I-Tech HNP717 User manual

DedicatedKVMswitchandrackmountscreentechnology
UserManual 17”/ 19”HighBrightnessLCD1000cd/m2
HNP717/HNP819
RackmountDisplayPanel
Options:
-SDI/ MCS
-AV/ HDMI/ Audio
-Touchscreen/ DCpower
-MIL-typeorlockableconnector
F©C€k/ REACH
i-Tech CompanyLLC
TOLL FREE: [phone]• EMAIL:[email protected]m• WEB:www.iTechLCD.com

LegalInformation
FirstEnglishprinting,October2002
Informationinthisdocumenthasbeencarefullycheckedforaccuracy;however,noguaranteeisgiventothecorrectness
ofthecontents.Theinformationinthisdocumentissubjecttochangewithoutnotice.Wearenotliableforanyinjuryor
lossthatresultsfromtheuseofthisequipment.
SafetyInstructions
Pleasereadalloftheseinstructionscarefullybeforeyouusethedevice.Savethismanualfor
futurereference.
■Unplugequipmentbeforecleaning.Don'tuseliquidorspraydetergent;usea moistcloth.
■Keepequipmentawayfromexcessivehumidityandheat.Preferably,keepitinanair-conditionedenvironmentwith
temperaturesnotexceeding40°Celsius(104°Fahrenheit).
■Wheninstalling,placetheequipmentona sturdy,levelsurfacetopreventitfromaccidentallyfallingandcausing
damagetootherequipmentorinjurytopersonsnearby.
■Whentheequipmentisinanopenposition,donotcover,blockorinanywayobstructthegapbetweenitandthe
powersupply.Properairconvectionisnecessarytokeepitfromoverheating.
■Arrangetheequipment'spowercordinsucha waythatotherswon'ttriporfalloverit.
■Ifyouareusinga powercordthatdidn'tshipwiththeequipment,ensurethatitisratedforthevoltageandcurrent
labeledontheequipment'selectricalratingslabel.Thevoltageratingonthecordshouldbehigherthantheonelisted
ontheequipment'sratingslabel.
■Observeallprecautionsandwarningsattachedtotheequipment.
■Ifyoudon'tintendonusingtheequipmentfora longtime,disconnectitfromthepoweroutlettopreventbeing
damagedbytransientover-voltage.
■Keepallliquidsawayfromtheequipmenttominimizetheriskofaccidentalspillage.Liquidspilledontothepower
supplyoronotherhardwaremaycausedamage,fireorelectricalshock.
■Onlyqualifiedservicepersonnelshouldopenthechassis.Openingityourselfcoulddamagetheequipmentand
invalidateitswarranty.
■Ifanypartoftheequipmentbecomesdamagedorstopsfunctioning,haveitcheckedbyqualifiedservicepersonnel.
Whatthewarrantydoesnotcover
■Anyproduct,onwhichtheserialnumberhasbeendefaced,modifiedorremoved.
■Damage,deteriorationormalfunctionresultingfrom:
DAccident,misuse,neglect,fire,water,lightning,orotheractsofnature,unauthorizedproductmodification,or
failuretofollowinstructionssuppliedwiththeproduct.
□Repairorattemptedrepairbyanyonenotauthorizedbyus.
□Anydamageoftheproductduetoshipment.
□Removalorinstallationoftheproduct.
□Causesexternaltotheproduct,suchaselectricpowerfluctuationorfailure.
□Useofsuppliesorpartsnotmeetingourspecifications.
□Normalwearandtear.
□Anyothercauseswhichdoesnotrelatetoa productdefect.
■Removal,installation,andset-upservicecharges.
RegulatoryNoticesFederalCommunicationsCommission(FCC)
Thisequipmenthasbeentestedandfoundtocomplywiththelimitsfora ClassB digitaldevice,pursuanttoPart15of
theFCCrules.Theselimitsaredesignedtoprovidereasonableprotectionagainstharmfulinterferenceina residential
installation.
Anychangesormodificationsmadetothisequipmentmayvoidtheuser'sauthoritytooperatethisequipment.This
equipmentgenerates,uses,andcanradiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththe
instructions,maycauseharmfulinterferencetoradiocommunications.
However,thereisnoguaranteethatinterferencewillnotoccurina particularinstallation.Ifthisequipmentdoescause
harmfulinterferencetoradioortelevisionreception,whichcanbedeterminedbyturningtheequipmentoffandon,the
userisencouragedtotrytocorrecttheinterferencebyoneormoreofthefollowingmeasures:
■Re-positionorrelocatethereceivingantenna.
■Increasetheseparationbetweentheequipmentandreceiver.
■Connecttheequipmentintoanoutletona circuitdifferentfromthattowhichthereceiverisconnected.

