CONTENTS
1. SAFETYINSTRUCTIONS 3
2. YOURPRODUCT 6
3. ASSEMBLY 8
4. FILLINGFUELTANK 10
5. USE 12
6. MAINTENANCEAND STORAGE 14
7. EC DECLARATION 17

3
1. SAFETYINSTRUCTIONS
Instructions
 Read the instructions carefully. Be familiar with the controls and proper use of the
equipment.
 Never allow children to use this mower. If the mower is given to an other people, also give
this manual. Also make sure that this person uses this device only after receiving the
necessary instructions. Local laws may restrict the age of the user.
 Never mow while people, especially children, or animals are nearby.

Keep in mind that the operator or user is responsible for accidents or risks that may occur
to other persons or their properties.
Preparation
 During mowing, always wear safety shoes and long pants. Do not use the equipment
barefoot or wearing sandals open.

Carefully inspect the area where equipment is being used by removing all objects that
may be affected by the machine.
 WARNING - Gasoline is extremely flammable.
o Add fuel before starting. Do not remove the fuel tank cap while the machine is
running or when it is hot.
o If the fuel has spilled or leaked, do not attempt to start the machine but move the
machine away from the leakage area and avoid creating a source of ignition until the
gasoline vapors has dissipated.
o Refuel only outside and do not smoke during refueling.
o Store fuel in tanks specifically designated for this purpose.
o Replace the fuel tank or the defective gasoline plug securely.
 Replace defective mufflers.

Before use, always inspect visually that the blades, blade assembly and blade lock are
not worn or damaged. Replace blades and blade assemblies that are not in good
condition to maintain balance.

Thebladesmustbebalancedtoensureproperoperationandtobeabletoworksafely.
Operation
 Do not use the machine in a confined space or hazardous carbon monoxide emissions
can be collected.

Mow only under daylight or under good artificial light.
 Avoid using the equipment on greasy grass, where possible.
 Always be sure of your walking on the slopes.

Walk, never run.
 For lawn mowers, mow across slopes, never from top to bottom.
 Exercise extreme caution when changing direction on slopes.
 Stop the blades if the mower is to be tilted during transport when crossing surfaces other
than grass, and when transporting the mower due to the area to be mowed.

Do not mow on steep slopes.
 Use extreme caution when tipping or pulling the mower towards you.
 Never use the mower with defective guards, or without safety devices such as baffles and
or collection bins, which are not in place.
 Do not change the motor configuration or increase the speed.

For starting, disengage all blades, the gears must be in neutral, the traction control lever
must be released. Set foot well away from the blades.
 Before starting the engine or starting the engine, carefully read and understand all
instructions.
 Do not tilt the mower when starting the machine or turn on the engine, unless the mower
needs to be tilted for starting. In this case, do not tilt it more than absolutely necessary
and lift only the part that is furthest away from the user.

Do not start the machine by standing in front of the ejection

Do not place hands or feet near or under rotating parts. Keep clean the mouth of the
grass extractor.

4
 Never take or carry the mower while the machine is running.

Stop the machine and remove the ignition key, disconnect the spark plug from the spark
plug:
o Before cleaning or unclogging the grass extractor.
o Before checking, cleaning, and working on the mower.
o After hitting an object. Inspect the mower for damage and repair before re-using the
mower.
o If the mower begins to vibrate abnormally, stop the engine immediately and check
according to previous recommendations.
 Stop the engine immediately:
o Every time you leave the craft.
o Before refueling.

To stop the engine, reduce the throttle setting, turn off the ignition and release the
operator presence grip, close the fuel cock (depending on the equipment).

Move slowly when moving.
Maintenance and storage
 Check, check and tighten all bolts, bolts, and screws to ensure that the equipment is in
safe operating condition.
 Never keep the mower with gasoline in the tank in a building or vapors can cause a bright
flame or spark.
 Allow the machine to cool before storing it in an enclosed area.
 To reduce the risk of fire, keep the machine clean without grass, without grease, the
mufflerandtheenginecools,disconnectthebatteryifnecessaryandemptythefueltank

Check the grass catcher frequently, its condition or deterioration.
 Replace worn and damaged parts for safety.
 If the fuel tank is to be drained, it must be made outdoors.
Special safety instructions
 Always use the mower with its pick-up bag and / or deflector in the intended position.

