Hyundai power products HYM3300E User manual

ELECTRIC CORDED LAWNMOWER
HYM3300E
Instruction Manual

Introduction
Thank You For Purchasing Your HYUNDAI Product
We work very hard to give all of our customers the best possible service. If you have any
problems, before leaving negative feedback, please contact us to give us a chance to resolve
the issue. We would be delighted if you left us positive feedback! Thank you for purchasing this
product.
Important!
This manual has been produced by Hyundai Power Products and should be kept with the
product. Please read and understand these instructions before you use your product. Failure to
do this may result in personal injury or damage to the product.
The safety precautions and warnings are to ensure your safety and protect you from harm or
damage to the product.
The information contained in this manual was accurate at the time of production, however
HYUNDAI Power Products may make modifications to the product without notification.
WARNING : READ THE INSTRUCTION BOOKLET THOROUGHLY BEFORE
USING THE MACHINE. Keep for future reference and pass it on if the machine is
loaned or sold to another user.
!
2 www.hyundaipowerproducts.co.uk 01646 687 880 [email protected].uk

Contents
3
www.hyundaipowerproducts.co.uk 01646 687 880 [email protected].uk
Safety Information.....................4-15
Understand Your Machine...............................4
Personal Safety................................................5
Inspect Your Machine......................................6
Work Area........................................................7
During Use....................................................8-9
Batteries.........................................................10
Electrical Safety..............................................11
Vibrations........................................................12
Noise..............................................................12
Personal Protective Equipment......................13
Intended Use..................................................14
Symbols On The Machine..............................15
Features....................................16-17
Unboxing........................................18
Assembly..................................19-23
Assembly Safety.............................................19
Grass Collector Assembly..............................20
Lower Handle Assembly................................21
Upper Handle Assembly................................22
Cable Hook....................................................23
Cable Clips....................................................23
Operation..................................24-27
Useful Information........................44
Our YouTube Channel....................................44
Warranty.........................................................44
Manual Updates.............................................44
Returning Your Product..................................44
Leaving A Review...........................................44
Ordering Spare Parts......................................44
Contact Us.....................................47
Technical Data..............................36
Spare Parts...............................37-41
Recycling And Disposal...............42
Declaration Of Conformity...........43
Grass Collection.............................................24
Mulching.........................................................25
Cutting Height Adjustment.............................26
Rear Roller......................................................27
Starting / Stopping..................28-29
Maintenance.............................30-35
Maintenance Safety........................................30
Checking Your Machine.................................30
Cleaning..........................................................31
Transportation................................................32
Storage...........................................................33
Blade Maintenance........................................34
Troubleshooting.............................................35
Our Product Range.......................45
Product Information......................46

Safety Information
4 www.hyundaipowerproducts.co.uk 01646 687 880 [email protected].uk
Understand Your Machine
•WARNING! You must read these instructions carefully before operating the machine. Make
sure that you are familiar with the controls and properly operate the machine. You must learn how
to stop the machine quickly. If you do not follow the warnings and instructions, it may result in fire
and/or serious injury. Make sure to save all warnings and instructions for future reference.
• Read this manual and labels affixed to the machine to understand its limitations and potential
hazards.
• Be thoroughly familiar with the controls and their proper operation. Know how to stop the
machine and disengage the controls quickly.
• If the unit is to be used by someone other than original purchaser, or is to be loaned, rented, or
sold, always provide this manual and any needed safety training before operation. The user can
prevent and is responsible for accidents or injuries that may occur to themselves, to other
people, or to property.
• Do not force the machine beyond its limits. Use the correct machine for your application.
• Know how to stop the machine quickly in case of emergency. Understand the use of all
controls.
• ALL MAINTENANCE other than that listed in this manual, should be carried out by
professionally trained and certified personnel.
• When using this machine for the first time and before actual work, you MUST learn how to
handle the machine from an experienced or skilled person.
!
Safety
No list of safety guidelines can be complete. Every environment is different. Always consider
safety first, as it applies to your individual working conditions. Use this and other machinery with
caution and respect. Failure to do so could result in serious injury, damage to equipment, or poor
work results.
Some or all of the following - warning signs and symbols may appear throughout this
manual. You MUST adhere to their warnings. Failure to do so may result in personal injury to
yourself or those around you.
DANGER
Indicates a hazard, which, if not avoided, could result in serious injury or death.
WARNING
Indicates a hazard, which, if not avoided, could result in serious injury.
CAUTION
Indicates a hazard which, if not avoided, might result in minor or moderate injury.
!

