This manual should be considered a permanent part of the motorcycle and
should remain with the motorcycle when resold or otherwise transferred to
a new owner or operator. The manual contains important safety
information and instructions which should be read carefully before
operating the motorcycle.
*GT250R/S영문내지 2005.12.7 12:28 PM 페이지1 001 PagePro 9100 300DPI 100LPI

2
&
&
*GT250R/S영문내지 2005.12.7 12:28 PM 페이지2 001 PagePro 9100 300DPI 100LPI

3
All information, illustrations photographs
and specifications contained in this manual
are based on the latest product information
available at the time of publication. Due to
improvements or other changes, there may
be some discrepancies in this manual.
Hyosung reserves the right to make
changes at any time.
lease note that this manual applies to all
specifications for all respective destinations
and explains all equipments. Therefore,
your model may have different standard
features than shown in this manual.
HYOSUNG MOTORS & MACHINERY INC.
CO YRIGHT HYOSUNG MOTORS & MACHINERY INC.
FOREWORD
THANK YOU for choosing Hyosung
motorcycle. We at Hyosung have
designed, tested and produced this
motorcycle using the most modern
technology available to provide you with
much happy, enjoyable, safe riding.
Motorcycling is one of the most exhilarating
sports and insure your riding enjoyment,
you should become thoroughly familiar with
the information presented in this Owner's
Manual before riding the motorcycle.
The proper care and maintenance that
your motorcycle requires are outlined in this
manual.
By following these instructions explicitly
you will insure a long trouble-free operating
life for your motorcycle. Your Hyosung
dealer has experienced technicians that are
trained to provide your machine with the
best possible service with the right tools and
equipment.
*GT250R/S영문내지 2005.12.7 12:29 PM 페이지3 001 PagePro 9100 300DPI 100LPI

4
I PORTANT
BREAK-IN INFOR ATION FOR
YOUR OTORCYCLE
The first 1,600km (1,000miles) are the
most important in the life of your motorcycle.
roper break-in operation during this time
will help ensure maximum life and
performance from your new motorcycle.
Hyosung parts are manufactured of high
quality materials, and manufactured parts
are finished to close tolerances. roper
break-in operation allows the machined
surfaces to polish each other and mate
smoothly.
Motorcycle reliability and performance
depend on special care and restraint
exercise during the break-in period. It is
especially important that you avoid
operating the engine in a manner which
could expose the engine parts to excessive
heat.
lease refer to the BREAK-IN section for
specific break-in recommendations.
WARNING / CAUTION / NOTE
lease read this manual and follow its
instructions carefully. To emphasize special
information the words WARNING,
CAUTION and NOTE 
N O T E
This provides special information to
make maintenance easier or important
instructions clearer.
These instructions point out special
service procedures or precautions that
must be followed to avoid damaging the
machine.
CAUTION
The personal safety of the rider may be
involved. Disregarding this information
could result in injury to the rider.
WARNING
*GT250R/S영문내지 2005.12.7 12:29 PM 페이지4 001 PagePro 9100 300DPI 100LPI

5
Noise Control System (muffler assembly)
TA PERING WITH NOISE CONTROL SYSTE PROHIBITED
Owners are warned that the law may prohibit :
(a) The removal or rendering inoperative by any person other than for the
purpose of maintenance, repair or replacement, of any device or
element of design incorporated into any new vehicle for the purpose of
noise control prior to its any sale or delivery to the ultimate purchaser or
while it is in use ; and
(b) The use of the vehicle after such device or element of design has been
removed or rendered inoperative by any person.
AINTENANCE :
The exhaust system of this motorcycle requires no periodic maintenance.
The engine should be adjusted to the manufacture s specifications and the
spark plug should be kept in good condition. Running the engine with
incorrectly operating spark plug or misadjusted carburetor may cause
permanent damage to the catalyst and to the noise control system.
WARNING
*GT250R/S영문내지 2005.12.7 12:29 PM 페이지5 001 PagePro 9100 300DPI 100LPI

