i-Vac S40 User manual

Pure Fresh S40
Stick Vacuum
2-in-1 functionality
Swivel power head
Lightweight and convenient

2.
5
6
7
8
15
16
17
18
9
10
11
12
13
14
1
2
3
4

3
Specications:
Voltage: 25.9V DC
Power: 300W with powerhead
Dust capacity: 0.4L
Battery type: 2500mAh Lion
Runtime: 25 mins*
Charge time: 4-5 hours
Net weight: 2.34Kg
Features:
1. Exhaustlter
2. Boost button
3. Rod release button
4. Rod
5. Charging port
6. Battery release button
7. Charging indicator
8. Battery
9. On/off trigger
10. Dust bin release button
11. Dust bin
12. Dust bin lid release button
13. Floor head release button
14. Combinationoorhead
Please contact Godfreys Customer Care 1800 815 270, NZ 0800 282 288 to nd
your local spare parts provider.
S40 Stick Vacuum
Congratulations on the purchase of your new i-Vac Stick Vacuum. There are many useful features
built into your cleaner and we recommend that you carefully read this instruction manual to take
the best advantage of these features.
Features
Accessories:
15. Crevice tool
16. Dusting brush
17. Wall storage bracket
(screws are not included.)
18. Charger
* Applies to low mode with powerhead.

4
Before You Begin
This cleaner must be operated in accordance with these instructions and used only for domestic
householdcleaningtoremoveDRYdirtanddustfromhouseholdcarpets,ooring,wallsandfabrics.
Thiscleanerisnotttobeusedasanindustrialcleanerandwillvoidthemanufacturer’swarrant yifused
inappropriately.
Please read these instructions thoroughly
Thiswillensureyouobtainfullbenetfromyournewcleaner.Keepthisinstructionmanualinahandy
place for future reference.
Important
Alwaysswitchofftheappliancebeforecleaning,attemptinganymaintenancetask,ttingorremoving
accessories, or when not in use. The charger must only be connected to an AC power supply at the
voltage shown on the rating label. This cleaner should only be charged with the charger provided. This
cleaner should only be used for its intended purpose as described in these instructions.
Precautionary measures:
1. Do not operate the vacuum cleaner too close to heaters, radiators or other
hot surfaces.
2. Before inserting the plug into the wall, make sure your hands are dry.
3. Before turning on the vacuum cleaner, safely remove any large objects from the
oororcleaningsur faceinordertopreventdamagetothelter.
4. When you want to remove the plug from the power socket, do not use the power cable,
gently pull the plug from the power socket.
5. Do not use this vacuum cleaner to pick-up water or liquids.

5
When using your vacuum cleaner, basic precautions
should always be observed, including the following;
1. This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities or lack
of experience and knowledge, unless they
have been given supervision or instruction
concerning use of the appliance by a person
responsible for their safety.
2. Children should be supervised to ensure that
they do not play with the appliance.
3. To prevent electrical shock, do not immerse
the appliance, battery, or power plug into
water or other liquids.
4. To prevent electrical shock, do not use the
vacuum cleaner outdoors or on wet surfaces.
5. Always check the power cord before use, the
power cord and the plug should be in a good
condition and must not be damaged. If the
power supply cord is damaged or defective,
it must be replaced by the manufacturer, its
serviceagentorsimilarlyqualiedpersons
in order to avoid a hazard.
6. The appliance and charging base are intended
for domestic indoors use only.
7. Do not unplug by pulling on the power cord.
To unplug, grasp the plug, not the power cord.
Use only Australian and New Zealand electrical
safety approved extension cords.
8. Do not pull or carry the appliance by the power
cable, use the power cable as a handle or
pull the power cable around sharp edges or
corners. Avoid running the appliance over the
power cable.
9. Do not handle or operate the appliance
with wet hands and follow electrical safety
precautions at all times.
10. Extreme caution should be exercised when
using the appliance on stairs.
11. Do not attempt to change the attachments
while the appliance is switched on. Use only
manufacturer’srecommendedaccessories.
12. Do not operate the vacuum cleaner too close
to heaters, radiators and other hot surfaces.
13. Donotusetheappliancetopickupammable
items or combustible liquids (i.e. gasoline, hot
ashes, cigarettes, matches, explosive materials
or anything burning) or use in areas where such
substances and items may be present.
14. Do not use the appliance to pick up toxic
materials (i.e. chlorine bleach, ammonia).
Safety Precautions & Warnings
IMPORTANT! Always switch off the appliance before cleaning, when not in use or
before attempting any maintenance task. The charger must only be connected to
an AC power supply at the voltage shown on the rating label. This cleaner should
only be used for its intended purpose as described in this instruction manual.
Never operate the vacuum cleaner without lters.
Read the manual attentively before using the appliance for the rst time.
Before You Begin & Warnings