Safety Information
5
www.hyundaipowerproducts.co.uk 01646 687 880 [email protected].uk
Personal Safety
!
• WARNING! Never allow children or people unfamiliar with these instructions to use the
product. Local regulations can restrict the minimum age of the operator.
• Keep children, pets, and other people not using the unit away from the work area (at least
15m). Be alert and shut off the unit if anyone enters work area. Keep children under the watchful
care of a responsible adult.
• Stay alert, watch what you are doing and use common sense when operating the machine.
Never operate the machine when unwell or tired, or if you have taken alcohol, medicine, drugs or
any substances which may slow your reflexes and compromise judgment. A moment of
inattention while operating the machine may result in serious personal injury.
• Appropriate Personal Protective Equipment (PPE), MUST be worn at all times when operating
or repairing the machine. Always wear anti-slip and resistant work footwear and long trousers
while using the machine. Do not use the machine when barefoot, wearing sandals or similar
lightweight footwear. Do not wear chains, bracelets or clothing that is loose fitting or hanging
ties or cords. Tie long hair back. Always wear protective earplugs. Loose clothes, jewellery, or
long hair can be caught in moving parts. Protect eyes, face, and head from objects that may be
thrown from the unit. Always wear safety goggles or safety glasses with side shields when
operating.
• Always keep hands and feet away from all moving parts during operation. Moving parts can cut
or crush body parts. Always keep hands and feet away from all pinch points.
• Do not touch parts that might be hot from operation. Allow parts to cool before attempting to
maintain, adjust, or service.
• Do not overreach. Keep proper footing and balance at all times. This enables better control of
the machine in unexpected situations. Extending your body too far can result in a loss of balance
and you may fall which will result in injury.
• Never place any part of your body where it would be in danger if movement should occur
during assembly, installation, and operation, maintenance, repairing or moving.
• Start the machine carefully according to instructions and with feet away from the moving parts.
• Do not place your hands or feet near or under rotating parts. Keep away from any discharge
openings.
• Keep in mind that the operator or user is responsible for accidents, hazards or unexpected
events involving the machine that occur to other people or their property. It is the responsibility of
the user to assess the potential risk of the area where work is being carried out. The operator or
user must take all necessary precautions to ensure their own safety and that of others, especially
on slopes or rough, slippery and unstable ground.

Safety Information
6 www.hyundaipowerproducts.co.uk 01646 687 880 [email protected].uk
Inspect Your Machine
• Check your machine before starting it. Keep guards in place and in working order. Make
sure all nuts, bolts, etc., are securely tightened.
• You must check the general condition of the machine before use.
• Never operate the machine when it is in need of repair or is in poor mechanical condition.
Replace damaged, missing, or failed parts before using it. Keep the machine in safe working con-
dition.
• Do not use the machine if the switch does not turn off the machine when running.
• Regularly check to see that keys and adjusting wrenches are removed from the machine area
before starting it. A wrench or a key that is left attached to a rotating part of the machine may
result in personal injury.
• If the machine should start to vibrate abnormally, stop the machine and check immediately for
the cause. Vibration is generally a warning sign of trouble.
• Avoid accidental starting. Be sure the machine’s switch is off before transporting the machine
or performing any maintenance or service on the unit. Transporting or performing maintenance or
service on a machine with its switch on invites accidents.
• Do not tamper with or disable safety systems.
• Only use manufacturer-recommended attachments.
• Before using, always visually inspect to see that the tools are not worn out or damaged.
Replace worn out or damaged elements and bolts in set to preserve balance.
• Keep the machine in good operating condition. Operating the machine in poor or questionable
condition could result in serious injury.
• Be sure all safety devices are in working order and warning labels are in place. These items are
installed for your safety.
!

