IP417
Mini-ITX COM Express Type 10 (R3.0)
Carrier Board
User’s Manual
Version 1.0
(July 2019)

ii
IP417 User’s Manual
Copyright
©2019 IBASE Technology, Inc. All rights reserved.
No part of this publication may be reproduced, copied, stored in a retrieval system,
translated into any language or transmitted in any form or by any means,
electronic, mechanical, photocopying, or otherwise, without the prior written
consent of IBASE Technology, Inc. (hereinafter referred to as “IBASE”).
Disclaimer
IBASE reserves the right to make changes and improvements to the products
described in this document without prior notice. Every effort has been made to
ensure the information in the document is correct; however, IBASE does not
guarantee this document is error-free.
IBASE assumes no liability for incidental or consequential damages arising from
misapplication or inability to use the product or the information contained herein,
nor for any infringements of rights of third parties, which may result from its use.
Trademarks
All the trademarks, registrations and brands mentioned herein are used for
identification purposes only and may be trademarks and/or registered trademarks
of their respective owners.

IP417 User’s Manual
iii
Compliance
In a domestic environment, this product may cause radio interference in which
case users may be required to take adequate measures.
This product has been tested and found to comply with the limits for a Class A
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with manufacturer’s instructions, may cause
harmful interference to radio communications.
WEEE
This product must not be disposed of as normal household
waste, in accordance with the EU directive of for waste
electrical and electronic equipment (WEEE - 2012/19/EU).
Instead, it should be disposed of by returning it to a
municipal recycling collection point. Check local
regulations for disposal of electronic products.
Green IBASE
This product is compliant with the current RoHS
restrictions and prohibits use of the following substances in
concentrations exceeding 0.1% by weight (1000 ppm)
except for cadmium, limited to 0.01% by weight (100 ppm).
•Lead (Pb)
•Mercury (Hg)
•Cadmium (Cd)
•Hexavalent chromium (Cr6+)
•Polybrominated biphenyls (PBB)
•Polybrominated diphenyl ether (PBDE)

iv
IP417 User’s Manual
Important Safety Information
Carefully read the precautions before using the board.
Environmental conditions:
•Use this product in environments with ambient temperatures between -20˚C
and 70˚C.
•Do not leave this product in an environment where the storage temperature
may be below -40°C or above 90°C. To prevent from damages, the product
must be used in a controlled environment.
WARNING.
Attention during use:
•Do not use this product near water.
•Do not spill water or any other liquids on this product.
•Do not place heavy objects on the top of this product.
Anti-static precautions
•Wear an anti-static wrist strap to avoid electrostatic discharge.
•Place the PCB on an anti-static kit or mat.
•Hold the edges of PCB when handling.
•Touch the edges of non-metallic components of the product instead of the
surface of the PCB.
•Ground yourself by touching a grounded conductor or a grounded bit of metal
frequently to discharge any static.
CAUTION
Danger of explosion if the internal lithium-ion battery is replaced by an incorrect
type. Replace only with the same or equivalent type recommended by the
manufacturer. Dispose of used batteries according to the manufacturer’s
instructions or recycle them at a local recycling facility or battery collection point.

IP417 User’s Manual
v
Warranty Policy
•IBASE standard products:
24-month (2-year) warranty from the date of shipment. If the date of shipment
cannot be ascertained, the product serial numbers can be used to determine
the approximate shipping date.
•3rd-party parts:
12-month (1-year) warranty from delivery for the 3rd-party parts that are not
manufactured by IBASE, such as CPU, CPU cooler, memory, storage
devices, power adapter, panel and touchscreen.
＊PRODUCTS, HOWEVER, THAT FAIL DUE TO MISUSE, ACCIDENT,
IMPROPER INSTALLATION OR UNAUTHORIZED REPAIR SHALL BE
TREATED AS OUT OF WARRANTY AND CUSTOMERS SHALL BE BILLED
FOR REPAIR AND SHIPPING CHARGES.
Technical Support & Services
1. Visit the IBASE website at www.ibase.com.tw to find the latest information
about the product.
2. If you need any further assistance fromyour distributor or sales representative,
prepare the following information of your product and elaborate upon the
problem.
•Product model name
•Product serial number
•Detailed description of the problem
•The error messages in text or in screenshots if there is any
•The arrangement of the peripherals
•Software in use (such as OS and application software, including the
version numbers)
3. If repair service is required, you can download the RMA form at
http://www.ibase.com.tw/english/Supports/RMAService/. Fill out the form and
contact your distributor or sales representative.

