husdata H1 User manual

H1 Interface developers manual. © 2013-2017 Arandis AB
_______________________________________________________________________________________
1
H1 interface developers manual
Firmware version 17.01
©2013-2017, Husdata.se, Arandis AB
Norra Pitholmsvägen 14, 941 46 Piteå, SWEDEN
[email protected]

H1 Interface developers manual. © 2013-2017 Arandis AB
_______________________________________________________________________________________
2
Overview of solution
The H1 interface bridges the often complex communication methods with a heat pump
controllers and provides access through a simple standard interface over RS-232.
The interfacing on the computer side is the same even if connected to different heat pump
models.
For example, reading the radiator return temperature or setting the room temp will use the
same method on IVT, NIBE, Thermia heat pumps and their different models.
The interface has hardware and software support for different connectivity with heat pumps.
When interfaces are manufactured, the interfacing circuit for the relevant heat pump is
implemented and the specific firmware is loaded into the controller.
Features summary
 Available in two versions. The standard using the H1-protocol or the optional using
the Modbus protocol. The H1-protocol is easier to use and provides more functionality
but the Modbus protocol is compatible with PLC:s and commercial equipment.
 Available with USB (standard) or RS-232 interface.
 Available in Standard cable connected model, or Raspberry PI PCB formats to fit
directly on GPIO connector.
 Interface provides a generic platform to communicate with different heat pumps using
the same standard protocol and parameters.
 Provides a secure and convenient way to read and write information to and from heat
pump controllers.
 Interface is provided in different hardware configuration, supporting the majority of
all popular heat pump models.
 Features galvanic insulation (RS-232 version), electrically separating the heat pump
from the connected equipment.
 Firmware upgradable via the serial interface and Windows based upgrade program.
 A LED indicator shows status and enables for troubleshooting.
 Has support for Dallas 1-wire sensors. Up to 16 can be connected. (not supported)
 Has support for Electrical meter S0 or Led-eye connection. Up to 2 electrical meters
can be connected.
 Easy clear text based protocol in clear text manageable directly from serial terminal

H1 Interface developers manual. © 2013-2017 Arandis AB
_______________________________________________________________________________________
3
H1-Protocol interface type (standard)
Serial interface specifications
Interface: RS-232 or USB(serial), Modbus with RS-232 or RS-485
Baud rate: 19200
Bits: 8
Stop bits: 1
Flow control none
Protocol: H1-Proprietary as described in this manual.
Communication structure
All communication is made in plain text and all numbers are in hexadecimal format. Tests of
communications can be managed from standard terminal software, such as Putty.
Data received from the interface has a two letter command structure + data and always end
with chr 13 + chr 10 (Carriage Return + New Line, \r\n).
The command sent to the interface is always two capital letters followed by optional data and
an ending (cr).

H1 Interface developers manual. © 2013-2017 Arandis AB
_______________________________________________________________________________________
4
When powering up the interface (getting power from the heat pump) it first displays copyright
information like below, followed by version information. This information is also shown at
reset. You can manually reset the interface by sending the letter "!".
(C)2013-2017 Arandis AB, Pitea Sweden.
http://www.husdata.se
XV401028
The version information start with XV followed by three hexadecimal bytes.
1. Firmware/Interface variant for different heat pump types.
Rego600, Rego400, Rego80, Rego1000, NIBE EB100, NIBE Styr2002,
Thermia Diplomat, Thermia Villa.
2. Version
3. Revision
After this message is displayed, the communication with the heat pump will initialize. It can
take up to 30 seconds depending on heat pump model.
The registers on the heat pump is then automatically acquired by the interface and will be
output continuously via the serial interface. After all registers are read once, the interface will
only output data if something changes. For example if a temperature is changed on a sensor, it
will output the new value.
If all values need to be refreshed the Re-sync command can be called by the command XR.
Registers
The interface firmware has a common set of pre-programmed heat pump registers to be read
and written to. These registers are listed at the end of this document.
The register data format is a 2 byte number, ex 0101. The leftmost number (4 bits)
representing the data type and the rest is the actual index number. For example on 0001, the
left 0 indicating that this is a temperature. 001 indicating the Radiator return sensor index
number. And likewise 1A01, 1 is indicating that this is a bool on/off device. and A01
indicating index for the Compressor.
No Unit / Data type Additional info
0 Degrees Divide by 10
1 On/off bool 0 or 1
2 Number Divide by 10
3 Percent Divide by 10
4 Ampere Divide by 10
5 kWh Divide by 10
6 Hours As is
7 Minutes As is
8 Degree minutes As is
9 kw As is
A Pulses As is (For S0 El-meter pulse counter)

