Hurst Jaws Of Life EDraulic S 788 EWXT User manual

Instruction manual for rescue equipment
272288085 EN
(Original instruction manual)
replaces 07.2019
Edition 10.2019
eDRAULIC cutters

2
Content Page
1. Dangerclassications 4
2. Productsafety 5
3. Intendeduse 8
4. Functionaldescription 10
4.1 Description 10
4.2 Structure of rescue devices 11
4.3 Hydraulic circuit diagram 12
4.4 Operating movement controls 12
5. Operation 12
5.1 Battery for eDRAULIC device 12
5.2 Operating the star grip 13
6. Cutting 14
6.1 Safety notes 14
6.2 Cutting 15
7. Dismantlingtheequipment/deactivationfollowingoperation 16
8. Maintenanceandservice 17
8.1 Oil change 17
8.2 Maintenance after use under water 17
8.3 Overview of eDRAULIC cutting tools 18
8.4 Protective equipment 18
9. Repairs 19
9.1 General information 19
9.2 Preventive service 20
9.3 Repairs 20

3
10.Troubleshooting 24
11.Technicaldata 26
11.1 eDRAULIC cutter 27
11.2 Noise emission (based on standard EN ISO 3744) 27
11.3 Operating and storage temperature ranges 28
11.4 Oscillation / vibration 28
11.5 Torques for central bolts 28
11.6 Cutting performance 28
12.Accessories 29
12.1 Batteries 29
12.2 Battery charger 30
13.Instructionsregardingdisposal 30
14.Notes 31
Content Page

4
 Wearahelmetwithafaceguard.
 Wearprotectivegloves.
 Wearsafetyshoes
 Properrecycling
 Protecttheenvironment
 Readandfollowtheoperatinginstructions.
Wedi󰀨erentiatebetweenvariousdi󰀨erentcategoriesofsafetyinstructions.Thetableshown
belowprovidesanoverviewoftheassignmentofsymbols(pictograms)andsignalwordsto
thespecicdangerandthepossibleconsequences.
1. Danger classications
Pictogram Damage /
injury to Keyword Denition Consequences
Persons
DANGER! Immediatedanger Deathorsevere
injury
WARNING!
Potentially
dangerous
situation
Potentialdeathor
seriousinjury
CAUTION! Lessdangerous
situation
Minororslight
injury
Property
ATTENTION!
Riskofdamage
toproperty/
environment
Damagetothe
equipment,
damagetothe
environment,
damageto
surroundings
-NOTE
Handlingtipsand
otherimportant/
usefulinformation
andadvice
Noinjury/damage
topersons/
environment/
device

5
2. Product safety
HURST products are developed and manufactured to ensure the best performance and
qualitywhenusedasintended.
Thesafetyoftheoperatoristhemostimportantconsiderationinproductdesign.Furthermore,
theoperatinginstructionsareintendedtohelpyouuseHURSTproductssafely.
Thegenerallyapplicablelegalandotherbindingregulationspertainingtothepreventionof
accidentsandprotectionoftheenvironmentapplyandaretobecompliedwithinadditionto
theoperatinginstructions.
The equipment may only be operated by persons with appropriate training in the safety
aspectsofsuchequipment,otherwise,thereisariskofinjury.
Wewouldliketopointouttoallusersthattheyshouldcarefullyreadtheoperatinginstructions
andtheinstructionstheycontainbeforetheyusetheequipmentandcarefullyfollowthem.
Wefurtherrecommendthatyouhaveaqualiedtrainershowyouhowtousetheproduct.
WARNING / CAUTION!
Theoperatinginstructionsforaccessoriesmustalsobetakenintoaccount!
Evenifyouhavealreadyreceivedinstructionsonhowtousetheequipment,youshouldstill
readthroughthefollowingsafetyinstructionsagain.
WARNING / CAUTION!
Pleaseensurethattheaccessoriesyouuseareappropriateforthemaximum
operatingpressureandtheperformanceoftherescuedevice!
Pleaseensurethatnobody
partsorclothingarecaught
betweenthevisiblymoving
parts(e.g.bladearms).
Workingundersuspended
loadsisnotpermittedwhere
suchloadsarebeinglifted
onlybymeansofhydraulic
orelectro-hydraulicdevices.
Ifthisworkisunavoidable,
suitablemechanicalsupports
arealsorequired.
Wearprotectiveclothing,
asafetyhelmetwithvisor,
protectivefootwearand
gloves.
Inspectthedevicebeforeand
afteruseforvisibledefectsor
damage.

