Hyundai power products HTHEN40V-A User manual

1
CORDLESS HEDGE TRIMMER
HTHEN40V-A
WARNING: Read thoroughly the instruction manual before use.

2
1. SAFETY WARNINGS
WARNING Read all safety warnings and all instructions. Failure to follow the warnings and instructions
may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference. The term "power tool" in the warnings refers to your
mains-operated (corded) power tool or battery-operated (cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit.Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids,
gases or dust. Power tools create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions can cause you to lose
control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric
shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of
electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of
electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of electric shock.
NOTE the term “residual current device (RCD)” may be replaced by the term “ground fault circuit interrupter
(GFCI)” or “earth leakage circuit breaker (ELCB)”.
3) Personal safety
a) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use
a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of
inattention while operating power tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection. Protective equipment such as dust mask,
non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position connecting to power source
and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or
energizing power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to
a rotating part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power
tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing and gloves away from
moving parts. Loose clothes, jewelry or long hair can be caught in moving parts.

3
g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection can reduce dust-related hazards.
4) Power tool use and care
a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will
do the job better and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or the battery pack from the power tool before making
any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the
risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained
users.
e) Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely
to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into
account the working conditions and the work to be performed. Use of the power tool for operations different
from those intended could result in a hazardous situation.
5) Battery tool use and care
a) Recharge only with the charger specified by the manufacturer.A charger that is suitable for one type of
battery pack may create a risk of fire when used with another battery pack.
b) Use power tools only with specifically designated battery packs.Use of any other battery packs may
create a risk of injury and fire.
c) When battery pack is not in use, keep it away from other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects, that can make a connection from one terminal to another.
Shorting the battery terminals together may cause burns or a fire.
d) Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally
occurs, flush with water. If liquid contacts eyes, additionally seek medical help.Liquid ejected from the
battery may cause irritation or burns.
e) Never service damaged battery packs. Service of battery packs should only be performed by the
manufacturer or authorized service providers
6) Service
a) Have your power tool serviced by a qualified repair person using only identical replacement parts.This
will ensure that the safety of the power tool is maintained
Hedge trimmer safety warnings:
Keep all parts of the body away from the cutter blade. Do not remove cut material or hold material to
be cut when blades are moving. Make sure the switch is off when clearing jammed material. A
moment of inattention while operating the hedge trimmer may result in serious personal injury.
Carry the hedge trimmer by the handle with the cutter blade stopped. When transporting or storing
the hedge trimmer always fit the cutting device cover.Proper handling of the hedge trimmer will reduce
possible personal injury from the cutter blades.

4
Hold the power tool by insulated gripping surfaces only, because the cutter blade may contact
hidden wiring. Cutter blades contacting a "live" wire may make exposed metal parts of the power tool "live"
and could give the operator an electric shock.
Advice to check the hedge for foreign objects, e.g. wire fences
Hold the hedge trimmer properly, e.g. with both hands if two handles are provided
Symbols
Warning symbol
Read the instruction manual
Wear protection glasses
Wear hearing protection
Do not touch the blades
Guarantee sound power level
Do not expose to rain
Intended use
This hedge trimmer is intended for cutting and trimming hedges and bushes in domestic use. It is not intended to
be used for cutting above shoulder level.

5
2. YOUR TOOL
a. Description
1. REAR HANDLE
2. TRIGGER SWITCH
3. TWO SPEED BUTTON
4. FRONT HANDLE
5. FRONT HANDLE TRIGGER
6. GUARD
7. BLADE
8. BLADE PROTECTION COVER
9. BATTERY PACK(no provided)
10. CHARGER(no provided)

