen the likelihood of failures that might cau se harm and take appropriate