Contents
>HNP717/HNP819
PackageContentP.1
StructureDiagram& DimensionP.1
InstallationP.4
>Specifications/ OSD/ RemoteController
ProductSpecificationsP.5
On-screenDisplayOperation( OSD) P.7
>Options
3G/HD/SD-SDIBroadcast-gradeinputP.9
MCSMulti-displaycontrolsolution P. 10
AV2.2DUpgrade: DVI-D+ VGA+ BNC+ S-Video+Audio P. 11
AV2.2HUpgrade: HDMI+ VGA+ BNC+ S-Video+AudioP.11
AV3.0Upgrade: P. 12
DVI-D+ VGA+ HDMI+ BNC+ S-Video+ Audio
H17" / H19"Touchscreen: Resistive,CapacitiveP.13
48V,24Vor12VDCpower P. 14
MIL-typeorlockableconnectorP.15

BeforeInstallation
■Itisveryimportanttomounttheequipmentina suitablecabinetorona stablesurface.
■Makesuretheplacehasa goodventilation,isoutofdirectsunlight,awayfromsourcesofexcessive
dust,dirt,heat,water,moistureandvibration.
Unpacking
Theequipmentcomeswiththestandardpartsshowninpackagecontent.Checkandmakesuretheyare
includedandingoodcondition.Ifanythingismissing,ordamaged,contactthesupplierimmediately.
HowToCleanYourLCDMonitor
4kCaution:
■Toavoidtheriskofelectricshock,makesureyourhandsaredrybeforeunpluggingyourmonitorfromor
pluggingyourmonitorintoanelectricaloutlet.
■Whenyoucleanyourmonitor,donotpressdownontheLCDscreen.Pressingdownonthescreencan
scratchordamageyourdisplay.Pressuredamageisnotcoveredunderwarranty.
■Useonlycleansersmadespecificallyforcleaningmonitorsandmonitorscreens.Cleansersnotmadeto
cleanmonitorsandmonitorscreenscanscratchtheLCDdisplayorstripoffthefinish.
■Donotsprayanykindofliquiddirectlyontothescreenorcaseofyourmonitor.Sprayingliquidsdirectly
ontothescreenorcasecancausedamage whichisnotcoveredunderwarranty.
■Donotusepapertowelsorabrasivepadstocleanyourmonitor.Usinganabrasivepadoranywoodbased
paperproductsuchaspapertowelscanscratchyourLCDscreen.
CleaningYourMonitor
TocleanyourLCDsafely,pleasefollowthesesteps:
®Disconnectthepower cord.
®Gentlywipethesurfaceusinga clean,drymicrofibercloth.Useaslittlepressureaspossible.
CleaningToughMarksandSmudges
Toremovetoughmarksandsmudges,pleasefollowthesesteps:
©Disconnectthepower cord.
©Spraya smallamountofnon-abrasivecleanserona microfibercloth.
^^Caution: Donotsprayorapplyanyliquidsdirectlyontothemonitor.Alwaysapplythesolutiontoyour
•*microfiberclothfirst,notdirectlyonthepartsyouarecleaning.
®Gentlywipethesurface.Useaslittlepressureaspossible.
®Waituntilyourmonitoriscompletelydrybeforepluggingitinandpoweringitup.