6
b. Technical data
Model
HTHEN40V-A
Rated voltage
40V d.c.
No load speed
1500 min-1
Blade length
600 mm
Cutting capacity
27 mm
Vibration
<2.5 m/s² 1.5 m/s²
Sound pressure level
90dB(A) K =3dB
Sound power level
104dB(A) K =3 dB
Weight without battery pack
3.20Kg
Information
 The declared vibration total value has been measured in accordance with a standard test
method and may be used for comparing one tool with another;
 The declared vibration total value may also be used in a preliminary assessment of
exposure.
Warning
 that the vibration emission during actual use of the power tool can differ from the declared
total value depending on the ways in which the tool is used; and
 of the need to identify safety measures to protect the operator that are based on an
estimation of exposure in the actual conditions of use (taking account of all parts of the
operating cycle such as the times when the tool is switched off and when it is running idle
in addition to the trigger time).
Wear hearing protection

7
3. OPERATION
Note：The battery and charger were not included in pack
1) Wear personal protective equipment (gloves, hearing and eye protection, protective clothing).
2) Remove the blade guard.
3) Place the battery in the hedge trimmer. Align the grooves in the battery with those in the battery
compartment. Push the battery into its compartment to lock it in place. Make sure that the battery
is properly installed to avoid any incident.
To remove the battery, hold and pull the tab and remove the battery.
4) To start the tool, hold it with both hands, one hand pressing the trigger, the other holding the start
switch.
To stop the operation, release the trigger and the switch

8
OPERATING TIPS
Do not force the hedge trimmer through heavy shrubbery. This can cause the blades to bind and slow
down. If the blades slow down, reduce the pace.
Do not try to cut stems or twigs that are larger than 20mm thick, or those obviously too large to feed
into the cutting blade. Use a non-powered hand saw or pruning saw to trim large stems.
If desired, you can use a string to help cut your hedge level. Decide how high you want the hedge.
Then stretch a piece of string along the hedge at this height. Trim the hedge just above this guide line
of string. Trim the side of a hedge so that it will be slightly narrower at the top. More of the edge will be
exposed when shaped this way, and it will be more uniform. If blades do become jammed, stop the
motor, allow the blades to stop and remove the battery pack before attempting to remove the
obstruction.
Wear gloves when trimming thorny or prickly growth. When trimming new growth, use a wide
sweeping action, so that the stems are fed directly into the cutting blade. Older growth will have thicker
stems and will be trimmed easiest by using a sawing movement.
4. MAINTENANCE AND STORAGE
WARNING
To prevent serious personal injury, remove the battery pack before servicing, cleaning, or
removing material from the unit.
BLADE CARE
Lubricate the cutting blades after each use.
Periodically inspect the blades for damage and wear.
Always use the manufacturer's specified replacement blades.
TO LUBRICATE BLADE
Remove battery pack from hedge trimmer.
For easier operation and longer blade life, lubricate the hedge trimmer blade before and after each
use.
Before lubricating, remove the battery pack and lay hedge trimmer on a flat surface. Apply light weight
machine oil along the edge of the top blade.
Occasionally, you should oil your hedge trimmer during prolonged use. Before oiling, stop hedge
trimmer, remove battery pack, then oil. You then can resume trimming. Do not oil while hedge trimmer
is running.
SHARPENING BLADE
Allow the blades of the hedge trimmer to come to a stop in the position. This will allow clearance for
the file between cutter teeth and guard teeth.
Remove battery pack from hedge trimmer.

