Hyundai Sonata CS-HY1120 User manual

CarShow Copyright 2012 All Rights Reserved
Multi-Media Navigation System Installation Guide Rev A
Installation Guide
NOTICE OF INTENDED INSTALLATION AND USE
THE CARSHOW MULTI-MEDIA NAVIGATION SYSTEMS CONTAIN AN INTERNAL VIDEO PLAYER, WHICH
IS NOT INTENDED FOR VIEWING BY THE DRIVER. THE VIDEO PLAYER IS DISABLED WHEN THE
VEHICLE IS IN MOTION THROUGH A CONNECTION TO THE PARKING BRAKE.
THE INSTALLER OF THIS PRODUCT MUST INSURE THE VIDEO DISABLE CONNECTION IS
WORKING PROPERLY PRIOR TO DELIVERY OF THE VEHICLE.
IMPROPER INSTALLATION COULD DISTRACT THE DRIVER OR INTERFERE WITH SAFE OPERATION
OF THE VEHICLE, WHICH COULD RESULT IN SERIOUS INJURY OR DEATH, AND COULD ALSO
VIOLATE STATE AND/OR FEDERAL LAW.
CARSHOW DISCLAIMS ANY LIABILITY FOR ANY BODILY INJURY OR PROPERTY DAMAGE THAT MAY
RESULT FROM ANY IMPROPER OR UNINTENDED INSTALLATION AND/OR USE.
STOP
Damage to the vehicle may occur
Do not proceed until process has been completed
CAUTION
CAUTION
Process must be carefully observed in order to reduce
the risk of damage to the accessory or vehicle
CRITICAL
Process must be carefully observed in order to ensure a
quality installation
TOOLS and EQUIPMENT
Specific tools and equipment recommended for this
process
SAFETY RISK
Observe safe practices, this process can be dangerous
and there is a risk of personal injury
TESTING and TROUBLESHOOTING
Content specific testing and troubleshooting points
CS-HY1120 Hyundai Sonata Installation Guide

CarShow Installation Guide
CarShow Copyright 2012 All Rights Reserved
Installation Guide CS-HY1124 Rev A
Page 2
PREPARING FOR THE INSTALLATION
Before you start, please read these critical steps below STEP
1
BEFORE YOU START THE
INSTALLATION,
READ THIS GUIDE!
CHECK THE BATTERY
Test the battery voltage to make sure it’s fully charged to
a minimum of 12.8 VDC
This only takes seconds and can save hours of
troubleshooting later.
TURN THE VEHICLE
OFF
Keep the Vehicle Off during the installation to avoid
setting various Vehicle Fault sensors
Keep the Vehicle OFF during the
installation
Failure to follow this may cause the AIRBAG FAULT
SENSOR to become enabled. Dealer Service
Departments charge a significant fee to reset the Fault
Sensor.

CarShow Installation Guide
CarShow Copyright 2012 All Rights Reserved
Installation Guide CS-HY1124 Rev A
Page 3
REMOVE THE FACTORY RADIO
You will need to remove multiple interior trim components prior to removing the factory radio.
The following steps will help guide you through this process.
STEP
2
Remove Lower Right Dash Trim
Carefully remove lower right side dash trim
Remove Lower Left Dash Trim
Carefully remove lower left side dash trim
Remove Phillips Screws
Carefully remove 2 x phillips (1-left & 1-right)screws to
release dash
Remove Radio Dash Trim
Carefully remove radio dash trim. Be sure to use proper
equipment and carefully pry on instructed area.
CAUTION
CAUTION
CAUTION

CarShow Installation Guide
CarShow Copyright 2012 All Rights Reserved
Installation Guide CS-HY1124 Rev A
Page 4
Remove Radio Dash Trim
Carefully remove radio dash trim. Be sure to use proper
equipment and carefully pry on instructed area.
Remove Radio Dash Trim
Carefully remove radio dash trim. Be sure to use proper
equipment and carefully pry on instructed area.
Remove Radio Dash Trim
Carefully remove radio dash trim. Be sure to use proper
equipment and carefully pry on instructed area.
Remove Radio Mounting Screws
Carefully remove 4 x phillips radio mounting screws
CAUTION
CAUTION
CAUTION

