Hussmann SSG User manual

T'Stat Bulb
Location
(Optional
Lights)
D
C
B
A
P/N 0420062B
SSG
Data Sheet Set
P/N 0420062B
NSF®Certified
May, 2003
Merchandisers
®
Note: Changed items have been underlined.
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
Item Part # Description Wiring Item #
FAN ASSEMBLIES AND THERMOSTATS
A. 0404551 Fan Motor, Ambient (120V) (1)
0404552 Fan Motor, Ambient (220V)
B. 0137880 Optional Adjustable (2)
Refrigeration Thermostat
Item Part # Description Wiring Item #
LAMPS AND BALLASTS
C. 0355716 Ballast, Electronic, 2 lamps
(120V) (3)
C. 0355398 Ballast, Electronic, 3 lamps
(120V) (4)
C. 0440215 Ballast, Electronic, 2 lamps
(230V 50-60 Hz) (3)
C. 0428652 Ballast, Electronic, 3 lamps
(230V 50-60 Hz) (4)
0385104 Ballast Transformer
(230V 50-60 Hz, per ballast)
D. Fluorescent Lamp (5)
Replace with like fixtures

HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A. SSG Data Sheet
2 of 6
Engineering
Plan Views
C
L
(See Note*)
255 / 8
(651)
25 5/8
(651)
Legs
283 / 4
(730)
Front
Refrigeration
Outlet
Water Seal
Waste Outlet
Leg Center Lines
Electrical
44 5/8
(1133)
333 / 8
(849)
(See Note**)
SMB
SMG
SSG
A
B
DC
E
Dimensions shown as in. and (mm).
4 ft 6 ft 8 ft 12 ft
General
(A) Case Length* 48 1/4 (1226) 72 1/4 (1835) 96 3/8(2448) 144 1/2(3670)
Maximum O/S dimension of case back to front 44 5/8(1134) 44 5/8(1134) 44 5/8(1134) 44 5/8(1134)
(Note: Includes bumper)
Back of case to front of splashguard 33 3/8(848) 33 3/8(848) 33 3/8(848) 33 3/8(848)
Center of rear legs to center of front legs 25 5/8(651) 25 5/8(651) 25 5/8(651) 25 5/8(651)
Each End and Partition adds 1 1/2in. (38 mm) to the length of the lineup.
Electrical Service
(B) RH end of case to Electrical raceway right edge 7 (178) 7 (178) 7 (178) 7 (178)
(C) RH end of case to Electrical raceway left edge 41 3/8(1051) 32 3/4(831) 44 1/2(1131) 44 1/2(1131)
Back of case to center of knockout 3 5/8(92) 3 5/8(92) 3 5/8(92) 3 5/8(92)
* Electrical Field Wiring Connection Point
Waste Outlet
(D) RH end of case to the center of waste outlet 24 (610) 24 (610) 24 (610) 24 (610)
Back of case to center of waste outlet 25 5/8(652) 25 5/8(652) 25 5/8(652) 25 5/8(652)
Water Seal
Center of tee to center of waste outlet 11 3/8(289) 11 3/8(289) 11 3/8(289) 11 3/8(289)
Outside diameter of drip piping 1 1/2(38) 1 1/2(38) 1 1/2(38) 1 1/2(38)
** Field installed water seal outlets, tees, and connectors are shipped with the merchandiser.
Refrigeration Outlet
Back of case to center of refrigeration outlet 28 3/4(731) 28 3/4(731) 28 3/4(731) 28 3/4(731)
(E) RH end of case to center of refrigeration outlet 9 3/8(238) 9 3/8(238) 9 3/8(238) 9 3/8(238)
Outside diameter of the liquid line 3/8(9.5) 3/8(9.5) 3/8(9.5) 3/8(9.5)
Outside diameter of the suction line 5/8(16) 5/8(16) 5/8(16) 5/8(16)
Seafood
Double Curved
Hinged Glass Models

REFRIGERATION DATA
Note: This data is based on store temperature
and humidity that does not exceed 75°F and
55% R.H. Schedule defrost at night while
lights are off.
SSG
Discharge Air (°F) 21
Evaporator (°F) 18
Unit Sizing (°F) 16
Btu/hr/ft* SSG
Parallel 380
Conventional 400
*For all refrigeration equipment other than
Hussmann, use conventional Btu values.
DEFROST DATA
SSG
Frequency (hr) 24
Defrost Water (lb/ft/day) 0.15
(± 15% based on case configuration and
product loading).
SSG
OFFTIME (minutes) 70
Failsafe (minutes) 90
ELECTRIC OR GAS Not Recommended
CONVENTIONAL CONTROLS
Low Pressure Backup Control
SSG
CI/CO (Temp °F)** 11°F / 1°F
Indoor Unit Only, Pressure Defrost
Termination (Temp °F)**
Not Recommended
**Use a Temperature Pressure Chart to
determine PSIG conversions.
PHYSICAL DATA
Merchandiser Drip Pipe (in.) 1 1/2
Merchandiser Liquid Line (in.) 3/8
Merchandiser Suction Line (in.) 5/8
Estimated Charge (lb)***
4 ft 0.75
6 ft 1.0
8 ft 1.5
12 ft 2.0
***This is an average for all refrigerant
types. Actual refrigerant charge may vary by
approximately half a pound.
Length Added to Lineup by:
Each Plastic End w/ Bumper (in.) 3 1/2
Each End/Partition (in.) 1 1/2
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A. 3 of 6P/N 0420062B
SSG
52
(1321)
33
5/8
(854)
221/2
(572)
25 5/8(651)
283/4 (730)
34
(864)
20
(508)
24 1/4
(616)
133/4
(349)
333/8 (849)
445/8 (1133)
35/8
(92)
11 3 /8
(289)
10 1 /2
(267)
Refrig.
Outlet Elec.
FAN
21O
C
O
I
L
COIL
Impact SSG
Seafood
Curved Hinged Glass, Single Display Level
Dimensions shown as in. and (mm).
NSF Certification
These merchandisers are manufactured to meet ANSI /National Sanitation
Foundation (NSF®) Standard #7 requirements.
NOTE: The bumper is 4 in. (102 mm) wide. Center of the bumper is
181/2in. (470 mm) from the floor.