6
Motorcycle riding is great fun and an
exciting sport. Motorcycle riding also
requires that some extra precautions be
taken to ensure the safety of the rider and
passenger. These precautions are :
Before first use of the
& read this owner

s manual carefully to become familiar
with the &
 s features, and safety
and maintenance requirements.
Review all instructions, requirements
and warnings with the riders. Keep
the owner
 s manual in the owner  s
manual storage compartment located
under the seat.
Before the rider
 s first use of the
& ,
make sure that he/she is familiar with
the location and operation of all
controls, and has been instructed in
the proper operation of the
motorcycle.
For first use of the
& , find a level, open
area for the rider to use to become
familiar with the operation of controls
and the operating and handling
characteristics of the
& .
WARNING
Before each use, perform daily
inspections with the rider. Specific
items to check are listed in the
INSPECTION BEFORE RIDING
section on page 48 of this owner
 s
manual.
ake sure the rider wears a helmet,
eye protection, and protective
clothing (gloves, leather or heavy
cloth pants, long sleeved shirt or
jacket, boots).
Permit use only by two rider. This
motorcycle is designed for use only
by two rider.
Do not permit anyone to operate the
&
under the influence of alcohol or
other drugs caused by damage to the
motorcycle or altered handling
characteristics.
Observe periodic maintenance
requirements your authorized
HYOSUNG dealer is trained and
equipped to perform this service.
Drain gasoline from the fuel tank and
carburetor prior to transporting the
& .
Caution the rider and others near the
&
not to get close to or touch any
moving parts or any heated areas
such as the engine and exhaust
system.

Do not make any modifications to the
& .
odifications may make the
motorcycle unsafe or illegal in your
state.
WARNING
CONSU ER INFOR ATION
SAFE RIDING RECO ENDATION
FOR OTORCYCLE RIDERS
*GT250R/S영문내지 2005.12.7 12:29 PM 페이지6 001 PagePro 9100 300DPI 100LPI

7
The &
is equipped with the side stand ignition
interlock system.
1. If the transmission is in neutral, you
can start the engine regardless of
clutch lever and side stand.
2. If the transmission is not in neutral, you
can only start the engine with pulling in
clutch lever and side stand up.
ake sure that the side stand igintion
interlock system is working properly
before riding.
WARNING
Do not run the engine indoors or
where there is little or no ventilation.
Exhaust gases contain carbon
monoxide, a potentially lethal gas that
is colorless and odorless.
Never leave the motorcycle running
while unattended, even for a short
time.
WARNING
&
always come on the position lamp,
meter lamp, tail lamp and license plate
lamp when starting engine.
CAUTION
While operating the
& , the rider should
keep both feet on the footrests at all
times, or injuries resulting from
accidents. oving the rider
 s feet from
the footrests reduces the rider
 s ability
to control the motorcycle, and could
lead to an accident.
WARNING
Keep both hands on the handgrips at all
times when riding. Removing your
hands from the handgrips reduces your
ability to control the motorcycle, and
could result in an accident.
WARNING
Always open the throttle gradually to
prevent front wheel lifting. Failure to
observe this precaution may result in
loss of control and an accident.
WARNING
&
are started as the battery ignition
system.
Do not permit to start or operate the
throttle grip after started without the
battery caused by damage to the
electrical system.
Always start or ride these motorcycles
with the battery.
WARNING
*GT250R/S영문내지 2005.12.7 12:29 PM 페이지7 001 PagePro 9100 300DPI 100LPI