Switch off the engine before emptying the pick-up bag or before changing the cutting
height.
 While the engine is running, never put your hands or feet under the mower or under the
grass ejection area.
 Before mowing, remove all foreign objects from the grass that can be propelled by the
machine.

Keep children and pets at a safe distance while using the mower.
 Never lift the mower when the engine starts.

Alcohol, drug, as well as illness, fever and fatigue affect your ability to respond. Do not
use power tools in such circumstances.

Never change the rated speed of the motor.
 Never lift or carry the tool while the engine is running.
 Before starting the engine, release the drawbar.

Before mowing, install the collection bag in its intended position.
 Do not use the mower in the event of rain or when the grass is wet.
 Never lift the rear of the mower when starting the engine and never place your hands or
feet under the mower deck or in the rear ejection port while the engine is running.
 Turn off the engine and remove the spark plug cap in the following cases:
o Before operating under the mower deck or near the ejection opening.
o Before any maintenance, repair or verification.
o Before transporting, lifting or storing the mower.
o If you leave the mower unattended or change the cutting height.
o To remove and empty the collection bag.
 After striking a foreign object, turn off the engine and carefully inspect the mower for
damage. Take the lawnmower to an authorized service center for repair if necessary.
 If the mower vibrates abnormally, try to understand the reason and bring your lawnmower
to an authorized repair center.

5
 Regularly check that the bolts, nuts and screws are properly tightened for safe use of the
mower.

Do not use the tool where there is a risk of lighting.

During the operation, the lawnmower emits exhaust gases; these gases are poisonous
and care makes in danger the life of the operator. Do not inhale them. Do not approach of
exhaust gases and wear a protection mask when using the tool.
Fuel Handling
Use caution when handling fuels. They are flammable and the vapors are explosive.
Use only an approved container.
Never remove the fuel cap or add fuel while the machine is on. Turn off the unit and allow the
engine and exhaust components to cool down before refueling.
Do not smoke.
Never refuel inside a room.
Never store the tool and the fuel tank indoors where there is a naked flame, such as near a
water heater.
If fuel has spilled, do not attempt to start the machine, but move it away from the spill before
starting to use it. Please clean up any spills.
Replace and tighten the fuel tank cap after refueling.
Follow strictly the instructions in this manual for filling the tool with fuel.
During maintenance and storage
Switch off the tool and wait until it stops completely. Make sure that all moving parts are
stopped.
Allow the machine to cool before performing inspection, adjustments, maintenance, servicing
and storage.
Store the tool where fuel vapor will not reach a flame or spark.
When transporting and storing the tool, always use a protection device to avoid fuel spillage,
accidents and injuries.
Residual risks
Even if you use this product in compliance with all safety requirements, the potential risks of
injury and damage remain. The following hazards may arise in the structure and design of this
product:
There are adverse health consequences resulting from the emission of vibration if the product
is used for long periods of time or not properly managed and properly maintained.
There are risks of injury and property damage due to attachments or broken the sudden
impact of hidden objects when using cutting.
Risk of injury to persons and property caused by flying objects.
Prolonged use of this product exposes the operator to vibrations and can produce so-called
"white finger" disease. To reduce the risk, wear gloves and keep your hands warm.
If any of the symptoms of "white finger syndrome" occur, seek immediate medical attention.
Symptoms of "white finger" include numbness, loss of sensitivity, tingling, tingling, and pain,
loss of strength, color changes or skin condition. These symptoms usually appear on the
fingers, hands or wrists. Risk increases at low temperatures.
Risk of loss hearing in case of prolonged use, specifically when a hearing protection is not
used.
Intended use
This model of thermal mower is designed for natural grass mowing. Any other use is
prohibited.
It is suitable only for private use in a garden or plot. Lawnmowers designed for private plots or
gardens are those used for the maintenance of grassy areas and private lawns and should
not be used in public areas, parks, sports, agricultural or forest areas.