6
Immediatelyreportany
changesthatoccur(including
changesinoperating
behavior)totheappropriate
persons/departments!If
necessary,theequipmentis
tobeshutdownimmediately
andsecured!
Allboltedconnectionsmust
becheckedforleaksand
externallyvisibledamage,
whichmustberepaired
immediately!Escaping
hydraulicuidcancause
injuriesandres.
Intheeventofmalfunction,
immediatelydeactivatethe
deviceandsecureit.Repair
thefaultimmediately.
Donotcarryoutanychanges
(additionsorconversions)
totheequipmentwithout
obtainingthepriorapprovalof
HURST.
Observeallsafetyanddanger
informationonthedeviceand
intheoperatinginstructions.
Allsafetyanddanger
instructionsonthedevice
mustalwaysbecompleteand
inalegiblecondition.
Anymodeofoperationwhich
compromisesthesafetyand/
orstabilityofthedeviceis
forbidden!
Repairstotheequipment
mayonlybecarriedoutby
atrainedservicetechnician
withspecicknowledgeofthe
device.
Safetydevicesmayneverbe
disabled!
OnlygenuineHURST
accessoriesandspareparts
aretobeusedforrepairs.
Beforeswitchingon/starting
upthedeviceandduringits
operation,makesurethat
nobodywillbeendangered
bythis.
Observeallintervals
forrecurringtestsand/
orinspectionsthatare
prescribedorstatedinthe
operatinginstructions.
Whenworkingclosetolive
componentsandcables,
suitablemeasuresmust
betakentoavoidcurrent
transfersorhigh-voltage
transferstotheequipment.
Pleasenotethatmaterial
couldfalldownorsuddenly
breakfreeduringcuttingasa
resultofshearing,tearingor
breaking;appropriatesteps
mustbetakentoavoidthis.

7
Theequipmentislledwith
hydraulicuid.Thishydraulic
uidcanbedetrimentalto
healthifitisswallowedor
itsvaporisinhaled.Direct
contactwiththeskinmust
beavoidedforthesame
reason.Also,whenhandling
hydraulicuid,notethatitcan
negativelya󰀨ectbiological
systems.
Whenworkingwithorstoring
theequipment,ensurethat
thefunctionandthesafety
oftheequipmentarenot
impairedbythee󰀨ectsof
severeexternaltemperatures
andthattheequipmentisnot
damagedinanyway.Please
notethattheequipmentcan
alsoheatupoveralong
periodofuse.
Makesurethatthereis
adequatelightingwhile
working.
Beforetransportingthe
equipment,alwaysensure
thattheaccessoriesare
positionedinsuchaway
thattheycannotcausean
accident.
Alwayskeeptheseoperating
instructionseasilyaccessible
attheplaceofoperation.
Ensuretheproperdisposalof
allremovedparts,left-overoil
andhydraulicuidaswellas
packagingmaterials!
TheeDRAULICdevicesare
notsuitableforunderwater
useinsaltwaterorseawater.
Pleaseensurethatyoudonot
becomeentangledincables
andtripwhenworkingwithor
transportingthedevice.
Pleaseensurethatthe
batterycontactsarenotshort-
circuited.
Thebuild-upofstaticcharges
andthereforepossible
sparkingmustbeavoided
whenhandlingthedevice.
Onlytouchbroken-o󰀨or
cut-o󰀨partswhilewearing
protectivegloves,asthetorn/
cutedgescanbeverysharp.

