Advantech IDK-1115WP-45FHA1 User manual

User Manual
IDK-1115WP-50HDA1E
IDK-1115WP-45FHA1
15.6” WXGA/FHD Industrial
Display Kit with Projected
Capacitive Touch Solution

IDK-1115WP User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2020
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. Information provided in this manual is intended to be accurate and reliable. How-
ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-
ments of the rights of third parties, which may result from its use.
Acknowledgments
AMI is a trademark of American Megatrends Inc.
IBM and PC are trademarks of International Business Machines Corporation.
Intel® Core™ 2 Quad, Pentium® Dual Core™ and Celeron® are trademarks of
Intel® Corporation.
WinBond is a trademark of Winbond Corporation.
All other product names or trademarks are properties of their respective owners.
Part No. 2006111521 Edition 2
Printed in China June 2020

iii IDK-1115WP User Manual
A Message to the Customer
Advantech Customer Services
Each and every Advantech product is built to the most exacting specifications to
ensure reliable performance in the harsh and demanding conditions typical of indus-
trial environments. Whether your new Advantech equipment is destined for the labo-
ratory or the factory floor, you can be assured that your product will provide the
reliability and ease of operation for which the name Advantech has come to be
known.
Your satisfaction is our primary concern. Here is a guide to Advantech’s customer
services. To ensure you get the full benefit of our services, please follow the instruc-
tions below carefully.
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions,
you can easily find answers in your product documentation. These answers are nor-
mally a lot more detailed than the ones we can give over the phone.
So please consult this manual first. If you still cannot find the answer, gather all the
information or questions that apply to your problem, and with the product close at
hand, call your dealer. Our dealers are well trained and ready to give you the support
you need to get the most from your Advantech products. In fact, most problems
reported are minor and are able to be easily solved over the phone.
In addition, free technical support is available from Advantech engineers every busi-
ness day. We are always ready to give advice on application requirements or specific
information on the installation and operation of any of our products.

IDK-1115WP User Manual iv
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that each of its products will be
free from defects in materials and workmanship for two years from the date of pur-
chase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Advantech, or which have been
subject to misuse, abuse, accident or improper installation. Advantech assumes no
liability under the terms of this warranty as a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous testing, most of
our customers never need to use our repair service. If an Advantech product is defec-
tive, it will be repaired or replaced at no charge during the warranty period. For out-
of-warranty repairs, you will be billed according to the cost of replacement materials,
service time and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any onscreen messages you get when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an return merchandise authori-
zation (RMA) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales receipt)
in a shippable container. A product returned without proof of the purchase date
is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid
to your dealer.

v IDK-1115WP User Manual
Contents
Chapter 1 Overview...............................................1
1.1 General Description .................................................................................. 2
1.2 Specifications............................................................................................ 2
1.2.1 LCD Panel..................................................................................... 2
1.2.2 Touch Screen................................................................................ 2
1.3 Mechanical Characteristics ....................................................................... 4
1.3.1 IDK-1115WP-50HDA1E................................................................ 4
1.3.2 IDK-1115WP-45FHA1................................................................... 5
Chapter 2 IDK-1115WP-50HDA1E LCD Display..7
2.1 LCD Functional Block Diagram ................................................................. 8
Figure 2.1 Function block diagram .............................................. 8
2.2 Absolute Maximum Ratings ...................................................................... 8
2.2.1 TFT LCD Module .......................................................................... 8
2.2.2 Backlight Unit ................................................................................ 8
2.3 LCD Electronics Specification ................................................................... 9
2.3.1 LCD Electronics Specification....................................................... 9
Table 2.1: Power specification..................................................... 9
2.3.2 Vcc Power Dip Condition ............................................................ 11
2.4 Backlight Unit .......................................................................................... 11
Table 2.2: Backlight driving conditions ...................................... 11
2.5 Backlight Pin Assignment........................................................................ 12
Table 2.3: Backlight Pin Assignment ......................................... 12
2.6 LVDS Input Signal Specifications............................................................ 12
2.6.1 LVDS Data Mapping Table ......................................................... 12
Table 2.4: LVDS Data Mapping Table....................................... 12
2.6.2 Color Data Input Assignment ...................................................... 13
2.7 Display Timing Specifications ................................................................. 14
Table 2.5: Display Timing Specifications................................... 14
2.8 Power On/Off Sequence ......................................................................... 16
Table 2.6: Timing Specifications:............................................... 16
2.9 Pin Description........................................................................................ 18
Table 2.7: Pin Description ......................................................... 18
Chapter 3 IDK-1115WP-45FHA1 LCD Display...19
3.1 Functional Block Diagram ....................................................................... 20
3.2 Absolute Maximum Ratings .................................................................... 20
3.2.1 TFT LCD Module ........................................................................ 20
3.3 LCD Electronics Specification ................................................................. 21
3.3.1 LCD Electronics Specification..................................................... 21
3.4 Backlight Unit .......................................................................................... 23
3.5 LVDS INPUT SIGNAL SPECIFICATIONS.............................................. 24
3.5.1 LVDS DATA MAPPING TABLE .................................................. 24
3.5.2 Color Data Input Assignment ...................................................... 25
3.6 Display Timing Specifications ................................................................. 26
3.7 Power On/Off Sequence ......................................................................... 28
Table 3.1: Timing Specifications:............................................... 29
3.8 Pin Description........................................................................................ 30
Table 3.2: PIN ASSIGNMENT................................................... 30

