Huvema HU 270 DHG-4 User manual

B A N D - S A W I N G - M A C H I N E S
HU 270 DGH-4

2
IMPORTANT
UPON THE DELIVERY OF THE MACHINE, THE CONSUMER MUST MAKE HIMSELF SURE THAT ALL THE DEVICES INDICATED
IN THE PARAGRAPH OF THE SAFETY MANUAL ARE PRESENT AND WORKING CORRECTLY. FURTHERMORE, HE MUST MOUNT IN
CONFORMITY WITH THE INSTRUCTIONS INDICATED THOSE DEVICES WHICH ARE NOT MOUNTED AT THE TIME OF DELIVERY TO
FACILITATE TRANSPORT.
WHEN ORDERING SPARE PARTS
IT IS NECESSARY TO STATE:
- MACHINE MODEL
- SERIAL NUMBER AND YEAR OF PRODUCTION
- ITEM REFERENCE NUMBER
WITHOUT SERIAL NUMBER NO SPARE PARTS WILL BE DELIVERED
WARRANTY
- THE FIRM GUARANTEES THE MACHINE DESCRIBED HEREBY, DESIGNED IN COMPLIANCE WITH ALL REGULATIONS IN FORCE,
IN PARTICULAR SAFETY AND HEALTH REGULATIONS; THE MACHINE HAS UNDERGONE SUCCESSFUL TESTING.
- THE WARRANTY COVERS A PERIOD OF 12 MONTHS. IT DOESN’T COVER ELECTRICAL MOTORS AND TOOLS.
- THE PURCHASER IS ENTITLED ‘REPLACEMENT OF FAULTY PARTS’. SHIPPING AND PACKING COSTS ARE AT HIS EXPENSE.
- THE WARRANTY DOESN’T COVER THE PARTS DAMAGED BY FALLS OR CARELESS HANDLING OF THE MACHINE, INCORRECT
OPERATION, NON-COMPLIANCE WITH THE MAINTENANCE RULES. ANY TAMPERING WITH THE MACHINE, ESPECIALLY WITH
THE SAFETY DEVICES AUTOMATICALLY EXPIRES THE WARRANTY AND THE MANUFACTURER WILL BE FREED FROM ANY
RESPONSIBILITY.
- ANY KIND OF ALTERATION ON THE MACHINE ENDS THE WARRANTY AND THE MANUFACTURER BECOMES FREE FROM EVERY
KIND OF RESPONSIBILITY.
- NO CLAIM FOR DAMAGES SHALL BE ACCEPTED IN CASE THE MACHINE LAYS IDLE FOR A LONG PERIOD OF TIME.
- MACHINE IS DESIGNED TO BE RUN INDOORS. IT IS NOT RECOMMENDED TO RUN THE MACHINE OUTDOORS.
- THE SERIAL NUMBER ON THE MACHINE IS A ‘MAIN REFERENCE FOR THE WARRANTY’, INSTRUCTIONS MANUAL, AFTER SALE
SERVICE AND IDENTIFY THE MACHINE IN CASE OF NEED.
GENERAL INFORMATION
- THE MACHINES ARE MANUFACTURED IN COMPLIANCE WITH THE ACCIDENT PREVENTION RULES IN FORCE.
- STRICTLY COMPLY WITH THE INSTRUCTIONS CONTAINED IN THIS MANUAL TO OBTAIN THE BEST PERFORMANCE FROM THE
MACHINE. STRICT COMPLIANCE WITH THE RULES CONTAINED HEREWITH WILL ENSURE OPTIMUM RESULTS AND AVOID ANY
INCONVENIENCE CAUSED BY THE NON-COMPLIANCE OF OPERATION AND MAINTENANCE INSTRUCTIONS.
- CLOSELY FOLLOW THE INSTRUCTIONS GIVEN BELOW TO AVOID CONTACTING THE MANUFACTURER FOR THE PROBLEMS
WHICH CAN BE EASILY SOLVED..
- IF AFTER HAVING STRICTLY COMPLIANCE WITH THE GIVEN INSTRUCTIONS, THE PURCHASER STILL NEEDS THE HELP OF OUR
TECHNICAL ASSISTANCE SERVICE, HE MUST SUPPLY ALL THE TECHNICAL INDICATIONS NECESSARY TO DETERMINE THE TYPE
OF PROBLEM AND/OR THE PARTS WHICH ARE NOT FUNCTIONING CORRECTLY. THIS WILL ENABLE OUR TECHNICAL
ASSISTANCE SERVICE TO INTERVENE QUICKLY AND EFFICIENTLY ON THE MACHINE.
- COPIES OF THE INSTRUCTION MANUAL MAY BE REQUESTED UPON INDICATION OF THE MACHINE SERIAL NUMBER.