<Part1 >
<1.1> PackageContent
HNP717/HNP819X1
6ftVGAcableX1
PoweradapterX1
PowercordX1
<1.2> StructureDiagram
Frontview
A
o
o||
o A a o o
o||
HNP717 ■
<
V
A HNP819|H
&
o
o||
HNP717
6
IIo
%9
A
S
e
IIo
w uII
S
e
IIo
Rearview Poweradapter
0LCDpanel
@LCDmembrane
(DAudiospeaker
(5)Poweradapterbasket
Powercord
DVI-D Audio
0O O O
out- in- in
VideoPC
PowerBNCS-VideoVGA
©© © c|5x?|o
HDMI
BasicI/O
AV2.2Dupgrade
AV2.2Hupgrade
AV3.0upgrade
Options
DVI-D+ VGA
DVI-D+ VGA+ BNC+ S-Video+ audio
HDMI+ VGA+ BNC+ S-Video+ audio
HDMI+ DVI-D+ VGA+ BNC+ S-Video+ audio
USBfortouchscreen& DCpower
SDI(AV3.0upgraderequired)
P.1

<1.2> Dimension- HNP717
FrontView SideView
o
oII
II
HNP717g
OJ
340
o
II
A
V
<
>
A
in
CO
OJ
o
CO
o
oII
II II°
II
463
480
-^^-
BottomView UNIT:mm
1mm= 0.03937 inch
480
OQ®OoooJ fe
440
Model ProductDimension
(Wx D x H) PackingDimension
(Wx D x H) Net
Weight Gross Weight
HNP717 480x54.2x310mm
18.9x2.1x12.2inch 529x124x495mm
20.8x4.9x19.5inch 6kg
13lbs 8.5kg 19lbs
P.2

< 1.2> Dimension - HNP819
FrontView SideView
o
° II
HNP819 o
CO
379
c
©
•
©
©
©
e
!!c
o
° II
HNP819 o
CO
379
c
©
•
©
©
©
e
!!c
o>
OJ
5
00
in
CO
o
° II
c
©
•
©
©
©
e
!!c
o>
OJ
5
00
in
CO
463
480
CO
ON
co
BottomView UNIT:
mm
1mm = 0.03937 inch
480
C2^ O © ° ®o®
J fe
440,6
CO
CO
in
Model ProductDimension
(W x D x H)
PackingDimension
(W x D x H)
Net
Weight Gross Weight
HNP819
480x53.3x354.8 mm
18.9x2.1 x 14 inch
539 x129 x529 mm
21.2x5.1x20.8inch 6.5
kg
14 lbs
9 kg
20 lbs
P.3

<1.3> Installation
StepO
■MountthedisplaypanelwithM6screwset.
■M6screwx 4 pcsrequired( Left& rightside).
M6screwsetsarenotprovided.
StepO
FixtheLCDintotherack.
P.4

<Part2 >
<2.1> ProductSpecifications
HNP717 HNP819
PanelSize( diagonal) 17-inchTFTcolorLCD 19-inchTFTcolorLCD
Displaypixel( dotsx lines) 1280x1024 1280x1024
Brightness(typ.) 1000 1000
ContrastRatio(typ.) 1000:1 1000:1
Color 16.7M 16.7M
ViewingAngle(L/R/U/D) 85/85/80/80 80/80/80/80
ResponseTime( ms) 5 5
Dotpitch( mm)
0.264 0.294
DisplayArea( mm) 337.92Hx 270.33V 376.32Hx301.05V
Surfacetreatment Anti-glare Haze25%,Hard-coating
Surfacehardness 3H 3H
BacklightType LED LED
MTBF( hrs) 50,000 50,000
Video
Connectivity Digital HDMI HDMI
1.1.CEA-861-D
DVI
DVI-D, TMDSsinglelink
Analog VGA Analog
0.7Vp-p
Composite( BNC) NTSC& PAL
S-Video (4-pin) NTSC& PAL
Plug& Play DVI/ VGA VESAEDIDstructure1.3
Synchronization VGA Separate,Composite& SOG
Audio
Connectivity AudioInput Connector
3.5mm stereojack
AudioInput Impedance/ Powerlevel 30kO/ 750mV
AudioOutput Connector
3.5mm stereojack
AudioOutput
Resistance/ Powerlevel 30kQ/ 2.8V
SpeakerOutput Power 2x2W
"Whentheaudiooutputisconnected,speakeroutputisOFF
PowerSupply Range Auto-sensing100to240VAC,
50/ 60Hz
PowerConsumption ScreendisplayON 35Worless PowerConsumption
Powersavingmode 4Worless
PowerConsumption
PowerbuttonOFF 1Worless
Regulatory Safety FCC& CEcertified
Environmental RoHS2& REACHcompliant
R5