H1 Interface developers manual. © 2013-2017 Arandis AB
_______________________________________________________________________________________
5
There are two types of registers. The "Common" and the "HP-Specfic" registers.
The interface is continuously syncing with the Common registers and will output any change.
A Common register consists of sensor information, status of devices (compressor, pumps,
valves), a few standard settings and a some other controller parameter such as Degree
minutes. The Common registers has a common structure and id's for all heat pump models.
With the "XL" command will get a list of all available registers for to connected heatpump
and with the "XP" command you have the option to turn on clear text register names and
values shown in decimal. This feature is convenient for test and debug.
The HP-Specific registers will only be read and output if the "XS" command is sent. These
registers are unique for every heat pump model. You can set/write to some of the HP-Specific
registers using the "XW" command. Please see tables in the end of this document for details.
Example of register data output from the interface
XR00010106(cr) 0x0001=reg Radiator return of temp type (0)
0x0106=data (0x01*256)+0x06 = 262 = 26.2 deg C
XR00030198(cr) 0x0003=reg Heat carrier return of temp type (0)
0x0198=data (0x01*256)+0x98 = 408 = 40.8 deg C
XR0006FFE6(cr) 0x0001=reg Cold carrier out of temp type (0)
0xFFE6 and 0x8000 = true (left most bit set=negative)
0xFFE6=data ((0xFF*256)+0xE9)-65536 = -2.3 deg C
XR1A040001(cr) 0x1A04=reg Radiator return of on/off type (1)
0x0001=data ON
Example of data output from the interface with clear text output turned on (XP)
XR000200ED 002 Radiator Forward (23.7c)
XR0003018A 003 Heat carrier Return (39.4c)
XR000400E9 004 Heat carrier Forwrd (23.3c)
XR00050075 005 Brine in/Evaporator (11.7c)
XR00060057 006 Brine out/Condenser (8.7c)
XR0007FF6A 007 Outdoor (-15.0c)
XR0008DEAD 008 Indoor (-853.1c)
XR000901D3 009 Hot water 1 / Top (46.7c)
XR000B024A 00B Hot gas / Compr. (58.6c)
XR000E0000 00E Air intake (0.0c)
XR002000D9 020 Radiator Forward 2 (21.7c)
XR00210000 021 Indoor 2 (0.0c)
XR1A010001 A01 Compressor (1.0 )
XR1A040001 A04 Pump Cold circuit (1.0 )
XR1A050001 A05 Pump Heat circuit (1.0 )
XR1A060001 A06 Pump Radiator (1.0 )
XR1A070000 A07 Switch valve 1 (0.0 )
XR1A090000 A09 Fan (0.0 )
XR1A0A0001 A0A High Pressostat (1.0 )
XR1A0B0001 A0B Low Pressostat (1.0 )
XR1A0C0000 A0C Heating cable (0.0 )
XR1A0D0000 A0D Crank case heater (0.0 )
XR1A200000 A20 Alarm (0.0 )