3
GENERAL SAFETY NOTES
ALL INSTALLATION WORK INCLUDING THE ELECTRICAL CONNECTION MUST ONLY BE CARRIED OUT BY QUALIFIED PERSONNEL.
THE MACHINE MUST ONLY BE OPERATED BY A TECHNICALLY TRAINED AND EXPERIENCED OPERATIVE WHO IS ALSO INSTRUCTED
IN ‘SAFETY AT WORK ’ PROCEDURES.
ANY ADJUSTMENTS, CLEANING, REPAIRS OR CHANGING OF THE SAW BLADE MUST UNDER NO CIRCUMSTANCES BE PERFORMED
UNLESS THE MACHINE IS FULLY ISOLATED FROM THE ELECTRICAL POWER SUPPLY. ENSURE THE EMERGENCY STOP BUTTON ON
THE CONTROL BINNACLE IS PRESSED AND THE POWER SUPPLIES AT THE MAINS ARE DISCONNECTED.”
THE BAND SAW MUST BE REGULARLY INSPECTED AND MAINTAINED IN GOOD SERVICEABLE CONDITION. EYE PROTECTION, EAR
PROTECTION, GLOVES AND PROTECTIVE CLOTHING MUST BE WORN WHEN ANY OF THE ABOVE PROCEDURES ARE BEING CARRIED
OUT, AS WELL AS WHEN CUTTING FLUID IS PREPARED, INTRODUCED OR DISPLACED FROM THE BAND SAW MACHINE (THE
RELEVANT ENVIRONMENTAL REGULATIONS MUST BE OBSERVED IN CASE OF THE USE AND DISPOSAL OF CUTTING FLUID ETC.)
THE BAND SAW MUST BE INSTALLED ON GROUND. OBSERVE THE PERMISSIBLE FLOOR LOAD. THAN THE BAND SAW MACHINE HAS
BEEN PROPERLY BOLT TO GROUND SECURELY.
ALLOW SUFFICIENT WORKING SPACE AROUND THE BAND SAW OF AT LEAST 1 METER. INSTALLATIONS OF STOCK ROLLER
CONVEYORS REQUIRE ADDITIONAL SPACE AND POSSIBLY A LIFTING MECHANISM FOR HEAVY WORK PIECES. ALWAYS ENSURE
THAT THE WORKING AREA AROUND THE BAND SAW IS WELL LIT.
SAFETY INSTRUCTIONS
BE SURE THAT ELECTRICAL CONNECTION IS MADE CAREFULLY. TO AVOID UNWANTED SITUATIONS LIKE ELECTRICAL SHOCK,
PROTECT THE MAIN SUPPLY CABLE WITH A HOLSTER.
BEFORE RUNNING THE MACHINE, BE SURE THAT ALL OF THE PROTECTIONS ARE MOUNTED PROPERLY AND ALL THE COVERS
ARE CLOSED.
AVOID FROM SMOKE AND MOISTURE.
PLEASE USE THE PARTS AND EQUIPMENTS WHICH ARE RECOMMENDED. USAGE OF UNSUITABLE PARTS AND MATERIALS
WHICH ARE BIGGER THAN THE CAPACITY OF THE MACHINE CAN CAUSE UNWANTED SITUATIONS.
CHECK THE MACHINE AND INFORM THE DEFECTS EVERYDAY.
DON’T LEAVE ANY MATERIAL AFTER CHANCING THE BAND.
DO NOT HOLD THE MATERIAL WHILE THE MACHINE IS CUTTING. ALWAYS TIGHTEN THE MATERIAL BY USING ESSENTIAL
PARTS.
PLEASE PAY ATTENTION TO CHOOSE THE AREA OF THE MACHINE WHICH DOESN’T INCLUDE ANYTHING THAT CREATES
DIFFICULTIES TO CONTROL THE MACHINE
PLEASE BE SURE THAT THE TEETH OF THE BAND ARE LOOKING TO CORRECT DIRECTION.
DON’T LEAVE THE BAND ON THE GROUND OR ANY PLACE THAT IS DANGEROUS FOR OTHER PEOPLE.
BE CAREFUL WHEN USING THE MACHINE AND KEEP THE WORKING AREA CLEAN ( CLEAN THE SAW DUSTS AND OIL TRACES
)
PAY ATTENTION TO SECURITY INSTRUCTIONS WHEN USING THE MACHINE.
DON’T WEAR LOOSE CLOTHS WHEN USING THE MACHINE.
REGARDLESS USE THE PROTECTIVE GLOVES WHEN USING THE MACHINE.
DON’T GET CLOSE TOO MUCH TO THE MACHINE WHEN RUNNING.
BEFORE CARRYING OUT ANY CLEANING OR MAINTENANCE PROCEDURE, DISCONNECT THE MACHINE FROM MAIN SUPPLY.
IN SOME CONDITIONS, NOISE LEVEL CAN BE ABOUT 85 DB. BAND CHOICE AND CUTTING SPEED IS IMPORTANT FACTOR FOR
NOISE LEVEL.
ILLUMINATION IS AN IMPORTANT FACTOR FOR SECURITY.
RATIO OF COOLANT LIQUID IS IMPORTANT FOR OBTAINING OPTIMUM LUBRICATION.
NEVER USE THE MACHINE IF YOU NOTICE ANY FAULT OF THE MACHINE OR ABSENCE OF ANY PART OF THE MACHINE.
CONTROL THE EMERGENCY BUTTON AT LEAST ONCE A WEEK AND BE SURE THAT IT IS WORKING PROPERLY.