vi
IP417 User’s Manual
Table of Contents
Compliance.....................................................................................iii
Important Safety Information........................................................iv
Warranty Policy...............................................................................v
Technical Support & Services .......................................................v
Chapter 1 General Information.............................................1
1.1 Introduction .........................................................................................2
1.2 Features..............................................................................................2
1.3 Specifications......................................................................................3
1.4 Overview.............................................................................................5
1.5 Dimensions .........................................................................................6
Chapter 2 Hardware Configuration..........................................7
2.1 Setting the Jumpers.............................................................................8
2.2.1 How to Set Jumpers...............................................................8
2.2 Connector Locations on IP417.............................................................9
2.3 Jumpers Quick Reference.................................................................10
2.3.1 BIOS Boot Selection (JP1, JP9)..........................................10
2.3.2 COM1 RS-232 Power Selection (JP2).................................11
2.3.3 COM2 RS-232 Powr Selection (JP3)...................................11
2.3.4 PS/2 Mouse/Keyboard Power Selection (JP4).....................12
2.3.5 eDP / LVDS Function Setting (JP5).....................................12
2.3.6 LVDS Panel Power (JP6)....................................................12
2.3.7 eDP Panel Power (JP7).......................................................12
2.3.8 LVDS Backlight Power Selection (JP8)................................13
2.3.9 eDP Backlight Power Selection (JP10)................................13
2.3.10 AT / ATX Mode Selection (JP11).........................................13

IP417 User’s Manual
vii
2.4 Connectors Quick Reference.............................................................14
2.4.1 SATA HDD Power Connector (J1, J2).................................15
2.4.2 LVDS Panel Inverter Power Connector (J6).........................15
2.4.3 COM3 & COM4 Ports (J13, J8) ...........................................15
2.4.4 GPIO Connector (J17).........................................................16
2.4.5 System Function Connector (J11) .......................................16
2.4.6 DC-In 12V Power Connector (J14)......................................17
2.4.7 COM1 & COM2 Ports (CN2)................................................17
2.4.8 LVDS Connector (CN10).....................................................18
2.4.9 eDP Connector (CN15) .......................................................19
2.4.10 Fan Power Connector (CPU_FAN1)....................................19
Appendix........................................................................................21
A. Onboard Connector Types ................................................................22

viii
IP417 User’s Manual
This page is intentionally left blank.

1
Chapter 1
General Information
The information provided in this chapter includes:
•Features
•Specifications
•Board Overview
•Board Dimensions

2
IP417 User’s Manual
1.1 Introduction
IP417 is a carrier board for mini-ITX COM Express Type 10 (R3.0) CPU module. It
features expansion slots for a PCIe and two mini-PCIe slots and I/O interface for a
DP display, two RJ45, eight USB 3.0 and two USB 2.0 ports. It measures 170mm x
170mm.
COM Express Modules are designed for the needs of IoT embedded applications
including amusement gaming, ATM/POS, medical imaging, and industrial control,
these mini modules combine graphics and energy-efficient computing power to
handle various tasks.
Photo of IP417
1.2 Features
•1 x PCIe (x1), 2 x Mini-PCIe sockets (full-size & half-size)
•8 x USB 2.0, 2x USB 3.0
•Supports 1x eDP or 1x LVDS (depending on COMe module),
•1 x DisplayPort
•2 x LAN connectors

General Information
IP417 User’s Manual
3
1
1.3 Specifications
Product Name
IP417
Form Factor
Mini-ITX COM Express Type 10 (R3.0) carrier board
Super I/O
Fintek F81964D-I
Digital I/O
4-In / 4-Out
Watchdog
Watchdog Timer 256 segments, 0, 1, 2…255
sec/min
Dimensions
170 x 170 mm (6.69” x 6.69”)
RoHS
Yes
I/O Ports / Connectors
Power Supply
DC-In 12V via an onboard 2x2 pin connector
Display
Derived from COMe module ET875.
•1 x DisplayPort
•1 x 18/24-bit dual channel LVDS or 1 x eDP
(Choose either one)
LAN
2 x RJ45 LAN ports:
•LAN 1: Derived from COMe module
•LAN 2: from Intel I210IT
USB
Derived from COMe module ET875.
•8 x USB 2.0 (4 are edge I/O connectors, and 2
from onboard box-headers, .2 from mini-PCIe)
•2 x USB 3.0
Serial
4 x COM ports:
•COM1 & COM2: RS-232 (full-function)
(edge I/O connector)
•COM3 & COM4: RS-232 (TX and RX only)
(from the COMe module, via an on-board
box-headers)
Serial ATA
Derived from COMe module.
2 x SATA 3.0

4
IP417 User’s Manual
Audio Jacks
Onboard Realtek ALC662 with 5.1 channel HD
audio: 1 x Line-In, 1 x Line-Out, 1 x Mic-In
PS/2 Keyboard
& Mouse
•1 x PS/2 Keyboard port
•1 x PS/2 Mouse port
Battery for
RTC/CMOS
1 x Lithium battery button cell for RTC of COMe
module
Expansion
Slots
•1 x PCIe (x1) slot
•2 x Mini-PCIe slot
Environment
Temperature
•Operating: -40 ~ 85°C (-40 ~ -185°F)
•Storage: -40 ~ 90 °C (-40 ~ 194°F)
Relative
Humidity
10 ~ 90 % (non-condensing)
All specifications are subject to change without prior notice.

