IAdea PSP-108 User manual

2
IAdea PSP 8-Port True 4K Advanced HDMI Splitter Solution
Copyright© 2019 IAdea all rights reserved
Package content:
Smart splitter Power adapter Instruction Sheet

3
IAdea 8-Port True 4K Advanced HDMI Splitter Solution
Copyright© 2019 IAdea all rights reserved
Physical views and features:

4
IAdea PSP 8-Port True 4K Advanced HDMI Splitter Solution
Copyright© 2019 IAdea all rights reserved
1Power LED: Visible light indicates splitter is ready for use.
2
3
EDID Mode: Choose splitter performance by adjusting rotary switch.
(See next page for rotary switch settings)
4
Signal LED: Visible light indicates input is recognized by splitter.
5
HDMI-In: Input to connect splitter to a HDMI source.
6
Output LED: Indicators which corresponds to each HDMI-Out.
7HDMI-Out 1-8: Outputs to HDMI-compatible displays.
1 3 42 5
6
8
Micro-USB Port: Support for rmware update.
85 V DC Port: Input to connect splitter to the 5 V DC power supply.
7

5
IAdea 8-Port True 4K Advanced HDMI Splitter Solution
Copyright© 2019 IAdea all rights reserved
Rotary Switch Description
0Ultra HD (4K2K @ 60) - 8 / 10 / 12 bit 3D HDR video & 7.1
CH audio
1Ultra HD (4K2K @ 60) - 8 / 10 / 12 bit 3D HDR video & 2 CH
audio
2Ultra HD (4K2K @ 30) (4K2K @ 60 4:2:0) - 8 / 10 / 12 bit 3D
HDR video & 7.1 CH audio
3Ultra HD (4K2K @30) (4K2K @ 60 4:2:0) - 8 / 10 / 12 bit 3D
HDR video & 2 CH audio
4 Full HD (1080p @ 60) - 12 bit 3D video & 7.1 CH audio
5 Full HD (1080p @ 60) - 8 bit 2D video & 2 CH audio
6 Learning EDID from output 1
7
Automatic EDID analysis learning mode
(Detect and analyze the EDID content of the all connected
HDMI-compatible displays and the display with the highest
resolution will be used as the main EDID reference for all
incoming HDMI-compatible displays)

6
IAdea PSP 8-Port True 4K Advanced HDMI Splitter Solution
Copyright© 2019 IAdea all rights reserved
Installation:
How to broadcast one HDMI signal to eight HDMI-compatible displays?
1Power down all devices intended for use, including the HDMI-compatible
displays which will be connected to HDMI-Out 1-8.
2Connect the HDMI-compatible displays to HDMI-Out 1-8.
3Connect the splitter to a HDMI source, such as a Blu-ray Disc player, to
the HDMI-In.
4Connect the splitter to the supplied 5 V DC power supply.
5Power on the connected HDMI-compatible displays.
6Power on the connected HDMI source.

7
IAdea 8-Port True 4K Advanced HDMI Splitter Solution
Copyright© 2019 IAdea all rights reserved
Troubleshooting:
To ensure proper video outputs from the splitter, the user needs to make sure
the following splitter implementation requirements are satised:
1
2
1
2
3
Set to Full HD (1080p @ 60) - 8 bit 2D video & 2 CH audio
Set the rotary switch to "Mode 5."
Restart the splitter.
Set to Learning EDID from output 1
Set the rotary switch to "Mode 6."
Restart the splitter.
Splitter will automatically learn EDID settings.
1
2
3
Connected HDMI-compatible displays support Full HD videos.
Connected HDMI-compatible display with the lowest resolution must be
connected to HDMI-Out 1.
Restart the splitter after every adjustment made to the EDID rotary switch.
If the splitter continues to project inaccurate video outputs, even when the
requirements above are satised, the users are recommended to go through
the steps below to troubleshoot this issue.

8
IAdea PSP 8-Port True 4K Advanced HDMI Splitter Solution
Copyright© 2019 IAdea all rights reserved
To update splitter rmware, follow the steps below (applicable in any mode):
1
2
3
Save the rmware le (.bin) and update software in a folder.
Connect the splitter to PC via Micro-USB port.
Execute the update software and the splitter will automatically start
updating its rmware.
4
5
When the "Success" notication appears, rmware update is com-
plete and the update software will close automatically.
Restart the splitter and it will be ready for use.
Important Information:
1
2
3
HDR = High Dynamic Range
The video bandwidth of 4K2K @ 60 4:2:0 10 bits (HDR) is 384 MHz, and
the 4K2K @ 60 4:4:4 8 bits is 594 MHz.
PSP-108 does not support the following functions:
4PSP-108 can bypass 4K HDR data content but, CANNOT process it and
make HDR content completely t into 1080p.
1
2
3
Resolution downscaling from 4K2K @ 60 4:2:2 to 1080p.
4K2K @ 60 4:2:2 to 4K2K @ 60 4:2:0.
Frame rate conversion.

9
IAdea 8-Port True 4K Advanced HDMI Splitter Solution
Copyright© 2019 IAdea all rights reserved
Technical Specication:
PSP-108 Functions
HDMI compliance HDMI 2.0a
HDCP compliance HDCP 2.2 / 1.4
Input HDMI x 1
Output HDMI x 8
HDMI connector Type A (19-pin female)
Video bandwidth Single-link 600 MHz (18 Gbps)
Video support HDR 4K2K @ 60 (4:2:0 10 bits)
/ 4K2K @ 60 (4:4:4 8 bits)
Audio support DTS-HD Master Audio, Dolby TrueHD Dolby Digital,
DTS, DVD-Audio, LPCM, SACD, MPCM
Rotary switch EDID mode selection
ESD protection Human body level
(± 15 kV air-gap discharge & ± 8 kV contact discharge)
Firmware update Via Micro-USB port

10
IAdea PSP 8-Port True 4K Advanced HDMI Splitter Solution
Copyright© 2019 IAdea all rights reserved
PSP-108 Mechanical
Dimension
System 232 mm x 68 mm x 23 mm
(9.1" x 2.7" x 0.9")
Package 325 mm x 196 mm x 92 mm
(12.7" x 7.7" x 3.6")
Weight
System 439 g (0.97 lb)
Package 805 g (1.78 lb)
Housing Metal enclosure
Power supply 5 V / 2 A DC
Power connector Power adapter
Power consumption 7 W (max)
Operation temperature 0 ~ 40° C (32 ~ 104° F)
Storage temperature -20 ~ 60° C (-4 ~ 140° F)
Humidity 20 ~ 90 % RH (no condensation)
Accessory Instruction sheet