7
2. YOURPRODUCT
a. Description
1. Self-propeller bar
2. Handlebar
3. Operator control lever
4. Lower bar
5. Hook
6. Grass catcher
7. Flap
8. Fuel tank
9. Starter rope
10. Cutting height lever
11. Oil dipstick
12. Air filter box
13. Primer bulb
b. Technical data
Model
HTDT46-2
Nominal power
2,6kW
Displacement
161cm³
Max engine speed
2850/min
Cutting width
460mm
Cutting height
25-65mm
Volume of the collection bag
55l
Weight
30kg
Engine type
DY1P65FC
Blade type
DY0608-12
Fuel tank capacity
1,35l
Oil tank capacity
0,6l
Sound pressure level
Lpa: 83.2dB(A), K=3,0 dB(A)
Guaranteed Sound Power Level
Lwa:96 dB(A)
Sound power level
Lwa: 95.64dB(A)
Vibration value
Max. 3.85m/s², K=1,5m/s²

8
3. ASSEMBLY
a. Handles/bar
- Install the lower bar on the tool and screw it with the 4 screws and nuts (2 on each
side).
- Combine the upper handle and the lower handle and put the screw. Install then the
hook on the screw and then fix the handle with the 2 wingnuts.
- You can attach the cables with the clip supplied with the machine.

9
b. Grass catcher
- Open and hold the flap. Insert the grass catcher and attach it to the bar with the
hooks. The flap should fit securely.
- To remove the grass catcher, remove the hooks from the bar and remove the tray.
c. Setting of the cutting height
According operation to be performed, adjust the desired cutting height; Grasp the lever,
pull it to the right and then lower it to decrease the cutting height or raise it to increase
the cutting height

10
WARNING! Gasoline is extremely flammable.
Store fuel in specially designed cans for this purpose.
Fill the fuel tank only outdoors and before starting the engine. Do not smoke when
filling the fuel tank or handling fuel.
Never open the fuel tank cap and never add fuel while the engine is running or when it
is hot.
If fuel has spilled, do not start the engine any further, move the tool away from where
the fuel has been spilled, and be careful not to create a spark or flame until the fuel
vapors have dissipated.
Fully close all fuel tank and fuel canisters.
Before tilting the mower to maintain the blade or drain the oil, empty the fuel tank.
WARNING: Never fill the fuel tank indoors, while the engine is running, or before the
engine has cooled down for at least 15 minutes after use.
CAUTION: Do not use unapproved gasoline, such as E15 and E85. Do not mix the oil
with gasoline or modify the engine to operate with alternative fuels. The use of
unapproved fuels will damage the engine parts and will void the engine warranty. To
protect the fuel system from scale formation, add a fuel stabilizer to the fuel. All fuels
are not identical. If start up or performance problems occur, change supplier or fuel
brand. This engine is certified to run on gasoline. Emission control for this engine is
via the EM (Engine Modifications)system.
At altitudes above 1524 m, a gasoline with a minimum octane rating of 85/85 AKI (89
RON) is acceptable. To remain emission compliant, high altitude adjustment is
required. Use without this setting will reduce performance, increase fuel consumption
and emission levels.
Use of the engine at altitudes less than 762 m with high altitude setting is not
recommended.
Do not overfill. Wipe off any fuel that has overflowed before starting the engine.
4. FILLING FUELTANK
a. Filling tank
Fuel must meet the following criteria:
- Clean, new and lead-free gasoline.
- Aminimumoctaneratingof87/87AKI(91RON).Foruseathighaltitudes,seebelow
- A gasoline containing up to 10% ethanol is acceptable.
- Remove the fuel tank cap. Add fuel.
- Close the fuel tank with the cap.

11
a. Engine oil
Recommended oil: We recommend the use of high quality detergent oil classified for SF,
SG, SH, SJ or higher. Do not use special additives.
Filling oil tank
- Open the oil tank.
- Fill directly the oil in the tank. Do not overfill.
- Close the oil tank. Wipe any spillage.
Checking the oil level
Check the oil level when the engine is off and horizontal.
 Remove the plug / dipstick from the oil tank and wipe it off.

Insert the oil tank plug / dipstick into the tank neck as shown, without screwing it in, and
then remove it to check the oil level.

If the oil level is near or below the lower limit of the dipstick, remove the dipstick and fill
the recommended oil reservoir up to the upper limit of the dipstick (bottom edge of the
dipstick). Do not overfill.

Replace the oil tank plug /dipstick.

