Hussmann FG Instruction Manual

B
A
G
E
F
D
C
I
H
P/N 0465895_D
Item Part # Description Wiring Item #
FAN ASSEMBLIES, AND THERMOSTATS
A. 4W Standard Fan Assembly (1)
0392457 Fan Motor, Evaporator
(MO.4410101)
0464847 Fan Blade (FB.4780649)
4W Energy Efficient Fan Assembly (1)
0477653 Fan Motor, Evaporator
(MO.4410544)
0464847 Fan Blade (FB.4780649)
B. Optional Adjustable Refrigeration Thermostat (2)
C. 0398557 Defrost Termination Thermostat (3)
(Electric Defrost only)
(CT.4440611)
D. 0481370 Heater Switch (4)
(Koolgas Defrost only)
(CT.4440738)
Item Part # Description Wiring Item #
HEATERS
E. 208V Evaporator Defrost Heaters (5)
0462159 8 ft case (HE.4850603)
0444058 12 ft case (HE.4850571)
F. 208V Drip Pan Defrost Heaters, Electric (6)
0462160 8 ft case (HE.4850636)
0444296 12 ft case (HE.4850572)
120V Drip Pan Defrost Heaters, Koolgas (7)
0465907 8 ft case (HE.4850622)
0465908 12 ft case (HE.4850623)
G. Nosing Anti-sweat Heaters (8)
0495007 8 ft case (HE.4850685)
0495008 12 ft case (HE.4850686)
H. Return Grille Anti-sweat Heaters (9)
0495011 8 ft case (HE.4850689)
0495012 12 ft case (HE.4850690)
I. Return Glass Anti-sweat Heaters (10)
0474778 8 ft case (GL.4987838)
0474779 12 ft case (GL.4987839)
We reserve the right to change or
revise specifications and product
design in connection with any feature
of our products. Such changes do not
entitle the buyer to corresponding
changes, improvements, additions or
replacements for equipment
previously sold or shipped.
FG
Technical Data Sheet
P/N 0465895_D
NSF®Certified
March 2008
©2008 HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
U.S. & CANADA 1-800-922-1919 • MEXICO 1-800-522-1900 • WWW.HUSSMANN.COM
Note: Revision D updates the Heater Switch part number on Page 1 and adds capacity and weight (Page 5).

2 of 7 FG Technical Data Sheet
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
4 3/4 (120)
10 3/8
(263)
FRONT
12 1/8(307)
F / FG
Waste Outlet
Electrical
Field
Connection
A
B
C
D
26 1/4
(665) 30 1/4
(767) 33 1/2
(851)
42
(1065)
Splashguard
8 (203)
Refrigeration
Outlet
Waste
Outlet
24
(612)
Electrical
Stub Up Area
6 x 6
(152 x 152)
26 1/2 (673)
NOTE: Case-to-Case Electrical Connections
are made IN FRONT OF SPLASHGUARD.
41 1/2
(1054)
43 7/8
(1114)
41 1/2
(1054)
4 1/4 (108)
31 5/8
(804)
4 1/2 (115)
Wireway
3 In.
(77 mm)
Required
Air Gap
Engineering
Plan Views
Dimensions shown as inches & (mm).
10-2004
8 ft 12 ft
General
(A) Case Length (without ends or partitions) 96 3/8(2448) 144 1/2(3670)
(Each end and insulated partition adds 2 in. (51 mm) to case line up.)
Maximum O/S dimension of case back to front (includes bumper) 42 (1065) 42 (1065)
Back of case to front of splashguard 33 1/2 (851) 33 1/2 (851)
Back of case to O/S edge of front leg 30 1/4 (767) 30 1/4 (767)
Distance between edges of external legs and center legs 41 1/2 (1054) 41 1/2 (1054)
Distance between edges of center legs NA 43 7/8 (1114)
Distance between front legs and splashguard 3 1/8(82) 3 1/8(82)
Electrical Service (Electrical Field Wiring connection point)
(B) RH End of case to center of stub up area 84 1/4 (2140) 132 3/8 (3363)
Back of case to center of stub up area 24 (612) 24 (612)
Length of electrical wireway 26 1/2 (673) 26 1/2 (673)
(C) RH End of case to LH end of wireway 90 1/8 (2289) 138 1/4 (3511)
Waste Outlets (One each end)
(D) RH End of case to the center of LH waste outlet 84 1/4 (2140) 132 3/8 (3363)
RH End of case to the center of RH waste outlet 12 1/8 (307) 12 1/8 (307)
Back O/S of case to center of waste outlets 31 5/8 (804) 31 5/8 (804)
Schedule 40 PVC drip pipe 1 1/4 (32) 1 1/4 (32)
Refrigeration Outlet
Back of case to center of refrigeration outlet 26 1/4 (665) 26 1/4 (665)
RH end of case to center of refrigeration outlet 8 (203) 8 (203)
Low / Medium Temperature
Wireway
PHYSICAL DATA
Merchandiser Drip Pipe (in.) 1 1/4
Merchandiser Liquid Line (in.) 3/8
Merchandiser Suction Line (in.) 5/8

