Husqvarna LZ30, LZ30C User manual

English
Operator Manual
LZ5227 / 968999674 LZ6130 / 968999675
LZ7230 / 968999676 LZ6127 / 968999709
LZ30 / 968999776 LZ30C / 968999751
LZ6130C / 968999752 LZ7230C / 968999753
Please read the operator’s manual carefully and make sure you
understand the instructions before using the machine.

©2007 HTC. All rights reserved.
Beatrice, NE. Printed in U.S.A.

CONTENTS
English-3
INTRODUCTION................................................................5
General........................................................................5
Driving and Transport on Public Roads.......................5
Towing..........................................................................5
Operating.....................................................................5
Good Service...............................................................6
Manufacturing Number................................................6
SYMBOLS AND DECALS ..................................................7
SAFETY..............................................................................9
Safety Instructions.......................................................9
General Operation.......................................................9
Personal Safety Equipment.......................................11
Slope Operation.........................................................11
Safe Handling of Gasoline.........................................13
General Maintenance ................................................14
Transport ...................................................................16
Customer responsibilities...........................................16
Roll over Protection system (ROPS) .........................17
Spark Arresters..........................................................17
CONTROLS......................................................................18
Motion Control Levers................................................19
Hour meter.................................................................20
Tracking knob ............................................................20
Parking Brake............................................................20
Blade switch...............................................................21
Ignition Switch............................................................21
Fuses.........................................................................21
Refueling....................................................................22
Seat Lock...................................................................23
Fuel shut off valve......................................................23
Seat adjustment lever................................................23
Choke control.............................................................24
Throttle control...........................................................24
Cutting height lift pedal..............................................25
Pump release valves ................................................25
Accessories ...............................................................25
OPERATION.....................................................................26
Training......................................................................26
Steering .....................................................................26
Roll bar and safety belt..............................................27
Before Starting...........................................................27
Starting the Engine....................................................27
Weak battery..............................................................31
Jumper cables ...........................................................31
Running .....................................................................32
Operating on hills.......................................................33
Mowing Tips ..............................................................34
Stopping the Engine ..................................................35
Moving by Hand.........................................................35
MAINTENANCE ...............................................................36
Battery .......................................................................38
Ignition System..........................................................39
Safety System............................................................39
Engine’s CoolingAir Intake........................................41
Throttle Cable............................................................41
Choke Cable..............................................................41
Air Filter .....................................................................42
Dust cap.....................................................................42
Air filter housing and filter..........................................42
Engine oil cooler........................................................43
Fuel Filter...................................................................44
V-belts........................................................................45
Tire Pressures ...........................................................46
Parking Brake............................................................46
Blades........................................................................47
Adjusting the Mower Deck.........................................48
Leveling .....................................................................48
Cutting Height............................................................48
Cleaning and Washing...............................................49
Caster Wheels...........................................................49
Hardware...................................................................49
LUBRICATION..................................................................50
Lubrication Schedule.................................................50
Lubricating Cables.....................................................51
Lubricating with Schedule..........................................51
Hydraulic System, Oil Level.......................................51
Driver’s Seat..............................................................51
Engine Oil..................................................................52
Oil Level..................................................................53
Oil Recommendations.............................................54
Oil Type...................................................................54
Throttle and Choke Cables, Lever Bearings..............55
Front Wheel Mount....................................................55
Front Wheel Bearings................................................55
Deck belt pulleys........................................................55
Mower Deck Height Adjuster .....................................55
Steering Control Shafts..............................................56
Mower Deck Struts ....................................................56
Changing the Oil Filter...............................................56
TROUBLESHOOTING GUIDE.........................................57
STORAGE........................................................................59
Winter Storage...........................................................59
Service.......................................................................59
WIRING DIAGRAMS........................................................60
TECHNICAL DATA...........................................................61
ACCESSORIES................................................................65
TORQUE SPECIFICATIONS ...........................................65
CONFORMITY CERTIFICATES.......................................66
USA REQUIREMENTS ....................................................66
SERVICE JOURNAL........................................................67