4
DEFINITIONS
(EXTRACTED FROM EN292/1 –292/2)
USER: THE PERSON, BODY OR COMPANY WHO HAS BOUGHT OR RENTED THE MACHINE AND INTENDS TO EMPLOY IT FOR THE
USES CONTEMPLATED.
OPERATOR: THE PHYSICAL PERSON AUTHORIZED BY THE USER TO OPERATE THE MACHINE AFTER HAVING BEEN SUITABLE
TRAINED ON THE USE AND SPECIFIC RISKS OF THE MACHINE..
AUTHORIZED PERSON: THE SKILLED PERSON, WHO IS AUTHORIZED BY THE USER TO CARRY OUT MAINTENANCE OR SETTING-UP
OPERATION OF THE MACHINE.
DANGEROUS ZONE: ANYWHERE INSIDE AND/OR NEAR A MACHINE, WHICH THE PRESENCE OF AN EXPOSED PERSON REPRESENTS
A RISK FOR HIS SAFETY AND HEALTH.
EXPOSED PERSON: ANY PERSON WHO FINDS HIMSELF IN DANGEROUS ZONE, EITHER ENTIRELY OR PARTIALLY
PURPOSE OF MACHINE
THIS MACHINE HAS BEEN DESIGNED TO BE MAINLY USED BY LIGHT AND MEDIUM STRUCTURAL STEEL INDUSTRIES.
THIS MACHINE HAS BEEN DESIGNED FOR THE CUTTING OF FERROUS MATERIAL AND THE OTHER LIGHT MATERIALS WITH SOLID,
HOLLOW OR CROSS SECTION. ANY OTHER MATERIAL USE DIFFERING FROM THE ABOVE MENTIONED MATERIALS IS TO BE
CONSIDERED INAPPROPRIATE AND PROHIBITED.
THE MACHINE OPERATOR MUST BE TRAINED AND INFORMED OF RISKS AND MUST HAVE THE INSTRUCTION MANUAL AT HIS
DISPOSAL.
THE OPERATOR MUST NOT WORK IN THE VICINITY OF THE DANGER ZONE (CUTTING AREA) WITH ANY OTHER PEOPLE.
DURING THE CUTTING PROCESS, THE OPERATOR MUST NEVER PUT HANDS OR USE TOOLS IN THE CUTTING AREA
RELATED DIRECTIVES AND STANDARDS
DIRECTIVES:
MACHINERY DIRECTIVE 98/37/EC
LOW VOLTAGE DIRECTIVE 2006/95/EC
ELECTROMAGNETIC COMPATIBILITY DIRECTIVE 2004/108/EC
STANDARDS:
NEN-EN-ISO 13857:2008;
NEN-EN-ISO 4413:2010;
NEN-EN-ISO 13849-1:2008;
NEN-EN 13898:2003+A1:2009/C1:2010
NEN-EN-ISO 12100:2010;
NEN-EN-IEC 60204-1:2006/C11:2010.

5
WARNING
THIS CHAPTER OUTLINING THE SAFETY DEVICES AND NORMS WAS DRAWN UP BEARING IN MIND THE NORMAL USE OF THE
MACHINE AS STATED IN THE CHAPTER ON THE OPERATION OF THE MACHINE AND THE ADEQUATE PREPARATION OF THE
OPERATORS AS REGARDS THE SPECIFIC RISKS LINKED TO THE OPERATION OF THE MACHINE.
IF THE MACHINE ISN’T USED ACCORDING TO INSTRUCTION GIVEN IN THE ‘PURPOSE OF THE MACHINE’ CHAPTER IN THIS MANUAL,
THE MANUFACTURER ISN’T RESPONSIBLE FOR ANY DAMAGE CAUSED TO PEOPLE AND THINGS.
FURTHERMORE, THE MANUFACTURER ISN’T RESPONSIBLE FOR ANY DAMAGE TO PEOPLE AND THINGS AND THINGS RESULTING
FROM THE NON-COMPLIANCE WITH THE FOLLOWING WARNINGS.
A) ADOPT ALL THE NECESSARY PRECAUTIONS DURING LOADING, CALIBRATION, PART REPLACEMENT, CLEANING, AND
REPAIR OR MAINTENANCE OPERATIONS TO PREVENT SOMEONE ELSE FROM TURNING THE MACHINE ON.
B) DO NOT TEMPER WITH THE SAFETY DEVICES AND GUARDS ON THE MACHINE.
C) DO NOT REMOVE ANY OF THE SAFETY DEVICES AND GUARDS ON THE MACHINE.
D) ALWAYS MAKE SURE THAT SAFETY DEVICES AND GUARDS ARE REMOUNTED AFTER THEIR TEMPORARY REMOVAL FOR
TECHNICAL REASONS ORDERED BY THE BOSS
TECHNICAL DATA
DIMENSIONS
HU 270 DGH
Cutting Capacity
0°
Round
mm
270
Flat
mm
350 x 220
Square
mm
270
Cutting Capacity
-45°(Left)
Round
mm
210
Flat
mm
270 x 210
Square
mm
180
Cutting Capacity
+45°(Right)
Round
mm
240
Flat
mm
270 x 200
Square
mm
170
Cutting Capacity
+60°
Round
mm
150
Flat
mm
150 x 100
Square
mm
100
Main Drive Motor
kW
0,75 - 1,5
Hydraulic Motor
kW
0,37
Coolant Motor
kW
0,12
Cutting Speeds
m/min
34 - 68
Band Dimensions
mm
3160 x 27 x 0,9
Work Heigt
mm
910
Weight
Kg
510
Dimensions
Length
mm
1730
Width
mm
770
Height
mm
1550

6
TRANSPORTATION AND CARRYING OF MACHINE
THE MACHINES ARE SENT TO DOMESTIC BUYERS WITHOUT PACKING AND TO FOREIGN BUYERS ON SPECIAL TRANSPORT
PEDESTAL.
AFTER ARRIVAL OF THE MACHINE AND HAVING CERTIFIED THAT NO DAMAGE HAS BEEN DONE TO THE MACHINE, THE
MACHINE MAY BE UNPACKED. AFTER UNPACKING, THE MACHINE LEFT ON THE PEDESTAL MAY BE ROLLED ON A ROLLER TO ITS
DESTINATION OR TRANSPORTED BY MEANS OF A HEMP ROPE IN MANNER SHOW BELOW. DURING TRANSPORT, SPECIAL CARE
SHOULD BE PAID TO ALL THE PROJECTING ELEMENTS TO AVOID THEIR DAMAGE.