8
WEAR A HEL ET
RIDING APPAREL
INSPECTION BEFORE RIDING
otorcycle safety equipment starts with
a quality safety helmet. One of the most
serious injuries that can happen is a
head injury. ALWAYS wear a properly
approved helmet. You should also wear
a suitable eye protection.
WARNING
Do not operate for the ignition switch is
in the “OFF” or “LOCK” position or the
engine stop switch is in the “ ”
position while driving at one
 s pleasure.
WARNING
Loose fancy clothing can be
uncomfortable and unsafe in terms of
riding your motorcycle.
Choose good quality motorcycle riding
apparel in terms of riding your
motorcycle.
WARNING
Review thoroughly the instructions in
the “INSPECTION BEFORE RIDING”
section of this manual. Do not forget to
perform an entire safety inspection to
ensure the safety of the rider and its
passenger.
WARNING
The trunk could be heated. Don
 t
keep anything that doesn
 t endure
heat.
Don
 t keep the fragile.
Check if it is locked.
The unlocking of rear seat could
cause serious accident.
Don
 t allow water to get inside the
trunk or it could damage.
Don
 t keep the valuables in the trunk
when leaving unattended.
Loading limit of trunk : 1(2.21lbs)
CAUTION
WHEN KEEPING FOR LONG PERIOD :
1. Supply enough the fuel in the fuel
tank.
2. Do drain wholly the fuel in the
carburetor.
3. Remove the battery from the
motorcycle.
CAUTION
*GT250R/S영문내지 2005.12.7 12:29 PM 페이지8 001 PagePro 9100 300DPI 100LPI

9
FA ILIARIZE YOURSELF WITH
THE OTORCYCLE
KNOW YOUR LI ITS
BE EXTRA SAFETY CONSCIOUS
ON BAD WEATHER DAYS
Your riding skill and mechanical
knowledge form the foundation for safe
riding practices.
We suggest that you practice riding
your motorcycle in a non-traffic situation
until you are thoroughly familiar with
your machine and its controls.
Remember practice makes perfect.
WARNING
Ride within the boundaries of your own
skill at all times. Knowing these limits
and staying within them will help you to
avoid accidents.
WARNING
Riding on bad weather days, especially
wet ones, requires extra caution.
Braking distances double on a rainy
day. Stay off of the painted surface
marks, manhole covers and greasy
appearing areas as they can be
especially slippery.
Use extreme caution at railway
crossings and on metal gratings and
bridges. Whenever you have a doubt
about road condition, slow down!
WARNING
*GT250R/S영문내지 2005.12.7 12:29 PM 페이지9 001 PagePro 9100 300DPI 100LPI

10
There are a great variety of accessories
available to Hyosung owners. Hyosung
can not have direct control over the quality
or suitability of accessories you may wish to
purchase except genuine parts.
The addition of unsuitable accessories
can lead to unsafe operating conditions. It
is not possible for Hyosung to test each
accessory on the market or combinations
of all available accessories, however, your
dealer can assist you in selecting quality
accessories and installing them correctly.
Use extreme caution when selecting and
installing the accessories for your
Hyosung. We have developed some
general guidelines which will aid you when
deciding whether, and how to equip your
motorcycle.
1. In case that additional weight or
aerodynamic affecting accessories are
installed, they should be mounted as
low as possible, as close to the
motorcycle and as near the center of
gravity as is feasible. The mounting
brackets and other attachment
hardware should be carefully checked
to ensure that it provides for a rigid,
nonmovable mount. Weak mounts can
allow the shifting of the weight and
create a dangerous, unstable condition.
2. Inspect for proper ground clearance
and bank angle. An improperly
mounted load could critically reduce
these two safety factors. Also
determine that the “load” does not
interfere with the operation of the
suspension steering or other control
operations.
3. Accessories fitted to the handlebars or
the front fork area can create serious
stability problems. This extra weight will
cause the motorcycle to be less
responsive to your steering control.
The weight may also cause oscillations
in the front end and lead to instability
problems. Accessories added to the
machine should be as light as possible
and kept to a minimum.
4. The motorcycle may be affected by a
lifting condition or by an instability in
cross winds or when being passed or
passing large vehicles. Improperly
mounted or poorly designed
accessories can result in an unsafe
riding condition, therefore caution
should be used when selecting and
installing all accessories.
5. Certain accessories displace the rider
from his or her normal riding position.
This limits the freedom of movement of
the rider and may limit his or her control
ability.
6. Additional electrical accessories may
damage the existing electrical system.
Severe overloads may damage the
wiring harness or create a dangerous
situation due to the loss of electrical
power during the operation of the
motorcycle.
When carrying a load on the motorcycle,
mount it as low as possible and as close as
possible to the machine. An improperly
mounted load can create a high center of
gravity which is very dangerous and makes
the motorcycle difficult to handle. The size
of the “load” can also affect the
ACCESSORY INSTALLATION AND
PRECAUTION SAFETY TIPS
*GT250R/S영문내지 2005.12.7 12:29 PM 페이지10 001 PagePro 9100 300DPI 100LPI