12
5. USE
a. Starting the tool
Before starting and using the mower, check for the presence
and operation of safety devices. Also, check the
condition of the blade and its securing bolt. If necessary,
replace or repair defective items. Use only genuine
original parts.
- Place the mower in a clear, level area.
- Push the primer bulb (1) several times (at least 3
times).
- Pull the starter rope firmly until that the motor starts.
- Stand behind the handlebars. Move the operator
control lever positioned in front of the handlebars
rearwards so that the lever is resting against the handlebars. Take hold of the starter
handle firmly with the other hand.
-If possible, mow only when the grass is dry. If the grass is wet or excessively long, perform two
cutting passes. Make the first pass at maximum cutting height to avoid overloading the mower.
The second pass should be made at the required finished height. If grass builds up beneath the
mower’s chassis, stop the engine and remove the spark plug’s cap before cleaning the
underside of the cutter deck.
a. Self-propelling
The mower can be self-propelled when in use. When the transmission is operated, the
rear wheels turn automatically. Push and hold the traction bar forward.
Release this bar to stop this function.
b. Stopping
To stop the mower, release the operator control lever. The engine and the blade will stop
turning automatically.
If there is a build‐up of grass beneath the chassis, stop the engine, remove the spark
plug’s cap and wait until the engine has cooled before clearing the grass.

13
6. MAINTENANCE ANDSTORAGE
Before working on the cutting system of the machine, switch off the engine and
remove the spark plug’s cap.
a. Cleaning the mower
- Cut grass is damp. Regular cleaning after each use will ensure better functioning of
the mower and reduce the risk of corrosion or seizure.
- Having finished mowing, allow the engine to cool then remove accumulated grass
clippings from and around the engine with a brush.
- Clean the grass collection bag annually with a brush or gentle spray of water.
- Disconnect the spark plug’s cap and tilt the mower on its side with the air filter and
carburettor uppermost.
- Remove any remaining cut grass from the cutting system with a scraper and a
brush.
- Reposition the mower onto its four wheels.
- Do not use a pressure washer or hot water to clean the mower. Be careful to avoid
soaking parts such as the engine, air cleaner, wheel bearings and metal fastenings.
Dry off the machine before storing by leaving it running for a few minutes on a flat,
clear surface to prevent corrosion or seizure.
b. Storing the mower
Store your mower in a dry, well-ventilated area, away from flames, sparks or heat sources.
If the storage area is accessible to children, immobilise the machine by
disconnecting the spark plug’s cap. Storing the mower beneath a tarpaulin or similar
cover is not recommended as it may cause a build‐up of condensation resulting in
corrosion of the mower.
Extended shutdown and winter storage
Thoroughly clean the mower. Ideally, run the engine outdoors until the fuel tank is empty.
Alternatively, empty any remaining fuel using a fuel suction pump.
Dispose of discarded fuel safely and responsibly, remembering that petrol vapours can
cause explosion or fire. Run the engine until any remaining fuel is consumed. Allow the
engine to cool. Check the condition and cleanliness of the air cleaner. Remove the spark
plug from the engine and pour a tablespoon of engine oil into the cylinder. Gently pull the
starter rope several times to turn over the engine, distributing the oil to protect the
cylinder over winter. Replace and tighten the sparkplug.
At the start of the new season
Remove the spark plug and gently clean off any carbon deposits from the tip with a small
copper wire brush, finishing off with petrol. Allow the spark plug to dry. Pull the starter
rope several times to expel excess oil from the cylinder. Replace and tighten the spark
plug. Fill the fuel tank with unleaded petrol. Turn over the engine until it starts.
Before transporting the mower
Thoroughly clean the mower. Empty the fuel tank using a suction pump. Dispose of
discarded fuel safely and responsibly, remembering that petrol vapours can cause
explosion or fire. Run the engine until any remaining fuel is consumed.
Allow the engine to cool. Remove the grass collection bag. Loosen the quick release and
fold down the top section of the handles taking care not to bend the cables.
To avoid scratching the mower, insert corrugated cardboard or similar padding between
the upper and lower handlebars and the engine.
Due to the mower’s weight, use ramps or seek assistance when lifting or loading the
mower.