7
MOUNTING
MOSTLY THERE IS NO NEED FOR MOUNTING. IF YOU WANT TO MOUNT THE MACHINE TO THE GROUND, PLEASE KEEP IN
MIND THE DIMENSIONS GIVEN BELOW, THE HEIGHT ADJUSTABLE SCREWS WILL BE USEFUL WHEN ADJUSTING THE HORIZONTAL
POSITION OF THE MACHINE.

8
OPERATING INSTRUCTION
CONTROL PANEL
THE CONTROL PANEL OF HU 230DG HAS TWO PARTS; ONE OF THEM INCLUDES ONLY THE DOWN FEED VALVE AND THE OTHER
PART INCLUDES ALL THE BUTTONS THAT YOU WILL NEED IN USAGE OF YOUR SAWING MACHINE. YOU CAN SEE BOTH PARTS
BELOW AND THE DESCRIPTION OF THE BUTTONS ARE WRITTEN BELOW THEM.
(1) INDICATOR LAMP……..: THIS LAMP SHOWS THAT THE MACHINE IS CONNECTED TO ELECTRICITY.
(2) INDICATOR LAMP……..: THIS LAMP SHOWS THAT THE BLADE IS BROKEN OR NOT TIGHTENED.
(3) START BUTTON………...: USE THIS BUTTON TO START THE CUTTING PROCESS
(4) STOP BUTTON…….......: USE THIS BUTTON TO STOP THE CUTTING PROCESS
(5) BOW UP BUTTON……..: THIS BUTTON PROVIDES THE RAISE THE BOW UP.
(6) EMERGENCY STOP…….. : USE THIS BUTTON TO STOP THE MACHINE IN EMERGENCY
(7) COOLANT PUMP…..........: USE THIS SWITCH TO START / STOP THE COOLANT PUMP.
(8) BLADE SPEED SELECTOR.: USE THIS SWITCH TO SELECT THE BLADE SWITCH ( 35 –70 M /SN. )
(9) HYDRAULIC VICE BUTTON..: THIS BUTTON IS NOT USED IN DG TYPE MACHINES (USED IN DGH)
(10) BOW DOWN BUTTON…..: THIS BUTTON PROVIDES THE RAISE THE BOW UP.
(11) DOWN FEED VALVE…..: USE THIS VALVE TO ADJUST CUTTING PRESSURE

9
THE ADJUSTMENT OF CUTTING PRESSURE
ACCORDING TO THE GRADE OF MATERIAL, IT PROWIDES TO REGULATE CUTTING PRESSURE. THE CUTTING PRESSURE SHOULD BE
REDUCED WHEN THE BLADE IS BEING DULL. AFTER THAT THE BLADE MUST BE CHANGED.
AREA I : THIS SHOWS THAT THE TENSION OF THE BLADE IS LESS THAN IT MUST BE. ADJUST THE BLADE TENSION.
AREA II : THIS SHOWS THAT THE TENSION OF THE BLADE IS NORMAL
AREA III : THIS SHOWS THAT THE TENSION OF THE BLADE IS MORE THAN IT MUST BE.
THIS MAY BREAK THEBLADE. REDUCE THE TENSION.
HYDRAULIC VICE : 30 BAR
MAIN PRESSURE:30BAR
HYDROMECANIC BLADE TENSION :Min:150 BAR Max:170 BAR
DAILY MAINTENANCE
1-REMOVE THE CHIPS ON WHEELS
2-CLEAN THE CHIPS BETWEEN THE JAWS AND WORKING
TABLE
3-CLEAN THE HYDRAULIC DRAWER
4-CLEAN THE CHIPS IN THE COOLANT DEPOT.
*PUMP AIR TO REMOVE THE DIRTH IN HOSES
5-MANOMETER SHOULD BE BETWEEN 190-210 BAR
6-CLEAN THE TENSIONING SLIDE FLATS
MONTHLY MAINTENANCE
A-CONTROL THE CHIP BRUSH.
B-FILL GREASE OIL FROM THE HOLE ON THE REDUCTOR
SHAFT.
C-FILL GREASE OIL FROM THE HOLE ON THE TENSIONING
SLIDE.
D-CONTROL THE OIL LEVEL IN HYDRAULIC TANK
1-BLADE BREAK SWITCH
2-UPPER SWITCH
3-LOWER SWITCH