11
odification of the motorcycle, or
removal of original equipment may
render the vehicle unsafe or illegal.
WARNING
aerodynamics and handling of the
motorcycle.
Balance the load between the left and
right side of the motorcycle and fasten it
securely.
*GT250R/S영문내지 2005.12.7 12:29 PM 페이지11 001 PagePro 9100 300DPI 100LPI

12
1. SERIAL NU BER LOCATION  14
2. FUEL AND OIL RECO ENDATION 15
FUEL
ENGINE OIL
3. NA ES OF EACH PARTS [ ]16
4. NA ES OF EACH PARTS [ ] 19
5. CONTROLS  22
IGNITION SWITCH
IGNITION KEY
INSTRUMENT ANEL ( )
INSTRUMENT ANEL ( )
LEFT HANDLE SWITCH
RIGHT HANDLE SWITCH
CARBURETOR CHOKE LEVER
REAR BRAKE EDAL
GEARSHIFT LEVER
FOOTRESTS
SIDE STAND
SEAT LOCK
TRUNK
REAR SHOCK ABSORBER
6. SUPPLY OF GASOLINE AND ENGINE OIL  37
GASOLINE
ENGINE OIL
7. RIDING TIPS 41
STARTING THE ENGINE
STARTING OFF
USING THE TRANSMISSION
RIDING ON HILLS
STO ING AND ARKING
TABLE OF CONTENTS
&
&
&
&
*GT250R/S영문내지 2005.12.7 12:29 PM 페이지12 001 PagePro 9100 300DPI 100LPI

13
8. BREAK-IN  46
9. INSPECTION BEFORE RIDING 48
10. PERIODIC AINTENANCE  49
11. INSPECTION AND AINTENANCE 52
TOOL
ENGINE OIL
FUEL HOSE
GASOLINE
RUBBER CA OF CABLES
EXHAUST I E AND MUFFLER
FRONT FORK
REAR SHOCK ABSORBER
BATTERY
AIR CLEANER
S ARK LUG
CARBURETOR
CLUTCH CABLE
DRIVE CHAIN
BRAKES
TIRE
RE LACEMENT OF THE LAM
WHEN THE ENGINE REFUSES TO START
WHEN KEE ING FOR LONG ERIOD
CLEANING ROCEDURE
12. LABEL 73
13. SPECIFICATIONS 76
*GT250R/S영문내지 2005.12.7 12:29 PM 페이지13 001 PagePro 9100 300DPI 100LPI

14
Frame number :
Engine number :
The frame number  is stamped on the
steering head tube.
The engine serial number
 is stamped
on the left upside of the crankcase
assembly.
lease write down the numbers in the box
provided below for your future reference.
The frame and/or engine serial numbers
are used to register the motorcycle. They
are also to assist your dealer in terms of
ordering parts or referring to special service
information.
SERIAL NU BER LOCATION