8
3. Intended use
HURSTeDRAULICdeviceshavebeenspeciallydesignedtorescueorretrievethebodies
of victims of road, rail or aircraft accidents or to be used during rescue operations from
buildings.HURSTeDRAULICcuttingdevicesareusedtofreeinjuredpersonsataccident
scenesbycuttingthroughdoors,roofbeamsandhinges.
HURSTeDRAULICdevicesEWXTaresuitableforunderwateruse,but not in saltwater or
seawater.
The generally applicable, legal and other binding national and international regulations
pertainingtothepreventionofaccidentsandprotectionoftheenvironmentapplyandareto
beimplementedinadditiontotheoperatinginstructions.
WARNING / CAUTION / ATTENTION!
Thedeviceisintendedexclusively forthepurposestatedintheoperatinginstructions(see
chapter"ProperUse").Any other use is not in accordance with its designated purpose.
Themanufacturer/supplierisnotliableforanydamageresultingfromimproperuse.Theuser
bearssoleresponsibilityforsuchuse.
Proper use includes observance of the operating instructions and compliance with the
inspectionandmaintenanceconditions.
Never work in a fatigued or intoxicated state!
CAUTION / PLEASE NOTE!
Caremustalwaysbetakenthattheenvironmentoftheobjecttobeprocessed
remainsstableandsecuredagainstunintentionalshiftingbyusingstrongsupports
orunderpinning.

9
WARNING / CAUTION / PLEASE NOTE!
Thefollowingmaynotbecut/squeezed:
- live cables
- prestressed and hardened parts such as springs, spring steels,
steeringcolumnsandrollers
 - pipesundergasorliquidpressure,
 - compoundmaterials(steel/concrete)
 - explosivebodiessuchasairbagcartridges
Theoperatingpressureplacedontherescuedevicemayonlybedirectlychanged
after consultation with HURST.A change in settings may result in damage to
propertyand/orinjuries.
HURSTeDRAULICdevicesarenotexplosion-protected!
When using the devices in potentially explosive environment, the following
mustbeexcluded:
 - thatthedevicecouldtriggeranexplosion.
 - thatworkingwiththedevicecouldtriggeranexplosion;e.g.sparksmayresult
fromcuttinganobject.
TheresponsibilityforexplosionpreventionorforrulingoutworkwithaneDRAULIC
devicewiththeoperatorofthedeviceorwiththepersonresponsibleattheplace
ofuse.
When working in areas at risk of explosion, all applicable legal,
national and international regulations, standards and safety rules
for avoiding explosions must be observed without restriction!
Therescueequipmentshouldnotcomeintocontactwithacidsoralkalies.Ifthis
is unavoidable, clean the equipment immediately afterwards with a suitable
cleaningagent.
You can obtain accessories and replacement parts for the rescue devices from your
authorizedHURSTdealer!

10
4. Functional description
4.1 Description
Thecuttingdeviceshavebeendesignedinsuchawaythatahydraulicallyoperatedpiston
activatesmechanicaljointssymmetricallytoopenorcloseasetoftwooppositebladearms,
thusenablingobjectstobecut.
Foralldevices,themovementisactivatedbymeansofavalveintheformofastargrip.
Alldevicesguaranteethedeadman'sswitchandthefullload-supportingfunctionwhenthe
stargripisreleased.
HURSTeDRAULICdevicesdonotneedtobeconnectedtoanexternalhydraulicsource
(e.g.amotorpump).Generationoftherequiredhydraulicpressuretakesplacewithinthe
bodyofthedevice.
Abatterymustbeconnectedasanenergysource.
Theaccumulatorbatterycanbeinsertedintotheopeningprovidedinthebodyofthetool
andisautomaticallylockedintoposition.
YoucanextendtheoperatingtimeofyoureDRAULICdevicebyusingseveralbatteries.
Thebatteriescanberechargedafteruse,usingasuitableexternalcharger.
ThebatteryisnotpartofthedeliveryscopeYouwillndsuitablebatteriesintheHURST
accessorieslist.
eDRAULICdevicescomewithstandardlightttingstofacilitateworkunderpoorlight
conditions.
Thelight-emittingdiodesattachedontheoperatingsidelightuptheworkarea.The
mainswitchhasalsobeenequippedwitharinglight,sothatyoucanimmediatelydetect
whetherthedeviceisswitchedonornot.