Operating Temperature 0 to50°CdegreeOperating Humidity
20-90%, non-condensing
Storage Temperature -5to60°Cdegree Storage
Humidity 5-90%,non-condensing
Storage
Shock 10Gacceleration(11msduration)
Storage
Vibration 5-500Hz 1GRMSrandom
HNP717 HNP819
Product( W x D x H) 480x54.2x310mm
18.9x2.1x 12.2inch 480x 53.3x 354.8mm 18.9x2.1x 14inch
Packing(WxDxH) 529x 124x495mm
20.8x 4.9x 19.5inch 539x 129x529mm 21.2x5.1x 20.8inch
NetWeight 6kgs/13lbs 6.5kgs/14lbs
GrossWeight 8.5kgs/19lbs 9kgs/ 20lbs
DVI-D/VGAInput PCSignal 1280x 1024x 60/ 75HzDVI-D/VGAInput PCSignal 1280x960x60Hz DVI-D/VGAInput PCSignal
1280x760x60/75Hz
DVI-D/VGAInput PCSignal
1152x864x75Hz
DVI-D/VGAInput PCSignal
1024x768x60/70/75Hz
DVI-D/VGAInput PCSignal
848x 480x 60Hz
DVI-D/VGAInput PCSignal
800x 600x 60/ 72/ 75Hz
DVI-D/VGAInput PCSignal
720x 400x 70Hz
DVI-D/VGAInput PCSignal
640x 480x 60/ 72/ 75Hz
DVI-D/VGAInput PCSignal
640x 400x 70Hz
DVI-D/VGAInput PCSignal
640x 350x 70Hz
P.6

<2.2> On-screenDisplayOperation( OSD)
HNP819
OPowerlight
•Green= On
•Orange= Powersaving
MembraneSwitch
•©<►♦*♦
Function
e Poweron/ offLCD
DisplaytheOSDmenu
«>«»#€> Scrollsthroughmenuoptionsandadjuststhedisplayedcontrol
(Toautoadjustmentbypressingthebutton<§> for5 seconds)
if*
ExittheOSDscreen
Toggleanalog,digital& videoconnection(DVI-Dandvideooptionsonly)
HNP717
i= t>
MembraneSwitch Function
6 Turnthemonitoronoroff
DCZI
Dl=l
DCZI DisplaytheOSDmenu
ActasanEnterkeytoselectscreensettingoptions
AV < > Scrollthroughmenuoptionsandadjust
thedisplayedcontrol
^ ExittheOSDscreen
Gobacktothepreviouson-screensub-menuor
mainmenu
Remark : AllLEDtouchbuttonsinWHITElight.
TheLEDofPower(§)touchbuttonwillflashcontinuouslywhenthereisnosignalinput.
(T)AlltheLEDtouchbuttonswillautomaticallyturnoffafter10minutesofidlestatus( exceptthePower© ).
©Lightupallmembranebuttons,pleasepressanybuttonfor 1 - 2 seconds( exceptthePower@ ).
P.7