CarShow Installation Guide
CarShow Copyright 2012 All Rights Reserved
Installation Guide CS-HY1124 Rev A
Page 5
LOCATING REMOTE COMPONENTS
You will need to mount the GPS and Optional Satellite Radio Antennas on the exterior of the vehicle.
And mount the iPod Interface Connector in the vehicle. The following steps will help guide you
through this process.
STEP
3
Use Caution around SRS Components
It is the installer’s responsibility to ensure that the safety
equipment in the vehicle is NOT adversely affected by
installation of this system. Ensure that the routing of the
harnesses do NOT obstruct airbags, SRS or other safety
devices.
Mount the GPS and Sat Radio antenna in
a location on the exterior of the Vehicle
Route the GPS harness away from other power harnesses in
the vehicle.
This will help to ensure optimum performance of the GPS
system.
“OPTIONAL”
Install the iPod interface connector in a
location accessible to the end-user
Locate the iPod interface module in an area which can be
serviced in the future.
The iPod cable is intended to be a serviceable item, which
plugs into the iPod/Sat radio Interface Module.
INSTALL THE CARSHOW NAVIGATION SYSTEM
You will need to prepare the CarShow Navigation System for installation in the vehicle. STEP
4
Remove the DVD Transport Screws
There are 2 x Phillips Transport Screws which protect the DVD
Mechanism during transportation.
Transport Screws must be removed prior to installation.

CarShow Installation Guide
CarShow Copyright 2012 All Rights Reserved
Installation Guide CS-HY1124 Rev A
Page 6
Connect the Power and GPS Harnesses
The GPS Harness must be tightened with a WRENCH to
ensure it is properly seated.
Be sure to use white cable clamp to secure GPS antenna cable
Failure to follow this step may result in poor GPS signal
Connect Optional Harnesses such as
iPod, Satellite Radio, Camera, Reverse
Sensors
These harnesses must be fully engaged prior to the system
installation.
See the Harness Diagrams for more information
Prepare the Vehicle side harnesses for
connection to the CarShow Harness
Use care not to pinch or damage cables as this will cause
performance issues/failures
CAUTION
Remove OEM Hazard Switch
Carefully remove OEM Hazard switch and relocate into
CarShow Dash Bezel
Remove OEM Climate Controls
Carefully remove OEM climate controls and relocate into
CarShow Dash Bezel
OEM Dash Bezel
OEM Dash Bezel shown at right with all OEM switches
removed
CAUTION
CAUTION

CarShow Installation Guide
CarShow Copyright 2012 All Rights Reserved
Installation Guide CS-HY1124 Rev A
Page 7
CarShow dash Bezel
CarShow Dash Bezel shown at right with all OEM
switches installed
Important Connections Part 1 of 9
Connect Passenger airbag/Seatbelt display into supplied
CarShow T-Harness shown at right.
(If not plugged in when starting vehicle, this might cause
error code.)
Important Connections Part 2 of 9
Connect Proper end of CarShow T-Harness into OEM
Airbag/Seatbelt display
(If not plugged in when starting vehicle, this might cause
error code.)
Important Connections Part 3 of 9
Locate supplied foam wrap
Important Connections Part 4 of 9
Carefully wrap OEM Airbag/Seatbelt display with
supplied foam
Important Connections Part 5 of 9
Peel back only enough white backing to adhere foam
CAUTION
CAUTION

CarShow Installation Guide
CarShow Copyright 2012 All Rights Reserved
Installation Guide CS-HY1124 Rev A
Page 8
Important Connections Part 6 of 9
Finished wrap shown at right
Important Connections Part 7 of 9
Carefully put airbag/seatbelt display into dash cavity
below passenger side ac vent.
Airbag/Seat display shown in BLUE at right
Important Connections Part 8 of 9
Connect proper harness to vehicle side of
airbag/seatbelt display connector
Important Connections Part 9 of 9
Connect proper connector from CarShow T-harness to
airbag/seatbelt indicator as shown at right
Install CarShow Unit
Install CarShow unit into dash and be sure to re-install all
mounting screws that were removed.
Install CarShow Dash
Install CarShow dash and be sure to connect all
harnesses
CAUTION
CAUTION
CAUTION