10
MANUEL CUTTING OPERATION
1) SWITCH ON THE MAIN SWITCH.
2) SELECT THE MANUAL-AUTOMATIC SELECTOR TO POSITION 2.
3) ADJUST S3 LIMIT SWITCH ACCORDING TO THE MATERIAL’S DIAMETER OR HEIGHT.
4) PRESS B3 PUSHBUTTON TO GO UP THE BOW. ( S2 LIMIT SWITCH MUST BE IN CIRCUIT OTHERWISE THE MACHINE DOES NOT
WORK. )
5) ADJUST THE LENGHT OF THE MATERIAL TO REQUIRED LENGHT. (BY USING S4 SWITCH.)
6) PRESS START PUSHBUTTON. ( IN MANUAL POSITION, START PUSHBUTTON MUST BE KEPT PRESED UNTIL THE BOW LEFT S2
LIMIT SWITCH.)
7) REGULATE THE CUTTING PRESSURE BY THE THROTTINLING VALVE.
8) BECAUSE OF COUNTER, THE MACHINE COULD BE LOCKED. IN THIS SITUATION THE MACHINE DOES NOT WORK. UPPER LINE OF
COUNTER MUST BE PRESET AFTER THAT THE RESET BUTTON MUST BE PRESSED.
9) FOR THE NEXT CUTTING, FOLLOW THE SOME WAY.
AUTOMATIC CUTTING OPERATION
1.SWITCH ON THE MAIN SWITCH.
2.SEALET B6 SELECTOR TO POSITION 2.
3.ADJUST S2 LIMIT SWITCH ACCORDING TO THE MATERIALS DIAMETER OR HEIGHT.
4.PRESS B3 PUHBUTTON TO THE BOW UP.
5.SELECT B6 SELECTOR TO POSITION 1.
6.SLIDE THE LENGHT-STOP ON THE SPINDLE UNTIL REACHING REQUIRED LENGHT AND THE TIGHTEN.
7.PRESET THE NUMBER OF CUTS REQOIRED AND PRESS THE RESET BUTTON ON THE COUNTER.
8.PRESS START BUTTON THE CUTTING OPERATION.
9.REGULATE THE CUTTING PRESSURE BY THROTTING VALVE.
AFTER STARTING THE CUTTING OPERATION, YOU DO NOT NEED ANY OPERATION ELSE, BUT ACCORDING TO THE GRADE OF
METERIAL YOU SWITCH ON THE COOLANTPUMP OR NOT.
P.S. IF THE MACHINE STOPPED WITHOUT REACHING PRESET NUMBER, THE BLADE COULD BE BROKEN OR THE MATERIAL LENGHT
COULD BE SHORTENED.

11
REGULATIONS
DEFECT SYMPTOMS CAUSE OF DEFECT TYP OF REPAIR
AFTER SWITCHING ON THE MAIN A) FUSE IS OFF. A) RESET FUSE.
SWITCH, THE LAMP ON CONTROL
PANEL DOES NOT WORK. B) BUMT BULB. B) REPLACE BULB.
AFTER GOING THE BOW DOWN A) THE BOW DOES NOT TOUCH A) RE-ADJUST S3 LIMIT SWITCH.
COMPLATELY, DOES NOT GO UP. S3 LIMIT SWITCH.
B)REVERSE DIRECTION PUMP B)TAKE THE COVER OFF AT THE
ROTATION. BACSIDE OF THE MACHINE
AND CHECK IF DIRECTION OF
ROTATION AGREE WITH THE
ARROW. IN CASE OF DISCRE-
PACY, PHASES IN THE
PUMP SUPPLY.
AFTER PRESING START BUTTON A)S2 LIMIT SWITCH DOES NOT A) PRESS BOW-UP BUTTON.
THE MOTOR DOES NOT WORK. GET IN TOUCH WITH THE BOW.
B) COUNTER IS LOCKED. B) PRESET THE COUNTER AND
PRESS RESET BUTTON.
C) THERMAL PROTECTION HAS C) WAIT A FEW MINUTES UNTIL
WORKED
. THERMAL RELAY COOL. IF THE
MOTOR STILL DOES NOT WORK.
PRESS RESET BUTTON.
PUMP DOES NOT SUPPLY A) REVERSE DIRECTION OF A) EXCHANGE PHASES IN THE
COOLANT. PUMP ROTATION. PUMP’S SUPPLY.
B) LACK OF COOLANT. B) POUR IN COOLANT.
C) SHUT VALVES THAT CUM OFF C) OPEN VALVE’S.
COOLANT.
D) THERNAL PROTECTION HAS D) WAIT A FEW MINUTES UNTIL
WORKED. RELAY COOL. IF THE MOTOR
STILL DOES NOT WORK PRESS
KEY.
IF THE ABOVE DEFECTS HAVE BEEN REMOVED AND IF THE MACHINE STILL DOES NOT WORK, CHECK APPROPRIATE ELECTRIC
CIRCUITS AND THEN CALL A CREW TRAINED TO REPAIR FOR THIS PURPOSE.
COOLANT INSTALLATION
A) TANK CAPACITY ………………….. LT.
B) INSTRUCTION: THE COOLANT SHOULD BE USED FOR CUTTING STEEL. THE COOLANT IS MADE FROM A MIX OF
LUBRICANT WITH WATER.
CAST HAS TO BE CUT DRY. AFTER A CERTAIN TIME (AT LEAST ONCE A MONTH) THE COOLANT HAS TO BE REMOVED TO CLEAN ITS
DEPOSIT. IN CASE THAT THE COOLANT SUPPLY COMES WEAK, PUT MORE COOLANT INTO THE TANK.
CONNECTING WITH THE MAINS
THE MACHINE IS EQUIPPED WITH A DRIVE MOTOR DRIVING BY A V-BELT AND OTHER NECESSARY ELECTRICAL
EQUIPMENTS. ELECTRICAL BOX IS INSTALLED ON THE LOWER PART. CONTROL PANEL IS MOUNTED ON THE ELECTRICAL BOX. THE
MACHINE IS CONNECTED WITH THE MAINS AT THE ELECTRICAL BOX. R, S AND T STAND FOR PHASES, N STANDS FOR NEUTER AND
PE STANDS FOR GROUND.
THREE-PHASE MOTORS ALLOW AN EASY CHANGE OF THE POLES AT THE CONNECTING FLEXES IN ORDER TO CORRECT THE
DIRECTION OF CUTTING

