IAP FAN-DM-1HP-110-220V-1P User manual

Extraction Fans
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the
product described. The continual observance of these procedures will help increase your production and extend the life of the
equipment.
Operations manual

Extraction Fans
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the
product described. The continual observance of these procedures will help increase your production and extend the life of the
equipment.
1
Table of Contents
Parts Description...................................................................................................................... 2
Specifications........................................................................................................................... 3
Dimensions (in inches) ............................................................................................................. 3
Safety Instructions of Extractions Fans ...................................................................................... 4
Electrical Installation ................................................................................................................5
Electric Circuit Diagram ............................................................................................................6
Assembly............................................................................................................................... 10
Parts Diagram........................................................................................................................ 12
Parts List ............................................................................................................................... 13
Contact Information ............................................................................................................... 14

Extraction Fans
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the
product described. The continual observance of these procedures will help increase your production and extend the life of the
equipment.
2
Parts Description
Refer to the following figures and descriptions to better understand the instructions in this manual.
1 HP, 1.5 HP, 2 HP or 3HP Motor
Square to round outlet
Aluminum impeller
in steel housing
Converter tube
Inlet
Wall mounting bracket

Extraction Fans
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the
product described. The continual observance of these procedures will help increase your production and extend the life of the
equipment.
3
Specifications
Model type
Motor
Nominal
Airflow
[cfm]
Machine Dimension
Inlet Ø
[inches]
Outlet Ø
[inches]
Supply
Power
FAN-DM-1HP-110-220V-1P
1HP
600
20.8" x 17.4" x 16.4"
4
6
110V or 220V/60Hz/1Ph
FAN-DM-1.5HP-110-220V-1P
1.5HP
900
19.9" x 18.9" x 17.5"
6
6
110V or 220V/60Hz/1Ph
FAN-DM-2HP-110-220V-1P
2HP
1600
21.5" x 20.5" x 17.5"
8
8
110V or 220V/60Hz/1Ph
FAN-DM-3HP-3P
3HP
1900
21.5" x 20.5" x 21.85
8
8
208-230V or 460V/60Hz/3Ph
Dimensions (in inches)
W
L W
H H
L

Extraction Fans
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the
product described. The continual observance of these procedures will help increase your production and extend the life of the
equipment.
4
Safety Instructions of Extractions Fans
DANGER: Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation which, if not avoided, will result in minor or moderate injury.
NOTE: Alerts the user to useful information about proper operation of the machine to avoid machine damage.
WARNING: To reduce your risk of serious injury, read
this Manual carefully before operating the product and
preserve the Operation Manual properly.
•Keep children, the elderly, handicapped people, and
others who are not familiar with this piece of
equipment away from it during operation.
•Safely store all tools when not in use. Store tools in a
dry safe place to inhibit rust. Always lock up tools and
keep them out of reach of children and others.
•Always use common sense and exercise caution. Do not
operate under the influence of drugs or alcohol, when
tired, or when distracted.
•Do not wear loose fitting clothing or jewelry as they can
be caught in moving machine parts. Use proper welding
clothing and eye protection when using this product for
welding fume extraction.
•Keep work area clean and organized. Cluttered areas
can be unsafe and dangerous during operation.
•Ensure that the working environment is suitable for this
machine. Do not use this product in areas that are wet,
cluttered, or have poor lighting.
WARNING: To reduce the risk of accidental injury,
never leave machine running while unattended.
•Check for damaged parts before using machinery.
Repair or replace any damaged parts before operation.
•Do not clean, repair, or replace any parts unless power
to the machine is off.
•Replace the damaged parts by the instructions of the
manual. If the said instructions are not specified in the
manual, then contact your dealer.
•If the machine breaks down, contact your dealer
immediately. Do not attempt to repair to avoid
damaging the machine.
•All wires used by the product shall be safely located to
prevent personal contact with the wires.