WARNING!
Failure to follow cautious operating practices can result in serious injury to the
operator or other persons. The owner must understand these instructions, and must
allow only trained persons who understand these instructions to operate the mower.
Each person operating the mower must be of sound mind and body and must not be
under the influence of any mind altering substance.
WARNING!
Engine exhaust, some of its constituents, and certain vehicle components contain
or emit chemicals known to the State of California to cause cancer and birth defects
or other reproductive harm.
WARNING!
Battery posts, terminals and related accessories contain lead and lead compounds,
chemicals known to the State of California to cause cancer and birth defects or other
reproductive harm. Wash hands after handling.
English-4

English-5
INTRODUCTION
Congratulations
Thank you for purchasing a Husqvarna ride-on mower. This machine is built for superior efficiency to rapidly mow
primarily large areas. A control panel easily accessible to the operator and a hydrostatic transmission regulated by
steering controls both contribute to the machine’s performance.
This manual is a valuable document. Read the contents carefully before using or servicing the machine. The
following of instructions (use, service, maintenance, etc.) by all who operate this machine is important for the
safety of the operator and others. It can also considerably increase the life span of the machine and increase its
resale value.
If you sell your machine, be sure to give the operator’s manual to the new owner.
The final chapter of this operator’s manual provides a Service Journal. Ensure that service and repair work are
documented. A well-kept service journal reduces service costs for the maintenance and affects the machine’s
resale value. Please contact your dealer for more information. Take the operator’s manual along when the
machine is taken to your dealer for service.
General
In this operator’s manual, left and right, backward and forward are used in relation to the machine’s normal driving
direction.
Continuous dedication to improve our products require that specifications and design are subject to change
without notice.
Driving and Transport on Public Roads
Check applicable road traffic regulations before transporting on public roads. If the machine is transported, you
must always use approved fastening equipment and ensure that the machine is well anchored. DO NOT operate
this machine on public roadways.
Towing
Do not tow this machine, it may cause damage to the drive system.
Do not tow any trailers, etc. with this mower. They may jackknife or overturn causing damage to the mower and
possible serious injury to the operator.
Operating
This machine is constructed only for mowing grass on lawns and even ground without obstacles such as stones,
tree stumps, etc. The machine can also be used for other tasks when equipped with special accessories provided
by the manufacturer. Operating instructions for the accessories are provided with delivery. All other types of uses
are incorrect. The manufacturer’s directions concerning operation, maintenance, and repairs must be carefully
followed.
Lawn mowers and all power equipment, can be potentially dangerous if used improperly. Safety requires good
judgement, careful use in accordance with these instructions and common sense.
The machine must only be operated, maintained, and repaired by persons familiar with the machine’s special
characteristics and who are also knowledgeable about the safety instructions. Use only approved repair parts to
maintain this machine.
Accident prevention regulations, other general safety regulations, occupational safety rules, and traffic regulations
must be followed without fail.
Unauthorized modifications to the design of the machine may absolve the manufacturer from liability for any
resulting personal injury or property damage.

English-6
INTRODUCTION
Good Service
Husqvarna’s products are sold all over the world and only in specialized retail stores with complete service. This
ensures that you as a customer receive only the best support and service. Before the product is delivered, the
machine has, for example, been inspected and adjusted by your retailer. See the certificate in the Service Journal
in this operator’s manual.
When you need spare parts or support in service questions, warranty issues, etc., please consult the following
professional:
Manufacturing Number
The machine’s manufacturing number can be found on the printed plate affixed to the left in the engine
compartment. Stated on the plate, from the top are:
• The machine’s type designation (I.D.).
• The manufacturer’s type number (Model).
• The machine’s serial number (Serial no.)
Please have the type designation and serial number available when ordering spare parts.
The engine’s manufacturing number is stamped on one of the valve covers.
The plate states:
• The engine’s model.
• The engine’s type.
• Code
Please have these available when ordering spare parts.
The wheel motors and hydrostatic pumps have a barcode decal affixed at the rear.
This Operator’s Manual belongs to the machine with
the manufacturing number: Engine Transmission