General Information
IP417 User’s Manual
5
1
1.4 Overview
Top View
I/O View
No.
Name
No.
Name
1
PS/2 Mouse Port
7
USB 2.0 Ports
2
PS/2 Keyboard Port
8
GbE LAN Ports
3
COM1 RS-232 Port
9
Microphone Input
4
COM2 RS-232 Ports
10
Audio Line-Out
5
USB 3.0 Port
11
Audio Line-In
6
DisplayPort
＊The photos above are for reference only. Some minor components may differ.

6
IP417 User’s Manual
1.5 Dimensions

7
Chapter 2
Hardware Configuration
This section provides information on jumper settings and connectors
on the board in order to set up a workable system.
•Jumper and connector locations
•Jumper settings and information of connectors

8
IP417 User’s Manual
2.1 Setting the Jumpers
Set up and configure your board by using jumpers forvarious settings and features
according to your needs and applications. Contact your supplier if you have doubts
about the best configuration for your use.
2.2.1 How to Set Jumpers
Jumpers are short-length conductors consisting of several metal pins with a
non-conductive base mounted on the circuit board. Jumper caps are used to have
the functions and features enabled or disabled. If a jumper has 3 pins, you can
connect either PIN1 to PIN2 or PIN2 to PIN3 by shorting.
Pin# 1 23
A 3-pin jumper
A jumper cap
Refer to the illustration below to set jumpers.
Pin closed
Oblique view
Schematic illustration
Open
1 2 3
1-2
1 2 3
2-3
1 2 3
When two pins of a jumper are encased in a jumper cap, this jumper is closed, i.e.
turned On.
When a jumper cap is removed from two jumper pins, this jumper is open, i.e.
turned Off.

Hardware Configuration
IP417 User’s Manual
9
2
2.2 Connector Locations on IP417
Board diagram of IP417

10
IP417 User’s Manual
2.3 Jumpers Quick Reference
Function
Jumper Name
BIOS Boot Selection
JP1, JP9
COM1 RS-232 Power Selection
JP2
COM2 RS-232 Powr Selection
JP3
PS/2 Mouse/Keyboard Power
Selection
JP4
eDP / LVDS Function Setting
JP5
LVDS Panel Power
JP6
eDP Panel Power
JP7
LVDS Backlight Power Selection
JP8
eDP Backlight Power Selection
JP10
AT / ATX Mode Selection
JP11
2.3.1 BIOS Boot Selection (JP1, JP9)
Pin closed
SPI_CS0#
SPI_CS1#
SPI0/FWH
JP9
JP1
1-2
1
1-2
1
Module
Module
SPI0 (default)
1-2
1
2-3
1
Module
Module
Carrier FWH
2-3
1
1-2
1
Carrier
Module
SPI0/SPI1
2-3
1
2-3
1
Module
Carrier
SPI0/SPI1

Hardware Configuration
IP417 User’s Manual
11
2
2.3.2 COM1 RS-232 Power Selection (JP2)
Function
Pin closed
Illustration
12V
1-3
65
21
Normal (default)
3-4
65
21
5V
3-5
65
21
2.3.3 COM2 RS-232 Powr Selection (JP3)
Function
Pin closed
Illustration
12V
1-3
65
21
Normal (default)
3-4
65
21
5V
3-5
65
21

12
IP417 User’s Manual
2.3.4 PS/2 Mouse/Keyboard Power Selection (JP4)
Function
Pin closed
Illustration
5VSB (default)
1-2
1
5V
2-3
1
2.3.5 eDP / LVDS Function Setting (JP5)
Function
Pin closed
Illustration
eDP (default)
1-2
1
LVDS
2-3
1
2.3.6 LVDS Panel Power (JP6)
Function
Pin closed
Illustration
3.3V (default)
1-2
1
5V
2-3
1
2.3.7 eDP Panel Power (JP7)
Function
Pin closed
Illustration
3.3V (default)
1-2
1
5V
2-3
1