Extraction Fans
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the
product described. The continual observance of these procedures will help increase your production and extend the life of the
equipment.
5
•Do not drag the electrical wires with force and do not
use the wires if frayed or current leakage occurs to
avoid harming the operator.
NOTE: The original manufacturer’s parts and accessories
shall be used to avoid injuries from occurring. If any
problem happens, contact your dealer immediately.
•Keep machine away from oil, chemicals or flammables,
as sparks may ignite these materials and cause
explosion.
•When the fan blades are operated at high-speed, do
not reach hand near these blades to prevent finger
from breaking or clothes/necktie from getting caught.
•Do not put hand or foreign matter into the air inlet to
avoid getting caught due to the high- speed rotation of
fan blades.
Electrical Installation
•Check if the voltage, phase count and earth wire fit the
machine.
•Inspect power and control cables periodically. Replace
if damaged or bare wires are exposed.
•Be sure to follow local electrical codes and the
electrical safety standards when connecting the
machine.
CAUTION: For your safety, all electrical wire
connections and installation shall be carried out by a
professional technician.
•In the event of certain malfunctions or breakdowns,
grounding provides a path of least resistance for
electric current to reduce the risk of electric shock.
•Before connecting the electric cord, make sure the
switch is in the “OFF” position.
WARNING: If machine is not properly grounded and
connected to power supply, can result in risk of electric
shock.

Extraction Fans
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the
product described. The continual observance of these procedures will help increase your production and extend the life of the
equipment.
6
Electric Circuit Diagram

Extraction Fans
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the
product described. The continual observance of these procedures will help increase your production and extend the life of the
equipment.
7

Extraction Fans
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the
product described. The continual observance of these procedures will help increase your production and extend the life of the
equipment.
8

Extraction Fans
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the
product described. The continual observance of these procedures will help increase your production and extend the life of the
equipment.
9

Extraction Fans
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the
product described. The continual observance of these procedures will help increase your production and extend the life of the
equipment.
10
Assembly
WARNING: Read and understand all of the precautions
stated in the Manual, and for your safety, do not connect
the Extraction Fan before the assembly is finished.
The machine must be fully assembled before it can be
operated.
Before beginning the assembly process, check if the machine
and components are consistent with those indicated in the
Parts List.
If any doubt arises or when the components are incomplete,
please contact your dealer.
NOTE: For correct assembly, refer to the Illustrations and
Parts List on pages 10-13.
Option 1 (without converter tube)
1. Using the appropriate hardware, secure the wall mount
bracket using the pre-drilled holes in the bracket.
2. Use attached hardware, install fan and fume arm
together with wall mount bracket.
3. Use attached hardware, install outlet onto the fan.

Extraction Fans
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the
product described. The continual observance of these procedures will help increase your production and extend the life of the
equipment.
11
Option 2 (with converter tube)
1. Using the appropriate hardware, secure the wall mount
bracket using the pre-drilled holes in the bracket.
2. Use attached hardware, install converter tube and fume
arm together with wall mount bracket.
3. Use attached hardware, install fan onto the converter
tube.
4. Use attached hardware, install outlet onto the fan.

Extraction Fans
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the
product described. The continual observance of these procedures will help increase your production and extend the life of the
equipment.
12
Parts Diagram

Extraction Fans
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the
product described. The continual observance of these procedures will help increase your production and extend the life of the
equipment.
13
Parts List
Item
Description
Qty.
1
Motor
1
2
Impeller Cover
1
3
Impeller
1
4
Main Body
1
5
Square to round outlet
1
6
Converter tube (optional)
1
7
Wall mounting bracket
1
8
Fume arm
1

Extraction Fans
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the
product described. The continual observance of these procedures will help increase your production and extend the life of the
equipment.
14
Contact Information
Industrial Air Purification, Inc.
580 Technology Drive
Sparta, TN 38583
Tel : [phone]
E-mail : [e-mail]
Website : www.IAP-AirProducts.com
