Hyundai power products HTHE75DEM User manual

Instructions originales
1
WARNING: Read thoroughly the instruction manual before use.
ORIGINAL INSTRUCTIONS

2
Symbol explanation
Waste electrical products should not be discarded together with household waste. Please
recycle if facilities exist. Take advice on recycling from local authorities or your distributor.
Class II protection (double isolation)
READ THE INSTRUCTIONS MANUAL
In conformity with the European regulations
Remove the mains plug immediately if the cable is damaged or cut
Do not use the tool under rain
Guarantee sound power level
General Power Tool Safety Warnings
WARNING Read all safety warnings and all instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference. The term "power tool" in the warnings refers to
your mains-operated (corded) power tool or battery-operated (cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids,
gases or dust. Power tools create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions can cause you to lose
control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of
electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
Original instructions

3
c) Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk
of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of
electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of electric shock.
NOTE the term “residual current device (RCD)” may be replaced by the term “ground fault circuit
interrupter (GFCI)” or “earth leakage circuit breaker (ELCB)”.
3) Personal safety
a) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not
use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce
personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position connecting to power source
and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch
or energizing power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the
power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection can reduce dust-related hazards.
4) Power tool use and care
a) Do not force the power tool. Use the correct power tool for your application. The correct power tool
will do the job better and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or the battery pack from the power tool before
making any adjustments, changing accessories, or storing power tools. Such preventive safety measures
reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with the
power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of
untrained users.
e) Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less
Original instructions

4
likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into
account the working conditions and the work to be performed. Use of the power tool for operations
different from those intended could result in a hazardous situation.
5) Battery tool use and care
a) Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fire when used with another battery pack.
b) Use power tools only with specifically designated battery packs. Use of any other battery packs may
create a risk of injury and fire.
c) When battery pack is not in use, keep it away from other metal objects, like paper lips, coins, keys,
nails, screws or other small metal objects, that can make a connection from one terminal to another.
Shorting the battery terminals together may cause burns or a fire.
d) Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help. Liquid
ejected from the battery may cause irritation or burns.
6) Service
a) Have your power tool serviced by a qualified repair person using only identical replacement parts.
This will ensure that the safety of the power tool is maintained
Hedge trimmer safety warnings:
Keep all parts of the body away from the cutter blade. Do not remove cut material or hold material
to be cut when blades are moving. Make sure the switch is off when clearing jammed material. A
moment of inattention while operating the hedge trimmer may result in serious personal injury.
Carry the hedge trimmer by the handle with the cutter blade stopped. When transporting or
storing the hedge trimmer always fit the cutting device cover. Proper handling of the hedge trimmer
will reduce possible personal injury from the cutter blades.
Hold the power tool by insulated gripping surfaces only, because the cutter blade may contact
hidden wiring or its own cord. Cutter blades contacting a “live” wire may make exposed metal parts
of the power tool “live” and could give the operator an electric shock.
Hold the power tool by insulated gripping surfaces only, because the cutter blade
may contact hidden wiring or its own cord. Cutter blades contacting a "live" wire may
make exposed metal parts of the power tool "live" and could give the operator an electric
shock.
-Check the hedge for foreign objects, e.g. wire fences.
-Wear hearing protection.
-It is advisable to use a residual current differential device whose tripping current is less than or equal to
30 mA
-During cutting, be sure not to touch objects such as wire fences or a frame. Touching these objects can
damage the blade.
Original instructions