IDK-1115WP User Manual vi
Chapter 4 Touchscreen & Touch Controller .... 33
4.1 Touchscreen ........................................................................................... 34
4.1.1 Touch Characteristics ................................................................. 34
4.1.2 Optical Characteristics................................................................ 34
4.1.3 Mechanical Characteristics......................................................... 34
4.2 Touch Controller ..................................................................................... 34
4.2.1 Electrical Specifications .............................................................. 35
4.2.2 Pin Assignment and Description................................................. 35
Appendix A LCD Optical Characteristics ............ 37
A.1 LCD Module Optical Characteristics ....................................................... 38
Table A.1: IDK-1115WP-50HDA1E Optical Characteristics ...... 38
Table A.2: IDK-1115WP-45FHA1 Optical Characteristics ........ 38
Appendix B Safety Precautions............................ 41
B.1 Safety Precautions.................................................................................. 42

Chapter 1
1Overview

IDK-1115WP User Manual 2
1.1 Introduction
The Advantech IDK-1115WP series comes with a 15.6" industrial grade LCD display
with Projected Capacitive touch. IDK-1115WP series supports Projected Capacitive
touch with low power consumption. IDK-1115WP series is ideal for embedded appli-
cations in which customers need maximum flexibility for mechanical design.
1.2 Specifications
1.2.1 LCD Panel
1.2.2 Touch Screen
Touch Screen: Projected Capacitive
Light Transmission: 87  2%
Interface: USB
Surface Treatment: Clear
Black Border Print: Yes
IDK-1115WP-50HDA1E IDK-1115WP-45FHA1
Display Size 15.6", 16:9 15.6", 16: 9
Resolution 1366 x 768 1920 x 1080
Display mode Normally White (TN) Normally Black (IPS like)
Viewing Angle (U/D/L/R) 150° / 160° 170° / 170°
Brightness (cd/m2 ) 500 450
Backlight Life (hrs) 50,000 min 50,000 min
Contrast Ratio 600: 1 800:1
Response Time (ms) 11 25
Colors 16.7M (8bit) 16.2M (8bit)
LCD Nominal Input Voltage / Current 5V / 370mA 3.3V / 1.22A
Backlight Input Voltage/ Current 12V / 0.7A 12V / 1A
Power Consumption 12.1 W (Black Pattern) 16W (White Pattern)
Signal Interface 1 channel LVDS 2 channel LVDS
Weight (g) 720 1050
Dimensions (W x H x D) (mm) 363.80x215.98x9.30 363.80x215.9x9.3
Operating Temperature -10 ~ 60 °C (14 ~ 140 °F) -20 ~ 70 °C (-4 ~ 158 °F)
Storage Temperature -20 ~ 60 °C (-4 ~ 140 °F) -30 ~80 °C (-22 ~ 176 °F)
Note! Temperature and relative humidity range is shown in the figure below.
(a) 90 %RH Max. (Ta ≤ 40 °C/104 °F).
(b)Wet-bulb temperature should be 39 °C/102 °F Max. (Ta > 40 °C/104
°F).