Electrical Data
Number of Fans 4 ft 6 ft 8 ft 12 ft
Refrigeration (120V 60hz) – 4W NA NA NA NA
Ambient Air Wipe – 15W 1 2 3 4
Export Refrigeration (230V 50 hz ) – 4W NA NA NA NA
Export Ambient Air Wipe – 15W 1 2 2 3
Amperes Watts
Merchandiser 4 ft 6 ft 8 ft 12 ft 4 ft 6 ft 8 ft 12 ft
Refrigeration Fans
Standard (120V 60hz) NA NA NA NA NA NA NA NA
Energy Efficient(120V 60hz) NA NA NA NA NA NA NA NA
Export: 230V 50 hz NA NA NA NA NA NA NA NA
Ambient Air Wipe Fans
Standard (120V 60hz) 0.26 0.52 0.52 0.78 15 30 30 45
Energy Efficient(120V 60hz) NA NA NA NA NA NA NA NA
Export: 230V 50 hz 0.13 0.26 0.26 0.39 15 30 30 45
Constant On Anti-sweat Heaters NA NA NA NA NA NA NA NA
Cycling Anti-sweat Heaters NA NA NA NA NA NA NA NA
Minimum Circuit Ampacity
With Standard Fans (120V 60hz) 0.46 0.72 0.72 0.98
With Energy Efficient Fans (120V 60hz) NA NA NA NA
With Export Fans (230V 50 hz ) 0.33 0.46 0.46 0.59
Maximum Over Circuit Protection 120V 20 20 20 20
Electric Defrost Heaters (208V) NA NA NA NA NA NA NA NA
Gas Defrost Heaters (208V) NA NA NA NA NA NA NA NA
Standard Lighting* (120V 60hz) 4 ft 6 ft 8 ft 12 ft 4 ft 6 ft 8 ft 12 ft
2 Row Canopy 0.49 0.80 0.98 1.42 58 92 116 170
1 Row Rail 0.49 0.40 0.49 0.71 58 46 58 85
Optional Lighting
1 Row Ledge 0.49 0.40 0.49 0.71 58 46 58 85
*230V lighting values are under review.
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A. SSG Data Sheet
4 of 6
Impact SSG
Seafood

HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A. 5 of 6P/N 0420062B
R = Red G = Green BL = Blue LB =Light Blue B = Black W = White
= 120V POWER = 120V NEUTRAL = Field GROUND = Case GROUND
Fans
Electric Service Receptacle Receptacles
120V NEUTRAL
MAROON
BAND
120V POWER
W
B
G
N.E.C.
TAGS MAROON
BAND
Refrigeration
Thermostat
To
Condensing Unit
}
(Field Installed)
2
WARNING
All components must have mechanical ground, and the merchandiser must be grounded.
Circled Numbers = Parts List Item Numbers
Grayed components in 12 foot models only.
Ambient Fan
Wiring
Glass Air Wipe
LB
LB
BROWN BAND
Fans
BROWN BAND
120V POWER
120V NEUTRAL
1
8 ft case has 2 Fans
12 ft case has 3 Fans

SSG Data Sheet
6 of 6 HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
Standard Lighting 2 Row Canopy,
1 Row Interior Rail
Light Circuits
R = Red G = Green BL = Blue B = Black W = White
= 120V POWER = 120V NEUTRAL = Field GROUND = Case GROUND
WARNING
All components must have mechanical ground, and the merchandiser must be grounded.
Circled Numbers = Parts List Item Numbers
Grayed components in 12 foot models only.
3
55
120V NEUTRAL
ORANGE OR TAN BAND
RR
BL
BL BL
BL
W
Light
Switch
120V POWER
ORANGE OR TAN
BAND
B
W
RR
BL
BL
R
BL
RR
BL
BL
R
BL
BL
B
B
W
GG
G
G
G
GG
GG
G
G
R
3
3
5
5
55
55 5
W
B
RR
BL
BL
R
BL
BL
G
GGG
3
55 5
Optional Ledge Light Circuit
Rail Light Circuit
