i3-TECHNOLOGIES i3TOUCH Premium P6505 T10 User manual

Premium
Installation Manual
Model no.
P6505 T10
P7505 T10

2| Learn more about i3TOUCH and other product in the i3 line? Visit www.i3-learning.com
Wall mount Installation Guide
Step 1: Choose the siding appropriate for mounting.
The thickness of siding is 5 cm at least or above.
Please confirm the material and strength of the wall is appropriate for mounting.
Use the expansion bolts (B) to fix the hanging bracket (A) on the wall.
Step 2 : Mounting the hanging profiles (C) on the display.
Please power off the display between mounting.
Use screws to fix the hanging plate (C) on the display.
Screw D
PHW M6* L18mm, 4 PCS
For 42"~55"
Screw E
PHW M8*L18mm, 4 PCS
For 65"~80"
B
A
C
