HYDRA-PULL HP 880 Guide

Pik Rite, Inc. Phone: [phone] HP 880
60 Pik Rite Lane Fax: [phone]
Lewisburg, PA 17837 www.pikrite.com Manure Spreader
Operation and Parts Manual
November 16, 2017

(SPECIFICATIONS AND DESIGN SUBJECT TO CHANGE WITHOUT NOTICE)
2

(SPECIFICATIONS AND DESIGN SUBJECT TO CHANGE WITHOUT NOTICE)
3
Some illustrations may not represent the spreader
model you have; however, the principles of operation
and maintenance are the same. If you have questions
specific to your spreader please contact your dealer.

Pik Rite, Inc. Phone: [phone] HP 880
60 Pik Rite Lane Fax: [phone]
Lewisburg, PA 17837 www.pikrite.com Manure Spreader
Table of Contents
OPERATOR’S MANUAL ....................................................................6
SAFETY................................................................................................................................................................................. 8
PREPARING THE TRACTOR ................................................................................................................................................ 13
PREPARING THE SPREADER............................................................................................................................................... 16
CONTROLS......................................................................................................................................................................... 18
ATTACHING THE SPREADER .............................................................................................................................................. 19
DETACHING THE SPREADER .............................................................................................................................................. 20
TRANSPORT....................................................................................................................................................................... 21
OPERATING THE SPREADER .............................................................................................................................................. 24
LUBRICATION & MAINTENANCE ....................................................................................................................................... 27
SPECIFICATIONS ................................................................................................................................................................ 32
PARTS MANUAL..............................................................................34
7415-1-01 Main Frame & Hitch ................................................................................................................................. 36
7415-1-02 Stone Guard ............................................................................................................................................. 40
7415-1-03 Front Shields............................................................................................................................................. 41
7415-1-05 Endgate .................................................................................................................................................... 42
7415-1-07 Axle & Walking Beam, Weigh Scale Compatible...................................................................................... 43
7415-1-07A Opt. –Weight Scale Assy, 5 pt, GT400 .................................................................................................... 44
7415-1-07B Opt. –Weight Scale Assy, 5 pt, NT460 .................................................................................................... 45
7415-1-07C Opt. –Weight Scale Assy, 5 pt, 8000i...................................................................................................... 46
7415-1-08 Wheels & Tires ......................................................................................................................................... 47
7415-1-09 Opt. –Metering Shield ............................................................................................................................. 48
7415-2-01 Driveline, 1000 rpm.................................................................................................................................. 49
7415-2-02 Main Drive Shaft....................................................................................................................................... 50
7415-2-03 Vertical Beaters, Quick Disconnect .......................................................................................................... 52
7415-2-03A Vertical Beater Gearbox ........................................................................................................................... 54
7415-2-03B Compost Beaters: Hydraulic Hood........................................................................................................... 55
7415-2-03B Compost Beaters: Hydraulic Hood........................................................................................................ 56
7415-2-03C Compost Beaters: Hydraulic Hood W/ Trim Shield............................................................................... 57

Pik Rite, Inc. Phone: [phone] HP 880
60 Pik Rite Lane Fax: [phone]
Lewisburg, PA 17837 www.pikrite.com Manure Spreader
7415-2-03C Compost Beaters: Hydraulic Hood W/ Trim Shield............................................................................... 58
7415-2-03D Compost Beaters: Hydraulic Hood W/ Turnbuckle............................................................................... 59
7415-2-03D Compost Beaters: Hydraulic Hood W/ Turnbuckle............................................................................... 60
7415-2-04 Web Chain Drive....................................................................................................................................... 61
7415-2-05 Web Chain Gearbox ................................................................................................................................. 62
7415-3-01 Hydraulics, Web Drive.............................................................................................................................. 63
7415-3-02 Hydraulics, Endgate................................................................................................................................. 64
7415-3-03 Endgate Cylinders.................................................................................................................................... 65
7415-3-04 Hydraulic Hoods W/ Trim Shield ............................................................................................................. 66
7415-3-05 Hydraulic Hoods W/O Trim Shield.......................................................................................................... 67
7415-4-01 Air Brakes ................................................................................................................................................ 68
7415-4-02 Hydraulic Brake Assembly........................................................................................................................ 70
7415-4-03 Opt. –Tractor Brake Control.................................................................................................................... 71
7415-5-01 Electrical & Lighting.................................................................................................................................. 72
7415-6-01 Safety Tow Chain...................................................................................................................................... 73
7415-6-02 Jack Stand................................................................................................................................................. 74
7415-6-03 SMV Emblem & Bracket ........................................................................................................................... 75
7415-6-04 Decals, Front............................................................................................................................................. 76
7415-6-05 Decals, Sides & Rear................................................................................................................................. 77
7415-6-06 OPTIONAL SIDE EXTENSION, BOLT-ON..................................................................................................... 78
W/O BOARD ...................................................................................................................................................................... 78
WARRANTY.....................................................................................81