*GT250R/S영문내지 2005.12.7 12:29 PM 페이지14 001 PagePro 9100 300DPI 100LPI

15
ENGINE OIL
Classification
system
A I
SAE
Grade
Over SL
10W/40
Remarks
ENGINE OIL SPECIFICATION
ENGINE OIL
Temperature


-30
-22
-20
-4
-10
14
0
32
10
50
20
68
30
86
40
104
20W50
15W40 15W50
10W40 10W50
10W30
Using a premium quality four stroke motor
oil will increase the service life of your
motorcycle.
If a SAE 10W/40 motor oil is not
available, select alternative according to
the following chart.
Don
t mix the unrecommended oil. It
could damage the engine.
When refilling the oil, don
t allow the
dust to get inside.
op the oil spilt.
Don
t put the patch on the filler cap.
It could disturb the oil to be provided
and damage the engine.
WARNING
F U E L
Use unleaded gasoline with an octane
rating of 91 or higher.
Unleaded gasoline can extend spark plug
life and exhaust components life.
FUEL AND OIL
RECO ENDATION
When refueling, always shut the
engine off and turn the ignition key to
the “OFF position. Never refuel near
the flames, sparks and heat sources.
Do not overfill the fuel tank. Do not fill
the fuel tank above the entrance
lower end.
WARNING
Spilling gasoline can damage the
painted surfaces.
Be careful not to spill any fuel when
filling the fuel tank.
Wipe spilled gasoline up immediately.
CAUTION
*GT250R/S영문내지 2005.12.7 12:29 PM 페이지15 001 PagePro 9100 300DPI 100LPI

16
NA ES OF EACH PARTS [ ]
Clutch lever
Left handle switches
Choke lever
Tachometer
Speedometer
Front brake fluid reservoir
Right handle switches
Front brake lever
Throttle grip
Ignition switches
Fuel tank cap
&
&
*GT250R/S영문내지 2005.12.7 12:29 PM 페이지16 001 PagePro 9100 300DPI 100LPI

17
Spark pulg (Front)
Front turn signal lamp
Head lamp
Ignition coil (Front)
Ignition coil (Rear)
Spark pulg (Rear)
Fuse
Seat lock
Rear turn signal lamp
Tail / Brake lamp
License plate lamp
assenger footrests
Footrests
Gearshift lever
Side stand
Engine oil drain plug
Throttle stop screw
N O T E
“ ” means the invisable parts.
&
*GT250R/S영문내지 2005.12.7 12:29 PM 페이지17 001 PagePro 9100 300DPI 100LPI

18
Muffler
Rear carrier
Rear seat & Trunk
Front seat
Tools
Battery
Fuel pump
Air cleaner
Front brake fluid reservoir
Front brake lamp switch
Engine oil filter
Engine oil filler cap
Engine oil level lens
Rear brake pedal
Rear brake lamp switch
Rear brake fluid reservoir
N O T E
“ ” means the invisable parts.
&
*GT250R/S영문내지 2005.12.7 12:29 PM 페이지18 001 PagePro 9100 300DPI 100LPI

19
NA ES OF EACH PARTS [ ]
Clutch lever
Left handle switches
Choke lever
Speedometer
Fuel meter
Tachometer
Front brake fluid reservoir
Right handle switches
Front brake lever
Throttle grip
Ignition switches
Fuel tank cap
&
&
*GT250R/S영문내지 2005.12.7 12:29 PM 페이지19 001 PagePro 9100 300DPI 100LPI

20
Spark pulg (Front)
Head lamp
Front turn signal lamp
Ignition coil (Front)
Throttle stop screw
Ignition coil (Rear)
Spark pulg (Rear)
Fuse
Seat lock
Rear turn signal lamp
Tail / Brake lamp
License plate lamp
assenger footrests
Footrests
Gearshift lever
Side stand
Engine oil drain plug
N O T E
“ ” means the invisable parts.
&
*GT250R/S영문내지 2005.12.7 12:29 PM 페이지20 001 PagePro 9100 300DPI 100LPI
