i3 International Cortex S243 User manual

www.i3international.com
1.866.840.0004
CANADA 780 Birchmount Road,
Unit 16, Scarborough
ON, M1K5H4
U.S.A. 4450 Witmer Industrial Estates,
Unit 4, Niagara Falls,
NY, 14305
Rev:170215
S243
USER MANUAL
PoE Managed Switch for video surveillance networks

1
Safety Warning
Purpose
This manual gives specific information on how to operate and use the management functions of this switch.
Audience
This manual is intended for use by netowrk administrators who are responsible for operating and maintaining network
equipments; consequently, it assumes a basic working knowledge of general switch functions, the Internet Protocol (IP),
IEEE 802.3at/af Power over Ethernet Standard and Simple Network Management Protocol(SNMP).
FCC Warning
This device has been tested and found to comply with limits for a Class A digital device, pursuant to Part 15 of FCC
Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates and radiates radio frequency energy and, if not
installed and used in accordance with the user’s manual, it may cause interference in which case users will be
required to correct interference at their own expenses.
CE Warning
This is a CE certificated product. In a domestic environment, this product may cause radio interference in which case the
user may be required to take adequate measures.
Revision Date:170215

2
Table of Contents
Safety Warning ............................................................................................................................................ 1
Purpose............................................................................................................................................... 1
Audience ............................................................................................................................................. 1
FCC Warning........................................................................................................................................ 1
CE Warning.......................................................................................................................................... 1
Chapter 1 INTRODUCTION................................................................................................................. 8
Product Overview ................................................................................................................................ 8
Specifications...................................................................................................................................... 8
Package Contents.............................................................................................................................. 11
Chapter 2 HARDWARE DESCRIPTION .............................................................................................. 12
Front Panel........................................................................................................................................ 12
LED Indicators ................................................................................................................................... 12
Rear Panel......................................................................................................................................... 12
Connecting Power ............................................................................................................................. 12
Power ON/OFF Device ....................................................................................................................... 12
Installing Equipment .......................................................................................................................... 13
Network Connections ........................................................................................................................ 13
1000Base-T Ports ............................................................................................................................. 13
SFP Transceiver Slots ........................................................................................................................ 13
Installing an Optional SFP Transceiver................................................................................................ 13
Making Network Connections ............................................................................................................ 14
1000BASE-T Cable Requirements...................................................................................................... 14
Cable labelling and Connection Records ............................................................................................ 15
Troubleshooting................................................................................................................................. 15
Troubleshooting Chart........................................................................................................................ 16
Power and cooling problems ............................................................................................................. 16
In-Band Access ................................................................................................................................. 16
Chapter 3 WEB MANAGEMENT ......................................................................................................... 17
Switch Configuration ......................................................................................................................... 17
System Configuration ........................................................................................................................ 18
System Information ................................................................................................................... 18
IP ADDRESS .............................................................................................................................. 19
Network Time Protocol (NTP)..................................................................................................... 21
Time ......................................................................................................................................... 21
Log ........................................................................................................................................... 23
Green Ethernet .................................................................................................................................. 24
Ports Configuration............................................................................................................................ 25
The Ports .................................................................................................................................. 25
Ports Description....................................................................................................................... 26
DHCP ................................................................................................................................................ 27
DHCP Server Mode.................................................................................................................... 27
DHCP Server Excluded IP .......................................................................................................... 28
DHCP Server Pool...................................................................................................................... 29
DCHP Snooping......................................................................................................................... 30
DHCP Relay............................................................................................................................... 30
Security............................................................................................................................................. 31
Security Users........................................................................................................................... 32
Security Privilege Level ............................................................................................................. 33
Authentication Method .............................................................................................................. 34