11
4.2 Structure of rescue devices
 1 Stargrip
 2 Mainswitch
 3 Quickexchangebattery
 4 Releasebuttonforbattery
 5 Handle
 6 Bladearms
 7 Pivotboltwithsecurednut
 8 Plastichousing
 9 Toolbody
10 Protectivecover
11 Light
2
3
4
5
6
7
8
1
10
11
9
S 788 EWXT

12
4.4 Operating movement controls
Thepistonmovementiscontrolledbythestargripontheattachedvalve(seeillustrationbelow).
5.1 Battery for eDRAULIC device
5. Operation
Commissioning
Before initial operation, the battery of the rescue device must be fully loaded, using the
externalcharger.
4.3 Hydraulic circuit diagram
AB
cutting
opening
Belowasimpliedhydraulicramrepresentingthetoolisdepicted.
A=toolB=stargripvalve
Stargrip

13
Procedure:
 1. Fullypulltheunlockingbuttonandcarefullypullthebatteryupwardsoutofthede-
vice.
Do not use force!
 2. Thebatterycannowberechargedinthecharger(pleasetakenoteoftheseparate
operatinginstructionsforthechargerandthebatteriestobeused).
 3. InserttherechargedornewbatteryintotheeDRAULICdeviceuntilitreachesthe
stop.Thebatterywillbeautomaticallylockedwhencorrectlyoperated.
Open the device:
Turnthestargripinthedirectionofthecorrespondingsymbol
(open)andholditinthisposition.
Close the device:
Turnthestargripinthedirectionofthecorrespondingsymbol
(close)andholditinthisposition.
"Dead-man’s" function:
Followingrelease,thestargripautomaticallyreturnstothe
centralposition,fullyguaranteeingloadretention.
5.2 Operating the star grip
(alsoseechapteron"Operatingmovementcontrol")
Connectionslot

14
6. Cutting
6.1 Safety notes
Before rescue work can commence, the object must be stabilized in its current position.
Ensurethattheobjectstobeworkedonareadequatelyunderpinnedand/orsupportedto
ensurethatthereisnoriskofslidingorshifting.
Worldwide safety guidelines pertaining to the specic country must be observed and
compliedwith.
WARNING / CAUTION / PLEASE NOTE!
HURSTeDRAULICdevicesarenotexplosion-protected!
Whenusingthedevicesinpotentiallyexplosiveenvironments,the following
mustbeexcluded:
 - thatthedevicecouldtriggeranexplosion.
 - thatworkingwiththedevicecouldtriggeranexplosion;e.g.sparksmayresult
fromcuttinganobject.
TheresponsibilityforexplosionpreventionorforrulingoutworkwithaneDRAULIC
devicelieswiththeoperatorofthedeviceorwiththepersonresponsibleatthe
placeofuse.
When working in areas at risk of explosion, all applicable legal,
national and international regulations, standards and safety rules
for avoiding explosions must be observed without restriction!
Thefollowingaretobewornwhenworkingwiththerescueequipment:
- protectiveclothing,
- safetyhelmetwithvisororprotectivegoggles,
- protectivegloves,
- and,ifnecessary,earprotection.
Beforeoperatingtherescuedevice,youshouldensurethatnoparticipantsorbystandersare
atriskfromthemovementsoftherescuedeviceorfromyingfragments!Avoidunnecessary
damagetopropertybelongingtoothersortoobjectsnotinvolvedintherescueordamage
causedbyyingfragments.