English-7
SYMBOLS AND DECALS
These symbols are found on the machine and in the operator’s manual.
Study them carefully so that you know what they mean.
Used in this publication to notify the reader of a risk of personal injury or death, particularly if the reader should
neglect to follow instructions given in the manual.
Used in this publication to notify the reader of a risk of material damage, particularly if the reader should neglect
to follow instructions given in the manual. Used also when there is a potential for misuse or misassembly.
WARNING!
Xxxx xxxxxx xxxxx xxxx
xxxxxxxxx xxxxxx xxxxxxxxx.
xx xxxxxxxx xxxx xxxxxx.
IMPORTANT INFORMATION
Xxxx xxxxxx xxxxx xxxx xxxxxxxxx
xxxxxx xxxxxxxxx. xx xxxxxxxx xxxx
xxxxxx.
RN
Reverse Neutral Fast Slow Choke Fuel
Warning! Parking Brake CE conformity Warning! Rotating blades, Do not touch parts
marking. Only for keep away from the
European market discharge deck
Battery acid is corrosive, explosive and flammable Do not stand here
Noise emissions to the
surroundings in accordance with
the European Union’s directive.
The machine’s emission is stated
in the chapter TECHNICAL DATA
and on the decals.
Only machines for European
market
Use protective glasses Use protective gloves
P

English-8
SYMBOLS AND DECALS
Read Shut off engine and Keep a safe Use on slopes No passengers
Operator’s remove key before distance from no greater
Manual performing any the machine than 10°
maintenance or repair work
Whole body Severing of fingers Do not open or Careful backing up, Careful going
exposure to and toes remove safety watch for other forward, watch for
thrown objects shields while people other people
engine is running
Moving sharp blades under cover

English-9
SAFETY
Safety Instructions
These instructions are for your safety. Read them carefully.
IMPORTANT: THIS CUTTING MACHINE IS CAPABLE OF AMPUTATING HANDS AND FEET AND THROWING
OBJECTS. FAILURE TO OBSERVE THE FOLLOWING SAFETY INSTRUCTIONS COULD RESULT IN
SERIOUS INJURY OR DEATH.
General Operation
• Read, understand, and follow all instructions
on the machine and in the manual before
starting.
• Do not put hands or feet near rotating parts
or under the machine. Keep clear of the
discharge opening at all times.
• Only allow responsible adults, who are familiar
with the instructions, to operate the machine.
• Clear the area of objects such as rocks, toys,
wire, etc., which could be picked up and
thrown by the blades.
• Be sure the area is clear of bystanders before
operating. Stop machine if anyone enters the
area.
• Never carry passengers. The machine is only
intended for use by one person.
• Do not mow in reverse unless absolutely
necessary.Always look down and behind
before and while backing.
• Never direct discharged material toward
anyone. Avoid discharging material against a
wall or obstruction. Material may ricochet back
toward the operator. Stop the blades when
crossing gravel surfaces.
• Do not operate machine without the entire
grass catcher, discharge guard, or other safety
devices in place and working
• Slow down before turning.
• Never leave a running machine unattended.
Always turn off blades, set parking brake, stop
engine, and remove keys before dismounting.
• Disengage blades when not mowing. Shut
off engine and wait for all parts to come to a
complete stop before cleaning the machine,
removing the grass catcher, or unclogging the
discharge guard.
Read the operator’s manual before starting the machine
Clear the area of objects before mowing
8011-512
8011-513
WARNING!
This symbol means that important safety instructions need to be emphasized.
It concerns your safety.