9
Clamp blade assembly in a vice and file the exposed cutting surface of each blade tooth with a 203
mm (8 inch) smooth round file, 6.4 mm (1/4 inch) or 5.6mm (7/32 inch) diameter. Be sure to retain the
original angle of tooth when filing.
Re move the hedge trimmer from the vice, replace battery pack and restart the hedge trimmer. Allow
the blades of the hedge trimmer to come to a stop so that the unsharpened edges of the cutter blade
teeth are exposed.
Remove battery pack from hedge trimmer and repeat the sharpening procedure as described above.
HEDGE TRIMMER LUBRICATION
All of the bearings in this tool are lubricated with a sufficient amount of high-grade lubricant for the life
of the unit under normal operating procedures. Therefore, no further lubrication is required.
WARNING
Do not attempt to modify this unit or create or mount any accessory not specifically recommended in
this manual for use with this hedge trimmer. Any such alteration or modification is misuse and could
result in a hazardous condition leading to possible serious personal injury.
WARNING
Examine hedge trimmer frequently to assure all parts are unbroken and securely attached. Make sure
all screws and fasteners are securely tightened to prevent the risk of serious personal injury.
CLEANING THE HEDGE TRIMMER
To prevent serious personal injury, remove the battery pack before servicing, cleaning, or removing
material from the unit.
Remove the battery pack.
Clean the unit using a damp cloth with a mild detergent.
Do not use any strong detergents on the plastic housing or the handle. They can be damaged by
certain aromatic oils such as pine and lemon, and by solvents such as kerosene.
Moisture can cause a shock hazard. Wipe off any moisture with a soft dry cloth.
Use a small brush or the air discharge of a small vacuum cleaner brush to clean the air vents on the
battery pack housing and motor housing.
Keep the air vents free of obstructions.
STORING THE HEDGE TRIMMER
Clean the hedge trimmer thoroughly before storing. Store the hedge trimmer in a dry, well-ventilated
place that is inaccessible to children. Keep away from corrosive agents such as garden chemicals and
de-icing salts.
Always place blade cover on cutting blades before storing.
Store and charge your batteries below in a cool area. Temperatures above or below normal room
temperature will shorten battery pack life.

10
Never store batteries in a discharged condition. Wait for battery pack to cool and fully charge
immediately.
Store the battery pack where the temperature is below 27$C, and away from moisture.
All batteries gradually lose their charge. The higher the temperature, the quicker they lose their charge.
If you store your unit for long periods of time without using it, recharge the batteries every month or
two. This practice will prolong battery pack life.
5. DISPOSAL
Separate collection of used products and packaging allows materials to be recycled and
used again. Re-use of recycled materials helps prevent environmental pollution and
reduces the demand for raw materials.
At the end of their useful life, discard batteries with due care for our environment. The
battery contains material which is hazardous to you and the environment. It must be
removed and disposed of separately at a facility that accepts lithium-ion batteries.

11
6. CE DECLARATION
EC Declaration of conformity
BUILDER SAS
32, rue Aristide Bergès - ZI 31270 Cugnaux – France
Declares that the machine
Designation: CORDLESS HEDGE TRIMMER
Model: HTHEN40V-A
Serial number : 20201141029-20201141478
Is in conformity with the European Directives:
Machine Directive 2006/42/EC
EMC Directive 2014/30/EU
ROHS Directive (EU)2015/863 amending 2011/65/EU
Noise emission Directive 2000/14/EC Annex V + 2005/88/EC
A-weighted sound pressure level
LPA: 90dB(A) K=3dB(A)
Guarantee sound power level
LWA: 104dB(A)
This product is also in conformity with the following standards:
EN60745-1:2009+A11:2010
EN60745-2-15:2009+A1:2010
EN55014-1:2006+A1:2009+A2:2011
EN55014-2:2015
The technical documentation is kept by: Olivier Patriarca
Philippe MARIE / PDG
Cugnaux, 23/09/2020

WARRANTY
The manufacturer guarantees the product against defects in material and workmanship for a period of 2
years from the date of the original purchase. The warranty only applies if the product is for household use.
The warranty does not cover breakdowns due to normal wear and tear.
The manufacturer agrees to replace parts identied as defective by the designated distributor. The
manufacturer does not accept responsibility for the replacement of the machine, in whole or in part , and/or
ensuing damage.
The warranty does not cover breakdowns due to:
• insu󰀩cient maintenance.
• abnormal assembly, adjustment or operations of the product.
• parts subject to normal wear and tear.
The warranty does not extend to:
• shipping and packaging costs.
• using the tool for a purpose other than that for which it was designed.
• the use and maintenance of the machine done in a manner not described in the user manual.
Due to our policy of continuous product improvement, we reserve the right to alter or change specications
without notice. Consequently, the product may be di󰀨erent from the information contained therein, but a
modication will be undertaken without notice if it is recognized as an improvement of the preceding
characteristic.
READ THE MANUAL CAREFULLY BEFORE USING THE MACHINE.
When ordering spare parts, please indicate the part number or code, you can nd this in the spare parts list
in this manual. Keep the purchase receipt; without it, the warranty is invalid. To help you with your product,
we invite you to contact us by phone or via our website:
• +33 (0)9.70.75.30.30
• https://services.swap-europe.com/contact
You must create a "ticket" via the web platform.
• Register or create your account.
• Indicate the reference of the tool.
• Choose the subject of your request.
• Describe your problem.
• Attach these les: invoice or sales receipt, photo
of the identication plate (serial number), photo
of the part you need (for example: pins on the
transformer plug which are broken).
7. WARRANTY
12