H1 Interface developers manual. © 2013-2017 Arandis AB
_______________________________________________________________________________________
6
Commands for the H1 Interface.
Data to interface
Command Function Example / Returns
XV Request version number XV010304(cr)
XR Request read and dump of Real-time
registers
XR(cr)
XS Request read and dump of heat pump
specific registers
XS(cr)
XWrrrrdddd Set a register value on HP.
rrrr=register, dddd=data.
XW010600AA(cr)
XW01(ok)
XL Request list of register names XL(cr)
XP Toggle clear text register names print
out
XP(cr)
Warmwater (35.2c)
XM Enable auto refresh of all registers
every second minute. default=off
XA Disable auto read registers and output
change.
XO Enable auto read registers and output
on change. default = on
XU Enable simulator mode. Will output
random data every second.
Only available on
rego600 firmware.
RP1, RP0 Enable/disable Can bus activity
printout
Only rego800/1000
SA Toggle OFF/ON to printout collected
pulses every 10 sec. Default=on
SP Print out collected pulses and reset
counter.
SS Set S0 port 1 to Input port instead to
detect an on/off state.
WE Scan for 1-wire temp sensors and
return all ID's
WR Read all 1-wire temp sensors and dump
result.
XBxx Read alarm logs XB=Last log, XB05 = 5
last logs, etc. Max 20.
Support only for Rego 600 and
Rego2000.
XB010E0B1B0D3130
Or
XB1540 (R2000)
See below for desc.
Data from interface
Input Description Usage Example
XRrrrrdddd(cr) Receive new data from a register.
rrrr= Reg ID, dddd=data.
XV040304 Interface version
WRxxxxxxxxpptt(cr)
Return DS temp: x=8 bytes DS-ID,
pp=00=+ FF=-
XE002 Info. Rego1000 interface was
moved to other Rego version, re-
synchronizing.
XE005 Can bus communication error,
Check cables (Rego 800/1000 only)
XE006 Fatal error identifying Rego1000
version. Contact Husdata.se

H1 Interface developers manual. © 2013-2017 Arandis AB
_______________________________________________________________________________________
7
XE007 Unsupported Rego800 version
detected, switching to
compatibility mode.
XI024 NIBE EB100 detected comm alarm,
will be reset in 10 minutes
XI025 NIBE EB100 alarm has been reset
XB010E0B1B0D3130 XB 01 0E0B1B 0D3130
01 = Alarm Code
Next part is date YYMMDD
Last part is Time HHMMSS
Rego 600 only
For Rego 600 Only
XB1540
XB1541
XB1542
XB 1540
1540 = alarmcode
1540h= 5440 HP Alarm
Command XB always answers with 3
rows of alarmcodes. 0000= no
alarm.
For Rego 2000 Only

H1 Interface developers manual. © 2013-2017 Arandis AB
_______________________________________________________________________________________
8
Modbus protocol interface type (optional)
Serial interface specification (Modbus)
Interface: RS-232 or RS-485
Baud rate: 19200 but can special ordered for other baudrate
ID: 8 but can be special ordered for other ID:s
Protocol: Modbus
Modbus command implementation
 COIL_STATUS, Read one or many. First register: 1, 0x0001
Used for compressor, pumps, valves, etc.
 INPUT_REGISTERS, read one or many. First register: 30001, 0x7501
Used for temp sensors
 HOLDING_REGISTERS, read one or many. First register: 40001, 0x9C01
Read settings like heat curve or temp set.
 SET_REGISTERS, Set heat curve or indoor temp. First register: 40001, 0x9C01

