I-Tech FCOP0430 User manual

i-Tech Company LLC
TOLL FREE: (888) 83-2418 • EMAIL: [email protected] • WEB: www.iTechLCD.com Modified: 10-20-21
4.3" Digital TFT-LCD Module
MODEL: FCOP0430

FCOP430-TR-v1 2021 03 18 V1.2
P.1
1. General Description
1.1 Features
■4.3” (480x272) Digital TFT LCD
■Aspect Ratio: 16:9
■Input Signal CVBS / VGA
■Maximum Support Resolution 1920x1080
■4 Wires Resistive Touch Panel
■5 Key Buttons Controls
■9 Language OSD Menu
■LED Backlight
■Single Operation Voltage +12V
1.2 Applications
■Industrial
■Medical Environment
■Instrument Display
■Kiosk
■Security
■Signage
■Office Electronics
■Home Application
■Educate Application

FCOP430-TR-v1 2021 03 18 V1.2
P.2
2. Contents
Contents Page
1. General Description…………………………………………………………………………………….……………. 1
1.1 Features 1
1.2 Applications 1
2. Contents……………….…………………………………………………………...…………………………….…. 2-3
3. Specifications………..………………………………………….………………..…………………………………… 4
4. Black Diagram………………………………………………………………….………………………………….…. 4
5. Order Information…..………………...……………………………………………………………………………… 5-6
5.1 Unit
5.2 Customized
5-6
6
5.3 Demo Board (Option) 6
6. Accessories (Option)……………………………………………………………………………….…………….…. 7
7. Operation manual / Connection……………………………………………………………………………………. 8
7.1 Driver Board Manual 8
8. Pin Description……………………………………………………………………………………………………….. 9-11
8.1 J105：Pin Assignment of Analog RGB Input ( D-Sub 15Pin) 9
8.2 J103: Pin Assignment of UART (Pitch 1.25mm 4Pin, Top Entry Type) 9
8.3 DC JACK: Pin Assignment of Power Input (Inside Diameter:2.1ψOutside Diameter:5.5ψSide Entry Type) 10
8.4 RCA: Pin Assignment of Video Input (RCA JACK Yellow, Side Entry Type) 10
8.5 J402：Pin Assignment of Touch USB (USBA-Female, Side Entry Type )(Option) 10
8.6 J404：Pin Assignment of Touch RS232 (D-SUB 9 FEMALE)(Option) 10
8.7 J102：Pin Assignment of Analog RGB Input (Pitch 2.0mm 14Pin, Side Entry Type) 11
8.8 J101：Pin Assignment of Signal Input (Pitch 1.25mm 8Pin, Side Entry Type) 11
8.9 J401：Pin Assignment of Touch (Pitch 2.0mm 4Pin, Side Entry Type) 11
9. Absolute Maximum Ratings………………………………………………………………………………...………... 12
9.1 Absolute Maximum Ratings 12
10. Recommended Operating Conditions……………………………………………………………………...………. 12
10.1 Electrical Characteristics 12
10.2 Support Display Mode Characteristics 12
11. 4W Resistance Touch Panel Characteristics………….………………………….………………………………… 13-16
11.1 Electrical Performance 13
11.2 Mechanical Performance 13
11.3 Durability Performance 13
11.4 Touch Panel Operation System Support 14
11.5 Touch Screen Integration Design Guide 15
11.6 Mechanical Design Notice For Touch Panel 16
12. Key Function by OSD………………………………………………………………………………………………. 17-21

FCOP430-TR-v1 2021 03 18 V1.2
P.3
12.1 Menu Operation 17-21
13. Dimension Information……………………………………………………………………………………………. 22
22
13.1Unit (FCOP430-TR-v1)
14. Appendix………………………………………………………………………………….………………………… 23-29
14.1 TFT-LCD Mechanical Specifications 23
23
24
25
26
27
28
14.2 TFT-LCD Optical Characteristics
14.3 Application Circuit
14.4 Application Circuit
14.5 (Option)
14.6 (Option)
14.7 Cable: 8P-8P 1.25mm L:100mm (Option)
14.8 Cable: 14P-14P 2.0mm L:110mm (Option) 29