5
-Hold the electric hedge trimmer firmly with both hands, one hand on the back and the other on the front
handle. The thumb and fingers should be tight.
Residual risks
Even when the tool is used as prescribed, it is impossible to eliminate all residual risk factors. The
following risks may occur in connection with the construction and design of the tool:
1. Damage to the lungs due to failure to wear an effective dust mask.
2. Hearing damage due to failure to wear effective hearing protection.
3. Health problems resulting from the emission of vibrations if the power tool is used for a long period
of time or is not properly managed and properly maintained.
WARNING! This machine generates an electromagnetic field during its operation. This field may in
certain circumstances interfere with the operation of active or passive medical implants. To reduce
the risk of serious injury or death, persons wearing medical implants should consult their physician
and their implant manufacturer before using this machine.
Data information
Model
Voltage and
frequency
Power
Non load
speed
(min-1)
Cutting
length
(mm)
Cutting
capacity
(mm)
HTHE75DEM
230-240 V~ 50 Hz
750 W
900 min-1
690
28
Clutch system for the blade
Laser cutting blade made of SK5 steel
Double gear system (2 speeds)
Mechanical motor brake
Noise and vibration information:
HTHE75DEM
Sound pressure level LpA
96,08 dB(A)
Uncertainty KpA
3 dB
Sound power level LWA
104,04 dB(A)
Uncertainty KWA
3 dB
Guarantee sound power level LWA
108 dB(A)
Vibration ah - front handle: m/s2
3,079 m/s2
- rear handle: m/s2
3,544 m/s2
Uncertainty K
Original instructions
1,5 m/s2
Sound emission and vibration values determined according to EN 60745-1 and EN 60745-2-15.

6
Wear hearing protection when using the tool
Information:
The declared vibration total value has been measured in accordance with a standard test method and
may be used for comparing one tool with another;
The declared vibration total value may also be used in a preliminary assessment of exposure.
Warning:
that the vibration emission during actual use of the power tool can differ from the declared total value
depending on the ways in which the tool is used; and
of the need to identify safety measures to protect the operator that are based on an estimation of
exposure in the actual conditions of use (taking account of all parts of the operating cycle such as the
times when the tool is switched off and when it is running idle in addition to the trigger time).
Description
1
3
2
5
6
7
4
8
Original instructions
6. Cable holder
7. Cable and plug
8. Rear handle lock button
1. Blade safety cover
2. Blade
3. Security protection guard
4. Rear handle with on / off switch
5. Front handle with on / off switch

7
Intended use
The hedge trimmer should only be used to trim hedges, bushes and shrubs. Uses not mentioned in this manual
may damage the trimmer or cause serious injury to the operator.
Before use
Connection
This hedge trimmer can only be connected to single-phase AC power. Make sure that the mains voltage is
the same as the operating voltage indicated on the rating plate.
Connect the power plug to the outlet of an appropriate extension cord. Make a loop, push it through the
opening in the back handle and hook onto the cable holder (6).
Starting
Avertissement ! N'utilisez cette machine que pour les domaines décrits dans le
chapitre «domaine d'utilisation»
.
Warning! Only use this machine for the intended use described in the section "intended use".
Adjusting the position of the rear handle
Press the lock button (8), and then turn the rear handle around the main part of the tool, the rear handle can
be set to different positions to make comfortable working with the right hand or left hand or to be held without
difficulty. Make sure that the lock button (8) is returned to the lock position when the rear handle is set to a
position, otherwise the on / off switch cannot be operated.
Starting/stopping
Starting: Press the on / off button (5) on the rear handle and the switch (4) on the front handle with both
hands at the same time.
Stop: release one of the switches (5) or (4).
The blade brake stops immediately in 1 s, the small spark in the area of the upper ventilation slots is a normal
phenomenon and does not cause any damage to you or your machine.
Trim the hedges
Before starting your work, select the branches with a diameter greater than 20 mm and cut them with shears.
A trapezoidal cut corresponds to the natural growth of the plants and gives rise to a rapid growth of the hedge.
-Size first the bottom sides up. Cut the upper part into the desired shape, horizontally, rounded or arched.
-The safety blade has rounded and offset side teeth to reduce the risk of injury. Extra protection against
shock prevents accidental surprises when the blades come in contact with walls, fences, etc.
-If the blades get stuck or jammed, immediately turn off the engine, unplug the plug and release the blades
from the blocking object.
-Warning! Metallic objects such as fences, etc. can damage the cutting blades.
-Always make sure the extension cord is behind you and start trimming the hedge at the closest point to the
Original instructions
power outlet. So define your direction of work before you start

