I.D. AL NanoPlayer box User manual

® Waves System - La Ville en Bois - 44830 BOUAYE - FRANCE - Tel : [phone] - www.id-al.com
I.D.AL - NanoPlayer box - Interactive amplied MP3/Wav audio player - Quick start guide
NanoPlayer box - Quick start guide
(firmware v2.x )
1 - Connections
2 - Operating the NanoPlayer box
Files are organized into two folders ; folder names are composed of 3 digits:
Folder 0 contains the les to be read on powering on and played back in loop
Folder 1 contains the les to be read when the input contact is triggered
Naming of the folders - composed of 3 characters
● Main/Autoplay folder «0xy»
0xy : Folder 0 is the default directory, automatically read when the player is powered on
x = playback mode :
0Ry : R for random mode (RND) - All the les of the folder are read randomly
0Sy : S for sort mode, i.e. playback in a dened order (SORT) - All the les of the folder are read in a sequenced order
y = Contact input mode
0x0 : The trigger contact input play the folder «1xy» (see below)
0x1 : The trigger contact input play next le in the folder «0xy» (no need of the 1xy folder)
The 4 possibities are : 0R0 / 0S0 / 0R1 / 0S1
0R0 ou 0S0 -> Trigger = Play folder 1xx
0R1 ou 0S1 -> Trigger = Play next le in the current folder
● Folder «1xy» is read when the input contact is triggered with the case 0R0 or 0S0
1xy : Folder 1 has 4 playback modes when a contact is detected on the input
x = playback mode :
1Ry : R for random mode (RND) - All the les of the folder are read randomly
1Sy : S for sort mode, i.e. playback in a dened order (SORT) - All the les of the folder are read in a sequenced order
1Ny : N Read one le only - On each trigger input contact, the next le (and only this one) is read in random mode
1Ty : T Read one le only - On each trigger input contact, the next le (and only this one) is read in a dened order mode
y = trigger activation mode
1x0 : The trigger folder is launched by an impulse in Non re-activation mode, a new impulse has no effect
1x1 : The trigger folder is launched by an impulse in Re-activation mode, a new impulse stops current playback to broadcast a new le.
1x2 : The trigger folder is read as long as the input contact is activated. Playback PAUSE when the contact is released
1x3 : The trigger folder is read as long as the input contact is activated. A new contact read from the begining.
Possibilties are : 1R0 / 1R1 / 1R2 / 1R3 / 1S0 / 1S1 / 1S2 / 1S3 / 1N0 / 1N1 / 1N2 / 1N3 / 1T0 / 1T1 / 1T2 / 1T3
Naming of the audio les included in the folders
● In random mode, naming of les is free. Only the extension is meaningful: name.mp3 for MP3 les or name.wav for WAVE les
● In sequential mode, i.e. in ordered playback mode, le names must include 3 gures to dene the sequence number of the le.
Example : «001.mp3» or «999.mp3» or «001.wav» or «099.wav»
Memory card :
We recommand the use of a quality
SD/SDHC card of a minimum size
of 64Mo.
A brand new card is usually pre-
formatted in «FAT». It is also possible
to use format FAT32 for cards over
512Mo capacity.
The SD/SDHC card must only be
inserted or removed whilst the
NanoPlayer is NOT POWERED ON.
Download complete
manual from web site
www.id-al.com
Files compatibility :
• Stereo MP3 les, 44.1KHz, from
32kbit/s to 128kbits/s (CBR and VBR)
• Stereo Wav les, 44.1kHz, 16 bits Power supply
12V - DC
-
+
85 7
6
34
1
9
2
In
G
1 - Volume settting + trigger
2 - Luminous indicator
3 - Headphone output
4 - Infrared sensor
5 - Power supply socket
6 - Audio output on line level
7 - Trigger input on dry contact
8 - Amplied audio output
9 - SD card connector
GND / In / V+

® Waves System - La Ville en Bois - 44830 BOUAYE - FRANCE - Tel : [phone] - www.id-al.com
I.D.AL - NanoPlayer box - Interactive amplied MP3/Wav audio player - Quick start guide
NanoPlayer box - Quick start guide
Connections
12v power supply
Trigger input internal schematic
Speakers
Amplier
In
G
Trigger input
Remote
control option
Headphone
Speakers
L+ / L-R- / R+
1 2
Cables are wired on the
removable part of the
connector