3
Access Management................................................................................................................. 34
SNMP........................................................................................................................................ 35
SNMP System ........................................................................................................................... 35
SNMP TRAP .............................................................................................................................. 36
SNMP Communities .................................................................................................................. 38
SNMP Users.............................................................................................................................. 38
SNMP GROUP............................................................................................................................ 40
SNMP VIEWS............................................................................................................................. 41
SNMP Access............................................................................................................................ 41
SNMP Trap Event Severity ......................................................................................................... 43
RMON ............................................................................................................................................... 43
RMON Statistics ........................................................................................................................ 43
RMON History ........................................................................................................................... 44
RMON Alarm ............................................................................................................................. 45
RMON Event.............................................................................................................................. 46
Network ............................................................................................................................................ 46
Limit Control ............................................................................................................................. 46
Network Access Server (NAS) ............................................................................................................ 48
Access Control List (ACL)................................................................................................................... 54
ACL Ports.................................................................................................................................. 54
ACL Rate Limiters .....................................................................................................................55
Access Control List.................................................................................................................... 56
IP Source Guard Configuration........................................................................................................... 58
Static Table. .............................................................................................................................. 59
ARP Inspection .................................................................................................................................. 59
VLAN Configuration ................................................................................................................... 61
Static ARP Inspection Table ....................................................................................................... 61
Dynamic ARP Inspection Table................................................................................................... 62
Authentication, Authorization, and Accounting (AAA) .......................................................................... 63
RADIUS ..................................................................................................................................... 63
AAA TACACS+ ........................................................................................................................... 65
AGGREGATION ................................................................................................................................... 66
Static Trucking .......................................................................................................................... 66
LACP ................................................................................................................................................. 67
Loop Protection ................................................................................................................................. 68
Spanning Tree ................................................................................................................................... 69
Bridge Setting ........................................................................................................................... 70
Spanning Tree MSTI Mapping.................................................................................................... 71
Spanning Tree MSTI Priorities.................................................................................................... 72
Spanning Tree CIST Ports .......................................................................................................... 73
Spanning Tree MSTI Ports ......................................................................................................... 75
IPMC Profile .............................................................................................................................. 76

4
IPMC Address Entry................................................................................................................... 77
MVR .................................................................................................................................................. 78
IGMP Snooping ......................................................................................................................... 80
IGMP Snooping VLAN Configuration ........................................................................................... 81
Port Filtering Profile................................................................................................................... 83
MLD Snooping .......................................................................................................................... 83
MLD Snooping VLAN ................................................................................................................. 85
Port Group Filtering ................................................................................................................... 86
Link Layer Discovery Protocol (LLDP)................................................................................................. 87
LLDP-MED Configuration........................................................................................................... 89
PoE ................................................................................................................................................... 93
PoE Power Delay ....................................................................................................................... 95
PoE Scheduling ......................................................................................................................... 96
PoE Auto Checking. ................................................................................................................... 97
MAC Table ......................................................................................................................................... 98
VLANs ............................................................................................................................................... 99
Private VLANs.................................................................................................................................. 102
Private VLAN Port Isolation ...................................................................................................... 102
MAC-Based VLAN (VCL) ................................................................................................................... 103
Protocol-based VLAN............................................................................................................... 104
Protocol to Group .................................................................................................................... 104
Group to VLAN......................................................................................................................... 105
IP Subnet-based VLAN ............................................................................................................ 106
VOICE VLAN ..................................................................................................................................... 107
OUI.......................................................................................................................................... 108
QoS................................................................................................................................................. 109
QoS Port Classification ............................................................................................................ 109
QoS Port Policing..................................................................................................................... 110
Qos Port Schedulers................................................................................................................ 111
QoS Port Shaping .................................................................................................................... 113
QoS Port Tag Remarking.......................................................................................................... 115
QoS Port DSCP........................................................................................................................ 117
DSCP-Based QoS .................................................................................................................... 118
QoS DSCP Translation ............................................................................................................. 118
QoS DSCP Classification.......................................................................................................... 119
QoS Control List Configuration................................................................................................. 121
QoS Storm Control .................................................................................................................. 123
Mirror.............................................................................................................................................. 124
Universal Plug and Play (UPnP) ........................................................................................................ 125
GVRP............................................................................................................................................... 126
GVRP Global Configuration ...................................................................................................... 126
GVRP Port Configuration.......................................................................................................... 127

5
sFLOW ............................................................................................................................................ 127
STMP Configuration......................................................................................................................... 129
Chapter 4 Monitor................................................................................................................ 131
System............................................................................................................................................ 131
Information ............................................................................................................................. 131
IP Status ................................................................................................................................. 132
System Log............................................................................................................................. 133
System Detailed Log ............................................................................................................... 134
System Overview .................................................................................................................... 134
Green Ethernet ................................................................................................................................ 135
Port Power Savings ................................................................................................................. 135
Ports ............................................................................................................................................... 136
Ports Traffic Overview ............................................................................................................. 136
QoS Statistics.......................................................................................................................... 136
Ports QoS Control List (QCL) Status ......................................................................................... 137
Ports Detailed Statistics .......................................................................................................... 138
SFP Information............................................................................................................................... 140
DHCP .............................................................................................................................................. 141
DHCP Server ........................................................................................................................... 141
DHCP Statistics ....................................................................................................................... 141
DHCP Server Binding IP........................................................................................................... 142
DHCP Server Declined IP ......................................................................................................... 143
Dynamic DHCP Snooping Table ............................................................................................... 143
DHCP Relay Statistics.............................................................................................................. 143
DHCP Detailed Statistics ......................................................................................................... 145
Security........................................................................................................................................... 146
Access management Statistics................................................................................................ 146
Network Port Security Switch .................................................................................................. 146
Port Security ........................................................................................................................... 148
NAS Switch Status .................................................................................................................. 149
NAS Port Status....................................................................................................................... 149
ACL Status .............................................................................................................................. 150
ARP Inspection........................................................................................................................ 151
IP Source Guard ...................................................................................................................... 152
AAA RADIUS Overview............................................................................................................. 152
AAA Radius Details.................................................................................................................. 153
Switch RMON Statistics........................................................................................................... 157
RMON History Overview .......................................................................................................... 158
RMON Alarm ........................................................................................................................... 159
RMON Event............................................................................................................................ 160
LACP ............................................................................................................................................... 161