English-10
SAFETY
WARNING!
Engine exhaust and certain
vehicle components contain
or emit chemicals considered
to cause cancer, birth defects,
or other reproductive system
damage. The engine exhaust
contains carbon monoxide,
which is a odorless, colorless,
poisonous gas. Do not use the
machine in enclosed spaces.
Never take passengers 8011-520
• Operate machine only in daylight or good
artificial light.
• Do not operate the machine while under the
influence of alcohol or drugs.
• Watch for traffic when operating near or
crossing roadways.
• Use extra care when loading or unloading the
machine into a trailer or truck.
• Always wear eye protection when operating
machine.
• Data indicates that operators, age 60 years
and above, are involved in a large percentage
of riding mower-related injuries. These
operators should evaluate their ability to
operate the riding mower safely enough to
protect themselves and others from serious
injury.
• Follow the manufacturer’s recommendation for
wheel weights or counterweights.
• Anyone who operates this machine must first
read and understand this Operation Manual.
Local laws may regulate the age of the user.
• Keep machine free of grass, leaves or other
debris buildup which can touch hot exhaust
/ engine part and burn. Do not allow the
mower deck to plow leaves or other debris
which can cause buildup to occur. Clean any
oil or fuel spillage before operating or storing
the machine. Allow machine to cool before
storage.

English-11
SAFETY
WARNING!
When using the machine, approved personal protective equipment (shown in
illustrations) shall be used. Personal protective equipment cannot eliminate the
risk of injury but it will reduce the degree of injury if an accident does happen.
Ask your retailer for help in choosing the right equipment.
Personal Safety Equipment
• Make sure that you have first aid equipment
close at hand when using the machine.
• Never use the machine when barefoot.
• Always wear protective shoes or boots,
preferably with steel toe caps.
• Always wear approved protective glasses or a
full visor when assembling or driving.
• Always wear gloves when handling the blades.
• Never wear loose clothing that can get caught
in moving parts.
• Use ear protectors to avoid damage to hearing.
Slope Operation
Slopes are a major factor related to loss of control and
tip-over accidents, which can result in severe injury or
death. Operation on all slopes requires extra caution. If
you cannot back up the slope or if you feel uneasy on
it, do not mow it.
• Mow up and down slopes (10 degrees
maximum), not across.
• Watch for holes, ruts, bumps, rocks, or other
hidden objects. Uneven terrain could overturn
the machine. Tall grass can hide obstacles.
• Choose a low ground speed so that you will
not have to stop while on the slope.
• Do not mow on wet grass. Tires may lose
traction.
• Avoid starting, stopping, or turning on a slope.
If tires lose traction, disengage blades and
proceed slowly straight down the slope.
• Keep all movement on the slopes slow and
gradual. Do not make sudden changes in
speed or direction, which could cause the
machine to roll over.
• Use extra care while operating machine with
grass catchers or other attachments; they can
affect the stability of the machine.
Personal protective equipment 8011-670a
6003-004
Mow up and down, not side to side
WARNING!
Do not drive up or down hills
with slopes greater than 10
degrees. And do not drive across
any slopes.

English-12
SAFETY
Be extra cautious when driving on slopes 8011-509
Never allow children to operate the machine 8011-517
Keep children away from work area
8011-518
• Do not use on steep slopes.
• Do not try to stabilize the machine by putting
your foot on the ground.
• Do not mow near drop-offs, ditches, or
embankments. The machine could suddenly
roll over if a wheel is over the edge or if the
edge caves in.
Children
Tragic accidents can occur if the operator is not
alert to the presence of children. Children are often
attracted to the machine and the mowing activity.
Never assume that children will remain where you last
saw them.
• Keep children out of the mowing area and in
the watchful care of a responsible adult other
than the operator.
• Be alert and turn machine off if a child enters
the area.
• Before and while backing, look behind and
down for small children.
• Never carry children, even with the blades shut
off. They may fall off and be seriously injured
or interfere with safe machine operation.
Children who have been given rides in the
past may suddenly appear in the mowing area
for another ride and be run over or backed
over by the machine.
• Never allow children to operate the machine.
• Use extra care when approaching blind
corners, shrubs, trees, or other objects that
may block your view of a child.