FCOP430-TR-v1 2021 03 18 V1.2
P.4
3. Specifications
4. Block Diagram
LCD Input Signal
Panel Size 4.3” CVBS RCA JACK
Resolution (Pixels) 480x272 VGA D-Sub15
Color 16.2M Controls
Luminance without TP 500 cd/m2Key 5 Buttons
Luminance (RTP) 400 cd/m2Serial Remote Control UART / RS232 (Option)
Contrast Ratio 500 Environment
Viewing Angle 70(L) / 70(R) / 50(T) / 70(B) Without TP 4W RTP
LED Life Time (Min.) 20K hours Operating Temp. -20~+70℃-20~+70℃
Power Requirement Storage Temp. -20~+70℃-20~+70℃
Power Input (DC Jack 2.1ψ)+12VDC High Temperature &
High Humidity (Non-condensing) +60℃/ 90% +60℃/ 90%
Power Consumption 2.28
Touch Screen
Resistive Type USB / RS232 Interface
Resistive Type Support OS Windows / Linux / DOS / Mac / QNX

FCOP430-TR-v1 2021 03 18 V1.2
P.5
5. Order Information
5.1 Unit
Item FCOP430-TR-v1 Unit Remark
CVBS ◎
Power Connector
(Dc Jack/CON. 1.25mm 8Pin) Dc Jack
VGA
(D-Sub15/CON. 2.0mm 14Pin) D-Sub15
Touch Panel Type 4W Resistive
Touch Screen Interface USB
Serial Remote Control UART
Dimension 118.5 x 69 x 20.4 mm
Weight 135.5
g ±10%
Condition Standard
Note: 1.The assembling of panel and bracket is aimed for delivery, packaging and experiment. If the demand of shockproof and long-term fix, pls
have it into consideration of mechanism design.

FCOP430-TR-v1 2021 03 18 V1.2
P.6
5.2 Customized
Note: Special order condition will apply to non-standard items and pls. contact salespersons in iTech.
5.3 Demo Board (Option)
Demo Board
Part Number Remark
Cable: 8P-8P 1.25mm L:100mm
Function Item
Serial Remote Control RS232 (DB9)
External Key 5 keys

FCOP430-TR-v1 2021 03 18 V1.2
P.7
6. Accessories (Option)
Before you begin installing the KIT, please make sure that the following materials have been shipped:
A. AC to DC Adapter (L:1500mm, 100-240VAC 50-60Hz to +12VDC @ 3.3A)
B. Power Cord (L:1800mm, Plug Type B for USA)
C. Video Cable (L:1800mm)
D. VGA Cable (L:1800mm)
E. USB Cable (L:1800mm)
F. RS232 Cable (L:1800mm)
G. Touch Screen Driver CD Disk / User Manual

2021 03 18 V1.2
P.8
FCOP430-TR-v1
7 Operation manual / Connection
7.1 Driver Board Manual

FCOP430-TR-v1 2021 03 18 V1.2
P.9
8. Pin Description
8.1 J105 ： Pin Assignment of Analog RGB Input ( D-Sub 15Pin)
8.2 J103: Pin Assignment of UART (Pitch 1.25mm 4Pin, Top Entry Type)
※Connector Part No.: MS24014 (STM) [Same as 53398-0471 (MOLEX)] ;
※Matching Connector Part No.: P24014 (STM) [Same as 51021-0400 (MOLEX)].
Pin No. Symbol I/O Description Remark
1TX / RS232 TX (Option) O UART / RS232 (Option) Transmission Data
2RX / RS232 RX (Option) I UART / RS232 (Option) Receive Data
3 GND - Ground
4 +3.3Vdc O +3.3Vdc Output Voltage
Note: All Functions can be controlled by UART , About UART command list please contact iTech sales.
Pin No. Symbol I/O Description Remark
1RI+ I Analog Red Signal
2GI+ I Analog Green Signal
3 BI+ I Analog Blue Signal
4 NC - No Connection
5 GND - Ground
6 AGND - Analog Ground
7 AGND - Analog Ground
8 AGND - Analog Ground
9 NC - No Connection
10 NC - No Connection
11 NC - No Connection
12 NC - No Connection
13 HS_IN I TTL Horizontal sync
14 VS_IN I TTL Vertical sync
15 NC - No Connection