8
Maintenance and servicing
-Before performing any maintenance or checking operation, disconnect the plug from the power supply.
-Check your machine regularly before starting work.
Damaged cutting blades must be repaired or replaced by qualified service personnel before working with the
machine.
-After each cutting operation, clean the blade with a soft brush and a cloth soaked in lubricant and spray a
light coat of protective oil
-Always keep the ventilation slots of the motor housing clean.
-Do not clean the machine with water or spray it with it. Clean the motor housing only with a damp cloth and
never use detergents or solvents! These substances can damage the plastic parts of the machine. Finally, dry
the motor housing carefully.
-Store the machine with its protective cover provided
All maintenance and repair of the appliance must be carried out by our after-sales service
Original instructions
Electrical products should not be discarded with household products. According to the European Directive
2012/19/EU on waste electrical and electronic equipment and its implementation into national law, electrical
products used must be collected separately and disposed of at collection points provided for this purpose.
Talk with your local authorities or dealer for advice on recycling.

9
BUILDER
ZI, 32 rue Aristide Bergès –31270 Cugnaux - France
Tel: [phone] Fax: [phone]
ZI, 32 rue Aristide Bergès –31270 Cugnaux - France
Also complies with European standards, national standards and the following technical provisions:
Original instructions
Noise emission Directive 2000/14/EC Annex V + 2005/88/EC
Measured sound power level Lwa 104,04 dB(A) K= 3 dB
Guarantee sound power level Lwa 108 dB(A)
Cugnaux, Le 31/07/2020
Philippe MARIE / PDG
Declaration of conformity
BUILDER
A la Directive EMC 2014/30/UE
ROHS Directive (EU)2015/863 amending 2011/65/EU
EN60745-1:2009+A11
EN60745-2-15:2009+A1
EN 55014-1:2017
EN 55014-2:2015
EN IEC61000-3-2:2019
EN 61000-3-3:2013
Declare that the machine
Hedge trimmer
HTHE75DEM
Serial number: 20200830763-20200831012
20200831013-20200831262
The person in charge of the technical file: M. Olivier Patriarca
Complies with the provisions of the Machinery Directive 2006/42/EC and the national regulations
transposing it;
Also complies with the provisions of the following European directives:

WARRANTY
The manufacturer guarantees the product against defects in material and workmanship for a period of 2
years from the date of the original purchase. The warranty only applies if the product is for household use.
The warranty does not cover breakdowns due to normal wear and tear.
The manufacturer agrees to replace parts identied as defective by the designated distributor. The
manufacturer does not accept responsibility for the replacement of the machine, in whole or in part , and/or
ensuing damage.
The warranty does not cover breakdowns due to:
• insu󰀩cient maintenance.
• abnormal assembly, adjustment or operations of the product.
• parts subject to normal wear and tear.
The warranty does not extend to:
• shipping and packaging costs.
• using the tool for a purpose other than that for which it was designed.
• the use and maintenance of the machine done in a manner not described in the user manual.
Due to our policy of continuous product improvement, we reserve the right to alter or change specications
without notice. Consequently, the product may be di󰀨erent from the information contained therein, but a
modication will be undertaken without notice if it is recognized as an improvement of the preceding
characteristic.
READ THE MANUAL CAREFULLY BEFORE USING THE MACHINE.
When ordering spare parts, please indicate the part number or code, you can nd this in the spare parts list
in this manual. Keep the purchase receipt; without it, the warranty is invalid. To help you with your product,
we invite you to contact us by phone or via our website:
• +33 (0)9.70.75.30.30
• https://services.swap-europe.com/contact
You must create a "ticket" via the web platform.
• Register or create your account.
• Indicate the reference of the tool.
• Choose the subject of your request.
• Describe your problem.
• Attach these les: invoice or sales receipt, photo
of the identication plate (serial number), photo
of the part you need (for example: pins on the
transformer plug which are broken).
WARRANTY
10