REFRIGERATION DATA
Note: This data is based on store temperature and
humidity that does not exceed 75°F and 55% R.H.
MED FF IC
Discharge Air (°F) +24 –12 –22
Evaporator(°F) +19 –20 –30
Unit Sizing (°F) +17 –23 –33
Btu/hr/ft MED FF IC
Parallel 300 420 430
Conventional 315 440 450
DEFROST DATA
MED FF IC
Frequency (hr) 24 24 24
Defrost Water (lb/ft/day) 1.1 1.05 0.9
(± 15% based on case configuration and product
loading).
ELECTRIC MED FF IC
Temp Term (°F) 48 48 48
Failsafe (minutes) 60 60 60
GAS
Duration (minutes) NA 15 18
OFFTIME Not Recommended
Standard Defrost Thermostat
Close on rise: close 48°F — open 33°F
CONVENTIONAL CONTROLS
Low Pressure Backup Control — CI/CO *
MED +12°F / +2°F
FF –17°F / –29°F
IC –27°F / –39°F
Indoor Unit Only, Pressure Defrost Termination*
Not Recommended
*Use a Temperature Pressure Chart to determine PSIG
conversions.
Estimated Charge (lb)**
8 ft 2.0
12 ft 3.0
**This is an average for all refrigerant types. Actual
refrigerant charge may vary by approximately half a
pound.
Length Added to Lineup by Each
End or Partition (in.) 2
3 of 7P/N 0465895_D HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A. • WWW.HUSSMANN.COM
FAN COIL
Refrigeration
Outlet
15 7/8
(404)
35 7/8
(910)
33 3/8(848)
5 1/2
(140)
3 1/8
(79)
24 3/8
(618)
26 1/4(665)
19 7/8(503)
31 5/8(804)
33 1/2(851)
42 (1065)
FG
9 7/8
(251)
30 1/4(767)
35 1/4
(893)
Case-to-Case
Connection
3 In. (77 mm)
Required
Air Gap
Impact Excel FG
Low / Medium Temperature
Single Deck Wall Display with Glass Front
Dimensions shown as inches & (mm).
NSF Certification
This merchandiser model is manufactured to meet ANSI/NSF
(National Sanitation Foundation) Standard #7 requirements for
construction, materials & cleanability.