Safety Information
7
www.hyundaipowerproducts.co.uk 01646 687 880 [email protected].uk
Work Area
•Make sure you thoroughly inspect the entire work area and remove all objects and anything that
could be thrown by the machine or could damage the machine (branches, stones, wire, toys, etc).
Attempting to clear the work area whilst using the machine will reduce your concentration and
creates a trip hazard. Any liquid spilled on the floor may result in you slipping.
•You must only work in daylight or with good artificial light in good visibility conditions. Do not
work at night, at times of heavy fog, or at any other times when your field of vision might be
limited and it would be difficult to gain a clear view of the area.
•Keep people, children and animals away from the working area.
• Operate on flat, level ground.
• DO NOT work on wet ground. If there has been heavy rain on the working site, wait until the
ground has dried up.
• You must pay special attention when approaching obstacles that could compromise visibility.
• Exercise extreme caution when changing direction on slopes. When changing direction, you
need to be careful that the wheels do not hit any obstacles (such as roots, branches, stones, etc)
that can cause the machine to slide sideways or make you lose control of it. Avoid driving on
slopes steeper than 15%. Make sure on slopes you have a steady foothold.
• Find and locate all fixed objects in the ground, such as sprinkler systems, poles, water valves,
bases for washing lines etc. Make sure that you check for hidden electrical cables or similar on
the surface of the lawn. ALWAYS run the machine around these objects. NEVER intentionally run
the machine over foreign objects.
• Never park the machine in a place with unstable ground which could give way.
• You must be careful near ravines, ditches or embankments.
• Exercise extreme caution when operating on or crossing gravel drives, walks, or roads. Stay
alert for hidden hazards or traffic.
• Pay the utmost attention when working on frozen ground as the machine may tend to skid.
• Do not work in the rain, when there is a thunderstorm or lightning risk, at times of strong or gale
force winds, or at any other times when the weather conditions might make it unsafe to use this
product. If there is bad weather conditions, do not use the machine.
!

Safety Information
8 www.hyundaipowerproducts.co.uk 01646 687 880 [email protected].uk
During Use
• Always hold the unit with both hands when operating. Keep a firm grip on the handlebars.
Be aware that the machine may unexpectedly bounce upward or jump forward if the machine
should strike buried obstacles such as large rocks or roots.
• Do not operate the machine in confined areas where there may be a risk of crushing the
operator between the machine and another object.
• Walk, never run with the machine. Be very careful when pulling the machine toward you. You
must look behind you to make sure there are no obstacles before and during operations in
reverse gear (if applicable). Do not allow the machine to pull you along.
• WARNING! If something breaks or an accident happens whilst working, you must turn off the
machine immediately and move the machine away to prevent further damage. If an accident
happens with injuries or third parties are injured, carry out the first aid measures most suitable
for the situation immediately and contact the medical authorities for any necessary health care.
Carefully remove any debris that might cause damage or harm persons or animals should it not
be seen.
• Use extreme caution when reversing or pulling the machine backwards.
• Do not carry passengers.
• Never operate the machine at a fast pace.
• The excessive speed of movement or the absence of maintenance have a significant influence
on noise emissions and vibrations. It is necessary to take preventive steps to eliminate possible
damage due to high levels of noise and stress from vibration. You must maintain the machine
well, wear ear protection and take breaks from working.
• After striking a foreign object, stop the machine immediately and inspect the machine
thoroughly for damage. Repair the damage before continuing.
• Never attempt to make any adjustments, while the machine is running.
• Never attempt to move the machine in any way other than intended for normal use while the
machine is running.
• Factory-fitted control devices, such as the handle-mounted clutch cable, must not be removed
or exposed.
!