English-13
SAFETY
Safe Handling of Gasoline
To avoid personal injury or property damage, use
extreme care in handling gasoline. Gasoline is
extremely flammable and the vapors are explosive.
• Extinguish all cigarettes, cigars, pipes, and
other sources of ignition.
• Use only approved gasoline container.
• Never remove gas cap or add fuel with the
engine running. Allow engine to cool at least
two (2) minutes before refueling.
• Never fuel the machine indoors.
• Never store the machine or fuel container
where there is an open flame, spark, or pilot
light such as on a water heater or other
appliances.
• Before you begin refueling, minimize the risk of
static electricity by touching a metal surface.
• Never fill containers inside a vehicle or on a
truck or trailer bed with plastic liner. Always
place containers on the ground away from your
vehicle when filling.
• Remove gas-powered equipment from the
truck or trailer and refuel it on the ground. If
this is not possible, then refuel such equipment
with a portable container, rather than from a
gasoline dispenser nozzle.
• Keep the nozzle in contact with the rim of the
fuel tank or container opening at all times until
fueling is complete. Do not use a nozzle lock-
open device.
• If fuel is spilled on clothing, change clothing
immediately.
• Never overfill fuel tank. Replace gas cap and
tighten securely.
• Do not start the engine near spilled fuel.
• Never use gasoline as a cleaning agent.
• If leaks arise in fuel system, engine must not
be started until problem has been resolved.
• Check the fuel level before each use and leave
space for the fuel to expand, because the heat
from the engine and the sun may otherwise
cause the fuel to expand and overflow.
WARNING!
The engine must not be started when the driver’s floor plate or any protective
plate for the mower deck’s drive belt is removed.
Never fill the fuel tank indoors 8011-516
WARNING!
The engine and the exhaust
system, become very hot
during operation.
Risk for burns if touched.
Allow engine and exhaust
system to cool at least two (2)
minutes before refueling.

English-14
SAFETY
Never drive the machine in an enclosed space 8011-515
WARNING!
The battery contains lead and
lead compounds, chemicals
that are considered to cause
cancer, birth defects, and other
reproductive system damage.
Wash your hands after handling
the battery.
Use protective glasses for
maintenance work.
General Maintenance
• Never operate machine in a closed area.
• Keep all nuts and bolts tight to be sure the
equipment is in safe working condition.
• Never tamper with safety devices. Check their
proper operation regularly.
• Keep machine free of grass, leaves, or other
debris buildup. Clean oil or fuel spillage and
remove any fuel-soaked debris. Allow machine
to cool before storing.
• If you strike a foreign object, stop and inspect
the machine. Repair, if necessary, before
restarting.
• Never make any adjustments or repairs with
the engine running.
• Check grass catcher components and the
discharge guard frequently and replace with
manufacturer’s recommended parts, when
necessary.
• Mower blades are sharp. Wrap the blade or
wear gloves, and use extra caution when
servicing them.
• Check brake operation frequently.Adjust and
service as required.
• Maintain or replace safety and instruction
labels, as necessary.
• Do not modify safety equipment. Check
regularly to be sure it works properly. The
machine must not be driven with defective
or unmounted protective plates, protective
cowlings, safety switches, or other protective
devices.
• Do not change the settings of governors and
avoid running the engine with overly high
engine speeds. If you run the engine too fast,
you risk damaging the machine components.
• Be very careful when handling battery acid.
Acid on skin can cause serious corrosive
burns. If you spill battery acid on your skin,
rinse immediately with water.
• Acid in the eyes can cause blindness, contact
a doctor immediately.
• Be careful when servicing the battery.
Explosive gases form in the battery. Never
perform maintenance on the battery when
smoking or near open flames or sparks.
• The battery can explode and cause serious
injury/damage.