FCOP430-TR-v1 2021 03 18 V1.2
P.10
8.3 DC JACK: Pin Assignment of Power Input (Inside Diameter:2.1 ψ Outside Diameter:5.5 ψ Side Entry Type)
8.4 RCA: Pin Assignment of Video Input (RCA JACK Yellow, Side Entry Type)
※Connector Part No.: MS240112R (STM) [Same as 53261-1219 (MOLEX)] ;
※Matching Connector Part No.: P240112 (STM) [Same as 51021-1200 (MOLEX)].
Pin No. Symbol I/O Description Remark
1Video I
Video Input
2 AGND -
Analog Ground
8.5 J402
： Pin Assignment of Touch USB (USBA-Female, Side Entry Type )(Option)
Pin No. Symbol I/O Description Remark
1VBUS - USB VCC
2D- - DATA (-)
3 D+ - DATA (+)
4 DGND - Digital Ground
8.6 J404 ： Pin Assignment of Touch RS232 (D-SUB 9 FEMALE)(Option)
Pin No. Symbol I/O Description Remark
1VIN I +12V Input Voltage
2GND - Power Ground
Pin No. Symbol I/O Description Remark
1NC - No Connection
2TXD - Transmit Data
3 TXD - Receive Data
4 NC - No Connection
5 GND - Ground
6 NC - No Connection
7 NC - No Connection
8 NC - No Connection
9 NC - No Connection

FCOP430-TR-v1 2021 03 18 V1.2
P.11
8.7 J102 ： Pin Assignment of Analog RGB Input (Pitch 2.0mm 14Pin, Side Entry Type)
※Connector Part No.: MS242614R (STM) [Same as S14B-PH-K-S (JST)] ;
Matching Connector Part No.: P242614 (STM) [Same as PHR-14 (JST)].
8.8 J101
： Pin Assignment of Signal Input (Pitch 1.25mm 8Pin, Side Entry Type)
※Connector Part No.: MS24018R (STM)[ Same as 53261-0819 (MOLEX)] ;
Matching Connector Part No.: P24018 (STM)[ Same as 51021-0800 (MOLEX)]
8.9 J401
： Pin Assignment of Touch (Pitch 2.0mm 4Pin, Side Entry Type)
※Connector Part No.: M24264R (STM) [Same as S4B-PH-K-S (JST)] ;
Matching Connector Part No.:P24264 (STM) [Same as PHR-4 (JST)].
Pin No. Symbol I/O Description Remark
1NC - No Connect
2NC - No Connect
3 NC - No Connect
4 GND - Ground
5 NC - No Connect
6 VS_IN I TTL Vertical sync.
7 HS_IN I TTL Horizontal sync.
8 AGND - Analog Ground
9 RI+ I Analog Red Signal
10 AGND - Analog Ground
11 GI+ I Analog Green Signal
12 AGND - Analog Ground
13 BI+ I Analog Blue Signal
14 GND - Ground
Pin No. Symbol I/O Description Remark
1VCC12V - +12V Input Voltage
2VCC12V - +12V Input Voltage
3 GND_D - Ground
4 GND_D - Ground
5 VIDEO1 I Video1 Input Signal
6 GND_A - Ground For Video1
7 VIDEO2 I Video2 Input Signal
8 GND_A - Ground For Video2
Pin No. Symbol I/O Description Remark
1VBUS - USB VCC/No Connection
2D-/RXD - DATA (-)/Receive Data
3 D-/TXD - DATA (+)/Transmit Data
4 DGND - Digital Ground