FG Technical Data Sheet
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
4 of 7
Impact Excel FG
Low / Medium Temperature
Electrical Data
8 ft 12 ft
Number of Fans – 4W Evaporator 2 2
Amperes Watts
8 ft 12 ft 8 ft 12 ft
Evaporator Fans
120V 60Hz Standard 0.62 0.62 48 48
120V 50Hz Standard 0.76 0.76 54 54
230V 60Hz Export 0.30 0.30 48 48
230V 50Hz Export 0.36 0.36 54 54
120V 60Hz Energy Efficient 0.24 0.24 16 16
230V 60Hz Energy Efficient 0.12 0.12 16 16
Anti-sweat Heaters (on fan circuit)
120V 50/60Hz Standard 0.87 1.30 104 156
230V 50/60Hz Export 0.45 0.68 104 156
Minimum Circuit Ampacity
120V 60Hz Standard 1.69 2.12
120V 50Hz Standard 1.83 2.26
230V 60Hz Export 0.95 1.18
230V 50Hz Export 1.01 1.24
120V 60Hz Energy Efficient 1.31 1.74
230V 60Hz Energy Efficient 0.77 1.00
Maximum Over Current Protection 120V 20 20
Maximum Over Current Protection 230V 15 15
Return Glass Anti-sweat Heaters
120V 50/60Hz Standard 0.08 0.11 9 13
230V 50/60Hz Export 0.04 0.06 9 13
208V Electric Defrost 7.69 11.54 1600 2400
230V Export Electric Defrost 6.96 10.43 1600 2400
120V Koolgas Defrost 1.67 3.33 200 400
Standard Lighting
None

5 of 7P/N 0465895_D HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A. • WWW.HUSSMANN.COM
Impact Excel FG
Low / Medium Temperature
ESTIMATED SHIPPING WEIGHT 5
Case Solid End
4 ft 6 ft 8 ft 12 ft (each)
lb (kg) 600 (272) 800 (363) 1000 (454) 1200 (544) 50 (23)
5Actual weights will vary according to optional kits included.
Product Data
ARI Refrigerated Volume 1 (Cu Ft/Ft) 3.54 ft3/ft (0.33 m3/m)
Recommended Usable Cube 2 (Cu Ft/Ft) 3.69 ft3 /ft (0.34 m3 /m)
ARI Total Display Area 3 (Sq Ft/Ft) 2.78 ft2/ft (0.85 m2 /m)
Shelf Area 4(Sq Ft/Ft) 2.79 ft2/ft (0.85 m2 /m)
1Computed using ARI 1200 standard methodology: Refrigerated Volume, ft3[m3]/Unit of Length, ft [m]
2ARI Refrigerated Volume less shelving and other unusable space: Refrigerated Volume/Unit of Length, ft3/ft [m3/m]
3Computed using ARI 1200 standard methodology: Total Display Area, ft2[m2]/Unit of Length, ft [m]
4Shelf surface area is composed of bottom deck plus standard shelf complement, as shown in the Hussmann
Product Reference Guide. The standard shelf complement for this model is NONE.

6 of 7 FG Technical Data Sheet
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
Red
208 V Power From Defrost Contactors
L1 L2
Electric Defrost Heaters
Drip Pan Heater
6
Red
5
Defrost Termination Thermostat
Dark Blue To
Condensing
Unit
}
3
Light Blue
2
To
Condensing Unit
}
Refrigeration Thermostat (Optional)
1
BROWN BAND
Fans
BROWN BAND
Nosing
Anti-sweat
Heater
120V POWER
120V NEUTRAL
89
Return Grille
Anti-sweat
Heater
WARNING
All components must have mechanical ground, and the merchandiser must be grounded.
Circled Numbers = Parts List Item Numbers.
10
Return Glass Anti-sweat Heater
White
Purple
120V POWER 120V NEUTRAL
Electric Defrost – Standard

7 of 7P/N 0465895_D HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A. • WWW.HUSSMANN.COM
Gas Defrost – Optional
WARNING
All components must have mechanical ground, and the merchandiser must be grounded.
Circled Numbers = Parts List Item Numbers.
7
4
120V Drip Pan Heater — Koolgas Only
Yellow
Heater Switch
Yellow
120V POWER 120V NEUTRAL
Dark Blue
Dark Blue