14
c. Mower maintenance
Cutting system
Before and after each mowing session, check that the blade, its attachment bolts and
drive shaft are not damaged or excessively worn. Never try to straighten a bent blade.
Replace a damaged, worn or bent blade as soon as possible. Use only genuine parts.
Excessive vibration when mowing is a good indication of a problem with the cutting
system.
WARNING: Vibration from a bent or damaged blade can cause costly damage to the
mower. Working with an excessively worn blade wastes fuel and can lead to injury if the
blade becomes detached from the machine.
Sharpening the blade
For best mowing results, have the edges sharpened and the blade balanced at least once
a year by a specialist service dealer or agent.
Removing the blade
Wear appropriate protective gloves to prevent possible injury when handling the blade.
Disconnect the spark plug cap and tilt the mower on its side with air filter and carburettor
side uppermost.
Holding the blade firmly in one hand, use a spanner or socket to loosen the blade screw.
Mounting the blade
Wear appropriate protective gloves to prevent possible injury when handling the blade.
Disconnect the spark plug cap and tilt the mower on its side with air filter and carburettor
side uppermost.
Check that all components (the blade, key, blade holder, screws and washers).are present,
clean and in good condition.
Position the blade on its support with the cooling fins facing the engine.
Check the correct alignment and matching of pads with the blade. The blade must be
positioned precisely on its stand.
Tighten the screws connecting all of the components. Make a final visual check that all
parts are present and aligned before tightening the fixing bolt very firmly with a wrench
while holding the blade firmly in one hand (NB wear suitable gloves).
Spark plug
Check the spark plug initially after the first five hours of mower use. Thereafter,
maintenance of the spark plug should take place every 25 hours.
Remove the spark plug cap using a rotary motion and then remove the spark plug with
the wrench not provided.
Clean off any carbon deposits using a copper brush and check the electrode gap with a
feeler gauge.
Replace and retighten the serviced spark plug and replace the cap.
If the spark plug is worn or damaged, replace with a new spark plug of the same or
suitable type for the engine.
Air Filter
An air filter in poor condition will reduce the performance and life of the engine while
making it harder to start. Regular checks are therefore essential, especially when using
the mower in dusty conditions. Check and clean the air filter every 25 hours of use or
more often if the engine is used in a dusty environment.
Remove the air box lid and carefully remove the foam filter cartridge. Clean the cartridge
in a small bowl of warm water containing a few drops of washing up liquid until it is
perfectly clean and free from all traces of grease and dust. Rinse the filter cartridge in
clean water and then squeeze gently to remove most of the water. Let it air dry until it is
completely dry.
WARNING: Never clean the foam cartridge in petrol, white spirit or other solvents. These
products will degrade the filter cartridge.
Clean the cover and inside of the air box with a clean lint‐free cloth. Apply a uniform

15
layer of oil to the outside of the cartridge filter with a brush (you can use clean engine oil
for this). Insert the filter cartridge into its housing and replace the air box lid, ensuring that
each component is in place and properly installed. If the filter cartridge is damaged or is
very dirty, replace it using a genuine part.
WARNING: Do not twist the cartridge to clean foam, as you could damage it. This mower
is equipped with a dual filtration system comprising a foam pre‐filter and a cartridge filter
paper.
Themaintenanceofafoampre‐filterisidenticaltothatofafoamcartridgefilter,as
described above. The cartridge filter paper should be cleaned with a vacuum cleaner. If it
is dirty or contaminated with oil or petrol, replace it.
Clean the cover and inside of the air box with a clean cloth. Evenly apply a thin layer of oil
to the outside of the cartridge filter with a brush (you can use clean engine oil for this).
Replace the filter cartridge in its housing and then replace the lid of the air box, ensuring
that each component is in place and properly installed.
Adjusting the transmission cable
In its transmission‐engaged position, the mower’s advance lever is pushed fully towards
the handlebar. An incorrectly‐adjusted transmission cable can cause premature wear to
the mower’s drive system.
If the transmission cable is too tight, it will be difficult to move the advance lever towards
the handlebars. Conversely, if the transmission cable is not tight enough, the transmission
will function poorly and will lack power.
To adjust the tension of the cable transmission, increase or reduce the length of the
adjustment device using the key. Check the effectiveness of the transmission and the
resistance of the lever.
Once proper adjustment has been reached, secure the adjustment device by tightening
the lock nuts.
Warranty
We guarantee this product for 2 full years.
The warranty period for this item starts on the day of purchase. You can prove the date of purchase
by sending us the original receipt.
We insure over the entire warranty period:
• Free repair of possible malfunctions.
• Free replacement of damaged parts.
• Including the free service of our specialized personnel (i.e. free assembly by our technicians)
Provided that the damage is not due to improper use of the device.
To help you with your product, we invite you to use this link or call us on [phone]:
https://services.swap-europe.com/contact
You must create a "ticket" via their platform:
• Register or create your account
• Indicate the reference of the tool
• Choose the subject of your request
• Explain your problem
• Attach these files: Invoice or receipt, identification plate photo (serial number), photo of the
part you need (eg broken transformer plug pins)

17