12
BLADE GUIDANCE:
FOR AN ACCURATE GUIDANCE OF THE BAND SAW BLADE THERE ARE TWO RIGID AND PRECISE VERTICAL GUIDE ARMS FITTED
WITH ROLLERS FOR TWISTING AND CARBIDE INSERTED PLATES FOR THE FINAL AND EXACT BLADE GUIDE. ALWAYS PUT THE
BLADE GUIDE ARMS AS CLOSE AS POSSIBLE TO MATERIAL TO BE CUT AND TIGHTEN IT. THE PLAY OF THE BLADE CAN BE RESET BY
ALTERING THE POSITION OF A CARBIDE INSERTED GUIDE PLATE.
SETTING NEW BLADE
- FIRST OF ALL BOTH GUARD FLAPS AND THE GUARDS WHICH ARE ON THE GUIDE ARMS HAVE TO BE OPEN UPWARDS.
- LOOSEN THE BLADE BY THE HAND LEVEL SO FAR THAT THE BLADE CAN BE EASILY TAKEN OFF AROUND THE PULLEYS.
- THE SAME WAY BUT VIC AVERSE, FIT AND TIGHTEN THE NEW BLADE. THERE IS ALSO POSSIBILITY TO TIGHTEN THE
BLADE BY TORQUE METER.
- ALWAYS PAY ATTENTION TO THE TEETH OF THE BLADE’S DIRECTION IS CORRECT. IF NOT CORRECT IT.
CUTTING SPEEDS
THE MACHINE HAS TWO PRE-SELECTED CUTTING SPEEDS OF 34 AND 68 m/sec. CUTTING SPEEDS HAS TO BE SELECTED
ACCORDING TO THE GRADE AND DIMENSIONS OF THE MATERIAL. IF ANY VIBRATION AND/OR NOISE RISES FROM THE BLADE,
CHANGE THE SPEED.
* ALL THE DETAILS ABOUT THE CUTTING OF VARIOUS MATERIALS AND DIMENSIONS ARE GIVEN BELOW

13
CUTTING RECOMENDATIONS
Note:The Cutting Speeds Given Below Are Guidelines Only
Material
Material Designation
DIN
Material
No
Cutting Speed
Coolant
Special
LG-Super
Bi-
Metal
Emulsion
Cutting Oil
Yes
No
Structual Steel
St 35 –St 42
1.0308-
0077
40 - 55
60 - 80
1:10
x
St 350 –St 70
1.0052-
0070
30 - 45
50 - 70
1:20
x
Hardening Steel
C 10 - C 16
1.0301-
0401
45 - 65
60 - 90
1:10
x
14 NICr 14
1.5752
30 - 40
40 –50
1:10
x
21 NICr Mo 2
1.6523
30 - 45
45 - 55
1:10
x
16 MrCr 5
1,7131
30 - 45
50 - 65
1:10
x
Nitricted Steel
(Heat Treated)
34 CrAl 6
1,8504
------
20 - 35
1:20
x
34 Cr Al NI 7
1,8550
------
20 - 35
1:20
x
Free Cutting Steel
9 S 20
1,0711
45 - 65
70 - 120
1:10
x
Heat Treatable Steel
C 35 C 45
1,0501-
0503
35 - 55
55 - 75
1:20
x
41 Cr 4
1,7035
35 - 35
40 - 60
1:20
x
40 Mn 4
1,5038
35 - 45
50 - 65
1:20
x
42 Crmo 4
1,7225
30 - 40
35 - 50
1:20
x
36 NI Cr 6
1,5710
30 - 40
50 - 60
1:20
x
24 NI Cr 14
1,5754
25 - 35
40 - 60
1:20
x
Ball Bearing Steel
100 - Cr 6
1,3505
25 - 35
50 - 65
1:30
x
105 –Cr 4
1,3503
25 - 35
50 - 65
1:30
x
100 –CrMo 6
1,3520
20 - 30
40 - 50
1:30
x
Spring Steel
65 SI 7
1,0906
30 - 40
40 - 60
1:30
x
50 CrV 4
1,8159
30 - 40
40 - 60
1:30
x
Unalloyed Tool Steel
C 80 W 1
1,1525
25 - 35
50 - 60
1:30
x
C 125 W 1
1,1560
20 - 30
20 - 35
1:30
x
C 105 W 2
1,1645
25 - 35
40 - 50
1:30
x
Alloyed Tool Steel
105 Cr 5
1,2060
30 - 40
50 - 60
1:30
x
X 210 Cr 12
1. 2080
------
20 - 35
------
x
x 40 Cr Mo V 51
1,2344
20 - 30
30 - 40
1:30
x
x 210 Cr W 12
1,2436
------
20 - 30
------
x
x 165 Cr Mp V 12
1,2601
------
20 - 35
1:30
x
56 NICrMoV 7
1,2714
25 - 30
20 - 40
1:30
x
100 CrMo 5
1,2303
20 - 30
35 - 45
1:30
x
x 32 CrMoV 33
1,2365
20 - 30
30 - 45
1:20
x
High Speed Steel
S 5-6-2
1,3343
------
25 - 40
1:30
x
S 5-6-2-5
1,3243
------
25 - 40
1:30
x
S 18-0-1
1,3355
------
25 - 40
1:30
x
S 18-1-2-10
1,3265
------
25 - 40
1:30
x
Valve Steel
x 45 CrSi 93
1,4718
------
30 - 40
1:20
x
x 45 CrNiW 189
1,4873
------
30 - 40
1:20
x
High Temperature Steel
CrNi 2520
1,4843
------
25 - 40
1:10
x
x 20 CrMoV 211
1,4922
------
25 - 40
1:10
x
x5 NiCrTi 2615
1,4980
------
25 - 40
1:10
x
Heat Resisting Steel
X 10 CrAl 7
1,4713
------
20 - 35
1:10
x
x 15 CrNiSi 25 / 20
1,4841
------
20 - 35
1:10
x
X 10 CrSi 6
1,4712
------
20 - 35
1:10
x
Stainless and Acid
Resisting Steel
X 5 CrNi 189
1,4301
------
25 - 35
1:10
x
x 10 CrNiMpT 1810
1,4571
------
25 - 35
1:10
x
X 10 Cr 13
1,4006
------
25 - 35
1:10
x
x 5 CrNiMo 1810
1,4401
------
25 - 35
1:10
x
Steel Casting
GS –38
30 - 40
50 - 60
1:50
x
GS –60
30 - 40
50 - 60
1:50
x
Cast Iron
GG –16
30 - 40
40 - 50
------
x
GG –30
30 - 40
40 - 50
------
x
GTW –40
30 - 40
40 - 50
------
x
GTS –65
30 - 40
40 - 50
------
x
High Temperature
Nickel Alloys
NiMoNic
2,4631
------
15 - 25
1:10
x
Hastelloy
X 2.4972
------
15 - 25
1:10
x
Inconel
2,4640
------
15 - 25
1:10
x
Aluminium Alloys
Al 99,5
3,0255
80 - 300
100 - 700
1:10
x
AlMg 3
3,3535
80 - 300
100 - 700
1:10
x
Bronze / Tin Bronze
CuSn 6
2,1020
50 - 70
70 - 100
1:50
x
G –CuSn 10
2,1050
50 - 70
70 - 100
1:50
x
Aluminium - Bronze
CuAl 8
2,0920
30 - 45
50 - 70
1:30
x
CuAl 8 Fe 38
2,0920,60
30 - 40
40 - 50
1:20
x
Red Brass
G –CuSn 10 Zn
2,1086,01
30 - 45
70 - 100
1:50
x
G –CuSn 5 Zn Pb
2,1096,01
30 - 45
70 - 100
1:50
x
Brass
CuZn 10
2,0230
80 - 200
100 - 300
1:50
x
CuZn 31 S
2,0490
80 - 200
100 - 300
1:50
x