Pik Rite, Inc. Phone: [phone] HP 880
60 Pik Rite Lane Fax: [phone]
Lewisburg, PA 17837 www.pikrite.com Manure Spreader
OPERATOR’S MANUAL

7
Operation Manual

SAFETY
8
Operation Manual
SAFETY
RECOGNIZE SAFETY INFORMATION
This is the safety-alert symbol. When you see this symbol on your
machine or in this manual be alert to the potential of personal injury.
Follow recommended precautions and safe operating
practices
UNDERSTAND SIGNAL WORDS
A signal word –DANGER, WARNING, or CAUTION-is used with the
safety-alert symbol. DANGER identifies the most serious hazards.
DANGER or WARNING safety signs are located near specific hazards.
General precautions are listed on CAUTION safety signs. CAUTION
also calls attention to safety messages in this manual.
FOLLOW SAFETY INSTRUCTIONS
Carefully read all safety messages in this manual and on your machine
safety signs. Keep safety signs in good condition. Replace missing or
damaged safety signs. Be sure new equipment components and repair
parts include the current safety signs. Replacement safety signs are
available from your Pik Rite dealer.
Learn how to operate the machine and how to use controls properly. Do
not let anyone operate without instruction.
Keep your machine in proper working condition. Unauthorized
modifications to the machine may impair the function and/or safety and
affect machine life.
If you do not understand any part of this manual and need assistance,
contact your Pik Rite dealer.

SAFETY
9
Operation Manual
KEEP SHIELDS IN PLACE
Do not operate spreader without safety shields in place.
Rotating parts can crush or dismember causing death or personal injury.
Disconnect PTO driveline and hydraulic lines from tractor before
removing shields for adjustment or service.
PROTECT BYSTANDERS
Never operate the spreader near people.
Do not place rocks, timbers or other solid objects in the spreader.
Objects can be thrown great distances causing injury to people.
WEAR PROTECTIVE CLOTHING
Wear close fitting clothing and safety equipment
appropriate to the job.
Prolonged exposure to loud noise can cause impairment or loss of
hearing.
Wear a suitable hearing protective device such as earmuffs or earplugs
to protect against objectionable or uncomfortable loud noises.
Operating equipment safely requires the full attention of the operator. Do
not wear radio or music headphones while operating machine.
USE SAFETY LIGHTS AND DEVICES
Slow moving tractors, self-propelled equipment and towed implements
or attachments can create a hazard when driven on public roads. They
are difficult to see, especially at night. Avoid personal injury or death
resulting from collision with a vehicle.
Flashing warning lights and turn signals are recommended whenever
driving on public roads. To increase visibility, use the devices provided
with your machine. For some equipment, install extra flashing warning
lights.
Keep safety items in good condition. Replace missing or damaged
items.

SAFETY
10
Operation Manual
KEEP RIDERS OFF MACHINE
Riders are subject to injury such as being struck by foreign objects and
being thrown off the machine. Riders also obstruct the operator’s view
resulting in the machine being operated in an unsafe manner
PARK SPREADER SAFELY
Park spreader on a level surface and block wheels.
Close endgate.
Secure jackstand with pin.
PREPARE FOR EMERGENCIES
Be prepared if a fire starts.
Keep a first aid kit and fire extinguisher handy.
Keep emergency numbers for doctors, ambulance service, hospital, and
fire department near your telephone.
USE A SAFETY CHAIN
A safety chain will help control drawn equipment should it accidentally
separate from the drawbar.
Using the appropriate adapter parts, attach the chain to the tractor
drawbar support or other specified anchor location. Provide only enough
slack in the chain to permit turning.
See your Pik Rite dealer for a chain with a strength rating equal to or
greater than the gross weight of the towed machine. Do not use safety
chain for towing.