FCOP430-TR-v1 2021 03 18 V1.2
P.12
9. Absolute Maximum Ratings
9.1 Absolute Maximum Ratings
Parameter Symbol Min Max Unit Remark
Input Voltage Vin 9 15 V
Video Input Signal Video in 0.5 2.0 Vp-p @75Ω
Analog RGB Input Signal Analog RGB in 0.5 2.0 Vp-p @75Ω
Digital Input Signal TTL +0.3 +3.6 V
Operating Temperature without TP -20 +70 ℃
Operating Temperature with RTP -20 +70 ℃
Storage Temperature without TP -30 +80 ℃
Storage Temperature with RTP -30 +80 ℃
High Temperature & High Humidity
(Non-condensing) without TP
- +60 / 90 ℃/ %
High Temperature & High Humidity
(Non-condensing) with RTP - +60 / 90 ℃/ %
10. Recommended Operating Conditions
10.1 Electrical Characteristics
Parameter Symbol I/O Min Typ Max Unit Note
Input Voltage Vin I +10 +12 +14 V
Total Current I-in (+12V) I - 190 - mA ±15%
Power Consumption I - 2.28 - W@+12V
Output Voltage VDD O +3.2 +3.3 +3.4 VI=10mA
Video Input Signal Video in I - 1.0 -
Vp-p @75Ω
Analog RGB Input Signal Analog RGB in I - 0.7 -
Vp-p @75Ω
10.2 Support Display Mode Characteristics
Dots per inch Standard H Unit Polarity V Unit Polarity Note
640 × 480 - 31.469 KHz Negative 59.941 Hz Negative
800 × 600 VESA 37.879 KHz Positive 60.317 Hz Positive
1024 × 768 VESA 48.363 KHz Negative 60.004 Hz Negative
Note: Polarity & standard only for VGA mode

FCOP430-TR-v1 2021 03 18 V1.2
P.13
11. 4W Resistance Touch Panel Characteristics
11.1 Electrical Performance
Parameter Symbol Min Typ Max Unit Remark
Terminal Resistance X 300 1500 Ω
Y 100 900 Ω
Linearity -1.5 - 1.5 %
Insulation Impedance 25 - - MΩDC 25V
Response Time - - 20 ms
11.2 Mechanical Performance
Parameter Specifications Remark
Input Method Finger or stylus pen
Operating Force 80g Min.
Surface Hardness 3H or more
11.3 Durability Performance
Parameter Specifications
Hitting Durability ≧1000000 times, with R8.0 mm silicon rubber,200g, 2 times/sec
Sliding Durability ≧100000 words, with R0.8 mm polyacetal stylus, 250g, 60 mm/sec

FCOP430-TR-v1 2021 03 18 V1.2
P.14
11.4 Touch Panel Operation System Support
Driver Vender：ITE (ITE Tech. Inc.)
OS Version Interface
Windows
Windows 7, 8, 8.1, 10
Windows Embedded 7, 8
Windows Embedded POSReady 2009, POSReady 7
Embedded Standard 7
Embedded Enterprise 7
Embedded 8 Standard
Embedded 8.1 Pro/ Embedded 8.1 Industry
Windows , XP, 2000
Windows XP Embedded
USB/RS232
Windows CE
Windows Embedded Compact 2013, 7
Windows CE 6.0
Windows CE.Net (4.x / 5.0)
USB/RS232
Linux
Kernel 2.6.24 Upward and 3.x.x / 4.x.x / 5.x.x (X86 / ARM / MIPS)
Kernel 2.6.23 Downward (X86)
Kernel 2.4.x (x86)
USB
Android Android Version 2.3.x upwards (X86 / ARM / MIPS) USB
Mac OS
Mac OS X 10.5.3 Leopart (Power PC)
Mac OS X 10.7.4 Earlier (32Bit / 64Bit) (Intel CPU)
Mac OS X 10.7.5 (32Bit / 64Bit) (Intel CPU)
Mac OS X 10.8.x Mountain Lion (Intel CPU)
Mac OS X 10.9.x Mavericks (Intel CPU)
Mac OS X 10.10.x Yosemite (Intel CPU)
Mac OS X 10.11 El Capitan (Intel CPU)
Mac OS 10.12 Sierra (Intel CPU)
Mac OS 10.13 High Sierra (Intel CPU)
Mac OS 10.14 Mojave (Intel CPU)
Mac OS 10.15 Catalina (Intel CPU)
USB
QNX
QNX Neutrino RTOS V6.5/6.4
QNX Neutrino RTOS V6.3
USB/RS232
Note: 1. Please refer to the iTech website for the driver installation and support operating system.
iTech website: www.itechlcd.com
2. How to use Touch Driver , please refer to Readme of Touch Screen Driver CD Disk.
3. Please refer to the iTech website for the latest driver version and support operating system.