6
15. Never operate or use the appliance without the
ltersinplace.
16. Before vacuuming, remove any large or sharp
objectsfromtheoororcleaningsur facein
ordertopreventdamagetothelter.
17. Iftheairinletoroorheadisblocked,switch
off the cleaner straight away. Clear the blocked
object before attempting to start the vacuum
cleaner again.
18. Before carrying out any maintenance service or
cleaningthelters,alwaysswitchoffthevacuum
cleaner.
19. Keep openings away from your face and body.
20. Do not use the vacuum cleaner if it is damaged or
broken. If connection cables are damaged, have
them replaced immediately.
21. Never clean the vacuum cleaner or any of
the electrical parts, especially the electrical
connections, with water or liquid cleaners.
22. Neverattempttomakeanymodications
electrically to the vacuum cleaner and charging
base.
23. Always store the appliance and charger indoors
in a cool and dry place.
24. Do not pick up water, for dry household use only.
25. Use the electric power head only for vacuuming
dust and dry substances in the home.
26. Never run over the power cable with the power
head as this may cause damage to the power
cable.
27. Never touch the roller brush while the vacuum
cleaner is switched on.
28. To prevent unnecessary wear on the power
head, keep it moving while in operation.
29. Damage caused by improper use or by not
observing the instructions in this manual
will void the warranty.
Battery use and care
1. The appliance is only to be used with the charger
uniquely provided with the appliance.
2. Onlyusethespecicallydesignatedchargerto
charge the battery.
3. When appliance is not in use, keep it away from
other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects that can
make a connection from one terminal to another.
Shorting the appliance terminals together may
causeburnsorare.
4. Underabusiveconditions,batterymaycatchre
and explode.
5. Do not charge or store the appliance outdoors or
inside the car. Only charge or store the battery in
a dry indoor area where the temperature is more
than 5oC but less than 45oC. The charger is for
indoor used only.
6. Never attempt to open the battery for any
reason. If the plastic housing of the battery
casing breaks or cracks, immediately discontinue
use and do not recharge. Battery is not a
serviceable part.
7. The charger is not a serviceable part.
8. Before disposal of your battery, fully discharge
your battery by running the product until it stops.
9. The cleaner contains a Li-Ion battery. Do not
dispose of the appliance with your local garbage.
Contact your local council for instructions on how
to safely dispose of the battery.
10. Do not use the charger to charge a
non-chargeable battery.

7
IMPORTANT! Always remove the battery from the appliance before tting or
removing accessories.
Assembly
1. Insert the power head into the rod. You will hear a “click”
sound when it is securely in place.
Warnings & Assembly
2. To install the rod, insert the plug end of the rod into the air
inlet of the cleaner. Once it is securely in place, you will hear
a “click” sound.
Inserting the battery
1. Slide the battery into the main unit of the vacuum cleaner.
Once it is in place, you will hear a “click” sound.
2. To remove the battery, press the battery release button and
gently pull the battery from the vacuum cleaner.
Connecting accessories to the unit
1. Insert accessories into the air inlet of the cleaner. You will
hear a “click” sound when each is securely in place.
2. To disassemble, press the rod release button on the cleaner
and then pull the accessory out from the air inlet.

8
Instructions for Use
Turning on the vacuum
1. Press the on/off button to turn on the vacuum.
Switch to boost mode
1. To switch between low power and high power, press the boost
button.

9
Instructions for Use
Charging the vacuum cleaner
NOTE: When the charging indicator light ashes during
use, the vacuum cleaner battery is running low and requires
charging.
1. Insert the charger cable into the battery charging port .
Charging indicator light:
Flashes red: battery require charging.When all three blue led
stopashingbatteryisfullycharged
ATTENTION: It is recommended to charge your
product after each use to maintain maximum
performance.
NOTE: This product takes 4-5 hours to charge. Before
the rst three uses of the vacuum cleaner, however, 12
hours of continuous charging is required.
CAUTION! Do not try to open the battery and repair it
yourself.
NOTE: As a safety precaution, the vacuum cannot be
switched on while the vacuum is charging.

10
Accessories
Dusting brush
The dusting brush can be used as a soft dusting brush for cleaning a
variety of surfaces or as an upholstery tool for cleaning furniture.
Crevice tool
The crevice tool can be used to clean hard-to-reach places or in tight
crevices.
Ideal for daily cleaning on carpets
andhardoors.
Carpet Hard oors
Power head
NOTE: If the power head is blocked, the motor switches off automatically. If this
occurs, switch off the vacuum cleaner and remove the battery. Remove any object
that has blocked the power head, and switch the vacuum cleaner on again. If the
power head does not start again after cleaning, do not try to dismantle the power
head. Please contact your local Godfreys store.

11
Accessories & Maintenance
IMPORTANT! Turn off the cleaner and remove the battery before conducting
any maintenance tasks. It is recommended to clean the dust bin after each use or
when dust reaches the max ll line.
Emptying the dust bin
Press the dust bin lid release button to open the bottom cover of
the vacuum cleaner and empty the dust bin.
Maintenance
Storage
1. Install the wall storage bracket onto the wall using wall
mounting screws (not included).
2. Insert the vacuum cleaner into the wall storage bracket,
ensuring it is securely in place.
3. Place the accessories into the corresponding slots on the
wall storage bracket.
NOTE: If you are not going to use the machine for a
long period of time, it is recommended to remove the
battery from the machine during storage to maintain
the battery life.

