roduct Instruction Manual
PRISM
PRMW, PRMBSS
0.9kW Automatic Hand Dryer
Version 3.2 Jan 2015
V17.11/1

2
Thank you for purchasing a Hyco rism hand dryer. lease ensure you read and
understand these instructions to ensure safe installation and operation. The rism is
a high speed, automatic hand dryer that is suitable for a variety of public washroom
applications. The stylish, compact design and durable stainless steel case makes this a
versatile and durable option that will compliment any environment. High performance
quality saves energy from reduced drying times and increases washroom throughput.
Key features
• 900W
• Energy efficient
• Fast dry time
• Stable and durable stainless steel cover
• White/ brushed stainless steel finish available
1. Important safety po nts
If the supply cord is damaged it must be replaced by the manufacturer, its service
agent or similarly qualified person in order to avoid electrocution hazard.
Do not proceed with installation if there is any sign of damage to the product.
The product should only be connected to a supply that meets the specifications
detailed on the rating label.
Electrical installation must be carried out by a qualified electrician in accordance
with the latest edition of the IEE wiring regulations.
The appliance is not intended for use by persons (including young children)
with reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning the safe use of the appliance by a person responsible for their safety.
Children should be supervised to ensure they do not play with the appliance.
The appliance must be earthed.
The appliance is intended for drying hands only; it should not be used for
any other purpose.

3
2. Installat on
To avoid malfunction do not install the appliance in the following environments:
Temperatures below -10 C or above 40 C.
laces directly sprinkled by water.
laces in direct sunlight or strong light.
Within 40cm of any surface beneath the air outlet.
• When selecting a suitable location and surface for installation of the dryer, consider
the following:
• Water droplets will be blown from the hands and may land on surrounding
surfaces.
• Access for doors and people.
• Height of dryer positioning based on likely users
User Recommended mounting height
(bottom edge of the dryer above finished floor)
Men 46”
Women 44”
Children 11-17yrs 42”
Children 3-10yrs 36”
• Using the template provided or dimensions supplied and ensuring a horizontal level,
mark out the four holes at each corner for mounting the dryer onto the desired
surface. If required, the junction box should also be planned and provided for
at this stage.
• Drill the 4 holes in each corner as shown and insert the wall plugs.
Always ensure no concealed electrical wiring or pipework prior to drilling
into the surface.

4
• Remove the dryer cover via the 2 x counter sunk screws, located at opposite sides
of the cover (Allen key tool provided).
• Before mounting the dryer to the surface, make provisions for the wiring.
• For concealed wiring via a junction box, it is necessary to knock out the provided
circle in the back plate. Ensure not to leave rough or sharp edges as this could
cause damage to the supply cable.
• Offer the dryer to the four holes, insert the screws and tighten fully.

5
3. Electr cal connect on
Always isolate the power supply before any electrical work or wiring of
the dryer.
• Connection should be made to the fixed wiring of the property via a double
pole switched fused spur.
• Electrical connections should be made as follows:
Green/Yellow earth wire to the terminal marked “ E” or
Brown/Red live wire to the terminal marked “L”
Blue/Black neutral wire to the terminal marked “N”
• Ensure the supply cord is well secured to the dryer using the provided cable clamp.
• Refit the dryer cover using the 2 x counter sink bolts.
• Turn on the power supply to complete installation.
Recommended mounting height
(bottom edge of dryer above nished oor)
M 43”
L 41”
C 39”
C 33”
1

6
4. Operat on
• Shake of excess water from washed hands.
• lace hands under the dryer outlet to initiate air flow.
• Slowly move hands under the air flow.
• Turn over hands and repeat.
• Rub hands together until sufficiently dry.
• Remove hands and airflow will stop.
5. Ma ntenance
• Isolate the appliance from the power supply via the fused spur or similar device.
• Remove any dust or debris form the inlet holes.
• Wipe the exterior with a soft damp cloth.
• Do no use abrasive chemicals on the dryer, damage to the finish may result.
• The filter should be removed and rinsed with clean water at regular intervals.

7
6. Spec f cat ons
PRMW PRMBSS
Voltage 230 ~ 230 ~
Power 0.9kW 0.9kW
Ingress rat ng IP22 IP22
F n sh 73db Wh te Brushed sta nless steel
We ght 3.4kg 3.4kg
169mm
250mm
300mm

hyco.co.uk
Hyco Manufacturing Ltd
Normandy Court
Express Way
Castleford, WF10 5NR
T 01924 225 200
F 01924 225 210
E [email protected]
INFORMATION FOR CORRECT DIS OSAL OF THE RODUCT IN ACCORDANCE WITH THE
EURO EAN DIRECTIVE 2002/96/E.
At the end of its working life this equipment must not be disposed of as household
waste. It must be taken to a local authority waste collection centre or to a dealer
providing this service. Disposing of electrical and electronic equipment separately
enables its components to be recovered and recycled to obtain significant savings in
energy and resources. In order to underline the duty to dispose of this equipment
separately, the product is marked with a crossed out dustbin.
7. Guarantee and serv ce pol cy
This product is covered by a standard parts or replacement warranty for a period of three
years from the date of purchase.
If there is a manufacturing defect within the warranty period we will send spare
parts, repair and return the unit or, at our discretion, supply a replacement product.
Incorrect installation and failure to follow correct operating instructions are excluded.
Consequential costs such as labour charges or damage to surroundings are expressly
excluded.
Contact us
If you experience a problem with this product you should first contact our service
department on 01924 225 200 before taking any further action. Experience has shown
that issues can often be resolved without the need to return or uninstall the product.