WHAT TO DO IF MY MACHINE BREAKS DOWN?
If you bought your product in a store:
a) Empty the fuel tank.
b) Make sure that your machine is complete with all accessories supplied, and clean! If this is not the case,
the repairer will refuse the machine.
Go to the store with the complete machine and with the receipt or invoice.
If you bought your product on a website:
a) Empty the fuel tank.
b) Make sure that your machine is complete with all accessories supplied, and clean! If this is not the case,
the repairer will refuse the machine.
c) Create a SWAP-Europe service ticket on the site: https://services.swap-europe.com When making the
request on SWAP-Europe, you must attach the invoice and the photo of the nameplate (serial number).
d) Contact the repair station to make sure it is available before dropping o󰀨 the machine.
Go to the repair station with the complete machine packed, accompanied by the purchase invoice and the
station support sheet downloadable after the service request is completed on the SWAP-Europe site
For machines with engine failure from manufacturers BRIGGS & STRATTON, HONDA and RATO, please
refer to the following instructions.
Repairs will be done by approved engine manufacturers of these manufacturers, see their site:
• http://www.briggsandstratton.com/eu/fr
• http://www.honda-engines-eu.com/fr/service-network-page;jsessionid=5EE8456CF39CD572AA2AEEDFD
290CDAE
• https://www.rato-europe.com/it/service-network
Please keep your original packaging to allow for after-sales service returns or pack your machine
with a similar cardboard box of the same dimensions.
For any question concerning our after-sales service you can make a request on our website https://
services.swap-europe.com
Our hotline remains available at [phone].
8. PRODUCT FAILURE
13

THE WARRANTY DOES NOT COVER:
• Start-up and setting up of the product.
• Damage resulting from normal wear and tear of the product.
• Damage resulting from improper use of the product.
• Damage resulting from assembly or start-up not in accordance with the user manual.
• Breakdowns related to carburetion beyond 90 days and fouling of carburetors.
• Periodic and standard maintenance events.
• Actions of modication and dismantling that directly void the warranty.
• Products whose original authentication marking (brand, serial number) has been degraded, altered or
withdrawn.
• Replacement of consumables.
• The use of non-original parts.
• Breakage of parts following impacts or projections.
• Accessories breakdowns.
• Defects and their consequences linked to any external cause.
• Loss of components and loss due to insu󰀩cient screwing.
• Cutting components and any damage related to the loosening of parts.
• Overload or overheating.
• Poor power supply quality: faulty voltage, voltage error, etc.
• Damages resulting from the deprivation of enjoyment of the product during the time necessary for repairs
and more generally the costs related to the immobilization of the product.
• The costs of a second opinion established by a third party following an estimate by a SWAP-Europe repair
station
• The use of a product which would show a defect or a breakage which was not the subject of an immediate
report and/or repair with the services of SWAP-Europe.
• Deterioration linked to transport and storage*.
• Launchers beyond 90 days.
• Oil, petrol, grease.
• Damages related to the use of non-compliant fuels or lubricants.
* In accordance with transport legislation, damage related to transport must be declared to carriers within 48
hours maximum after observation by registered letter with acknowledgement of receipt.
This document is a supplement to your notice, a non-exhaustive list.
Attention: all orders must be checked in the presence of the delivery person. In case of refusal by the
delivery person, it you must simply refuse the delivery and notify your refusal.
Reminder: the reserves do not exclude the notication by registered letter with acknowledgement within 72
hours.
Information:
Thermal devices must be wintered each season (service available on the SWAP-Europe site). Batteries must
be charged before being stored.
9. WARRANTY EXCLUSIONS
14

12