H1 Interface developers manual. © 2013-2017 Arandis AB
_______________________________________________________________________________________
9
General information
Supported heat pump models
Type SW HW Heat pump models Technical
A 00 R IVT Greenline / Optima 900 Rego 600 Serial
B 05 I IVT 490 Rego 400 Serial
C 35 C IVT Premiumline X, Optima/290-AW Rego 800, Can bus
D 30 C IVT Greenline HE/HC/HA+Prem HQ/EQ Rego 1000, Can bus
E 40 N NIBE xx45 EB100, RS-485
F 50 N NIBE Fighter series Styr 2002, RS-485
G 60 D Thermia Diplomat series 901510, i2c
H 70 D Thermia Villa series * 901353, i2c
I 10 E IVT AirX, Geo312, Vent202 Rego 2000
* Not released yet
Common registers
H1-ID
(hex)
Modbus
(hex)
Temperatures Unit System availability
0001 7531 Radiator Return Degrees ABCDEFG I
0002 7532 Radiator Forward Degrees B G I
0003 7533 Heat carrier Return Degrees ABCDE
0004 7534 Heat carrier Forward Degrees ABCDEF I
0005 7535 Brine In / Evaporator Degrees A CDEFG I
0006 7536 Brine Out / Condenser Degrees A CDEFG I
0007 7537 Outdoor Degrees ABCDEFG I
0008 7538 Indoor Degrees ABCDEFG I
0009 7539 Hot water 1 / Top Degrees ABCDEFG I
000A 753A Hot water 2 / Mid Degrees ABCDEF I GT3x on A
000B 753B Hot gas / Compressor Degrees ABCDEF I
000C 753C Suction gas Degrees EF I
000D 753D Liquid flow Degrees EF
000E 753E Air intake Degrees A CD I
000F 753F Exhaust air Degrees A C EF
0010 7540 Air outlet Degrees A EF
0011 7541 Pool Degrees C EF
0012 Pressure tube Degrees G
0020 HC2: Radiator Forward Degrees D
0021 HC2: Indoor Degrees
ID Other registers Unit System availability
4101 Load L1 Ampere EF
4102 Load L2 Ampere EF
4103 Load L3 Ampere EF
x104 Add heat status kW or % A CD-%, E-kW
2105 Degree minutes/integral Number EFG
0107 7542 Heating Setpoint Degrees ABCDEFG
3108 Compressor speed % CD
3109 Circ. pump speed % G I
3110 Brine pump speed % G

H1 Interface developers manual. © 2013-2017 Arandis AB
_______________________________________________________________________________________
10
0111 Hot water Setpoint Degrees B D G
0208 Hot water Stoptemp Degrees FG
0120 HC2: Heating Setpoint Degrees D
AFF1 Collected Pulses meter 1 Pulses <all>
AFF2 Collected Pulses meter 2 Pulses <all>
ID Settings Unit
2201 Operating mode 1 Number E
2202 Operating mode 2 Number
0203 9C41 Room temp target Degrees A CDEF
2204 9C42 Room sensor influence Number A CDEF
x205 9C43 Heat set 1, Curve Left Num/Degr A CDEF
x206 9C44 Heat set 2, Curve Right Num/Degr CD
x207 Heat set 3, Curve Parallel Num/Degr A EF
X208 Hot Water Stop temp
0220 HC2: Room temp target Degrees
0222 HC2: Curve Left Num/Degr D F
0223 HC2: Curve Right Num/Degr D
0224 HC2: Curve Parallel Num/Degr F
ID Status Unit System availability
1A01 0001 Compressor On/Off ABCDEFG I
1A02 0002 Add heat step 1 On/Off AB FG I
1A03 0003 Add heat step 2 On/Off AB FG I
1A04 0004 Pump Cold circuit On/Off A CDEFG
1A05 0005 Pump Heat circuit On/Off A CDEF I
1A06 0006 Pump Radiator On/Off AB G
1A07 0007 Switch valve 1 On/Off A CDEFG I
1A08 0008 Switch valve 2 On/Off
1A09 0009 Fan On/Off BCD I
1A0A 000A High Pressostat On/Off BCD
1A0B 000B Low Pressostat On/Off BCD
1A0C 000C Heating cable On/Off CD I
1A0D 000D Crank shaft heater On/Off CD
1A0E Shunt open On/Off B
1A0F Shunt close On/Off B
1A19 Add Heat step 3 On/Off F I
2A20 000E Alarm Number ABCDEF I
IVT Rego 1000 specific registers
ID(hex) Settings writable Unit Min/Max
2F00 Program Generation Number
2F01 Program Version Number
2F02 Program Revision Number
Rego 800 specific registers
ID(hex) Read only registers Unit Min/Max Comment
0F50 Adj. curve at 20° out Degrees Only Optima
0F51 Adj. curve at 15° out Degrees Only Optima
0F52 Adj. curve at 10° out Degrees Only Optima
0F53 Adj. curve at 5° out Degrees Only Optima