3 IDK-1115WP User Manual
Chapter 1 Overview

IDK-1115WP User Manual 4
1.3 Mechanical Characteristics
1.3.1 IDK-1115WP-50HDA1E
Front View
Rear View

5 IDK-1115WP User Manual
Chapter 1 Overview
1.3.2 IDK-1115WP-45FHA1
Front View
Rear View

IDK-1115WP User Manual 6

Chapter 2
2IDK-1115WP-50HDA1E
LCD Display

IDK-1115WP User Manual 8
2.1 LCD Functional Block Diagram
The following diagram shows the functional block of the 15.6” Color TFT-LCD Mod-
ule:
Figure 2.1 Function Block Diagram
2.2 Absolute Maximum Ratings
2.2.1 TFT LCD Module
2.2.2 Backlight Unit
Item Symbol Min. Max. Unit Note
Power Supply Voltage VCC -0.3 6 [Volt] (1)
Logic Input Voltage VIN -0.3 4 [Volt]
Item Symbol Value Unit Note
Min. Typ.Max.
(1), (2)
Duty=100%
Converter Voltage Vi0 12 18 [Volt]
Enable Voltage EN 0 3.3 7 [Volt]
Backlight Adjust ADJ 0 3.3 7 [Volt] (1), (2)
Pulse
Width ≦10msec.
and Duty ≦10%

9 IDK-1115WP User Manual
Chapter 2 IDK-1115WP-50HDA1E LCD Display
2.3 LCD Electronics Specification
2.3.1 LCD Electronics Specification
Input power specifications are as follows:
Table 2.1: Power specification
Parameter Symbol Value Unit Note
Min. Typ. Max.
Power Supply Voltage VCC 4.5 5 5.5 [Volt]
Input Current
White - 0.17 0.22
[A]
(3)a
Black - 0.24 0.29 (3)b
Vertical Stripe - 0.27 0.32 (3)c
Power Consumption PLCD - 1.35 1.6 [Watt] (4)
Ripple Voltage VCCrp - - 150 [mV]
Rush Current IRUSH - - 3 [A] (2)
LVDS differential input voltage Vid 200 - 600 [mV] (5)
LVDS common input voltage Vic 1.0 1.2 1.4 [V] (5)
LVDS terminating resistor RT - 100 - [ohm]
Note (1) The ambient temperature is Ta = 25oC ± 2 oC (75 ± 3.6 °F)
Note (2) Measurement conditions:

IDK-1115WP User Manual 10
Note (3) The specified power supply current is under the conditions at Vcc = 5.0
V, Ta = 25 oC ± 2 oC (75 ± 3.6 °F)Fr = 60Hz, whereas a power dissipation
check pattern below is displayed.
Note (4) The power consumption is specified at the pattern with the maximum
current.
Note (5) VID waveform condition

11 IDK-1115WP User Manual
Chapter 2 IDK-1115WP-50HDA1E LCD Display
2.3.2 Vcc Power Dip Condition
2.4 Backlight Unit
Following characteristics are measured under stable condition at 25°C:
Table 2.2: Backlight driving conditions
Item Symbol Values Unit Note
Min. Typ. Max.
Input Voltage VLED 10.8 12 13.2 [Volt]
Input Current ILED 0.6 0.8 1.0 [A] @ Vi = 12V
(Duty 100%)
Power Consumption PLED - - 10.5 [Watt]
PWM Dimming Frequency FPWM 190 200 20K [Hz]
PWM Control Duty Ratio 10 - 100 [%]
PWM Control Level High Level 2.0 3.3 5.0 V
Low Level 0 - 0.15 V
On Control Voltage VLED ON/OFF
2.0 3.3 5.0 [Volt]
Off Control Voltage 0 - 0.8 [Volt]
LED Life Time - 50,000 [Hrs] (2)
Note (1) LED light bar input voltage and current are measured by utilizing a true
RMS multimeter as shown below:
Note (2) The lifetime of LED is defined as the time when LED packages continue
to operate under the conditions at Ta = 25 oC ± 2 oC (75 ± 3.6 °F) and I=
70 mA (per chip) until the brightness becomes
≦ 50% of its original
value.