English-15
SAFETY
• Ensure that nuts and bolts, especially the
fastening bolts for the blade attachments,
are properly tightened, torqued and that the
equipment is in good condition.
• Do not modify safety equipment. Check
regularly to be sure it works properly. The
machine must not be driven with defective
or unmounted protective plates, protective
cowlings, safety switches, or other protective
devices.
• Do not change the settings of governors and
avoid running the engine with overly high
engine speeds. If you run the engine too fast,
you risk damaging the machine components.
• Sparking can occur when working with the
battery and the heavy cables of the starter
circuit. This can cause battery explosion, fire or
eye injury. Sparking in this circuit can not occur
after the chassis cable (normally negative,
black) is removed from the battery.
• Use protective goggles.
• Ensure that the fuel filler cap is mounted tightly
and no flammable substances is stored in an
open vessel.
• Never work with the starter circuit if there is
spilled fuel.
• Disconnect the chassis cable from the battery
first and reconnect it last.
• Do not make a bridge short circuit across the
starter relay to run the starter.
• Never use the machine indoors or in spaces
lacking proper ventilation. The exhaust fumes
contain carbon monoxide, an odorless,
poisonous, and lethal gas.
• Stop and inspect the equipment if you run over
or into anything. If necessary, make repairs
before starting.
• Never make adjustments with the engine
running.
• The machine is tested and approved only
with the equipment originally provided or
recommended by the manufacturer. Only use
approved repair parts for the machine.
Do not smoke when performing maintenance on the battery.
The battery can explode and cause serious injury/damage.
6003-009
Risk of sparking 8009-728
WARNING!
Avoid electrical sparking and its
consequences by the following
routines:

English-16
SAFETY
8011-515
Clean the machine regularly
IMPORTANT INFORMATION
The parking brake is not sufficient
to lock the machine in place during
transport. Ensure that the machine is
well fastened to the transport vehicle.
Always reverse the machine onto the
transport vehicle to avoid tipping it over.
WARNING!
This mower is equipped
with an internal combustion
engine and should not
be used on or near any
unimproved forest-covered,
bush-covered or grass-
covered land unless the
engine’s exhaust system
is equipped with a spark
arrester meeting applicable
local or state laws (if any).
If a spark arrester is used,
it should be maintained in
effective working order by
the operator.
A spark arrester for the muffler is available through
your authorized Husqvarna dealer.
• The blades are sharp and can cause cuts and
gashes. Wrap the blades or use protective
gloves when handling them.
• Check the parking brake’s functionality
regularly.Adjust and service as necessary.
• The mulch blades should only be used in
familiar areas when higher quality mowing is
desired.
• Reduce the risk of fire by removing grass,
leaves, and other debris that may have
accumulated on the machine. Allow the
machine to cool before putting it in storage.
• Regularly clean deck and underside of
deck, avoid spraying engine and electrical
components with water.
Transport
• The machine is heavy and can cause serious
crushing injuries. Be extra cautious when it is
loaded on or unloaded from a vehicle or trailer.
• Use an approved trailer to transport the
machine. Activate the parking brake, turn off
the fuel supply, and fasten the machine with
approved fastening devices, such as bands,
chains, or straps, when transporting.
• Do not operate this machine on public
roadways.
• Check and abide by local traffic regulations
before transporting the machine on any road.
• Do not tow this machine, it may cause damage
to the drive system.
• Do not tow any trailers, etc. with this mower.
They may jackknife or overturn causing
damage to the mower and possibly serious
injury to the operator.
•Load the unit onto truck or trailer by driving up
ramps of suitable strength using a slow speed.
Do not lift! The machine is not intended to be
lifted by hand.
Customer responsibilities
• Read and observe the safety rules.
• Follow a regular schedule in maintaining,
caring for and using your mower.
• Follow the instructions under “Maintenance”
and “Storage” sections of this owner’s manual.

English-17
SAFETY
Roll over Protection system (ROPS)
The ROPS increases the basic weight of the unit by 42
lbs/19 kg. The ROPS on the US units are standard, on
the European units the ROPS is an accessory.
Do not use ROPS as a lifting, attaching or• anchoring point.
Do not use ROPS for wrecking or towing.• Do not exceed Max GVW: 2822 lbs/1283 kg.• Read machine operator´s manual before• each use.
Securely fasten your seat belt if the unit has• a ROPS.
Where possible, avoid operating the unit• near ditches, embankments and holes.
Reduce speed when turning, crossing• slopes and on rough, slick or muddy
surfaces.
Stay off slopes too steep for safe operation.• Watch where you are going, especially at• row ends, on roads and around trees.
Do not permit others to ride.• Operate the mower smoothly - no jerky• turns, starts or stops.
When mower is stopped, set brakes• securely and use park brake.
If any part of ROPS is damaged, the entire• ROPS must be replaced.
Check all bolts including seat belt for correct• torque before each use.
Check ROPS structure for damage before• each use.
ROPS bar is NOT intended for use in sub• zero temperatures.
Spark Arresters
A spark arrester for the muffler is available through
your authorized Husqvarna dealer.
WARNING!
The rollover protection
system's capabilities may
be impaired by damage if
the mower is overturned
or if alteration to the ROPS
occurs. If these conditions
take place, the total structure
MUST be replaced.
WARNING!
This mower is equipped
with an internal combustion
engine and should not
be used on or near any
unimproved forested, bush
covered or grassy lands
unless the engine's system
is equipped with a spark
arrester meeting applicable
local or state laws (if any).
If a spark arrester is used,
it should be maintained in
effective working order by
the operator.