WHAT TO DO IF MY MACHINE BREAKS DOWN?
If you bought your product in a store:
a) Empty the fuel tank.
b) Make sure that your machine is complete with all accessories supplied, and clean! If this is not the case,
the repairer will refuse the machine.
Go to the store with the complete machine and with the receipt or invoice.
If you bought your product on a website:
a) Empty the fuel tank.
b) Make sure that your machine is complete with all accessories supplied, and clean! If this is not the case,
the repairer will refuse the machine.
c) Create a SWAP-Europe service ticket on the site: https://services.swap-europe.com When making the
request on SWAP-Europe, you must attach the invoice and the photo of the nameplate (serial number).
d) Contact the repair station to make sure it is available before dropping o󰀨 the machine.
Go to the repair station with the complete machine packed, accompanied by the purchase invoice and the
station support sheet downloadable after the service request is completed on the SWAP-Europe site
For machines with engine failure from manufacturers BRIGGS & STRATTON, HONDA and RATO, please
refer to the following instructions.
Repairs will be done by approved engine manufacturers of these manufacturers, see their site:
• http://www.briggsandstratton.com/eu/fr
• http://www.honda-engines-eu.com/fr/service-network-page;jsessionid=5EE8456CF39CD572AA2AEEDFD
290CDAE
• https://www.rato-europe.com/it/service-network
Please keep your original packaging to allow for after-sales service returns or pack your machine
with a similar cardboard box of the same dimensions.
For any question concerning our after-sales service you can make a request on our website https://
services.swap-europe.com
Our hotline remains available at [phone].
PRODUCT FAILURE
11

THE WARRANTY DOES NOT COVER:
• Start-up and setting up of the product.
• Damage resulting from normal wear and tear of the product.
• Damage resulting from improper use of the product.
• Damage resulting from assembly or start-up not in accordance with the user manual.
• Breakdowns related to carburetion beyond 90 days and fouling of carburetors.
• Periodic and standard maintenance events.
• Actions of modication and dismantling that directly void the warranty.
• Products whose original authentication marking (brand, serial number) has been degraded, altered or
withdrawn.
• Replacement of consumables.
• The use of non-original parts.
• Breakage of parts following impacts or projections.
• Accessories breakdowns.
• Defects and their consequences linked to any external cause.
• Loss of components and loss due to insu󰀩cient screwing.
• Cutting components and any damage related to the loosening of parts.
• Overload or overheating.
• Poor power supply quality: faulty voltage, voltage error, etc.
• Damages resulting from the deprivation of enjoyment of the product during the time necessary for repairs
and more generally the costs related to the immobilization of the product.
• The costs of a second opinion established by a third party following an estimate by a SWAP-Europe repair
station
• The use of a product which would show a defect or a breakage which was not the subject of an immediate
report and/or repair with the services of SWAP-Europe.
• Deterioration linked to transport and storage*.
• Launchers beyond 90 days.
• Oil, petrol, grease.
• Damages related to the use of non-compliant fuels or lubricants.
* In accordance with transport legislation, damage related to transport must be declared to carriers within 48
hours maximum after observation by registered letter with acknowledgement of receipt.
This document is a supplement to your notice, a non-exhaustive list.
Attention: all orders must be checked in the presence of the delivery person. In case of refusal by the
delivery person, it you must simply refuse the delivery and notify your refusal.
Reminder: the reserves do not exclude the notication by registered letter with acknowledgement within 72
hours.
Information:
Thermal devices must be wintered each season (service available on the SWAP-Europe site). Batteries must
be charged before being stored.
WARRANTY EXCLUSIONS
12

11