12
Cleaning the dust bin and lters
1. Press the dust bin release button and, at the same time, turn the
dust bin anti-clockwise to remove it from the unit.
3. Liftthecyclonelterandreleaseitfromthecleaner.
4. Toremovetheexhaustlter,turntheltercapanti-clockwise.
Then,pulltheexhaustlterfromtheltercap.
NOTE: It is recommended to replace the lters every six
months or when they become visibly dirty.
2. TheHEPAltercanbefoundinthedustbin.
NOTE: It is recommended to replace the lters every six
months or when they become visibly dirty.
Maintenance

13
Maintenance
Cleaning the roller brush
1. Slide the roller brush release button in the direction of the
arrow shown on the button.
2. Gently pull the roller brush out to clean or replace it.

14
Spare Parts
PleasecontactGodfreysCustomerCare:1800815270,NZ:0800282288tondyourlocal
spare parts provider.
Part Part Number
Battery Assembly 33202102
Charging Adaptor 33202103
ExhuastandHEPAlterset 32201856
Cyclone Mesh Cone Filter 32201857
Agitator brush assembly 33788197

15
Troubleshooting
Spare Parts & Troubleshooting
Fault Cause Solution
Cleaner doesn’t start Flat battery Charge the vacuum cleaner
Reduced suction
The dust bin is full of dust Empty the dust bin
Filter is blocked Cleanorreplacethelter
The airway is blocked Clear the airway
The charging indicator light
fails to turn blue during
charging (led 1 to 3 ashes
blue indicates the status of
charging)
The charger is not fully
inserted into the cleaner
Reinsert the charger into the
cleaner, ensuring it is securely
in place
The charger is not connected
to the mains power Connect the charger to the mains power
Insufcient application
time after charging
Insufcientchargingtime
Fully charge the battery
according to the instructions
described in the charging
section
Normal discharge reduction
in battery Purchase a new battery
Light ashes from red to
blue intermittently.
Battery is not inserted into
the cleaner properly
Remove the battery and
reinsert it into the cleaner
until you hear it click into
place
Problems and solutions
If you come across a problem, please use the checklist of troubleshooting tips before contacting
Godfreys Customer Care.

Your i-Vac stick vacuum, in the case of domestic use, has a
one year parts and labour warranty against product defects
and failures when the product is used in accordance with the
terms and conditions of this warranty statement.
This warranty commences from the original date of purchase
and is not transferable; please retain your original proof of
purchase for any warranty claims. This warranty is valid only in
the country where the cleaner is purchased.
The cleaner must be operated in accordance with these
instructions and used only for domestic household cleaning
to remove dirt and dust from household carpets, flooring
and fabrics. This cleaner is not fit to be used as an industrial
cleaner, hence will void the manufacturer’s warranty if used
inappropriately.
Accessories and consumables, unless defective in
manufacture, are not subject to this warranty. In order to
prolong the life of accessories and consumables, regular care
and maintenance is recommended.
When properly used and cared for, your cleaner will render
excellent service; refer to the instruction manual for further
details, as misuse or failure to follow the instructions makes
this warranty void.
In the event of service or advice being needed, please
contact Electrical Home-Aids Pty. Limited, Brandon Office
Park, Building 3, First Floor, 530-540 Springvale Road, Glen
Waverley, Victoria, 3150, or on 1800 815 270 (AUS) or 0800
282 288 (NZ), Monday-Friday 9am-5pm EST. The decision
to repair or replace the cleaner is at the sole discretion of
Electrical Home-Aids Pty. Limited. If Electrical Home-Aids Pty.
Limited decide to repair or replace the cleaner, it will do so at
its own cost.
Electrical Home-Aids Pty. Limited is unable to accept
responsibility under this warranty for any repair work not
carried out by an authorised Service Agent or from the use
of non-genuine parts. If any part is no longer available or
manufactured, Electrical Home-Aids Pty. Limited will replace
it with a genuine functional replacement part. This warranty
does not apply to the cost of replacing any parts of the
product due to normal wear and tear, alterations, improper
installation, physical abuse, misuse or accidental damage. Any
transportation costs involved in the repair of defective parts
shall be borne by the claimant.
If proof of purchase cannot be provided at the time of a
warranty claim or service, any work carried out on the cleaner
is chargeable.
The repair of the cleaner under this warranty does not extend
the original period of warranty.
The benefits conferred by this warranty are in addition to
all other rights and remedies in respect of the product as
outlined under the Competition and Consumer Act and other
State and Territory laws.
“Our goods come with guarantees that cannot be
excluded in the Australian Consumer Law. You are entitled
to a replacement or refund for a major failure and for
compensation for any other reasonably foreseeable loss or
damage. You are also entitled to have the goods repaired or
replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.”
Conditions of warranty
V4 2/22
Call Godfreys Customer Care
with any product queries
Australia 1800 815 270
New Zealand 0800 282 288
To find out more about our range,
visit: www.godfreys.com.au
www.godfreys.co.nz
email: [e-mail]
Pure Fresh S40
Stick Vacuum
