Hussmann RDI Instruction Manual

13
1 of 13
RDI
Technical Data Sheet
Rev A
S
p
ecialt
y
Products
RDI
These merchandisers are manufactured to meet ANSI/National Sanitation
Foundation Standard #7 requirements.
We reserve the right to change or revise specifications and
p
roduct design in connection with any feature of our
p
roducts. Such changes do not entitle the buyer to
corresponding changes, improvements, additions or
replacements for equipment previously sold or shipped.
REFRIGERATION DATA
Note: This data is based on store temperature and
humidity that does not exceed 75F and 55% R.H.
Discharge Air (F) 30
Evaporator (F) 20
N
ote: Not recommended to control temp by regulating
coil temp allow t-stat to cycle and control temp.
B
tu/hr/
ft
*
Parallel 750
Conventional 863
*For all refrigeration equipment other than Hussmann,
use conventional Btu values.
DEFROST DATA
Frequency Hrs 4
OFFTIME
Temp Term °F 54
Failsafe Minutes 20
ELECTRIC or GAS Not Recommended
PHYSICAL DATA
Merchandiser Drip Pipe (in.) 1 ½*
Merchandiser Liquid Line (in.) 3/8*
Merchandiser Suction Line (in.) 5/8*
Estimated Charge (lb)***
4ft 1.2
5ft 1.5
6ft 1.8
*Dependent on case length and refrigerant type.
*** This is an average for all refrigerants types. Actual
refrigerant charge may vary by approximately half a
p
ound. GLYCOL REQUIREMENTS
GPM PSI
NA NA
NA NA
NA NA
CUL Listed
UL Sanitation

13
2 of 13
RDI
Technical Data Sheet
Rev A
S
p
ecialt
y
Products
RDI
Engineering
Cut & Plan View RDI

13
3 of 13
RDI
Technical Data Sheet
Rev A
S
p
ecialt
y
Products
RDI
RDl 1 or 2 Pans, 1/4 HP-115V W2100001
Remote or S/Contained 3 or 4 Pans, 1/4 HP-115V W2100002
5 or 6 Pans, 1/4 HP-115V W2100003
7 or 8 Pans, 1/3 HP-115V 8' W2100004
9 or 10 Pans, 1/2HP-115V W2100005
11 Pans, 3/4 HP-230V W2100006
RDI-20-6WELL-SC 6 W2100005
RDI-20-7WELL-SC W2100007
RDI-20-9WELL-SC 1H07238
RDI-27 5 Well-SC 1H07235