14
Recommendation for Tooth Style and Tooth Pitch Selections for HSS Bi-Metal Bandsaws
Standard Toolth
Combi Tooth
For cuting pipes and shapes
Material
Diameter
Tooth Pitch
Tooth Shape
Material
Diameter
Tooth Pitch
Tooth Shape
O(mm)
S (mm)
Tooth Pitch
<40
80
100
150
200
300
< 12mm
14 tpi N
< 25 mm
10/14 tpi 0°
8/1
22
8/1
2
8/1
2
8/1
2
6/1
0
6/1
0
12-30
mm
10 tpi N
2-40 mm
8/12 tpi 0°
8/1
22
6/1
0
6/1
0
5/8
4/6
4/6
30-50
mm
8 tpi N
25-70 mm
6/10 tpi 0°
6/1
0
5/8
5/8
4/6
4/6
4/6
50-80
mm
6 tpi N
35-90 mm
5/8 tpi 0°
5/8
4/6
4/6
4/6
3/4
3/4
80-100
mm
4 tpi KL.
50-100 mm
4/6 tpi pos.
4/6
4/6
3/4
3/4
3/4
110-200
mm
3. tpi KL.
80-200 mm
¾ tpi pos.
3/4
3/4
3/4
2/3
2/3
200-400
mm
2, tpi KL.
>200 mm
2/3 tpi pos.
3/4
2/3
2/3
>400 mm
1,25 tpi KL.
Tooth Style Selection
Economies of cutting can be achived by chosing the tooth
style or shape correctyle suiled to the being cut.Saving can
be made by selectong the best tooth style because of:Faster
sawing,more accurale sawing,longer blade life abd less
breakage of teeth,
The following four (4) tooth styles are avaible.
Standart Tooth (N)
0° rake angle,fully rounded gulet,general purpose
Skip Tooth (L)
0° rake angle,low tooth height,flat gulet-to be used for bitle
materials of larger diameters,i.e.
bronce,brass,zinc,aluminium gales & risers,plastics.
Hook Tooth (KL)
10° positive rake angle with wide spacing between
tips,deep gulles-suitable for NF-metals,low carbon
steeli,large diameters.
Combi Tooth and Positive
The tooth pitch varies thougth the blade,regular,tooth
patlern broken up the reduce noise,less vibration and
chatler,longer balde lifesuitable for a wide range of cutting,
İ.e. structurals,pipe,tubing and micellaneous steels.
Tooth Set Selection
The purpase of ‘sel’ in a bandsaw blade is to provide
clearance and to allow the body of the blade to pass freely
though the materiall being cut.The sel depends on stock
diameter,shape and material to be cut.
Regular or Raker-Set
Is the most widly used setting.If consits of a repetitiv
patlern with one tooth set the right,the next to the left and
the third(the raker)wilhout set.This type of set is best
where the material being cut is uniform size;also used in
contour sawing.
Right-Left Set
For sofler materials, i.e. NF-metals,plastic&wood.
Group Set
For vibration free sawing of smaller diameters such as pipe
tubing and shapes-faster cutting speeds and smoother
sufaces.
Wavy Set
Spaceial set for cutting thin stock or variely of shapes and
thicknesses without changing the blade.
Combi Tooth Set
With 0° rake angle.Consisles pf teeth set allernately right
and left regular intervals with a raker tooth-excellen for
cuttin a variely of shapes and pipes 15mm wall thivkness
and upwards.