<2.2> On-screenDisplayOperation( OSD)
OSDConfigurationPage
Ver:G56SN20SSTD701 1024x76859.8Hz
Mi
Brightness[1
ContrastJ
ColorTempUser
RedI^^M
Green[I
BlueJ
Adjust: Select:♦+Set:®/i=i
m Image:
forthebrightness,contrast,color temp, red,green,andblue
Geometry:
fortheautoadjust,H position,V position,phaseandclock
to- Video:
forthecolour,tint,sharpness,noisereduction,DCDiandTVSetup
J>
Audio:
forvolume,bass,treble,balance,AVLandmute
Misc Misc:
forthelanguage,OSDposition,graphicmode,ratio,resetandtimer
]50
]50
0255
Q255
Q255
Exit:t
P.8

<Part3 >
<3.1> Options: 3G/ HD/ SD-SDIinput
iTechLCDs'SDIinputisanidealsolutionforthebroadcast-
gradevideoandhighresolutionCCTVmarket.
DesignedforusewithNetViewFullHD1080pandultrahigh
resolution1920x 1200LCDdisplays,iTechLCDprovidesa
SDIinputmodulewithoutusingadditionalspaceorpowerandit
comesstandardwitha 2-yearwarranty.
SDI
DVI-D Audio
i1
oo o
out- in- in
VideoPC
|°lHfflJoj
Audio
i1
oo o
out- in- in
VideoPC
PowerBNCS-VideoVGA ©
out © -in
HDMI
0© © cp^Jp ©
out © -in P=^fl
ForSDIoption,theADboardwillbeupgradedto AV3.0, andthiscomesstandardwith HDMI, DVI-D,
VGA,S-Video,BNCandaudioinputs.
3G-SDIIN
3G-SDIOUT BNCxI/0.8Vp-p(75ohm) BNCx 1 /Activethrough,equalized& relocked
StandardCompliance Video SMPTE425M/ 274M/ 296M/ 125M
ITU-RBT.656
StandardCompliance
Audio SMPTE299M/ 272M-C
CompatibleVideoFormat 3G-SDI 1080p
1080p
1080i
720p
@60/50Hz,4:2:2
@30/ 25/24Hz,4:4:4
@60/ 50Hz,4:4:4
@60/50Hz,4:4:4
CompatibleVideoFormat
HD-SDI 1080p
1080i
720p
@30/ 25/24Hz,4:2:2
@60/50Hz,4:2:2
@60/50Hz,4:2:2
CompatibleVideoFormat
SD-SDI 480i @60Hz,4:2:2
CompatibleVideoFormat
ITU-RBT.656 576i @50Hz,4:2:2
CompatibleAudioFormat 3G-SDI 48kHz,16/ 20/ 24bit,2 CH,SynchronizedVideo CompatibleAudioFormat
HD-SDI 48kHz,16/ 20/ 24bit,2 CH,SynchronizedVideo
CompatibleAudioFormat
SD-SDI 48kHz,16/ 20/ 24bit,2 CH,Synchronized/
AsynchronizedVideo
Max.TransmissionDistance
75ohmcoaxialcable 3G-SDI 150mat2.97Gb/s
Max.TransmissionDistance
75ohmcoaxialcable HD-SDI 250mat1.485Gb/s
Max.TransmissionDistance
75ohmcoaxialcable
SD-SDI 480mat270Mb/s
P.9