Safety Information
9
www.hyundaipowerproducts.co.uk 01646 687 880 [email protected].uk
• You must disengage the blade, switch off the machine and disconnect from the power supply
(making sure that all moving parts are stationary):
- Before adjusting the cutting height.
- After striking a foreign object, you must inspect the machine for damage and make repairs
before using it again.
- Before checking or working on the machine.
- Before clearing blockages.
- When transporting the machine.
- Whenever you leave the machine unattended.
- When crossing surfaces other than grass.
- Before emptying the grass collector.
- Before changing the cutting height.
During Use (Continued)
!

Safety Information
10 www.hyundaipowerproducts.co.uk 01646 687 880 [email protected].uk
Batteries (Where Present)
Batteries present a risk if they become damaged by the possible leaking of electrolyte. This
electrolyte is an acid and can cause serious burn injuries. Care should be taken when working on
or near them. NOTE the electrolyte may be in a liquid or gel form.
Should you come in to contact with electrolyte you should;
• Remove all clothing contaminated with
electrolyte. If you cannot remove then saturate them in water.
• Get medical assistance as soon as possible.
You must advise the medical staff of the type of acid.
• Lead/acid battery = dilute sulphuric acid.
• Nickel/cadmium = potassium hydroxide alkali electrolyte.
• Use fresh running water to wash off excess electrolyte, continue this until medical assistance
arrives. Make sure that you do not wash the electrolyte to another part of your body or face.
• If electrolyte comes in to contact with Eyes the electrolyte needs to be immediately washed
away with large amounts of water. Make sure that you do not wash the electrolyte to another part
of your face or body.
• Gasses from charging batteries are highly flammable and great care should be taken to charge
in well ventilated areas.
!
• There is an explosion risk if the battery terminals are short circuited, when
connecting/disconnecting ALWAYS exercise great care so that the terminals or battery
leads are NOT allowed to touch and cause a spark. ALWAYS use suitable insulated tools.

Safety Information
11
www.hyundaipowerproducts.co.uk 01646 687 880 [email protected].uk
Electrical Safety
!
ELECTRICITY CAN KILL - NEVER WORK ON LIVE/ENERGISED EQUIPMENT.
DANGER!
• Prior to carrying out any maintenance work you MUST identify electrical isolation methods and
isolate all electrical supplies.
• Prior to use and with all electrical supplies isolated, you MUST check all electrical cables, plugs
and connectors for the following;
- Are intact and have no signs of damage, to include but not limited to bare wires, chaffing, cuts
and loose wiring.
- If there are any signs of damage, the damaged item MUST be taken out of service until the
damage has been repaired by an electrically competent person.
- All trailing cables should be routed so as not to cause any kind of trip hazard.
- NEVER work on or near electricity with wet hands, wet clothing and wet gloves.
• Power tools plug must match the outlet. Never modify the plug in any way. DO NOT use any
adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will
reduce risk of electric shock.
• DO NOT expose this power tool to rain or wet conditions. Water entering a power tool will
increase the risk of electric shock. DO NOT abuse the power cord. Never use the cord for
carrying, pulling or unplugging the power tool. Keep the cord away from heat, oil and sharp edges
or moving parts. Damaged or entangled cords increase the risk of electric shock. When operating
a power tool, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor
use reduces the risk of electric shock.
• IMPORTANT: Make sure that the electric circuit is fused, and that the power, voltage and
frequency of the motor is supported by your mains supply. Also, make sure that your power
supply is earthed. Connect your lawnmower to earth. Never open the ON/OFF switchbox.
However, if it should become necessary to do so, contact a qualified electrician. Make sure that
you will never touch live contacts, specifically when you plug or unplug your lawnmower.
This machine and its power cord must never get into contact with water.
• Never use its power cord to move/shift your lawnmower. Always unplug the power cord before
handling your lawnmower. Do not pull the plug out of the wall socket by the cable and protect the
latter against heat sources, oil and objects which can damage it.
• Avoid body contact with earthed or grounded surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.