H1 Interface developers manual. © 2013-2017 Arandis AB
_______________________________________________________________________________________
11
0F54 Adj. curve at 0° out Degrees Only Optima
0F55 Adj. curve at -5° out Degrees Only Optima
0F56 Adj. curve at -10° out Degrees Only Optima
0F57 Adj. curve at -15° out Degrees Only Optima
0F58 Adj. curve at -20° out Degrees Only Optima
0F59 Adj. curve at -25° out Degrees Only Optima
0F5A Adj. curve at -30° out Degrees Only Optima
0F5B Adj. curve at -35° out Degrees Only Optima
0F60 Additional power Degrees
0F61 VV GT3 Start temp Degrees
0F62 VV GT9 Stopp temp Degrees
6F63 Runtime Comp rad Hours Only on some reg ver
6F64 Runtime Comp vv Hours Only on some reg ver
6F65 Runtime controller Hours Only on some reg ver
6F66 Runtime additional rad Hours Only on some reg ver
6F67 Runtime additional Hours Only on some reg ver
Rego 600 specific registers
ID(hex) Settings writable Unit Min/Max
0F50 Adj. curve at 20° out Degrees
0F51 Adj. curve at 15° out Degrees
0F52 Adj. curve at 10° out Degrees
0F53 Adj. curve at 5° out Degrees
0F54 Adj. curve at 0° out Degrees
0F55 Adj. curve at -5° out Degrees
0F56 Adj. curve at -10° out Degrees
0F57 Adj. curve at -15° out Degrees
0F58 Adj. curve at -20° out Degrees
0F59 Adj. curve at -25° out Degrees
0F5a Adj. curve at -30° out Degrees
0F5b Adj. curve at -35° out Degrees
0F61 GT1 On value Degrees
0F62 GT1 On EL value Degrees
0F63 GT1 Off EL value Degrees
0F64 GT1 Off value Degrees
0F65 GT3 On value Degrees
0F66 GT3 Off value Degrees
0F67 GT4 Target value Degrees
0F68 Heat curve coupling Degrees
Rego600 Alarm codes
Alarm no Description
0 No Alarm
1 Sensor radiator return (GT1)

H1 Interface developers manual. © 2013-2017 Arandis AB
_______________________________________________________________________________________
12
2 Outdoor sensor (GT2)
1 Sensor hot water (GT3)
2 Mixing valve sensor (GT4)
5 Room sensor (GT5)
6 Sensor compressor (GT6)
7 Sensor heat tran fluid out (GT8)
8 Sensor heat tran fluid in (GT9)
9 Sensor cold tran fluid in (GT10)
10 Sensor cold tran fluid in (GT11)
11 Compresor circuit switch
12 Electrical cassette
13 HTF C=pump switch (MB2)
14 Low pressure switch (LP)
15 High pressure switch (HP)
16 High return HP (GT9)
17 HTF out max (GT8)
18 HTF in under limit (GT10)
19 HTF out under limit (GT11)
20 Compressor superhear (GT6)
21 3-phase incorrect order
22 Power failure
Thermia Alarm codes
Bit mask Description
0 No Alarm
8 Warm water sensor failure
4 Return sensor failure
2 Forward sensor failure

H1 Interface developers manual. © 2013-2017 Arandis AB
_______________________________________________________________________________________
13
Styr2002 NIBE 1245 specific registers (not verified, use at own risk)
ID(hex) Settings writable Unit Min/Max
0F08 M1.6 : Stopp extra varmvatten
0F09 M1.7 : Stopp kpr extra varmvatten
0F0A M1.8 : Intervall periodiskt XVV
0F0B M1.10 : Drifttid varmvatten (min)
0F0C M1.10 : Drifttid varmvatten (h)
0F0D M2.3 : Mintemp. framledning
0F0E M2.4 : Maxtemp. framledning
0F0F M2.5 : Kompensering yttre
0F11 M2.7 : Max returtemperatur
0F14 M3.0 : Beräknad framledningstemp 2
0F17 M3.3 : Mintemp. framledning 2
0F18 M3.4 : Maxtemp. framledning 2
0F19 M3.5 : Kompensering yttre 2
0F1A M3.7 : Returledningstemperatur 2
Disclaimer
The information in this document is valid for a specific interface firmware and is subject to be
changed on later releases. We reserve us from incorrect information in this
document.