<3.2> Options: MCS
(Multi-displayControl) Morecontrolisalwaysgood.Especiallywhenitisnecessaryand
easy.iTechLCDprovidesMCSsolutiontocontroltheOSDof
variousNetViewLCDdisplayupto64units.
TheRS-232CisusedforthecommunicationbetweenthePCandthe
firstdisplayviaa 15feetserialcablewhiletheCANbusisusedforthe
variousLCDdisplayscascadetogetherviaCAT5/6cable,anddaisy
chainupto1,000meters.
DesignedforusewithNetViewLCDdisplays,iTechLCD
providesa MCSinputmodulewithoutusingadditionalspaceorpower
anditcomesstandardwitha 2-yearwarranty.
HDMI Audio
p0Wer BNCS-Video
1
OO O 0
nil it_ in_ in^-"^
\
1
out- in- in
VideoPC MCS
VGA DVI-D setout in Link
PleasedownloadtheprotocolofMCScontrol
ForMCSoption,casingdepthwillbechanged.
RS-232C
15feetserialcable
(over15feet,extenderrequired)
B
Setswitch
Forthe1standlastdisplay,
pushthesetswitchupward
Forotherdaisychaindisplays,
pushthesetswitchdownward.
inm
LINK
RJ-45jack
OUTIN
OUTIN OUTIN OUT
I t
!I
I t
Cat5/ 6 cable Cat5/ 6 cable Cat5/ 6 cable
max.300meters max.300meters max.300meters
Daisychainupto1,000 up to t 64displays
metersand64displays
P.10

< 3.3> AV2.2DUpgradeOptions :
-DVI-D(DVI-DTMDSsinglelink)
- AV( S-Video + Composite,BNC )
-Audio ( 3.5mmaudiojacks for audio in& out,and 2W+2W speakers )
DVI-D ,
Aud'°
, Power BNC S-Video VGA
c&b
l°n~s]°] O O O C% (8)fft
out- in- in^ ^=^^^> j
Video PC
< 3.4> AV2.2HUpgradeOptions :
-HDMI ( HDMI1.1,CEA-861-D )
- AV( S-Video + Composite,BNC )
-Audio ( 3.5mmaudiojacks for audio in& out,and 2W+2W speakers )
,Aud'° , Power BNC S-Video VGA HDMI
00 0 © 0 © ejSb
s
nut-in-in^^^=^ ^e^11A [i-——wj
out- in- in'^^^ ^^ "fci'"I']l
Video PC
P.11

<3.5> AV3.0UpgradeOptions:
-HDMI( HDMI1.1,CEA-861-D)
-DVI-D( DVI-DTMDSsinglelink)
-AV( S-Video+ Composite,BNC)
-Audio( 3.5mmaudiojacksforaudioin& out,and2W+ 2Wspeakers)
DVI-D, , PowerBNCS-VideoVGA
[°rjm°lO O O fS © fl£| J*^h
out- in- in^ ^=^^^\, j-
VideoPC
HDMI
P.12