Safety Information
12 www.hyundaipowerproducts.co.uk 01646 687 880 [email protected].uk
• Prolonged use of hand held (operated) machines will cause the user to feel the effects of/from
vibrations. These vibrations can lead to white finger (Raynaud’s phenomenon) or carpal tunnel
syndrome. This condition reduces the ability of the hand to feel and regulate temperature,
causing numbness and heat sensations and may cause nerve damage and circulatory tissue
death.
• Not all factors that lead to white finger disease are known, but cold weather, smoking and other
diseases that affect blood vessels and blood circulation as well as large and long-lasting impact
of shocks are considered factors in the formation of white finger. Note the following to reduce the
risk of white finger and carpal tunnel syndrome;
• Wear gloves and keep your hands warm.
• Take regular breaks.
• All of the above precautions may help reduce the risk of white finger disease but not rule out
the carpal tunnel syndrome. Long-term and regular users are therefore recommended to observe
the condition of your hands and fingers. Seek medical attention immediately if any of the above
symptoms should occur.
Vibrations (Where Applicable)
!
• The operating noise of the machine can damage your hearing. When wearing protection such
as earplugs or ear defenders to protect your hearing. Long-term and regular users are advised to
have hearing checked regularly. Be especially vigilant and cautious when wearing ear protection
because your ability to hear alarm warnings will be reduced.
• Noise emissions for this equipment is unavoidable. Carry out noisy work at approved times and
for certain periods. Limit the working time to a minimum. For your personal protection and
protection of people working nearby it is also advisable for them to wear hearing protection.
• See Certificate of Conformity section for Outdoor Noise declaration of conformity.
Noise (Where Applicable)
!

Safety Information
13
www.hyundaipowerproducts.co.uk 01646 687 880 [email protected].uk
Personal Protective Equipment
!
HAND PROTECTION MUST BE WORN
Protective electrically non-conductive gloves are highly recommended when working.
HEARING PROTECTION MUST BE WORN
Suitable safety hearing protection is recommended.
EYE PROTECTION MUST BE WORN
Always wear safety glasses/goggles and/or face shields. Everyday eyeglasses have
only impact resistant lenses; they are not safety glasses/goggles.
FOOT PROTECTION MUST BE WORN
Non-skid heavy duty footwear are highly recommended when working.
PROTECTIVE CLOTHING MUST BE WORN
Do not wear loose clothing, gloves, scarfs, neckties or jewellery
(rings, wrist watches), which can be caught in moving parts.
HEAD PROTECTION MUST BE WORN
Wear a safety helmet with a safety visor.
FACE SHIELD MUST BE WORN
Wear a face shield to protect your face.
RESPIRATOR MUST BE WORN
Wear a respirator.
Appropriate Personal Protective Equipment (PPE), MUST be worn at all times when
operating or repairing the machine. No protective equipment can ensure 100%
protection.
When selecting PPE, make sure it’s CE marked and it suits the user in terms of size, fit, etc. If
more than one item of PPE is worn at the same time, make sure they can be used together, e.g.
wearing safety glasses may disturb the seal of a respirator, causing air leaks.

Safety Information
14 www.hyundaipowerproducts.co.uk 01646 687 880 [email protected].uk
Intended Use
The HYM3300E is an electric lawnmower from Hyundai. The HYM3300E has a cutting width of
330mm and is powered by a 1200W Hyundai motor.
This machine is a garden tool and precisely a pedestrian controlled lawnmower. The operator is
able to operate the machine and use the main controls, always staying behind the handle at a
safe distance from the rotating blade.
The machine is manufactured according to the latest safety requirements. Every precaution is
only effective when it is followed exactly.
Intended Use
This machine was designed and manufactured for cutting (and collecting) grass is gardens and
grassy areas, in areas in proportion to its cutting capacity, controlled by a pedestrian operator.
User Types
This machine is intended for use by consumers, i.e. non professional operators. The machine is
intended for “DIY” and domestic use only.
Improper Use
Any other usage not in keeping with the above mentioned ones may be hazardous and harm
persons and/or damage things. Examples of improper use may include, but are not limited to:
- transporting people, children or animals on the lawnmower
- letting yourself be transported by the lawnmower
- using the machine to tow or push loads
- using the machine for leaf or debris collection
- using the machine to trim hedges, or cutting anything other than grass
- use of the machine by more than one person
- using the blade on surfaces other than grass