15
It is strictly prohibited to reach into the path of the
rescue device (e.g. between the blade arms and the
material/object to which the force is to be applied)!
CAUTION / PLEASE NOTE!
The strong e󰀨ect of the force of the rescue equipment during operation could
causepiecesof the vehicletobreak o󰀨 oryo󰀨, posing adangerto persons.
Those not involved in the rescue operation should therefore keep at a safe
distance appropriate to the situation.Anytrapped orenclosed persons must
beprotected.
6.2 Cutting
Thebladesshouldbepositionedata90°angletotheobjecttobecut,ifpossible.
RIGHT
WRONG
12
93
15°
15°
90°
Highercuttingcapacitiescanbeachievedbycuttingascloseaspossibletotheblade’spivotpoint.
RIGHT
WRONG

16
During cutting, the gap between the blade tips (in the transverse direction) must not be
exceeded,otherwisethebladeisindangerofbreaking:
ATTENTION!
Wherepossible,avoidcuttingthroughhigh-strengthpartsofthevehiclebody
(e.g. side impact protection). This may result in damage to the blades or to
increasedwearandtear!
eDRAULICcuttingdevice max.gapatthebladetips
[mm] / [in.]
S 788 EWXT 5/ 0.20
7. Dismantling the equipment / deactivation following operation
Onceworkhasbeencompleted,thedevicearmsshouldbecloseduntilthetipsareonlya
fewmillimetersapart.Thisrelievesthehydraulicandmechanicalstrainontheequipment.
Clean the rescue device after each operation and grease both the metallic and the
mechanicallymovableparts.
Greasingprovidesprotectionagainstexcessivewearandtearorcorrosion.
Avoidstoringtherescueequipmentinadampenvironment.
NOTE:
NeverstoretheeDRAULICdeviceswithfullyclosedarms!Byfullyclosingthe
armshydraulicandmechanicaltensionmaydevelopinthedevice.

17
8. Maintenance and service
Thedevicesaresubjecttoveryhighmechanicalstresses.Avisualinspectionmusttherefore
becarriedoutaftereveryuse.Thisinspectionenabletheearlydetectionofwearandtear
andhelpstopreventdamageofthedevice.Regularlycheckthetorqueofthepivotcentral
boltonthecuttingtools.Youwillndthetorquesforthepivotcentralboltinthe“Technical
Data”chapter.
Anannualinspectionofthetoolisdueonceayear.Thisinspectionmustbeperformedby
anauthorizedHURSTJawsofLifedealertechnicanorthewarrantywillbevoid.Thatmeans
thatthepersonmustpossessadequatespecialistknowledgeandexperienceintheeldsof
electricalengineeringandhydraulicstobeabletoassesstheconditionofthetool.
Everythreeyearsalsoacracktestofthebladesisessential.
ATTENTION!
Cleano󰀨anydirtbeforecheckingtheequipment!
WARNING / CAUTION / PLEASE NOTE!
MaintenanceandrepairsmustbecompletedbyanauthorizedHURSTJaws
ofLifedealertechniciantrained by HURSTJawsofLife. Repairs conducted
bynon-authorizeddealersand/ornon-HURSTtrainedtechnicianwillvoidthe
warranty.
8.1 Oil change
Under normal working conditions routine oil changes are not necessary with eDRAULIC
tools.
Theprerequisiteis:
• thetoolsarealwaysproperlyhandledandstowedaspertheapplicableoperatingmanual
• thetoolsaretestedonaregularbasisasperourinstructionsonpreventivemaintenance
Regulartests,oilchangeand/orrepairsmustbecarriedoutbyanauthorizedHURSTJaws
ofLifedealertechnican.
After10yearsservicelifeanoilchangeisrecommended.
WARNING / CAUTION / PLEASE NOTE!
DONOTUSEeDRAULICTOOLINSALTorSEAWATER!!!
• Afteruseunderwater,removebattery.Flushtoolandbatteryseveraltimesinfresh,clean
water.  Submerge tool fully in order to ll the case with clean water.  Lift tool out and
allowtodrainfully.Repeat2-5moretimesdependingonthetypeofwater(muddy,silt,
algae,etc)inwhichthetoolwasused.DONOTUSEeDRAULICTOOLINSALTorSEA
WATER!!!
8.2 Maintenance after use under water