<3.6> Options: Touchscreen& driver0^
H17" / H19"USBTouchscreenSpecification
Model
Technology
TouchPoint
Method
ActivationForce
Durability
ResponseTime
OpticalTransmittance
SurfaceHardness
Haze
Glass
Connector
Compatibility
17' 19"
17" 19"
Model
Technology
TouchPoint
Method
ActivationForce
Durability
ResponseTime
OpticalTransmittance
SurfaceHardness
Haze
Glass
Connector
Compatibility
TRB e-Resistive TCB e-Capacitive
Model
Technology
TouchPoint
Method
ActivationForce
Durability
ResponseTime
OpticalTransmittance
SurfaceHardness
Haze
Glass
Connector
Compatibility
5-Wire Resistive Capacitive
Model
Technology
TouchPoint
Method
ActivationForce
Durability
ResponseTime
OpticalTransmittance
SurfaceHardness
Haze
Glass
Connector
Compatibility
Single Single
Model
Technology
TouchPoint
Method
ActivationForce
Durability
ResponseTime
OpticalTransmittance
SurfaceHardness
Haze
Glass
Connector
Compatibility
Stylus or Finger Finger
Model
Technology
TouchPoint
Method
ActivationForce
Durability
ResponseTime
OpticalTransmittance
SurfaceHardness
Haze
Glass
Connector
Compatibility
<50g/Stylus=R0.8 <50g
Model
Technology
TouchPoint
Method
ActivationForce
Durability
ResponseTime
OpticalTransmittance
SurfaceHardness
Haze
Glass
Connector
Compatibility
35milliontouches 300milliontouches
Model
Technology
TouchPoint
Method
ActivationForce
Durability
ResponseTime
OpticalTransmittance
SurfaceHardness
Haze
Glass
Connector
Compatibility
15 ms 20 ms
Model
Technology
TouchPoint
Method
ActivationForce
Durability
ResponseTime
OpticalTransmittance
SurfaceHardness
Haze
Glass
Connector
Compatibility
80% ± 3% 93% ±2%
Model
Technology
TouchPoint
Method
ActivationForce
Durability
ResponseTime
OpticalTransmittance
SurfaceHardness
Haze
Glass
Connector
Compatibility
3H 9H
Model
Technology
TouchPoint
Method
ActivationForce
Durability
ResponseTime
OpticalTransmittance
SurfaceHardness
Haze
Glass
Connector
Compatibility
8% ± 3% 7%
Model
Technology
TouchPoint
Method
ActivationForce
Durability
ResponseTime
OpticalTransmittance
SurfaceHardness
Haze
Glass
Connector
Compatibility
1.4 ±0.2 mm 3.2±0.2 mm 2.8mm±10% 2.8mm±10%
Model
Technology
TouchPoint
Method
ActivationForce
Durability
ResponseTime
OpticalTransmittance
SurfaceHardness
Haze
Glass
Connector
Compatibility USBType
A USBType A
Model
Technology
TouchPoint
Method
ActivationForce
Durability
ResponseTime
OpticalTransmittance
SurfaceHardness
Haze
Glass
Connector
Compatibility Windows
7/ XP/ Vista,Linux Windows 7/ XP / Vista,Linux
USBtouchscreenpackageincludes 1 x 6ft USBcable,quickreferenceguidelineand CD disc
Fordetailedinformation,pleasereferto the attached CD disc
As the touchscreenunit isnot made of toughenedglass,pleasehandle it carefully
USBTouchscreen
DVI-D Power
0
VGA
Irxxxil [°lHH)°]
Power
0
VGA
Pleasefollow the belowsteps to setup the touchscreen
Step1.Run the bundled CD disc or download the driver
Step 2. Doubleclick the Setup.exe
Step 3. Followtheinstallationinstruction to finish the setup
Step4.Afterinstallation,run the TouchKitprogram & the"4 pointcalibration"
Please dothe initialcalibration
afterthefirstsetup
E
T^u^KKit
P.13

+-
<3.7> Options: DCPoweropiTelo
Model 24V 48V
Inputrating
Inputvoltage: 24-Volt 48-Volt
Inputrange: 18-36V 36- 75V
Inputcurrent
-Noload 50mA 50mA
-Fullload 4880 mA 2442mA
Outputrating
Outputvoltage: 12-Volt 12-Volt
Outputcurrent: 8.3A 8.3A
Efficiency
85%
86%
P.14

<3.8> Options: MIL-typeorLockableConnector
Input Partno. MILStandard
MIL-type
Connector DCPower***
(Male) MS3470W8-33Pffltf)
MIL-DTL-26482MIL-type
Connector
VGA***
(Male) MS3470W14-15P^^tf)
MIL-DTL-26482
VGA***
(Male) MS3470W14-15P^^tf)
MIL-DTL-26482
ThereareseveraladditionalMILDCandVGAconnectortypeswithvaryingdesign
characteristicstomeetcostconsiderationsandtoprovideuserswiththemost
designflexibilitypossible.Formoreinformation,pleasecontactus.
Input Partno. Standard
Lockable
Connector DCPower (Male) YM-Ext-461CP001 ^0
D-type 3W3
Lockable
Connector
USB LUSB-A111-00 USB LUSB-A111-00
MIL- typeorLockableconnectorsabovecanbeintegratedwithourLCDdisplays.
Saleservicejustforconnectorsnotprovided.
P.15

I-TECH
COMPANV
i-Tech CompanyLLC
TOLLFREE:[phone]• EMAIL:[email protected]m WEB: www.iTechLCD.com
