Product Instruction Manual
Jetstream Curve
JETC18W, JETC18S, JETC18BSS
1.8kW automatic hand dryer
Vers on 3.2 Jan 2015
V15.10/2

2
Thank you for purchas ng a Hyco Jetstream Curve h gh speed automat c hand
dryer. Recent research and developments n hand dryer technology have g ven
greater emphasis on air flow, minimising hand drying times and lowering
energy consumption. he Jetstream Curve hand dryer features a modern
stylish design and offers ultra fast hand drying performance.
Before installing this product, please take time to study and understand
these instructions.
Do not proceed with assembly or operation if there is sign of any damage
to the product. If you have any queries regarding operation or installation
please contact our technical department on 01924 225200.
1. Im ortant safety oints
•he Electrical installation must be carried out by a qualified electrician in accordance
with the current edition of the I.E.E. Wiring Regulations
•his appliance must be earthed
•Means for electrical disconnection must be incorporated in the fixed wiring in
accordance with the wiring rules
•Only connect the hand dryer to a single phase supply with a mains voltage as
specified on the rating plate
•he hand dryer must be fixed out of reach of a person taking a bath or shower
•his appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall not be made by children
without supervision
•Do not cover the air inlet or outlet
•Ensure nothing is located within a minimum of 40cm below the air outlet.

3
2. Installation
Wall Mounting
•Ensure that the surface selected for mounting the hand dryer is suitable for the
weight of the product.
•Ensure nothing is within a minimum of 40cm below the air outlet.
•Do not locate above any shiny or reflective surface.
1. Remove the two screws, located at the bottom of the unit, with the Allen key
provided. Gently slide the cover down to release the lugs, located at the top
of the unit.
2. Mark and drill four 7mm holes to a depth
of 40mm, following the diagram to the
right, insert the wall plugs provided.
3. Position the hand dryer back plate over
the four holes and feed the electrical
wiring through the hole in the back plate,
located above the terminal block. Place
the four screws into the holes and drive
them in firmly, ensuring the unit is fixed
to the wall with no movement.
LN
240
235 125
230
250
1300mm
L
L
N
N
LN
240
235 125
230
250
1300mm
L
L
N
N

Electrical
1. Make the electrical connection as illustrated in the diagram below.
2. Refit the front cover, ensuring the lugs in the back plate engage with the slots in the
cover. Replace the 2 retaining screws at the bottom of the unit.
4
LN
240
235 125
230
250
1300mm
L
L
N
N

5
3. O eration
•Shake off excess water from wet hand hands.
•Hold wet hands d rectly below the a r outlet; th s w ll start the un t automat cally.
•Remove wet hands when dry; th s w ll automat cally stop the un t.
The hand dryer will automatically stop after 60 seconds of continuous
usage, to restart, remove and replace hands.
Do not fully cover the outlet.
4. Maintenance
Always isolate the hand dryer from the power supply before
commencing any maintenance.
Never use abrasive chemicals or materials to clean the hand dryer.
•Clean the exterior of the hand dryer using a soft damp cloth.
•Ensure the outlet is kept free from debris and any other potential blockages.
•In the unlikely event of a hand dryer malfunction, discontinue use and isolate
the power. Contact the technical helpline on 01924 225200.
•If the power cord shows signs of damage discontinue usage and arrange for a
professional electrician to inspect/replace it.

5. S ecifications
Voltage 230V~50Hz
Power 1.8kW
Air speed 80m/s
Sound level 78dB
IP Rating IPX1
Weight 5.4kg
6

6. Guarantee and service olicy
his product is guaranteed against faulty materials and manufacture for a period of one
year from the date of purchase. Hyco will in its sole discretion replace, repair or refund
any faulty unit. Incorrect installation and failure to follow correct operating instructions
are excluded. Consequential costs such as labour charges or damage to surroundings
are expressly excluded.
7

hyco.co.uk
Hyco Manufacturing Ltd
Normandy Court
Express Way
Castleford, WF10 5NR
01924 225 200
F 01924 225 210
E [e-mail]
INFORMA ION FOR CORREC DISPOSAL OF HE PRODUC IN ACCORDANCE WI H HE
EUROPEAN DIREC IVE 2002/96/E.
At the end of its working life this equipment must not be disposed of as household
waste. It must be taken to a local authority waste collection centre or to a dealer
providing this service. Disposing of electrical and electronic equipment separately
enables its components to be recovered and recycled to obtain significant savings in
energy and resources. In order to underline the duty to dispose of this equipment
separately, the product is marked with a crossed out dustbin.