CarShow Installation Guide
CarShow Copyright 2012 All Rights Reserved
Installation Guide CS-HY1124 Rev A
Page 9
Install Complete
CarShow dash bezel shown installed at right
Turn the vehicle ON and confirm the unit
is fully operational
With the connectors Fully Engaged, turn the vehicle on
and press the RESET for 5 seconds on the unit.
Turn the vehicle ON and test OEM
Features
Test Emergency Lights, AC controls, and Passenger
Airbag/Seatbelt Display.
Insert a DVD to confirm the Video Disable
Circuit is properly Operating.
The Brake Wire must be connected to the Park Brake
Indicator Wire to complete a ground when the brake is
engaged.
RE-INSTALL THE TRIM COMPONENTS
You will need to reinstall all trim components
STEP
5
Re-install Lower Left/Right Dash Trim
Carefully re-install lower left/right side dash trim
CAUTION

CarShow Installation Guide
CarShow Copyright 2012 All Rights Reserved
Installation Guide CS-HY1124 Rev A
Page 10
ENABLE INSTALLER SETTINGS
You will need to select certain Installer Setting based on any Optional Equipment that you may have
installed
STEP
6
Launch the Installer Setting Screen
From any screen with the Menu Button, follow these
steps to display the Installer Setting Screen, select:
1) From any Screen, select “Menu”
2) From the Menu Screen, select “Settings”
3) Press “Keypad,” Press “7253” and “Enter”
Select the individual Settings as needed
for the installed components
Selectable options vary by product and installation.
Select the options as applicable for the installed optional
components.
Perform Pre-Delivery Tests
You will need to perform several Pre-Delivery Tests to ensure customer satisfaction
Some optional equipment may not be applicable
STEP
7
Turn the vehicle ON and System ON
Confirm the unit starts up properly
Troubleshooting
1) Reset the System while the Vehicle is ON
2) Confirm all connectors are properly installed
3) Check the Vehicle and System Fuses
Select RADIO as the Source
Confirm that the AM and FM reception are as expected
Troubleshooting
1) Confirm Antenna is properly connected.
2) Reset the System

CarShow Installation Guide
CarShow Copyright 2012 All Rights Reserved
Installation Guide CS-HY1124 Rev A
Page 11
Select SATELLITE RADIO as the Source
Confirm Channel 001 is present after ~5 minutes
Troubleshooting
1) Confirm the SAT Radio is Turned ON in the Installer
Settings
2) Confirm the antenna has unobstructed view of the Sky
3) Confirm the antenna is located on the outside of the
vehicle
Select iPOD as the Source
Confirm iPod is communicating and playback is OK
Troubleshooting
1) Confirm iPod Version Compatibility – not all are compatible
2) Confirm the harnesses are properly engaged
3) Reset the System
Select CD as the Source
Confirm CD audio playback is OK
Troubleshooting
1) Confirm the Disc is Store Bought and in good condition
2) Reset the system
Select DVD as the Source
Confirm DVD video playback is OK
Troubleshooting
1) Ensure the Park Brake is set to view video
2) Confirm the Disc is Store Bought and in good condition
3) Reset the system
Select MP3 as the Source
Confirm MP3 playback is OK – Select Favorites
Troubleshooting
1) Confirm that a Test Track exists in the Favorites Folder
2) Reset the system
Select Phone as the Source
Confirm Phone Pairing is successful
Troubleshooting
1) Confirm the Phone has BT and is in discoverable mode
2) Confirm the Phone is compatible with the system
3) Reset the system

CarShow Installation Guide
CarShow Copyright 2012 All Rights Reserved
Installation Guide CS-HY1124 Rev A
Page 12
Select NAV as the Source
Confirm the Navigation loads and signal strength is OK
Troubleshooting
1) Confirm the antenna has an unobstructed view of the sky
2) Confirm the antenna is located on the outside of the
vehicle
3) Confirm the antenna connection is properly tightened
Select Reverse Camera
Confirm the backup camera screen shows in reverse
Troubleshooting
1) Confirm the Camera is set to ON in the Installer Settings
2) Confirm the Reverse Trigger wire is attached properly
3) Confirm the Camera is receiving 12VDC as required
Main Harness Diagram

CarShow Installation Guide
CarShow Copyright 2012 All Rights Reserved
Installation Guide CS-HY1124 Rev A
Page 13
Optional Harness Diagram

CarShow Installation Guide
CarShow Copyright 2012 All Rights Reserved
Installation Guide CS-HY1124 Rev A
Page 14
Option Harness Diagram
www.CarShowElectronics.com