18
Inspections to be carried out:
Visual Inspection
Cutting tool
• Openingwidthofthebladearmsonthetips(seechapter"Technicaldata"),
• Generaltightness(leaks),
• Operabilityofthestargrip-checktheautomaticreturnintomiddlepositionafterrelease
(deadman’sfunction),
• Existenceandstabilityofhandle,
• Labelscompleteandlegible,
• Coversinperfectcondition,
• Checkthetorqueofthepivotbolt(fortorqueMA,see"TechnicalData").
• Bladearmsfreeofcracksandnicksordeformationsonthecuttingsurfaces,
• Cuttingsurfacestontopofeachotherwithoutmakingcontact,
• Theslidingplates,boltsandretainingringsofthebladearmsareinplaceandingood
condition,
• Illuminationofmainswitch,workareaandconnectionshaftfullyfunctional.
Battery
• Casingundamaged
• Electricalcontactsurfacescleanandundamaged
• Battery(-ies)fullycharged
• Chargingstatedisplayoflithium-ionbatteryorbatteriesfullyfunctional
Functional test
• Easyopeningandclosingofstargripcontrols,
• Nounusualnoises
• No further movement of cutter arms when interrupting the valve function during the
process(deadman'sswitch).
8.3 Overview of eDRAULIC cutting tools
Inspections to be carried out:
• Checktheprotectiveequipmentusedon/inthevicinityoftherescuedevice.Payparticular
attentiontotheprotectivecoverforthemovableparts(theremaybenocracks!).
8.4 Protective equipment
• Useaclean,dustfree,moisttoweltowipethetoolandbatterydowntoremoveresidual
dirtanddebris.
• Allowtoolandbatterytoairdryatroomtemperatureaslongaspossiblebeforenextuse.
36-48hoursisrecommended.
• Lubricateallexposedsteelparts(spreadertips,squeezingplates,protectiveplates,etc.)
witharustinhibitor,likeWD-40LongTermRustInhibitor.
• Carryoutfunctionaltestasdescribedin8.3

19
ATTENTION!
Whencleaningunitsandequipment,notethatnocleaningagentmaybeused
thathasapHvalueoutsidetherange5-8!
9.1 General information
9. Repairs
Serviceworkmayonlybeperformedbythedevicemanufacturerorbypersonneltrainedby
thedevicemanufacturerandauthorizedHURSTdealers.
OnlyHURSTsparepartsmaybeusedtoreplaceallcomponents(seesparepartslist),as
specialtoolsandcompliancewith,assemblyinstructions,safetyaspectsandinspectionsare
required(seealsochapter"MaintenanceandServicing").
During assembly, ensure that all components are particularly clean, as dirt can
damage the rescue equipment!
WARNING / CAUTION / PLEASE NOTE!
Protective clothes must be worn when repairs are being carried out, as the
devicesmayalsobepressurizedwhennotinoperation.
ATTENTION!
Because HURST rescue devices are designed for highest performance, only
componentsspeciedinthesparepartslistfortheappropriateequipmentmay
bereplaced.
Othercomponentsinthedevicemayonlybereplacedif:
- YouhaveparticipatedinanappropriateHURSTservicetrainingcourse.
- You have been explicitly granted permission by HURST Customer Service
(validHURSTcerticaterequired!)
NOTE:
AlwaysregisteryourtoolontheHURSTJawsofLifeinternetsite.Thisistheonly
waytoguaranteeextendedwarrantycover.

20
9.2 Preventive service
9.2.1 Care instructions
Theoutside ofthe deviceshould becleaned witha damp cloth from time to time(not the
electrical contacts in the connection slot, on the battery).Inaddition,themetalsurfaces
aretocoatedwithasuitablemediumtocounteractcorrosion(not the electrical contacts in
the connection slot, on the battery).
(In case of doubt, contact your authorized HURST dealer or HURST directly!)
9.2.2 Function and load test
Ifthereisanydoubtregardingthesafetyorreliabilityofadevice,afunctionandstresstest
mustalsobeperformed.
HURSTo󰀨ersappropriatetestequipmentforthis.
9.3.1 Replacing the blade, protective cover and hand grip of the cutter
S 788 EWXT
9.3 Repairs
Components to be
replaced Required work steps
Protectivecover 1.,2.and7.
Pivotbolt 1.-4.and7.
Handle 1.and7.
Blade 1.-5.and7.