6
LACP System Status................................................................................................................ 161
LACP Port Status..................................................................................................................... 161
LACP Port Statistics................................................................................................................. 162
Loop Protection ............................................................................................................................... 163
Spanning Tree ................................................................................................................................. 163
Bridge Status .......................................................................................................................... 163
Spanning Tree Port Status ....................................................................................................... 164
Spanning Tree Port Statistics................................................................................................... 165
MVR ................................................................................................................................................ 165
Statistics................................................................................................................................. 165
MVR Channel Groups .............................................................................................................. 166
MVR SFM Information ............................................................................................................. 167
IPMC ............................................................................................................................................... 168
IGMP Snooping ....................................................................................................................... 168
Group Information ................................................................................................................... 169
IPV4 SFM Information.............................................................................................................. 169
MLD Snooping ........................................................................................................................ 170
MLD Snooping Group Information............................................................................................ 171
IPv6 SFM Information .............................................................................................................. 172
LLDP ............................................................................................................................................... 173
Neighbor................................................................................................................................. 173
LLDP MED Neighbor................................................................................................................ 174
LLDP PoE ................................................................................................................................ 176
LLDP EEE ................................................................................................................................ 176
LLDP Port Statistics................................................................................................................. 177
LLDP PoE Statistics ................................................................................................................. 179
MAC Table ....................................................................................................................................... 180
VLANS............................................................................................................................................. 181
VLAN Membership .................................................................................................................. 181
VLAN PORT Status................................................................................................................... 182
VCL ................................................................................................................................................. 183
MAC-based VLAN.................................................................................................................... 183
Protocol-based VLAN Protocol to Group ................................................................................... 184
Group to VLAN......................................................................................................................... 185
IP Subnet-based VLAN ............................................................................................................ 185
sFlow .............................................................................................................................................. 186
Chapter 5 Diagnostics .................................................................................................................. 188
Ping ................................................................................................................................................ 188
Ping6 .............................................................................................................................................. 188
Cable Diagnostics............................................................................................................................ 189
Traceroute....................................................................................................................................... 190
Chapter 6 Maintenance .................................................................................................................. 191
Restart Device................................................................................................................................. 191
Reboot Schedule ............................................................................................................................. 191

7
Factory Defaults .............................................................................................................................. 192
Configuration................................................................................................................................... 193
Save startup-config................................................................................................................. 193
Download................................................................................................................................ 193
Upload .................................................................................................................................... 194
Activate................................................................................................................................... 194
Delete ..................................................................................................................................... 195
Server Report .................................................................................................................................. 195
Chapter 7 Device Management System (DMS).................................................................................... 196
Management.............................................................................................Error! Bookmark not defined.
DMS Mode ....................................................................................... Error! Bookmark not defined.
Management Device List......................................................................................................... 197
DMS Graphic Monitoring.................................................................................................................. 198
Topology View ......................................................................................................................... 198
Floor View ............................................................................................................................... 199
Map View ................................................................................................................................ 200
DMS Maintenance ........................................................................................................................... 201
Floor Image............................................................................................................................. 201
Diagnostics Trouble Shooting .................................................................................................. 202
Traffic Monitor......................................................................................................................... 203