FCOP430-TR-v1 2021 03 18 V1.2
P.15
11.5 Touch Screen Integration Design Guide
Front case design follow as below
1. Avoid the design that front case overlap and press on the active area of the LCM.
2. Give enough gap(over 0.5mm at compressed) between the front case and TSP to protect wrong operating.
3. Use a buffer material(Gasket) between the TSP and front case to protect damage and wrong operating.
4. Avoid the design that buffer material overlap and press on the inside of TSP view area.

FCOP430-TR-v1 2021 03 18 V1.2
P.16
11.6 Mechanical Design Notice For Touch Panel
Correct Installation Incorrect Installation

FCOP430-TR-v1 2021 03 18 V1.2
P.17
12. Key Function by OSD
12.1 Menu Operation
OSD ICON Instructions：
1. POWER / SOURCE：Power On/Off (※Press for 3 secs to turn off)
2. MENU / ENTER：(After turning on MENU, only ENTER is available)
3. UP：Move Upward / Increase Value / Option Switch
4. DOWN：Move Downward / Decrease Value / Option Switch
5. EXIT：Return to Previous Page
6. LED Indicator
•Waiting：Flickering Green
•PowerON：Green
•PowerOFF：Red
Save OSD Setting:
1. EXIT MENU and settings will be saved automatically
2. Settings will be saved as well when MENU shuts down automatically
POWER/SOURCE
LED Indicator MENU / ENTER UP DOWN EXIT
Func. Tab Enter
Next
Move
Previous Page
Configuration

2021 03 18 V1.2
P.18
FCOP430-TR-v1
Overview of the Menu：
Image (VGA)
Indicator Meaning Default Adjustable range Remark
Brightness 32 0~63 Adjust-Bar
Contrast 32 0~63 Adjust-Bar
Dimmer 9 0~9 Adjust-Bar
Color Temp. Normal Normal / Warm / Cool For VGA System
Only
H-Position 0 The adjusting value range depends on
each resolution mode
V-Position 0 The adjusting value range depends on
each resolution mode
Clock 0 -49~+49
Phase 0 0~63
Auto Depend on the Signal
Exit
Image (Video)
Indicator Meaning Default Adjustable range Remark
Brightness 22 0~63 Adjust-Bar
Contrast 40 0~63 Adjust-Bar
Color 50 0~63 Adjust-Bar
Tint 16 0~31 For NTSC System Only
Sharpness 8 0~15 Adjust-Bar
Dimmer 9 0~9 Adjust-Bar
Exit

FCOP430-TR-v1 2021 03 18 V1.2
P.19
Function
ICON Meaning Function Default Status Description Remark
Show Status Information of input source On
On Show input source
Off Hide input source
Blue Screen
Select blue/ black screen
when no input signal is
detected.
On
On
Show blue screen when
no input.
Off
Show black screen when
no input.
Auto Power On
Modules turns on
automatically without
power key input.
On
On Auto
Off Manual
Auto Save Power off , the last state
Detect Source Auto detect input source. On
On Auto-detect signal source
Off
Manual switch signal
source
Auto Power
Saving
Modules go standby when
no input source is
detected.
Off
6s / 15s / 30s
Go standby by settings
when no input
LED indicator:
Flickering Green
Off
Show no signal when no
input
LED indicator:
Green
Auto Sleep Modules go off when set
timing is out. Off
15M / 30M / 60M Go off by time setting
LED indicator: Red
Press Power Key
back to life.
Off Turn off sleep mode
Exit
Note：After configuration is set, RESET won’t restore to default setting.