IDK-1115WP User Manual 12
2.5 Backlight Pin Assignment
2.6 LVDS Input Signal Specifications
2.6.1 LVDS Data Mapping Table
Table 2.3: Backlight Pin Assignment
Pin Symbol Description Remark
1 Vi Converter input voltage 12V
2 VGND Converter ground Ground
3 EN Enable pin 3.3 V
4 ADJ Backlight Adjust PWM Dimming
(Hi: 3.3VDC, Lo: 0VDC)
5 NC Not Connect
Note! Connector Part No.:CI4205M2HRP-NH,CVILUX
Table 2.4: LVDS Data Mapping Table
LVDS Channel 0 LVDS output D7 D6 D4 D3 D2 D1 D0
Data order G0 R5 R4 R3 R2 R1 R0
LVDS Channel 1 LVDS output D18 D15 D14 D13 D12 D9 D8
Data order B1 B0 G5 G4 G3 G2 G1
LVDS Channel 2 LVDS output D26 D25 D24 D22 D21 D20 D19
Data order DE NA NA B5 B4 B3 B2
LVDS Channel 3 LVDS output D23 D17 D16 D11 D10 D5 D27
Data order NA B7 B6 G7 G6 R7 R6

13 IDK-1115WP User Manual
Chapter 2 IDK-1115WP-50HDA1E LCD Display
2.6.2 Color Data Input Assignment
The brightness of each primary color (red, green and blue) is based on the 8-bit gray
scale data input for the color. The higher the binary input, the brighter the color. The
table below provides the assignment of color versus data input.
Color
Data Signal
Red Green Blue
R7 R6 R5 R4 R3 R2 R1 R0 G7 G6 G5 G4 G3 G2 G1 G0 B7 B6 B5 B4 B3 B2 B1 B0
Basic
Colors
Black 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Red 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Green 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0
Blue 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1
Cyan 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Magenta 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1
Yellow 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0
White 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Gray
Scale
Of
Red"
Red(0) /
Dark 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Red(1) 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Red(2) 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
: : : : : : : : : : : : : : : : : : : : : : : : :
: : : : : : : : : : : : : : : : : : : : : : : : :
Red(253) 1 1 1 1 1 1 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Red(254) 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Red(255) 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Gray
Scale
Of
Green"
Green(0) /
Dark 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Green(1) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0
Green(2) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 0 0
: : : : : : : : : : : : : : : : : : : : : : : : :
: : : : : : : : : : : : : : : : : : : : : ::::
Green(253) 0 0 0 0 0 0 0 0 1 1 1 1 1 1 0 1 0 0 0 0 0 0 0 0
Green(254) 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0
Green(255) 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0
Gray
Scale
Of
Blue"
Blue(0) /
Dark 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Blue(1) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1
Blue(2) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0
: : : : : : : : : : : : : : : : : : : : : : : : :
: : : : : : : : : : : : : : : : : : : : : : : : :
Blue(253) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 0 1
Blue(254) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 0
Blue(255) 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1

IDK-1115WP User Manual 14
2.7 Display Timing Specifications
The input signal timing specifications are shown as the following table and
timing diagram.
Table 2.5: Display Timing Specifications
Signal Item Symbol Min. Typ. Max. Unit Note
LVDS Clock
Frequency Fc 63 76 96 MHz
Period Tc - 13.15 - ns
"Input cycle
to
cycle jitter"
Trcl -0.02*Tc - 0.02*Tc ns (3)
Input Clock
to data skew TLVCCS -0.02*Tc - 0.02*Tc ns (4)
"Spread
spectrum
modulation
range"
"Fclkin_
mod" FC*98% - FC*102 %MHz
(5)
"Spread
spectrum
modulation
frequency"
FSSM - - 200 KHz
Vertical Display
Term
Frame Rate Fr 50 60 76 Hz Tv=Tvd
+Tvb
Total Tv 800 806 815 Th -
Active Dis-
play Tvd 768 768 768 Th -
Blank Tvb 32 38 47 Th -
Horizontal
Display Term
Total Th 1500 1560 1570 Tc Th=Thd
+Thb
Active Dis-
play Thd 1366 1366 1366 Tc -
Blank Thb 134 194 204 Tc -
Note (1) Because this module is operated by DE only mode, Hsync and Vsync
input signals are ignored.
Note (2) The Tv (Tvd+Tvb) must be integer, otherwise, this module would oper-
ate abnormally.