CONTROLS
English-18
Controls
This operator’s manual describes the Husqvarna Zero
Turn Rider. The rider is fitted with a Kohler four-stroke
overhead valve engine developing 30 horse power*.
Transmission from the engine is made via two belt-
driven hydraulic pumps, which in turn drive a hydraulic
motor for each drive wheel. Using the left and right
steering controls, the flow is regulated and thereby the
direction and speed.
*As rated by the engine manufacturer.
8011-464
Zero Turn Rider
Control Locations
1. Motion control levers 19
2. Hour meter 20
3. Tracking knob 20
4. Parking brake 20
5. Blade switch 21
6. Ignition switch 21
7. Fuses 21
8. Fuel tank cap 22
9. Seat lock 23
10. Fuel shut-off valve 23
11. Seat adjustment lever 23
12. Choke control 24
13. Throttle control 24
14. Cutting height adjuster 25
14 13 12 11 10 9
1 2 3 4 5 6 7 8
Page Page

CONTROLS
English-19
8011-789
Steering controls
WARNING!
The machine can turn very
rapidly if one steering control
is moved much further forward
than the other.
Motion Control Levers
The machine’s speed and direction are continuously
variable using the two steering controls. The steering
controls can be moved forward or backward about
a neutral position. Furthermore, there is a neutral
position, which is locked if the steering controls are
moved outward.
When both controls are in the neutral position (N), the
machine stands still.
By moving both controls an equal amount forward
or backward, the machine moves in a straight line
forward or backward respectively.
In order, for example, to turn right while moving
forward, move the right control towards the neutral
position. The rotation of the right wheel is reduced and
the machine turns to the right.
Zero turn can be achieved by moving one control
backward (behind the neutral position) and carefully
moving the other steering control forward from its
neutral position. The rotation direction when zero
turning is determined by which steering control is
moved backward behind the neutral position. If the left
steering control is pulled backward, the machine turns
to the left. Use extra care when using this maneuver.
1
23
4
8011-7912
1. Forward
2. Neutral
3. Neutral slot, Neutral lock
4. Reverse
Motion control lever pattern (right side)

CONTROLS
English-20
Hour meter
The hour meter displays the total operating time.
It will flash CHG OIL (Change Oil) at 50 hour intervals.
The flash duration is one hour before and one hour
after the interval. The CHG OIL icon will come on
and shut off automatically. The hour meter cannot be
manually reset.
8011-749
Hour meter
Tracking knob
The tracking knob is located in front of the left control
lever. Rotating the knob allows fine tuning adjustments
so that the machine tracks straight with the motion
control levers in the full forward position.
Rotate the knob clockwise (as viewed from the
operating position) to increase the speed or counter
clockwise to decrease the speed on the left control
lever. For example: if the control levers are full forward
and the unit turns to the right, turn the tracking knob
counter clockwise to decrease the speed on the left
control lever.
8011-442
Tracking knob
Parking Brake
The parking brake is found below the operator's left
hand. Pull the lever backward to activate the brake
and push forward to release it.
8011-511-1
Parking brake not activated
IMPORTANT INFORMATION
The machine must stand absolutely still
when applying the parking brake. Always
set the parking brake before dismounting.
Release the parking brake before moving
the mower.