8
Chapter 1 INTRODUCTION
Product Overview
Introducing i3 International’s new 24 port Power over Ethernet switch. The S243 is a next generation L2 Managed PoE
switch offering a full suite of L2 features, additional RJ45/SFP combo uplink connections, better PoE functionality and
usability including advanced L3 features such as Static Route that delivers better cost performance and lower total cost of
ownership. This switch is made for megapixel and IP Camera installations using high performance Gigabit Power-over-
Ethernet (PoE).
This chapter provides an overview of the S243 switch, and introduces the key features and supported specifications of this
PoE Web Smart switch.
Specifications
Port Connections
24 10M/100M/1G RJ45 Connector Ports
2 RJ45/SFP Gigabit Combo ports
1 RJ45 console port
PoE Function
Supports IEEE802.3at (PoE+ 30W)
Supports IEEE802.3af (PoE 15.4W)
PoE ports: 24
PoE Budget: 370 Watts
Hardware Performance
Forwarding Capacity: 38.68Mpps
Switching Capacity: 52Gbps
Mac Table: 8K
Jumbo Frames: 9216 Bytes
Environment
Operating Temperature: 0 to 45℃(32 to 113 °F)
Storage Temperature: -20 to 70°C (-4 to 158 °F)
Humidity: 10 to 90% RH (non-condensing)
Mechanism
Dimensions: 442 x 211x 44 mm (L x W x H) (17 ½ x 8 ⅜x 1 ¾ inches)
Weight 3.3 Kg (7.3 lbs.)
Power Supply
AC input: 100-240VAC, 50~60Hz
Maximum Power Consumption: 521 Watts (PoE power included)
Certifications
CE, FCC Part 15 Class A UL
Layer 2 Management Features
Spanning Tree Protocol (STP)
Standard Spanning Tree 802.1d
Rapid Spanning Tree (RSTP) 802.1w
Multiple Spanning Tree (MSTP) 802.1s
Trunking
Link Aggregation Control Protocol (LACP IEEE 802.3ad
Up to 13 groups
Up to 4 ports per group
VLAN
Supports up to 4k VLANs simultaneously (out of 4096 VLAN IDs)
Port-based VLAN
802.1Q tag-based VLAN
MAC-based VLAN
Management VLAN
Private VLAN Edge (PVE)
Q-in-Q (double tag) VLAN
Voice VLAN
GARP VLAN Registration Protocol (GVRP)
DHCP Relay
Relay of DHCP traffic to DHCP server in different VLAN.
Works with DHCP Option 82
IGMP v1/v2/v3 Snooping
IGMP limits bandwidth-intensive multicast traffic to only the requesters.
Supports 1024 multicast groups
IGMP Querier
IGMP querier is used to support a Layer 2 multicast domain of snooping
switches in the absence of a multicast router
IGMP Proxy
IGMP snooping with proxy reporting or report suppression actively filters

9
IGMP packets in order to reduce load on the multicast router
MLD v1/v2 Snooping
Delivers IPv6 multicast packets only to the required receivers
Device Management System (DMS)
Graphical Monitoring
Topology view: Support intuitive way to configure and manage
switches and devices with visual relations
Floor view: It’s easy to drag and drop PoE devices and help you to build
smart workforces
Map view: Enhance efficiency to drag and drop devices and monitor
surroundings on google map
Traffic Monitoring
Display visual chart of network traffic of all devices and monitor every port
at any time from the switch.
Trouble Shooting
Network diagnostic between master switch and devices
Support protection mechanism, such as rate-limiting to protect your
devices from brute-force downloading
Layer 3 Switching
IPv4 Static Routing
IPv4 Unicast: Static routing
IPv6 Static Routing
IPv6 Unicast: Static routing
Security
Secure Shell (SSH)
SSH secures Telnet traffic in or out of the switch, SSH v1 and v2 are
supported.
Secure Sockets Layer (SSL)
SSL encrypts the HTTP traffic, allowing advanced secure access to the
browser-based management GUI in the switch.
IEEE 802.1X
IEEE802.1X: RADIUS authentication, authorization and accounting,
MD5 hash, guest VLAN, single/multiple host mode and single/multiple
sessions
Supports IGMP-RADIUS based 802.1X
Dynamic VLAN assignment
Layer 2 Isolation Private VLAN Edge
PVE (also known as protected ports) provides L2 isolation between clients in
the same VLAN. Supports multiple uplinks.
Port Security
Locks MAC addresses to ports and limits the number of learned MAC
addresses
IP Source Guard
Prevents illegal IP address from accessing to specific port in the switch.
RADIUS/ TACACS+
Supports RADIUS and TACACS+ authentication. The switch as client
Storm Control
Prevents traffic on a LAN from being disrupted by broadcast, multicast, or
unicast storm on a port.
DHCP Snooping
A feature acts as a firewall between untrusted hosts and trusted DHCP
servers
ACLs
Supports up to 256 entries. Drop or rate limitation based on:
Source and destination MAC, VLAN ID or IP address, protocol, port,
Differentiated services code point (DSCP) / IP precedence
TCP/ UDP source and destination ports
802.1p priority
Ethernet type
Internet Control Message Protocol (ICMP) packets
TCP flag
Quality of Service
Hardware Queue
Supports 8 hardware queues
Scheduling
Strict priority and weighted round-robin (WRR)
Queue assignment based on DSCP and class of service