15
www.hyundaipowerproducts.co.uk 01646 687 880 [email protected].uk
Safety Information
Symbols On The Machine
We have provided safety messages in this manual and on the machine. This information alerts
you to potential hazards that could hurt you or others. Please read these messages carefully.
However, we may not have listed all of the possible hazards, you must also use your own
judgment.
IMPORTANT
Please read this instruction
manual carefully, especially the
safety warnings marked with the
symbol.
INSTRUCTION MANUAL
Read and understand operator’s
manual before using the
machine. Failure to follow
instructions could result in
death or serious injury.
SAFETY DISTANCE
Do not put hands or feet near or
under rotating parts. Keep a 15
metre safety distance.
BYSTANDERS
Never allow any bystanders in
front of the unit. Keep a 15
metre safety distance.
UNPLUG FROM MAINS
Always switch the machine off
and unplug from the mains
when the unit is left unattended
and when carrying out
maintenance.
CE SYMBOL
This product complies with the
applicable European directives
and an evaluation method of
conformity for these directives
was done.
DANGER!
Keep hands and feet away
from cutting parts.
PROTECTION CLASS II
Equipped with enhanced or
double insulation.
WEEE SYMBOL
Waste electrical products should
not be disposed of with
household waste. Please recycle
where facilities exist. Check with
your local authority or local store
for recycling advice.
DANGER!
Do not mow over the cable.
DANGER!
Risk of electric shock.
IMPORTANT
Acoustic power level.

Features
HYM3300E Features
16 www.hyundaipowerproducts.co.uk 01646 687 880 [email protected].uk
123
4
5
6
7

Features
1Main Handle
Hold onto with both hands this whilst using the machine.
2Operator Presence Control (OPC) Lever
This is a safety feature. The machine will stop if you let go of this lever.
3
4
5
6
Quick Release Handle
7Mulching Plug
HYM3300E Features
17
www.hyundaipowerproducts.co.uk 01646 687 880 [email protected].uk
On / Off Button
Grass Collector
Wheel

Unboxing
• HYM3300E Lawnmower
• User Manual
• 30L Grass Collector (3 Parts - Needs Assembly)
• Mulching Plug
• Cable Clips
• Handle Fixings
Box Contents
WARNING! Unboxing and assembling the machine should be done on a flat, stable surface
with enough room. Disposal of the packaging should be done in accordance with the local
regulations in force.
WARNING! Some of the packaging material may be harmful to children. Keep out of reach of
children.
Unboxing Safety
!
Carefully remove the product from the packaging and examine it for any sign of damage caused
during shipping. Lay the contents out and check them. If any part is damaged or missing, you
must not use the machine. Contact HYUNDAI Power Products immediately. You must keep the
packaging material in case the machine needs to be returned or repaired.
Ensure that you have all the accessories and tools you need for assembly and operation
including the suitable personal protective equipment.
18 www.hyundaipowerproducts.co.uk 01646 687 880 [email protected].uk

Assembly
CAUTION - This guide is meant to serve as a quick reference for operating your HYUNDAI
machine. We always advise reading the manual in full before operation.
NOTE - Images may vary depending on model.
NOTE - The machine may be supplied with some parts already assembled. Prior to assembly,
check all items have been received. The mulching plug may already be installed for transport.
Assembly Safety
!
We recommend that you fill out the information on page 46. If you need to contact an
authorised dealer or customer service for information on servicing, you may need to
provide this information.
There is also a service record so you can keep track of your machine service dates.
19
www.hyundaipowerproducts.co.uk 01646 687 880 [email protected].uk

Assembly
Step 1 : Grass Collector Assembly
Unboxing & Assembly Video:
YOU MUST read and understand the instruction manual first.
Go to youtube.com and type in Hyundai HYM3300E assembly.
20 www.hyundaipowerproducts.co.uk 01646 687 880 [email protected].uk
Clip the two black parts together. See image 1.
1
Image 1 Image 2
Clip the blue top section onto the lower part. Start at one end and work your way around.
See image 2.
2