15

VICE UPPER GROUP
No.
HU 270DGH
PART NAME
1
272,01,01
VICE QUICK CLAMPING SHAFT
2
272,01,02
QUICK CLAMPING BLOCK
3
272,01,03
QUICK CLAMPING WASHER
4
272,01,04
QUICK CLAMPING PIN
5
272,01,05
QUICK CLAMPING FLAT
6
272,01,06
ANGLE PIN
7
272,01,07
ANGLE PIN 2
8
272,01,08
ANGLE FIXING BODY
9
272,01,09
ANGLE LEAN STOP SPRING
10
272,01,10
ANGLE NUT
11
272,01,11
BODY CONNECTION SHAFT
12
272,01,12
METAL RING
13
272,01,13
BEARING 32008
14
272,01,14
WASHER
15
272,01,15
BEARING 32008
16
272,01,16
METAL RING
17
272,01,17
WASHER
18
272,01,18
NUT M40x1,5
19
272,01,19
CONNECTION ARM
20
272,01,20
SPRING SHAFT
21
272,01,21
SPRING BLOCK
22
272,01,22
SPRING FLAT
23
272,01,23
CONNECTION SHAFT
24
272,01,24
SPRING
25
272,01,25
HANDLE
26
272,01,26
SCALE LEAN STOP SHAFT
27
272,01,27
SCALE LEAN STOP CASTING
28
272,01,28
LEG
29
272,01,29
LOWER MOVING VICE
30
272,01,30
SET SQUARE
31
272,01,31
LOWER FLANGE
32
272,01,32
SWIVEL ARM
33
272,01,33
UPPER FLANGE
34
272,01,34
FIXING JAW(REAR)
35
272,01,35
FIXING JAW(FRONT)
36
272,01,36
ANGLE ADJUST NUT
37
272,01,37
M10x30 INBUS
38
272,01,38
M10x70 INBUS
39
272,01,39
ANGLE ADJUST PLIER
4040
272,01,40
PLIER SHAFT

2
TENSIONING GROUP
No.
HU 270DGH
PART NAME
1
272,02,01
HANDLE
2
272,02,02
BEARING 51103
3
272,02,03
ORING Ø42,86x3,53
4
272,02,04
INNER BLOCK
5
272,02,05
ORING Ø34,59X2,62
6
272,02,06
OUTER BLOCK
7
272,02,07
WASHER
8
272,02,08
WASHER Ø16x34x2 10 PIECES
9
272,02,09
SHAFT
10
272,02,10
BUSHING
11
272,02,11
SWITCH PLATE
12
272,02,12
M12 INBUS
13
272,02,13
M10 INBUS
14
272,02,14
UPPER FLAT
15
270,02,15
SHAFT
16
270,02,16
KEY
17
270,02,17
BEARING SHEET IRON-FRONT
18
270,02,18
BEARING 32007
19
270,02,19
METAL RING
20
270,02,20
FRONT WHEEL
21
270,02,21
BEARING
22
270,02,22
BEARING SHEET IRON - REAR
23
270,02,23
WASHER
24
270,02,24
M35x1,5 NUT

3
LIFTING PISTON GROUP
No.
HU 270DGH
PART NAME
1
272,03,01
PISTON HOLDER
2
272,03,02
M8 INBUS
3
272,03,03
M12 NUT
4
272,03,04
M12 INBUS
5
272,03,05
PISTON SHAFT
6
272,03,06
PISTON RING
472/50
7
272,03,07
ORING 24,99x2,62
8
272,03,08
ORING 42,86x3,5
9
272,03,09
SHAFT HOLDER (UPPER)
10
272,03,10
BAND
11
272,03,11
PISTON RING 472/50
12
272,03,12
METAL RING
13
272,03,13
ORING 42,86x3,5
14
272,03,14
SHAFT’S END
15
272,03,15
ORİNG 42,86x3,5
16
272,03,16
M6 INBUS
17
272,03,17
PISTON PIPE
18
272,03,18
PIPE UNION 1/8"
19
272,03,19
PISTON RING 472/50
20
272,03,20
ORING 42,86x3,5
21
272,03,21
PIPE UNION 1/8"
22
272,03,22
RETAINING RING
23
272,03,23
PISTON RING 472/50
24
272,03,24
SPISTON RING 471/20
25
272,03,25
LOWER SHAFT
26
272,03,26
SEGMAN 471/20
27
272,03,27
LOWER PLATE
28
272,03,28
M8 INBUS

4
REDUCTOR GROUP
No.
HU 270DGH
PART NAME
1
272,04,01
Nut M30x1,5
2
272,04,02
Washer
3
272,04,03
Washer
4
272,04,04
Rear Wheel
5
272,04,05
M10 INBUS
6
272,04,06
COVER
7
272,04,07
M10 INBUS
8
272,04,08
DUST SEAL 40x55x8
9
272,04,09
BEARING 6208
10
272,04,10
REDUCTOR SHAFT
11
272,04,11
KEY
12
272,04,12
WASHER
13
272,04,13
NUT M25x1,5

5
CARBIDE GUIDE GROUP
No.
HU 270DGH
PART NAME
1
272,05,01
M8 INBUS
2
272,05,02
FIXING FLAT
3
272,05,03
CARBIDE PLATE
4
272,05,04
M8 INBUS
5
272,05,05
M10 SETSKUR
6
272,05,06
BEARING 608
7
272,05,07
CARBIDE
8
272,05,08
CARBIDE BUSHING
9
272,05,09
M4 BOLT
10
272,05,10
STRAIGHT SHAFT
11
270,05,10a
ECCENTRIC SHAFT
12
270,05,11
BEARING 608
13
270,05,12
SEGMAN
